Alto4.5 TMO_5042T_UM_Eng_USA_rev1-49-64
95 96
Available options:
• Edit name Rename and customize channel name
• Save channel Save the current tuned station to the channels list.
• Audio mode Listen to the radio using loudspeaker or headset.
• Exit Turn off the radio.
• Enter frequency Enter the frequency manually.
• Delete Delete the channel
10.4 Setup Wizard ................................................................................
To access this function, touch the Applications icon from the Home screen, then touch Setup
Wizard.
Setup Wizard helps set up your phone in multiple ways: language, data connection, account setup,
etc. This will also be performed the first time you power on your phone.
10.5 Other applications(1) ............................................................................
The previous applications in this section are preinstalled on your phone. To read a brief introduction of
the preinstalled 3rd party applications, please refer to the leaflet provided with the phone. You can also
download thousands of 3rd party applications by going to Android Market on your phone.
(1) Application availability depends on country and operator.
11 Settings ..............................................
Drag down notification panel and touch to access Settings.
11.1 Wireless & networks
11.1.1 Wi-Fi
Using Wi-Fi you can now surf the Internet without using your SIM card whenever you are in range of a
wireless network. The only thing you have to do is to enter the Wi-Fi screen and configure an access
point to connect your phone to the wireless network.
For detailed instructions on using Wi-Fi, please refer to "6.1.2 Wi-Fi".
11.1.2 Bluetooth
Bluetooth allows your phone to exchange data (videos, images, music, etc.) within a small range with
another Bluetooth supported device (phone, computer, printer, headset, car kit, etc.).
For more information on Bluetooth, please refer to "6.3 Connecting to Bluetooth devices".
11.1.3 Data usage
To enable/disable mobile data, touch the switch.
By marking the checkbox of Set mobile data limit, you can then drag the limit line and the warning
line according to your preferred limits. Your mobile data connection will be disabled when the specified
limit is reached. You can also choose a data usage cycle to view the statistics and related applications
of your phone's data use.
Touch the Menu key , and you can view more settings related to your data usage.
Data usage is measured by your phone, and your carrier may count differently. Please consider
using a conservative limit.
97 98
11.1.4 Airplane mode
Mark the checkbox of Airplane mode you can simultaneously disable all wireless connections
including Wi-Fi, Bluetooth and more.
11.1.5 VPN
A mobile virtual private network (mobile VPN or mVPN) provides mobile devices with access to
network resources and software applications on their home network, when they connect via other
wireless or wired networks. Mobile VPNs are used in environments where workers need to keep
application sessions open at all times, throughout the working day, as the user connects via various
wireless networks, encounters gaps in coverage, or suspends-and-resumes their device to preserve
battery life. A conventional VPN cannot survive such events because the network tunnel is disrupted,
causing applications to disconnect, time out, fail, or even the computing device itself to crash.
For more information on VPN, please refer to "6.6 Connecting to virtual private networks".
11.1.6 Tethering & portable hotspot
This function allows you to share your phone's mobile data connection via USB or as a portable Wi-Fi
access point (Please refer to "6.5 Sharing your phone's mobile data connection").
11.1.7 Mobile networks
•Data connection
Touch to turn on/off data connection.
•Network mode
Touch to select network modes.
•Access Point Names
You can select your preferred network with this menu.
•Network operators
You can select a network operator.
11.2 Device
11.2.1 Gestures
Touch to select to enable the following gestures: Double tap to unlock, Turn over to mute, Turn
over to activate, Shake to switch music.
11.2.2 Sound
Use the Sound settings to configure volume and ringtones for different events and environments.
Volume
Volume settings helps the user to adjust the volume of ringtone, notifications, music, video and alarms,
etc., or directly set the incoming calls to vibration or silence.
• Phone Vibrate Marking the checkbox makes your phone vibrate when receiving incoming
calls.
• Silent mode Marking the checkbox silences phone for incoming calls.
Ringtone & Notifications
• Phone ringtone Touch to set your default phone ringtone.
• Crescendo ringtone Mark the checkbox to activate ascending ring.
• Notification sound Touch to set your default notification sound.
99 100
System
• Dial pad touch tones Mark the checkbox to enable tones when using the dial pad.
• Touch sounds Mark the checkbox to enable sounds when making screen selections.
• Screen lock sound Mark the checkbox to enable sounds to play when locking and unlocking
the screen.
• Vibrate on touch Mark the checkbox to activate vibration when pressing soft keys and with
certain UI interactions.
• Power on ringtone Set your default power on ringtone.
• Power off ringtone Set your default power off ringtone.
11.2.3 Display
• Wallpaper Touch to set the wallpaper.
• Split screen Touch to turn on/off split screen function.
• Automatic brightness Touch to adjust the brightness of the screen.
• Auto-rotation Touch to select whether rotate screen automatically or not.
• Sleep Touch to set the screen timeout.
• Font size Touch to set the font size.
• Color configuration Touch to adjust the color temperature and saturation.
11.2.4 Lock settings
Select screen lock
• Slide Touch to enable slide unlock mode.
• Pattern Touch to unlock your phone's screen by drawing a pattern.
• PIN Touch to unlock your phone's screen with a numeric PIN.
• Password Touch to unlock your phone's screen with a password.
• Face unlock Touch to unlock your phone's screen by looking at it.
• None Touch to disable screen unlock security.
Lock options
You may select message and components to be displayed on lock screen.
Change lock wallpaper
Touch to select lock wallpaper from Lockscreen wallpapers or Gallery.
Owner information
Touch to show owner info on lock screen.
11.2.5 Status bar
Touch the switch to show all notifications of 3rd party application on the left top of the status
bar.
101 102
11.2.6 Storage
Use these settings to manage your phone storage by monitoring the total and available space on your
phone.
If a warning message comes up saying that phone memory is limited, you are required to free
up space by deleting some unwanted applications, downloaded files, etc.
11.2.7 Battery
In the battery management screen you can view battery usage data since you last connected the phone
to a power source. The screen also shows your battery status and how long it has been used since last
charging. Touch one category to reveal its specific power consumption.
You can adjust power use by adjusting screen brightness or screen timeout in the Display screen.
11.2.8 Applications
You use the Apps settings to view details about the applications installed on your phone, to manage
their data and force them to stop, and to set whether you want to permit installation of applications
that you obtain from web sites and emails.
11.3 Personal
11.3.1 Location
Mode
•High accuracy
Select to use GPS, Wi-Fi and mobile networks when locating.
•Battery saving
Select to use Wi-Fi and mobile networks when locating.
•Device only
Select to use only GPS when locating.
11.3.2 Security
Guest mode
Turn on the switch to activate this function. After setting up your password this will lock any assigned
apps in order to ensure your privacy.
Set up SIM card lock
Mark the checkbox of Lock SIM card to lock the SIM card with a PIN code.
Touch Change SIM PIN to change the PIN code.
Make passwords visible
Mark the checkbox to show passwords as you type.
Device administrators
Touch to view or deactivate device administrators.
Unknown sources
Mark the checkbox to permit installation of applications that you obtain from websites, emails, or other
locations other than Google Play Store.
To protect your phone and personal data, download applications only from trusted sources, such as
Google Play Store.
Verify apps
Mark the checkbox to prevent or warn you before installing apps which might cause harm.
103 104
Trusted credentials
Touch to display trusted CA certificates.
Install from phone storage
Touch to install encrypted certificates from phone storage.
Clear credentials
Touch to remove all credentials.
11.3.3 Language & input
Use the Language & input settings to select the language for the text on your phone and for configuring
the onscreen keyboard. You can also configure voice input settings and the pointer speed.
Language
Touch to select the language and the region you want.
Spell checker
Mark the checkbox to enable the system to show suggested words.
User dictionary
Touch to open a list of the words you’ve added to the dictionary. Touch a word to edit or delete it.
Touch the add button (+) to add a word.
Default
Touch to select a default input method. Touch Set up input methods to show all input methods.
Touch the settings icon to configure a certain input method.
Android keyboard
The Android keyboard settings apply to the onscreen keyboard that is included with your phone. The
correction and capitalization features affect only the English version of the keyboard. Available options
are as follows:
• Input languages
Touch to set input language.
• Auto-capitalization
Mark the checkbox to have the onscreen keyboard automatically capitalize the first letter of the first
word after a period, the first word in a text field, and each word in name fields.
• Vibrate on keypress
Mark the checkbox to have the phone vibrate briefly each time you touch a key on the onscreen
keyboard.
• Sound on keypress
Mark the checkbox to play a brief sound each time you touch a key on the onscreen keyboard.
• Popup on keypress
Mark the checkbox to popup the key that you touched.
• Voice input key
Touch to select location to display voice input key.
•Personal dictionary
Touch to enter Personal dictionary.
•Add-on dictionaries
Touch to show all installed add-on dictionaries.
105 106
•Block offensive words
Mark the checkbox to block offensive words.
• Auto-correction
Touch to turn on/off auto correction, or you can also adjust the sensitivity of correction.
• Show correction suggestions
Touch to show or not the correction suggestions while typing.
• Next-word suggestions
Mark the checkbox to popup word suggestions.
• Advanced settings
Touch to view more advanced settings for android keyboard, such as Key long press delay, Suggest
Contact name, and etc.
Voice search
Touch to view settings about voice search, such as Language, Speech output, etc.
Text-to-speech output
• Preferred engine
Touch to choose a preferred text-to-speech engine, touch the settings icon to show more choices
for each engine.
• Speech rate
Touch to open a dialog where you can select how quickly you want the synthesizer to speak.
• Listen to an example
Touch to play a brief sample of the speech synthesizer, using your current settings.
Pointer speed
Touch to open a dialog where you can change the pointer speed. Touch OK to confirm.
11.3.4 Backup and reset
Back up my data
Mark the checkbox to back up your phone’s settings and other application data to Google servers, with
your Google account. If you replace your phone, the settings and data you’ve backed up are restored
onto the new phone the first time you sign in with your Google account. If you mark this option, a
wide variety of settings and data are backed up, including your Wi-Fi passwords, bookmarks, a list of the
applications you’ve installed, the words you’ve added to the dictionary used by the onscreen keyboard,
and most of the settings that you configure with the Settings application. If you unmark this option, you
stop backing up your settings, and any existing backups are deleted from Google servers.
Back up account
Touch to back up your account.
Automatic restore
Mark the checkbox to restore your backed up settings or other data when you reinstall an application.
DRM reset
Touch to delete all DRM licenses.
Factory data reset
Phone reset will erase all of your personal data from the internal phone storage, including information
about your Google account, any other accounts, your system and application settings, and any
downloaded applications. Resetting the phone does not erase any system software updates you’ve
downloaded or any files on your microSD card, such as music or photos. If you mark the checkbox -
Reserve the content of Phone storage before touching Reset phone, any files stored on your phone’s
storage will not be erased. If you reset the phone in this way, you’re prompted to re-enter the same
kind of information as when you first started Android.
When you are unable to power on your phone, there is another way to perform a factory data reset
by using hardware keys. Press the Volume up key and the power key at same time until the screen
lights up.
107 108
11.4 Accounts
Use these settings to add, remove, and manage your email and other supported accounts. You can
also use them to control details of the ways applications send, receive, and synchronize data; if this is
according to their own schedules; and whether all applications can synchronize user data automatically.
11.5 System
11.5.1 Date & time
Use Date & Time settings to customize your preferences for how date and time are displayed.
Automatic date & time
Touch to select Use network/GPS provided time or Off.
Mark the checkbox to use network-provided time or use GPS provided time.
Automatic time zone
Mark the checkbox to use the network-provided time zone. Or unmark to set all values manually.
Set date
Touch to open a dialog where you can manually set the phone’s date.
Set time
Touch to open a dialog where you can manually set the phone’s time.
Select time zone
Touch to open a dialog where you can set the phone’s time zone.
Use 24-hour format
Mark the checkbox to display the time using 24-hour clock format.
Select date format
Touch to open a dialog where you can select the format for displaying dates.
11.5.2 Scheduled power on & off
Touch to set the power on & off time for every day or specified days.
11.5.3 Accessibility
Accessibility settings can be used to configure any accessibility plug-ins you have installed on your
phone.
TalkBack
Touch to turn on/off TalkBack.
Captions
Touch to enter captions function, you can set Language, Text size and Caption style.
Magnification gestures
Touch to turn on/off and to activate/deactivate the zoom in/out function by triple-tapping the screen.
Speak passwords
Mark the checkbox to speak passwords while typing.
Touch supporting gloves
Mark the checkbox to enable/disable this function.
Accessibility shortcut
Touch to turn on/off to enable/disable accessibility features.
109 110
Touch & hold delay
Touch to adjust the duration of touch and hold delay. This function enables your phone to differentiate
between touch and touch & hold, which may avoid incorrect operations.
The Developer options screen contains settings that are useful for developing Android applications. For
full information, including documentation of the Android applications and development tools, see the
Android developer website (http://developer.android.com).
Desktop backup password
Touch to set/change/remove desktop full backup password.
Stay awake
Mark the checkbox to prevent the screen from dimming and locking when the phone is connected to
a charger or to a USB device that provides power. Don’t use this setting with a static image on the
phone for long periods of time, or the screen may be marked with that image.
Select runtime
Touch to select Dalvik or ART runtime for your phone.
Enable Bluetooth HCI snoop log
Mark the checkbox to capture all bluetooth HCI packets in a file.
USB debugging
Mark the checkbox to permit debugging tools on a computer to communicate with your phone via a
USB connection.
Revoke USB debugging authorization
Touch to revoke access to USB debugging from all computers you've previously authorized.
Power menu bug report
Mark the checkbox to include the option of submitting a bug report in the power menu.
Allow mock locations
Mark the checkbox to permit a development tool on a computer to control where the phone believes
it is located, rather than using the phone’s own internal tools for this purpose.
Select debug app
Touch to select debug app.
Wait for debugger
Mark the checkbox to wait for debugger to attach before executing for debugged apps.
Verify apps over USB
Mark the checkbox to check apps over USB.
TV Link certification
Mark the checkbox to show options for TV Link certification.
Show touches
Mark the checkbox to show visual feedback for touches.
Pointer location
Mark the checkbox to show current touch data.
Show surface updates
Mark the checkbox to show flash entire windows surfaces when they update.
111 112
Show layout bounds
Mark the checkbox to show clip bounds, margins, etc.
Force RTL layout direction
Mark the checkbox to force screen layout direction to RTL for all locales.
Show GPU view updates
Mark the checkbox to show GPU view updates.
Show hardware layers updates
Mark the checkbox to show hardware layers updates.
Debug GPU overdraw
Touch to debug GPU overdraw.
Debug non-rectangular clip operation
Touch to debug non-rectangular clip operation.
Window animation scale
Touch to adjust the animation scale for your window.
Transition animation scale
Touch to adjust the animation scale while performing a transition.
Animation duration scale
Touch to adjust the animation duration scale.
Simulate secondary displays
Touch to simulate secondary displays.
Disable HW overlays
Mark the checkbox to select to always use GPU for screen compositing.
Force GPU rendering
Mark the checkbox to enforce the use of 2D hardware acceleration in applications.
Force 4x MSAA
Mark the checkbox to enable 4x MSAA.
Strict mode enabled
Mark the checkbox to enable strict mode. Once enabled, the screen will flash when applications do
long operations on the main thread.
Show CPU usage
Mark the checkbox to show current CPU usage.
Profile GPU rendering
Mark the checkbox to use 2D hardware acceleration in applications.
Enable OpenGL traces
Touch to adjust OpenGL traces.
Don't keep activities
Mark the checkbox to destroy all activities as soon as you leave.
113 114
Background process limit
Touch to change the limit for background processes.
Show all ANRs
Mark the checkbox to show "Application Not Responding" dialogs for background applications.
11.5.4 About phone
This contains information on items ranging from legal information, model number, firmware version,
baseband version, kernel version, build number etc. related to the following:
System Updates
Touch to check for system updates.
System Updates (storage)
Touch to check for system updates (storage).
Status
This contains Battery status, Battery level, My phone number, Network, Signal strength, etc.
Legal information
Touch to view legal information.
12 Making the most of your phone ...........
FOTA updates
Using FOTA Upgrade tool you can update your phone's software.
To access System Updates, please open Notifications panel touch and touch , then press
About phone\System updates and Settings\About phone\System updates. Or you can
directly touch System Updates on application list directly. Touch Check for updates and the phone
will search for the latest software. If you want to update the system touch the button Download,
after download is complete touch Install to complete the upgrade. Now your phone's software will
have the latest version.
You should turn on data connection before searching for updates.
During FOTA downloading or updating, to avoid errors in locating the correct update packages,
do not change your default storage location.
115 116
13 12 Month Limited Warranty .................
TCL Communications Ltd warrants to the original retail purchaser of this wireless device that should
this product or part thereof during normal consumer usage and condition be proven to be defective
in material or workmanship that results in product failure within the first twelve (12) months from the
date of purchase as shown on your original sales receipt from an authorized sales agent. Such defect(s)
will be repaired or replaced (with new or rebuilt parts) at the company’s option without charge for
parts or labor directly related to the defect(s). Batteries, power adapters, and other accessories sold as
in box items are also warranted against defects and workmanship that results in product failure within
the first twelve (12) month period from the date of purchase. This warranty extends to products
purchased and sold within the United States.
The limited warranty for your wireless device will be voided if any of the following conditions occur:
•Non-compliance with the instructions for use or installation, or with technical and safety standards
applicable in the geographical area where your phone is used;
•Connection to any equipment not supplied or not recommended by TCT Mobile Inc.;
•Modification or repair performed by individuals not authorized by TCT Mobile Inc. or its affiliates;
•Changes to the device operating system by the user or third party applications;
•Acts of god such as inclement weather, lightning, power surges, fire, humidity, infiltration of liquids or
foods, chemical products, download of files, crash, high voltage, corrosion, oxidation;
•Removal or altering of the wireless device’s event labels or serial numbers (IMEI);
•Damage from exposure to water or other liquids, moisture, humidity, excessive temperatures or
extreme environmental conditions, sand, excess dust and any condition outside the operating guidelines;
•Rooted devices;
•Damage as result of physical abuse regardless of cause.
There are no express warranties, whether written, oral or implied, other than this printed
limited warranty or the mandatory warranty provided by your jurisdiction. In no event shall TCL
Communications Ltd. or any of its affiliates be liable for incidental or consequential damages of any
nature whatsoever, including but not limited to commercial loss, to the full extent those damages can
be disclaimed by law. Some states do not allow the exclusion or limitation of incidental or consequential
damages, or limitation of the duration of implied warranties, so the preceding limitations or exclusions
may not apply to you.
How to obtain Support: Contact the customer care center by calling (855-368-0829) or going to
(http://www.alcatelonetouch.com/usa/). We have placed many self-help tools that may help you to
isolate the problem and eliminate the need to send your wireless device in for service. In the case that
your wireless device is no longer covered by this limited warranty due to time or condition, you may
utilize our out of warranty repair options.
117 118
14 Troubleshooting ......................................
Before contacting the service center, you are advised to follow the instructions below:
• You are advised to fully charge ( ) the battery for optimal operation.
• Avoid storing large amounts of data in your phone as this may affect its performance.
• Use Factory data reset and the upgrade tool to perform phone formatting or software
upgrading (to reset factory data, hold down the Power key and the Volume up key at the same
time). ALL User phone data: contacts, photos, messages and files, downloaded applications will
be lost permanently. It is strongly advised to fully backup the phone data and profile via Android
Manager before doing formatting and upgrading.
and carry out the following checks:
My phone is frozen or cannot be switched on
• Check the battery power level, charge for at least 20 minutes.
• If it still does not work, please reset the phone using the Power key and the Volume up key.
My phone has not responded for several minutes
• Restart your phone by pressing and holding the Power key.
My phone turns off by itself
• Check that your screen is locked when you are not using your phone, and make sure the Power key is
not mis-contacted due to unlocked screen.
• Check the battery charge level.
My phone cannot charge properly
• Make sure that your battery is not completely discharged; if the battery power is empty for a long
time, it may take around 20 minutes to display the battery charger indicator on the screen.
• Make sure charging is carried out under normal conditions (0°C (32°F) to +40°C (104°F)).
• When abroad, check that the voltage input is compatible.
My phone cannot connect to a network or “No service” is displayed
• Try connecting in another location.
• Verify the network coverage with your operator.
• Check with your operator that your SIM card is valid.
• Try selecting the available network(s) manually (see “11.1.7 Mobile networks”)
• Try connecting at a later time if the network is overloaded.
My phone cannot connect to the Internet
• Check that the IMEI number (press *#06#) is the same as the one printed on your warranty card
or box.
• Make sure that the internet access service of your SIM card is available.
• Check your phone's Internet connecting settings.
• Make sure you are in a place with network coverage.
• Try connecting at a later time or another location.
Invalid SIM card
• Make sure the SIM card has been correctly inserted (see “Inserting or removing the SIM card”).
• Make sure the chip on your SIM card is not damaged or scratched.
• Make sure the service of your SIM card is available.
Unable to make outgoing calls
• Make sure you have dialed a valid number and have touched .
• For international calls, check the country and area codes.
• Make sure your phone is connected to a network, and the network is not overloaded or
unavailable.
• Check your subscription status with your operator (credit, SIM card valid, etc.).
• Make sure you have not barred outgoing calls.
• Make sure that your phone is not in airplane mode.
Unable to receive incoming calls
• Make sure your phone is switched on and connected to a network (check for overloaded or
unavailable network).
• Check your subscription status with your operator (credit, SIM card valid, etc.).
• Make sure you have not forwarded incoming calls.
• Make sure that you have not barred certain calls.
• Make sure that your phone is not in airplane mode.
The caller’s name/number does not appear when a call is received
• Check that you have subscribed to this service with your operator.
• Your caller has concealed his/her name or number.
119 120
I cannot find my contacts
• Make sure your SIM card is not broken.
• Make sure your SIM card is inserted properly.
• Import all contacts stored in SIM card to phone.
The sound quality of the calls is poor
• You can adjust the volume during a call by pressing the Volume Up/Down key.
• Check the network strength .
• Make sure that the receiver, connector or speaker on your phone is clean.
I am unable to use the features described in the manual
• Check with your operator to make sure that your subscription includes this service.
• Make sure this feature does not require an ALCATEL ONETOUCH accessory.
When I select a number from my contacts, the number cannot be dialed
• Make sure that you have correctly recorded the number in your file.
• Make sure that you have selected the country prefix when calling a foreign country.
I am unable to add a contact in my contacts
• Make sure that your SIM card contacts are not full; delete some files or save the files in the phone
contacts.
My callers are unable to leave messages on my voicemail
• Contact your network operator to check service availability.
I cannot access my voicemail
• Make sure your operator’s voicemail number is correctly entered in "Voicemail number".
• Try later if the network is busy.
I am unable to send and receive MMS
• Check your phone memory availability as it might be full.
• Contact your network operator to check service availability and check MMS parameters (see “4.1.3
Adjust message settings”).
• Verify the server center number or your MMS profile with your operator.
• The server center may be swamped, try again later.
SIM card PIN locked
• Contact your network operator to obtain the PUK code (Personal Unblocking Key).
I am unable to connect my phone to my computer
• Check that your USB driver is installed properly.
• Open the Notifications panel to check if the Android Manager Agent has been activated.
• Check that you have marked the checkbox of USB debugging in Settings\About phone\
Advanced settings\USB debugging.
• Make sure that you’re using the right cable from the box.
I am unable to download new files
• Make sure there is sufficient phone memory for your download.
• Check your subscription status with your operator.
The phone cannot be detected by others via Bluetooth
• Make sure that Bluetooth is turned on and your phone is visible to other users (see “6.3
Connecting to Bluetooth devices”).
• Make sure that the two phones are within Bluetooth’s detection range.
How to make your battery last longer
• Make sure you follow the complete charge time (minimum 2.5 hours).
• After a partial charge, the battery level indicator may not be exact. Wait for at least 20 minutes
after removing the charger to obtain an exact indication.
• Switch on the backlight upon request.
• Extend the email auto-check interval for as long as possible.
• Update news and weather information on manual demand, or increase their auto-check interval.
• Exit background-running applications if they are not being used for a long time.
• Deactivate Bluetooth, Wi-Fi, or GPS when not in use.
The phone will become warm following prolonged calls, game playing, internet surfing
or running other complex applications.
• This heating is a normal consequence of the CPU handling excessive data. Ending above actions will
make your phone return to normal temperatures.
121 122
Safety and Use. .................................................
We recommend that you read this chapter carefully before using your phone. The manufacturer disclaims any liability for damage, which
may result as a consequence of improper use or use contrary to the instructions contained herein.
EXPOSURE TO RADIO FREQUENCY SIGNALS
Your wireless handheld portable telephone is a low power radio transmitter and receiver. When it is ON, it receives and also sends
out radio frequency (RF) signals. In August 1996, the Federal Communications Commissions (FCC) adopted RF exposure guidelines
with safety levels for handheld wireless phones. Those guidelines are consistent with the safety standards previously set by both U.S.
and international sta ndards bodies:
ANSI C95.1 (1992) *
NCRP Report 86 (1986) *
ICNIRP (1996) *
Those standards were based on comprehensive and periodic evaluations of the relevant scientific literature. For example, over 120
scientists, engineers, and physicians from universities, government health agencies, and industry reviewed the available body of research
to develop the ANSI Standard (C951).
The d esign of your phone complies with the FCC guidelines (and those standards).
1: American National Standards Institute.
2: National Council on Radiation Protection and Measurements.
3: International Commission on Nonionizing Radiation Protection.
ANTENNA SAFETY
Use only the supplied or an approved replacement antenna. Unauthorized antennas, modifications, or attachments could impair call quality,
damage the phone, or result in violation of FCC regulations. Please contact your local dealer for replacement antenna.
Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with the skin, a minor burn may result. Please
contact your local dealer for replacement antenna.
DRIVING SAFETY
Talking on the phone while driving is extremely dangerous and is illegal in some states. Remember, safety comes first. Check the laws
and regulations on the use of phones in the areas where you drive. Always obey them. Also, if using your phone while driving, please:
• Give full attention to driving. Driving safely is your first responsibility.
• Use hands-free operation, if available.
• Pull off the road and park before making or answering a call, if driving conditions so require.
If you must use the phone while driving, please use one-touch, speed dialing, and auto answer modes.
An airbag inflates with great force. DO NOT place objects, including both installed or portable wireless equipment, in the area over the
airbag or in the air bag deployment area. If in-vehicle wireless equipment is improperly installed and the air bag inflates, serious injury
could result.
WARNING: Failure to follow these instructions may lead to serious personal injury and possible property damage.
ELECTRONIC DEVICES
Your wireless handheld portable telephone is a low power radio transmitter and receiver. When it is ON, it receives and also sends out
radio frequency (RF) signals. Most modern electronic equipment is shielded from RF energy. However, certain electronic equipment may
not be shielded against the RF signals from your wireless phone. Therefore, use of your phone must be restricted in certain situations.
PACEMAKERS
The Health Industry Manufacturers Association recommends that a minimum separation of six (6”) inches be maintained between a
handheld wireless phone and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent
with the independent research by and recommendations of Wireless Technology Research. Persons with pacemakers:
• ALWAYS keep the phone more than six inches from your pacemaker when the phone is turned on.
• Do not carry the phone in a breast pocket.
• Use the ear opposite the pacemaker to minimize the potential for interference.
• If you have any reason to suspect that interference is taking place, turn your phone OFF immediately.
HEARING AIDS
Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your service
provider (or call the customer service line to discuss alternatives).
OTHER MEDICAL DEVICES
If you use any other personal medical device, consult the manufacturer of your device to determine if they are adequately shielded from
external RF energy.
Your physician may be able to assist you in obtaining this information. Turn your phone OFF in healthcare facilities when any regulations
posted in these areas instruct you to do so. Hospitals or healthcare facilities may be using equipment that could be sensitive to external
RF energy.
VEHICLES
RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles. Check with the manufacturer or
its representative regarding your vehicle. You should also consult the manufacturer of any equipment that has been added to your vehicle.
POSTED FACILITIES
Turn your phone OFF where posted notices so require.
OTHER SAFETY GUIDELINES
AIRCRAFT
FCC regulations prohibit using your phone while in the air. Turn your phone OFF before boarding an aircraft. Always request and obtain
prior consent and approval of an authorized airline representative before using your phone aboard an aircraft.
Always follow the instructions of the airline representative whenever using your phone aboard an aircraft, to prevent any possible
interference with airborne electronic equipment.
BLASTING AREAS
To avoid interfering with blasting operations, turn your phone OFF when in a “blasting area” or in areas posted: “Turn off two-way radio.”
Obey all signs and instructions.
123 124
POTENTIALLY EXPLOSIVE ATMOSPHERES
Turn your phone OFF when in any area with a potentially explosive atmosphere and obey all signs and instructions. Sparks in such areas
could cause an explosion or fire resulting in bodily injury or even death.
Areas with a potentially explosive atmosphere are often, but not always, clearly marked. They include fueling areas such as gas stations;
below deck on boats; fuel or chemical transfer or storage facilities; vehicles using liquefied petroleum gas (such as propane or butane);
areas where the air contains chemicals or particles, such as grain, dust, or metal powders; and any other area where you would normally
be advised to turn off your vehicle’s engine.
PRECAUTIONS
Your Handheld Portable Telephone is a high quality piece of equipment. Before operating, read all instructions and cautionary markings
on (1) USB AC Adapter (2) Battery.
Failure to follow the directions below could result in serious bodily injury and/or property damage due to battery liquid leakage, fire
or rupture.
• DO NOT use this equipment in an extreme environment where high temperature or high humidity exists.
• DO NOT abuse the equipment. Avoid striking, shaking or shocking. When not using, lay down the unit to avoid possible damage due
to instability.
• DO NOT expose this equipment to rain or spilled beverages.
• DO NOT use unauthorized accessories.
• DO NOT disassemble the phone or its accessories. If service or repair is required, return unit to an authorized cellular service center.
If unit is disassembled, the risk of electric shock or fire may result.
• DO NOT short-circuit the battery terminals with metal items etc.
SAFETY INFORMATION FOR FCC RF EXPOSURE
WARNING! READ THIS INFORMATION BEFORE USING
CAUTIONS
In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC
96-326 adopted an updated safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated
transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies.
The design of this phone complies with the FCC guidelines and these international standards.
BODY-WORN OPERATION
This device was tested for typical body-worn operations with the back of the phone kept 15 mm. from the body. To maintain compliance
requirements, use only belt-clips, holsters or similar accessories that maintain a 1.0 cm separation distance between the user’s Body and
the back of the phone, including the antenna.
The use of belt-clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that
do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided.
For more information about RF exposure, please visit the FCC website at http://www.fcc.gov
SAR INFORMATION
THIS MODEL PHONE MEETS THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure
to radiofrequency (RF) energy set by the Federal Communications Commission of the U.S. Government. These limits are part of
comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards
that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards
include a substantial safety margin designed to assure the safety of all persons, regardless of age and health.
The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The
SAR limit set by the FCC is 1.6 W/kg. * Tests for SAR are conducted with the phone transmitting at its highest certified power level
in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone
while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as
to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the
power output.
Before a phone model is available for sale to the public, it must be tested and certified to the FCC that it does not exceed the limit
established by the government adopted requirement for safe exposure. The tests are performed in positions and locations (e.g., at the
ear and worn on the body) as required by the FCC for each model. The highest SAR value for this model phone when tested for use at
the ear is 1.38 W/kg and when worn on the body, as described in this user guide, is 0.97 W/kg. (Body-worn measurements differ among
phone models, depending upon available accessories and FCC requirements). While there may be differences between the SAR levels of
various cellphones and at various positions, they all meet the government requirement for RF exposure.
For body-worn operation, the cellphone meets FCC RF exposure guidelines provided that it is used with a non-metallic accessory with
the handset at least 15 mm from the body. Use of other accessories may not ensure compliance with FCC RF exposure guidelines.
SAR information on this model phone is on file with the FCC and can be found under the Display Grant section of http://www.fcc.gov/
oet/ea after searching on JYCBLADE.
Additional information on Specific Absorption Rates (SAR) can be found on the Cellular Telecommunications Industry Association (CTIA)
web-site at http://www.ctia.org.
* In the United States and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kg (W/kg) averaged over one gram
of tissue. The standard incorporates a substantial margin of safety to give additional protection for the public and to account for any
variations in measurements.
125 126
HEARING AID COMPATIBILITY (HAC) FOR WIRELESS
TELECOMMUNICATIONS DEVICES
OUR COMMITMENT
We believe that all of our customers should be able to enjoy the benefits of digital wireless technologies. We are committed to providing
a selection of compatible devices for our customers who wear hearing aids.
THIS PHONE HAS A HAC RATING OF M4/T3
FCC ID: 2ACCJA002
WHAT IS HEARING AID COMPATIBILITY?
The Federal Communications Commission has implemented rules and a rating system designed to enable people who wear hearing aids
to more effectively use these wireless telecommunications devices. The standard for compatibility of digital wireless phones with hearing
aids is set forth in American National Standard Institute (ANSI) standard C63.19. There are two sets of ANSI standards with ratings from
one to four (four being the best rating): an “M” rating for reduced interference making it easier to hear conversations on the phone
when using the hearing aid microphone, and a “T” rating that enables the phone to be used with hearing aids operating in the telecoil
mode thus reducing unwanted background noise.
HOW WILL I KNOW WHICH WIRELESS PHONES ARE HEARING AID COMPATIBLE?
The Hearing Aid Compatibility rating is displayed on the wireless phone box.
A phone is considered Hearing Aid Compatible for acoustic coupling (microphone mode) if it has an “M3” or “M4” rating. A digital
wireless phone is considered Hearing Aid Compatible for inductive coupling (telecoil mode) if it has a “T3” or “T4” rating.
This phone has been tested and rated for use with hearing aids for some of the wireless technologies that it uses. However, there may
be some newer wireless technologies used in this phone that have not been tested yet for use with hearing aids. It is important to try
the different features of this phone thoroughly and in different locations, using your hearing aid or cochlear implant, to determine if
you hear any interfering noise. Consult your service provider about its return and exchange policies and for information on hearing aid
compatibility.
HOW WILL I KNOW IF MY HEARING AID WILL WORK WITH A PARTICULAR
DIGITAL WIRELESS PHONE?
You’ll want to try a number of wireless phones so that you can decide which works the best with your hearing aids. You may also want
to talk with your hearing aid professional about the extent to which your hearing aids are immune to interference, if they have wireless
phone shielding, and whether your hearing aid has a HAC rating.
FOR MORE INFORMATION ABOUT HEARING AIDS AND DIGITAL WIRELESS
PHONE
• FCC Hearing Aid Compatibility and Volume Control – http://www.fcc.gov/cgb/dro/hearing.html
• Hearing Loss Association of America – http://www.hearingloss.org/learn/cellphonetech.asp
• CTIA – http://www.accesswireless.org/Disability-Categories/Hearing.aspx
• Gallaudet University, RERC – http://tap.gallaudet.edu/voice
FDA CONSUMER UPDATE
U.S. FOOD AND DRUG ADMINISTRATION - CENTER FOR DEVICES AND
RADIOLOGICAL
HEALTH CONSUMER UPDATE ON WIRELESS PHONES
1. Do wireless phones pose a health hazard?
The available scientific evidence does not show that any health problems are associated with using wireless phones. There is no proof,
however, that wireless phones are absolutely safe. Wireless phones emit low levels of radiofrequency energy (RF) in the microwave range
while being used. They also emit very low levels of RF when in the idle mode. Whereas high levels of RF can produce health effects (by
heating tissue), exposure to low level RF that does not produce heating effects causes no known adverse health effects. Many studies of
low level RF exposures have not found any biological effects. Some studies have suggested that some biological effects may occur, but
such findings have not been confirmed by additional research. In some cases, other researchers have had difficulty in reproducing those
studies, or in determining the reasons for inconsistent results.
2. What is FDA’s role concerning the safety of wireless phones?
Under the law, FDA does not review the safety of radiation-emitting consumer products such as wireless phones before they can be sold,
as it does with new drugs or medical devices. However, the agency has authority to take action if wireless phones are shown to emit
radiofrequency energy (RF) at a level that is hazardous to the user. In such a case, FDA could require the manufacturers
of wireless phones to notify users of the health hazard and to repair, replace or recall the phones so that the hazard no longer exists.
Although the existing scientific data do not justify FDA regulatory actions, FDA has urged the wireless phone industry to take a number
of steps, including the following:
• Support needed research into possible biological effects of RF of the type emitted by wireless phones;
• Design wireless phones in a way that minimizes any RF exposure to the user that is not necessary for device function;
and
• Cooperate in providing users of wireless phones with the best possible information on possible effects of wireless phone use on
human health.
FDA belongs to an interagency working group of the federal agencies that have responsibility for different aspects of RF safety to ensure
coordinated efforts at the federal level. The following agencies
belong to this working group:
• National Institute for Occupational Safety and Health
• Environmental Protection Agency
• Federal Communications Commission
• Occupational Safety and Health Administration
• National Telecommunications and Information Administration
The National Institutes of Health participates in some inter-agency working group activities, as well. FDA shares regulatory responsibilities
for wireless phones with the Federal Communications Commission (FCC). All phones that are sold in the United States must comply with
FCC safety guidelines that limit RF exposure. FCC relies on FDA and other health agencies for safety questions about wireless phones.
FCC also regulates the base stations that the wireless phone net works rely upon. While these base stations operate at higher power
than do the wireless phones themselves, the RF exposures that people get from these base stations are typically thousands of times lower
than those they can get from wireless phones. Base stations are thus not the subject of the safety questions discussed in this document.
