User Manual

第1页共3页



LS1

Smart Light Strip

QUICK START GUIDE

1. Connect the USB connector to a power source (e.g., power bank, computer or USB

charger). The Smart Light Strip will light up in warm white to indicate it is ready for network

setup.

2. Make sure your iPhone or iPad (iOS 8.1 or later) is connected to a 2.4GHz Wi-Fi network.

Using the router utility software, shutdown 5GHz Wi-Fi networks.

3. Download and open the free Koogeek Home app from the App Store.

4. Log in or sign up for a Koogeek account or simply tap Skip.

5. Tap “+” on the top right corner and follow the on-screen directions to complete network

setup.

Note: To add more light strips (or repeat the Smart Light Strip setup process), tap “+” and

you will see the accessory list. Each accessory has an identification code, e.g.,

Koogeek-XXX-XXXXXX. Make sure the last 6 characters of the identification code is

consistent with the last 6 characters of MAC on the back of the switch.

6. When prompted, scan the setup code or manually enter the setup code, and then follow the

step to add the device to the Home and Room. Please keep the setup code for future use.

7. You can assign a name to your Smart Light Strip and use this name when speaking to Siri.

For example, you can name your Smart Light Strip “bedroom light”, then launch Siri and speak

“Turn on the bedroom light”.

8. Change the light color and adjust the brightness and saturation by tapping and holding the

icon for 2 seconds or just asking Siri, e.g., “Set bedroom light to green” or “Set bedroom light

brightness to 50%”.

9. Set up customized scenes to control multiple devices with a single command. For example,

if you assign the “I'm going to bed” command to the scene of turning off bedroom light and

turning on the living room light, when you speak “I'm going to bed” to Siri, everything is done.

10. For troubleshooting visit www.koogeek.com

Note:

The use of a HomeKit-enabled accessory need the follow permissions:

Settings > iCloud > iCloud Drive > Turn On

Settings > iCloud > Keychain > Turn On

Settings > Privacy > HomeKit > Koogeek Home > Turn On

第2页共3页



Smart Light Strip Overview

USB port

Switch (Reset button)

LED light

Restore Factory Settings

Press and hold the switch for 10 seconds and the light color will turn red. When the light color

turns warm white, it indicates that you have restored the device to factory settings.

Specifications

Interface: USB port

Input: 5V = 2A (Max.)

Rated power: 10W

Operating temperature: -20°C~45°C

LED light color: 16 million colors (Support the color changing function)

Dimmable: Yes

LED quantity: 60 * light emitting diodes

Luminous flux: 480lm (Max.)

Strip length: 78.74inch /2000mm

Waterproof and dustproof rating: IP65 (LED part only)

Wi-Fi: 802.11b/g/n, 2.4 GHz ONLY

General use

Safety Warnings

For indoor use only

Maintain with a dry cloth duster

Keep children away from Smart Light Strip

Avoid dropping

DO NOT cut

DO NOT disassemble

DO NOT clean with liquid

DO NOT use abrasives or solvents

DO NOT use in wet or damp areas (e.g. bathrooms)

DO NOT use with dimmers

DO NOT use in enclosed environments

DO NOT exceed the recommended electrical ratings

第3页共3页



Legal

Use of the Works with Apple HomeKit logo means that an electronic accessory has been

designed to connect specifically to iPod touch, iPhone, or iPad, respectively, and has been

certified by the developer to meet Apple performance standards. Apple is not responsible for

the operation of this device or its compliance with safety and regulatory standards.

Controlling this HomeKit-enabled accessory automatically and away from home requires

an Apple TV with tvOS 10.1 or later or an iPad with iOS 10.1 or later set up as a home hub.

FCC Caution.



Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwo

conditions:(1)Thisdevicemaynotcauseharmfulinterference,and(2)thisdevicemustaccept

anyinterferencereceived,includinginterferencethatmaycauseundesiredoperation.



AnyChangesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliance

couldvoidtheuser'sauthoritytooperatetheequipment.



Note:ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigital

device,pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonable

protectionagainstharmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates

usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththe

instructions,maycauseharmfulinterferencetoradiocommunications.However,thereisno

guaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoes

causeharmfulinterferencetoradioortelevisionreception,whichcanbedeterminedbyturning

theequipmentoffandon,theuserisencouragedtotrytocorrecttheinterferencebyoneor

moreofthefollowingmeasures:

‐Reorientorrelocatethereceivingantenna.

‐Increasetheseparationbetweentheequipmentandreceiver.

‐Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiveris

connected.

‐Consultthedealeroranexperiencedradio/TVtechnicianforhelp.



*RFwarningforMobiledevice:

ThisequipmentcomplieswithFCCradiationexposurelimitssetforthforanuncontrolled

environment.Thisequipmentshouldbeinstalledandoperatedwithminimumdistance20cm

betweentheradiator&yourbody.
