THA-101 WiFi Smart Plug Quick Install Guide
Setup for Repeater Mode
1
Power on the Extender
Step1. Plug your Wireless Extender into an
electrical socket.
Step2. Check the LEDs: the power LED
should be always on when system is
ready.
Connect to the Wireless
Extender
2
Step1. Default SSID is “THA-101” and
security key is “12345678”.
Step2. Set your wireless adapter in DHCP
client and waiting for getting IP
Address from the Wireless Extender.
Step3. Open a web browser and ente
r
“192.168.1.254” in URL field to open
the configuration page.
Step4. Default user name is “admin” and
password is “password” to access
WEB GUI.
3
Manually Configuration:
Step1. Open Wireless Settings / AP Client
page.
Step2. Setup the SSID and Security of AP
that you want to connect to: Click
APPLY to finish.
Notes:
The Wireless Extender is designed as a pure wireless
device, so there are no any RJ-45 ports for Etherne
t
cable to connect to. Please prepare any IEEE802.11
ac/b/g/n compliant wireless adapter for next setup
step. OR you can use “SCAN” to refresh the
wireless network and select an AP to
connect to.
“Theproductshallbeusedintheresidential
environmentnotwithstandinguseincommercial,
businessenvironments.Ifyouwanttouseother
thantheaboveenvironments,pleasecontact
AboComfirst.”
WPS Configuration:
Step1. Press the WPS button of the Wireless
Extender over 3 seconds.
Step2. Then press the WPS button of the
wireless router/AP over 3 seconds
too. Step 1 and Step 2 need to be
done in 200 seconds.
![](/img.php?id=2321324&img=bg2.png)
FCC Statement:
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one of the following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and receiver.
● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
● Consult the dealer or an experienced radio/TV technician for help.
Check if Connected
4
The green–checked icon ahead is the
Wireless Router/AP which the Wireless
Extender is working to.
WPS button behavior:
Less than 2 sec → N/A, WPS LED no blinking.
More than 2 sec → Do WPS, WPS LED start blinking
Reset button behavior:
Less than 2 sec → N/A, D5-D1 LEDs no blinking.
2-5 seconds → Do REBOOT, D5-D1 LEDs fast blinking.
More than 5 sec→ Do Factory Default, D5-D1 LEDs
blinking slowly.
Hardware Button Behavior
5
![](/img.php?id=2321324&img=bg3.png)
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation.
For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other channels is not
possible.
This device and it's antennas(s) must not be co-located or operating in conjunction with any other antenna or transmitter
except in accordance with FCC multi-transmitter product procedures.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance 20cm between the radiator & your body.
