Telepower Communication TPS900 Smart POS Terminal User Manual
Telepower Communication Co., Ltd. Smart POS Terminal
User Manual
Card Reading
1.
NFC tag, put the NFC tag over the printer case of the
device.
2.
Smart card, insert the smart card to the slot,
chip should bedownside.
3.
Magnetic card, put the card to the slot, then swipeit.
4
Accessories
MainDevice 1Set PowerAdapter 1Piece
Battery 1Piece UserGuide 1Volume
This device complies with part 15 of the FCC Rules. Operation is subject to
the condition that this device does not cause harmful interference
Any Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
This device was tested for typical body-worn operations. To comply with
RF exposure requirements, a minimum separation distance of 0 cm must
be maintained between the user’s body and the handset, including the
antenna. Third-party belt-clips, holsters, and similar accessories used by
this device should not contain any metallic components. Body-worn
accessories that do not meet these requirements may not comply with RF
exposure requirements and should be avoided. Use only the supplied or an
approved antenna.
TPS900 EFT POS
User Guide
TPS900 Specification
1
SIM Card, PSAM & TF Card
Installation
1. Take out the back cover and battery, the card socketswill
beshown.
2. Push the SIM card into the socket correctly. Be surethe
SIM card is in rightposition.
2
Battery Installation
1.
Open the back cover and put the battery into
theholder. Install the battery in rightdirection.
2.
Put the cover back to theterminal.
Warning: The changing of wrong battery type has risk to
be explosive.
Warning: Don't throw battery casually.
Before using the POS terminal, ensure that all the
accessories above are included in the package.
If you have any problems, please contact the services
provider of the distributors.
3
Processor
Qualcomm 8909, Quad-core, 1.1G
OS
Android 5.1
Memory
8GB FLASH, 1GB RAM,
optional 16GB Flash, 2GB RAM
Ext. Memory
TF Card, up to 32GB
Display
5.5”, TFT1280*720
Magnetic Card Reader
Track 1/2/3, bi-directional swipe,
ISO7810, ISO7811, ISO7812
Smart Card Reader
(Optional)
ISO 7816
PSAM
optional 2 slots
Contactless Card Reader
(Optional)
ISO14443 Type A/B, Mifare®,
ISO18092 compliant
Camera
5 megapixels, auto focus
Fingerprint
Optional
GPS
Built-in
SIM
2
Communications
FDD-LTE/TDD-LTE/WCDMA
/GPRS/WIFI/Bluetooth
Peripheral Ports
1 Micro USB
Power Supply
Input: 100-240V AC; Output: 5V DC, 2A.
Battery
Li-ion, 7.4V, 2200mAh
