Mechanical
size: 87mm x 87mm x 21mm
housing: moulded polycarbonate/ABS with fully encapsulated electronics
weight: 110g nominal
mounting: 2 x M3.5 screws (supplied)
Electrical
voltage: +5V dc to + 16V dc
current: 250 mA typical
data voltage: rest >4Vdc / active <1Vdc
data output: Wiegand / clock & data / custom output formats
indication: 1 RGB LED (operation reader model dependent)
speaker: audible indicator (external control on some models)
TECHNICAL SPECIFICATION
PRODUCT APPLICATION
The ELITE series RX1 reader is designed to
provide a low cost installed expenditure, and fits
directly onto a UK/EU electrical backbox using
standard M3.5mm screws (supplied).
Having a slim and innovative clean aesthetic,
the reader features an RGB LED which allows
each door to be set with a colour coded access
level, or to illuminate to compliment corporate
colours.
The unit is moulded using tough PC/ABS plastic,
and includes a unique shadow-line backplate
making the reader appear to almost float against
the wall.
PART NUMBERING
Third Millennium Systems Ltd
18 / 19 Torfaen Business Centre
New Inn PONTYPOOL
NP4 0LS
United Kingdom
Environmental
operating temp: -20 °C to +60°C
humidity: 100% RHNC
1
4
5
STYLE
RX 1 series
RX 4 series
RX 5 series
0
1
2
3
4
*
*
*
OUTPUT
pass through
clock & data
Wiegand
Watermark
RS232
*
*
*
CONFIGURATION
SPECIFIC (optional)
FEATURES
PANEL INTERFACE
A wide variety of output formats can be
supplied to suit most applications.
QUALITY DESIGN
Third Millennium has over 15 years of
experience in the design of RFID technology,
and offers complete peace of mind when
readers have been installed.
FLEXIBLE CONNECTIONS
With an RGB LED indicator and an integral
speaker, the reader allows for various
connection combinations.
CARDS & TAGS
A wide range of identity cards and keyfobs
are available to suit virtually every
application. Standard ISO style plastic cards,
with or without magnetic stripe, can be
supplied with surface printing using standard
PVC card printers, or to special order.
RX 1 * * * *
/
*
example:
RX102/A01
RX1 SERIES reader
with Third Millennium
technology, Wiegand
output and a specific
configuration reference.
TECHNOLOGY
8
®
m farei
6®
0
RX
elite
Connection (screw terminal)
1 - supply +5V dc to +16V dc
2 - clock / data 1
3 - data / data 0
4 - green LED
5 - red LED
6 - buzzer
7 - tamper
8 - supply 0V
9 - TTL Tx
10 - TTL Rx
