USERS MANUAL 4

GLOBAL DE-REGISTRATION
If one or more handsets becomes lost, you should de-register all
handsets to ensure proper system operation. Follow the steps below
to deregister both handsets at the same time.
1. Press and hold the PAGE button on the base of GE 25831, 25833,
or 25835 until the CHARGE/IN USE indicator on the base flashes.
2. Press and hold the PAGE button on the base of GE 25831, 25833,
or 25835 again until the CHARGE/IN USE indicator on the base
flashes rapidly.
3. Press and release the PAGE button on the base of GE 25831, 25833,
or 25835 once. All handsets are deregistered and
HANDSET NEEDS
REGISTRATION
shows in the display.
IMPORTANT : It is strongly recommended that a handset not
be de-registered unless absolutely necessary.
6. Use the touch-tone pad to enter
1YES
, or use the CALLER ID/VOL
(- or +) button to scroll to
1YES
.
7. Press MUTE/PROG and
MOVE NEAR TO BASE
displays until you
move the handset closer to the base.
DEFAULT
As you become familiar with this system, you may prefer to use the
system’s original settings. Follow the steps below to return to the
factory default settings.
1. Make sure your phone is OFF (not in talk mode).
2. Press the MUTE/PROG button to display main menus:
ROOM
MONITOR and HANDSET SETUP.
3. Use CALLER ID/VOL - button to locate to
HANDSET SETUP
and then
press MUTE/PROG button to select.
4. Use CALLER ID/VOL - / + button to locate the
DEFAULT SETTING
and then press MUTE/PROG button to select.
5. Then the handset shows
DEFAULT SETTING 1YES 2NO
in display.
6. Use the touch-tone pad on your handset to enter
1YES
or
2NO
, or
use the CALLER ID/VOL - / + button on your handset to scroll to
1YES
or
2NO
.
“2NO”
is the default setting.
1. Make sure the telephone is OFF before you replace battery.
2. Remove the battery compartment door.
3. Disconnect the cord attached to the battery pack from the jack
inside the battery compartment and remove the battery pack
from the handset.
4. Insert the new battery pack and reconnect the battery plug.
5. Put the battery compartment door back on.
6. Place handset in the base to charge. If you don’t charge the
handset battery properly (for 16 hours) when you first set up the
phone and/or when you install a new battery pack, the battery’s
long-term performance will be compromised.
NOTE: If the battery is not properly installed in the handset, or
if the battery pack is not properly connected to the jack inside
the battery compartment. “NO BATTERY” shows in the display
when the handset is placed in the charging cradle.
BATTERY SAFETY PRECAUTIONS
• Do not burn, disassemble, mutilate, or puncture. Like other
batteries of this type, toxic materials could be released which can
cause injury.
• Keep batteries out of the reach of children.
• Remove batteries if storing over 30 days.
HEADSET AND BELT CLIP INSTALLATION
CONNECTING AN OPTIONAL HEADSET TO THE HANDSET
For hands free conversation.
1. Insert the headset plug into the headset jack.
2. Adjust the headset to rest comfortably on the ear.
3. Move the microphone to approximately 2 to 3 inches from
your mouth.
4. Press the TALK/CALLBACK button to answer or place a call while
using the headset.
CONNECTING THE BELT CLIP
There are two slots, one on each side of the handset.
Attach the belt clip by inserting the sides of the belt clip into the slots.
Snap the ends of the belt clip into place.
GENERAL PRODUCT CARE
To keep your unit working and looking good, follow these guidelines:
• Avoid putting the phone near heating appliances and devices that
generate electrical noise (for example, motors or fluorescent lamps).
• DO NOT expose to direct sunlight or moisture.
• Avoid dropping the handset, as well as other rough treatment to the phone.
• Clean the phone with a soft cloth.
• Never use a strong cleaning agent or abrasive powder because
this will damage the finish.
• Retain the original packaging in case you need to ship the phone
at a later date.
• Periodically clean the charge contacts on the handset and base
with a clean pencil eraser.
CAUSES OF POOR RECEPTION
• Aluminum siding.
• Foil backing on insulation.
• Heating ducts and other metal construction that can shield
radio signals.
• You’re too close to appliances such as microwaves, stoves,
computers, etc.
• Atmospheric conditions, such as strong storms.
• Base is installed in the basement or lower floor of the house.
• Base is plugged into AC outlet with other electronic devices.
• Baby monitor is using the same frequency.
• Handset battery is low.
• You’re out of range of the base.
SERVICE
If trouble is experienced with this equipment, for repair or warranty
information, please contact customer service at 1-800-448-0329. If the
equipment is causing harm to the telephone network, the telephone
company may request that you disconnect the equipment until the
problem is resolved.
This product may be serviced only by the manufacturer or its
authorized service agents. Changes or modifications not expressly
approved by ATLINKS USA, Inc. could void the user’s authority to
operate this product. For instructions on how to obtain service, refer
to the warranty included in this guide or call customer service at 1-
800-448-0329.
Or refer inquiries to:
ATLINKS USA, Inc.
Manager, Consumer Relations
P O Box 1976
Indianapolis, IN 46206
Attach your sales receipt to the booklet for future reference or jot
down the date this product was purchased or received as a gift. This
information will be valuable if service should be required during the
warranty period.
Purchase date _______________________________________________
Name of store________________________________________________
LIMITED WARRANTY
What your warranty covers:
• Defects in materials or workmanship.
For how long after your purchase:
• One year, from date of purchase.
(The warranty period for rental units begins with the first rental or
45 days from date of shipment to the rental firm, whichever
comes first.)
What we will do:
• Provide you with a new or, at our option, a refurbished unit. The
exchange unit is under warranty for the remainder of the original
product’s warranty period.
How you get service:
• Properly pack your unit. Include any cables, etc., which were
originally provided with the product. We recommend using the
original carton and packing materials.
• ”Proof of purchase in the form of a bill of sale or receipted invoice
which is evidence that the product is within the warranty period,
must be presented to obtain warranty service.” For rental firms,
proof of first rental is also required. Also print your name and
address and a description of the defect. Send via standard UPS or
its equivalent to:
ATLINKS USA, Inc.
c/o Thomson
11721 B Alameda Ave.
Socorro, Texas 79927
• Pay any charges billed to you by the Exchange Center for service not
covered by the warranty.
• Insure your shipment for loss or damage. ATLINKS accepts no
liability in case of damage or loss.
• A new or refurbished unit will be shipped to you freight prepaid.
What your warranty
does not
cover:
• Customer instruction. (Your Owner’s Manual provides information
regarding operating instructions and user controls. Any additional
information, should be obtained from your dealer.)
• Installation and setup service adjustments.
• Batteries.
• Damage from misuse or neglect.
• Products which have been modified or incorporated into other
products.
• Products purchased or serviced outside the USA.
• Acts of nature, such as but not limited to lightning damage.
Product Registration:
• Please complete and mail the Product Registration Card packed
with your unit. It will make it easier to contact you should it
ever be necessary. The return of the card is not required for
warranty coverage.
ACCESSORY INFORMATION
To place order, have your Visa, MasterCard, or Discover Card ready
and call toll-free 1-800-338-0376.
A shipping and handling fee will be charged upon ordering.
We are required by law to collect appropriate sales tax for each
individual state, country, and locality to which the merchandise is
being sent.
Items are subject to availability.
*Prices are subject to change without notice.
DESCRIPTION
Belt clip 5-2658 (translucent gray)
Replacement battery 5-2660
Headset 5-2425
MODEL NO.
NOTE: The RBRC seal on the battery used in your
ATLINKS USA, Inc. product indicates that we
are participating in a program to collect and
recycle Nickel Cadmium batteries throughout the
United States. Please call 1-800-8-BATTERY for
information or contact your local recycling center.
Limitation of Warranty:
• THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY
APPLICABLE TO THIS PRODUCT. ALL OTHER WARRANTIES,
EXPRESS OR IMPLIED (INCLUDING ALL IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE)
ARE HEREBY DISCLAIMED. NO VERBAL OR WRITTEN
INFORMATION GIVEN BY ATLINKS USA, INC., ITS AGENTS, OR
EMPLOYEES SHALL CREATE A GUARANTY OR IN ANY WAY
INCREASE THE SCOPE OF THIS WARRANTY.
• REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS
WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER.
ATLINKS USA, INC. SHALL NOT BE LIABLE FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF
THIS PRODUCT OR ARISING OUT OF ANY BREACH OF ANY
EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. THIS
DISCLAIMER OF WARRANTIES AND LIMITED WARRANTY ARE
GOVERNED BY THE LAWS OF THE STATE OF INDIANA. EXCEPT TO
THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED TO THE
APPLICABLE WARRANTY PERIOD SET FORTH ABOVE.
How state law relates to this warranty:
• Some states do not allow the exclusion nor limitation of
incidental or consequential damages, or limitations on how long
an implied warranty lasts so the above limitations or exclusions
may not apply to you.
• This warranty gives you specific legal rights, and you also may
have other rights that vary from state to state.
If you purchased your product outside the USA:
• This warranty does not apply. Contact your dealer for
warranty information.
DEREGISTRATION
1YES 2NO
Then the handset displays
CONFIRM? 1YES 2NO
.
MOVE NEAR TO
BASE
CONFIRM
1YES 2NO
8. Use the touch-tone pad to enter
1YES
or use CALLER ID/VOL (- or +)
button to scroll to
1YES
.
NOTE: Press the *EXIT button once to keep the previous
setting and return to the main menu screen.
9. Press the MUTE/PROG button to confirm the deregistration.
DE-REGISTER
... displays for 30 seconds, then
HANDSET # DE-REGISTERED
displays for one second followed by
HANDSET NEEDS REGISTRATION
HANDSET NEEDS
REGISTRATION
DEFAULT SETTING
1YES 2NO
NOTE: If you choose “YES” all settings in the programmable
menu return to the factory default settings.
NOTE: Press the *EXIT button once to keep the previous
setting and return to the main menu.
7. Press the MUTE/PROG button to save your selection, and return
to the main menu. The default setting you choose shows on the
display for two seconds, and you will hear a confirmation tone.
PAGING ALL HANDSETS FROM A HANDSET
1. Make sure the originating phone is OFF (not in talk mode).
2. Press and release the INT button on a handset.
PAGING
EXTENSION?
shows in the display.
3. Use the touch-tone pad to enter the handset number you want to
page. (1=to page Handset 1, 2=to page handset 2, 3=to page
handset 3, 4=to page handset 4, and 5=to page all handsets)
4. To cancel the page on the originating handset, press the *EXIT,
INT, or TALK/CALLBACK button.
REPLACING THE BATTERY
CAUTION: to reduce the risk of fire or personal injury,
use only the 5-2660 replacement battery listed on the
accessory order form, which is compatible with this unit.
CAUTION: To ensure the phone/battery performance, use
ONLY 25832 charging cradle, and 25831, 25833, or 25835 base
for battery charging only.
DEFAULT SETTING
YES
Headset plug
Headset jack
Slot for
belt clip
Slot for
belt clip
GLOBAL DE-REGISTRATION
If one or more handsets becomes lost, you should de-register all
handsets to ensure proper system operation. Follow the steps below
to deregister both handsets at the same time.
1. Press and hold the PAGE button on the base of GE 25831, 25833,
or 25835 until the CHARGE/IN USE indicator on the base flashes.
2. Press and hold the PAGE button on the base of GE 25831, 25833,
or 25835 again until the CHARGE/IN USE indicator on the base
flashes rapidly.
3. Press and release the PAGE button on the base of GE 25831, 25833,
or 25835 once. All handsets are deregistered and
HANDSET NEEDS
REGISTRATION
shows in the display.
IMPORTANT : It is strongly recommended that a handset not
be de-registered unless absolutely necessary.
6. Use the touch-tone pad to enter
1YES
, or use the CALLER ID/VOL
(- or +) button to scroll to
1YES
.
7. Press MUTE/PROG and
MOVE NEAR TO BASE
displays until you
move the handset closer to the base.
DEFAULT
As you become familiar with this system, you may prefer to use the
system’s original settings. Follow the steps below to return to the
factory default settings.
1. Make sure your phone is OFF (not in talk mode).
2. Press the MUTE/PROG button to display main menus:
ROOM
MONITOR and HANDSET SETUP.
3. Use CALLER ID/VOL - button to locate to
HANDSET SETUP
and then
press MUTE/PROG button to select.
4. Use CALLER ID/VOL - / + button to locate the
DEFAULT SETTING
and then press MUTE/PROG button to select.
5. Then the handset shows
DEFAULT SETTING 1YES 2NO
in display.
6. Use the touch-tone pad on your handset to enter
1YES
or
2NO
, or
use the CALLER ID/VOL - / + button on your handset to scroll to
1YES
or
2NO
.
“2NO”
is the default setting.
1. Make sure the telephone is OFF before you replace battery.
2. Remove the battery compartment door.
3. Disconnect the cord attached to the battery pack from the jack
inside the battery compartment and remove the battery pack
from the handset.
4. Insert the new battery pack and reconnect the battery plug.
5. Put the battery compartment door back on.
6. Place handset in the base to charge. If you don’t charge the
handset battery properly (for 16 hours) when you first set up the
phone and/or when you install a new battery pack, the battery’s
long-term performance will be compromised.
NOTE: If the battery is not properly installed in the handset, or
if the battery pack is not properly connected to the jack inside
the battery compartment. “NO BATTERY” shows in the display
when the handset is placed in the charging cradle.
BATTERY SAFETY PRECAUTIONS
• Do not burn, disassemble, mutilate, or puncture. Like other
batteries of this type, toxic materials could be released which can
cause injury.
• Keep batteries out of the reach of children.
• Remove batteries if storing over 30 days.
HEADSET AND BELT CLIP INSTALLATION
CONNECTING AN OPTIONAL HEADSET TO THE HANDSET
For hands free conversation.
1. Insert the headset plug into the headset jack.
2. Adjust the headset to rest comfortably on the ear.
3. Move the microphone to approximately 2 to 3 inches from
your mouth.
4. Press the TALK/CALLBACK button to answer or place a call while
using the headset.
CONNECTING THE BELT CLIP
There are two slots, one on each side of the handset.
Attach the belt clip by inserting the sides of the belt clip into the slots.
Snap the ends of the belt clip into place.
GENERAL PRODUCT CARE
To keep your unit working and looking good, follow these guidelines:
• Avoid putting the phone near heating appliances and devices that
generate electrical noise (for example, motors or fluorescent lamps).
• DO NOT expose to direct sunlight or moisture.
• Avoid dropping the handset, as well as other rough treatment to the phone.
• Clean the phone with a soft cloth.
• Never use a strong cleaning agent or abrasive powder because
this will damage the finish.
• Retain the original packaging in case you need to ship the phone
at a later date.
• Periodically clean the charge contacts on the handset and base
with a clean pencil eraser.
CAUSES OF POOR RECEPTION
• Aluminum siding.
• Foil backing on insulation.
• Heating ducts and other metal construction that can shield
radio signals.
• You’re too close to appliances such as microwaves, stoves,
computers, etc.
• Atmospheric conditions, such as strong storms.
• Base is installed in the basement or lower floor of the house.
• Base is plugged into AC outlet with other electronic devices.
• Baby monitor is using the same frequency.
• Handset battery is low.
• You’re out of range of the base.
SERVICE
If trouble is experienced with this equipment, for repair or warranty
information, please contact customer service at 1-800-448-0329. If the
equipment is causing harm to the telephone network, the telephone
company may request that you disconnect the equipment until the
problem is resolved.
This product may be serviced only by the manufacturer or its
authorized service agents. Changes or modifications not expressly
approved by ATLINKS USA, Inc. could void the user’s authority to
operate this product. For instructions on how to obtain service, refer
to the warranty included in this guide or call customer service at 1-
800-448-0329.
Or refer inquiries to:
ATLINKS USA, Inc.
Manager, Consumer Relations
P O Box 1976
Indianapolis, IN 46206
Attach your sales receipt to the booklet for future reference or jot
down the date this product was purchased or received as a gift. This
information will be valuable if service should be required during the
warranty period.
Purchase date _______________________________________________
Name of store________________________________________________
LIMITED WARRANTY
What your warranty covers:
• Defects in materials or workmanship.
For how long after your purchase:
• One year, from date of purchase.
(The warranty period for rental units begins with the first rental or
45 days from date of shipment to the rental firm, whichever
comes first.)
What we will do:
• Provide you with a new or, at our option, a refurbished unit. The
exchange unit is under warranty for the remainder of the original
product’s warranty period.
How you get service:
• Properly pack your unit. Include any cables, etc., which were
originally provided with the product. We recommend using the
original carton and packing materials.
• ”Proof of purchase in the form of a bill of sale or receipted invoice
which is evidence that the product is within the warranty period,
must be presented to obtain warranty service.” For rental firms,
proof of first rental is also required. Also print your name and
address and a description of the defect. Send via standard UPS or
its equivalent to:
ATLINKS USA, Inc.
c/o Thomson
11721 B Alameda Ave.
Socorro, Texas 79927
• Pay any charges billed to you by the Exchange Center for service not
covered by the warranty.
• Insure your shipment for loss or damage. ATLINKS accepts no
liability in case of damage or loss.
• A new or refurbished unit will be shipped to you freight prepaid.
What your warranty
does not
cover:
• Customer instruction. (Your Owner’s Manual provides information
regarding operating instructions and user controls. Any additional
information, should be obtained from your dealer.)
• Installation and setup service adjustments.
• Batteries.
• Damage from misuse or neglect.
• Products which have been modified or incorporated into other
products.
• Products purchased or serviced outside the USA.
• Acts of nature, such as but not limited to lightning damage.
Product Registration:
• Please complete and mail the Product Registration Card packed
with your unit. It will make it easier to contact you should it
ever be necessary. The return of the card is not required for
warranty coverage.
ACCESSORY INFORMATION
To place order, have your Visa, MasterCard, or Discover Card ready
and call toll-free 1-800-338-0376.
A shipping and handling fee will be charged upon ordering.
We are required by law to collect appropriate sales tax for each
individual state, country, and locality to which the merchandise is
being sent.
Items are subject to availability.
*Prices are subject to change without notice.
DESCRIPTION
Belt clip 5-2658 (translucent gray)
Replacement battery 5-2660
Headset 5-2425
MODEL NO.
NOTE: The RBRC seal on the battery used in your
ATLINKS USA, Inc. product indicates that we
are participating in a program to collect and
recycle Nickel Cadmium batteries throughout the
United States. Please call 1-800-8-BATTERY for
information or contact your local recycling center.
Limitation of Warranty:
• THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY
APPLICABLE TO THIS PRODUCT. ALL OTHER WARRANTIES,
EXPRESS OR IMPLIED (INCLUDING ALL IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE)
ARE HEREBY DISCLAIMED. NO VERBAL OR WRITTEN
INFORMATION GIVEN BY ATLINKS USA, INC., ITS AGENTS, OR
EMPLOYEES SHALL CREATE A GUARANTY OR IN ANY WAY
INCREASE THE SCOPE OF THIS WARRANTY.
• REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS
WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER.
ATLINKS USA, INC. SHALL NOT BE LIABLE FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF
THIS PRODUCT OR ARISING OUT OF ANY BREACH OF ANY
EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. THIS
DISCLAIMER OF WARRANTIES AND LIMITED WARRANTY ARE
GOVERNED BY THE LAWS OF THE STATE OF INDIANA. EXCEPT TO
THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED TO THE
APPLICABLE WARRANTY PERIOD SET FORTH ABOVE.
How state law relates to this warranty:
• Some states do not allow the exclusion nor limitation of
incidental or consequential damages, or limitations on how long
an implied warranty lasts so the above limitations or exclusions
may not apply to you.
• This warranty gives you specific legal rights, and you also may
have other rights that vary from state to state.
If you purchased your product outside the USA:
• This warranty does not apply. Contact your dealer for
warranty information.
DEREGISTRATION
1YES 2NO
Then the handset displays
CONFIRM? 1YES 2NO
.
MOVE NEAR TO
BASE
CONFIRM
1YES 2NO
8. Use the touch-tone pad to enter
1YES
or use CALLER ID/VOL (- or +)
button to scroll to
1YES
.
NOTE: Press the *EXIT button once to keep the previous
setting and return to the main menu screen.
9. Press the MUTE/PROG button to confirm the deregistration.
DE-REGISTER
... displays for 30 seconds, then
HANDSET # DE-REGISTERED
displays for one second followed by
HANDSET NEEDS REGISTRATION
HANDSET NEEDS
REGISTRATION
DEFAULT SETTING
1YES 2NO
NOTE: If you choose “YES” all settings in the programmable
menu return to the factory default settings.
NOTE: Press the *EXIT button once to keep the previous
setting and return to the main menu.
7. Press the MUTE/PROG button to save your selection, and return
to the main menu. The default setting you choose shows on the
display for two seconds, and you will hear a confirmation tone.
PAGING ALL HANDSETS FROM A HANDSET
1. Make sure the originating phone is OFF (not in talk mode).
2. Press and release the INT button on a handset.
PAGING
EXTENSION?
shows in the display.
3. Use the touch-tone pad to enter the handset number you want to
page. (1=to page Handset 1, 2=to page handset 2, 3=to page
handset 3, 4=to page handset 4, and 5=to page all handsets)
4. To cancel the page on the originating handset, press the *EXIT,
INT, or TALK/CALLBACK button.
REPLACING THE BATTERY
CAUTION: to reduce the risk of fire or personal injury,
use only the 5-2660 replacement battery listed on the
accessory order form, which is compatible with this unit.
CAUTION: To ensure the phone/battery performance, use
ONLY 25832 charging cradle, and 25831, 25833, or 25835 base
for battery charging only.
DEFAULT SETTING
YES
Headset plug
Headset jack
Slot for
belt clip
Slot for
belt clip

Navigation menu
