Trilliant Networks, Inc. Wireless Mesh WAN Backhaul Node Manual
Manual
SECUREMESH 1 WATT RADIO MODULE
INSTALLATION INSTRUCTIONS
May30,2009
TheTrilliant1WattSecureMeshRadioModuleisa2.4GHz802.15.4transceiverradiomoduleintended
foruseinelectricmeters,gasmeters,andnetworkproductandinhomeproductsforutility
applications.Themodulecontainscastellationsforconnectionstoexternalantennaboard,suchasthe
1.1dBi“L”shapedantenna.ThemodulealsoallowsdirectconnectionforanoptionalU.FLconnector.
Powerissuppliedbyahostmodulewithanominalvoltageof3.3volts.
Specificationoftheradiomodule:
IEEEstandard: 802.15.4
PowerOutput: +30dBm
RadioSensitivity: ‐99dBm
RFDataRate: 250kbps
OperatingFrequency: 2.400‐2.483GHz
NetworkTopology: Mesh
Modulation: O‐QPSK
PhysicalDimensions: 1.400”x2.075”
AntennaOptions: CastellationtoExternalBoard,U.FL
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates uses and can
radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
Trilliant, Inc. 1100 Island Drive, Suite 201 Redwood City, CA 94065 (650) 204 5050 Page 2 of 3
INDUSTRY CANADA STATEMENTS
Operation is subject to the following two conditions: (1) this device may not cause interference,
and (2) this device must accept any interference, including interference that may cause
undesired operation of the device.
To reduce potential radio interference to other users, the antenna type and its gain should be so
chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that permitted
for successful communication.
This device has been designed to operate with the antennas listed below, and having a
maximum gain of 6.0 dB. Antennas not included in this list or having a gain greater than 6.0 dB
are strictly prohibited for use with this device. The required antenna impedance is 50 ohms. The
maximum gain antenna is the Mobile Mark OD6-2400 (6dbi gain).
Antennas Approved for use
Mobile Mark OD6-2400 (6dBi gain)
PCB Trace Inverted-L Antenna (1.1 dBi gain)
Trilliant Responsibilities to comply with FCC and Industry Canada Regulations
The SecureMesh 1 Watt Radio Module has been certified for integration into products only by a
professional under the following conditions:
1. The antenna(s) must be installed such that a minimum separation distance of 20cm is
maintained between the radiator (antenna) and all persons at all times.
2. The transmitter module must not be co-located or operating in conjunction with any other
antenna or transmitter.
As long as the two conditions above are met, further transmitter testing will not be required.
However, Trilliant is still responsible for testing their end-product for any additional compliance
requirements required with this module installed (for example, digital device emissions, PC
peripheral requirements, etc.).
IMPORTANT NOTE: In the event that these conditions cannot be met (for certain
configurations or co-location with another transmitter), then the FCC and Industry Canada
authorizations are no longer considered valid and the FCC ID and IC Certification Number
cannot be used on the final product. In these circumstances, Trilliant integrator will be
responsible for re-evaluating the end product (including the transmitter) and obtaining a
separate FCC and Industry Canada authorization.
End Product Labeling
The Trilliant SecureMesh 1 Watt Radio Module is labeled with its own FCC ID and IC Certification
Number. If the FCC ID and IC Certification Number are not visible when the module is installed inside
another device, then the outside of the device into which the module is installed must also display a
label referring to the enclosed module. In that case, the final end product must be labeled in a visible
area with the following:
“Contains Transmitter Module FCC ID: TMB-EM0069”
“Contains Transmitter Module IC: 6028A-EM0069
Trilliant, Inc. 1100 Island Drive, Suite 201 Redwood City, CA 94065 (650) 204 5050 Page 3 of 3
or
“Contains FCC ID: TMB-EM0069
“Contains IC: 6028A-EM0069
The Trilliant SecureMesh 1 Watt Radio Module must only use the approved antenna(s) listed above,
which have been certified with this module.
Trilliant will not provide information to the end user regarding how to install or remove this RF
module or change RF related parameters in the user manual of the end product. The module
will be professionally installed inside a meter. The meter will be professionally installed by
employees of a utility – who are professionals in their field.
The user manual for the end product must include the following information in a
prominent location:
“To comply with FCC and Industry Canada RF radiation exposure limits for general population,
the antenna(s) used for this transmitter must be installed such that a minimum separation
distance of 20cm is maintained between the radiator (antenna) and all persons at all times and
must not be co-located or operating in conjunction with any other antenna or transmitter.”
