User Manual Lowband Transmitter
Lowband Transmitter
Telecom Rack
Network Comms Chassis
Ethernet
Router/Hub
(
ma
y
be
p
art of a modem
)
Power Amp Chassis(es)
RF Amp Power Supply
Controller
Exciter Chassis
Modulator
Controller
PPS 10 MHz
Power Supply Chassis(es)
Surge Suppressor
Power Supply
& Char
g
er
Battery
110 VAC
110 VAC
10-16 VDC
Various
Any two of…
ISDN Modem
DSL Modem
Cable Modem
POTS Modem
CDPD Phone
Cell Phone with Modem
Point-to-Point Radio (e.g., 2.4 GHz)
Serial Port to External Device
Ethernet to External Device
Industrial PC Chassis
Thunderbolt Serial Port
Ethernet
Computer Stuff
Notes:
A single 110 VAC surge suppressor protects the whole rack.
The RF Amp has its own 110 VAC power supply.
Everything else runs off a single 10-16 VDC, battery-backed power supply/charger.
The controller in the power amp chassis runs off the 10-16 VDC (not the 110 VAC).
This power supply architecture avoids the need for a battery-backed AC inverter.
Both antennas need lightening/EMP protection.
The various comms connections need appropriate protection.
Connections within chassis are not shown.
The power supply/charger may have status that needs to be connected to the PC.
