Chapter 4

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-1

Chapter 4

Circuit Descriptions

4.0 (A1) UHF Exciter Assembly

(1278-1400; Appendix C)

The (A1) UHF Exciter Assembly

contains (A1) a UHF Exciter Tray

(1142458 or 1245-1100), (A4 & A5)

two Variable Gain/Phase Trays (1245-

1200), (A6) a Metering Panel (1136811

or 1245-1400), (A7) a UHF Receiver

Tray (1142479 or 1265-1100), (A8) an

Exciter AC Distribution Assembly

(1245-1500) and (A9) a Remote

Interface Assembly (1245-1801).

The (A7) UHF Receiver Tray, uses the

ON Channel RF input, at J5 for 75 or

J1 for 50, and produces a Combined

IF output at J4 that connects to the

UHF Exciter at J6.

The (A1) UHF Exciter Tray, if the

Optional Modulator Kit is present in the

tray, takes the Baseband Audio and

Video Inputs and mixes them with

internally generated 45.75 MHz and

41.25 MHz Ifs that combines them.

The Combined IF, from the Receiver

Tray or from the Modulator Kit, is

upconverted to the On Channel RF

output frequency by mixing it with a

L.O. signal generated by the Channel

Oscillator Assembly. The RF Output of

the UHF Exciter at J15 connects to (A3)

a Splitter which splits the RF two ways

with the RF Output #1 connected to the

input of the (A5) Variable Gain/Phase

Tray (1245-1200) and the RF Output

#2 connected to the input of the (A4)

Variable Gain/Phase Tray (1245-1200).

The output of the (A4) Variable

Gain/Phase Tray connects to (A2) the

Side A Amplifier Array Assembly. The

output of the (A5) Variable Gain/Phase

Tray connects to (A3) the Side B

Amplifier Array Assembly.

4.0.1 Control and Status

The Control and Status of the

Translator are provided by the Meter

indications on the Metering Panel and

the Variable Gain Phase Trays. There

are also Control, Status and LED

Indications located on the front panel of

the UHF Exciter Tray. The switches and

LED indicators, which are mounted so

that the switches and LEDs are

operated or viewed from the front

Panel of the UHF Exciter, are part of the

Transmitter Control Board (1245-

1101). On the UHF Exciter Tray, switch

(S1) is an Operate/Standby Switch that

provides the Operate Commands

(Enables), when in Operate, to each of

the Amplifier Arrays. The power supply

Enable is needed to turn on the

Switching Power Supplies located in

each of the UHF Amplifier Trays. The

Fan Enable is needed to turn on the

exhaust fan in the (Optional) External

Exhaust Kit. When the UHF Exciter is

in Operate, the Green LED (DS2) is On

and when in Standby the Amber LED

(DS1) is On. NOTE: If the Translator

does not switch to Operate, when S1 is

switched to Operate, check that a

Dummy Jumper Plug is connected to

Jack J7, with a Jumper between Pins 1

& 2, located on (A9) the Remote

Interface Assembly in the Single UHF

Exciter Assembly. The Jumper provides

the Interlock to the UHF Exciter needed

for the operation of the Translator. If

the Interlock is present, the Green LED

(DS5), located on the Transmitter

Control Board, should be lit.

Operation of the Translator is controlled

by the front panel switches located on

the UHF Exciter Tray. During Normal

operation of the Translator, Switch S2

should be in the Auto position. The

front panel of the UHF Exciter also has

LEDs that indicate a Video Fault (Loss),

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-2

Red LED (DS9) and a VSWR Cutback,

Amber LED (DS7).

4.0.2 RF, Baseband Input and

Remote Connections

The RF, Baseband Video and Audio

Inputs to the Translator, connect to the

(A9) Remote Interface Panel located on

the rear of the Single UHF Exciter

Assembly. The On Channel RF input

connects to the “F” connector J3 for

75 or the “N” connector J1 for 50.

If the (Optional) Modulator Kit is

present, the Baseband Video Input

connects to Jack J2 that is wired to J1

on the Exciter. The Baseband Audio

Input connects to the Terminal Block

TB1 for Balanced Audio or to Jack J6

that is wired to J3 on the Exciter, for

Composite, Stereo, Audio.

Remote Monitoring and Operation of

the Translator is provided through the

Jacks (J8, J9 & J10) located on (A9) the

Remote Interface Assembly mounted

toward the rear of the Single UHF

Exciter Assembly. Jack (J7) should

have a dummy plug connected to it,

which has a jumper connected between

Pins 1 & 2, that provides the Interlock

to the Exciter needed to operate the

Translator. If the Jumper is missing,

the Translator will not switch to

Operate. If remote connections are

made to the Translator they should be

made through the plugs provided in the

Installation Material as noted on the

Interconnect Drawing (1278-8400) for

the Single UHF Exciter.

4.0.3 AC Input

The Single UHF Exciter Assembly needs

an AC input of 208/240 VAC at 20

Amps. The AC Input to the Single UHF

Exciter Assembly connects to (A8) the

AC Distribution Assembly, UHF Exciter

Assembly (1245-1500) located in the

right, center rear of the Cabinet. The

Assembly contains the 4 Terminal Block

(TB1) to which the 208/240 VAC

connects. Line 1 to TB1-1A, Line 2 to

TB1-3A and Safety Ground to TB1-2A.

The AC Distribution Panel contains CB1

one 20 Amp Circuit Breaker that

supplies the AC to the rest of the Single

Exciter Assembly.

The Input AC is connected to (CB1) the

Main AC Circuit Breaker (20 Amps).

The output of CB1 has three MOVs,

VR1 connected from Line 1 to ground,

VR3 connected from Line 2 to ground

and VR3 connected across the two legs.

The AC output of CB1 connects to A1

and A2 that are IEC Outlet Strips. The

(A1) Exciter Tray and the (A4) Variable

Gain/Phase Tray plug into the (A1) IEC

Outlet Strip. The (A5) Variable

Gain/Phase Tray, the (A8) Metering

Panel and the (A7) Receiver Tray plug

into the (A2) IEC Outlet Strip.

When the Circuit Breaker CB1,

mounted on the AC Distribution

Assembly, is switched On, +12 VDC

from the Exciter, is supplied to the two

Amplifier Arrays for the operation of the

LED Status Indicators in each of the

UHF Amplifier Trays. The +12 VDC is

also connected to the (Optional)

External Exhaust Kits in each of the

Amplifier Arrays, if purchased.

4.1 (A7) UHF/VHF Receiver

(1142479 or 1265-1100; Appendix

The UHF/VHF Receiver Tray

w/(Optional) Frequency Correction

selects the desired UHF or VHF On

Channel Input Signal and converts it to

a Combined IF Signal of 45.75 MHz

Visual + 41.25 MHz Aural. The Tray

also has provisions for a Frequency

Correction Option that consists of a

VCXO Channel Oscillator Assembly with

a PLL Circuit which maintains an exact

IF Output Frequency, over the capture

range of the PLL circuit, even if the

Input UHF or VHF frequency varies.

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-3

RF Signal Path

4.1.1 (A7) 50Ω Filter, DC

Multiplexed, UHF (1035-1204), VHF

L.B. (1035-1902) or VHF H.B.

(2065-1024) or 75Ω, UHF (1035-

1207), VHF L.B. (1035-1903) or

VHF H.B. (2065-1023); Appendix

The RF Input to the Tray, (-61 dBm to -

16 dBm in Level), is fed through J1 for

50Ω to (A7) the input 50Ω Filter, DC

Multiplexed (1035-1204 UHF, 1035-

1902 VHF LB or 2065-1024 VHF HB) or

through J5 for 75Ω to (A7) the 75Ω

input Filter, DC Multiplexed (1035-1207

UHF, 1035-1903 VHF LB or 2065-1023

VHF HB), which is of a double tuned

design that is adjusted to the desired

Input UHF or VHF Channel Frequency.

Note: If the input signal is greater than

-25dBm, an attenuator should be used

to limit the level to -25dBm. +12 VDC,

for use by an (Optional) external

Preamplifier Assembly, connects to the

filter through F1 a 1 Amp Fuse. This

+12 VDC is DC Multiplexed onto the

input signal cable from the

Preamplifier. DS1 a Red LED located

on TB1 in the Tray will be lit if the +12

VDC is present on the input cable. If a

Preamplifier is not used, F1 should be

removed and DS1 should not be lit.

4.1.2 (A8) Dual Stage Amplifier

Assembly (1227-1503) ; Appendix

The signal is next amplified +12 dB to

approximately the -49 to -4 dBm level

by a low noise amplifier located on (A8-

A1) the Dual Stage Amplifier Board

(1227-1501) that is contained in (A8)

the Dual Stage Amplifier Assembly

(1227-1503). The board has

approximately +13 dB or +26 dB of

gain, depending on whether Jumper W1

on J5 is in place. The amplified output

connects out of the board at J2.

4.1.3 (A9) Channel Filter, UHF

(1007-1101), VHF L.B. (1034-

1202) or VHF H.B. (2065-1000) ;

Appendix D)

The signal is then filtered in (A9) a

Channel Filter (1007-1101 UHF, 1034-

1202 VHF LB or 2065-1000 VHF HB)

and then applied back to (A8-A1) the

Dual Stage Board at J3.

More amplification of the signal takes

place on the Dual Stage Board, if

needed. Jumper W1 on J7 should be

removed if the Receiver Input level is

greater than -40dBm.

4.1.4 (A10) Downconverter

Amplifier Assembly, 45.75 MHz.

(1227-1505) ; Appendix D)

The output is connected to (A10) the

Downconverter Amplifier Assembly

(1227-1505) that contains (A10-A1)

the Downconverter Amplifier Board

(1227-1502). The RF, at the -47 dBm

to -2 dBm Level, connects to the "R"

Input Jack of the Mixer Z1 located on

the Downconverter Amplifier Board.

Local Oscillator Signal Path

The Local Oscillator Signal is derived

from a cut to channel crystal mounted

in an oven that is factory set at 45° C.

The Oscillator operates at 1/8 for UHF,

1/4 for VHF High Band or 1/2 for VHF

Low Band of the desired local oscillator

frequency.

4.1.5 (A4) Channel Oscillator

Assembly (1145-1202) ; Appendix

The crystal is mounted on (A4-A1) the

Channel Oscillator Board, Dual Oven

(1145-1201), that is part of the

Channel Oscillator Assembly (1145-

1202). The oscillator circuitry is a

modified Colpitts design operating in a

separate oven set at 50° C. for

improved stability. If the Frequency

Correction Option is purchased, the

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-4

VCXO Channel Oscillator Assembly

(1145-1206), which contains the VCXO

Channel Oscillator Board (1145-1204),

is used in place of the standard

Channel Oscillator Assembly, and an

AFC voltage from the PLL circuit

maintains the frequency of the VCXO.

4.1.6 (A5-A1) x8 Multiplier Board

(1227-1002), x2 Multiplier Board

(1227-1524) or x4 Multiplier Board

(1227-1525) ; Appendix D)

The output of the Channel Oscillator is

connected to the (A5-A1) the x8

Multiplier Board (1227-1002) for UHF,

the x4 Multiplier Board (1227-1525) for

VHF HB or the x2 Multiplier Board

(1227-1524) for VHF LB, which is

located in (A5) the Multiplier Enclosure

(1265-1125). The proper multiplier

board takes the output of the Channel

Oscillator (+3 dBm) and multiplies it

eight, four or two times by a series of

three, two or one x2 Broadband

Doublers (2x2x2 = x8), which produces

the L.O. signal on the desired

frequency needed for the upconversion

process. The signal is then amplified to

the +16 dBm level. A sample of the

multiplied L.O. Signal is fed to a

detector circuit which lights the Green

LED DS1 that indicates that the L.O. is

present at the Output Jack J2 of the

Multiplier Board. This Green LED is

seen through a hole the lid of the

Multiplier Assembly and is an

indication, when lit, that there is a

signal present at the output of the

Multiplier Board.

4.1.7 (A6) L.O. Filter, UHF (1007-

1101), VHF L.B. (1034-1211) or

VHF H.B. (2065-1000) ; Appendix

The L.O. signal is filtered in (A6) a L.O.

Filter 1007-1101 UHF, 2065-1000 VHF

HB or 1034-1211 VHF LB) and then

sent (+15 dBm) to J2 on (A10-A1) the

Downconverter Amplifier Board.

The L.O. Input to the Downconverter

Amplifier Board is connected thru a 3

dB matching pad to the "L" Input of the

Mixer (Z1) at a +12 dBm level.

Combined IF Signal Path

The L.O. and the RF signals are mixed

in the Mixer Stage of the

Downconverter Amplifier Board to

produce the desired IF difference

frequency at -55 dBm to -10 dBm in

level, depending on the RF Input Level.

4.1.8 (A11-A1) IF Filter/ALC Board

(1227-1504) ; Appendix D)

The Combined IF Signal is routed to

(A11-A1) the IF Filter/ALC Board

(1227-1504), which is mounted in

(A11) the IF Filter/ALC Enclosure

(1265-1105). The IF Filter/ALC Board

contains a Pin Diode Attenuator circuit

which is part of the Automatic Level

Control (ALC) that controls the level of

the IF Signal to the two stage amplifier

ICs U1 and U2.

4.1.9 (A11-A2) (Optional) SAW

Filter/Amplifier Board (1035-1211)

; Appendix D)

The (Optional) (A11-A2) SAW

Filter/Amplifier Board (1035-1211) is

also contained in the IF Filter/ALC

Enclosure. The SAW Filter/Amplifier

Board connects to J5 and J6 of the IF

Filter/ALC Board if more attenuation of

the Out Of Band products is needed. If

the SAW Filter/Amplifier Board is not

needed, a jumper connects the

Combined IF from J5 to J6 on the IF

Filter/ALC Board.

The Combined IF is then bandpass

filtered to the needed 6 MHz IF

bandwidth around the 41.25 MHz +

45.75 MHz Combined IF signal and

amplified by U3 to the -41 dBm to +4

dBm Level before it is split. One output

is detected by U4 for use as the ALC

reference level to the Pin Diode

Attenuator Circuit. The ALC

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-5

comparator drives the Pin Diode

Attenuator Circuit to maintain the

desired output level, typically +2 dBm.

The other split output connects to J2

the Combined IF Output of the board

that is cabled to the IF Output Jack of

the Tray at J4 (+2 dBm).

Frequency Correction Option

If the Frequency Correction Option

(1227-1528) is purchased, (A13) the IF

Filter/Limiter Board (1109-1001), (A14)

the IF PLL Board (1109-1002), the

(A15) IF Carrier Oven Oscillator Board

(1100-1206), (A4) the VCXO Channel

Oscillator Assembly (1145-1206) and

(A16) an IF Amplifier Board, High Gain

(1197-1126) are part of the System.

4.1.10 (A13) (Optional) IF

Amplifier Board (1197-1126) ;

Appendix D)

A Sample of the amplified and ALC

controlled signal from the IF Filter/ALC

Board is directed to the IF Amplifier

Board, High Gain (1197-1126) where it

is amplified and connected to J2 on

(A13) the IF Filter/Limiter Board (1109-

1001).

4.1.11 (A13) (Optional) IF

Filter/Limiter Board (1109-1001) ;

Appendix D)

The IF is filtered by a SAW Filter, which

passes Visual Carrier and Aural Carrier

only, and amplified before it is split.

The Aural IF Output is not used in this

Tray. The other output of the splitter is

amplified and applied to a Notch Filter.

The Notch Filter is tuned to the Aural

Frequency by C17 and R10 which

reduces or eliminates the Aural IF from

the Visual IF signal. The Visual IF Only

signal then connects to a video detector

circuit which in conjunction with U5

strips the video from the Visual IF

signal. The IF CW Signal is amplified

and buffered before it is connected to

the output of the board at J6. The IF

CW connects to J2 of (A14) the IF PLL

Board (1109-1002).

4.1.12 (A14) (Optional) IF PLL

Board (1109-1002) ; Appendix D)

The IF CW Signal (+3 dBm) on the IF

PLL Board is wired to U1 a Divider IC

which, in conjunction with U2, sets up

one of the reference signals to the

comparator circuit. The other reference

signal is derived from the 50 kHz

reference Input at J4 which is a divided

down 50 kHz sample of the 38.9 MHz

signal generated on (A15) the IF

Carrier Oven Oscillator Board (1100-

1206).

4.1.13 (A15) (Optional) IF Carrier

Oven Oscillator Board (1100-1206)

; Appendix D)

The 38.9 MHz IF Carrier Oven Oscillator

Board is used instead of the 45.75 MHz

IF Carrier Oven Oscillator Board to

minimize the interference between the

generated 45.75 MHz IF and the signal

generated on the (A15) IF Carrier

Oscillator Board. The 38.9 MHz signal

itself is not used, just the divided down

50 kHz reference of the 38.9 MHz

Signal is used. The two reference

signals applied to the IF PLL Board are

compared by U2 and a difference

voltage (AFC) is produced. The

difference voltage (AFC), approximately

-3 VDC, is fed from J3 of the board to

FL2 of (A4) the VCXO Assembly. If the

frequency of the VHF or UHF Input to

the Tray should drift, the ALC voltage

will change to increase or decrease the

output frequency of the VCXO

Assembly which increases or decreases

the L.O. Frequency that maintains the

IF Frequency at the standard 45.75 +

41.25 MHz Frequency. If the frequency

of the Input Signal should drift out of

the capture range of the PLL Circuit,

DS1 the Red LED Unlock Indicator,

located on the IF PLL Board, lights.

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-6

Voltages for Operation of the Tray

The AC input to the Tray is 117 VAC or

230 VAC and is directed thru Jack J2, of

the (A1) Power Entry Module (1265-

1104), to the step down Toroid (A2).

The Power Entry Module contains an

On/Off Switch, a 4 Amp Slo-Blo Fuse

and three MOVs which protect the Tray

from transients or surges which may

occur on the AC Input Lines. When the

On/Off Switch is switched On, AC is

applied to the (A2) Toroid. The Toroid

steps down the voltage into two 16 VAC

outputs which are fed to (A3) the

+12V(3A)/-12V Power Supply Board

(1092-1206).

4.1.14 (A3) +12V(3A)/-12V Power

Supply Board (1092-1206) ;

Appendix D)

The 16 VAC Inputs are connected to

the two full wave bridge networks one

for +12 VDC and one for -12 VDC. The

output of the +12 VDC rectifier is fed to

three 7812 IC regulators (U1, U2 and

U3) and the output of the -12 VDC

rectifier is fed to one 7912 IC regulator

(U4). The ±12V Power Supply Board

provides the voltage regulated and

current limited +12 VDC and -12 VDC

to the rest of the boards in the Tray.

+12VDC for External Preamplifier

+12 VDC is also applied through a 1

Amp Fuse F1 to (A7) the input DC

Multiplexed UHF or VHF Filter. The +12

VDC is multiplexed in the Filter onto the

input coaxial cable that connects from

the (Optional) Remote Preamplifier Unit

to the Receiver Tray. This supplies the

Preamplifier with the +12 VDC needed

for operation. The Red LED DS1

mounted on the Terminal Block TB1 will

be lit if the +12 VDC is applied to the

coaxial cable. Note: If the Red LED,

DS1, is lit, the +12 VDC may damage

Test Equipment that is connected to the

input of the Receiver Tray. If a

Preamplifier Assembly is not part of

your System, F1 should be removed,

therefore DS1 should not be lit and the

+12 VDC is not multiplexed onto the

input coaxial cable. A spare Fuse for F1

is supplied and stored near the fuse

holder for F1.

4.2 (A4) UHF Exciter (1245-1100;

Appendix C)

4.2.1 (A4) (Optional) Aural IF

Synthesizer Board, 4.5 MHz (1265-

1303; Appendix D)

The aural IF synthesizer board

amplifies each of the three possible

audio inputs and the amplifier circuits

that supply the single audio output. The

balanced audio or the composite audio

input is connected to the board while

the subcarrier audio (SCA) input can be

connected at the same time as either of

the other two inputs. The board has the

4.5-MHz voltage-controlled oscillator

(VCO) and the aural modulation

circuitry that produces the modulated

4.5-MHz output. The board also

contains a phase lock loop (PLL) circuit

that maintains the precise 4.5-MHz

separation between the aural (41.25

MHz) and the visual (45.75 MHz) IF

frequencies.

4.2.1.1 Balanced Audio Input

The first of the three possible baseband

inputs to the board is a 600-Ω,

balanced-audio input (+10 dBm) that

enters through jack J2, pins 1 (+), 2

(GND), and 3 (-), and is buffered by

U1B and U1C. Diodes CR1 to CR4

protect the input stages of U1B and

U1C if an excessive signal level is

present on the input leads of jack J2.

The outputs of U1B and U1C are

applied to differential amplifier U1A;

U1A eliminates the common mode

signals (hum) on its input leads. A

pre-emphasis of 75 ms is provided by

R11, C11, and R10 and can be

eliminated by removing jumper W5 on

J5. The signal is then applied to

amplifier U1D whose gain is controlled

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-7

by jumper W3 on J11. Jumper W3 on

jack J11 is positioned according to the

input level of the audio signal (0 or +10

dBm). If the input level is

approximately 0 dBm, the mini-jumper

should be in the high gain position

between pins 1 and 2 of jack J11. If the

input level is approximately +10 dBm,

the mini-jumper should be in low gain

position between pins 2 and 3 of jack

J11. The balanced audio is then

connected to buffer amplifier U2A

whose input level is determined by the

setting of balanced audio gain pot R13.

The output of the amplifier stage is

wired to the summing point at U2D, pin

13.

4.2.1.2 Composite Audio Input

The second possible audio input to the

board is the composite audio (stereo)

input at BNC jacks J3 and J13. The two

jacks are loop-through connected; as a

result, the audio can be used in another

application by connecting the unused

jack and removing W4 from J12.

Jumper W4 on jack J12 provides a

75Ω-input impedance when the jumper

is between pins 1 and 2 of jack J12 and

a high impedance when it is between

pins 2 and 3. Diodes CR9 to CR12

protect the input stages of U6A and

U6B if an excessive signal level is

applied to the board. The outputs of

U6A and U6B are applied to differential

amplifier U2C, which eliminates

common mode signals (hum) on its

input leads. The composite input signal

is then applied to amplifier U2B; the

gain of this amplifier is controlled by

composite audio gain pot R17. The

composite audio signal is connected to

the summing point at U2D, pin 13.

4.2.1.3 Subcarrier Audio Input

The third possible input to the board is

the SCA input at BNC jack J4. The SCA

input has an input impedance of 75Ω

that can be eliminated by removing

jumper W2 from pins 1 and 2 of J14.

The SCA input is bandpass filtered by

C66, C14, R22, C15, C67, and R23 and

is fed to buffer amplifier U3A. The

amplified signal is then applied though

SCA gain pot R24 to the summing point

at pin 13 of U2D.

4.2.1.4 Audio Modulation of the VCO

The balanced audio, or the composite

audio and/or the SCA-buffered audio

signals, are fed to the common junction

of resistors R14, R20, and R27 that

connect to pin 13 of amplifier U2D. The

output audio signal at pin 14 of U2D is

typically .8 Vpk-pk at a ±25-kHz

deviation for balanced audio or .8 Vpk-

pk at ±75-kHz deviation for composite

audio as measured at TP1. This signal

is applied to VCO U10. A sample of the

deviation level is amplified, detected by

U7A and U7B, and connected to J10 on

the board. This audio-deviation level is

connected to the front panel meter

through the transmitter control board.

The audio is connected to CR13 to

CR16; these are varactor diodes that

frequency modulate the audio signal

onto the generated 4.5-MHz signal in

U10. U10 is the 4.5-MHz VCO that

generates the 4.5-MHz continuous

wave (CW) signal. The output

frequency of this signal is maintained

and controlled by the correction voltage

output of U5 PLL integrated circuit (IC).

The audio-modulated, 4.5-MHz signal is

fed to amplifiers U11A and U11B. The

output of U11B is connected to the 4.5-

MHz output jacks at J7 and J8.

4.2.1.5 Phase Lock Loop (PLL) Circuit

A sample of the signal from the 4.5-

MHz aural VCO at the output of U11A is

applied to PLL IC U5 at the Fin

connection. In U5, the signal is divided

down to 50 kHz and is compared to a

50-kHz reference signal. The reference

signal is a divided-down sample of the

visual IF, 45.75-MHz signal that is

applied to the oscillator-in connection

on the PLL chip through jack J6 on the

board. These two 50-kHz signals are

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-8

compared in the IC and the fV, and fR

is applied to the differential amplifier

U3B. The output of U3B is fed back

through CR17 to the 4.5-MHz VCO IC

U10; this sets up a PLL circuit. The 4.5-

MHz VCO will maintain the extremely

accurate 4.5-MHz separation between

the visual and aural IF signals; any

change in frequency will be corrected

by the AFC error voltage.

PLL chip U5 also contains an internal

lock detector that indicates the status

of the PLL circuit. When U5 is in a

"locked" state, pin 28 goes high and

causes the green LED DS1 to

illuminate. If the 4.5-MHz VCO and the

45.75-MHz oscillator become

"unlocked," out of the capture range of

the PLL circuit, pin 28 of U5 will go to a

logic low and cause the red LED DS2 to

light. A mute output signal from Q3

(unlock mute) will be applied to jack

J9. This mute is connected to the

transmitter control board.

4.2.1.6 Voltage Requirements

The ±12 VDC needed for the operation

of the board enters through jack J1.

The +12 VDC is connected to J1-3 and

filtered by L2, C3, and C4 before it is

connected to the rest of the board. The

-12 VDC is connected to J1-5 and

filtered by L1, C1, and C2 before it is

connected to the rest of the board. The

+12 VDC is connected to U8 and U9;

these are 5-volt regulator ICs that

provide the voltage to the U10 and U5

ICs.

4.2.2 (A5) (Optional) Sync Tip

Clamp/ Modulator Board (1265-

1302; Appendix D)

The sync tip clamp/modulator board is

made up of five circuits: the main video

circuit, the sync tip clamp circuit, the

visual modulator circuit, the aural IF

mixer circuit, and the diplexer circuit.

The sync tip clamp/modulator board

takes the baseband video or 4.5-MHz

composite input that is connected to

the video input jack (either J1 or J2,

which are loop-through connected) and

produces a modulated visual IF + aural

IF output at output jack J20 on the

board. The clamp portion of the board

maintains a constant peak of sync level

over varying average picture levels

(APL). The modulator portion of the

board contains the circuitry that

generates an amplitude-modulated

vestigial sideband visual IF signal

output that is made up of the baseband

video input signal (1 Vpk-pk)

modulated onto an externally

generated 45.75-MHz IF carrier

frequency. The visual IF signal and the

aural IF signal are then combined in the

diplexer circuit to produce the visual IF

+ aural IF output that is connected to

J20, the IF output jack of the board.

4.2.2.1 Main Video Signal Path (Part 1

of 2)

The baseband video or the 4.5-MHz

composite input connects to the board

at J2. J2 is loop-through connected to

J1 and terminated to 75 watts if jumper

W4 is on jack J3. With jumper W4

removed, the input can be connected to

another translator through J1; J1 is

loop-through connected to J2.

Test point TP1 is provided to monitor

the level of the input. The input is fed

to the non-inverting and inverting

inputs of U1A, a differential amplifier

that minimizes any common-mode hum

that may be present on the incoming

signal. Diodes CR1 to CR4 form a

voltage-limiter network in which, if the

input voltages exceed the supply

voltages for U1A, the diodes conduct,

preventing damage to U1A. CR1 and

CR3 conduct if the input voltage

exceeds the negative supply and CR2

and CR4 conduct if the input voltage

exceeds the positive supply voltage.

The video output of U1A is connected

to J22 on the board. Normally, the

video at J22 is jumpered to J27 on the

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-9

board. If the 4.5-MHz composite input

kit is purchased, the 4.5-MHz

composite signal at J22 connects to the

external composite 4.5-MHz filter board

and the 4.5-MHz bandpass filter board.

These two boards provide the video-

only signal to J27 and the 4.5-MHz

intercarrier signal to J28 from the 4.5-

MHz composite input. The video

through video gain pot R12 (adjusted

for 1 Vpk-pk at TP2) connects to

amplifier U1B.

The output of U1B, if the delay

equalizer board is present in the tray,

connects the video from J6, pin 2, to

the external delay equalizer board and

back to the sync tip clamp/modulator

board at J6, pin 4. If the delay

equalizer board is not present, the

video connects through jumper W1 on

J5, pins 1 and 2. The delay equalizer

board plugs directly to J6 on the sync

tip clamp/modulator board. The video

from J6, pin 4, is then connected

through jumper W1 on J5, pins 2 and

3, to amplifier Q1. The output of Q1

connects to Q2; the base voltage of Q2

is set by the DC offset voltage output of

the sync tip clamp circuit.

4.2.2.2 Sync Tip Clamp Circuit

The automatic sync tip clamp circuit is

made up of U4A, Q7, U3B, and

associated components. The circuit

begins with a sample of the clamped

video that is split off from the main

video path at the emitter of Q3. The

video sample is buffered by U3A and

connected to U4A. The level at which

the tip of sync is clamped,

approximately -1.04 VDC as measured

at TP2, is set by the voltage-divider

network connected to U4A. If the video

level changes, the sample applied to

U4A changes. If jumper W7 on J4 is in

the Clamp-On position, the voltage

from the clamp circuit that is applied to

the summing circuit at the base of Q2

will change; this will bring the sync tip

level back to approximately -1.04 VDC.

Q7 will be turned off and on according

to the peak of sync voltage level that is

applied to U4A. The capacitors C14,

C51, C77, and C41 will charge or

discharge to the new voltage level,

which biases U3B more or less, through

jumper W7 on J4 in the Auto Clamp-On

position. U3 will increase or decrease

its output, as needed, to bring the peak

of sync back to the correct level as set

by R152 and R12. This voltage level is

applied through U3B to Q2. In the

Manual position, jumper W7 on J4 is in

the Clamp-Off position, between pins 1

and 2, and adjustable resistor R41

provides the manual clamp bias

adjustment for the video that connects

to Q2.

Jumper W6 on jack J35 must be in the

Normal position, between pins 2 and 3,

for the clamp circuit to operate with a

normal non-scrambled signal. If a

scrambled signal is used, the tray is

operated with jumper W6 in the

Encoded position, connected between

pins 1 and 2. The clamp circuit is set by

adjusting depth of modulation pot R152

for the correct depth of modulation as

measured at TP2.

Depending on the input video level, the

waveform as measured at TP2 may not

be 1 Vpk-pk. If W7 on J4 is moved to

the Clamp-Off (Manual) position,

between pins 1 and 2, the clamp level

is adjusted by R41 and will not

automatically be clamped to the set

level. The output of buffer amplifier

U3A drives the sync tip clamp circuit

that consists of differential amplifier

U4A, field effect transistor (FET) Q7,

and buffer amplifier U3B. U4A is biased

by R124, R125, R184, R152, and R126

so that the clamped voltage level at

peak of sync is approximately -1.04

VDC as measured at TP2.

4.2.2.3 Main Video Signal Path (Part 2

of 2)

The clamped video from Q2 is

connected to white clipper circuit Q3.

Q3 is adjusted with R20 and set to

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-10

prevent video transients from

overmodulating the video carrier. The

clamped video is connected to sync

clipper circuit Q4 (adjusted by R24);

Q4 limits the sync to -40 IRE units. The

corrected video connects to emitter

follower Q4 whose output is wired to

unity gain amplifier U2A and provides a

low-impedance, clamped video output

at pin 1.

4.2.2.4 Visual Modulator Circuit

The clamped video signal from U2A is

split. One part connects to a metering

circuit, consisting of U20 and

associated components, that produces

a video output sample at J8-6 and

connects through the translator control

board to the front panel meter for

monitoring. The other clamped video

path from U2A is through a sync-

stretch circuit that consists of Q5 and

Q6. The sync-stretch circuit contains

R48; R48 adjusts the sync stretch

magnitude (amount) and R45 adjusts

the cut-in. This sync-stretch

adjustment should not be used to

correct for output sync problems, but it

can be used for video input sync

problems. The output of the sync-

stretch circuit connects to pin 5, the I

input of mixer Z1.

The video signal is heterodyned in

mixer Z1 with the visual IF CW signal

(45.75 MHz). The visual IF CW signal

enters the board at jack J15 and is

connected to U9, where it is amplified

and wired to pin 1, the L input of mixer

Z1. Adjustable capacitor C78 and

resistor R53 are set up to add a small

amount of incidental carrier phase

modulation (ICPM) correction to the

output of the mixer stage to

compensate for any non-linearities

generated by the mixer.

The modulated 45.75-MHz RF output of

mixer Z1 is amplified by U5 and is fed

to double-sideband visual IF output

jack J18. The level of this output jack is

adjusted by R70. J18 is the visual IF

loop-through output jack that is

normally jumpered to J19 on the board.

If the optional visual IF loop-through kit

is purchased, the visual is connected

out of the board to external IF

processor trays.

After any external processing, the

modulated visual IF, double-sideband

signal re-enters the board through J19.

The visual IF from J19 is amplified by

U10 and U11 and routed through the

vestigial sideband filter network,

consisting of T1, FL1, and T2, and

produces a vestigial sideband visual IF

signal output. The filtered vestigial

sideband visual IF is amplified by U7

and connected to a T-type attenuator.

R62 can be adjusted to set the visual IF

gain; this is the amount of the visual IF

signal that is coupled to amplifier IC

U8. R63 and C30 are adjusted for the

best VSBF frequency response. The

amplified IF signal is fed to the input of

the diplexer circuit that consists of R76,

L13, and L12. A detected voltage

sample of the visual IF is available at

test point TP5.

4.2.2.5 41.25-MHz Aural IF Circuit

On this board, the 41.25-MHz aural IF

is created by mixing the modulated

4.5-MHz aural intercarrier signal,

produced by the aural IF synthesizer

board or from the composite 4.5-MHz

filter board, with the 45.75-MHz CW

signal produced by the 45.75-MHz IF

carrier oven oscillator board. The

modulated 4.5-MHz aural intercarrier

signal enters the board at J14 or J28

and is connected to IF relay K1. Jumper

W3 on J7 determines whether the 4.5-

MHz used by the board is internally

generated or from an external source.

With jumper W3 connected between

pins 2 and 3, the 4.5 MHz from the

aural IF synthesizer board or from the

4.5-MHz composite input is connected

to mixer Z2. If an external 4.5-MHz

signal is used, it enters the board at

J12 and is fed through gain pot R88 to

amplifier IC U13A. The amplified 4.5

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-11

MHz is then connected to J7 and, if

jumper W3 is between pins 1 and 2,

the 4.5-MHz signal from the external

source is connected to the mixer. Mixer

Z2 heterodynes the aural-modulated,

4.5-MHz signal with the 45.75-MHz CW

signal to produce the modulated 41.25-

MHz aural IF signal.

The output of the mixer is fed to a

bandpass filter that is tuned to pass

only the modulated 41.25-MHz aural IF

signal that is fed to jack J16, the

41.25-MHz loop-through out jack of the

board.

For normal operation, the 41.25-MHz

signal is jumpered by a coaxial cable

from J16 to J17 on the board. If the

(optional) aural IF loop-through kit is

purchased, the 41.25-MHz signal is

connected to the rear of the tray, to

which any processing trays can be

connected, and then back to jack J17

on the board. The modulated 41.25-

MHz aural IF signal from J17 is

connected through amplifier ICs U15

and U16. The amplified output is

connected to the attenuator-matching

circuit that is adjusted by R85. R85

increases or decreases the level of the

41.25 MHz that sets the A/V ratio for

the diplexer circuit. The diplexer circuit

takes the modulated 45.75-MHz visual

IF and the modulated aural IF and

combines them to produce the 45.75-

MHz + 41.25-MHz IF output. The

combined 45.75-MHz + 41.25-MHz IF

signal is amplified by U12 and

connected to combined IF output jack

J20 on the board. A sample of the

combined IF output is provided at J21

on the board. If a NICAM input is used,

it connects to J36 on the board. The

level of the NICAM signal is set by R109

before it is fed to the diplexer circuit

consisting of L28, L29, and R115. This

circuit combines the NICAM signal with

the 45.75-MHz visual IF + 41.25-MHz

aural IF signal.

4.2.2.6 Operational Voltages

The +12 VDC needed to operate the

translator control board enters the

board at J23, pin 3, and is filtered by

L26, L33, and C73 before it is fed to

the rest of the board.

The -12 VDC needed to operate the

board enters the board at J23, pin 5,

and is filtered by L27 and C74 before

being fed to the rest of the board.

4.2.3 (A6) (Optional) Delay

Equalizer Board (1227-1204;

Appendix D)

The optional delay equalizer board

provides a delay to the video signal,

correction to the frequency response,

and amplification of the video signal.

The video signal enters the board at J1-

2 and is connected to a pi-type, low-

pass filter consisting of C16, L7, and

C17. This filter prevents any unwanted

higher frequencies from entering the

board. The output of the filter is

connected to amplifier stage U1; the

gain is controlled by R29. The video

output of the amplifier stage is wired to

the first of four delay-equalizing circuits

that shape the video signal to the FCC

specification for delay equalization or to

the shape needed for the system. The

board has been factory-adjusted to this

FCC specification and should not be

readjusted without the proper

equipment.

Resistors R7, R12, R17, and R22 adjust

the sharpness of the response curve

while inductors L1, L2, L3, and L4

adjust the position of the curve. With a

delay equalizer test generator signal or

a sine x/x video test pattern input, the

resistors and inductors can be

adjusted, while monitoring a Tektronix

VM700 test measurement set, until the

desired FCC delay equalization curve or

system curve is attained. The delay-

equalized video signal is connected to

J1-4, the video output of the board. A

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-12

sample of the delayed video signal is

connected to J2 on the board and can

be used for testing purposes.

The ±12 VDC needed to operate the

board enters the board at J1. The +12

VDC connects to J1-9, which is filtered

by L5 and C11 before it is directed to

the rest of the board. The -12 VDC

connects to J1-6, which is filtered by L6

and C12 before it is directed to the rest

of the board.

4.2.4 (A7) (Optional) IF Carrier

Oven Oscillator Board (1191-1404;

Appendix D)

The IF carrier oven oscillator board

generates the visual IF CW signal at

45.75 MHz for NTSC system "M" usage.

The +12 VDC is applied through jack

J10 to crystal oven HR1, which is

preset to operate at 60° C. The oven

encloses crystal Y1 and stabilizes the

crystal temperature. The crystal is the

principal device that determines the

operating frequency and is the most

sensitive in terms of temperature

stability.

Crystal Y1 operates in an oscillator

circuit consisting of transistor Q1 and

its associated components. Feedback is

provided through a capacitor-voltage

divider, consisting of C5 and C6, that

operates the crystal in a common-base

amplifier configuration using Q1. The

operating frequency of the oscillator

can be adjusted by variable capacitor

C17. The oscillator circuit around Q1

has a separate regulated voltage, 6.8

VDC, which is produced by a

combination of dropping resistor R4

and zener diode VR1. The output of the

oscillator at the collector of Q1 is

capacitively coupled through C8 to the

base of Q2. The small value of C8, 10

pF, keeps the oscillator from being

loaded down by Q2.

Q2 is operated as a common-emitter

amplifier stage whose bias is provided

through R8 from the +12 VDC line. The

output of Q2, at its collector, is split

between two emitter-follower transistor

stages, Q3 and Q4. The output of Q3 is

taken from its emitter through R11 to

establish an approximate 50-ohm

source impedance through C11 to J3,

the main output jack. This 45.75-MHz

signal is at about the +5 dBm power

level. In most systems, this output is

either directed to a visual modulator

board or to some splitting and

amplifying arrangement that distributes

the visual IF carrier for other purposes.

The second output from the collector of

Q2 is fed to the base of Q4, the emitter

follower transistor.

Q4 drives two different output circuits.

One output is directed through voltage

dividers R14 and R15 to jack J2 and is

fed to a frequency counter. While

monitoring J2, the oscillator can be set

exactly on the operating frequency

(45.75 MHz) by adjusting C17. The

output at J2 is at a power level of

approximately -2 dBm, which is

sufficient to drive most frequency

counters. The other output of Q4

connects to prescaler chip U1, which

divides the signal by 15. The output of

U1 is applied to U2, a programmable

divider IC. U2 is programmed through

pins 11 to 20 to divide by 61. This

results in a 50-kHz signal at pin 9 that

is available as an output at J1. The

output of 50 kHz is generally used in

systems where the visual IF carrier

oven oscillator is used as the reference

for a PLL circuit; an example of this is

when the PLL circuit uses the aural IF

synthesizer board and the aural VCO.

The 50-kHz CMOS output at jack J1 is

not capable of achieving enough drive

level for a long coaxial cable length. As

a result, when a long coaxial cable is

needed, the output at jack J5 is

utilized. The push-pull transistor stage

Q5 and Q6, along with emitter resistor

R18, provide a large-load output

capability at J5.

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-13

The stages U1, U2, Q5, and Q6 are

obtained by using the +12 VDC line

voltage, and voltage-dropping resistor

R16 and zener diode VR2.

The +12 VDC power is applied to the

board through jack J4, pin 3, and is

isolated from the RF signals which may

occur in the +12 VDC line through the

use of RF choke L2 and filter capacitor

C10.

4.2.5 (A8) ALC Board, NTSC (1265-

1305; Appendix D)

The automatic level control (ALC) board

provides the ALC and amplitude

linearity correction of the IF signal. The

ALC adjusts the level of the IF signal

through the board to control the output

power of the translator.

The visual + aural IF input (0 dBm)

from the receiver tray connects to

receiver IF input jack J1. The visual +

aural IF input (0 dBm) signal from the

(Optional) Modulator Kit enters the

board at modulator IF input jack J32.

The modulator IF input connects to

relay K3 and the receiver IF input

connects to relay K4. The two relays

are controlled by the Modulator Select

command that is connected to J30 on

the board. Modulator select

enable/disable jumper W11 on J29

controls whether the Modulator Select

command at J30 controls the operation

of the relays. With jumper W11 on J29,

pins 1 and 2, the Modulator Select

command at J30 controls the operation

of the relays; with jumper W11 on J29,

pins 2 and 3, the modulator is selected

all of the time.

4.2.5.1 Receiver Selected

With the receiver selected, which is

J11-10 and J11-28 on the rear of the

UHF exciter tray (connected to J30 on

the board) not connected together,

relays K3 and K4 are energized. When

K4 is energized, it connects the

receiver IF input at J1, if present, to

the rest of the board. When K3 is

energized, it connects to the modulator

IF input at J32 to 50 watts; Modulator

Enable LED DS5 will not be illuminated.

4.2.5.2 (Optional) Modulator Kit

Selected

With the modulator selected, J11-10

and J11-28 on the rear of the UHF

exciter tray are connected together;

this makes J30 low and causes relays

K3 and K4 to de-energize. When K4 is

de-energized, it connects the receiver

IF input at J1, if present, to 50 watts.

When K3 is de-energized, it connects

the modulator IF input at J32 to the

rest of the board; Modulator Enable

LED DS5 will be illuminated.

4.2.5.3 Main IF Signal Path (Part 1 of

The selected visual + aural IF input (0

dBm) signal is split, with one half of the

signal entering a bandpass filter that

consists of L3, L4, C4, L5, and L6. This

bandpass filter can be tuned with C4

and is substantially broader than the IF

signal bandwidth. It is used to slightly

steer the frequency response of the IF

to make up for any small discrepancies

in the frequency response in the stages

that precede this point. The filter also

serves the additional function of

rejecting unwanted frequencies that

may occur if the tray cover is off and

the tray is in a high RF environment.

(NOTE: If this is the case, the

translator will have to be serviced with

the tray cover off in spite of the

presence of other RF signals). The

filtered IF signal is fed through a pi-

type matching pad consisting of R2, R3,

and R4 to the pin-diode attenuator

circuit consisting of CR1, CR2, and CR3.

4.2.5.4 Input Level Detector Circuit

The other part of the split IF input is

connected through L2 and C44 to U7;

U7 is an IC amplifier that is the input to

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-14

the input level detector circuit. The

amplified IF is fed to T4; T4 is a step-

up transformer that feeds diode

detector CR14. The positive-going

detected signal is then low-pass filtered

by C49, L18, and C50. This allows only

the video with positive sync to be

applied through emitter follower Q1.

The signal is then connected to

detector CR15 to produce a peak-sync

voltage that is applied to op-amp U9A.

There is a test point at TP3 that

provides a voltage-reference check of

the input level. The detector serves the

dual function of providing a reference

that determines the input IF signal level

to the board and also serves as an

input threshold detector.

The input threshold detector prevents

the automatic level control from

reducing the attenuation of the pin-

diode attenuator to minimum (the

maximum signal) if the IF input to the

board is removed. The ALC, video loss

cutback, and the threshold detector

circuits will only operate when jumper

W3 on jack J6 is in the Auto position,

between pins 1 and 2. Without the

threshold detector, and with the pin-

diode attenuator at minimum, the

signal will overdrive the stages

following this board when it is restored.

As part of the threshold detector

operation, the minimum IF input level

at TP3 is fed through detector CR15 to

op-amp IC U9A pin 2. The reference

voltage for the op-amp is determined

by the voltage divider that consists of

R50 and R51 (off the +12 VDC line).

When the detected input signal level at

U9A, pin 2, falls below this reference

threshold (approximately 10 dB below

the normal input level), the output of

U9A at pin 1 goes to the +12 VDC rail.

This high is connected to the base of

Q2. At this point, Q2 is forward biased

and creates a current path. This path

runs from the -12 VDC line and through

red LED DS1, the input level fault

indicator, which becomes lit, resistor

R54, and transistor Q2 to +12 VDC.

The high from U9A also connects

through diode CR16 to U9B, pin 5,

whose output at pin 7 goes high. The

high connects through range adjust pot

R74 to J20, which connects to the front

panel-mounted power adjust pot. This

high connects to U10A, pin 2, and

causes it to go low at output U10A, pin

1. The low is applied through jumper

W3 on J6 to the pin-diode attenuator

circuit that cuts back the IF level and,

therefore, the output power level, to 0.

When the input signal level increases

above the threshold level, the output

power will raise, as the input level

increases, until normal output power is

reached.

The video input level at TP3 is also fed

to a sync-separator circuit, consisting

of IC U8, CR17, Q3, and associated

components, and then to a comparator

circuit made up of U9C and U9D. The

reference voltage for the comparators

is determined by a voltage divider

consisting of R129, R64, R65, R66, and

R130 (off the -12 VDC line). When the

input signal level to the detector at TP3

falls below this reference threshold,

which acts as a loss-of-sync detector

circuit, the output of U9C and U9D goes

towards the -12 VDC rail and is split,

with one part biasing on transistor Q5.

A current path is then established from

the +12 VDC line through Q5, the

resistors R69 and R137, and the red

LED DS3 (video loss indicator), which is

illuminated. When Q5 is on, it applies a

high to the gates of Q6 and Q7. This

causes them to conduct and apply

video loss fault pull-down outputs to

J18 pins 5 and 2.

The other low output of U9C and U9D is

connected through CR20 to jack J5.

Jumper W2 on J5, in the Cutback

Enable position (between pins 2 and 3),

connects the low to the base of the

forward-biased Q4. If jumper W2 is in

the Disable position, between pins 1

and 2, the auto cutback will not

operate. With Q4 biased on, a level

determined by the setting of cutback

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-15

level pot R71, which is set at the

factory to cut back the output to

approximately 25%, is applied to U9B,

pin 5. The output of U9B at pin 7 goes

low and is applied through the power

adjust pot to U10A, pin 2, whose

output goes low. This low is applied to

the pin-diode attenuator to cut back

the level of the output to approximately

25%.

4.2.5.5 Pin-Diode Attenuator Circuit

The input IF signal is fed to a pin-diode

attenuator circuit that consists of CR1

to CR3. Each of the pin diodes contains

a wide intrinsic region; this makes the

diodes function as voltage-variable

resistors at this intermediate

frequency. The value of the resistance

is controlled by the DC bias supplied to

the diode. The pin diodes are

configured in a pi-type attenuator

configuration where CR1 is the first

shunt element, CR3 is the series

element, and CR2 is the second shunt

element. The control voltage, which can

be measured at TP1, originates either

from the ALC circuit when jumper W3

on J6 is in the ALC Auto position,

between pins 1 and 2, or from pot R87

when the jumper is in the Manual Gain

position.

On the pin-diode attenuator circuit, a

current path exists from J6 through R6

and then through the diodes of the pin

attenuator. Changing the amount of

current through the diodes by forward

biasing them changes the IF output

level of the board. There are two

extremes of attenuation ranges for the

pin-diode attenuators. In the minimum

attenuation case, the voltage,

measured at TP1, approaches the +12

VDC line. There is a current path

created through R6, through series

diode CR3, and finally through R9 to

ground. This path forward biases CR3

and causes it to act as a relatively low-

value resistor. In addition, the larger

current flow increases the voltage drop

across R9 that tends to turn off diodes

CR1 and CR2 and causes them to act

as high-value resistors. In this case,

the shunt elements act as a high

resistance and the series element acts

as a low resistance to represent the

minimum loss condition of the

attenuator (maximum signal output).

The other extreme case occurs as the

voltage at TP1 is reduced and goes

towards ground or even slightly

negative. This tends to turn off (reverse

bias) diode CR3, the series element,

causing it to act as a high-value

resistor. An existing fixed current path

from the +12 VDC line, and through

R5, CR1, CR2, and R9, biases series

element CR3 off and shunt elements,

diodes CR1 and CR2, on, causing them

to act as relatively low-value resistors.

This represents the maximum

attenuation case of the pin attenuator

(minimum signal output). By controlling

the value of the voltage applied to the

pin diodes, the IF signal level is

maintained at the set level.

4.2.5.6 Main IF Signal Path (Part 2 of

When the IF signal passes out of the

pin-diode attenuator through C11, it is

applied to modular amplifier U1. This

device contains the biasing and

impedance-matching circuits that

makes it operate as a wide-band IF

amplifier. The output of U1 is available,

as a sample of the pre-correction IF for

troubleshooting purposes and system

setup, at jack J2. The IF signal is then

connected to the linearity corrector

portion of the board.

4.2.5.7 Linearity Corrector Circuits

The linearity corrector circuits use three

stages of correction to adjust for any

amplitude non-linearities of the IF

signal. Each stage has a variable

threshold control adjustment, R34,

R37, or R40, and a variable magnitude

control adjustment, R13, R18, or R23.

The threshold control determines the

point at which the gain is changed and

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-16

the magnitude control determines the

amount of gain change that occurs

once the breakpoint is reached. Two

reference voltages are needed for the

operation of the corrector circuits.

Zener diode VR1, with R33 and R135,

provides a +6.8 VDC reference and the

diodes CR11 and CR12 provide a .9

VDC reference that temperature

compensates for the two diodes in each

corrector stage.

For the linearity correctors to operate,

an IF signal is applied to transformer

T1, which doubles the voltage swing by

means of a 1:4 impedance

transformation. Resistors R14, R15,

and R16 form an L-pad that lowers the

level of the signal. The amount that the

level is lowered can be adjusted by

adding more or less resistance, using

R13, in parallel with the L-pad

resistors. R13 is only in parallel when

the signal reaches a level large enough

to turn on diodes CR4 and CR5. When

the diodes turn on, current flows

through R13, putting it in parallel with

the L-pad.

When R13 is put in parallel with the

resistors, the attenuation through the

L-pad is lowered, causing signal stretch

(the amount determined by the

adjustment of R13). The signal is next

applied to amplifier U2 to compensate

for the loss through the L-pad. The

breakpoint, or cut-in point, for the first

corrector is set by controlling where

CR4 and CR5 turn on. This is

accomplished by adjusting cut-in

resistor R34; R34 forms a voltage-

divider network from +6.8 VDC to

ground. The voltage at the wiper arm

of R34 is buffered by the unity-gain

amplifier U5D. This reference voltage is

then applied to R35, R36, and C39

through L12 to the CR4 diode. C39

keeps the reference from sagging

during the vertical interval. The .9 VDC

reference created by CR11 and CR12 is

applied to unity-gain amplifier U5B. The

reference voltage is then connected to

diode CR5 through choke L11. The two

chokes L11 and L12 form a high

impedance for RF that serves to isolate

the op-amp ICs from the IF.

After the signal is amplified by U2, it is

applied to the second corrector stage

through T2. This corrector and the third

corrector operate in the same fashion

as the first. All three corrector stages

are independent and do not interact

with each other.

The correctors can be disabled by

moving jumper W1 on J4 to the Disable

position, between pins 2 and 3; this

moves all of the breakpoints past the

tip of sync so that they will have no

affect. The IF signal exits the board at

IF output jack J3 after passing through

the three corrector stages and is

normally connected to an external IF

phase corrector board.

4.2.5.8 Main IF Signal Path (Part 3 of

After the IF signal passes through the

external IF phase corrector board, it

returns to the ALC board at IF input

jack J7. The IF then passes through a

bandpass filter consisting of L20, C97,

C62, L21, C63, L22, L23, C64, and

C99. This filter is intended to make up

for small errors in frequency response

that are incurred by the signal while

being processed through the linearity

and incidental phase correction circuits.

Following the bandpass filter, the signal

is split using L24, L25, and R89. The

signal passing through L24 is the main

IF path through the board. A sample of

the corrected IF signal is split off and

connected to J10, the IF sample jack.

The IF connects to jacks J27 and J28.

These jacks control whether a 6-dB pad

is included in the circuit by the

positioning of jumpers W9 and W10.

The 6-dB pad-in occurs when jumpers

W9 and W10 are connected between

pins 2 and 3 on J27 and J28. The 6-dB

pad-out occurs when jumpers W9 and

W10 are connected between pins 1 and

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-17

2 on J27 and J28. Normally, the pad is

out. The IF signal is then applied to a

two-stage, frequency-response

corrector circuit that is adjusted as

needed.

Variable resistors R103 and R106 are

used to adjust the depth and gain of

the notches and variable caps C71 and

C72 are used to adjust the frequency

position of the notches. The IF signal is

amplified by U13 and U14 before it is

connected to J12, the IF output jack of

the board. R99 is an output level

adjustment that is set to provide

approximately 0 dBm of IF output at

J12. A sample of the IF is fed to J11 to

provide an IF sample point that can be

monitored without breaking the signal

path and gives an indication of the IF

signal after the linearity and the

frequency-response correction takes

place.

4.2.5.9 ALC Circuit

The other path of the corrected IF

signal is used in the ALC circuit. The IF

is wired out of the splitter through L25

and connects to op-amp U12. The

output of U12 is wired to jacks J8 and

J9 on which jumpers W4 and W8

control the normal or encoded

operation of the ALC circuitry. For

normal operation, jumper W4 on J8 is

between pins 1 and 2 and jumper W8

on J9 is between pins 1 and 2. The IF

signal is applied to transformer T5; T5

doubles the voltage swing by means of

a 1:4 impedance transformation before

it is connected to the ALC detector

circuit on the board and amplified by

U10B.

For normal operation, jumper W7 on

J26 is between pins 1 and 2 and

jumper W5 on J21 is between pins 1

and 2. The detected ALC voltage is

wired to U10A, pin 2, where it is

summed with the front panel power

control setting. The output power

adjustment for the translator is

achieved, if the (optional) remote

power raise/lower kit (1227-1039) is

purchased, by R75, a motor-driven pot

controlled by switch S1 on the board,

or screwdriver adjust pot R1 on the

front panel of the UHF exciter tray. An

external power raise/lower switch can

be used by connecting it to jack J10, at

J10-11 power raise, J10-13 power

raise/lower return, and J10-12 power

lower, on the rear of the UHF exciter

tray. S1, or the Remote switch, controls

relays K1 and K2, which control motor

M1 that moves variable resistor R75. If

the (optional) remote power

raise/lower kit is not purchased, the

ALC voltage is controlled only by

screwdriver adjust pot R1 on the front

panel of the UHF exciter tray. The ALC

voltage is set for .8 VDC at TP4 with a

0-dBm output at J12 of the board. A

sample of the ALC at J19, pin 2, is

wired to the transmitter control board

where it is used on the front panel

meter and in the AGC circuits.

This ALC voltage, and the DC level

corresponding to the IF level after

signal correction, are fed to U10A, pin

2, whose output at pin 1 connects to

the ALC pin-diode attenuator circuit. If

there is a loss of gain somewhere in an

IF circuit, the output power of the

translator will drop. The ALC circuit

senses this drop at U10A and

automatically eases the loss of the pin-

diode attenuator circuit by increasing

its gain.

The ALC action starts with the ALC

detector level monitored at TP4. The

detector output at TP4 is nominally

+.8 VDC and is applied through resistor

R77 to a summing point at op-amp

U10A, pin 2. The current available from

the ALC detector is offset, or

complemented, by current taken away

from the summing junction. In normal

operation, U10A, pin 2, is at 0 VDC

when the loop is satisfied. If the

recovered or peak-detected IF signal

level at IF input jack J7 of this board

should drop, which normally means

that the output power is decreasing,

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-18

the null condition would no longer occur

at U10A, pin 2. When the level drops,

the output of U10A, pin 1, will go more

positive. If jumper W3 on J6 is in the

Automatic position, it will cause the

ALC pin-diode attenuators CR1, CR2,

and CR3 to have less attenuation and

increase the IF level; this will

compensate for the decrease in the

level. If the ALC cannot increase the

input level enough to satisfy the ALC

loop, due to there not being enough

range, an ALC fault will occur. The fault

is generated because U10D, pin 12,

increases above the trip point set by

R84 and R83 until it conducts. This

causes U10D pin 14 to go high and the

red ALC Fault LED DS2 to light.

4.2.5.10 Scrambled Operation with

Encoding

For encoded, scrambled operation,

jumper W4 on J8 must be connected

between pins 2 and 3, jumper W8 on J9

must be between pins 3 and 2, jumper

W7 on J26 must be between pins 2 and

3, and jumper W5 on J21 must be

between pins 2 and 3. The IF is

connected through W4 on J8 to the

sync regeneration circuits.

If this board is operated with

scrambling, using suppressed sync, the

ALC circuit operates differently because

there is no peak of sync present on the

IF input. A timing pulse from the

scrambling encoder connects to the

board at J24. This timing pulse is

converted to sync pulses by U17A and

U17B, which control the operation of

Q8. The sync amplitude is controlled by

R149 and then applied to U15A, where

it is added to the detected IF signal to

produce a peak of sync level. The

output of U15A is peak detected by

CR26 and fed to U15B. If necessary,

intercarrier notch L39 can be placed in

the circuit by placing W6 on J22. The

intercarrier notch is adjusted to filter

any aural and 4.5-MHz intercarrier

frequencies. The peak of sync signal is

fed through R162, the ALC calibration

control, to amplifier U15C. The

amplified peak of sync output is

connected through J21, pins 2 and 3, to

U10A, where it is used as the reference

for the ALC circuit and the AGC

reference to the transmitter control

board. Voltage TP4 should be the same

in either the normal or the encoded

video mode. Monitor J9, pins 3 and 4,

with a spectrum analyzer, check that

the board is in the AGC mode, and tune

C103 to notch-out the aural IF carrier.

4.2.5.11 Fault Command

The ALC board also has circuitry for an

external mute fault input at J19, pin 6.

This is a Mute command and, in most

systems, it protects the circuits of high-

gain output amplifier devices against

VSWR faults. In this case, the action

should occur faster than just pulling the

ALC reference down. Two different

mechanisms are employed: one is a

very fast-acting circuit to increase the

attenuation of the pin-diode attenuator,

CR3, CR1, and CR2, and the second is

the reference voltage being pulled

away from the ALC amplifier device. An

external Mute is a pull-down applied to

J19, pin 6, to provide a current path

from the +12 VDC line through R78

and R139, the LED DS4 (Mute

indicator), and the LED section of

opto-isolator U11.

These actions turn on the transistor

section of U11 that applies -12 VDC

through CR21 to U10A, pin 3, and pulls

down the reference voltage. This is a

fairly slow action that is kept at this

pace by the low-pass filter function of

R81 and C61. When the transistor

section of U11 is on, -12 VDC is also

connected through CR22 to the pin-

diode attenuator circuit. This

establishes a very fast muting action,

by reverse biasing CR3, in the event of

an external VSWR fault.

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-19

4.2.5.12 ±12 VDC Needed to Operate

the Board

The ±12 VDC connects to the board at

J14. The +12 VDC connects to J14-3

and is filtered by L30, L41, and C80

before it is applied to the rest of the

board. The -12 VDC connects to J14-5

and is filtered by L31 and C81 before it

is applied to the rest of the board.

The +12 VDC also connects to U16, a

5-VDC regulator IC, which produces the

+5 VDC needed to operate timing IC

U17.

4.2.6 (A9) IF Phase Corrector

Board (1227-1250; Appendix D)

The IF phase corrector board has

adjustments that pre-correct for any IF

phase modulation distortion that may

occur in output amplifier devices such

as Klystron power tubes and solid-state

amplifiers. Two separate, adjustable IF

paths are on the board: a quadrature

IF path and an in-phase IF path. The

quadrature IF is 90° out of phase and

much larger in amplitude than the in-

phase IF. When they are combined in

Z1, it provides the required, adjustable

phase correction to the IF signal.

The IF input signal enters at J1 and is

AC coupled to U1. U1 amplifies the IF

before it is connected to Z1, a splitter

that creates two equal IF outputs: IF

output 1 is connected to J2 and IF

output 2 is connected to J3. IF output 1

at J2 is jumpered through coaxial cable

W4 to jack J6, the quadrature input, on

the board. IF output 2 at J3 is

jumpered through coaxial cable W5 to

jack J7, the in-phase input, on the

board.

4.2.6.1 Phase Corrector Circuit

The phase corrector circuit corrects for

any amplitude nonlinearities of the IF

signal. It is designed to work at IF and

has three stages of correction. Each

stage has a variable threshold and

magnitude control. The threshold

control determines the point at which

the gain is changed and the magnitude

control determines the gain change

once the breakpoint is reached. The

second stage has a jumper that

determines the direction of correction,

so that the gain can be increased either

above or below the threshold and either

black or white stretch can be achieved.

In the phase-corrector circuit, the IF

signal from J6 is applied to transformer

T1; T1 doubles the voltage swing using

a 1:4 impedance transformation.

Resistors R8, R61, R9, and R48 form an

L-pad that attenuates the signal. This

attenuation is adjusted by adding R7, a

variable resistor, in parallel with the L-

pad. R7 is only in parallel when the

signal reaches a level large enough to

bias on CR1 and CR2 and allow current

to flow through R7. When R7 is put in

parallel with the L-pad, the attenuation

through the L-pad is lowered, causing

black stretch.

Two reference voltages are utilized in

the corrector stages and both are

derived from the +12 VDC line. Zener

diode VR1, with R46 as a dropping

resistor, provides +6.8 VDC from the

+12 VDC line. Diodes CR11 and CR12

provide a .9 VDC reference to

temperature compensate the corrector

circuits from the effects of the two

diodes in each corrector stage.

The threshold for the first corrector

stage is set by controlling where CR1

and CR2 turn on. This is accomplished

by adjusting R3 to form a voltage

divider from +6.8 VDC to ground. The

voltage at the wiper of R3 is buffered

by U9C, a unity-gain amplifier, and

applied to CR1. The .9 VDC reference is

connected to U9D, a unity-gain

amplifier, whose output is wired to

CR2. These two references are

connected to diodes CR1 and CR2

through chokes L2 and L3. The two

chokes form a high impedance for RF to

isolate the op-amps from the RF. The

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-20

adjusted signal is next applied to

amplifier U2 to compensate for the loss

through the L-pad. U2 is powered

through L4 and R10 from the +12 VDC

line. After the signal is amplified by U2,

it is applied to the second corrector

stage through T2 and then to a third

corrector stage through T3. The other

two corrector stages operate in the

same manner as the first; they are

independent and do not interact with

each other.

When jumper W1 on J8 is connected

from center to ground, R15 is put in

series with ground. In this

configuration, black stretch (white

compression) is applied to the IF signal

by controlling the attenuation through

the path. When W1 is connected from

the center pin to the end that connects

to T2, R15 is put in parallel with the L-

pad. In this configuration, black

compression (white stretch) is applied

to the IF signal by controlling the

attenuation through the path.

The phase correctors can be bypassed

by moving jumper W2 on J9 to the

Disable position. This action will move

all of the threshold points past sync tip

so that they will have no effect. R68

can be adjusted and set for the

correction range that is needed. TP2 is

a test point that gives the operator a

place to measure the level of the

quadrature IF signal that is connected

to pin 6 on combiner Z2.

4.2.6.2 Amplitude Corrector Circuit

The amplitude corrector circuit uses

one stage of correction to adjust for

any amplitude nonlinearities of the IF

signal. The stage has a variable

threshold control, R31, and a variable

magnitude control, R35. The threshold

control determines the point at which

the gain is changed and the magnitude

control determines the amount of gain

change once the breakpoint is reached.

Two reference voltages are needed for

the operation of the corrector circuit.

Zener diode VR1 with R46 provides

+6.8 VDC and the diodes CR11 and

CR12 provide a .9 VDC reference

voltage to temperature compensate for

the two diodes in the corrector stage.

In the amplitude corrector circuit, the

IF signal from J7 is applied to

transformer T4 to double the voltage

swing by means of a 1:4 impedance

transformation. Resistors R36, R55,

R56, and R37 form an L-pad that

lowers the level of the signal. The

amount that the level is lowered is

adjusted by adding more, or less,

resistance, using R35 in parallel with

the L-pad resistors. R35 is only in

parallel when the signal reaches a level

large enough to turn on diodes CR8 and

CR9. When the diodes turn on, current

flows through R35 and puts it in

parallel with the L-pad. When R35 is in

parallel with the resistors, the

attenuation through the L-pad is

lowered, causing signal stretch (the

amount of stretch determined by the

adjustment of R35).

The signal is next applied to amplifier

U5 to compensate for the loss in level

through the L-pad. The breakpoint, or

cut-in point, for the corrector stage is

set by controlling where CR8 and CR9

turn on. This is achieved by adjusting

cut-in resistor R31 to form a voltage

divider from +6.8 VDC to ground. The

voltage at the wiper arm of R31 is

buffered by the unity-gain amplifier

U8B. This voltage is then applied to

R34 through L11 to the CR9 diode. The

.9-VDC reference created by CR11 and

CR12 is applied to unity-gain amplifier

U8A. C36 keeps the reference from

sagging during the vertical interval. The

reference voltage is then connected to

diode CR8 through choke L12. Chokes

L11 and L12 form a high impedance for

RF to isolate the op-amp ICs from the

IF.

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-21

After the signal is amplified by U5, it is

applied to a second stage through T5.

The transformer doubles the voltage

swing by means of a 1:4 impedance

transformation. Resistors R39, R57,

R58, and R40 form an L-pad that

lowers the level of the signal. The

signal is applied to amplifier U6 to

compensate for the loss in level

through the L-pad. After the signal is

amplified by U6, it is applied to a third

stage through T6. The transformer

doubles the voltage swing by means of

a 1:4 impedance transformation.

Resistors R42, R59, R60, and R43 form

an L-pad to lower the level of the

signal. The signal is applied to amplifier

U7 to compensate for the loss in level

through the L-pad. TP1 is a test point

that gives the operator a place to

measure the level of the in-phase IF

signal that is connected to mixer stage

Z2. The amplitude corrector can be

disabled by moving jumper W3 on J10

to the Disable position; this will move

the breakpoint past sync tip and will

have no effect on the signal.

4.2.6.3 Output Circuit

The phase-corrected signal from pin 1

on combiner Z2 exits the board at IF

output jack J4 after passing through a

matching network consisting of six

resistors.

4.2.7 (A17) Transmitter Control

Board (1245-1101; Appendix D)

The transmitter control board provides

information on system control functions

and the operational LED indications;

these can be viewed on the front panel

of the translator. The main control

functions are for the Operate/Standby

and Auto/Manual selections. When the

translator is switched to Operate, the

board supplies the enables to any

external amplifier trays. The board also

performs the automatic switching of the

translator to Standby upon the loss of

the video input when the translator is

in Auto.

The transmitter control board contains

a VSWR cutback circuit. If the VSWR of

the translator increases above 20%,

the VSWR cutback circuit will become

active and cut back the output level of

the translator, as needed, to maintain a

maximum of 20% VSWR. An interlock

(low) must be present at J8-24 for the

translator to be switched to Operate.

When the interlock is present, the

green Interlock LED DS5 will be lit.

4.2.7.1 Operate/Standby Switch S1

K1 is a magnetic latching relay that

controls the switching of the translator

from Operate to Standby. When

Operate/Standby switch S1, on the

front panel of the tray, is moved to

Operate, one coil of relay K1 energizes

and causes the contacts to close and

apply a low to U4B-9. If the translator

interlock is present, and there is no

overtemperature fault, lows will also be

applied to U4B-10, U4B-11, and U4B-

12.

With all of the low inputs to U4B, the

output at U4B-13 will be low. The low

biases off Q1 and this turns off the

amber Standby LED DS1 on the front

panel. In addition, this action applies a

high to Q2 and turns on and lights the

green Operate LED DS2 (also on the

front panel). When Q2 is biased on, it

connects a low to Q12 and biases it off;

this allows the ALC to be applied to J1

and connect to any external amplifier

trays. The low from U4B-13 is also

applied to Q4 and Q24, which are

biased off, and removes the disables

from J1-4 and J18-1. The low from

U4B-13 also connects to Q10, which is

biased on, and connects a high to Q6,

Q7, Q8, and Q9; these are biased on

and apply -12 VDC enables to J8-2, J8-

3, J8-4, and J8-5, which connect to any

external amplifier trays. The high

applied to Q2 is also connected to Q5

and Q26, which are biased on, and

apply a low enable to J1-3, which

connects to a remote operate indicator.

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-22

The translator is now in the Operate

mode.

When Operate/Standby switch S1 is

moved to Standby, the other coil of

relay K1 energizes, causing the

contacts to open and a high (+12 VDC)

to be applied to U4B-9. The high at the

input causes the output at U4B-13 to

go high. The high biases on Q1 and

applies a low to the amber Standby

LED DS1, on the front panel, which

turns on and applies a low to Q2. This

causes Q2 to turn off and extinguishes

the green Operate LED DS2. When Q12

is biased on, the output from U2C goes

low and pulls the ALC voltages at J1

low; this lowers the gain of the external

amplifier trays. The high from U4B-13

is applied to Q4 and Q24, which are

biased on, and applies disables at J1-4

and J18-1. The high from U4B-13

connects to Q10, which is biased off.

The Q10 bias off removes the high from

Q6, Q7, Q8, and Q9, which are biased

off, and removes the -12 VDC enables

at J8-2, J8-3, J8-4, and J8-5, which

connect to the external amplifier trays.

The low applied to Q2 is also connected

to Q5 and Q26, which are biased off,

and the remote enable at J1-3 is

removed. The translator is now in the

Standby mode.

4.2.7.2 Automatic/Manual Switch S2

K2 is a magnetic latching relay that

switches the operation of the translator

to Automatic or Manual using

Auto/Manual switch S2 on the front

panel of the tray.

When S2 is set to the Auto position, the

operation of the translator is controlled

by the fault circuits and will stay in

Operate even if Operate/ Standby

switch S1 is moved to Standby. With

S2 in Auto, a low is applied to one coil

in the relay and this energizes and

closes the contacts. The closed contacts

apply a low to the green Automatic LED

DS3; as a result, DS3 is illuminated.

The low from the relay connects to

U5A, pin 2; U5D, pin 13; Q21; and

Q23. When Q21 and Q23 are biased

off, this causes their outputs to go

high. The high from Q21 connects to

the amber Manual LED DS4, on the

front panel, biasing it off, and to Q22,

biasing it on. The drain of Q22 goes low

and is applied to J8-7; this enables any

remote auto indicator connected to J8-

7. The low to Q23 biases it off and

removes the enable to any remote

manual indicator connected to J8-6.

When S2 is set to the Manual position,

the operation of the translator is no

longer controlled by the fault circuits, it

is controlled by Operate/Standby switch

S1. With S2 in Manual, a low is applied

to the other coil in the relay and this

energizes and opens the contacts. The

open contacts of the relay remove the

low from the green Automatic LED DS3

on the front panel and causes it to not

light. The high connects to U5A, pin 2;

U5D, pin 13; Q21; and Q23. Q21 and

Q23 are biased on; this causes their

outputs to go low. The low from Q21

connects to the amber Manual LED DS4

on the front panel, biasing it on, and to

Q22, biasing it off. The drain of Q22

goes high and is applied to J8-7; this

will disable any remote auto indicators

connected to J8-7. Q23 is biased on

and applies a low enable to any remote

manual indicator connected to J8-6.

4.2.7.3 Automatic Turning On and Off

of the Translator Using the Presence of

Video

The transmitter control board also

allows the translator to be turned on

and off by the presence of video at the

translator, when the translator is in

Auto. When a video fault occurs due to

the loss of video, J7-5 goes low. The

low is applied through W1, on J10, to

Q16, which is biased off, and to the red

Video Loss Fault LED DS9, on the front

panel, which will light. The drain of Q16

goes high and connects to U5B, pin 5,

causing the output at pin 4 to go low.

The low connects to Q18, which is

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-23

biased off, and causes the drain of Q18

to go high. The high connects to U3D,

pin 12, whose output at pin 14 goes

high. The high connects to U5C, pins 8

and 9, causing its output at pin 10 to

go low, and to U5A, pin 1, causing its

output at pin 3 to go low.

With S2 set to Automatic, a low is

applied to U5A, pin 2, and to U5D, pin

13. When U5A, pin 1, is high and U5A,

pin 2, is low, it causes the output at pin

3 to go low. When U5D, pin 12, is low

and U5D, pin 13, is low, it causes its

output to go high. When U5A, pin 3, is

low, it biases off Q20 and removes any

pull down to the Operate switch. A high

at U5D, pin 11, biases on Q19 and

applies a low enable to the Standby

switch that places the translator in the

Standby mode.

When the video signal is returned, J7-5

goes high. The high is applied to Q16,

which is biased on, and to the red

Video Fault LED DS9, which is

extinguished. The output of Q16 goes

low and connects to U5B, pin 5. If there

is no receiver ALC fault, U5B, pin 6, is

also low; this causes the output at pin

4 to go high. The high connects to Q18,

which is biased on, and causes the

drain of Q18 to go low. The low

connects to U3D, pin 12, whose output

at pin 14 goes low. The low connects to

U5C, pins 8 and 9, which causes its

output at pin 10 to go high, and to

U5A, pin 1. With Auto/Manual switch

S2 in Auto, a low is applied to U5A, pin

2, and to U5D, pin 13. When U5A, pins

1 and 2, is low, its output at pin 3 goes

high. When pin 12 of U5D is high, the

output of U5D at pin 11 goes low.

When U5A, pin 3, is high, it biases on

Q20 and applies a pull-down enable to

the Operate switch. A low at U5D, pin

11, biases off Q19 and removes any

pull down to the Standby switch. As a

result of these actions, the translator is

switched to Operate.

4.2.7.4 Faults

There are four possible faults, video

loss fault, VSWR cutback fault,

overtemperature fault, and ALC fault,

which may occur in the translator and

are applied to the transmitter control

board. During normal operation, no

faults are sent to the board. The

overtemperature fault is connected to

the (A8-A1) thermal switch on the (A8)

2500W reject load for the translator.

Video Loss Fault

If a video loss occurs while the

translator is in Auto, the system will

change to the Standby mode until the

video is returned; at that point, it will

immediately revert to Operate. A video

loss fault applies a low from the ALC

board to the video fault input at J7-5

on the board.

With jumper W1 in place on J10, the

video fault is connected to LED DS9

and to Q16. The red Video Loss Fault

LED DS9 on the front panel will light.

Q16 is biased off and causes its drain

to go high. The high is wired to U5B,

pin 5, whose output at U5B, pin 4, goes

low. The low is wired to Q18, which is

biased off, and causes the drain to go

high. The high is connected to U3D, pin

12, which causes its output at U3D, pin

14, to go high. The high connects to

U5A, pin 1, and, if the translator is in

Auto, pin 2 of U5A is low. When pin 1 is

high and pin 2 is low, the output of U5A

goes low and reverse biases Q20,

shutting it off. The high at U5C, pins 8

and 9, causes its output at pin 10 to go

low. This low is connected to U5D, pin

12, and, if the translator is in Auto, pin

13 of U5D is also low. The lows on pins

12 and 13 cause the output to go high

and forward bias Q19. The drain of Q19

goes low and connects the coil in relay

K1, causing it to switch to Standby.

When the video returns, the video loss

fault is removed from the video fault

input at J7-5. With jumper W1 in place

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-24

on J10, the base of Q16 goes high. The

red Video Loss Fault LED DS9 on the

front panel will be extinguished. Q16 is

biased on, which causes its drain to go

low. The low is wired to U5B, pin 5;

U5B, pin 6, will be low if no ALC fault

occurs. The two lows at the inputs

make the output at U5B, pin 4, go high.

The high is wired to Q18, which is

biased on, causing the drain to go low.

The low is connected to U3D, pin 12,

which causes its output at U3D, pin 14,

to go low. The low connects to U5A, pin

1, and, if the translator is in Auto, pin 2

of U5A is also low. With both inputs

low, the output of U5A at pin 3 goes

high. The high forward biases Q20 and

causes its drain to go low. The low

connects to the operate coil on relay K1

that switches the translator to Operate.

The low at U5C, pins 8 and 9, causes

its output at pin 10 to go high. This

high is connected to U5D, pin 12, and,

if the translator is in Auto, pin 13 of

U5D is low. The high on pin 12 causes

the output of U5D to go low and

reverse bias Q19. The drain of Q19

goes high and this removes the low

from the standby coil in relay K1.

Overtemperature Fault

The (A8-A1) thermal switch on the (A8)

output reject load connects to J8-1 on

the board. If the temperature of the

thermal switch raises above 170° F, it

closes and applies a low to J8-1. The

low connects to Q3, which is biased off,

and to the red Overtemperature LED

DS6, which is biased on. The drain of

Q3 goes high and connects to pins 11

and 12 of U4B. The high at the input to

U4B causes it to go high and switches

the system to Standby; this removes

the Operate Enable commands to the

external amplifier trays and also to the

(Optional) External Exhaust Kits.

VSWR Cutback Fault

The reflected power sample of the RF

output of the translator is connected to

J2, pin 9, on the translator control

board. The sample connects to op-amp

U1B, pin 5, which buffers the signal

before it is split. One of the split-

reflected samples connects to J1-5 on

the board; J1-5 is wired to J10-5 on the

rear of the tray for remote monitoring.

Another split-reflected sample connects

to position 3 on the front panel meter

for the tray. The final split remote-

reflected sample connects to U2B, pin

If the reflected sample level increases

above the level set by R22, the VSWR

cutback pot, the output of U2B at pin 7,

goes high. The high is connected to

Q11 through CR11, which is biased on,

making U2C, pin 10, low and causing

U2C, pin 8, to go low. This low is split

and fed out of the tray at J1-6, J1-7,

J1-8, and J1-9. These are ALC outputs

to the amplifier tray that cut back the

output power of the amplifier tray. The

low from U2C, pin 8, is also fed through

coaxial jumper W2 on J13 and J14 to

R73. R73 is a bias-adjust pot that sets

the level of the pin attenuator bias that

is available as an output at J16. The

high at U2B, pin 7, is also fed to the

base of Q14 and Q13, which are

forward biased. This produces a low at

the drains that connect to the front

panel amber VSWR Cutback LED DS7,

causing it to light and indicate that the

tray is in cutback, and to output jack

J8-37 for the connection to a remote

VSWR cutback indicator.

Receiver ALC Fault

A sample of the ALC voltage from the

Receiver tray is connected to J8-11 on

the transmitter control board. If the

receiver is operating normally, the ALC

level that is applied to U3C, pin 9,

remains below the trip level set by

R35; as a result, the output at pin 13

stays high. The high is applied to the

red ALC Fault LED DS8, which is off.

The high also connects to U3A, pin 2,

and to Q15. Q15 is biased on and the

drain goes low. The low connects to

U5B, pin 6. In addition, U5B normally

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-25

has a low that is connected to U5B, pin

5, and produces a high at output pin 4.

The high is wired to Q18, which is

biased on, and makes its drain low. The

low connects to U3D, pin 12, which,

because the level is below the preset,

causes the output at U3D, pin 14, to go

low. A low at this point indicates a no-

fault condition. The high that is

connected to U3A, pin 2, causes its

output to go low. The low is connected

to Q25, which is biased off. The low is

removed from J8-12, which will not

light any remote receiver fault indicator

that is connected to it.

If the receiver malfunctions, the ALC

level applied to U3C, pin 9, goes high.

This is above the level set by R35 and it

causes the output at pin 13 to go low.

The low is applied to the red ALC Fault

LED DS8, which lights. The low also

connects to U3A, pin 2, and to Q15.

Q15 is biased off and the drain goes

high. The high connects to U5B, pin 6,

and produces a low at output pin 4. The

low is wired to Q18, which is biased off,

and this makes its drain go high. The

high connects to U3D, pin 12 and,

because the level is above the preset,

the output at U3D, pin 14, goes high. A

high at this point indicates a fault

condition that switches the translator to

Standby. The low connected to U3A,

pin 2, causes its output to go high. The

high is connected to Q25, which is

biased on, and causes the drain to go

low. The low is connected to J8-12,

which can light any remote receiver

fault indicator that is connected to it.

4.2.7.5 Metering

The front panel meter connects to J3-1

(-) and J3-2 (+), the output of switch

S3, on the transmitter control board.

The front panel meter has seven

metering positions that are controlled

by S3: Audio, Video, % Aural Power, %

Visual Power, % Reflected Power,

% Exciter, and ALC. The video sample

connects to the board at J5-4 and is

connected through video calibration pot

R20 to position 6 on Front panel meter

switch S3. The audio sample enters the

board at J5-6 and is connected through

audio calibration pot R19 to position 7

on Front Panel Meter switch S3.

The reflected sample connects to the

board at J2-9 and is connected through

buffer amplifier U1B and 100-Ω resistor

R84 to position 3 on Front Panel Meter

switch S3. The visual sample connects

to the board at J2-5 and is connected

through buffer amplifier U1D and 100-

Ω resistor R86 to position 4 on Front

Panel Meter switch S3. The aural

sample connects to the board at J2-7

and is connected through buffer

amplifier U1C and 100-ohm resistor

R85 to position 5 on Front Panel Meter

switch S3. The exciter sample connects

to the board at J2-3 and is connected

through buffer amplifier U1A and 100-Ω

resistor R87 to position 2 on Front

Panel Meter switch S3. The ALC sample

connects to the board at J6-1 and is

connected through buffer amplifier

U2C, ALC calibration pot R15 (which

adjusts the output of U2A, pin 1), and

through 100-Ω resistor R18 to position

1 on Front Panel Meter Switch S3.

Typical readings on the meter are:

• Video = 1 Vpk-pk at white

• % Reflected = < 5%

• % Visual power = 100%

• % Aural power = 100%

• % Exciter = The level on the meter

needed to attain 100% output

power from the translator

Refer to the test data sheet for the

translator for the actual reading:

• ALC = .8 VDC

• Audio = ±25 kHz with a balanced

audio input or ±75 kHz with a

composite audio input

Samples are provided for the remote

metering of the exciter at J1-10, the

visual at J8-26, the aural at J8-27, and

the reflected at J1-5.

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-26

U6 is a temperature-sensor IC that

gives the operator the ability to

measure the temperature inside the

tray by measuring the voltage at TP1.

The sensor is set up for +10 mV equals

1° F (for example, 750 mV equals 75°

F).

4.2.7.6 Operational Voltages

The +12 VDC needed for the operation

of the transmitter control board enters

the board at jack J4, pin 3. C28, L1,

and L3 are for the filtering and isolation

of the +12 VDC before it is split and

applied to the rest of the board. The -

12 VDC needed for the operation of the

board enters the board at jack J4, pin

5. C29 and L2 are for the filtering and

isolation of the -12 VDC before it is split

and applied to the rest of the board.

The +12 VDC is split when it is

connected to the board. Four of the

+12 VDC outputs are fed out of the

board at J8-16, J8-17, J8-18, and J8-

19 through diodes CR7, CR8, CR9, or

CR10. Resistors R50, R51, R52, or R53

are fed to any external amplifier trays

for use in their logic circuits. The +12

VDC is also fed to the (Optional)

External Exhaust Kits in the Amplifier

Array Assemblies. The resistors are for

current limiting and the diodes are to

prevent voltage feedback from the

external amplifier trays.

4.2.8 (A14) Channel Oscillator

Assembly, Dual Oven (1145-1202;

Appendix D)

The channel oscillator assembly

contains (A14-A1) the channel

oscillator board (1145-1201) that

generates a stable frequency-reference

signal of approximately 100 MHz. The

channel oscillator assembly is an

enclosure that provides temperature

stability for the crystal oscillator. An

SMA output at jack J1 and an RF

sample at BNC connector jack J2 are

also part of the assembly.

Adjustments can be made through

access holes in the top cover of the

assembly. These adjustments are set at

the factory and should not be tampered

with unless it is absolutely necessary

and the proper, calibrated equipment is

available. R1 is the temperature

adjustment; C11 is the course-

frequency adjustment; C9 is the fine-

frequency adjustment; and C6, C18,

L2, and L4 are adjusted for the

maximum output of the frequency as

measured at jacks J1 or J2.

The +12 VDC for the assembly enters

through FL1 and the circuit-ground

connection is made at E1.

4.2.9 (A14) (Optional) VCXO

Assembly, Dual Oven (1145-1206;

Appendix D)

The VCXO assembly contains the VCXO

channel oscillator board (1145-1204)

which generates a stable frequency

reference signal of approximately 100

MHz. The VCXO channel oscillator

assembly is an enclosure that provides

temperature stability for the crystal

oscillator. An SMA output at jack J1

feeds the x8 multiplier assembly and an

RF sample at BNC connector jack J2

provides an oscillator sample.

Adjustments are provided through

access holes in the top cover of the

assembly. These adjustments are set at

the factory and should not be adjusted

unless it is absolutely necessary and

the properly calibrated equipment is

available. R1 is the temperature

adjustment; C11 is the course

frequency adjustment; and C6, C18,

L2, and L4 are adjusted for maximum

output of the frequency as measured at

jacks J1 or J2. The AFC voltage, which

is fed to FL2 from an external source, is

the fine frequency adjustment.

The +12 VDC for the assembly enters

through FL1 and the circuit ground

connection is made at E1.

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-27

4.2.10 (A13) (Optional) EEPROM

FSK Identifier Board (1265-1308;

Appendix D)

The optional FSK identifier board, with

EEPROM, generates a morse code

identification call sign by frequency-

shift keying the VCXO oscillator in the

upconverter or by sending a bias

voltage to the IF attenuator board to

amplitude modulate the aural carrier.

This gives the station a means of

automatically repeating its identification

call sign, at a given time interval, to

meet FCC requirements.

The starting circuit is made up of U1B

and U1D, which are connected as a

flip-flop, with gate U1A used as the set

flip-flop. U1A automatically starts the

flip-flop each time U3 completes its

timing cycle. At the start of a cycle,

U1B enables clock U2. U2 applies the

clock pulses that set the speed, which

is adjusted by R2, for when the

identification code is sent to 12-bit

binary counter U4. R2, fully clockwise

(CW), is the fastest pulse train and R2,

fully counter-clockwise (CCW), is the

slowest pulse train. U4 provides binary

outputs that address EEPROM U5.

The scans in U4 will continue until field

effect transistor (FET) Q1 is gated on.

The gate of Q1 is connected to pin 13

on U4, which is the maximum count

used in the EEPROM, and will provide a

reset pulse each time the binary

counter goes high on pin 13. The reset

pulse, when the drain of Q1 goes low,

is applied to the flip-flop and the timer

U3, which determines the length of

time between the sending of the

identification code. R14 is adjusted to

set this time interval. R14, fully CW, is

the longest interval between

identification calls, approximately eight

minutes. R14, fully CCW, is the

shortest interval between the sending

of the code (approximately 10

seconds).

U6B is an amplifier connected to the

output of U5, which turns the LED DS1

on and off at the rate set by R2. This

gives the operator a visual indication

that the FSK identifier board is

operating and at the rate at which it is

operating.

The data output of U5, which is serial,

is connected to U6A, whose output

shifts low and high, and is applied to

the VCXO board, which shifts the

frequency according to the

programming of U5. The deviation of

the shift is adjusted by R4 and is

typically set at 1 kHz. Once R4 is set,

R9 is re-adjusted to -1.5 VDC at J3-2.

The +12 VDC from an external power

supply enters the board at J1, pin 3.

The voltage is fed through RF choke L1

and is filtered by C1 before being

applied to the rest of the tray. The +12

VDC is also applied to U7, which is a

voltage regulator that regulates its

output at +5 VDC. The +5 VDC is fed

to the ICs on the board. The -12 VDC

from an external power supply enters

the board at J1, pin 5. The voltage is

fed through RF choke L2 and filtered by

C2 before being applied to the rest of

the tray.

4.2.11 (A24) (Optional) Composite

4.5-MHz Filter Board (1227-1244;

Appendix D)

The composite 4.5-MHz filter board is

mounted in the UHF exciter tray and is

part of the composite 4.5-MHz input

kit. The board filters the 4.5-MHz

composite signal to produce a video-

only output that connects to the sync

tip clamp/modulator board.

The composite 4.5-MHz signal from the

sync tip clamp/modulator board enters

the board at J1 and is amplified by U1A

and then split. A sample of the

composite 4.5-MHz signal is connected

out of the board at J2 and connects to

the 4.5-MHz bandpass filter board. The

other split portion of the composite 4.5-

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-28

MHz signal is connected to a four-

section, low-pass filter circuit, which is

adjusted by C2, L1, C5, L2, C8, L3, L4,

C11, L5, C15, L6, and C19, and has a

sharp roll-off that eliminates the 4.5-

MHz signal. The filter is set up at the

factory for the desired video-only

output and should not be adjusted by

the customer. The video low-pass

signal is amplified by U2B and applied

to the video low-pass output jack of the

board at J5, which is connected to the

sync tip clamp/modulator board. C21,

with jumper W1 on J9, can be adjusted

to set up the frequency response of the

video. The video-only signal is

amplified by U2A and connected to

three group delay circuits, which are

adjusted by L8 and R18, L9 and R22,

and L10 and R27. These circuits correct

for frequency-response problems

created by the filtering process.

A 4.5-MHz intercarrier signal from the

4.5-MHz bandpass filter board connects

to J3, the intercarrier input jack. The

intercarrier signal is amplified by U1B,

whose gain is set by R38, and

connected out of the board at J4. The

4.5-MHz signal connects to J28 on the

sync tip clamp/modulator board.

The ±12 VDC needed by the board is

supplied by an external power supply in

the tray. The +12 VDC enters the

board at J8, pin 3, and is filtered and

isolated from the rest of the tray by

L12 and C36 before being applied to

the rest of the board. The -12 VDC

enters the board at J8, pin 5, and is

filtered and isolated from the rest of

the tray by L32 and C37 before being

applied to the rest of the board.

4.2.12 (A25) (Optional) 4.5-MHz

Bandpass Filter Board (1265-1307;

Appendix D)

The 4.5-MHz bandpass filter board

passes the 4.5-MHz aural subcarrier

frequency and filters out any out-of-

band products that may be present.

The board consists of two circuits: a

bandpass filter circuit and an envelope

delay equalizer circuit. The filter circuit

has a bandpass characteristic that is

relatively flat around the aural

subcarrier frequency of 4.5 MHz ±100

kHz. It also has zeros (or notches) at

frequencies near 4 and 5 MHz that

prevent asymmetrical envelope delay

error in the pass-band. There is some

symmetrical delay error introduced, but

this is corrected by the envelope delay

equalizer circuit portion of the board.

This circuit places a hump for correction

in the center of the band at 4.5 MHz.

The composite input to the board is

through J1 at an impedance of 75Ω.

The filter circuit consists of the

capacitors C1 to C11 and inductors L1

to L5. The variable components L2, C3,

L4, and C7 are tuned for a peak in the

response around 4.5 MHz; this forms a

relatively flat-frequency response of 4.5

MHz ±100 kHz. The filtered output is

amplified by U1A before it is connected

to the envelope delay equalizer circuit.

The equalizer portion of the board

consists of capacitors C14 to C19 and

inductors L6 and L7. The tuning of the

equalizer is accomplished by removing

jumper W1 on J5 and adjusting L6 for a

notch in the frequency response at the

desired maximum envelope delay

frequency. Replace jumper W1 on J5,

the Operate position, and tune C19 for

a flat response around 4.5 MHz. The L-

pass network creates a flat response

around 4.5 MHz and also generates a

hump in the envelope delay response

to cancel the effects caused by the filter

half of the board that proceeds it.

The filtered and equalized output is

amplified by U1B and connected to J2,

the output jack of the board.

The DC voltages needed to operate the

board enter at jack J4. The +12 VDC

connects to the board at J4-3 and is

filtered and isolated by L8 and C20

before it is connected to the rest of the

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-29

board. The -12 VDC connects to the

board at J4-5 and is filtered and

isolated by L9 and C21 before it is

connected to the rest of the board.

4.2.13 (A3)+12V(4A)/-12V(1A)

Power Supply Board (1265-1312;

Appendix D)

The ±12-volt power supply board

consists of three separate power

supplies, two of which produce the +12

VDC and one for the -12 VDC needed

to power the circuit boards in the

exciter tray.

4.2.13.1 +12 VDC Power Supply

The 18 VAC from the external step-

down toroid in the tray connects to J1,

pins 7 and 8. The 18 VAC connects

through 7-amp fuse F2, for over-

current protection, to two full-wave

bridge rectifier circuits.

CR1, CR2, CR3, and CR4 rectify the AC

that is then filtered by C2 and

connected to U3 and U4; U3 and U4

are voltage-regulator ICs for the +12

VDC. The voltage-regulated and

current-limited +12-VDC output of U3

connects to J4, pins 1, 2, 3, and 4,

which is one of the +12-VDC outputs of

the board. The green LED DS3 will be

lit if +12 VDC is present to J4; C7 and

C8 are bypass capacitors. The +12 VDC

output of U4 connects to J5, pins 1, 2,

3, and 4, which is another one of the

+12-VDC outputs of the board. The

green LED DS4 will be lit if +12 VDC is

present to J5; C9 and C10 are bypass

capacitors.

CR5, CR6, CR7, and CR8 rectify the AC

that is then filtered by C1 and

connected to U1 and U2; U1 and U2

are voltage-regulator ICs for the +12

VDC. The voltage-regulated and

current-limited +12-VDC output of U1

connects to J6, pins 1, 2, 3, and 4,

which is one of the +12-VDC outputs of

the board. The green LED DS1 will be

lit if +12 VDC is present to J6; C3 and

C4 are bypass capacitors. The +12-

VDC output of U2 connects to J3, pins

1, 2, 3, and 4, which is another one of

the +12-VDC outputs of the board. The

green LED DS2 will be lit if +12 VDC is

present to J3; C5 and C6 are bypass

capacitors.

4.2.13.2 -12 VDC Power Supply

The 18 VAC from an external step-

down toroid connects to J1, pins 1 and

4, of the board and is wired to CR9,

CR10, CR11, and CR12 which form a

full-wave bridge rectifier network for

the –12-VDC power supply. F1 is a 3-

amp fuse that provides over-current

protection. The rectified output is

filtered by C11 and fed to U5, the

voltage-regulator IC for the -12 VDC.

The voltage-regulated and current-

limited -12 VDC is connected to the

-12-VDC output jacks J7, pins 5

through 10, and J8, pins 5 through 10.

The green LED DS5 will be lit if -12

VDC is present to J7 and J8; C12 and

C13 are bypass capacitors.

4.2.14 (A15) x8 Multiplier Enclosure

(1265-1347; Appendix D)

The x8 multiplier enclosure is an

aluminum box that provides RFI and

EMI protection for the x8 multiplier

board (1227-1002) that is mounted

inside of it. This protection is needed to

prevent any interference from

obstructing the upconversion process.

The output from the channel oscillator

at +5 dBm enters the enclosure at J1.

The oscillator signal is multiplied and

amplified by the x8 multiplier board to

+16 dBm and sent out of the enclosure

at J2.

The +12 VDC needed to operate the

board enters the enclosure through FL1

and connects to J3-3 on the board. The

return for the +12 VDC enters the

enclosure through E1 and connects to

J3-4 on the board.

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-30

4.2.15 (A15-A1) x8 Multiplier

Board (1227-1002; Appendix D)

The x8 multiplier board multiplies the

frequency of an RF input signal by a

factor of eight. The board is made up of

three identical x2 broadband frequency

doublers.

The input signal (+5 dBm) at the

fundamental frequency enters through

SMA jack J1 and is fed through a 3-dB

matching pad, consisting of R1, R2, and

R3, to amplifier IC U1. The output of

the amplifier stage is directed through

a bandpass filter, consisting of L2 and

C4, that is tuned to the fundamental

frequency (87 to 114 MHz). The

voltage measured at TP1 is typically

+.6 VDC.

The first doubler stage consists of Z1

with bandpass filter L3 and C6 tuned to

the second harmonic (174 to 228 MHz).

The harmonic is amplified by U2 and it

is again bandpass filtered at the

second-harmonic frequency by C10 and

L5 (174 to 228 MHz). The voltage

measured at TP2 is typically +1.2 VDC.

The next doubler stage consists of Z2

with bandpass filter C12 and L6 tuned

to the fourth harmonic of the

fundamental frequency (348 to 456

MHz). The fourth harmonic is then

amplified by U3 and fed through

another bandpass filter, consisting of

L11 and C18, that is tuned to the fourth

harmonic (348 to 456 MHz). The

voltage measured at TP3 is typically

+2.0 VDC.

The final doubler stage consists of Z3

with bandpass filter C20 and L12 tuned

to the eighth harmonic of the

fundamental frequency (696 to 912

MHz). The signal is amplified by U4,

U5, and U6 to a typical value of +2 to

+4 VDC as measured at test point TP4.

The amplified eighth harmonic is then

fed to J2, the SMA output jack of the

board. The typical LO signal output

level is +15 dBm nominal.

The detected sample of the output of

the x8 multiplier board at TP4 is also

fed to the base of Q1, which forward

biases it and lights the green LED DS1

on the board to indicate that the LO

signal is present.

The +12 VDC for the board enters

through jack J3-3 and is filtered by L7

and C16 before being distributed to the

circuits on the board.

4.2.16 (A12 and A16) UHF Filters

(1007-1101; Appendix D)

Each of the UHF filters is a tunable

two-section cavity filter that is

typically tuned for a bandwidth of 6

MHz and has a loss of -1 dB through

the filter.

4.2.17 (A11) UHF Upconverter

Board (1265-1310; Appendix D)

The UHF upconverter board provides

upconversion processing by mixing the

IF and LO signals in mixer Z1 to

produce the desired RF-frequency

output. The RF output is connected

through J3 to an external filter and

applied back to the board at J4 where

the gain is set by R10. The RF is

amplified and connected to the RF

output jack of the board at J5.

The IF signal (0 dBm) enters the board

at J1, an SMA connector, and is applied

through a filter circuit consisting of L10

and C25 to C28 and to a matching pad.

This pad consists of R1, R2, and R3,

which presents a relatively good source

impedance, and feeds the signal to pins

3 and 4, the I input of mixer Z1. The

local oscillator signal (+13 dBm) from

the x8 multiplier connects to the board

at jack J2, an SMA connector, through

a UHF channel filter and is connected

directly to pin 8, the L input of the

mixer.

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-31

The frequency of the LO is the sum of

the IF frequency above the required

visual carrier. For instance, in system

M, the IF visual frequency is at 45.75

MHz and the relative location of the

aural would be 4.5 MHz lower, or 41.25

MHz. For digital applications, the LO is

the center frequency of the digital

channel added to the 44-MHz IF

frequency. By picking the local

oscillator to be 45.75 MHz above the

visual carrier, a conversion in frequency

occurs by selecting the difference

product. The difference product, the

local oscillator minus the IF, will be at

the required visual carrier frequency

output. There will also be other signals

present at the RF output connector J3

at a lower level. These are the sum

conversion product: the LO and the IF

frequencies. Usually, the output

product that is selected by the tuning

of the external filter is the difference

product: the LO minus the 45.75-MHz

IF. The difference product has its side-

bands flipped so that the visual carrier

is lower in frequency than the aural

carrier.

If a bad reactive load is connected to

the mixer, the LO signal that is fed

through it can be increased because

the mixer no longer serves as a double-

balanced mixer. The mixer has the

inherent property of suppressing

signals that may leak from one input

port to any of the other ports. This

property is enhanced by having the

inputs and outputs of the mixer at a

50-Ω impedance. The reactive filter

that is externally connected to J3 of the

board does not appear as a good 50-Ω

load at all frequencies. The pad, in the

output line of the board, consists of R5,

R4, R6, and R7. The pad buffers the

bad effects of the reactive filter load

and makes it appear as a 50-Ω

impedance. The RF signal is amplified

by U1, a modular amplifier, and

contains biasing and impedance-

matching networks that makes U1 act

as a wideband-RF amplifier device. This

amplifier, in a 50-Ω system, has

approximately 12 dB of gain. U1 is

powered from the +12-VDC line

through RF decoupling components

R27, R28, C30, R8, and L1. Inductor L1

is a broadband-RF choke and is

resonance free through the UHF band.

The amplified RF connects to SMA RF

output jack J3, which is cabled to the

external filter.

The RF input signal from the external

filter re-enters the board at J4 (-11 to

-14 dBm) and is capacitively coupled to

the pin-diode attenuator circuit

consisting of CR1, CR2, and CR5. The

pin-diode attenuator acts as a voltage-

variable attenuator in which each pin

diode functions as a voltage-variable

resistor that depends on the DC bias

supplied to the diode for its resistance

value. The pin diodes, because of a

large, intrinsic region, cannot rectify

signals at this RF frequency; as a

result, they act as a linear voltage-

variable resistor.

The pin diodes are configured in shunt

configuration: CR1 is the first shunt

element, CR2 is the second shunt

element, and CR5 is the series

element. The manual gain AGC, W1 on

J10 between pins 1 and 2, is used in

most cases. The control voltage from

manual gain pot R10 sets up a current

path through R11 and the diodes in the

pin attenuator. The level-controlled RF

signal, from the pin-diode attenuator

circuit, is amplified by wideband-hybrid

amplifier IC U2 that is configured in the

same way as U1. The RF signal is

buffered by Q1 and applied to the

push-pull Class A amplifier circuit

consisting of Q2 and Q3. At the input to

the transistors, the RF is converted to a

balanced, dual feed by balun L4, which

is made from a short length of UT-141

coaxial cable.

Capacitors C12 and C13 provide DC

blocking for the input signal to the

amplifier devices. The RF outputs at the

collectors of the transistors are applied

through C19 and C20, which provide

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-32

DC blocking for the output signals. The

RF signals connect to L7, which consists

of UT-141 coaxial cable. L7 combines

the RF back to a single-RF output at a

50-Ω impedance and sends it to L8,

which provides a sample of the RF. The

main path through L10 is to J5, the RF

output jack of the board (+10 to +20

dBm). The sample of the RF connects

to a splitter that provides a sample

output (0 dBm) at J6 of the board. The

other output of the splitter connects to

a peak-detector circuit consisting of

CR3 and U3, which provides a DC level

at J7 that represents the RF output of

the UHF exciter to the front panel

meter. R29 sets up the calibration of

the front panel meter for 100% in the

UHF Exciter position when the output

power of the exciter is at +17 dBm

peak visual or +10 dBm average for

digital applications.

The board is powered by ±12 VDC that

is produced by an external power

supply. The +12 VDC enters the board

through J8, pin 3, and is filtered and

isolated by RF choke L9 and shunt

capacitors C24 and C33. This circuit

isolates the RF signals from the board

away from those of other devices

connected to the same +12 VDC line

external to the UHF upconverter board.

The +12 VDC is then applied to the rest

of the board.

The -12 VDC enters the board through

J8, pin 5, and is filtered and isolated by

RF choke L11 and shunt capacitors C34

and C35. This circuit isolates the RF

signals from this board away from

those of other devices connected to the

same -12 VDC line external to the UHF

upconverter board; the -12 VDC is then

applied to the rest of the board.

4.2.18 (A1) Power Entry Module

Assembly (1227-1206;Appendix D)

The power entry module assembly

provides overvoltage and surge

protection for the input AC lines that

connect to the exciter tray. The AC

input plug connects to J14; J14 is part

of the power entry module on the rear

panel of the exciter tray.

The module assembly contains two

130-VAC varistors and one 250-VAC

varistor that connect across the AC

lines and to ground. The module also

contains two 4-amp fuses for

overcurrent protection, one in each

input line.

4.3 (A4 and A5) Variable

Phase/Gain Trays (1245-1200;

Appendix C)

The Variable Phase/Gain Tray sets the

phase and gain adjustments of the RF

to provide maximum output when the

outputs of the two Amplifier Arrays are

combined. There are two Variable

Phase/Gain Trays in the 837B UHF

Translator, each controlling the phase

and gain of one of the two Amplifier

Arrays.

The Tray is made up of (A4) a Variable

Phase/Gain Assembly (1245-1204),

which contains (A4-A1) a Variable

Phase/Gain Board (1245-1201), (A5) a

Metering Board (1245-1202) and (A3)

a +15V/-12V Power Supply Board

(1245-1203).

4.3.1 (A4-A1) Variable Gain/Phase

Board (1245-1201; Appendix D)

The RF Input signal connects to the

rear panel of the Tray at J1 and is

cabled to J1 on (A4-A1) the Variable

Phase/Gain Board (1245-1201) that is

mounted inside (A4) the Variable

Phase/Gain Assembly (1245-1204) for

RFI and EMI protection. The Variable

Phase/Gain Board contains two main

circuits, one for ALC and one for Phase

adjustment of the RF signal. A front

panel mounted ALC adjust Pot (A8)

connects through (A5) the Metering

Board (1245-1202) to J5 on the Board

which controls the output level to the

tray. A front panel mounted Phase

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-33

adjust Pot (A7) connects through the

Metering Board to J4 on the Variable

Phase/Gain Board which controls the

phasing of the RF output. The Phasing

adjust is needed to phase the two RF

outputs of the Amplifier Arrays, when

they are combined, to achieve

maximum output. The phase and level

controlled RF signal connects to J2 of

the Variable Phase/Gain Board which

connects to the RF Output Jack J3

located on the rear panel of the Tray.

A sample of the RF from the Variable

Phase/Gain Board connects to J4 the

output Sample Jack located on the

front panel of the Tray.

4.3.2 (A5) Metering Board (1245-

1202; Appendix D)

A detected output sample level

connects to the Metering Board at J7

Pins 3 & 4 which is connected to the %

Power Level position on (A6) the front

panel meter of the Tray. S1 is a two

position front panel mounted switch

that allows the operator to view the

ALC Level, typically reads .6V - 1V, or

the % Power, which is calibrated for

100 % is +23 dBm output.

4.3.3 (A1) Power Entry Module

Assembly (1227-1206; Appendix

120/240 VAC connects to the Tray at J2

on (A1) the Power Entry Module

Assembly. Jumpers on the Power Entry

Module are set for the desired AC

Voltage Input. The assembly contains

an On/Off Switch, two 4 Amp Fuses

and three Varistors for AC line

protection. The AC is connected to

(A2) a step down Toroid that supplies

an 18 VAC output to the +15VDC/-

12VDC Power Supply Board.

4.3.4 (A3) +15V/-12V Power

Supply Board (1245-1203;

Appendix D)

The +15 VDC and -12 VDC needed to

operate the boards in the Tray are

generated on (A3) the +15 VDC/-12

VDC Power Supply Board (1245-1203).

The +15VDC/-12VDC Power Supply

Board supplies voltage regulated +15

VDC and -12 VDC Outputs to the rest

of the Tray. The Green LED DS1 is lit if

+15 VDC is present and the Green LED

DS2 is lit if -12 VDC is present at the

output of the +15V/-12V Power Supply

Board.

4.4 (A6) Metering Panel (1136811

or 1245-1400; Appendix C)

The Metering Panel provides three

meters, one for Combined, one for Side

A Amplifier Array and one for Side B

Amplifier Array Outputs. The Side A

Meter (A15) displays the % Forward

and the % Reflected Power samples for

the Side A Amplifier Array. The Side B

Meter (A17) displays the % Forward

and the % Reflected Power samples for

the Side B Amplifier Array. The

Combined Meter (A13) displays the %

Reject, % Visual, % Aural and the %

Reflected Power samples for the

Combined Output of the 4-6 kW

Translator. The Metering Panel also

takes the ALC Reference Inputs from

the (A4 & A5) Variable Phase/Gain

Trays and splits them six ways which

are then connected to the UHF

Amplifier Trays in the two amplifier

arrays.

The Metering Panel (A6) contains (A4,

A5, A6 & A11) four Splitter Boards

(1181-1002), (A7, A8 & A9) three Dual

Peak Detector Modules (1159965),

(A10) a Visual/Aural Metering Board

(1265-1309), (A18) a Detector

Threshold Board (1245-1402) and (A3)

a ±12V Power Supply Board (1062-

1013).

The (A13) Front Panel Meter monitors

the Combined Output Power and is

controlled by (S1) the Meter Control

Switch. The (A15) Front Panel Meter

monitors the Side A Output Power with

(S2) the Meter Control Switch. The

(A17) Front Panel Meter monitors Side

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-34

B Output Power with (S3) the Meter

Control Switch.

4.4.1 (A4, A5, A6 & A11) Splitter

Board (1181-1002; Appendix D)

The (A4) Splitter Board (1181-1002)

takes the ALC reference from the (A4)

Variable Phase/Gain Tray at J1-1 and

splits it six ways that connect to the

UHF Amplifier Trays mounted in the

Side A Amplifier Array.

The (A5) Splitter Board (1181-1002)

takes the ALC reference from the (A5)

Variable Phase/Gain Tray at J1-1 and

splits it six ways that connect to the

UHF Amplifier Trays mounted in the

Side B Amplifier Array.

The (A6) Splitter Board takes the

Combined Reflected Sample Input at

J1-1 and splits it. One of the split

Combined Samples connects to the

front panel Meter, one is used for

Remote Monitoring and the other two

connect back to the UHF Exciters for

use in the VSWR Cutback circuitry.

The (A11) Splitter Board (1181-1002)

takes the Combined Aural Sample

Input at J1-1 from the (A10)

Visual/Aural Metering Board and splits

it. One of the split Aural Samples

connects to the front panel Meter and

the other is used for Remote

Monitoring.

4.4.2 (A10) Visual/Aural Metering

Board (1265-1309; Appendix D)

The (A10) Visual/Aural Metering Board

has a Combined Forward Sample from

the Output Coupler Assembly of the

Translator connected to J1 on the

Board where it is split. One Forward

Sample connects to J2 on the board

that is cabled to J9, the Translator

Output Sample Jack, located on the

front panel of the Metering Panel. The

Combined Forward Sample on the

Visual/Aural Metering Board is split

again with one Sample used to produce

a Combined Visual Sample, that

connects to the front panel Meter (A13)

and also to the rear panel for Remote

monitoring. The other Combined

Forward Sample produces a combined

Aural Sample that connects to the

(A11) Splitter Board.

4.4.3 (A7, A8 & A9) Dual Peak

Detectors (1159965; Appendix D)

The (A7) Dual Peak Detector takes the

Combined Reflected Sample Input from

the Output Coupler Module and splits it.

A peak detected output of the reflected

sample connects to the (A6) Splitter

Board. The (A7) Dual Peak Detector

also has a Reject Sample Input from

the Reject Output Coupler Module and

splits it. One of the peak detected split

Reject Samples connects to the front

panel Meter and the other is used for

Remote Monitoring.

The (A8) Dual Peak Detector Module

takes a Reflected Sample from the Side

B Amplifier Array that is peak detected

and connected to the (A17) front panel

meter. Another input to the (A8) Dual

Peak Detector Module is a Forward

Sample from the Side B Amplifier Array

that is peak detected and connected to

the (A17) front panel meter.

The (A9) Dual Peak Detector Module

receives the Reflected Sample from the

Side A Amplifier Array which is peak

detected and connected to the (A15)

front panel meter. Another input to the

(A9) Dual Peak Detector Module is the

Forward Sample from the Side A

Amplifier Array which is peak detected

and connected to the (A15) front panel

meter.

4.4.4 (A18) Detector Threshold

Board (1245-1402; Appendix D)

The Detector Threshold Board consists

of three identical signal paths. One

path uses a detected Reflected sample

from Side A, another the detected

Reflected sample from Side B and the

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-35

final path uses a detected Combined

Reflected sample. These samples are

compared to the threshold settings,

20% Reflected level, and provide an

output to cut back the translator if the

reflected level of any of the input

samples increase above 20%.

A Sample of the Side A Reflected level

enters the board at J1-1. The level is

split and one path connects to J1-2 to

be used as a Side A Remote Reflected

output. The other path connects to the

Operational Amplifier U1A whose turn

on level is controlled by the setting of

R5. R5 is set to cause U1A to conduct

if the reflected sample input increases

above the 20% level. The output, at

J2-1 and also J2-5 through the jumper

W1 on J4, connects to the Transmitter

Control Board, located in the UHF

Exciter, where it cuts back the

translator using the VSWR cut back

circuits.

A Sample of the Side B Reflected level

enters the board at J8-1. The level is

split and one path connects to J8-2 to

be used as a Side B Remote Reflected

output. The other path connects to the

Operational Amplifier U1B whose turn

on level is controlled by the setting of

R12. R12 is set to cause U1B to

conduct if the reflected sample input

increases above the 20% level. The

output, at J2-5 and also J2-1 through

the jumper W1 on J4 connects to the

Transmitter Control Board, located in

the UHF Exciter, where it cuts back the

translator using the VSWR cut back

circuits.

A Sample of the Combined Reflected

level enters the board at J7-1. The

level is split and one path connects to

J7-2 to be used as a Remote Combined

Reflected output. The other path

connects to the Operational Amplifier

U1C whose turn on level is controlled

by the setting of R19. R19 is set to

cause U1C to conduct if the combined

reflected input sample increases above

the 20% level. The output, at J6-1 and

also J2-5 through the jumper W2 on J5

connects to the Transmitter Control

Board, located in the UHF Exciter,

where it cuts back the translator using

the VSWR cut back circuits

4.4.5 (A1) Power Entry Module

Assembly (1227-1206; Appendix D)

120/240 VAC connects to the Tray at J8

on (A1) the Power Entry Module

Assembly. Jumpers on the Power Entry

Module are set for the desired AC

Voltage Input. The assembly contains

an On/Off Switch, two 4 Amp Fuses

and three Varistors for AC line

protection. The AC is connected to

(A2) a step down Toroid that supplies

an 18 VAC output thru TB1 to the ±12V

Power Supply Board.

4.4.6 (A3) ±12V Power Supply

Board (1062-1013; Appendix D)

The ±12 VDC needed to operate the

Boards in the Metering Panel are

provided by the ±12 VDC Power Supply

Board (1062-1013).

The 18 VAC, from an external step-

down Transformer, is directed to the

Board thru J5 Pins 1 & 4, with Pin 2

connected to the center tap of the

secondary of the Transformer.

The +12 VDC is produced by using a

Full-Wave rectifier circuit consisting of

CR1 and CR2 whose output is filtered

by capacitor C1 and bypassed by C2 to

prevent oscillations. The filtered +12

VDC is applied to U1 a 7812 IC voltage

regulator and current limiter. C3 is a

bypass capacitor to prevent oscillations

in the output DC lines. DS1 is a Green

LED which when lit indicates that the

+12VDC is present at the output of the

board. The +12 VDC is distributed thru

Pins 2 & 7 of each of the Output Jacks,

J1, J2, J3 & J4, to the rest of the

boards in the Tray.

The -12 VDC is produced by using a

Full-Wave rectifier circuit that consists

of CR3 and CR4 whose output is filtered

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-36

by capacitor C4 and bypassed by C5 to

prevent oscillations. The filtered -12

VDC is applied to U2 a 7912 IC voltage

regulator and current limiter. C6 is a

bypass capacitor to prevent oscillations

in the output DC lines. C7 is a holding

capacitor to maintain -12VDC for an

instance even if the supply is lost. This

is to allow the positive voltages to be

removed from the Amplifier devices to

prevent damage to the devices. DS2 is

a Green LED which when lit indicates

that the -12 VDC is present at the

output of the board. The -12VDC is

distributed to the rest of the Boards in

the Tray thru Pins 4 & 5 of each of the

Output Jacks, J1, J2, J3 & J4.

The ±12 VDC outputs of the board are

connected to the rest of the boards in

the Metering Panel.

4.5 (A8) AC Distribution Assembly

(1245-1500; Appendix C)

The AC Distribution Assembly

distributes the Main AC Input, 208/240

VAC @ 20 Amps, that connects to the

UHF Exciter Assembly Cabinet to the

Trays and Assemblies which make up

the Exciter.

The 208/240 VAC Main AC Input to the

Exciter Cabinet connects to the

Terminal Block TB1, Line 1 to TB1-1A,

Line 2 to TB1-3A and Ground to TB1-

2A.

The 208/240 VAC Main AC Input

connects from the Terminal Block TB1-

1B (Line 1) to the 20 Amp Circuit

Breaker CB1-1, TB1-2B (Ground) to

Chassis Ground & TB1-3B (Line 2) to

the Circuit Breaker CB1-3. Three

MOVs, for surge and transient

protection, are connected to the AC

Lines from the Circuit Breaker, VR1

from Line 1 to Ground, VR3 from Line 2

to Ground and VR2 across the AC Lines.

The switched 208/240 VAC Main AC

Input is wired from the Circuit Breaker

Terminal 2 to the L inputs and Terminal

4 to the N Inputs of the (A1 & A2) IEC

Outlet Strips. The E Inputs to both IEC

Outlet Strips connect to Chassis

Ground.

There are four outputs for both the

(A1) and the (A2) IEC Outlet Strips.

On the A1 Outlet Strip, J1 connects to

J14 on the (A1) Exciter #1, J2 connects

to J14 on the (Optional) (A2) Exciter

#1, J3 connects to J8 on the (Optional)

(A3) Exciter Switcher Tray and J4

connects to J2 on the (A4) Variable

Phase/Gain Tray. On the A2 Outlet

Strip, J5 connects to J2 on the (A5)

Variable Phase/Gain Tray, J6 connects

to J8 on the (A6) Metering Panel, J7

connects to J2 on the (A7) Receiver

Tray or to the AC Input Jack on the

(Optional) Digital Modulator and J8 is

not used in this System.

4.6 (A2 & A3) 2-3 kW Amplifier

Arrays (1278-1300; Appendix C)

There are two Amplifier Array

Assemblies in the 837B 4-6 kW UHF

Solid State Internally Diplexed

Television Translator. The (A2 & A3)

Amplifier Array Assemblies (1278-

1300) are identical. Each Amplifier

Array contains; (A9-A1) an 8 Way

Splitter (ZFSC-8-43), (A1 thru A4,

A5(5kW) and A6(6kW)) UHF Amplifier

Trays, (A7) a 4, 5 or 6 Way Combiner,

(A12) a Reject Load Assembly (Only

with 5 & 6 kW transmiters), (A8) an

Output Coupler, (A10) an AC

Distribution Assembly (1278-1100

three phase or 1278-1200 single

phase) and (A11) an Interface Panel.

The output of the (A4) Variable

Phase/Gain Tray, located in the Exciter

Assembly, connects to (A2) the Side A

Amplifier Assembly. The output of the

(A5) Variable Phase/Gain Tray connects

to (A3) the Side B Amplifier Assembly.

The RF Input (+16 dBm) from the

Variable Phase/Gain Tray connects to

the RF Input Jack J1 on (A11) the

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-37

Interface Panel located in the Amplifier

Array Assembly. The RF is cabled to

the COM Input of (A9-A1) the 8 Way

Splitter that splits it eight ways. Four,

five or six of the RF outputs (+6 dBm)

of the Splitter are connected to J1, the

RF Input Jack on each of the four, five

or six UHF Amplifier Trays. The outputs

of the Splitter that are not used are

terminated with 50. Each of the UHF

Amplifier Trays amplify the RF signals

to approximately (+60 dBm), which is

the power needed to produce a total of

4000 - 6000 Watts Peak of Sync after

combining of the two Amplifier

Assemblies, with a maximum of 600

Watts Peak of Sync output per Tray.

The outputs of the UHF Amplifier Trays

are combined in the (A7) 4, 5 or 6 Way

Combiner. The Reject Output of the

Combiner is connected to (A12) the

Reject Load Assembly (Only in 5 or 6

kW transmitters).

The RF Output of the Combiner is

connected to (A8) the Output Coupler

Assembly which supplies a Forward

and a Reflected Power Sample of the

output from the Amplifier Assembly

that connect through the SMA

Connectors J2 and J3 located on the

(A11) Interface Panel to the Metering

Panel located in the UHF Exciter

Assembly.

The RF output of the Amplifier Array

(+63.5 to +65.2 dBm) is at J2 (1-5/8”)

of the Output Coupler.

In each UHF Amplifier Tray, a Forward

Power Sample and a Reflected Power

Sample, from the 4 Way Combiner

Board, are connected to the Dual Peak

Detector Board, Single Supply. The

Dual Peak Detector provides peak

detected forward samples to the

Amplifier Control Board that supplies

the samples to the front panel meter of

the UHF Amplifier Tray and also to the

Interface Panel for remote monitoring.

Before exiting each UHF Amplifier Tray

the RF is fed through a Circulator which

protects the Tray from high VSWR

conditions. The Reject Port of the

Circulator provides a Reject Sample to

the 4 Way Combiner Board which

supplies the Reflected Sample to the

Dual Peak Detector Board, Single

Supply located in the UHF Amplifier

Tray that connects to the front panel

meter.

The two power supply Enable (Operate)

Commands from the UHF Exciter Tray,

located in the UHF Exciter Assembly,

connect to the Terminal Block (A9-TB2)

mounted in each Amplifier Array. The

terminal block splits the Enables fur,

five or six ways in each array and

supplies them to all of the UHF

Amplifier Trays. The Enable is needed

to turn on the Switching Power Supply

located in each UHF Amplifier Tray. If

the Amplifier Array contains an

(Optional) External Exhaust Kit, then a

Fan Enable is supplied at J4-19 along

with +12V at J4-20 that connect to the

fan mounted on the roof, which turns it

on.

Main AC Input

Each Amplifier Assembly needs an AC

Input of 208/240 VAC at 55 Amps three

phase or 100 Amps Single Phase wired

to it. The 208/240 VAC Input to each

Amplifier Assembly connects to (A10)

the AC Distribution Assembly, Amplifier

Array (1278-1100 three phase or 1278-

1200 single phase) located on the right

side, center rear of each Cabinet. Each

AC Distribution Assembly contains the

Terminal Block (TB1) to which the

208/240 VAC connects.

For three phase, connect Line 1 to TB1-

1A, Line 2 to TB1-2A, Line 3 to TB1-3A

and Ground to TB1-4A. The AC

Distribution Panel contains Circuit

Breakers that supply the AC to the rest

of the Amplifier Assembly. The Input

AC from TB1 is connected to (CB1) the

Main AC Circuit Breaker (55 Amps) that

distributes the 220 VAC to the other

circuit breakers (CB2-CB9). The output

of CB1 has six MOVs for protection,

VR1 from Line 1 to Line 2, VR2 from

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-38

Line 2 to Line 3, VR3 from Line 1 to

Line 3, VR4 from Line 1 to Ground, VR5

from Line 2 to Ground and VR6 from

Line 3 to Ground.

For single phase, connect Line 1 to

TB1-1A, Line 2 to TB1-3A and Ground

to TB1-4A. The AC Distribution Panel

contains Circuit Breakers that supply

the AC to the rest of the Amplifier

Assembly. The Input AC from TB1 is

connected to (CB1) the Main AC Circuit

Breaker (100 Amps) that distributes

the 220 VAC to the other circuit

breakers (CB2-CB9). The output of

CB1 has three MOVs, VR4 from Line 1

to Ground, VR6 from Line 2 to Ground

and VR3 connected across the legs.

The switched Input AC is wired through

six Circuit Breakers, CB2-CB7, to the

six UHF Amplifier Trays in the Amplifier

Array Cabinets. CB2 is a 20 Amp

Circuit Breaker that supplies the AC

voltage to the (A1) UHF Amplifier Tray.

CB3 is a 20 Amp Circuit Breaker that

supplies the AC voltage to the (A2) UHF

Amplifier Tray. CB4 is a 20 Amp Circuit

Breaker that supplies the AC voltage to

the (A3) UHF Amplifier Tray. CB5 is a

20 Amp Circuit Breaker that supplies

the AC voltage to the (A4) UHF

Amplifier Tray. In 5 & 6 kW, CB6 is a

20 Amp Circuit Breaker that supplies

the AC voltage to the (A5) UHF

Amplifier Tray. In 6 kW, CB7 is a 20

Amp Circuit Breaker that supplies the

AC voltage to the (A6) UHF Amplifier

Tray. CB8 and CB9 are 3 Amp circuit

breakers that supply AC to the two

cooling fans located in the Reject Load

Assembly.

When the Circuit Breaker CB1 on the

AC Distribution Assembly in the UHF

Exciter Assembly is switched On, +12

VDC from the Exciter is supplied to

each of the Amplifier Array Cabinets.

In the Amplifier Array, the +12 VDC is

split and connected to each of the UHF

Amplifier Trays for operation of the LED

Status Indicators in the Tray. +12 VDC

from the Exciter is also supplied to each

of the (Optional) External Exhaust Kits

in the Amplifier Array Cabinets for

operation of the isolation relays.

4.7 {A1, A2, A3, A4, A5(5&6kW) &

A6(6kW)} UHF Amplifier Trays,

LDMOS (1301560 low

band/1301561 mid band/1301562

high band; Appendix C)

The LDMOS amplifier tray, with an RF

input of approximately +3 dBm,

provides a maximum power level of

+57.8 dBm, 600W + sound. All the

amplifier modules are broadband in

nature and require no tuning.

4.7.1 (A2) Variable Gain/Phase

Board Enclosure (1301548;

Appendix D)

The variable gain/phase enclosure

assembly provides EMI and RFI

protection for the variable gain/phase

board (1301549) that is mounted

inside of the assembly.

The RF input to the assembly is at SMA

jack J1 and the RF output is at SMA

jack J2. There are two control inputs

that connect to the assembly: the

attenuator bias input and the phase

control input. The attenuator bias input

from the amplifier control board

connects to FL4 and FL5 on the

assembly and is wired to J5 on the

board. The phase control input from the

amplifier control board connects to FL2

and E1 on the assembly and is wired to

J4 on the board. The input fault to the

amplifier control board connects to FL3

on the assembly and is wired to J6-1 on

the board. Ground E1 on the assembly

connects to J3-4 on the board.

The +32 VDC needed to operate the

board connects to FL1 on the assembly

which is wired to J3-3 on the board.

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-39

4.7.2 (A2-A1) Variable Gain/Phase

Board (1301549; Appendix D)

The variable gain/phase board provides

the circuits that adjust the phase and

the gain of the RF signal for the

amplifier tray in which it is mounted.

The RF input signal at J1 (+3dBm) is

split, with one output connected to a

detector circuit consisting of C8, CR4,

and U3A. This detected level is then

applied to comparator U3D, which

provides a high output when the input

signal level drops below a threshold set

by R16, R17, and CR5. This high is

applied to the red Input Fault LED DS1,

which lights to indicate an input fault

has occurred. DS1 can be seen through

the hole in the lid on the variable

gain/phase assembly. The high is also

connected to the gate of Q1, which

biases it on and causes its drain to go

low. The low is applied to the pin-diode

attenuator circuit consisting of CR1,

CR2, and CR3. The low to CR3

decreases the current through it and

increases its resistance, decreasing or

completely shutting off the RF applied

through it.

The other output of the RF input signal

from J1 is connected through C1 to a

voltage-controlled, pin-diode attenuator

circuit consisting of diodes CR1, CR2,

and CR3. The diodes are pin diodes in a

pi-type configuration whose resistance

varies inversely with the DC current

flow through them.

As the AGC voltage, attenuator bias,

applied to J5 increases, CR3 is forward

biased even more. This increases the

current flow through it by decreasing

its resistance; the RF signal that flows

through it increases in level. CR1 and

CR2 have less current through them;

this raises their resistance, causing the

RF signal that is applied to them to

decrease in level. The three diodes

form a pi-type attenuator whose

attenuation decreases with the

increasing AGC voltage.

U4 provides amplification,

approximately 8 dB, of the RF signal

before it is connected to the phase-

shifter circuit. The phase-shifter circuit

consists of L1, C16, C17, CR7, and

CR8. L1 is a 90°, 2-way splitter. The

signal at pin 1 of L1 is split and applied

to pins 2 and 4. The signal reflects off

CR7 and CR8 and is passed to pin 3.

The phase shift between pins 1 and 3

changes with the voltage applied across

CR7 and CR8. This voltage is controlled

by an external phase-adjust pot that

connects to J4. The +32 VDC from the

external switching power supply is used

as the reference that is applied to the

phase-control pot. The IC U2 provides

approximately 10 dB of gain at the

output of the phase-shifter circuit that

connects to two class A amplifier

stages, Q2 and Q3, with a total gain of

approximately 20 dB.

The first amplifier stage, Q2, is biased

at a collector current of approximately

100 mA. This current is set by R29,

R30, VR1, and Q2. VR1 forces the

voltage at the collector to stay at 8.9

VDC. This biases on Q2 and draws

enough current through R29 and R30

to keep the collector voltage at 8.9

VDC. The amplified output connects to

the second amplifier Q3. The bias

circuit for Q3 works in a manner similar

to the bias circuit for Q2. VR2 and VR3

maintain a collector voltage of 21 VDC,

while R36 and R37 limit the collector

current to 650 mA.

The output connects to J2 on the

board. A sample of the output is

detected by CR10 and connected to

TP4. A DVM can be connected to TP4 to

give a voltage indication of the RF

output level.

The +32 VDC connects to the board at

J3-3 and is split, with one half

connected to the two, class A amplifier

circuits. The other half of the +32 VDC

input is filtered, isolated by L4 and C13,

and connected to U1. U1 is a +12 VDC

regulator IC that produces the +12

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-40

VDC needed to operate the ICs on the

board.

The output of the variable gain/phase

board (+19 dBm) at J2 connects

through A16 a 6dB pad to J1 (+13

dBm) on the 1 Watt amplifier board

assembly.

4.7.3 (A3) 1-Watt Amplifier Board

Assembly (1301546; Appendix D)

The 1-watt UHF amplifier board

assembly provides radio frequency

interference (RFI) and electromagnetic

interference (EMI) protection, as well

as the heatsink, for the 1-watt UHF

amplifier board, 32V (1301547) that is

mounted inside the assembly.

Depending on the frequency of the

channel of operation, the assembly has

approximately 9 dB of gain.

The RF input to the assembly connects

to SMA jack J1. The amplified RF output

of the assembly is at SMA jack J2.

Typically, with an input signal of +13

dBm at J1 of the assembly, an output

of +22 dBm can be expected at J2.

The +32-VDC bias voltage connects

through FL1, a RF-bypassed, feed-

through capacitor, to E1 on the

amplifier board.

4.7.4 (A3-A1) 1-Watt Amplifier

Board, 32V (1301547; Appendix D)

The 1-watt UHF amplifier board, 32V is

mounted in the 1-watt UHF amplifier

assembly (1301546) and provides

approximately +9 dB of gain.

The UHF signal enters the board at J1,

a SMA connector, and is applied

through coupling capacitor C1 and a

stripline circuit to Q1, a UTV040F UHF

wideband-amplifier device. The base

and collector voltages needed to

operate the transistor are obtained

from the +32 VDC line that connects to

the board at E1 and is divided down to

26 volts by R4 and R5. The collector

voltage is fed through L4 and the base

voltage is fed through R3, VR1, VR2 the

divider network R1 and R2 and L2. The

amplified UHF output of Q1 is coupled

through a stripline circuit and C14 to

J2, the output SMA jack of the board.

The board is powered by the +32 VDC

that is produced by an external power

supply in the tray. The +32 VDC enters

through E1 and is fed across R4 and

R5, which drops approximately 6 volts,

to the collector (+26 VDC). The voltage

is filtered by RF decoupling components

L4, C11, C12, and C15 before it is

connected to the collector. The base

bias voltage is connected across R3,

VR1, VR2, R1, and R2, which sets the

base bias voltage at +.8 VDC and

forward biases Q1. C6, L1, and L2

provide RF decoupling of the bias

voltage before it is connected to the

base.

The board has a self-bias protection

circuit that uses Zener diodes VR1 and

VR2. If the current draw of the device

increases, the voltage drop across R4

and R5 increases; this decreases the

voltage that is applied to VR1 and VR2.

These two diodes drop a fixed voltage

of 20 VDC across them. As a result, if

the voltage drop across R4 and R5

increases, the voltage available to the

base of Q1 decreases and the device

will eventually be shut off.

4.7.5 (A1) UHF Filter (1007-1101;

Appendix D)

The UHF filter is a tunable two-section

cavity filter that is typically tuned for a

bandwidth of 6 MHz and has a loss of

-1 dB through the filter.

4.7.6 (A4-A1) 40 Watt UHF

Amplifier Assembly (1206693;

Appendix D)

The output of the UHF filter is

connected to the input J1 of (A4-A1)

the 40 Watt UHF amplifier assembly

that is mounted on (A4) the amplifier

enclosure. The (A4-A1) 40 watt UHF

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-41

amplifier assembly is made up of a (51-

5378-308-00) module, which is a class

AB module that is a highly linear

broadband amplifier for the frequency

range of 470 to 860 MHz. It can

deliver an output power of 40 watts

(CW) at an amplification of

approximately 13 dB.

The amplification circuit consists of

LDMOS transistors V804 and V805

connected in parallel and operating in

class AB. The paralleling network is

achieved with the aid of 3 dB couplers

Z802 and Z803. A further 3 dB coupler

Z801, in conjunction with capacitors

C800 and C819, serves as a phase

shifter. Phase alignment (for the

complete amplifier), as well as

quiescent current setting by means of

potentiometers R807 and R808. It is

factory implemented and should not

be altered.

PIN diodes V810/V811 form a

variable-damping circuit that is used to

adjust the amplification of the 40-watt

module. The adjustment is performed

with the Gain potentiometer R838. A

readjustment of the amplification may

be required, e.g., after repair work, to

ensure that all amplifiers in a

translator deliver the same output

power

4.7.7 (A4-A2) Coupler Board

Assembly (1227-1316;

Appendix D)

The UHF coupler assembly is mounted

in the A4 amplifier enclosure and

provides a forward power sample of the

input drive level to the (A4-A3) LDMOS

amplifier assembly. The drive-level

sample from J3 is cabled to the

amplifier control board where it

connects to the input of the overdrive-

protection circuit.

The RF input to the UHF coupler

assembly, from the 40 Watt UHF

amplifier module, connects to SMA jack

J1. The RF is connected by a stripline

track to SMA output jack J2. A hybrid-

coupler circuit picks off a forward

sample that is connected to SMA type

connector jack J3. R1 is a dissipation

load for the reject port of the coupler.

4.7.8 (A4-A3) LDMOS Amplifier

Assembly (1301556; Appendix D)

The output of the coupler assembly is

fed to (A4-A3) the LDMOS amplifier

assembly. The LDMOS amplifier

assembly is made up of a (51-5379-

309-00) module that operates class AB.

The module is a broadband amplifier

for the frequency range of 470 to 860

MHz. The amplification is

approximately 13 dB.

The amplification circuit consists of the

parallel connected push-pull amplifier

blocks V1 and V2 operating in class

AB. In order to match the transistor

impedance to the characteristic

impedance of the input and output

sides, matching networks are placed

ahead and behind the amplifier blocks.

Transformers Z3 to Z6 serve to

balance the input and output signals.

The paralleling circuit is achieved with

the aid of 3 dB couplers Z1 and Z2.

The working point setting is factory

implemented by means of

potentiometers R9, R11 and R12 and

should not be altered.

The output of the (A4-A3) LDMOS

amplifier module is connected to (A5-

A1) the 4 way splitter board.

4.7.9 (A5-A1) 4-Way Splitter

Assembly (1301580;Appendix D)

The 4-way splitter assembly is made up

of three 2-way Wilkinson stripline

splitters. One RF input to the board

provides four, equal RF outputs.

The RF input to the board is connected

to the input of the first 2-way splitter

that contains R1. R1 is a 100 

balancing resistor in which any RF due

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-42

to mismatching in the first splitter will

be dissipated. One of the two outputs

from the splitter connects to another 2-

way splitter that contains R2. R2 is a

100  balancing resistor in which any

RF due to mismatching in the splitter

will be dissipated. The other output of

the first splitter connects to the third 2-

way splitter that contains R3. R3 is a

100  balancing resistor in which any

RF due to mismatching in the splitter

will be dissipated. The two output

splitters provide four, equal RF outputs,

two each, which are connected to the

inputs of the (A5-A2, A5-A3, A5-A4 &

A5-A5) amplifier modules.

4.7.10 (A5-A2 to A5-A5) LDMOS

Amplifier Assemblies (1301556;

Appendix D)

The outputs of the splitter assembly are

fed to the inputs of the four LDMOS

amplifier assemblies. Each of the

LDMOS amplifier assemblies is made up

of a (51-5379-309-00) module that

operates class AB. The module is a

broadband amplifier for the frequency

range of 470 to 860 MHz. The

amplification is approximately 13 dB.

The amplification circuit consists of the

parallel connected push-pull amplifier

blocks V1 and V2 operating in class

AB. In order to match the transistor

impedance to the characteristic

impedance of the input and output

sides, matching networks are placed

ahead and behind the amplifier blocks.

Transformers Z3 to Z6 serve to

balance the input and output signals.

The paralleling circuit is achieved with

the aid of 3 dB couplers Z1 and Z2.

The working point setting is factory

implemented by means of

potentiometers R9, R11 and R12 and

should not be altered.

The output of the four LDMOS amplifier

modules are connected to (A5-A6) the

4 way combiner assembly.

4.7.11 (A5-A6) 4-Way Combiner

Assembly (1301557 [CH. 14 to

26], 1301558 [CH. 27 to 43], and

1301559 [CH. 44 to 69]; Appendix

The 4-way combiner assembly contains

(A5-A6-A1) a 4-way combiner board,

(A5-A6-A2) a circulator, (A5-A6-A3) a

thermal switch and (A5-A6-A4) another

thermal switch.

The 4-way combiner board is made up

of three, 2-way Wilkinson stripline

combiners. Two of the RF inputs to the

board are soldered directly to the

inputs for the 2-way combiner that

contains R5. R5 is a balancing resistor

in which any RF due to mismatching in

the combiner will be dissipated. The

other two RF inputs are soldered

directly to the 2-way combiner that

contains R6. R6 is a balancing resistor

in which any RF due to mismatching in

the combiner will be dissipated. The

outputs of the two, input 2-way

combiners connect to the third 2-way

combiner that contains R7. R7 is a

balancing resistor in which any RF due

to mismatching in the combiner will be

dissipated. The output of the third

combiner is connected to the output of

the 4-way combiner board that is

cabled to an external circulator.

The circulator protects the tray from

high-reflected power. A directional

coupler is built into the RF output

circuit on the 4-way combiner board.

The coupler provides a forward power

sample at J1 that is -40 dB down from

the level of the RF output signal.

A reject power sample from the

circulator is fed to the reject sample

input jack J2 on the 4-way combiner

board that is terminated into a 50-Ω

load. A directional coupler is built into

the reject sample circuit that provides

at J3 a signal that is -40 dB down from

the level of the reject power sample.

Both the reject and forward samples

are fed to (A6) the dual peak detector

enclosure.

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-43

4.7.12 (A6) Dual Peak Detector

Enclosure (1227-1317; Appendix

The dual peak detector enclosure

provides EMI and RFI protection for the

dual peak detector board, single supply

(1227-1333), which is mounted inside

the enclosure. The enclosure has two

inputs: a forward power sample at SMA

jack J1 and a reflected power sample at

SMA jack J2. The module has two

peak-detected sample outputs: a

forward power sample at FL2 from J4-4

on the board and a reflected power

sample at FL3 from J4-2 on the board.

The module also has a forward power

sample output at SMA jack J3 that

connects to a BNC jack J5 located on

the front panel.

The voltage, +32 VDC from the

amplifier protection board, connects to

FL1 on the assembly, which is wired to

J4-7 on the board.

4.7.13 (A6-A1) Dual Peak Detector

Board, Single Supply (1227-1333;

Appendix D)

The function of the dual peak detector

board is to detect forward and reflected

samples of visual or aural RF signals

and generate an output voltage

proportional to the power levels of the

sampled signals for metering purposes.

There are two identical signal paths on

the board: one for forward power and

one for reflected power. A sample of

forward output power, from the 4 way

combiner, enters the board at SMA jack

J1. Resistors R1, R2, and R3 form an

input impedance-matching network of

50Ω. The forward power signal is

detected by CR1, R4, R5, R7, R10, C1,

and C2. The output is buffered by

operational amplifiers U3B and U1C

before it is connected to forward power

output jack J4-4. U3 has a very high

input impedance that makes the IC less

sensitive to changes in the video level.

A sample of the forward power is

tapped off by R6 and R8 and fed to J3,

the forward sample output jack. Diode

CR2 provides temperature

compensation for diode CR1. An input

signal level of approximately +17 dBm

is enough to give a 1-VDC level at the

output of U1C.

A reflected output power sample, from

the 4 way combiner, enters the board

at SMA jack J2. Resistors R18, R19,

and R20 form an input impedance-

matching network of 50Ω. The reflected

power signal is then detected by CR3,

R21, R22, R24, C5, and C6 and the

output is buffered by operational

amplifiers U3A and U1B before it is

connected to reflected power output

jack J4-2. U3 has a very high input

impedance that makes the IC less

sensitive to changes in the video level.

Diode CR4 provides temperature

compensation for diode CR3. An input

signal level of approximately +17 dBm

is enough to give a 1-VDC level at the

output of U1B.

The +12 VDC needed for the operation

of U1 on the board is generated from

the +32 VDC that enters at J4, pin 7.

The +32 VDC is fed to U2, a voltage

regulator IC that produces +12 VDC at

its output, which is connected to U1.

4.7.14 (A7) Amplifier Protection

Board (1207117; Appendix D)

The amplifier protection board

distributes the biasing voltages to the

transistor amplifier devices that are

mounted on the amplifier boards in the

UHF amplifier tray. It also protects the

LDMOS devices on (A5-A2 to A5-A5)

the output amplifier modules from

overcurrent conditions using the board-

mounted 15-amp fuses F3 to F6. F1 is

board-mounted 10-amp fuse that

protects the LDMOS devices on (A4-A1)

the 40 Watt amplifier assembly and

also the transistor mounted on A3-A1

the 1 Watt amplifier board from

overcurrent conditions. F9 is a 3-amp

board-mounted fuse that protects the

+32 VDC that is applied to the amplifier

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-44

control board and is connected to the

dual peak detector board. F7 is a 15-

amp and F8 is a 3-amp spare fuse.

The +32 VDC from the switching power

supply enters the board at TB1, with

the plus (+) connections sent to pins 1

to 4 and the minus (-) connections sent

to pins 5 and 6. The +32 VDC is

connected across the .01-W/3-Ω

voltage-dropping resistors R14 to R26

that are used to set up the idling

currents for the transistor devices; the

fuses F1 to F6 that protect the

transistor devices during an

overcurrent condition through the

outputs of the board at TB2, TB3; and

also to output jack J1. Table 4-1

indicates the fuse, the amplifier device

it protects, and the idling current

settings for the class AB amplifier

devices.

Table 4-1. Fuses, Idling Currents, and Voltage Settings for the Class AB Amplifier Devices

SWITCH

POSITION

AMPLIFIER

MODULE

LDMOS

DEVICE

BIAS

ADJUST

POT

IDLING

CURRENT

VOLTAGE

SETTING FUSE

A3-A1* Q1*

Transistor NONE

.65A*

operating

current

A4-A1 V804 & V805

R807 &

R808 .5A

11.5mV F1 10A

I2 A4-A3 V1 & V2 R206 2A 20mV F2 10A

I3 A5-A2 V1 & V2 R9, R11

& R12 2A 20mV F3 15A

I4 A5-A3 V1 & V2 R9, R11

& R12 2A 20mV F4 15A

I5 A5-A4 V1 & V2 R9, R11

& R12 2A 20mV F5 15A

I6 A5-A5 V1 & V2 R9, R11

& R12 2A 20mV F6 15A

*The A3-A1 transistor Q1 operates class A at .65 amps of operating current.

The voltage drop across the selected

resistor that uses switch S1 is read with

a digital voltmeter (DVM) that is

connected from E2 to E3 on the board.

This voltage reading converts to the

idling current, with no RF drive applied,

or the operating current, with RF drive

applied, of the Q1 transistor device

operating Class A.

4.7.15 (A8) Amplifier Control

Board (1265-1414; Appendix D)

The amplifier control board provides

LED fault and enable indications on the

front panel of the tray and also

performs the following functions:

automatic gain control (AGC);

overdrive cutback, when the drive level

reaches the amount needed to attain

110% output power; and

overtemperature, VSWR, and overdrive

faults. The board also provides

connections to the front panel meter for

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-45

monitoring the AGC, % Reflected

Power, % Output Power, and the power

supply voltage.

A –12-VDC enable is applied to the

board at J4-1 from the transmitter

control board in the UHF exciter tray.

The enable causes the J-FET Q5 to be

biased off, making the drain go high;

the high is applied to Q4, which is

biased on. The drain of Q4 goes low

and lights the green Enable LED DS4

on the front panel. The high at the

drain of Q5 is also applied through CR5

to J4, pin 7, which is a high enable, to

the +32-VDC switching power supply,

switching it on.

If there is an overtemperature fault,

which is a low applied to J4, pin 3, the

low connects through CR4 and

overrides the high enable, switching off

the switching power supply. As long as

the fault is present, the switching

power supply is off and the red

Overtemperature LED DS3 on the front

panel is lit.

4.7.15.1 Phase Control

The phase control pot on the front of

the tray connects to J8-1 (+32 VDC),

J8-3 (phase I/P), and J8-4 (RTN) on

the board. The phase-control output

connects from J7 on the board to the

input of the phase-control circuit on the

variable gain/phase board (1301549).

4.7.15.2 Automatic and Manual Gain

Control Circuits

The amplifier control board contains the

AGC function for the UHF amplifier tray

in which it is mounted. An AGC

reference-level input from the UHF

exciter tray is applied to J3 pin 1, and

is amplified by U3B. The output of U3B

is connected to J5, which is wired to

the front panel gain pot that sets the

output power level of the tray when the

AGC is in the Auto position. The voltage

at the arm of the front panel gain pot is

amplified by U2D and is compared to a

sample of the output power of the tray

in U2A. The error voltage from U2A is

sent through Auto/Manual switch S1 to

J10, which connects to the pin-diode

attenuator circuit on the variable

gain/phase board. A sample of the AGC

voltage level is connected to position 1

on the front panel meter switch. The

tray can also be operated in manual

gain by switching S1 to the Manual

position and adjusting R16 for the

desired output power level.

FETs Q1 and Q3 delay and slowly

reapply the AGC voltage to the variable

gain/phase board when the system is

switched on or when the board is

switched from Auto to Manual (or back)

to prevent the overdriving of the tray.

4.7.15.3 Overdrive Circuit

A sample of the output of the 40 Watt

amplifier assembly, from the coupler

board assembly connects to J11 on the

amplifier control board. The sample is

peak detected by CR7 and U3A and the

output is connected to U3D.

If the input drive level increases above

the overdrive threshold reference set

by R71, which is the drive level needed

to produce 110% output power, the

output of U3D goes high and is split

three ways. One of the highs is

connected through R38 and CR3 to

U3C, causing its output to go high and

lighting the red Overdrive LED DS2 on

the front panel. Another of the highs is

connected through R74 and R75 to Q6,

which is biased on, causing its output

to go low. The low is connected through

J10 to the variable gain/phase board

that cuts back its output level.

The final high from U3D is connected

through CR2 and R37 to U1D, which is

biased on, causing its output to go

high. The high is connected to U2A,

whose output decreases and its output

power is cut back. If this path is not

present, the AGC, because the forward

power decreases, will try to drive the

variable gain/phase board harder

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-46

creating a positive feedback loop that

could damage the amplifier tray.

4.7.15.4 Metering Circuits

The +32 VDC that is connected to the

board from the switching power supply

is applied to jack J6, pin 1, of the board

and connected through R63, R96, R66,

R65, and R76 to the front panel meter

for monitoring. R65 can be adjusted to

calibrate the voltage reading to >30

VDC (+32 VDC) on the front panel

meter. This calibration was completed

at the factory and should not need to

be adjusted at this time.

A forward power sample of the output

of the tray is applied to jack J1-1 and

J1-2 of the board from the dual peak

detector board, single supply. The

forward power sample is connected

through R1 and R2 to U1A, a buffer

amplifier. The output of U1A is split,

with one part going to the AGC circuits,

another sample connected to J1-5 for

remote metering, and the final sample

applied to the meter at position 3 on

S2, the front panel meter switch. R2

can be adjusted to calibrate the %

Forward Power indication on the front

panel meter.

A sample of the reflected power output

of the tray is applied to jack J2-1 and

J2-2 of the board from the dual peak

detector board, single supply. The

reflected power sample is connected

through R21 and R22 to U1B, a buffer

amplifier. The output of U1B is split,

with one part going to the VSWR

threshold circuit, another sample

connected to J2-5 for remote metering,

and the final sample applied to the

meter at position 2 on S2, the front

panel meter switch. R22 can be

adjusted to calibrate the % Reflected

Power indication on the front panel

meter. A sample of the AGC voltage

level at R20 on the board is connected

through a divider network consisting of

R87, R88, R19, and R18 to the meter

at position 1 of S2, the Front Panel

Meter switch.

4.7.15.5 Operational Voltages

The voltage input to the board is +32

VDC from the switching power supply.

The +32 VDC connects to the board at

J6-1 and is wired to U4, which is a 3-

terminal regulator IC that takes the

+32 VDC input and produces the +12

VDC needed for the operation of the

board.

The +12 VDC from U4 is connected

through CR6 to U5, a +5-VDC

regulator, that takes the +12 VDC

input from U4, or the transmitter

control board in the UHF exciter tray,

through J6, pin 3, and produces a +5-

VDC output that is applied to the rest of

the board. This +12 VDC is connected

to U5, a regulator IC, which produces a

+5-VDC output that is applied to the

Enable and Overtemperature LEDs that

operate even when the +32 VDC input

to the board from the switching power

supply is removed.

4.8 (A13) (Optional) External

Exhaust Kit (1061320)

Each of the 2-3kW Amplifier Array

Assemblies may have an (Optional)

(A13) External Exhaust Kit mounted on

the roof of the cabinets. This kit

provides greater cooling by venting the

hot air outside the transmitter room

using a blower fan. +12 VDC is applied

to TB1-4A in the Exhaust enclosure

when the UHF Exciter circuit breaker is

switched On. An Enable is connected

to TB1-3A when the UHF Exciter,

Translator, is switched to Operate. The

Enable energizes the Isolation Relay

that applies the 120 VAC to the fan that

will operate.

4-6 kW UHF Translator Chapter 4, Circuit Descriptions

837B, Rev. 0 4-47

4.9 Translator Output Assemblies

The outputs of the (A2 & A3) 2-3 kW

Amplifier Assemblies (+63.5-+65.2

dBm) connect through 1-5/8” hard-line

and (A5 or A6) 1-5/8” to 3-1/8”

Adapters to (A4) a Hybrid Combiner.

The combiner combines the output

from each Amplifier Assembly into a

single output. The Reject Output of the

Hybrid Combiner is connected through

(A12) a 1-5/8” to 3-1/8” Adapter to

(A7) a Directional Coupler (1016-1043)

that provides a Reject Sample from J3

to the Metering Panel located in the

UHF Exciter Assembly for monitoring

purposes. The output of the Directional

Coupler connects to (A8) a 2500 Watt

Reject Load which dissipates any reject

due to problems in one of the Amplifier

Arrays. Mounted on the 2500 Watt

Load is (A8-A1) a Thermal Switch that

connects to the Overtemperature Fault

circuit located on the Transmitter

Control Board in the UHF Exciter Tray.

If the temperature of the load reaches

155°F. the switch closes and causes an

Overtemperature Fault to occur which

shuts down the Translator.

The output of the Hybrid Combiner at

J3 is fed to (A9) a Bandpass Filter,

(A10) an Output Trap Filter Assembly,

then to (A11) the Output Coupler

Assembly and finally to the Antenna for

your System. The Bandpass Filter and

Trap Filter are tuned to provide high

out of band rejection of unwanted

generated products. The filtered signal

is connected to (A11) an Output

Coupler Assembly which provides a

Combined Forward and a Combined

Reflected Power Sample to the

Metering Panel located in the Single

UHF Exciter Assembly. The Forward

Sample is processed to provide peak

detected Visual and Aural Power Output

Samples to the front panel Meter of the

Metering Panel. The Reflected Power

Sample is also peak detected and wired

to the front panel Meter. A Sample of

the RF Output, for test purposes can be

taken from J5 on the Coupler, but a 20

dB Attenuator must be connected to J6

for the Sample port to operate. An

appropriate attenuator must be

connected to J5 to protect any test

equipment connected to it.

The RF output of the Coupler at J2

(+66 to + 67.7 dBm pk of sync) is the

RF output of the translator and is

connected to the Antenna for your

System.

UBS Axcera 837B-5 5000-Watt UHF Translator User Manual 315946

UBS-Axcera 5000-Watt UHF Translator 315946

Contents

Chapter 4

Navigation menu

Namespaces

Views

Navigation
