837B-4, 837B-5, 837B-6
Visual Performance Aural Performance
Power Output (Peak)-3 4, 5 or 6 kW Power Output (Average) 400, 500 or 600W
Output Impedance 50 ohms Distortion 0.5%
Output Connector 3 1/8” EIA FM Noise -60 dB
Frequency Range*470 to 860MHz AM Noise -50 dB
Frequency Translation Stability ±1 kHz (standard) Aural to Visual Separation 4.5 MHz, ±100 Hz
±350 Hz (optional)
Regulation of RF Output Power 3%
Output Variation (over 1 frame) 2%
Sideband Response (System M/N-others on request)
-1.25 MHz and below -20 dB
-0.75 to -0.5 MHz +0.5 dB, -2 dB
-0.5 to +3.58 MHz ±0.5 dB
+3.58 MHz to +4.18 MHz +0.5 dB, -1 dB
Freq Response vs. Brightness ±0.5 dB
Differential Gain 5%
Incidental Phase Modulation ±3°
Linearity (Low Frequency) 5%
Differential Phase ±3°
Signal- to-Noise Ratio 55 dB
2t K-Factor 2%
Noise Figure 5 dB (max.)
w/input Preamp 3 dB (max.)
Input Dynamic Range -60 dBm to -15 dBm
w/input Preamp -75 dBm to -30 dBm
Env. Delay .02 to 4.18 MHz ±40 ns
Harmonics -60 dB or better
Intermodulation Products -52 dB or better
Spurious -60 dB or better
(>3 MHz from channel edge)
General
Operational Temperature Range -30°C to +50°C
Altitude* 8500 feet (2600 m) AMSL
Operational Humidity Range 0% to 95% non-condensing
Line Voltage 230V, ±10% 1 phase ro 3 phase, 50/60 Hz
Power Factor 0.95
Transmitter Dimensions (W x D x H) Weight PowerConsumption
837B-4 80” x 66” x 34” 1350 lbs 13,700 W (50% APL)
837B-5 80” x 66” x 34” 1500 lbs 13,700 W (50% APL)
837B-6 80” x 66” x 34” 1650 lbs 20,200 W (50% APL)
UHF Solid State LDMOS Translator
