Users Manual pt 5
55
Appendix E: WarrantyairFiber X User Guide
Ubiquiti Networks, Inc.
Appendix E: Warranty
Limited Warranty
UBIQUITI NETWORKS, Inc (“UBIQUITI NETWORKS”)
warrants that the product(s) furnished hereunder (the
“Product(s)”) shall be free from defects in material and
workmanship for a period of one (1) year from the date
of shipment by UBIQUITI NETWORKS under normal use
and operation. UBIQUITI NETWORKS’ sole and exclusive
obligation and liability under the foregoing warranty
shall be for UBIQUITI NETWORKS, at its discretion, to
repair or replace any Product that fails to conform to the
above warranty during the above warranty period. The
expense of removal and reinstallation of any Product is
not included in this warranty. The warranty period of any
repaired or replaced Product shall not extend beyond its
original term.
Warranty Conditions
The above warranty does not apply if the Product:
(I) has been modified and/or altered, or an addition
made thereto, except by Ubiquiti Networks, or
Ubiquiti Networks’ authorized representatives, or as
approved by Ubiquiti Networks in writing;
(II) has been painted, rebranded or physically modified in
any way;
(III) has been damaged due to errors or defects in cabling;
(IV) has been subjected to misuse, abuse, negligence,
abnormal physical, electromagnetic or electrical
stress, including lightning strikes, or accident;
(V) has been damaged or impaired as a result of using
third party firmware;
(VI) has no original Ubiquiti MAC label, or is missing any
other original Ubiquiti label(s); or
(VII) has not been received by Ubiquiti within 30 days of
issuance of the RMA.
In addition, the above warranty shall apply only if: the
product has been properly installed and used at all times
in accordance, and in all material respects, with the
applicable Product documentation; all Ethernet cabling
runs use CAT5 (or above), and for outdoor installations,
shielded Ethernet cabling is used, and for indoor
installations, indoor cabling requirements are followed.
WARNING: Failure to properly ground your
airFiber units will void your warranty. (Please
follow the instructions on “Install a Ground Wire”
on page 5 for installation of the ground wires.)
Returns
No Products will be accepted for replacement or repair
without obtaining a Return Materials Authorization (RMA)
number from UBIQUITI NETWORKS during the warranty
period, and the Products being received at UBIQUITI
NETWORKS’ facility freight prepaid in accordance with the
RMA process of UBIQUITI NETWORKS. Products returned
without an RMA number will not be processed and will be
returned freight collect or subject to disposal. Information
on the RMA process and obtaining an RMA number can be
found at: www.ubnt.com/support/warranty.
Disclaimer
EXCEPT FOR ANY EXPRESS WARRANTIES PROVIDED
HEREIN, UBIQUITI NETWORKS, ITS AFFILIATES, AND ITS
AND THEIR THIRD PARTY DATA, SERVICE, SOFTWARE AND
HARDWARE PROVIDERS HEREBY DISCLAIM AND MAKE
NO OTHER REPRESENTATION OR WARRANTY OF ANY
KIND, EXPRESS, IMPLIED OR STATUTORY, INCLUDING,
BUT NOT LIMITED TO, REPRESENTATIONS, GUARANTEES,
OR WARRANTIES OF MERCHANTABILITY, ACCURACY,
QUALITY OF SERVICE OR RESULTS, AVAILABILITY,
SATISFACTORY QUALITY, LACK OF VIRUSES, QUIET
ENJOYMENT, FITNESS FOR A PARTICULAR PURPOSE AND
NON-INFRINGEMENT AND ANY WARRANTIES ARISING
FROM ANY COURSE OF DEALING, USAGE OR TRADE
PRACTICE IN CONNECTION WITH SUCH PRODUCTS
AND SERVICES. BUYER ACKNOWLEDGES THAT NEITHER
UBIQUITI NETWORKS NOR ITS THIRD PARTY PROVIDERS
CONTROL BUYER’S EQUIPMENT OR THE TRANSFER OF
DATA OVER COMMUNICATIONS FACILITIES, INCLUDING
THE INTERNET, AND THAT THE PRODUCTS AND SERVICES
MAY BE SUBJECT TO LIMITATIONS, INTERRUPTIONS,
DELAYS, CANCELLATIONS AND OTHER PROBLEMS
INHERENT IN THE USE OF COMMUNICATIONS FACILITIES.
UBIQUITI NETWORKS, ITS AFFILIATES AND ITS AND THEIR
THIRD PARTY PROVIDERS ARE NOT RESPONSIBLE FOR ANY
INTERRUPTIONS, DELAYS, CANCELLATIONS, DELIVERY
FAILURES, DATA LOSS, CONTENT CORRUPTION, PACKET
LOSS, OR OTHER DAMAGE RESULTING FROM ANY OF THE
FOREGOING. In addition, UBIQUITI NETWORKS does not
warrant that the operation of the Products will be error-
free or that operation will be uninterrupted. In no event
shall UBIQUITI NETWORKS be responsible for damages
or claims of any nature or description relating to system
performance, including coverage, buyer’s selection of
products (including the Products) for buyer’s application
and/or failure of products (including the Products) to meet
government or regulatory requirements.
56
Appendix E: Warranty airFiber X User Guide
Ubiquiti Networks, Inc.
Limitation of Liability
EXCEPT TO THE EXTENT PROHIBITED BY LOCAL LAW, IN NO
EVENT WILL UBIQUITI OR ITS SUBSIDIARIES, AFFILIATES OR
SUPPLIERS BE LIABLE FOR DIRECT, SPECIAL, INCIDENTAL,
CONSEQUENTIAL OR OTHER DAMAGES (INCLUDING LOST
PROFIT, LOST DATA, OR DOWNTIME COSTS), ARISING
OUT OF THE USE, INABILITY TO USE, OR THE RESULTS OF
USE OF THE PRODUCT, WHETHER BASED IN WARRANTY,
CONTRACT, TORT OR OTHER LEGAL THEORY, AND
WHETHER OR NOT ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES.
Note
Some countries, states and provinces do not allow
exclusions of implied warranties or conditions, so the
above exclusion may not apply to you. You may have
other rights that vary from country to country, state to
state, or province to province. Some countries, states
and provinces do not allow the exclusion or limitation of
liability for incidental or consequential damages, so the
above limitation may not apply to you. EXCEPT TO THE
EXTENT ALLOWED BY LOCAL LAW, THESE WARRANTY
TERMS DO NOT EXCLUDE, RESTRICT OR MODIFY, AND
ARE IN ADDITION TO, THE MANDATORY STATUTORY
RIGHTS APPLICABLE TO THE LICENSE OF ANY SOFTWARE
(EMBEDDED IN THE PRODUCT) TO YOU. The United
Nations Convention on Contracts for the International Sale
of Goods shall not apply to any transactions regarding the
sale of the Products.
57
Appendix F: Compliance InformationairFiber X User Guide
Ubiquiti Networks, Inc.
Appendix F: Compliance
Information
Installer Compliance Responsibility
Devices must be professionally installed and it is the
professional installer’s responsibility to make sure the
device is operated within local country regulatory
requirements.
FCC
airFiber AF-2X
Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions.
1. This device may not cause harmful interference, and
2. This device must accept any interference received,
including interference that may cause undesired
operation.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in
a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Operations of this equipment in a residential area is likely
to cause harmful interference in which case the user will
be required to correct the interference at his own expense.
This radio transmitter (FCC: SWX-AF2X) has been approved
by FCC to operate with the antenna types listed below
with the maximum permissible gain and required antenna
impedance for each antenna type indicated. Antenna
types not included in this list, having a gain greater than
the maximum gain indicated for that type, are strictly
prohibited for use with this device.
• Dish antenna, gain: 6 dBi
• Dish antenna, gain: 24 dBi
airFiber AF-3X
Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions.
1. This device may not cause harmful interference, and
2. This device must accept any interference received,
including interference that may cause undesired
operation.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in
a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Operations of this equipment in a residential area is likely
to cause harmful interference in which case the user will
be required to correct the interference at his own expense.
This radio transmitter (FCC: SWX-AF3X) has been approved
by FCC to operate with the antenna types listed below
with the maximum permissible gain and required antenna
impedance for each antenna type indicated. Antenna
types not included in this list, having a gain greater than
the maximum gain indicated for that type, are strictly
prohibited for use with this device.
• Dish antenna, gain: 12 dBi
• Dish antenna, gain: 26 dBi
• Dish antenna, gain: 29 dBi
58
Appendix F: Compliance Information airFiber X User Guide
Ubiquiti Networks, Inc.
airFiber AF-4X
Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions.
1. This device may not cause harmful interference, and
2. This device must accept any interference received,
including interference that may cause undesired
operation.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in
a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Operations of this equipment in a residential area is likely
to cause harmful interference in which case the user will
be required to correct the interference at his own expense.
airFiber AF-5X
Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions.
1. This device may not cause harmful interference, and
2. This device must accept any interference received,
including interference that may cause undesired
operation.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in
a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Operations of this equipment in a residential area is likely
to cause harmful interference in which case the user will
be required to correct the interference at his own expense.
This radio transmitter (FCC: SWX-AF5X) has been approved
by FCC to operate with the antenna types listed below
with the maximum permissible gain and required antenna
impedance for each antenna type indicated. Antenna
types not included in this list, having a gain greater than
the maximum gain indicated for that type, are strictly
prohibited for use with this device.
• Dish antenna, gain: 23 dBi
• Dish antenna, gain: 30 dBi
• Dish antenna, gain: 34 dBi
DFS Regulatory Regions
Operation in DFS regulatory regions requires an antenna
with minimum gain of 23 dBi.
59
Appendix F: Compliance InformationairFiber X User Guide
Ubiquiti Networks, Inc.
Industry Canada
airFiber AF-2X
CAN ICES-3(B)/NMB-3(B)
To reduce potential radio interference to other users, the
antenna type and its gain should be so chosen that the
equivalent isotropically radiated power (e.i.r.p.) is not more
than that permitted for successful communication.
This device complies with Industry Canada licence-exempt
RSS standard(s). Operation is subject to the following two
conditions:
1. This device may not cause interference, and
2. This device must accept any interference, including
interference that may cause undesired operation of the
device.
This radio transmitter (IC: 6545A-AF2X) has been approved
by Industry Canada to operate with the antenna types
listed below with the maximum permissible gain and
required antenna impedance for each antenna type
indicated. Antenna types not included in this list, having
a gain greater than the maximum gain indicated for that
type, are strictly prohibited for use with this device.
• Dish antenna, gain: 6 dBi
• Dish antenna, gain: 24 dBi
CAN ICES-3(B)/NMB-3(B)
Pour réduire le risque d’interférence aux autres utilisateurs,
le type d’antenne et son gain doivent être choisies de
façon que la puissance isotrope rayonnée équivalente
(PIRE) ne dépasse pas ce qui est nécessaire pour une
communication réussie.
Cet appareil est conforme à la norme RSS Industrie Canada
exempts de licence norme(s). Son fonctionnement est
soumis aux deux conditions suivantes:
1. Cet appareil ne peut pas provoquer d’interférences et
2. Cet appareil doit accepter toute interférence, y compris
les interférences qui peuvent causer un mauvais
fonctionnement du dispositif.
Cet émetteur radio (IC: 6545A-AF2X) a été approuvée par
Industrie Canada pour l’exploitation avec l’antenne types
énumérés ci-dessous avec le gain maximal admissible
et requis l’impédance de l’antenne pour chaque type
d’antenne indiqué. Types d’antenne non inclus dans cette
liste, ayant un gain supérieur au gain maximal indiqué
pour ce type, sont strictement interdits pour une utilisation
avec cet appareil. Immédiatement suite à la remarque, le
fabricant doit fournir une liste de tous les types d’antenne
approuvé pour une utilisation avec l’émetteur, ce qui
indique le gain maximal d’antenne permis (en dBi) et
requis d’impédance pour chacun.
• Antenne parabolique, gain: 6 dBi
• Antenne parabolique, gain: 24 dBi
airFiber AF-3X
CAN ICES-3(B)/NMB-3(B)
To reduce potential radio interference to other users, the
antenna type and its gain should be so chosen that the
equivalent isotropically radiated power (e.i.r.p.) is not more
than that permitted for successful communication.
This device complies with Industry Canada licence-exempt
RSS standard(s). Operation is subject to the following two
conditions:
1. This device may not cause interference, and
2. This device must accept any interference, including
interference that may cause undesired operation of the
device.
This radio transmitter (IC: 6545A-AF3X) has been approved
by Industry Canada to operate with the antenna types
listed below with the maximum permissible gain and
required antenna impedance for each antenna type
indicated. Antenna types not included in this list, having
a gain greater than the maximum gain indicated for that
type, are strictly prohibited for use with this device.
• Dish antenna, gain: 12 dBi
• Dish antenna, gain: 26 dBi
• Dish antenna, gain: 29 dBi
CAN ICES-3(B)/NMB-3(B)
Pour réduire le risque d’interférence aux autres utilisateurs,
le type d’antenne et son gain doivent être choisies de
façon que la puissance isotrope rayonnée équivalente
(PIRE) ne dépasse pas ce qui est nécessaire pour une
communication réussie.
Cet appareil est conforme à la norme RSS Industrie Canada
exempts de licence norme(s). Son fonctionnement est
soumis aux deux conditions suivantes:
1. Cet appareil ne peut pas provoquer d’interférences et
2. Cet appareil doit accepter toute interférence, y compris
les interférences qui peuvent causer un mauvais
fonctionnement du dispositif.
Cet émetteur radio (IC: 6545A-AF3X) a été approuvée par
Industrie Canada pour l’exploitation avec l’antenne types
énumérés ci-dessous avec le gain maximal admissible
et requis l’impédance de l’antenne pour chaque type
d’antenne indiqué. Types d’antenne non inclus dans cette
liste, ayant un gain supérieur au gain maximal indiqué
pour ce type, sont strictement interdits pour une utilisation
avec cet appareil. Immédiatement suite à la remarque, le
fabricant doit fournir une liste de tous les types d’antenne
approuvé pour une utilisation avec l’émetteur, ce qui
indique le gain maximal d’antenne permis (en dBi) et
requis d’impédance pour chacun.
• Antenne parabolique, gain: 12 dBi
• Antenne parabolique, gain: 26 dBi
• Antenne parabolique, gain: 29 dBi
60
Appendix F: Compliance Information airFiber X User Guide
Ubiquiti Networks, Inc.
airFiber AF-4X
CAN ICES-3(B)/NMB-3(B)
To reduce potential radio interference to other users, the
antenna type and its gain should be so chosen that the
equivalent isotropically radiated power (e.i.r.p.) is not more
than that permitted for successful communication.
This device complies with Industry Canada licence-exempt
RSS standard(s). Operation is subject to the following two
conditions:
1. This device may not cause interference, and
2. This device must accept any interference, including
interference that may cause undesired operation of the
device.
CAN ICES-3(B)/NMB-3(B)
Pour réduire le risque d’interférence aux autres utilisateurs,
le type d’antenne et son gain doivent être choisies de
façon que la puissance isotrope rayonnée équivalente
(PIRE) ne dépasse pas ce qui est nécessaire pour une
communication réussie.
Cet appareil est conforme à la norme RSS Industrie Canada
exempts de licence norme(s). Son fonctionnement est
soumis aux deux conditions suivantes:
1. Cet appareil ne peut pas provoquer d’interférences et
2. Cet appareil doit accepter toute interférence, y compris
les interférences qui peuvent causer un mauvais
fonctionnement du dispositif.
airFiber AF-5X
CAN ICES-3(B)/NMB-3(B)
To reduce potential radio interference to other users, the
antenna type and its gain should be so chosen that the
equivalent isotropically radiated power (e.i.r.p.) is not more
than that permitted for successful communication.
This device complies with Industry Canada licence-exempt
RSS standard(s). Operation is subject to the following two
conditions:
1. This device may not cause interference, and
2. This device must accept any interference, including
interference that may cause undesired operation of the
device.
This radio transmitter (IC: 6545A-AF5X) has been approved
by Industry Canada to operate with the antenna types
listed below with the maximum permissible gain and
required antenna impedance for each antenna type
indicated. Antenna types not included in this list, having
a gain greater than the maximum gain indicated for that
type, are strictly prohibited for use with this device.
• Dish antenna, gain: 23 dBi
• Dish antenna, gain: 30 dBi
• Dish antenna, gain: 34 dBi
CAN ICES-3(B)/NMB-3(B)
Pour réduire le risque d’interférence aux autres utilisateurs,
le type d’antenne et son gain doivent être choisies de
façon que la puissance isotrope rayonnée équivalente
(PIRE) ne dépasse pas ce qui est nécessaire pour une
communication réussie.
Cet appareil est conforme à la norme RSS Industrie Canada
exempts de licence norme(s). Son fonctionnement est
soumis aux deux conditions suivantes:
1. Cet appareil ne peut pas provoquer d’interférences et
2. Cet appareil doit accepter toute interférence, y compris
les interférences qui peuvent causer un mauvais
fonctionnement du dispositif.
Cet émetteur radio (IC: 6545A-AF5X) a été approuvée par
Industrie Canada pour l’exploitation avec l’antenne types
énumérés ci-dessous avec le gain maximal admissible
et requis l’impédance de l’antenne pour chaque type
d’antenne indiqué. Types d’antenne non inclus dans cette
liste, ayant un gain supérieur au gain maximal indiqué
pour ce type, sont strictement interdits pour une utilisation
avec cet appareil. Immédiatement suite à la remarque, le
fabricant doit fournir une liste de tous les types d’antenne
approuvé pour une utilisation avec l’émetteur, ce qui
indique le gain maximal d’antenne permis (en dBi) et
requis d’impédance pour chacun.
• Antenne parabolique, gain: 23 dBi
• Antenne parabolique, gain: 30 dBi
• Antenne parabolique, gain: 34 dBi
61
Appendix F: Compliance InformationairFiber X User Guide
Ubiquiti Networks, Inc.
RF Exposure Warning
airFiber AF-2X
The antennas used for this transmitter must be installed
to provide a separation distance of at least 126 cm from
all persons and must not be located or operating in
conjunction with any other antenna or transmitter.
Les antennes utilisées pour ce transmetteur doivent être
installé en considérant une distance de séparation de
toute personnes d’au moins 126cm et ne doivent pas être
localisé ou utilisé en conflit avec tout autre antenne ou
transmetteur.
airFiber AF-3X
The antennas used for this transmitter must be installed
to provide a separation distance of at least 364 cm from
all persons and must not be located or operating in
conjunction with any other antenna or transmitter.
Les antennes utilisées pour ce transmetteur doivent être
installé en considérant une distance de séparation de
toute personnes d’au moins 364cm et ne doivent pas être
localisé ou utilisé en conflit avec tout autre antenne ou
transmetteur.
airFiber AF-4X
The radiated output power of this device is below the FCC
radio frequency exposure limits. Nevertheless, the device
should be used in such a manner that the potential for
human contact during the normal operation is minimized.
In order to avoid the possibility of exceeding the FCC radio
frequency exposure limit, human proximity to the antenna
should be more than 180 cm.
La puissance de sortie rayonnée de cet appareil est
inférieure aux limites d’exposition de radio de fréquence
FCC. Néanmoins, le dispositif doit être utilisé de telle
manière que le potentiel pour le contact humain pendant
l’utilisation normale soit minimisé. Afin d’éviter la
possibilité de dépasser la limite d’exposition de fréquence
radio de la FCC, la proximité humaine à l’antenne devrait
être plus que 180 cm.
airFiber AF-5X
The antennas used for this transmitter must be installed
to provide a separation distance of at least 126 cm from
all persons and must not be located or operating in
conjunction with any other antenna or transmitter.
Les antennes utilisées pour ce transmetteur doivent être
installé en considérant une distance de séparation de
toute personnes d’au moins 126cm et ne doivent pas être
localisé ou utilisé en conflit avec tout autre antenne ou
transmetteur.
Australia and New Zealand
airFiber AF-2X
Warning: This is a Class B product. In a domestic
environment this product may cause radio interference
in which case the user may be required to take adequate
measures.
airFiber AF-3X
Warning: This is a Class B product. In a domestic
environment this product may cause radio interference
in which case the user may be required to take adequate
measures.
airFiber AF-4X
Warning: This is a Class B product. In a domestic
environment this product may cause radio interference
in which case the user may be required to take adequate
measures.
airFiber AF-5X
Warning: This is a Class B product. In a domestic
environment this product may cause radio interference
in which case the user may be required to take adequate
measures.
62
Appendix F: Compliance Information airFiber X User Guide
Ubiquiti Networks, Inc.
CE Marking
airFiber AF-2X
CE marking on this product represents the product is in
compliance with all directives that are applicable to it.
airFiber AF-3X
CE marking on this product represents the product is in
compliance with all directives that are applicable to it.
airFiber AF-4X
CE marking on this product represents the product is in
compliance with all directives that are applicable to it.
airFiber AF-5X
CE marking on this product represents the product is in
compliance with all directives that are applicable to it.
Alert sign! follows CE marking
Alert sign must be indicated if a restriction on use applied
to the product and it must follow the CE marking.
airFiber AF-4X Compliance
The user is responsible for obtaining all licenses that are
required by the local country in which the product will
be operated, and all such licenses must be obtained prior
to operation in the particular country. For information on
licenses required by your country as well as conditions of
use for the 4 GHz band, contact your appropriate national
authority.
4.9 GHz Band Devices (FCC and Industry
Canada)
The 4.9 GHz band is a licensed band allocated to public
safety services. State and local government entities that
provide public safety services are eligible to apply for
4.9GHz licenses. For additional information, refer to FCC or
Industry Canada regulations.
63
Appendix F: Compliance InformationairFiber X User Guide
Ubiquiti Networks, Inc.
Frequency Ranges and Power Levels
per Country/Region
airFiber AF-2X
The product can be operated in the countries and regions
listed in the following table, within the stated frequency
ranges and output power (EIRP)limits.
Each country has its own power level and frequency
regulations. To ensure the product operates under the
necessary regulatory compliance rules, the country
where the device will be used must be selected during
installation. The frequency settings and output power
(EIRP) limits will be tuned according to the regulations of
the selected country/region:
Country/Region Frequency Range
(Band Edges in MHz) Max. EIRP (dBm)
Argentina 2400-2483 36
Australia 2400-2483 36
Bahrain 2400-2483 36
Brazil 2400-2483 36
Canada 2400-2483 36*
Chile 2400-2483 36
China 2400-2483 36
Colombia 2400-2483 36
Ecuador 2400-2483 36
Ghana 2400-2483 36
Guam
(U.S. territory) 2400-2483 36*
Hong Kong 2400-2483 36
Indonesia 2400-2483 36
India 2400-2483 36
Kenya 2400-2483 36
Korea Republic 2400-2483 36
Kyrgyzstan 2400-2483 Not applicable
Malaysia 2400-2483 36
Mexico 2400-2483 36
New Zealand 2400-2483 36
Nigeria 2400-2483 36
Peru 2400-2483 36
Philippines 2400-2483 36
Puerto Rico
(U.S. territory) 2400-2483 36*
Singapore 2400-2483 36
South Africa 2400-2483 36
Taiwan 2400-2483 36
Tajikistan 2400-2483 Not applicable
Thailand 2400-2483 20
Turkmenistan 2400-2483 Not applicable
Uganda 2400-2483 Not applicable
United States 2400-2483 36*
Uzbekistan 2400-2483 Not applicable
Venezuela 2400-2483 36
Virgin Islands
(U.S. territory) 2400-2483 36*
Vietnam 2400-2483 36
* A higher EIRP is possible based on FCC Part 15 requirements
of reduction of conducted power by 1dBm per 3dBi increase of
antenna gain beyond 6dBi.
64
Appendix F: Compliance Information airFiber X User Guide
Ubiquiti Networks, Inc.
airFiber AF-3X
The product can be operated in the countries and regions
listed in the following table, within the stated frequency
ranges and output power (EIRP)limits.
Each country has its own power level and frequency
regulations. To ensure the product operates under the
necessary regulatory compliance rules, the country
where the device will be used must be selected during
installation. The frequency settings and output power
(EIRP) limits will be tuned according to the regulations of
the selected country/region:
Country/Region Frequency Range
(Band Edges in MHz) Max. EIRP (dBm)
Austria 3410-3900 66
Belgium 3410-3900 66
Bulgaria 3410-3900 66
Canada 3450-3650
3650-3700
57
44
Croatia 3410-3900 66
Cyprus 3410-3900 66
Czech Republic 3410-3900 66
Denmark 3410-3900 66
Estonia 3410-3900 66
Finland 3410-3900 66
France 3410-3900 66
Germany 3410-3900 66
Greece 3410-3900 66
Guam
(U.S. territory) 3650-3700 44
Hungary 3410-3900 66
Ireland 3410-3900 66
Italy 3410-3900 66
Latvia 3410-3900 66
Lithuania 3410-3900 66
Malta 3410-3900 66
Netherlands 3410-3900 66
Poland 3410-3900 66
Portugal 3410-3900 66
Puerto Rico
(U.S. territory) 3650-3700 44
Romania 3410-3900 66
Slovakia 3410-3900 66
Spain 3410-3900 66
Sweden 3410-3900 66
United Kingdom 3410-3900 66
United States 3650-3700 44
Virgin Islands
(U.S. territory) 3650-3700 44
65
Appendix F: Compliance InformationairFiber X User Guide
Ubiquiti Networks, Inc.
airFiber AF-4X
The product can be operated in the countries and regions
listed in the following table, within the stated frequency
ranges and output power (EIRP)limits.
Users are responsible to comply with all local regulatory
rules and requirements beyond what is stated in the table.
Each country has its own power level and frequency
regulations. To ensure the product operates under the
necessary regulatory compliance rules, the country
where the device will be used must be selected during
installation. The frequency settings and output power
(EIRP) limits will be tuned according to the regulations of
the selected country/region:
Country/Region Frequency Range
(Band Edges in MHz) Max. EIRP (dBm)
Austria 3410-3900 55
Belgium 3410-3900 55
Bulgaria 3410-3900 55
Canada 4940-4990 55
Croatia 3410-3900 55
Cyprus 3410-3900 55
Czech Republic 3410-3900 55
Denmark 3410-3900 55
Estonia 3410-3900 55
Finland 3410-3900 55
France 3410-3900 55
Germany 3410-3900 55
Greece 3410-3900 55
Guam
(U.S. territory) 4940-4990 55
Hungary 3410-3900 55
Ireland 3410-3900 55
Italy 3410-3900 55
Latvia 3410-3900 55
Lithuania 3410-3900 55
Malta 3410-3900 55
Netherlands 3410-3900 55
Poland 3410-3900 55
Portugal 3410-3900 55
Puerto Rico
(U.S. territory) 4940-4990 55
Romania 3410-3900 55
Slovakia 3410-3900 55
Spain 3410-3900 55
Sweden 3410-3900 55
United Kingdom 3410-3900 55
United States 4940-4990 55
Virgin Islands
(U.S. territory) 4940-4990 55
airFiber X User GuideAppendix F: Compliance Information
Ubiquiti Networks, Inc.66
airFiber AF-5X
The product can be operated in the countries and regions listed in the following table, within the stated frequency ranges
and output power (EIRP)limits.
Each country has its own power level and frequency regulations. To ensure the product operates under the necessary
regulatory compliance rules, the country where the device will be used must be selected during installation. The frequency
settings and output power (EIRP) limits will be tuned according to the regulations of the selected country/region:
Country/Region
5.1 GHz 5.2 GHz 5.4 GHz 5.8 GHz
Frequency Range
(Band Edges in
MHz)
Max.
EIRP
(dBm)
Frequency Range
(Band Edges in
MHz)
Max.
EIRP
(dBm)
Frequency Range
(Band Edges in
MHz)
Max.
EIRP
(dBm)
Frequency Range
(Band Edges in
MHz)
Max.
EIRP
(dBm)
Argentina 5150-5250 49 5470-5725 30 5725-5850 36
Australia 5470-5600,
5650-5725 30 5725-5855 36
Bahrain 5735-5835 20
Barbados 5725-5850 36
Belize 5735-5835 30
Bolivia 5735-5835 30
Brazil 5470-5725 30 5725-5850 53
Brunei
Darussalam 5735-5835 20
Canada 5250-5350 30 5470-5600,
5650-5725 30 5725-5850 60
Chile 5250-5350 30 5735-5835 20
China 5735-5835 30
Colombia 5250-5350 30 5735-5835 30
Costa Rica 5735-5835 30
Denmark 5470-5725 30 5725-5795,
5815-5850 36
Dominican
Republic 5735-5835 30
Ecuador 5150-5250 49 5250-5350 30 5735-5835 30
El Salvador 5735-5835 30
Finland 5470-5725 30 5725-5795,
5815-5850 36
Germany 5470-5725 30 5755-5875 36
Greece 5470-5725 30 5725-5795 36
Grenada 5470-5725 30 5725-5850 36
Guatemala 5735-5835 30
Honduras 5470-5725 30 5725-5850 36
Hong Kong 5250-5350 30 5470-5725 30 5725-5850 36
Iceland 5470-5725 30 5725-5875 36
India 5825-5875 36
Iraq 5735-5835 36
Ireland 5470-5725 30 5725-5875 33
Italy 5470-5725 30
Jamaica 5470-5725 30 5725-5850 36
67
Appendix F: Compliance InformationairFiber X User Guide
Ubiquiti Networks, Inc.
Country/Region
5.1 GHz 5.2 GHz 5.4 GHz 5.8 GHz
Frequency Range
(Band Edges in
MHz)
Max.
EIRP
(dBm)
Frequency Range
(Band Edges in
MHz)
Max.
EIRP
(dBm)
Frequency Range
(Band Edges in
MHz)
Max.
EIRP
(dBm)
Frequency Range
(Band Edges in
MHz)
Max.
EIRP
(dBm)
Kenya 5250-5350 30 5735-5835 30
Korea Republic 5490-5710 30 5735-5815 30
Lebanon 5735-5835 30
Liechtenstein 5470-5725 30 5725-5795,
5815-5875 36
Macau 5725-5850 36
Malaysia 5150-5250 49 5250-5350 30 5735-5835 30
Mexico 5735-5835 30
Morocco 5735-5835 20
Nepal 5735-5835 30
New Zealand 5470-5725 30 5725-5850 53
Norway 5470-5725 30 5725-5795,
5815-5850 53
Oman 5470-5725 30 5725-5850 36
Pakistan 5735-5835 30
Panama 5735-5835 30
Papua New
Guinea 5735-5835 30
Peru 5150-5250 49 5250-5350 30 5470-5725 30 5725-5850 36
Philippines 5150-5250 49 5250-5350 30 5470-5725 30 5725-5850 36
Portugal 5470-5725 30 5725-5875 36
Puerto Rico
(U.S. territory) 5250-5350 30 5470-5600,
5650-5725 30 5725-5850 60
Qatar 5735-5835 30
Russia 5150-5350 43 5470-5650 23 5650-5950 53
Singapore 5735-5835 30
South Africa 5470-5725 30 5725-5850 60
Spain 5470-5725 30 5725-5795,
5815-5855 36
Switzerland 5470-5725 30 5725-5795,
5815-5855 36
Taiwan 5250-5350 30 5490-5710 30 5735-5815 30
Thailand 5250-5350 30 5470-5725 30 5725-5850 36
Trinidad And
Tobago 5470-5725 30 5725-5850 36
United
Kingdom 5470-5725 30 5725-5790,
5815-5850 36
United States 5150-5250 49 5250-5350 30 5470-5600,
5650-5725 30 5725-5850 60
Uruguay 5470-5725 30 5725-5850 36
Uzbekistan 5470-5725 30 5725-5850 36
Venezuela 5150-5250 49 5250-5350 30 5735-5835 30
68
Appendix F: Compliance Information airFiber X User Guide
Ubiquiti Networks, Inc.
The following table lists the maximum transmit output
power (EIRP) for the 5.1 GHz band.
5.1 GHz Band Maximum
Transmit Output
Power (EIRP)
in dBm
Channel Bandwidth Frequency Range
(Band Edges in MHz)
10 MHz
5155-5175 39
5166-5186 44
5177-5250 49
20 MHz
5156-5180 37
5161-5185 39
5166-5209 44
5190-5250 49
30 MHz
5155-5192 37
5163-5202 39
5173-5211 44
5182-5250 49
40 MHz
5155-5204 37
5165-5219 39
5180-5228 44
5189-5250 49
50 MHz
5155-5214 37
5165-5233 39
5184-5242 44
5193-5250 49
69
Appendix F: Compliance InformationairFiber X User Guide
Ubiquiti Networks, Inc.
RoHS/WEEE Compliance Statement
English
European Directive 2012/19/EU requires that the
equipment bearing this symbol on the product and/
or its packaging must not be disposed of with unsorted
municipal waste. The symbol indicates that this product
should be disposed of separately from regular household
waste streams. It is your responsibility to dispose
of this and other electric and electronic equipment
via designated collection facilities appointed by the
government or local authorities. Correct disposal
and recycling will help prevent potential negative
consequences to the environment and human health. For
more detailed information about the disposal of your old
equipment, please contact your local authorities, waste
disposal service, or the shop where you purchased the
product.
Deutsch
Die Europäische Richtlinie 2012/19/EU verlangt, dass
technische Ausrüstung, die direkt am Gerät und/oder an
der Verpackung mit diesem Symbol versehen ist , nicht
zusammen mit unsortiertem Gemeindeabfall entsorgt
werden darf. Das Symbol weist darauf hin, dass das
Produkt von regulärem Haushaltmüll getrennt entsorgt
werden sollte. Es liegt in Ihrer Verantwortung, dieses Gerät
und andere elektrische und elektronische Geräte über die
dafür zuständigen und von der Regierung oder örtlichen
Behörden dazu bestimmten Sammelstellen zu entsorgen.
Ordnungsgemäßes Entsorgen und Recyceln trägt dazu
bei, potentielle negative Folgen für Umwelt und die
menschliche Gesundheit zu vermeiden. Wenn Sie weitere
Informationen zur Entsorgung Ihrer Altgeräte benötigen,
wenden Sie sich bitte an die örtlichen Behörden oder
städtischen Entsorgungsdienste oder an den Händler, bei
dem Sie das Produkt erworben haben.
Español
La Directiva 2012/19/UE exige que los equipos que
lleven este símbolo en el propio aparato y/o en su
embalaje no deben eliminarse junto con otros residuos
urbanos no seleccionados. El símbolo indica que el
producto en cuestión debe separarse de los residuos
domésticos convencionales con vistas a su eliminación. Es
responsabilidad suya desechar este y cualesquiera otros
aparatos eléctricos y electrónicos a través de los puntos
de recogida que ponen a su disposición el gobierno y las
autoridades locales. Al desechar y reciclar correctamente
estos aparatos estará contribuyendo a evitar posibles
consecuencias negativas para el medio ambiente y la
salud de las personas. Si desea obtener información más
detallada sobre la eliminación segura de su aparato usado,
consulte a las autoridades locales, al servicio de recogida
y eliminación de residuos de su zona o pregunte en la
tienda donde adquirió el producto.
Français
La directive européenne 2012/19/UE exige que
l’équipement sur lequel est apposé ce symbole sur le
produit et/ou son emballage ne soit pas jeté avec les
autres ordures ménagères. Ce symbole indique que
le produit doit être éliminé dans un circuit distinct
de celui pour les déchets des ménages. Il est de votre
responsabilité de jeter ce matériel ainsi que tout autre
matériel électrique ou électronique par les moyens de
collecte indiqués par le gouvernement et les pouvoirs
publics des collectivités territoriales. L’élimination et le
recyclage en bonne et due forme ont pour but de lutter
contre l’impact néfaste potentiel de ce type de produits
sur l’environnement et la santé publique. Pour plus
d’informations sur le mode d’élimination de votre ancien
équipement, veuillez prendre contact avec les pouvoirs
publics locaux, le service de traitement des déchets, ou
l’endroit où vous avez acheté le produit.
Italiano
La direttiva europea 2012/19/UE richiede che le
apparecchiature contrassegnate con questo simbolo sul
prodotto e/o sull’imballaggio non siano smaltite insieme
ai rifiuti urbani non differenziati. Il simbolo indica che
questo prodotto non deve essere smaltito insieme ai
normali rifiuti domestici. È responsabilità del proprietario
smaltire sia questi prodotti sia le altre apparecchiature
elettriche ed elettroniche mediante le specifiche strutture
di raccolta indicate dal governo o dagli enti pubblici
locali. Il corretto smaltimento ed il riciclaggio aiuteranno
a prevenire conseguenze potenzialmente negative per
l’ambiente e per la salute dell’essere umano. Per ricevere
informazioni più dettagliate circa lo smaltimento delle
vecchie apparecchiature in Vostro possesso, Vi invitiamo
a contattare gli enti pubblici di competenza, il servizio di
smaltimento rifiuti o il negozio nel quale avete acquistato
il prodotto.
70
Appendix F: Compliance Information airFiber X User Guide
Ubiquiti Networks, Inc.
71
Appendix G: Declaration of ConformityairFiber X User Guide
Ubiquiti Networks, Inc.
Appendix G: Declaration of
Conformity
Česky
[Czech]
UBIQUITI NETWORKS tímto prohlašuje, že toto UBIQUITI
NETWORKS zařízení, je ve shod se základními požadavky a
dalšími příslušnými ustanoveními směrnice 1999/5/ES.
Dansk
[Danish]
Hermed, UBIQUITI NETWORKS, erklærer at denne UBIQUITI
NETWORKS enhed, er i overensstemmelse med de væsentlige
krav og øvrige relevante krav i direktiv 1999/5/EF.
Nederlands
[Dutch]
Hierbij verklaart UBIQUITI NETWORKS, dat deze UBIQUITI
NETWORKS apparaat, in overeenstemming is met de essentiële
eisen en de andere relevante bepalingen van richtlijn 1999/5/EC.
English
Hereby, UBIQUITI NETWORKS, declares that this UBIQUITI
NETWORKS device, is in compliance with the essential
requirements and other relevant provisions of Directive
1999/5/EC.
Eesti
[Estonian]
Käesolevaga UBIQUITI NETWORKS kinnitab, et antud UBIQUITI
NETWORKS seade, on vastavus olulistele nõuetele ja teistele
asjakohastele sätetele direktiivi 1999/5/EÜ.
Suomi
[Finnish]
Täten UBIQUITI NETWORKS vakuuttaa, että tämä UBIQUITI
NETWORKS laite, on yhdenmukainen olennaisten vaatimusten ja
muiden sitä koskevien direktiivin 1999/5/EY.
Français
[French]
Par la présente UBIQUITI NETWORKS déclare que l’appareil
UBIQUITI NETWORKS, est conforme aux exigences essentielles et
aux autres dispositions pertinentes de la directive 1999/5/CE.
Deutsch
[German]
Hiermit erklärt UBIQUITI NETWORKS, dass sich dieses UBIQUITI
NETWORKS Gerät, in Übereinstimmung mit den grundlegenden
Anforderungen und den anderen relevanten Vorschriften der
Richtlinie 1999/5/EG befindet.
Ελληνική
[Greek]
Δια του παρόντος, UBIQUITI NETWORKS, δηλώνει ότι αυτή η
συσκευή UBIQUITI NETWORKS, είναι σε συμμόρφωση με τις
βασικές απαιτήσεις και τις λοιπές σχετικές διατάξεις της οδηγίας
1995/5/ΕΚ.
Magyar
[Hungarian]
Ezennel UBIQUITI NETWORKS kijelenti, hogy ez a UBIQUITI
NETWORKS készülék megfelel az alapvető követelményeknek és
más vonatkozó 1999/5/EK irányelv rendelkezéseit.
Íslenska
[Icelandic]
Hér, UBIQUITI NETWORKS, því yfir að þetta UBIQUITI NETWORKS
tæki er í samræmi við grunnkröfur og önnur viðeigandi ákvæði
tilskipun 1999/5/EC.
Italiano
[Italian]
Con la presente, UBIQUITI NETWORKS, dichiara che questo
dispositivo UBIQUITI NETWORKS, è conforme ai requisiti
essenziali ed alle altre disposizioni pertinenti della direttiva
1999/5/CE.
Latviski
[Latvian]
Ar šo, UBIQUITI NETWORKS, deklarē, ka UBIQUITI NETWORKS
ierīce, ir saskaņā ar būtiskajām prasībām un citiem attiecīgiem
noteikumiem Direktīvā 1999/5/EK.
Lietuviškai
[Lithuanian]
UBIQUITI NETWORKS deklaruoja, kad šis UBIQUITI NETWORKS
įrenginys atitinka esminius reikalavimus ir kitas 1999/5/EB
Direktyvos nuostatas.
Malti
[Maltese]
Hawnhekk, UBIQUITI NETWORKS, tiddikjara li dan il-mezz
UBIQUITI NETWORKS huwa konformi mar-rekwiżiti essenzjali u
dispożizzjonijiet rilevanti oħrajn ta ‘Direttiva 1999/5/EC.
Norsk
[Norwegian]
Herved UBIQUITI NETWORKS, erklærer at denne UBIQUITI
NETWORKS enheten, er i samsvar med de grunnleggende
kravene og andre relevante bestemmelser i direktiv
1999/5/EF.
Slovensky
[Slovak]
Týmto
UBIQUITI NETWORKS
, prehlasuje, že toto
UBIQUITI
NETWORKS
zariadenie, je v súlade so základnými požiadavkami a
ďalšími relevantnými ustanoveniami smernice 1999/5/ES.
Svenska
[Swedish]
Härmed UBIQUITI NETWORKS, intygar att denna UBIQUITI
NETWORKS enhet är i överensstämmelse med de väsentliga
egenskapskrav och övriga relevanta bestämmelser som framgår
av direktiv 1999/5/EG.
Español
[Spanish]
Por medio de la presente UBIQUITI NETWORKS declara que este
dispositivo UBIQUITI NETWORKS, cumple con los requisitos
esenciales y cualesquiera otras disposiciones aplicables o
exigibles de la Directiva 1999/5/CE.
Polski
[Polish]
Niniejszym, Ubiquiti Networks, oświadcza, że urządzenie
UBIQUITI NETWORKS, jest zgodny z zasadniczymi wymaganiami
oraz pozostałymi stosownymi postanowieniami Dyrektywy
1999/5/EC.
Português
[Portuguese]
UBIQUITI NETWORKS declara que este dispositivo UBIQUITI
NETWORKS, está conforme com os requisitos essenciais e outras
disposições da Directiva 1999/5/CE.
Română
[Romanian]
Prin prezenta, UBIQUITI NETWORKS declară că acest dispozitiv
UBIQUITI NETWORKS este în conformitate cu cerințele esențiale
și alte prevederi relevante ale Directivei 1999/5/CE.
72
Appendix G: Declaration of Conformity airFiber X User Guide
Ubiquiti Networks, Inc.
73
Appendix H: Contact InformationairFiber X User Guide
Ubiquiti Networks, Inc.
Appendix H: Contact
Information
Ubiquiti Networks Support
Ubiquiti Support Engineers are located around the world
and are dedicated to helping customers resolve software,
hardware compatibility, or field issues as quickly as
possible. We strive to respond to support inquiries within
a 24-hour period.
Ubiquiti Networks, Inc.
2580 Orchard Parkway
San Jose, CA 95131
www.ubnt.com
Online Resources
Support: ubnt.link/airFiber-Support
Community: community.ubnt.com/airfiber
Downloads: downloads.ubnt.com/airfiber
AI040116
www.ubnt.com
©2016 Ubiquiti Networks, Inc. All rights reserved. Ubiquiti, Ubiquiti Networks, the Ubiquiti U logo, the Ubiquiti beam logo, airFiber, airOS, RocketDish,
TOUGHCable, and xRT are trademarks or registered trademarks of Ubiquiti Networks, Inc. in the United States and in other countries. All other trademarks are
the property of their respective owners.
