Contents
User Manual 2
16
Telephone operation
REMOVE
REMOVE
Options while on calls
Volume control
While on a call, press CID/-VOLUME to decrease
the volume, press DIR /VOLUME+ to increase
the volume.
When changing the volume level, the new setting
is saved.
Call waiting
If you subscribe to call waiting service with your
local telephone company, there will be a beep if
there is an incoming call while you are already on a
call. Press PHONE/FLASH to put your current call
on hold and take the new call. Press PHONE/FLASH
anytime to switch back and forth between calls. For
more information on caller ID, see page 26.
Mute
Press MUTE to silence the microphone. When mute
is on, MIC MUTED will show on the handset screen
temporarily. You will be able to hear the caller, but
the caller can not hear you until you press MUTE
again to resume your conversation. When the mute
function is turned off, MIC ON will show temporar-
ily on the handset screen.
Temporary tone dialing
If dial pulse (rotary) is selected, you can switch
to touch tone dialing during a call by pressing
*
.
This can be useful if it is necessary to send tone
signals for access to answering systems or long-
distance services.
After you hang up or press PHONE/FLASH (to
receive a call waiting call), the telephone auto-
matically returns to dial pulse (rotary) service.
Channel selection
During a call, if you hear clicks and pops, or if the
speech sometimes fades, press CHAN
/REMOVE
on
the handset to scan for a clearer radio channel
between cordless handset and base.
VOLUME
17
REMOVE
Directory
Memory capacity
The handset directory can store up to 30 entries
(including nine speed dial entries). Each entry can
contain a number up to 24 digits, and a name up
to 14 characters. A convenient search feature can
help you find and dial numbers quickly (page 21).
Timeouts and error messages
If you pause for too long while creating an entry,
the procedure will time out and you will have to
begin again.
If all memory locations are in use, the screen
will display MEMORY FULL. You will not be able
to store a new number until an existing one is
deleted.
PAT WILLIAMS
5551234
MEMORY FULL
18
Directory
Speed dial
You can enter nine speed dial numbers of up to 24
digits. Each number is stored in a speed dial location
(1-9).
The nine speed dial numbers on the handset will
be automatically added to the handset directory.
Press and hold a dial pad key (1-9) and then press
PHONE/FLASH
can easily dial these telephone
numbers. You can also make existing directory
entries into speed dial entries.
To enter a speed dial number
1. Press MENU/SELECT.
2. Press CID or DIR until the screen displays
SPEED DIAL.
3. Press MENU/SELECT.
4. Press a dial pad key (1-9) to select a speed dial
location.
5. Enter a name up to 14 characters (page 19), then
press MENU/SELECT.
6. Enter a telephone number up to 24 digits (page
21), then press MENU/SELECT.
7. Choose distinctive ringing (N or Y) by pressing
CID or DIR . If you choose yes (and if you
have caller ID service), a different ringing style
will alert you when this person calls.
8. Press MENU/SELECT to store the number. You'll
hear a confirmation tone.
To call a speed dial number
To use speed dialing, press and hold a dial pad key
(1-9) to display the number and name stored in that
speed dial location, then press
PHONE/FLASH
to
dial.
To edit or delete a speed dial number
Press and hold a dial pad key (1-9) to display the
entry you want. Press MENU/SELECT, then press
CID or DIR until the option you want is dis-
played (page 22).
NOTE: The speed dial
feature occupies up to nine of
the thirty memory locations in
the directory. For example, if
there are only five speed dial
entries, then up to 25 entries
can be stored in the directory.
If there are already 30 entries
in the directory, no new direc-
tory and speed dial entries
can be stored in memory until
some of the existing ones are
deleted.
1. MENU/SELECT
2. CID or DIR
3. MENU/SELECT
(Pages 19-20).
4.
NOTE: You can con-
vert any directory entry into
speed dial entry (page 22).
DIRECTORY
SPEED DIAL
ENTER 1-9
ENTER NAME
01
19
Directory
New directory entries
To enter a name
• Press MENU/SELECT twice.
• The screen will show ENTER NAME.
• Enter the name (up to 14 alphanumeric charac-
ters) of the person using the table below.
• Use DIR to advance to the next space to the
right, or use CID then
CHAN/REMOVE
to delete
a mistake.
• When finished entering the name, press
MENU/SELECT.
Each press of a particular key causes characters to
be displayed in the following order:
Options while entering names:
• Press DIR to move the cursor to the right.
Press DIR twice to enter a space.
• Press CID then
CHAN/REMOVE
to erase letter(s) if
you make mistake(s).
• Press # repeatedly to enter an ampersand (&),
apostrophe ('), comma (,) hyphen (-), period (.),
or pound sign (#).
• When finished, press MENU/SELECT.
3.
2. MENU/SELECT
NOTE: If all memory
locations are in use, an error
tone will sound when you
attempt to enter a number.
This means the memory is
full, and you will not be able
to store a new number until
you delete an existing one.
1. MENU/SELECT
DIRECTORY
ENTER NAME
PAT JOHNSON_
20
Directory
New directory entries
To enter a number
Use the dial pad keys to enter up to 24 digits. When
the number is complete, press MENU/SELECT.
Options while entering numbers:
• Press CID then
CHAN/DELETE
to erase digit(s) if
you make mistake(s).
• Press REDIAL/PAUSE to enter a four-second dialing
pause. A P will be inserted.
• When finished entering the telephone number,
press MENU/SELECT to confirm.
To assign a distinctive ring
Press CID or DIR to select Y (if you want to
assign a distinctive ring tone) or N (for a normal
ring pattern). If you choose yes (and if you have
caller ID service), a different ringing style will alert
you when this person calls.
Press MENU/SELECT to choose the desired option
and store this entry in the directory.
AD appears in the display of each entry that has
been assigned a distinctive ring.
4. MENU/SELECT
5.
6. MENU/SELECT
7. MENU/SELECT
ENTER NUMBER
PRT JOHNSON
5556789_
DISTINCT RING? N
5556789
21
Directory
Directory search
Follow the steps on the left to browse through the
directory or search to find a specific entry. You can
press OFF/CLEAR anytime to exit the directory.
To browse through the directory
To browse, press DIR then press CID or DIR
to scroll through all entries one by one.
AD appears in the display of each entry that has
been assigned a distinctive ring (page 20).
NOTE: When reviewing directory entries, all entries
(including those in the directory and in the speed dial) are dis-
played in alphabetical order. The entries in the speed dial are
identified by its speed dial number (01-09) in the lower right
corner of the screen.
To search alphabetically
To shorten your search, press DIR then use the
telephone dial pad keys to enter the first letter
of a name, then press DIR to scroll forward until
you find the desired name.
If you have more than one name entry that begin
with the same letter, it is necessary to scroll through
all the names beginning with that letter before see-
ing names that begin with the next letter.
Press dial pad keys once for the first letter, twice for
the second, three times for the third, as shown on
page 19.
For example, if you have name entries JENNIFER,
KEVIN and LINDA in your directory, pressing the
dial pad key 5(JKL) once will show JENNIFER,
twice KEVIN, three times LINDA.
NOTE: When searching alphabetically and you press a
dial pad button, if there are no entries beginning with the let-
ters on that button, the handset will show NO DATA.
1. DIR
2. DIR
DIR
To scroll name by
name
To display first entry
To search alpha-
betically
-OR-
DIRECTORY
ADAM
5551234
BETH
5554321
JOHN
5550123
22
Directory
To change or dial entries
When any entry is displayed, press MENU/SELECT
to see options. Press CID or DIR to highlight
the option you want (blinking text), then press
MENU/SELECT again to select it.
To edit an entry
When EDIT is blinking, press MENU/SELECT. You
can change the name and number (or distinctive
ring setting on the cordless handset) by following
the steps described on pages XX.
To delete an entry
Press CID or DIR until DEL is blinking, then
press MENU/SELECT to display a confirmation
screen of ERASE? N Y.
You can press CID or DIR to alternate between
N or Y to determine:
• When the Y blinking, press MENU/SELECT to
delete the entry.
• When the N blinking, press MENU/SELECT to
cancel the procedure.
To make an entry into a speed dial entry
Press CID or DIR until
SPEED
is blinking, press
MENU/SELECT
, then dial a memory location (1-9) to
transfer this entry to your speed dial directory.
NOTE: If you use a memory location that is already assigned
to a different entry in the directory, that entry will remain in the
directory, but will no longer be a speed dial number.
To dial a displayed number
When any directory entry is displayed, press
PHONE/FLASH
or to dial the displayed number.
1. DIR
2. DIR
3. MENU/SELECT
DIR
DIR
Press MENU/SELECT to
choose blinking option
DIRECTORY
ADRM
5551234
SPEED EDIT DEL
5551234
SPEED EDIT DEL
5551234
SPEED EDIT DEL
5551234
23
REMOVE
Caller ID summary
Information about caller ID with call waiting
This product has a caller ID function with call
waiting feature which works with service from
your local telephone company.
Caller ID with call waiting lets you see the name and
telephone number of the caller before answering
the telephone, even while on another call.
It may be necessary to change your telephone
service to use this feature. Contact your telephone
company if:
• You have both caller ID and call waiting, but
as separate services (you may need combined
service).
• You have only caller ID service, or only call
waiting service.
• You do not have any caller ID or call waiting
services.
This product can be used with regular caller ID
service, or this product’s other features can be used
without subscribing to either caller ID or combined
caller ID with call waiting service.
There are fees for caller ID services. In addition,
services may not be available in all areas.
Depending on your service, you may see the
caller’s number or the caller’s name and number.
This product can provide information only if both
you and the caller are in areas offering caller
ID service and if both telephone companies use
compatible equipment. The time and date are
sent by the telephone company along with the
call information.
CHRISTINE SMITH
10:08
AM
02/14
908-555-0100
24
Caller ID operation
REMOVE
Caller ID summary
How caller ID works
If you subscribe to caller ID service provided by
your local telephone company, information about
each caller will be displayed between the first and
second ring.
Information about the last 30 incoming calls is
stored in the call summary. You can review the call
summary to find out who has called, return the call,
or copy the caller’s name and number into direc-
tory.
When the call summary is full, the oldest entry is
deleted to make room for new incoming call infor-
mation.
If you answer a call before the information appears
on the screen, it will not be saved in the call sum-
mary.
About names
Names of callers will be displayed only if the infor-
mation is provided by your local telephone com-
pany.
If the incoming telephone number exactly matches
a telephone number in your directory, the name
that appears on the screen will match the corre-
sponding name in your directory.
For example: If Christine Smith calls, her name will
appear as CHRIS if this is how you entered it into
your directory.
CHRISTINE SMITH
10:08
AM
02/14
908-555-0100
Caller’s name
Caller’s phone
number
Time of call
Call number of
call summary
Appears when
the call is missed
and un-reviewed.
CHRISTINE SMITH
10:08
AM
02/14
908-555-0100
02
Date of call
NOTES:
1.
Caller ID features will work
only if both you and the
caller are in areas offering
caller ID service, and if both
telephone companies use
compatible equipment.
2. The number shown by your
caller ID will be in the for-
mat sent by the telephone
company. The telephone
company usually delivers
10-digit telephone numbers
(area code plus telephone
number). If the telephone
number of the person call-
ing does not exactly match a
number in your directory, the
name will appear as deliv-
ered by the telephone com-
pany. For example if the tele-
phone company includes the
area code and the directory
number does not, the name
will appear as delivered by
the telephone company.
25
Caller ID operation
REMOVE
Caller ID summary
There are also occasions when other information
or no information is displayed for various reasons:
On-screen message Reason
PRIVATE NAME Caller prefers to remain anony-
mous.
PRIVATE CALLER Caller name and telephone
number not revealed at caller's
request.
UNKNOWN NAME Your local telephone company is
unable to determine the caller's
name.
UNKNOWN CALLER Your local telephone company is
unable to determine the caller's
name and telephone number. Calls
from other countries may also
generate this message.
Missed calls
When the handset is in idle mode and have calls
that have not been reviewed, its screen will show
XX MISSED CALLS.
Any entries which have not been reviewed will be
counted as
MISSED CALLS
when the telephone is
idle. Each time a call summary entry marked
NEW
is
reviewed, the number of missed calls decreases by
one.
If there are too many missed calls and you don’t
want to review them one by one, but still want to
keep them in the call summary, press and hold
OFF/CLEAR for two seconds when the handset is
idle. All the entries in the caller ID summary will be
considered old (have been reviewed), and the missed
calls counter is reset to 0.
CHRISTINE SMITH
10:08
AM
02/14
908-555-0100
02 MISSED CALLS
10:08
AM
02/14
26
Caller ID operation
To review the call summary
The call summary displays the caller ID in reverse
chronological order, with the latest one (the one
with the highest number) first.
When the telephone is not in use, press CID to
display information about the most recent caller.
To review your call summary
Press CID to scroll backward (display older calls)
or DIR to scroll forward (display newer calls). The
highest call number is the most recent call received.
Each un-reviewed caller ID entry in the call summa-
ry will be designated NEW until you have reviewed
it. After all calls have been reviewed, the NEW will
be disappeared.
To return a call
Press
PHONE/FLASH
to call the number currently
displayed.
NOTE:If the number displayed is not in the
correct format, see Dialing options for detail.
Dialing options
Caller ID numbers may appear with an area code
that may not be required for local calls.
If the number displayed is not in the correct for-
mat, you can change how it is dialed. Press #
repeatedly to see dialing options. With each but-
ton press, a new option will be displayed. Press
PHONE/FLASH to dial when the number appears
in the proper format for your area.
The various dialing options are:
908-555-0100
1-908-555-0100
555-0100
1-555-0100
1. CID
2. CID
3.
PHONE/
FLASH
To dial this number
-OR-
PAT JOHNSON
10:08
AM
02/14
908-555-0100
CHRIS WILLIAMS
10:08
AM
02/14
908-555-1234
1.
2.
3.
4. #
PAT JOHNSON
PAT JOHNSON
PAT JOHNSON
PAT JOHNSON
10:08
AM
02/14
908-555-0100
03
10:08
AM
02/14
1-908-555-0100
03
10:08
AM
02/14
555-0100
03
10:08
AM
02/14
1-555-0100
03
#
#
CID
CID
PAT JOHNSON
10:08
AM
02/14
908-555-0100
03
02
03
PHONE ON 00:10
9085555678
27
Caller ID operation
Delete call summary entries
To delete a single call summary entry
Press CID to display the latest caller ID listing. Use
the CID or DIR keys to find the entry you want to
delete, then press CHAN/REMOVE. When the entry is
deleted, the next oldest record is displayed.
To delete all call summary entries
To clear your call summary completely, press and
hold CHAN/REMOVE while the telephone is idle (not
in use). This will display a confirmation screen ask-
ing if you want to erase all entries in the caller ID
summary. If you select yes, the call summary will be
cleared and the screen will return to normal standby
display, and the missed calls counter is reset to 0.
NOTE: When there are already 30 entries in the caller ID
memory, the next incoming call will automatically cause the old-
est entry to be deleted from the caller ID memory.
1. CID
2. CID
3. CHAN/REMOVE
-OR-
1.
2. DIR
3. MENU/SELECT
Call summary cleared
MARK CLAYTON
10:08
AM
02/14
908-555-5678
01
CHRIS WILLIAMS
10:08
AM
02/14
908-555-1234
02
PAT JOHNSON
10:08
AM
02/14
908-555-0100
03
27 MISSED CALLS
10:08
AM
02/14
ERASE ALL N Y
ERASE ALL N Y
10:08
AM
02/14
Press and hold
CHAN/REMOVE
28
Caller ID operation
2. MENU/SELECT then
CID or DIR
3. MENU/SELECT
6. MENU/SELECT
Add entries to the directory
When any caller ID is displayed, follow the steps on
left to enter it into your telephone directory.
Both the caller’s name and the telephone number
will be entered as they appear in the call sum-
mary. At steps 3-4, you can make any changes to
the name or number by pressing CHAN/REMOVE to
erase characters, then use the dial pad keys to
enter the correct information (see pages 19-20
for instructions).
When the number is stored, the screen returns to
the call summary display. The entry copied to your
telephone directory remains in the call summary
until deleted.
1. CID
Entry added to
phone directory
Edit name as desired
4. MENU/SELECT
Edit number as desired
5. MENU/SELECT
PAT JOHNSON
10:08
AM
02/14
908-555-0100
03
DIAL PROGRAM
10:08
AM
02/14
908-555-0100
03
PAT JOHNSON
10:08
AM
02/14
9085550100
03
PAT JOHNSON
10:08
AM
02/14
9085550100_
03
DISTINCT RING? N
10:08
AM
02/14
9085550100
03
PAT JOHNSON
10:08
AM
02/14
908-555-0100
03
29
Answering system operation
Message capacity
The answering system can record up to 95 mes-
sages depending on the length of each message.
Individual messages can be up to four minutes,
and total maximum recording time is 15 minutes.
Messages will remain available for replay until you
delete them.
Voice prompts
Each time you press any answering system key,
the answering system uses voice prompts to guide
you.
Message counter
Number of messages (or dur-
ing playback, message number
currently playing)
Press repeatedly to hear
setup options (page 32).
Press to review or set
clock (page 30).
Press to review or record
announcement; press
again to quit (page 31).
Press to turn answering
system on or off (page
36).
Press to delete mes-
sage currently play-
ing; press and hold to
delete all old messages
(page 33).
Press to record a memo
(page 34) or after press-
ing ANNC. to record an
outgoing announce-
ment (page 31).
Press to adjust play-
back volume (page
33).
Press to repeat message;
press twice to play previ-
ous message (page 33).
Press to skip a mes-
sage (page 33).
Press to start or stop
message playback
(page 33).
RECORD
ANNC.
30
Answering system operation
1. CLOCK.
The system will announce
the current clock setting,
then announces “To set the
clock, press CLOCK.”
3. SKIP or
REPEAT
until the system announces
the correct day, then press
CLOCK.
2. CLOCK.
The system will announce
the current day setting, then
announces “To change the day,
press SKIP or REPEAT ,
to change the hour, press
CLOCK.”
4.
until the system announces
the correct hour, then press
CLOCK.
until the system announc-
es the correct minute, then
press CLOCK.
5.
6.
until the system announc-
es the correct year, then
press CLOCK. The system
announces the current clock
setting.
SKIP or
REPEAT
SKIP or
REPEAT
SKIP or
REPEAT
Day & time announcements
To set day and time
Before playing each message, the answering sys-
tem announces the day and time when the mes-
sage was received.
Before using the answering system, follow the
steps on the left to set the day, time and year, so
that messages are dated correctly. If the clock is
not set, before new messages are recorded, the
system will announce "Time and day not set"
before each message is played back.
The system uses voice prompts to guide you. Each
time you press SKIP or REPEAT, the day, hour,
minute or year increases or decreases by one.
When you hear the correct setting, press CLOCK
to move to the next setting.
To check day and time
You can press CLOCK at any time to hear the cur-
rent day and time without changing it.
NOTES:
1. You can press and hold SKIP or REPEAT to increase or
decrease the minutes or years by ten.
2. Caller ID provides the time and date. Set the year so that
the day of the week can be calculated from the caller ID
information. After you set the time once, it will thereafter
be set automatically with incoming caller ID information.
The time will be set automatically only if you subscribe to
caller ID service provided by your local telephone company
(page 23).
RECORD
ANNC.
31
Answering system operation
RECORD
ANNC.
RECORD
ANNC.
Outgoing announcements
The outgoing announcement is the message callers
hear when calls are answered by the answering system.
The telephone is factory set with an announcement.
If the telephone is set up to record messages, it
answers calls with “Hello. Please leave a message
after the tone.” You can use this announcement, or
replace it with a recording of your own voice.
To play your outgoing announcement
Press ANNC., you will hear "Announcement. Press
PLAY or press RECORD." Then press PLAY/STOP.
You will hear the outgoing announcement. Press
ANNC. to exit the announcement menu.
To record your outgoing announcement
Press ANNC. , then you will hear "Announcement.
Press PLAY or press RECORD." Press RECORD
and begin speaking after hearing "Record after
the tone. Press STOP when you are done." Speak
facing the telephone base from about nine inches
away. Press PLAY/STOP when you are done.
Your recorded announcement will be played back.
Press ANNC. to exit the announcement menu.
Elapsed time (in seconds) will be shown in the
message window when recording. You can
record an announcement up to 90 seconds long.
Announcements shorter than two seconds long will
not be recorded.
To delete your outgoing announcement
Press ANNC. , then you will hear “Announcement. Press
PLAY or press RECORD.” Then press PLAY/STOP
to begin playback. Press DELETE during playback to
delete your announcement. Press ANNC. to exit the
announcement menu.
When your announcement is deleted, calls will be
answered with the the factory set announcement
described above.
1. ANNC.
“Announcement.
Press PLAY or press
RECORD.”
2.
(Plays announce-
ment previously
recorded).
-OR-
PLAY/STOP
Elapsed
recording
time (in
seconds).
Press to stop recording.
2. RECORD
“Record after the
tone. Press STOP
when you are
done.”
3.
4.
(Announcement
is played back).
Speak into microphone.
Microphone
PLAY/STOP
5. ANNC.
to exit announcement record-
ing.
1. ANNC.
“Announcement.
Press PLAY or press
RECORD.”
32
Answering system operation
1. SETUP
3. SETUP
-OR-
2. SKIP or
REPEAT
PLAY/STOP
Changing feature options
You can change the answering system operation.
Press SETUP repeatedly to hear each feature.
When you hear the feature you want to modify
press SKIP or REPEAT to change the setting.
Press PLAY/STOP to confirm the setting and
exit the menu.
Feature options (Default settings underlined)
System announces: Feature description:
"Number of rings," cur-
rent setting, then "To
change the setting press
SKIP or REPEAT; to con-
tinue setup, press SETUP."
Options: 2/4/6/toll saver
“Base ringer,” current set-
ting, then “To change the
setting, press SKIP or
REPEAT
; to continue setup,
press SETUP.”
Options: high/low/off
"Remote access code,"
current setting, then "To
change the setting press
SKIP or REPEAT; to con-
tinue setup, press SETUP."
Options: (select a two-
digit code) 19
"Message alert tone,"
current setting, then "To
change the setting, press
SKIP or REPEAT; to con-
tinue setup, press SETUP."
Options: on/off
Choose number of rings before
the system answers a call. When
toll saver is active, the system
answers after two rings if you
have new messages, and after
four rings if you have no new
messages. When retrieving mes-
sages from a long distance call,
you may disconnect your call
after three rings so that there
will be no long distance charge
incurred.
Choose the base ringer volume
between high and low level, or
turn the base ringer off.
Select a two-digit number (10-99)
for remote access from another
telephone (page 37).
When on, the telephone beeps
every 10 seconds when there are
new messages.
NOTE: Press and hold
SKIP
or
REPEAT
to increase or decrease
the remote access code number by
ten.
until desired feature
is heard (see list at
right).
until desired selection
is heard.
to set selection and
move to next menu
option.
to set selection and
exit menu.
NOTES:
1. The message alert tone will
beep only if all the conditions
below are met:
Answering system is on
Message alert tone setting
is on
Have new messages
2. Press any base key (except
HANDSET LOCATOR)
to
temporarily silence the mes-
sage alert tone. If you press
and hold DELETE you will
delete all old messages and
the message alert tone will
be temporarily silenced. The
message alert tone will be
re-activated with the next
incoming message.
RECORD
ANNC.
33
Answering system operation
RECORD
ANNC.
Message playback
Press PLAY/STOP to listen to messages. The
system announces the number of messages, then
begins playback.
If you have new messages waiting, you will hear
only the new messages (oldest first). If there are
no new messages, the system will playback all
messages (oldest first).
Announcements
• When playback begins, you will hear the total
number of messages.
• Before each message, you will hear the day and
time it was received.
• After the last message, you will hear “End of mes-
sages.” If the system has less than five minutes
of recording time left, you will hear the time
remaining.
Options during playback
• Press VOLUME button to adjust the speaker
volume.
• Press SKIP to skip to next message.
• Press REPEAT to repeat the message cur-
rently playing. Press twice to hear previous
message.
• Press DELETE to delete the message being
played back.
• Press PLAY/STOP to stop playback.
To delete all messages
To delete all old messages, press and hold DELETE
while the telephone is idle (not during a call, or
during message playback).
1.
“You have [xx] new
messages and [xx]
old messages”
Number of messages (or during
playback, message number cur-
rently playing).
Message playback begins.
See options at right.
2.
PLAY/STOP to begin
or end message playback.
PLAY/STOP
PLAY/STOP
to end message playback.
NOTES:
1. If F is flashing in the mes-
sage window, memory
is full. You will have to
delete some messages
before new ones can be
received.
2. The maximum record time
is 11 minutes.
3. If you receive calls when
the memory is full, the
telephone will ring 10
times, then answer and
announce “Memory is
full, enter remote access
code.”
4. New (unheard) messages
cannot be deleted.
34
Answering system operation
RECORD
ANNC.
RECORD
ANNC.
Recording & playing memos
Memos are messages you record yourself. They
are saved, played back and deleted exactly like
incoming messages. You can record a memo as
a reminder to yourself, or leave a message for
someone else if other members of your household
are using the answering system.
To record a memo
Press RECORD. Elapsed time (in seconds) is shown
in the message window as you record. You can
record a memo up to four minutes. Memos less
than one second will not be saved.
Press PLAY/STOP to stop recording.
To play back a memo
Press PLAY/STOP to hear messages and memos
(see page 33 for other options).
1. RECORD
“Record after the
tone. Press STOP
when you are done.”
3.
Elapsed
recording
time (sec-
onds).
Press to stop recording.
2.
PLAY/STOP
Microphone
“Recorded, beep,”
the memo has
been recorded.
Speak into microphone.
35
Answering system operation
RECORD
ANNC.
Message counter displays
The message counter usually displays the total
number of memos and incoming messages. See the
list below for explanations of other displays in this
counter.
Message counter displays
0 No messages.
0(flashing) The clock needs to be set (page 31).
1-95 Total number of messages and memos, or
message number currently playing.
1-95 (flashing) Total number of messages and memos.
The number flashes when there are new
(un-reviewed) messages.
If the telephone loses power, after power is
restored, the number in the message coun-
ter will flash to indicate the clock needs to
be set.
10-99 Current remote access code while setting
(page 32).
1-99 (counting) Elapsed time while recording a memo
(page 34) or announcement up to 90
seconds (page 31).
99 (flashing) Memo recording time has exceeded the
maximum counter capacity of 99 seconds.
F(flashing) Memory is full. Messages must be deleted
before new messages can be received.
-- System is answering a call, being accessed
remotely, or the clock is being set.
-- (flashing) System is being setup or initialized.
On (or) OF Displayed for one second when any answer-
ing system setting is turned on or off.
02, 04, 06, S Current number of rings while setting
(page 32).
1-8 Displayed for two seconds while telephone
base speaker volume is being adjusted.
35
HI, LO, OF Displayed for two seconds while telephone
base ringer volume is being adjusted.
36
Answering system operation
RECORD
ANNC.
ANSWER ON
until the system announces
“Calls will not be answered.”
"Beep"
The system has been
turned off.
1.
2.
Answering system mode
The answering system’s default factory setting is
ON in order to answer and record messages. You
can turn the answering system off, but if you do
so, the answering system will not answer calls or
record incoming messages.
To turn the answering system off
Press ANSWER ON until you hear “Calls will
not be answered” and a confirmation beep. The
ANSWER ON will be turned off.
NOTE: If the answering system is off and someone calls,
the telephone will ring 10 times then answer and announce
“Please enter your remote access code.” Enter your remote
access code to enter remote access mode (page 37). If you do
not enter the correct remote access code, the call will be
ended automatically.
To turn the answering system on
Press ANSWER ON until you hear “Calls will be
answered” then a beep to confirm the ON setting.
The ANSWER ON light will be turned on.
Call screening
If the answering system is on and the base volume
is not off, you will hear the announcement and the
incoming message when a call comes in.
Call intercept
While you are call screening, you can intercept the
call by pressing PHONE/FLASH on the handset.
-OR-
ANSWER ON
until the system announces
“Calls will be answered.”
"Beep"
The system has been turned
on.
2.
1.
37
Answering system operation
1.
Remote access
A two digit security code is required to access your
answering system from any touch-tone telephone.
This code is 19 by default, see Changing feature
options (page 32) to change it.
Dial your telephone number
from any touch-tone tel-
ephone.
2. When the system answers,
enter two digit remote
access code (19 unless
you have changed it).
3. Enter remote commands
(see list at right).
4. Hang up to end the call
and save all undeleted
messages.
NOTE: If you pause for
more than four seconds dur-
ing remote access, you will
hear a help menu listing all
features and commands. If
there is no command entered
for another 20 seconds, the
call will end automatically.
Play all messages
1
Play new messages
2
Delete the message
3
33
Repeat or go back
4
Stop
5
Skip to next message
6
Record announcement
*7 to begin recording
5to stop recording
Help menu
*5
Turn system off
0
Turn system on
0
Exit
8
Press to hear all messages.
Press to hear new messages.
Press once during playback to
delete current message. Press
twice to delete all old messages.
Press during the caller’s message
to repeat the message. Press dur-
ing the beginning of the day and
time announcement to go back to
the previous message.
Press to stop any operation (stop
playback, stop recording).
Press to skip the current message
and advance to next message.
Press * 7, wait for the beep, then
begin speaking. Press 5 to stop
recording and hear the playback
of new announcement.
Press to hear list of features &
commands.
Press to turn off answering sys-
tem. Incoming calls will no longer
be answered.
If off, system will answer after
10 rings. Enter your access code,
then press 0 to turn the answer-
ing system on.
Press 8 or hang up to end the
remote access call.
38
Appendix
RECORD
ANNC.
Screen icons, indicator lights & tones
Screen icons & alert tones
Screen icons
Battery charging (animated display).
Low battery (flashing); place handset in telephone base to
recharge.
Missed and un-reviewed calls.
Handset alert tones
Two short beeps
Double beep every
five seconds
Five beeps
Confirmation tone Command completed successfully.
Out of range when on the line.
Low battery warning.
The volume level is at the maximum or minimum setting.
Telephone base tones
One beep every
10 seconds
A series of beeps
Message alert.
Press VOL keys while the volume level is already at
the maximum or minimum
setting.
REMOVE
Ringer off.
Indicator lights
ANSWER ON
On when the answering
system is on and ready to
receive messages.
06 MISSED CALLS
10:08
AM
02/14
02
Microphone is muted.
IN USE
• On steady when the handset is in use.
• Flashes quickly while an incoming call
is ringing.
CHARGE
On when the cordless handset is properly
positioned to charge in the telephone base.
39
Appendix
Handset display screen messages
Screen display messages
REMOVE
CONNECTING . . .
CONNECTING... The cordless handset is waiting
for a dial tone.
NEEDS CHARGING Cordless handset battery is
depleted. Place the cordless
handset in the base to charge the
battery.
BATTERY LOW Cordless handset battery is low.
Place cordless handset in base
to charge the battery.
SCANNING... Cordless handset is scanning
for a clear channel to improve
sound quality.
** RINGING ** There is an incoming call.
** PAGING ** The cordless handset locator
has been activated (the cord-
less handset beep to help you
locate it).
XX MISSED CALLS There are missed and un-reviewed
calls in your call summary.
CAN'T CONNECT The handset cannot communicate
with the base.
MIC ON
MEMORY FULL
MIC MUTED
RINGER OFF
The call switches from normal call
to mute.
You are saving to a full directory.
The call switches from mute to
normal call.
The cordless handset ringer is
turned off.
PARALLEL SET ON Another telephone on the same
line is in use.
40
Appendix
Troubleshooting
If you have difficulty with your telephone, please try the suggestions below.
For Customer Service, visit our website at www.telephones.att.com or
call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.
My telephone
does not work
at all
• Make sure the battery is installed and charged correctly
(page 7). For optimum daily performance, return the cord-
less handset to the telephone base after use.
• Make sure the power adapter is securely plugged into an
outlet not connected to a wall switch.
• Make sure the telephone line cord is plugged firmly into
the telephone base and the modular wall jack.
• Unplug the telephone’s electrical power. Wait for approx-
imately 15 seconds, then plug it back in. Allow up to one
minute for the cordless handset and base to synchronize.
• Charge the battery in the cordless handset for at least
16 hours.
• Remove and re-insert the battery. If that still does not work,
it may be necessary to purchase a new battery.
• Disconnect the telephone base from the modular jack
and plug in a working telephone. If this telephone does
not work, the problem is probably in the wiring or the
local service. Call the local telephone company.
BATTERY LOW
is displayed on
screen
• Place the handset in the base for recharging.
• Remove and re-install the battery and use it normally
until fully discharged, then recharge the handset on the
telephone base for 16 hours.
• If the above measures do not correct the problem, the
battery may need to be replaced.
The battery does
not charge in the
handset or the
handset battery
does not accept
charge
• Make sure the handset is placed in the telephone base
correctly. The CHARGE light on the handset should be on.
• If the cordless handset is in the telephone base but the
CHARGE light is not on, refer to The CHARGE light is off
in this section.
• It may be necessary to purchase a new battery. Please refer
to the Batteries section of this user’s manual.
• The telephone might be malfunctioning. Please refer to
the Limited warranty section of this user’s manual for
further instruction.
41
Appendix
There is no dial
tone
• First, try all the above suggestions.
• Move the cordless handset closer to the telephone base.
It might be out of range.
• The telephone line cord might be malfunctioning. Try
installing a new telephone line cord.
• Disconnect the telephone base from the telephone jack
and connect a different telephone. If there is no dial tone
on the telephone either, the problem is in your wiring or
local service. Contact your local telephone company.
The telephone
does not ring
when there is
an incoming
call
• Make sure the ringer is on (pages 11-12).
• Make sure the telephone line cord and power adapter
are plugged in properly (page 6).
• The cordless handset may be too far from the telephone
base. Move it closer to the telephone base.
• There may be too many extension telephones on the tel-
ephone line to allow all of them to ring simultaneously.
Try unplugging some of them.
• If the other telephones in your home are having the same
problem, the problem is in the wiring or local service.
Contact the local telephone company (charges may apply).
• Other electronic products can cause interference to your
cordless telephone. Try installing your telephone as far
away as possible from the following electronic devices:
wireless routers, radios, radio towers, pager towers, cel-
lular telephones, digital telephones, intercoms, room
monitors, televisions, VCRs, personal computers, kitchen
appliances, and other cordless telephones.
Troubleshooting
The CHARGE
light is off
• Clean the metallic charging contacts on the cordless hand-
set and telephone base each month using a pencil eraser
or a dry non-abrasive fabric.
• Make sure the power adapter and telephone line cords are
plugged in correctly and securely.
• Unplug the power adapter. Wait for 15 seconds before
plugging it back in. Allow up to one minute for the cordless
handset and telephone base to reset.
• The telephone might be malfunctioning. Please refer to
the Limited warranty section of this user’s manual for
further instruction.
42
Appendix
Troubleshooting
There is noise or
interference dur-
ing a telephone
conversation
• The handset may be out of range. Move it closer to the
telephone base.
I cannot dial out • First, try all the above suggestions.
• Make sure there is a dial tone before dialing. It is nor-
mal if the cordless handset takes a second or two to
synchronize with the telephone before producing a dial
tone. Wait an extra second before dialing.
• Make sure the telephone is set to the correct dial mode
(pulse dial or tone dial) for the service in your area.
Refer to the Settings section of this user’s manual (page
11) to set the dial mode.
• If the other telephones in your home are having the
same problem, the problem is in the wiring or local
service. Contact your local telephone company (charg-
es may apply).
• Eliminate any background noise. Noise from a televi-
sion, radio, or other appliances may cause the telephone
to not dial out properly. If you cannot eliminate the
background noise, first try muting the cordless hand-
set before dialing, or dialing from another room in your
home with less background noise.
My phone rings
but when I try
to answer the
call the handset
screen shows
CONNECTING…
• The cordless handset may be too far from the telephone
base. Move closer to the telephone base and try to
answer the call.
• Test a working telephone at the same telephone jack. If
another telephone has the same problem, the problem is
in the telephone jack. Contact your local telephone com-
pany (charges may apply).
• The telephone line cord might be malfunctioning. Try
installing a new telephone line cord.
• Re-install the battery and place the cordless handset in
the telephone base.
• Wait for the cordless handset to synchronize with the
telephone base. Allow up to one minute for this to take
place.
43
Appendix
Troubleshooting
I hear other calls
when using the
telephone
• Disconnect the telephone base from the telephone jack.
Plug in a different telephone. If you still hear other calls,
the problem is probably in the wiring or local service.
Call your local telephone company.
• Appliances or other cordless telephones plugged into the
same circuit as the telephone base can cause interference.
Try moving the appliance or telephone base to another outlet.
• Other electronic products can cause interference to your
cordless telephone. Try installing your telephone as far
away as possible from the following electronic devices:
wireless routers, radios, radio towers, pager towers, cellular
telephones, digital telephones, intercoms, room monitors,
televisions, VCRs, personal computers, kitchen appliances,
and other cordless telephones.
• Microwave ovens operate on the same frequency as your
telephone. It is normal to experience static on your telephone
while the microwave oven is operating. Do not install this
telephone in the same outlet or near a microwave oven.
• If your telephone is plugged in with a modem or a surge
protector, plug the telephone (or modem/surge protec-
tor) into a different location. If this solves the problem, re-
locate your telephone or modem farther apart from each
other, or use a different surge protector.
• The layout of your home or office might be limiting the
operating range. Try moving the base to another location,
preferably a higher location for better reception.
• Disconnect the telephone base from the modular jack and
plug in a corded telephone. If calls are still not clear, the
problem is probably in the wiring or local service. Contact
your local service company (charges may apply).
• Select channels four through 10 for your router (refer to
the user’s manual of your router for more information).
• If the other telephones in your home are having the same
problem, the problem is in the wiring or local service.
Contact the local telephone company (charges may apply).
• Do you have DSL service? If yes, you need to have a
DSL filter installed at every telephone jack that has a
telephone connected to it. Contact your DSL service
provider for filter information.
My calls fade
out or cut in
and out when
I am using the
cordless hand-
set
“Time and day
not set” prompts
• You need to set the answering system clock (page 30).
44
Appendix
• If the telephone is not responding normally, try putting
the cordless handset in the telephone base. If it does not
seem to respond, try the following (in the order listed):
1. Disconnect the power to the telephone base.
2. Disconnect the battery on the cordless handset.
3. Wait a few minutes before connecting power to the
telephone base.
4. Re-install the battery and place the cordless handset
into the telephone base .
5. Wait for the cordless handset to synchronize its con-
nection with the telephone base. Allow up to one
minute for this to take place.
Common cure
for electronic
equipment
My caller ID
features are not
working properly
• Caller ID is a subscription service. You must subscribe to
this service from your local telephone company for this
feature to work on your telephone.
• The caller may not be calling from an area which supports
caller ID.
• Both you and the caller’s telephone companies must use
equipment which are compatible with caller ID service.
• If you subscribe to DSL service, install a DSL filter to
the telephone line between the telephone base and the
telephone line jack. Contact your DSL service provider
for filter information.
The system does
not receive caller
ID or the system
does not display
caller ID during
call waiting
• Make sure you subscribe to caller ID with call waiting fea-
tures services provided by the local telephone company.
• The caller may not be calling from an area which sup-
ports caller ID.
• Both you and the caller’s telephone companies must use
equipment which are compatible with caller ID service.
• If you subscribe to DSL service, install a DSL filter to
the telephone line between the telephone base and the
telephone line jack. Contact your DSL service provider
for filter information.
Troubleshooting
The announce-
ment message is
not clear
• When recording the announcement, make sure you
speak in a normal tone of voice about nine inches from
the telephone base.
• Make sure there is no background noise (television, music,
traffic, etc.) when recording.
45
Appendix
Troubleshooting
The answering
system does
not respond to
remote com-
mands
• Make sure your remote access code is correct (page 37).
• Make sure you are calling from a touch-tone telephone.
When dialing a number, you should hear tones. If you hear
clicks, then it is not a touch-tone telephone and cannot
activate the answering system.
• The answering system may not detect the remote access
code when your announcement is playing. Wait until the
announcement is over before entering the code.
• There may be interference on the telephone line you are
using. Press the dial pad keys firmly when dialing.
The answering
system does not
answer after the
correct number
of rings
• Make sure the answering system is on. When the answer-
ing system is on, the red light on the ANSWER ON key
should be lit.
• If toll saver is activated, the number of rings changes to
two when there are new messages waiting (page 32).
• If the memory is full or if the answering system is off, the
system will answer after ten rings. If the memory is full,
you need to delete some old messages in order to make
room for new messages.
• In some cases, the answering system may be affected by
the ringing system used by the local telephone company.
The answering
system does not
record message
• Make sure the answering system is on.
• If the memory is full the system will answer after ten rings
and announce “Memory full. Enter remote access code.”
You need to delete some old messages in order to make
room for new messages.
The messages
on the answer-
ing system are
incomplete
• If a caller reaches the maximum recording time of four
minutes, for each message, the system will disconnect and
part of the message may be lost.
• If the caller pauses for more than seven seconds, the sys-
tem stops recording and disconnects the call.
• If the memory on the system becomes full during a mes-
sage, the system stops recording and disconnects the call.
• If the caller’s voice is very soft, the system may stop
recording and disconnect the call.
The messages
on the system
are very difficult
to hear
• Press VOL on the telephone base to increase the speaker
volume.
46
Appendix
Important safety instructions
This symbol is to alert you to important operating or servicing instructions
that may appear in this user’s manual. Always follow basic safety precautions
when using this product to reduce the risk of injury, fire, or electric shock.
Safety information
•Read and understand all instructions in the user’s manual. Observe all
markings on the product.
•Avoid using a telephone during a thunderstorm. There may be a slight
chance of electric shock from lightning.
•Do not use a telephone in the vicinity of a gas leak. If you suspect a gas
leak, report it immediately, but use a telephone away from the area where
gas is leaking. If this product is a cordless model, make sure the base is
also away from the area.
•Do not use this product near water, or when you are wet. For example,
do not use it in a wet basement or shower, or next to a swimming pool,
bathtub, kitchen sink, or laundry tub. Do not use liquids or aerosol sprays
for cleaning. If the product comes in contact with any liquids, unplug any
line or power cord immediately. Do not plug the product back in until it has
dried thoroughly.
•Install this product in a protected location where no one can trip over
any line or power cords. Protect cords from damage or abrasion.
•If this product does not operate normally, read Troubleshooting in this
user’s manual. If you cannot solve the problem, or if the product is dam-
aged, refer to the limited warranty. Do not open this product except as may
be directed in your user’s manual. Opening the product or reassembling it
incorrectly may expose you to hazardous voltages or other risks.
•If this product has user-replaceable batteries, replace batteries only
as described in your user’s manual. Do not burn or puncture batteries
— they contain caustic chemicals.
•If this product has a three-prong (grounding) plug or a polarized plug
with one wide prong, it may not fit in non-polarized outlets. Do not defeat
the purpose of these plugs. If they do not fit in your outlet, the outlet
should be replaced by an electrician.
CAUTION: Use only the power adapter provided with this product. To
obtain a replacement, visit our website at www.telephones.att.com or
call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.
47
Appendix
Important safety instructions
Especially About Cordless Telephones
•Privacy: The same features that make a cordless telephone conve-
nient create some limitations. Telephone calls are transmitted between
the telephone base and handset by radio waves, so there is a possibil-
ity that your cordless telephone conversations could be intercepted by
radio receiving equipment within range of the cordless handset. For this
reason, you should not think of cordless telephone conversations as
being as private as those on corded telephones.
•Electrical power: The telephone base of this cordless telephone must be
connected to a working electrical outlet. The electrical outlet should not be
controlled by a wall switch. Calls cannot be made from the handset if the
telephone base is unplugged or switched off, or if the electrical power
is interrupted.
•Power adapter: This power adapter is intended to be plugged into a vertical
wall outlet or a floor outlet.
•Potential TV interference: Some cordless telephones operate at frequencies
that may cause interference to TVs and VCRs. To minimize or prevent such inter-
ference, do not place the telephone base of the cordless telephone near or on
top of a TV or VCR. If interference is experienced, moving the cordless telephone
farther away from the TV or VCR will often reduce or eliminate the interference.
•Rechargeable batteries: This product contains either Nickel-Cadmium or
Nickel-Metal Hydride rechargeable batteries. Exercise care in handling batter-
ies in order not to short the battery with conducting material such as rings,
bracelets, and keys. The battery or conductor may overheat and cause harm.
Observe proper polarity between the battery and the battery charger.
•Nickel-cadmium rechargeable batteries: Must be recycled or disposed of
properly. Do not dispose of in household garbage. Do not burn or puncture.
Like other batteries of this type, if burned or punctured, they could release
caustic material which could cause injury.
The RBRC™ Seal means that the manufacturer is voluntarily participating in an
industry program to collect and recycle nickel-cadmium rechargeable batteries when
taken out of service within the United States. These batteries may be taken to a participating
local retailer of replacement batteries or recycling center. Or you may call 1 (800) 8 BATTERY for
locations accepting spent nickel-cadmium Batteries.
48
Appendix
Important safety instructions
•Nickel-metal hydride rechargeable batteries: Dispose of these batteries
in a safe manner. Do not burn or puncture. Like other batteries of this type,
if burned or punctured, they could release caustic material which could
cause injury.
The RBRC™ Seal means that the manufacturer is voluntarily participating in an
industry program to collect and recycle nickel-metal rechargeable batteries when taken out of
service within the United States. These batteries may be taken to a participating local retailer of
replacement batteries or recycling center. Or you may call 1 (800) 8 BATTERY for locations
accepting spent nickel-metal Batteries.
Precautions for users of implanted cardiac pacemakers
Cardiac pacemakers (applies only to digital cordless telephones):
Wireless Technology Research, LLC (WTR), an independent research entity, led
a multidisciplinary evaluation of the interference between portable wireless
telephones and implanted cardiac pacemakers. Supported by the U.S. Food
and Drug Administration, WTR had recommended to physicians that:
Pacemaker patients
• Should keep wireless telephones at least six inches from the pacemaker.
• Should NOT place wireless telephones directly over the pacemaker, such
as in a breast pocket, when it is turned ON.
• Should use the wireless telephone at the ear opposite the pacemaker.
WTR’s evaluation did not identify any risk to bystanders with pacemakers from
other persons using wireless telephones.
Especially about telephones answering systems
Two-way recording: This telephone does not sound warning beeps to let
the other party know that the call is being recorded. To ensure that you
are in compliance with any federal or state regulations regarding recording
a telephone call, you should start the recording process and then inform
the other party that you are recording the call.
SAVE THESE INSTRUCTIONS
49
Appendix
FCC Part 68 & ACTA
This equipment complies with Part 68 of the FCC rules and with tech-
nical requirements adopted by the Administrative Council for Terminal
Attachments (ACTA). The label on the back or bottom of this equip-
ment contains, among other things, a product identifier in the format US:
AAAEQ##TXXXX. This identifier must be provided to your local telephone
company upon request.
The plug and jack used to connect this equipment to premises wiring and
the telephone network must comply with applicable Part 68 rules and
technical requirements adopted by ACTA. A compliant telephone cord and
modular plug is provided with this product. It is designed to be connected
to a compatible modular jack that is also compliant. An RJ11 jack should
normally be used for connecting to a single line and an RJ14 jack for two
lines. See Installation Instructions in the user’s manual.
The Ringer Equivalence Number (REN) is used to determine how many
devices you may connect to your telephone line and still have them ring
when you are called. The REN for this product is encoded as the 6th and
7th characters following the US: in the product identifier (e.g., if ## is 03,
the REN is 0.3). In most, but not all areas, the sum of all RENs should be
five (5.0) or less. For more information, please contact your local telephone
company.
This equipment may not be used with Party Lines. If you have specially
wired alarm dialing equipment connected to your telephone line, ensure
the connection of this equipment does not disable your alarm equipment.
If you have questions about what will disable alarm equipment, consult
your telephone company or a qualified installer.
If this equipment is malfunctioning, it must be unplugged from the modu-
lar jack until the problem has been corrected. Repairs to this telephone
equipment can only be made by the manufacturer or its authorized agents.
For repair procedures, follow the instructions outlined under the Limited
Warranty.
If this equipment is causing harm to the telephone network, the telephone
company may temporarily discontinue your telephone service. The tel-
ephone company is required to notify you before interrupting service. If
advance notice is not practical, you will be notified as soon as possible.
You will be given the opportunity to correct the problem and the tel-
ephone company is required to inform you of your right to file a complaint
with the FCC. Your telephone company may make changes in its facilities,
equipment, operation, or procedures that could affect the proper function-
ing of this product. The telephone company is required to notify you if
such changes are planned.
50
Appendix
FCC Part 68 & ACTA
If this product is equipped with a corded or cordless handset, it is hearing
aid compatible.
If this product has memory dialing locations, you may choose to store
emergency telephone numbers (e.g., police, fire, medical) in these loca-
tions. If you do store or test emergency numbers, please:
Remain on the line and briefly explain the reason for the call before hang-
ing up.
Perform such activities in off-peak hours, such as early morning or late
evening.
Industry Canada
Operation is subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any interfer-
ence, including interference that may cause undesired operation.
The term ‘’IC: ‘’ before the certification/registration number only signifies
that the Industry Canada technical specifications were met.
The Ringer Equivalence Number (REN) for this terminal equipment is 0.1.
The REN is an indication of the maximum number of devices allowed to
be connected to a telephone interface. The termination on an interface
may consist of any combination of devices subject only to the require-
ment that the sum of the RENs of all the devices does not exceed five.
This product meets the applicable Industry Canada technical specifications.
51
Appendix
FCC Part 15
This equipment has been tested and found to comply with the requirements
for a Class B digital device under Part 15 of the Federal Communications
Commission (FCC) rules. These requirements are intended to provide reason-
able protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harm-
ful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications to this equipment not expressly approved by the
party responsible for compliance could void the user’s authority to operate
the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful interfer-
ence, and (2) this device must accept any interference received, including
interference that may cause undesired operation. Privacy of communications
may not be ensured when using this telephone.
To ensure safety of users, the FCC has established criteria for the amount of
radio frequency energy that can be safely absorbed by a user or bystander
according to the intended usage of the product. This product has been tested
and found to comply with the FCC criteria. The handset may be safely held
against the ear of the user. The telephone base shall be installed and used
such that parts of the user’s body other than the hands are maintained at a
distance of approximately 20 cm (8 inches) or more. If you choose to use a
clipping device, please make sure to only use the supplied AT&T belt clip.
This Class B digital apparatus complies with Canadian ICES-003.
52
Appendix
Limited warranty
The AT&T brand is used under license - any repair, replacement or warranty
service, and all questions about this product should be directed to: In the United
States of America visit our website at www.telephones.att.com or
call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.
1. What does this limited warranty cover?
The manufacturer of this AT&T-branded product warrants to the holder of
a valid proof of purchase (“CONSUMER” or “you”) that the product and all
accessories provided in the sales package (“PRODUCT”) are free from defects
in material and workmanship, pursuant to the following terms and conditions,
when installed and used normally and in accordance with the PRODUCT oper-
ating instructions. This limited warranty extends only to the CONSUMER for
products purchased and used in the United States of America and Canada.
2. What will be done if the PRODUCT is not free from defects in materials
and workmanship during the limited warranty period (“materially defective
PRODUCT”)?
During the limited warranty period, the manufacturer’s authorized service
representative will repair or replace at the manufacturer’s option, without
charge, a materially defective PRODUCT. If the manufacturer repairs the
PRODUCT, they may use new or refurbished replacement parts. If the man-
ufacturer chooses to replace the PRODUCT, they may replace it with a new
or refurbished PRODUCT of the same or similar design. The manufacturer
will retain defective parts, modules, or equipment. Repair or replacement of
the PRODUCT, at the manufacturer’s option, is your exclusive remedy. The
manufacturer will return repaired or replacement products to you in work-
ing condition. You should expect the repair or replacement to take approxi-
mately 30 days.
3. How long is the limited warranty period?
The limited warranty period for the PRODUCT extends for ONE (1) YEAR
from the date of purchase. If the manufacturer repairs or replaces a materi-
ally defective PRODUCT under the terms of this limited warranty, this limit-
ed warranty also applies to repaired or replacement PRODUCT for a period
of either (a) 90 days from the date the repaired or replacement PRODUCT
is shipped to you or (b) the time remaining on the original one-year limited
warranty; whichever is longer.
53
Appendix
Limited warranty
4. What is not covered by this limited warranty?
This limited warranty does not cover:
• PRODUCT that has been subjected to misuse, accident, shipping or other
physical damage, improper installation, abnormal operation or handling,
neglect, inundation, fire, water, or other liquid intrusion; or
• PRODUCT that has been damaged due to repair, alteration, or modifica-
tion by anyone other than an authorized service representative of the
manufacturer; or
• PRODUCT to the extent that the problem experienced is caused by signal
conditions, network reliability or cable or antenna systems; or
• PRODUCT to the extent that the problem is caused by use with non-AT&T
accessories; or
• PRODUCT whose warranty/quality stickers, PRODUCT serial number
plates or electronic serial numbers have been removed, altered or ren-
dered illegible; or
• PRODUCT purchased, used, serviced, or shipped for repair from outside the
United States of America or Canada, or used for commercial or institutional
purposes (including but not limited to products used for rental purposes); or
• PRODUCT returned without valid proof of purchase (see item 6 below); or
• Charges for installation or setup, adjustment of customer controls, and
installation or repair of systems outside the telephone.
5. How do you get warranty service?
To obtain warranty service in the United States of America, call
1 (800) 222-3111; In Canada, please dial 1 (866) 288-4268. NOTE:
Before calling for service, please review the user’s manual - a check of the
PRODUCT controls and features may save you a service call.
Except as provided by applicable law, you assume the risk of loss or damage
during transit and transportation and are responsible for delivery or handling
charges incurred in the transport of the PRODUCT(s) to the service location.
The manufacturer will return repaired or replaced PRODUCT under this limited
warranty to you, transportation, delivery or handling charges prepaid. The
manufacturer assumes no risk for damage or loss of the PRODUCT in transit.
If the PRODUCT failure is not covered by this limited warranty, or proof of pur-
chase does not meet the terms of this limited warranty, the manufacturer will
notify you and will request that you authorize the cost of repair prior to any
further repair activity. You must pay for the cost of repair and return shipping
costs for the repair of products that are not covered by this limited warranty.
54
Appendix
Limited warranty
6. What must you return with the PRODUCT to get warranty service?
You must:
a. Return the entire original package and contents including the PRODUCT
to the service location along with a description of the malfunction or dif-
ficulty; and
b. Include “valid proof of purchase” (sales receipt) identifying the PRODUCT
purchased (PRODUCT model) and the date of purchase or receipt; and
c. Provide your name, complete and correct mailing address, and telephone
number.
7. Other limitations
This warranty is the complete and exclusive agreement between you and the
manufacturer of this AT&T branded PRODUCT. It supersedes all other written
or oral communications related to this PRODUCT. The manufacturer provides
no other warranties for this PRODUCT. The warranty exclusively describes all
of the manufacturer’s responsibilities regarding the PRODUCT. There are no
other express warranties. No one is authorized to make modifications to this
limited warranty and you should not rely on any such modification.
State/Provincial Law Rights: This warranty gives you specific legal rights,
and you may also have other rights which vary from state to state or prov-
ince to province.
Limitations: Implied warranties, including those of fitness for a particular
purpose and merchantability (an unwritten warranty that the PRODUCT is
fit for ordinary use) are limited to one year from date of purchase. Some
states/provinces do not allow limitations on how long an implied warranty
lasts, so the above limitation may not apply to you. In no event shall the
manufacturer be liable for any indirect, special, incidental, consequential, or
similar damages (including, but not limited to lost profits or revenue, inabil-
ity to use the PRODUCT or other associated equipment, the cost of substi-
tute equipment, and claims by third parties) resulting from the use of this
PRODUCT. Some states/provinces do not allow the exclusion or limitation
of incidental or consequential damages, so the above limitation or exclu-
sion may not apply to you.
Please retain your original sales receipt as
proof of purchase.
55
Appendix
Technical specifications
RF frequency band
(handset to telephone base)
5857.2 MHz — 5865.9 MHz
RF frequency band
(telephone base to handset)
912.75 MHė — 917.10 MHz
Channels 30
Operating temperature 32°F — 122°F
0°C — 50°C
Telephone base voltage
(AC voltage, 60Hz)
104 — 129Vrms
Telephone base voltage
(AC adapter output)
DC7.5V @250mA
Handset voltage DC3.1 — 4.3V 400mAh
Rechargeable battery 3.6V 400mAh
Modulation FM
Telephone operating range
This cordless telephone operates with the maximum power allowed by the
Federal Communications Commission (FCC). Even so, the handset and tele-
phone base can communicate over only a certain distance - which can vary
with the locations of the telephone base and handset, the weather, the layout,
and the construction of your home or office.
56
Appendix
A
Alert tones, 38
Answering calls, 13
Answering system, 29-37
B
Battery charging, 7
Battery installation, 7
Battery low, 7
Belt clip, 10
C
Call waiting, 16
Caller ID, 23
add entries to the directory, 28
delete entries, 27
dial entries, 26
Channel, 16
Call screening,36
Call intercept, 36
D
Delete call summary entries, 27
Delete redial entries, 14
Dialing,
directory dialing, 22
from a CID record, 26
mode, 11
Directory, 17
dial number, 22
edit entries, 22
make an entry, 22
search, 21
DSL filter, 6
E
Elapsed time, 13
F
Flash (switchhook flash), 16
H
Hands-free use, 13
Handset locator, 15
Headset, 10
I
Incoming call summary, 24
Incoming calls, answering, 13
Indicator lights, 38
L
Last number redial, 14
M
Making calls, 13
Menus, 2
Message playback, 33
Missed calls, 25
Mute, 16
N
Names,
search for, 21
P
Power adapter, 6
Q
Quick reference guide, 2-3
R
Receiving calls, 13
Recharging, 7
Redial, 14
Ring silencing, 14
Ringer sound, 12
Ringer volume, 11
S
Screen display messages, 39
Search for names, 21
Speakerphone, 13
T
Technical specifications, 55
Temporary tone dialing, 16
Troubleshooting, 40
V
Volume control, 16
Voice prompts, 29
Index
Appendix
Remote access wallet card
Use the wallet card below to help you remember commands to control your
answering system from any touch tone telephone.
Fold here.
Cut along dotted line.
Action Remote command
Play all messages ..................1
Play new messages...............2
Delete the message..............3
Delete all old messages .....33
Repeat or go back.................4
Stop...............................................5
Help menu .................................*5
Skip the message...................6
Record announcement ........*7
Turn system off or on ..........0
End remote access call ......8(or hang up)
Call your phone number, then
enter your two-digit access code
(preset to 19).
EL42108
5.8 GHz cordless telephone/answering system
© 2007 Advanced American Telephones. All rights reserved.
AT&T and the AT&T logo are trademarks of AT&T Knowledge Ventures,
licensed to Advanced American Telephones. Printed in China.
www.telephones.att.com
© 2007 Advanced American Telephones. All rights reserved.
AT&T and the AT&T logo are trademarks of AT&T Knowledge Ventures,
licensed to Advanced American Telephones. Printed in China. Issue 1 AT&T 09/07.
91-001523-010-100
