c 2005 VeriFone, Inc. All rights reserved.
2099 Gateway Place, Suite 600
San Jose CA 95110
Tel: 800 VeriFone (837-4366)
www.verifone.com
M
x
870 Certifications and Regulations
VeriFone Part Number: 23750 Revision 01
*23750*
Electrical
Optional Power Pack
Before you connect the optional power pack to an electrical outlet, check that the cable is disconnected from the Mx870.
or
When connecting the Mx870 to the optional power pack, always connect the plug of the power pack to an electrical wall outlet first.
Then connect the cable to the Mx870.
The power pack is rated as follows:
Input Voltage: 120 V AC, 60 Hz
Output Voltage: 24 V DC, 1 A
AC Adapter
The optional AC adapter is designed to ensure your personal safety and to be compatible with this equipment. Please follow these
guidelines:
• Do not use the adapter in a high moisture environment. Never touch the adapter when your hands or feet are wet.
• Allow adequate ventilation around the adapter. Avoid locations with restricted airflow.
• Connect the adapter to a proper power source. The voltage and grounding requirements are found on the product case and/or
packaging.
• Do not use the adapter if the cord becomes damaged.
• Do not attempt to service the adapter. There are no serviceable parts inside. Replace the unit if it is damaged or exposed to
excess moisture.
Separate Power Sources
Some peripherals require a separate power source. Before connecting a check reader or similar device, remove the power cable
connector from the terminal’s power port.
Peripherals
Before connecting any peripheral device, turn off power to the terminal and check that the power cable connector is removed from
the terminal’s power port. Turn on power only after you are finished connecting the peripheral device(s). For complete information
about peripheral installation and use, please refer to the user documentation supplied with those devices.
Disconnecting Power
Disconnecting cable and/or power during a transaction may cause transaction data files to be lost.
Location – Electrical Considerations
CAUTION: Due to risk of electrical shock or Mx870 damage, do not use the Mx870 near water, including a bathtub, wash bowl,
kitchen sink or laundry tub, in a wet basement, or near a swimming pool. Also, avoid using this product during electrical storms.
Avoid locations near electrical appliances or other devices that cause excessive voltage fluctuations or emit electrical noise (for
example, air conditioners, neon signs, high-frequency or magnetic security devices, or electric motors).
Equipment
Repairs
Do not, under any circumstances, attempt any service, adjustments, or repairs on this equipment. Instead, contact your local
VeriFone distributor or service provider for assistance. Failure to comply may void the product warranty.
Location – Environmental Considerations
Do not plug the optional power pack into an outdoor outlet or operate the Mx870 outdoors. It is not waterproof or dustproof, and is
for indoor use only. Any damage to the unit from exposure to rain or dust may void your warranty.
Do not use the Mx870 where there is high heat, dust, humidity, moisture, or caustic chemicals or oils. Keep the Mx870 away from
direct sunlight and anything that radiates heat, such as a stove or a motor.
M
x
870 Certifications and Regulations
FCC Compliance
The following product has been tested and certified as compliant with the regulations and guidelines detailed below:
Manufacturer: VeriFone, Inc.
Brand, Model: Mx870
Part 15 of FCC Rules
This equipment complies with the limits for a Class B digital device as specified in Part 15 of FCC Rules which provide reasonable
protection against harmful interference in a residential area.
This equipment generates and uses radio frequency energy, and if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation.
In the unlikely event that there is interference to radio or television reception (which can be determined by turning the equipment off
and on), the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult with the dealer or ask an experienced radio/TV technician for help.
Any changes or modifications to this equipment not expressly approved by VeriFone could void the user’s authority to operate this
equipment.
continued on rear cover
