Visteon TX9 Transmitter for Remote Keyless Entry System User Manual
Visteon Corporation Transmitter for Remote Keyless Entry System
Visteon >
User Manual
USING THE REMOTE
CONTROL
Remote control
WARNING
Never leave the remote control
in the vehicle if children or
animals are also left in the vehicle.
The vehicle's systems and remote
control functions could be operated,
which may result in injury.
Note:
The operational range of the
remote control will vary considerably
depending on atmospheric
conditions and interference from
other transmitting devices.
The vehicle is supplied with two
remote controls, but up to six can be
programmed to the vehicle at any
one time.
1. Unlock.
2. Lock.
3. Tailgate release.
4. Approach lighting.
5. Emergency alarm.
6. Key blade release tab.
7. Key blade.
FCC and Canadian warning
statement
This device complies with part 15 of
the FCC rules.
Operation is subject to the following
two conditions:
1. This device may not cause
harmful interference, and
2. this device must accept any
interference received, including
interference that may cause
undesired operation.
Any changes or modifications not
expressly approved by the party
responsible for compliance could
void the user’s authority to operate
the equipment.
This device complies with RSS-210
of Industry Canada.
Operation is subject to the following
two conditions:
1. This device may not cause
harmful interference, and
2. this device must accept any
interference, including
interference that may cause
undesired operation of the device.
Transmitter FCC ID: NT8-TX9
IC : 3043A-TX9
1
Using the remote control
Unlocking
Press briefly to unlock the
vehicle, and deactivate the
alarm. The hazard warning
lamps will flash twice to indicate that
the vehicle is unlocked and the alarm
has been deactivated. The interior
lamps will illuminate to assist entry to
the vehicle.
Single/Multi-point entry
When you press the unlock button
your vehicle will unlock in one of two
ways:
1. Unlock the driver's door only. A
second press is required to unlock
the remaining doors and tailgate.
2. Unlock all doors, and the tailgate.
This security feature unlocks only the
driver’s door and tailgate. It can be
disabled on individual remote controls
by unlocking the vehicle then
simultaneously pressing and holding
the lock and unlock buttons for three
seconds. The vehicle will lock and
then unlock in the currently selected
mode and the hazard warning lights
will flash twice to confirm the change.
You can now unlock all doors with a
single press. Repeating the
procedure will re-enable Single point
entry.
Locking
Press briefly to lock the
vehicle, and activate the
alarm. The hazard warning
lamps will flash to indicate that the
vehicle is locked.
Automatic relocking
If a door, or the tailgate, are not
opened within one minute of
unlocking the vehicle, doors will lock
again automatically.
Approach lighting
When approaching the
vehicle during darkness
press to switch on the
approach illumination. Press again to
turn the approach lamps off.
The approach illumination
period set at the factory is
thirty seconds. This can be
configured by a Land Rover Dealer
to provide illumination lasting
between Zero and 120 seconds.
Tailgate
Press briefly to release the
tailgate.
Emergency alarm
Press and hold for three
seconds, or press twice
within three seconds, to
activate the horn and the hazard
lamps.
Once active for more than five
seconds the alarm can be cancelled
by pressing the button and holding
for three seconds, or pressing twice
within three seconds.
Note:
The horn and hazard lamps
will switch off automatically after two
minutes and forty five seconds.
2
Using the remote control
Remote battery
The remote control batteries are
recharged when the remote is
docked and the engine is running.
For this reason it is recommended
that each remote is used periodically.
This will ensure that the batteries are
kept charged and ready for use.
