The Science of Security
™
featuring CClliiffffoorrdd RReessppoonnddeerr
PN 489X
Compatible with the
following systems:
1100..55
Standard Configuration
A remote that has been programmed to an standard
configuration will use separate buttons for arm and
disarm similar to a factory keyless entry. Using the
expanded configuration, the transmitter buttons are
assigned to the following functions:
Lock Icon Button
The lock icon button arms and locks the system.
Unlock Icon Button
The unlock icon button disarms and unlocks the system.
AUX Icon Buttons
The AUX icon button operates channel 2.
Siren (or Star) Icon Button
The siren (or star) icon button operates Panic only.
Unlock and Lock (or Star) Icon Buttons
When pressed together, the lock and unlock (or star)
icon buttons operate channel 3.
P Button (on the back of the transmitter)
Used for mult-car selection and also to enter the
Transmitter's programming menu. (See Security/
Remote Start manual for details).
FCC/ID Notice
This device complies with Part 15 of FCC rules.
Operation is subject to the following conditions: (1) This
device may not cause harmful interference, and (2) This
device must accept any interference received, including
interference that may cause undesired operation.
CAUTION! Changes or modifications not expressly
approved by the party responsible for compli-
ance could void the user's authority to oper-
ate this device.
MADE IN TAIWAN
©2004 Directed Electronics, Inc. Vista CA 92081
All rights reserved. 11/04
P/N 489X 11-04
REPLACEMENT TRANSMITTER
Model 489X, 4 Button Responder, HF, Stealth Code Remote
1. Door. Open a door.
2. Key. Turn the key to the ON position.
3. Choose. Within 5 seconds press and release the
Valet/Program button the number of times corre-
sponding to the desired channel listed below.
Once you have selected the channel, press the
Valet/Program button once more and hold it. The
LED will flash the same number of times as the
channel selected and the siren (if connected) will
chirp to confirm the selected channel. Do NOT
release the button.
4. Transmit. While holding the Valet/program
button, press the button from the transmitter you
wish to assign to that channel. The unit will chirp
(if horn or siren connected) to confirm that the
transmitter has been taught to the receiver
5. Release. Once the code is learned you can release
the Valet/Program button and remove the key.
The following Learn Routine can be used to program
this replacement transmitter to the system. In order to
enter the Learn Routine, the system’s Valet/Program
switch must be plugged into the BLUE port.
Channel Number Function
without remote start
1 Auto-learn Standard Configuration
11 Delete All Transmitters
P/N 489P
Python Responder 2-Way Transmitter
featuring
Replacement
Transmitter
Compatible with the
following systems:
PPyytthhoonn 990000
MADE IN TAIWAN
©2004 Directed Electronics, Inc. Vista CA 92081
All rights reserved.
P/N 489P 11/04
REPLACEMENT TRANSMITTER
Model 489P, 4 Button Responder, HF, Stealth Code Remote
The following Learn Routine can be used to program
this replacement transmitter to the system. In order to
enter the Learn Routine, the system’s Valet/Program
switch must be plugged into the BLUE port.
1. Door. Open a door.
2. Key. Turn the key to the ON position.
3. Choose. Within 5 seconds press and release the
Valet/Program button the number of times corre-
sponding to the desired channel listed below.
Once you have selected the channel, press the
Valet/Program button once more and hold it. The
LED will flash the same number of times as the
channel selected and the siren (if connected) will
chirp to confirm the selected channel. Do NOT
release the button.
4. Transmit. While holding the Valet/program
button, press the button from the transmitter you
wish to assign to that channel. The unit will chirp
(if horn or siren connected) to confirm that the
transmitter has been taught to the receiver
5. Release. Once the code is learned you can release
the Valet/Program button and remove the key.
Channel Number Function
without remote start
1 Auto-learn Standard Configuration
11 Delete All Transmitters
Standard Configuration
A remote that has been programmed to an standard
configuration will use separate buttons for arm and
disarm similar to a factory keyless entry. Using the
expanded configuration, the transmitter buttons are
assigned to the following functions:
Lock Icon Button
The lock icon button arms and locks the system.
Unlock Icon Button
The unlock icon button disarms and unlocks the system.
AUX Icon Buttons
The AUX icon button operates channel 2.
Siren (or Star) Icon Button
The siren (or star) icon button operates Panic only.
Unlock and Lock (or Star) Icon Buttons
When pressed together, the lock and unlock (or star)
icon buttons operate channel 3.
P Button (on the back of the transmitter)
For multi-car selection and also Used to enter the
Transmitter's programming menu. (See Security/
Remote Start manual for details).
FCC/ID Notice
This device complies with Part 15 of FCC rules.
Operation is subject to the following conditions: (1) This
device may not cause harmful interference, and (2) This
device must accept any interference received, including
interference that may cause undesired operation.
CAUTION! Changes or modifications not expressly
approved by the party responsible for compli-
ance could void the user's authority to oper-
ate this device.
P/N 489V
P/N 489V
Replacement
Transmitter
featuring
Replacement
Transmitter
Compatible with the
following systems:
VViippeerr 55000000
viper responder 2-way transmitter
viper responder 2-way transmitter
MADE IN TAIWAN
©2004 Directed Electronics, Inc. Vista CA 92081
All rights reserved.
P/N 489V 11/04
REPLACEMENT TRANSMITTER
Model 489V, 4 Button Responder, HF, Stealth Code Remote
The following Learn Routine can be used to program
this replacement transmitter to the system. In order to
enter the Learn Routine, the system’s Valet/Program
switch must be plugged into the BLUE port.
1. Door. Open a door.
2. Key. Turn the key to the ON position.
3. Choose. Within 5 seconds press and release the
Valet/Program button the number of times corre-
sponding to the desired channel listed below.
Once you have selected the channel, press the
Valet/Program button once more and hold it. The
LED will flash the same number of times as the
channel selected and the siren (if connected) will
chirp to confirm the selected channel. Do NOT
release the button.
4. Transmit. While holding the Valet/program
button, press the button from the transmitter you
wish to assign to that channel. The unit will chirp
(if horn or siren connected) to confirm that the
transmitter has been taught to the receiver
5. Release. Once the code is learned you can release
the Valet/Program button and remove the key.
Channel Number Function
1 Auto-learn Standard Configuration
11 Delete All Transmitters
Standard Configuration
A remote that has been programmed to an standard
configuration will use separate buttons for arm and
disarm similar to a factory keyless entry. Using the
expanded configuration, the transmitter buttons are
assigned to the following functions:
Lock Icon Button
The lock icon button arms and locks the system.
Unlock Icon Button
The unlock icon button disarms and unlocks the system.
AUX Icon Buttons
The AUX icon button operates channel 2.
Siren (or Star) Icon Button
The siren (or star) icon button operates Panic only.
Unlock and Lock (or Star) Icon Buttons
When pressed together, the lock and unlock (or star)
icon buttons operate channel 3.
P Button (on the back of the transmitter)
Used for multicar selection and also to enter the
Transmitter's programming menu. (See Security/
Remote Start manual for details).
FCC/ID Notice
This device complies with Part 15 of FCC rules.
Operation is subject to the following conditions: (1) This
device may not cause harmful interference, and (2) This
device must accept any interference received, including
interference that may cause undesired operation.
CAUTION! Changes or modifications not expressly
approved by the party responsible for compli-
ance could void the user's authority to oper-
ate this device.
