If the alarm is triggered when armed.•

When the Remote Start command is sent again from a remote •

control

➤ Runtime Check

To check the amount of runtime remaining (2 way remote only):

After the vehicle is remote started, press the

A U X

button three-times and

then hold until the remote beeps, and then release. The display will

show a text indicating remaining run time.

➤ Manual transmission

If the vehicle has manual transmission the proper steps must be fol-

lowed before leaving the parked vehicle or the remote start feature is

disabled.

Put the transmission in neutral.1.

Press on the vehicle’s foot brake.2.

Apply the emergency brake.3.

Release the vehicle’s foot brake. 4.

Note:

Pressing the brake again

after this step will disable the remote start feature.

Within 15 seconds activate the remote start from the remote.5.

The parking lights will ﬂash 5 times conﬁrming that the remote start 6.

is active.

Turn off the ignition (the car should stay running when key is turned 7.

off).

Exit the vehicle and close the door.8.

Arm the alarm (the vehicle should shut off when arming the sys-9.

tem).

You can now remote start the vehicle. If a door is opened or if the alarm

is triggered before the next remote start activation the system will not

remote start.

To drive your vehicle after it has been remote started:

Get in without stepping on the brake. 1.

Insert the ignition key and turn it to the ON position.2.

Now, step on the brake. 3.

The remote control will play the remote start shutdown tone. You have

now taken direct control from the remote start system.

➤ Timer mode

To activate the runtime of the vehicles engine during remote start:

Press the 1.

A U X

button two-times and then

A U X

The vehicle will conﬁrm with 4 fast parking light ﬂashes.2.

The system will start every 3 hours until canceled by the brake, 3.

hood, or neutral safety shut-down wires. The remote will respond

with the Start and Stop remote start notiﬁcation during each Start

and Stop of the Vehicle while in Timer mode.

Important!

Timer Mode should be used only in open areas. Never

start and run the vehicle in an enclosed space such as a garage or

carport.

To exit timer mode, Press the

A U X

button two-times and then

A U X

again.

➤ Turbo timer mode

Turbo timer mode keeps the engine running after arriving at your desti-

nation for a programmable period of 1, 3, 5 or 10 minutes. This allows

the system’s timer to conveniently cool down the turbo after you have

left the vehicle.

Transmit the timer mode feature with the remote while the engine is run-

ning, press

A U X

two-times and then

A U X

. After exiting the vehicle, arm the

alarm and the vehicle will remain running for the programmed runtime.

(The remote start feature is still enabled).

The system monitors the engine speed and will automatically shut the

engine off if the RPMs rise above or fall below the programmed levels.

This feature prevents damage to the motor due to fuel delivery system

failures or other problems which may cause the engine to race.

Note:

To enter turbo timer mode with a manual transmission, perform

the manual transmission procedure (See p.29), with the door open.

Rear defogger

The rear defogger (if connected) is programmed to automatically acti-

vate when remote start is turned on. If the interior cabin temperature is

above 55˚ F the defogger will not activate.

To manually activate the rear defogger after remote start is on:

Press

A U X

four times, and then .

Valet take-over

The Valet take-over feature allows the vehicle to remain running after

the key has been removed from the ignition. This feature is useful for

occasions when you wish to exit and lock the vehicle for short periods

of time, but would like to leave the motor running and the climate

controls on.

To perform Valet take-over:

Before turning off the engine, press and release 1. on the trans-

mitter. Then wait a few seconds.

Turn the ignition key to the OFF position (The engine will stay 2.

running).

The engine will run until the pre-programmed time elapses or a 3.

shut-down input is received.

Note:

To enable Valet take-over with a manual transmission, open

the door when going into a manual transmission mode. After you

exit the vehicle you can arm the alarm and the car will remain run-

ning. If the vehicle shuts down when arming, then the unit did not

enter the valet take-over mode.

Safety features

This system has several important safety features to ensure proper op-

eration of the motor and prevent accidental damage to the engine or

its components.

➤ Starter anti-grind circuitry

Whenever the vehicle is remote started, advanced anti-grind circuitry

prevents the starter from engaging, even if the key is turned to the start

position. This prevents damage to the starter motor if the key is turned

to the start position during remote start operation.

Note:

Anti-grind circuitry only works when the remote start system is

operating the motor and the Failsafe® Starter Kill relay is installed.

➤ Disabling the remote start system

This feature allows the remote start unit to be temporarily disabled

to prevent the vehicle from being remote started accidentally. This

feature is useful when the vehicle is being serviced or stored in an

enclosed area.

To disable the remote start, move the shutdown toggle switch to the

OFF position. Check with your installer for the location.

Location of Shutdown Switch____________________________

Diagnostics

The microprocessor at the heart of your system is constantly monitoring

all of the switches and sensors connected to it. It is designed to detect

any faulty switches and sensors and prevent them from disabling the

entire system. The microprocessor will also record and report any trig-

gers that occurred during your absence.

Refer to System Status Chirps and Table of Zones sections of this guide

for diagnostic information.

➤ Arming

If the security system is armed at the same time that an input is active

(such as a door opening or sensor triggering), you will hear one siren

chirp to indicate arming and a second siren chirp to indicate Bypass

Notiﬁcation.

A Bypass Notiﬁcation chirp means that the security system ignores

the input that was active when the system was armed, until that input

ceases. Three seconds after that input ceases, the security system will

resume normal monitoring.

For example

: if your vehicle has an interior light exit delay and you arm

your security system before the interior light turns off, you may hear a

second Bypass Notiﬁcation chirp.

Once the light turns off, however, the security system resumes normal

monitoring.

Note:

Bypass Notiﬁcation does not occur when the system is in Silent

Mode or if the notiﬁcation chirps have been programmed off by the

installer.

➤ Disarming

Extra chirps heard when disarming the system are the Tamper Alert.

If four chirps are heard when disarming the system, then the security

system was triggered in your absence.

If ﬁve chirps are heard when disarming the system, the system was

triggered so many times that the Nuisance Protection® Circuitry has

bypassed the intended zone. In either case, the status LED will indicate

which zone was involved (see Table of Zones).

The security system will retain this information in its memory, and chirp

four or ve times each time it is disarmed, until the next time that the

ignition is turned on.

➤ System status chirps

The siren will chirp when arming/disarming the system. The pattern of

chirps will audibly report the system’s status as described below.

Action Number of Chirps Description

Arm 1 System armed

Arm 1 (3-second delay) System armed with bypass notification

Disarm 2 System armed

Disarm 4 System disarmed with Tamper Alert

Disarm 5 System disarmed

➤ Table of zones

A zone is represented by the number of LED ﬂashes used by the system

to identify a particular type of input. Standard input assignments are

listed in the following table, along with spaces to write in any optional

sensors or switches that have been installed.

Zone Description Dealer installed options

1 Trunk Pin

2 Instant trigger: a heavier impact

detected by the shock sensor

3 Door switch trigger

4 Instant trigger: For optional

sensors

5 Ignition trigger

6 Hood Pin

➤ Interpreting zone diagnostics

Warn Away responses are not reported by arming or disarming diag-

nostics. If you receive a Bypass notiﬁcation when arming or a Tamper

Alert notiﬁcation when disarming, look at the LED.

Active or triggered zones will be indicated by a pattern of blinks by

the LED.

For example:

If zone 3 was active or triggered, the LED will blink three

times with a two-second pause. Then it will blink three times again, and

repeat until the ignition is turned on.

➤ Nuisance prevention® circuitry

Your system has Directed’s Nuisance Prevention® Circuitry (NPC). It

prevents annoying repetitive trigger sequences due to faulty door pin

switches or environmental conditions such as thunder, jackhammers,

airport noise, etc.

For example:

If the alarm triggers three times within a 60-minute period

and each time the same sensor or switch triggers the alarm, NPC will

interpret those triggers as false alarms. After the third trigger, NPC ig-

nores, or bypasses, that sensor or switch (along with any other sensors

or switches sharing the same zone) for 60 minutes.

If the bypassed sensor tries to trigger the security system while it is being

bypassed, the 60-minute bypass period will start over. This ensures that

a sensor that is continually being triggered will remain bypassed.

The vehicle doors are protected by NPC differently. If your security

system is triggered by an open door for three full cycles, the system will

bypass the doors until the trigger ceases.

Owner recognition

Owner Recognition lets up to four users of the system have unique set-

tings that meet their speciﬁc needs. It is almost like having four separate

alarms in your vehicle, one for each user. This feature is only available

to authorized dealers using the Bitwriter or Bitwriter 2 program tool.

Rapid resume logic

This Directed system will store its current state to non-volatile memory.

If power is lost and then reconnected the system will recall the stored

state from memory.

For example, if the unit is in Valet Mode and the battery is disconnected

for any reason, such as servicing the car, when the battery is recon-

nected the unit will still be in Valet Mode. This applies to all states of the

system including arm, disarm, and Valet Mode.

Power saver mode

➤ System

Your system will automatically enter Power Saver Mode while armed or

in Valet Mode, after a period of time in which no operation has been

performed. This lowers the current draw on the vehicle’s battery. Power

Saver Mode takes over under the following conditions:

Power Saver when the system is armed:

After the system has been

armed for 24 hours the LED will ﬂash at half its normal rate, decreasing

the system’s current draw.

Power Saver in Valet Mode:

When the system enters Valet Mode the

Status LED on the Responder LE control center illuminates steadily. If the

vehicle is not used (ignition is not turned on) for a one hour period while

the system is in Valet Mode, the status LED will shut off. If the system

remains in Valet Mode, the LED will come back on the next time the

ignition is turned on and then back off.

➤ 2-way remote

Your Responder LE 2way remote control has a feature called remote

power save mode. When programmed ON under remote options, the

remote will conserve power by disabling the paging function if unused

for more than 72 hours. Pressing any button on the remote will restore

the paging function.

The default setting is ON. See Remote control programming section of

this guide or ask your dealer for details on how to program.

Programming options

Your system has many custom programmable options. Some may re-

quire installation labor. Ask your authorized dealer for details.

The following is a list of the programmable options, with the factory

settings in Bold.

Active

• arming (remote only) passive arming with or without locking

the doors (automatic arming without locking the doors 30 seconds

after the last door has been closed), or Auto Re-arm with or without

locking the doors (Automatically arms 60 seconds after disarm if

no door is opened).

Arming/disarming siren chirps

with or without Warn-away chirps,

Or OFF with or without Warn-away chirps.

Ignition controlled door lock feature•

or OFF: When this fea-

ture is programmed on, the doors will lock three seconds after the

ignition is turned on, and unlock when the ignition is turned off.

If your installer is programming the security system with the Directed

Bitwriter®, ignition lock and unlock are independent features that can

be programmed separately.

Panic mode enabled

• /disabled when the ignition is turned on or

completely turned OFF. (Some states have laws against sirens

sounding in moving cars.)

Full trigger response 30 or 60 seconds:

• This determines how long

the full triggered sequence lasts. Some states have laws regulating

how long a security system can sound before it is considered a

nuisance.

If your installer is programming the security system with the Di-•

rected Bitwriter®, the full triggered response can be programmed

for any duration ranging from 1 to 180 seconds.

Siren tones and chirp volume:

• The output of the Revenger™Soft

Chirp™ siren consists of six different tones in sequence. Any of

these tones can be eliminated by a dealer, resulting in a unique,

easily identiﬁable siren sound. The chirps can be either full volume

or 6 decibels quieter than the full alarm blast.

Comfort closure

• is a programming option which closes the ve-

hicle’s windows after remote locking.

Security & convenience expansions

Listed below are some of the many expansion options available. Please

consult your dealer for a complete explanation of all the options avail-

able to you.

Audio Sensor:

Metal on glass, glass cracking, and breaking

glass produce distinctive acoustic signatures. The 506T audio sensor

uses a microphone to pick up sounds, then analyzes them with propri-

etary acoustic software to determine if the glass has been struck.

Backup Battery:

The 520T keeps the system armed, triggers the alarm

and keeps the starter interrupt active if main battery is disconnected.

Digital Tilt Sensor:

The 507M tilt sensor can be added to your system

to protect your car when its parked. It can protect your vehicle from be-

ing lifted and provide protection for your expensive rims.

Field Disturbance Sensor:

An invisible dome of coverage is established

by installing the 508D “radar” sensor. Your system can react to any

intrusions into this ﬁeld with the full triggered sequence.

Power Locks: This system offers lock outputs that can control some manu-

facturers’ power door lock systems. For other systems, additional parts

may be required.

Hood Lock:

Prevents the vehicle’s hood from being opened without a

key, keeping thieves away from the system’s siren, the battery connec-

tions, and other components under the hood.

Power Trunk Release:

The accessory output of the system can operate

a factory power release for the vehicle’s trunk or hatch. Although the

on-board relay can control most power trunk releases, sometimes an

optional relay is required. If the factory release is not power-activated,

Directed®’s 522T trunk release solenoid can often be added.

Power Window Control:

Automatic power window control is provided

with the 529T and 530T systems. These can operate power windows,

and can roll them up automatically when the system is armed, roll them

down, or both up and down.

Ultrasonic Cabin Sensor:

Using the 509U Ultrasonic cabin sensor pro-

vides a ﬁeld of protection inside the car to protect your belongings.

Glossary of terms

2-Way Remote:

A hand-held, remote control which operates the

various functions of your system and receives feedback and pages from

the alarm system.

Control Center:

The control center contains the system’s radio-frequency

antenna, the valet and override switch, and the Status LED.

For maximum remote-control range, the Control Center is usually lo-

cated at the top of the windshield, centered near the rear-view mirror.

Control Module:

The “brain” of your system. Usually hidden underneath

the dash area of the vehicle. It houses the microprocessor which moni-

tors your vehicle and controls all of the alarm’s Functions.

Failsafe® Starter Kill

(if equipped): An automatic switch controlled by

the security system which prevents the vehicle’s starter from cranking

whenever the system is armed. The vehicle is never prevented from

cranking when the system is disarmed, in Valet® Mode, or should the

starter kill switch itself fail. Your system is ready for this feature, however

installation of this feature may require additional labor.

Input:

Any physical connection to the security system. An input can

be provided through a sensor, pin-switch or by existing systems in the

vehicle, such as ignition or courtesy lights.

In-vehicle status LED:

A light used to indicate the status of your system.

It is located on your systems control center.

Shock Sensor:

This system has a dual zone shock sensor. This

sensor is mounted in the vehicle and designed to pick up impacts

to the vehicle or glass.

Trigger or Triggered Sequence:

This is what happens when the

alarm “goes off ” or “trips.” The triggered sequence of your

system consists of the siren sounding and parking lights ﬂashing

for the programmed duration.

Valet Button:

A small push button switch located on your systems control

center. It is used to override the

starter interrupt when a 2-way remote is lost or damaged, or to

enter or exit Valet Mode.

Warn Away® Response:

Light impacts to the vehicle generate the

Warn Away® Response, which consists of several seconds of horn

honks and ﬂashing parking lights.

Zone:

A zone is a separate input that the alarm can recognize as

unique. Each input to the system is connected to a particular zone.

Often, two or more inputs may share the same zone.

Quick reference guide

Arming

To arm, press

A U X

. When the system arms, the LOCK LED blinks for

one second, with 1 beep and siren tone.

Arming while driving

To arm the system while driving, press

A U X

on your remote while the

vehicle is running. The LOCK LED blinks for one second.

Disarming

To disarm, press

A U X

. The UNLOCK LED blinks for one second, and

you will hear 2 beeps.

Disarming without a remote

Turn on the ignition. Press the Valet button within 15 seconds. The

system should now disarm. If it does not, you may have waited too

long or pressed the button incorrect number of times. Refer to reverse

side for Valet pushes and try again.

2. Radious will be if not specied.

1. Tex ture is same as

3. Body color :



INJECT TOLERANCE SPEC.

*Tolerance please refer specication

of tolerance limits "c"

120~300

DIMENSION

30~120

UNDER 6

0.40 0.80

0.20

0.10

0.08

GRADE

6~30

0.40

0.20

0.16

2.00

0.40

0.80

0.30 DEI

NUTEK

FELIX

VICTO R

APPD BY

UNIT:

M/M

CODE

MATERIAL

FINISH

SCALE:

1:1

YG F

SHEET

DRN BY

CHK BY

11/20/07

DATE

TITLE

DEPTSIZE

REV.

REVISIONS

DESCRIPTION

CORPORA T ION

OLED IVU

94I0600

DRAWING NO

REV

DATE DRN.

94I0600

CASE P/N:IADGH0A1

KEY P/N:IKDEL0A0

36.32

11.50

10.44

%2'<0$7(5,$/+,+($7$%689

%/$&.

Number of Valet button pulses for disarming_______________

Silent Arm

Press

A U X

one time and then press

A U X

. Arm LED will blink for one

second with no sound.

Silent Disarm

Press

A U X

one time and then press

A U X

. Disarm LED will blink for 1

second with no sound.

Cut along the dotted line and fold to keep in purse or wallet for a quick and easy reference.

✂

Remote Start

Press

A U X

. Remote start LED blinks for 3 seconds and remote start

tone sounds.

Rear Defogger

Press

A U X

four times, and then press

A U X

(only after remote start is

ON.) Remote start LED turns ON, and you will hear 1 beep.

To disable the remote start system

Move the shutdown toggle switch to the OFF position.

Location of Shutdown Toggle Switch___________________

Valet Mode

Press

A U X

two times and then

A U X

. The UNLOCK LED and Function

LED blink and remote beeps one time. When valet Mode OFF, the

remote beeps two-times.

Valet take over

Before turning off the engine, press and release

A U X

. within 3 sec-

onds. Then wait a few seconds.

Turn the ignition key to the OFF position.

The engine will remain running until the programmed time elapses or

a shut-down input is received.

Location of Valet button_________________________________

Cut along the dotted line and fold to keep in purse or wallet for a quick and easy reference.

✂

Limited lifetime consumer warranty

Directed Electronics. (“Directed”) promises to the original purchaser to repair or replace (at

Directed’s election) with a comparable reconditioned model any Directed unit (hereafter

the “unit”), excluding without limitation the siren, the remote transmitters, the associated

sensors and accessories, which proves to be defective in workmanship or material under

reasonable use during the lifetime of the vehicle provided the following conditions are met:

the unit was purchased from an authorized Directed dealer, the unit was professionally

installed and serviced by an authorized Directed dealer; the unit will be professionally

reinstalled in the vehicle in which it was originally installed by an authorized Directed

dealer; and the unit is returned to Directed, shipping prepaid with a legible copy of the

bill of sale or other dated proof of purchase bearing the following information: consumer’s

name, telephone number and address; the authorized dealers name, telephone number

and address; complete product description, including accessories; the year, make and

model of the vehicle; vehicle license number and vehicle identification number. All com-

ponents other than the unit, including without limitation the siren, the remote transmitters

and the associated sensors and accessories, carry a one-year warranty from the date of

purchase of the same. ALL PRODUCTS RECEIVED BY DIRECTED FOR WARRANTY REPAIR

WITHOUT PROOF OF PURCHASE WILL BE DENIED. This warranty is non-transferable

and is automatically void if: the original purchaser has not completed the warranty card

and mailed it within ten (10) days from the date of purchase to the address listed on the

card; the unit’s date code or serial number is defaced, missing or altered; the unit has been

modified or used in a manner contrary to its intended purpose; the unit has been damaged

by accident, unreasonable use, neglect, improper service, installation or other causes not

arising out of defects in materials or construction. The warranty does not cover damage

to the unit caused by installation or removal of the unit. Directed, in its sole discretion, will

determine what constitutes excessive damage and may refuse the return of any unit with

excessive damage.

TO THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WARRANTIES, INCLUDING

BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY, WARRANTY OF

MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE AND WARRANTY OF NON-

INFRINGEMENT OF INTELLECTUAL PROPERTY, ARE EXPRESSLY EXCLUDED; AND

DIRECTED NEITHER ASSUMES NOR AUTHORIZES ANY PERSON OR ENTITY TO ASSUME

FOR IT ANY DUTY, OBLIGATION OR LIABILITY IN CONNECTION WITH ITS PRODUCTS.

DIRECTED DISCLAIMS AND HAS ABSOLUTELY NO LIABILITY FOR ANY AND ALL ACTS

OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEALERS OR INSTALLERS. DIRECTED

SECURITY SYSTEMS, INCLUDING THIS UNIT, ARE DETERRENTS AGAINST POSSIBLE

THEFT. DIRECTED IS NOT OFFERING A GUARANTEE OR INSURANCE AGAINST

VANDALISM, DAMAGE OR THEFT OF THE AUTOMOBILE, ITS PARTS OR CONTENTS;

AND HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER, INCLUDING

WITHOUT LIMITATION, LIABILITY FOR THEFT, DAMAGE AND/OR VANDALISM. THIS

WARRANTY DOES NOT COVER LABOR COSTS FOR MAINTENANCE, REMOVAL OR

REINSTALLATION OF THE UNIT OR ANY CONSEQUENTIAL DAMAGES OF ANY KIND.

IN THE EVENT OF A CLAIM OR A DISPUTE INVOLVING DIRECTED OR ITS SUBSIDIARY,

THE VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA.

CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY AND GOVERN

THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY CLAIM AGAINST DIRECTED

SHALL BE STRICTLY LIMITED TO THE AUTHORIZED DIRECTED DEALER’S PURCHASE

PRICE OF THE UNIT. DIRECTED SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES

WHATSOEVER, INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES,

INCIDENTAL DAMAGES, DAMAGE TO VEHICLE, DAMAGES FOR THE LOSS OF TIME,

LOSS OF EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY

AND THE LIKE. NOTWITHSTANDING THE ABOVE, THE MANUFACTURER DOES OFFER

A LIMITED WARRANTY TO REPLACE OR REPAIR THE CONTROL MODULE SUBJECT TO

THE CONDITIONS AS DESCRIBED HEREIN. THIS WARRANTY IS VOID IF THE UNIT

HAS NOT BEEN PURCHASED FROM DIRECTED, OR AN AUTHORIZED DIRECTED

DEALER, OR IF THE UNIT HAS BEEN DAMAGED BY ACCIDENT, UNREASONABLE USE,

NEGLIGENCE, ACTS OF GOD, NEGLECT, IMPROPER SERVICE, OR OTHER CAUSES

NOT ARISING OUT OF DEFECT IN MATERIALS OR CONSTRUCTION.

Some states do not allow limitations on how long an implied warranty will last or the exclu-

sion or limitation of incidental or consequential damages. This warranty gives you specific

legal rights and you may also have other rights that vary from State to State.

This warranty is only valid for sale of product(s) within the United States of America.

Product(s) sold outside of the United States of America are sold “AS-IS” and shall have NO

WARRANTY, express or implied. This product may be covered by a Guaranteed Protection

Plan (“GPP”). See your authorized Directed dealer for details of the plan or call Directed

Customer Service at 1-800-876-0800.

Make sure you have all of the following information from your authorized Directed

dealer:

A clear copy of the sales receipt, showing the following:

o Date of purchase

o Your full name and address

o Authorized dealer’s company name and address

o Type of alarm installed

o Year, make, model and color of the automobile

o Automobile license number

o Vehicle identification number

o All security options installed on automobile

o Installation receipts

920-0003 06-06

G5902 2008-03

Vista, CA 92081

www.directed.com

The company behind this system is Directed Electronics

Since its inception, Directed Electronics has had one purpose, to provide

consumers with the ﬁnest vehicle security and car stereo products and

accessories available. The recipient of nearly 100 patents and Innovations

Awards in the ﬁeld of advanced electronic technology.

Directed is ISO 9001 registered.

Quality Directed Electronics products are sold and serviced throughout

North America and around the world.

Call (800) 274-0200 for more information about our products and services.

Voxx Electronics DEI7752 Hand Held Security/Remote Control Transceiver User Manual page 31 to 54

DEI Headquarters, Inc. Hand Held Security/Remote Control Transceiver page 31 to 54

Contents

user manual page 31 to 54

Navigation menu

Namespaces

Views

Navigation
