WEIKING TECHNOLOGY BT36S BLUETOOTH SPEAKER User Manual
SHENZHEN WEIKING TECHNOLOGY CO.,LTD BLUETOOTH SPEAKER
User Manual
CHARGING/PLAYING:
Standard USB port connects to all PC USB ports and AC adapters.
1. Connect USB charging cable (2) to speaker.
2. Connect USB plug to available USB port of
computer (see Fig. 1).
3. Power indicator light (3)
will show red while
charging.
4. When charge is
completed,
unplug the USB cable
from the speaker and
the computer.
5. Connect the built-in
3.5 mm audio cable (5)
to a laptop/audio device
and turn the speaker
ON.
Note: Actual battery life will vary with use,
settings and environmental conditions.
Rechargeable batteries have a limited
( Fig. 1)
ACCESSORY:
1. Mini USB charging cable
2. User Manual
PRODUCT DEMO:
1.
2.
3.
4.
indicati on lamp
USB connector for charge
Switch
Line In cable
Output:3W ;
Dimension:62*62*46.5mm
Diameter of speaker:36mm,4ohm
Frequency:180Hz-20KHz
S/N: ±65dB
Battery voltage:3.7V
Battery capacity:500mAH
Battery charging voltage:5v+-0.2v
Battery charging time:3.5hours by USB
Working time:2-5 hours
Working Distance:10M(Distance vary with environment
and Bluetooth devices)
Compliance with Bluetooth 2.0
Support A2DPV 1.2
Indication led status:
1)continuous blue led for Linein, Shiny blue led for
Bluetooth status;
2)Red indication for Charging status
3)Light off for full charging
SPECIFICATIONS:
Connection with Bluetooth Speaker:
1)BT speaker will have a sound (ding) out when
switch it to the Bluetooth mode. Shiny blue led
indication for connection to Bluetooth devices.
2)Start the Bluetooth on your devices and
search ."W-king" will show on the searching
Bluetooth devices and press it and put the code
at "0000" to match the speaker.The speaker will
again have the "ding" sound which means the
match is succeded. Matching time is around 1
minutes .It is vary with different devices. It's
unnecessary to put the code next time .
3)Play the music on your mobile or other
Bluetooth devices if both speakers match your
mobile or other devices.
4)Switch off the Bluetooth speaker if don't use .
5)Swi
tch i
t to th
e "LINE
IN" an
d p
lug th
e 3.5
cable in
to yo
ur m
obil
e phon
e or other audio
devices and play the music directly.
OPERATION INSTRUCTION: Q&A
Q&A1: speaker could not match the devices under
Bluetooth status
1)Check if the speaker is under standby status.
2)Turn off other Bluetooth devices
3)Delete the W-king name and research .
" "
Q&A2:Very low sound or distorted sound:Check
your audio volumes and adjust to be the
suitable volumes.
Q&A3: Sound is cut-off instantly.
1)Check if it is far away from working distance or
it have other obstacles between two devices.
Bluetooth Speaker
Battery capacity:400mAH
Federal Communications Commission (FCC) Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Warning: Changes or modifications made to this device not expressly approved by
SHENZHEN WEIKING TECHNOLOGY CO.,LTD may void the FCC authorization to
operate this device.
Note: The manufacturer is not responsible for any radio or tv interference caused by
unauthorized modifications to this equipment. Such modifications could void the user’s
authority to operate the equipment.
