MANUAL APPENDIX A
Installation and Operators Handbook Appendix A
AMX-MA-00658 Issue 0.02 (USA) A-1
APPENDIX A BOX ID AND TRANSCEIVER DEFAULT
CHANNEL SETTINGS
Table A-1 Box ID and Transceiver Default Settings
Box ID Transceiver
Default Channel
Switch 1
(LSB) Switch 2 Switch 3 Switch 4 Switch 5 Switch 6 Switch 7 Switch 8
(MSB)
TxRx 1 TxRx 2
0 0 1 Off Off Off Off Off Off Off Off
1 2 3 On Off Off Off Off Off Off Off
2 4 5 Off On Off Off Off Off Off Off
3 6 7 On On Off Off Off Off Off Off
4 8 9 Off Off On Off Off Off Off Off
5 10 11 On Off On Off Off Off Off Off
6 12 13 Off On On Off Off Off Off Off
7 14 15 On On On Off Off Off Off Off
8 16 17 Off Off Off On Off Off Off Off
9 18 19 On Off Off On Off Off Off Off
10 20 21 Off On Off On Off Off Off Off
11 22 23 On On Off On Off Off Off Off
12 24 25 Off Off On On Off Off Off Off
13 26 27 On Off On On Off Off Off Off
14 28 29 Off On On On Off Off Off Off
15 30 31 On On On On Off Off Off Off
16 32 33 Off Off Off Off On Off Off Off
17 34 35 On Off Off Off On Off Off Off
18 36 37 Off On Off Off On On Off Off
19 38 39 On On Off Off On On Off Off
20 40 41 Off Off On Off On On Off Off
21 42 43 On Off On Off On On Off Off
22 44 45 Off On On Off On On Off Off
23 46 47 On On On Off On On Off Off
24 48 49 Off Off Off On On On Off Off
25 50 51 On Off Off On On On Off Off
26 52 53 Off On Off On On On Off Off
27 54 55 On On Off On On On Off Off
28 56 57 Off Off On On On On Off Off
29 58 59 On Off On On On On Off Off
30 60 61 off On On On On On Off Off
31 62 63 On On On On On On Off Off
32 64 65 Off Off Off Off Off On Off Off
33 66 67 On Off Off Off Off On Off Off
34 68 69 Off On Off Off Off On Off Off
35 70 71 On On Off Off Off On Off Off
36 72 73 Off Off On Off Off On Off Off
37 74 75 On Off On Off Off On Off Off
38 76 77 Off On On Off Off On Off Off
39 78 79 On On On Off Off On Off Off
40 80 81 Off Off Off On Off On Off Off
41 82 83 On Off Off On Off On Off Off
42 84 85 Off On Off On Off On Off Off
43 86 87 On On Off On Off On Off Off
44 88 89 Off Off On On Off On Off Off
45 90 91 On Off On On Off On Off Off
Installation and Operators Handbook Appendix A
AMX-MA-00658 Issue 0.02 (USA) A-2
Box ID Transceiver
Default Channel
Switch 1
(LSB) Switch 2 Switch 3 Switch 4 Switch 5 Switch 6 Switch 7 Switch 8
(MSB)
TxRx 1 TxRx 2
46 92 93 Off On On On Off On Off Off
47 94 95 On On On On Off On Off Off
48 96 97 Off Off Off Off On On Off Off
49 98 99 On Off Off Off On On Off Off
50 100 101 Off On Off Off On On Off Off
51 102 103 On On Off Off On On Off Off
52 104 105 Off Off On Off On On Off Off
53 106 107 On Off On Off On On Off Off
54 108 109 Off On On Off On On Off Off
55 110 111 On On On Off On On Off Off
56 112 113 Off Off Off On On On Off Off
57 114 115 On Off Off On On On Off Off
58 116 117 Off On Off On On On Off Off
59 118 119 On On Off On On On Off Off
60 120 121 Off Off On On On On Off Off
61 122 123 On Off On On On On Off Off
62 124 125 Off On On On On On Off Off
63 126 127 On On On On On On Off Off
64 128 129 Off Off Off Off Off Off On Off
65 130 131 On Off Off Off Off Off On Off
66 132 133 Off On Off Off Off Off On Off
67 134 135 On On Off Off Off Off On Off
68 136 137 Off Off On Off Off Off On Off
69 138 139 On Off On Off Off Off On Off
70 140 141 Off On On Off Off Off On Off
71 142 143 On On On Off Off Off On Off
72 144 145 Off Off Off On Off Off On Off
73 146 147 On Off Off On Off Off On Off
74 148 149 Off On Off On Off Off On Off
75 150 151 On On Off On Off Off On Off
76 152 153 Off Off On On Off Off On Off
77 154 155 On Off On On Off Off On Off
78 156 157 Off On On On Off Off On Off
79 158 159 On On On On Off Off On Off
80 160 161 Off Off Off Off Off Off On Off
81 162 163 On Off Off Off On Off On Off
82 164 165 Off On Off Off On Off On Off
83 166 167 On On Off Off On Off On Off
84 168 169 Off Off On Off On Off On Off
85 170 171 On Off On Off On Off On Off
86 172 173 Off On On Off On Off On Off
87 174 175 On On On Off On On On Off
88 176 177 Off Off Off On On On On Off
89 178 179 On Off Off On On On On Off
90 180 181 Off On Off On On On On Off
91 182 183 On On Off On On On On Off
92 184 185 Off Off On On On On On Off
93 186 187 On Off On On On On On Off
94 188 189 off On On On On On On Off
95 190 191 On On On On On On On Off
96 192 193 Off Off Off Off Off On On Off
97 194 195 On Off Off Off Off On On Off
98 196 197 Off On Off Off Off On On Off
99 198 199 On On Off Off Off On On Off
Installation and Operators Handbook Appendix A
AMX-MA-00658 Issue 0.02 (USA) A-3
Box ID Transceiver
Default Channel
Switch 1
(LSB) Switch 2 Switch 3 Switch 4 Switch 5 Switch 6 Switch 7 Switch 8
(MSB)
TxRx 1 TxRx 2
100 200 201 Off Off On Off Off On On Off
101 202 203 On Off On Off Off On On Off
102 204 205 Off On On Off Off On On Off
103 206 207 On On On Off Off On On Off
104 208 209 Off Off Off On Off On On Off
105 210 211 On Off Off On Off On On Off
106 212 213 Off On Off On Off On On Off
107 214 215 On On Off On Off On On Off
108 216 217 Off Off On On Off On On Off
109 218 219 On Off On On Off On On Off
110 220 221 Off On On On Off On On Off
111 222 223 On On On On Off On On Off
112 224 225 Off Off Off Off On On On Off
113 226 227 On Off Off Off On On On Off
114 228 229 Off On Off Off On On On On
115 230 231 On On Off Off On On On On
116 232 233 Off Off On Off On On On On
117 234 235 On Off On Off On On On On
118 236 237 Off On On Off On On On On
119 238 239 On On On Off On On On On
120 240 241 Off Off Off On On On On On
121 242 243 On Off Off On On On On On
122 244 245 Off On Off On On On On On
123 246 247 On On Off On On On On On
124 248 249 Off Off On On On On On On
125 250 251 On Off On On On On On On
126 252 253 Off On On On On On On On
127 254 255 On On On On On On On On
128 256 257 Off Off Off Off Off Off Off On
129 258 259 On Off Off Off Off Off Off On
130 260 261 Off On Off Off Off Off Off On
131 262 263 On On Off Off Off Off Off On
132 264 265 Off Off On Off Off Off Off On
133 266 267 On Off On Off Off Off Off On
134 268 269 Off On On Off Off Off Off On
135 270 271 On On On Off Off Off Off On
136 272 273 Off Off Off On Off Off Off On
137 274 275 On Off Off On Off Off Off On
138 276 277 Off On Off On Off Off Off On
139 278 279 On On Off On Off Off Off On
140 280 281 Off Off On On Off Off Off On
141 282 283 On Off On On Off Off Off On
142 284 285 Off On On On Off Off Off On
143 286 287 On On On On Off Off Off On
144 288 289 Off Off Off Off On Off Off On
145 290 291 On Off Off Off On Off Off On
146 292 293 Off On Off Off On On Off On
147 294 295 On On Off Off On On Off On
148 296 297 Off Off On Off On On Off On
149 298 299 On Off On Off On On Off On
150 300 301 Off On On Off On On Off On
151 302 303 On On On Off On On Off On
152 304 305 Off Off Off On On On Off On
153 306 307 On Off Off On On On Off On
Installation and Operators Handbook Appendix A
AMX-MA-00658 Issue 0.02 (USA) A-4
Box ID Transceiver
Default Channel
Switch 1
(LSB) Switch 2 Switch 3 Switch 4 Switch 5 Switch 6 Switch 7 Switch 8
(MSB)
TxRx 1 TxRx 2
154 308 309 Off On Off On On On Off On
155 310 311 On On Off On On On Off On
156 312 313 Off Off On On On On Off On
157 314 315 On Off On On On On Off On
158 316 317 off On On On On On Off On
159 318 319 On On On On On On Off On
160 320 321 Off Off Off Off Off On Off On
161 322 323 On Off Off Off Off On Off On
162 324 325 Off On Off Off Off On Off On
163 326 327 On On Off Off Off On Off On
164 328 329 Off Off On Off Off On Off On
165 330 331 On Off On Off Off On Off On
166 332 333 Off On On Off Off On Off On
167 334 335 On On On Off Off On Off On
168 336 337 Off Off Off On Off On Off On
169 338 339 On Off Off On Off On Off On
170 340 341 Off On Off On Off On Off On
171 342 343 On On Off On Off On Off On
172 344 345 Off Off On On Off On Off On
173 346 347 On Off On On Off On Off On
174 348 349 Off On On On Off On Off On
175 350 351 On On On On Off On Off On
176 352 353 Off Off Off Off On On Off On
177 354 355 On Off Off Off On On Off On
178 356 357 Off On Off Off On On Off On
179 358 359 On On Off Off On On Off On
180 360 361 Off Off On Off On On Off On
181 362 363 On Off On Off On On Off On
182 364 365 Off On On Off On On Off On
183 366 367 On On On Off On On Off On
184 368 369 Off Off Off On On On Off On
185 370 371 On Off Off On On On Off On
186 372 373 Off On Off On On On Off On
187 374 375 On On Off On On On Off On
188 376 377 Off Off On On On On Off On
189 378 379 On Off On On On On Off On
190 380 381 Off On On On On On Off On
191 382 383 On On On On On On Off On
192 384 385 Off Off Off Off Off Off On On
193 386 387 On Off Off Off Off Off On On
194 388 389 Off On Off Off Off Off On On
195 390 391 On On Off Off Off Off On On
196 392 393 Off Off On Off Off Off On On
197 394 395 On Off On Off Off Off On On
198 396 397 Off On On Off Off Off On On
199 398 399 On On On Off Off Off On On
200 400 401 Off Off Off On Off Off On On
201 402 403 On Off Off On Off Off On On
202 404 405 Off On Off On Off Off On On
203 406 407 On On Off On Off Off On On
204 408 409 Off Off On On Off Off On On
205 410 411 On Off On On Off Off On On
206 412 413 Off On On On Off Off On On
207 414 415 On On On On Off Off On On
Installation and Operators Handbook Appendix A
AMX-MA-00658 Issue 0.02 (USA) A-5
Box ID Transceiver
Default Channel
Switch 1
(LSB) Switch 2 Switch 3 Switch 4 Switch 5 Switch 6 Switch 7 Switch 8
(MSB)
TxRx 1 TxRx 2
208 416 417 Off Off Off Off On Off On On
209 418 419 On Off Off Off On Off On On
210 420 421 Off On Off Off On On On On
211 422 423 On On Off Off On On On On
212 424 425 Off Off On Off On On On On
213 426 427 On Off On Off On On On On
214 428 429 Off On On Off On On On On
215 430 431 On On On Off On On On On
216 432 433 Off Off Off On On On On On
217 434 435 On Off Off On On On On On
218 436 437 Off On Off On On On On On
219 438 439 On On Off On On On On On
220 440 441 Off Off On On On On On On
221 442 443 On Off On On On On On On
222 444 445 Off On On On On On On On
223 446 447 On On On On On On On On
224 448 449 Off Off Off Off Off On On On
225 450 451 On Off Off Off Off On On On
226 452 453 Off On Off Off Off On On On
227 454 455 On On Off Off Off On On On
228 456 457 Off Off On Off Off On On On
229 458 459 On Off On Off Off On On On
230 460 461 Off On On Off Off On On On
231 462 463 On On On Off Off On On On
232 464 465 Off Off Off On Off On On On
233 466 467 On Off Off On Off On On On
234 468 469 Off On Off On Off On On On
235 470 471 On On Off On Off On On On
236 472 473 Off Off On On Off On On On
237 474 475 On Off On On Off On On On
238 476 477 Off On On On Off On On On
239 478 479 On On On On Off On On On
240 480 481 Off Off Off Off On On On On
241 482 483 On Off Off Off On On On On
242 484 485 Off On Off Off On On On On
243 486 487 On On Off Off On On On On
244 488 489 Off Off On Off On On On On
245 490 491 On Off On Off On On On On
246 492 493 Off On On Off On On On On
247 494 495 On On On Off On On On On
248 496 497 Off Off Off On On On On On
249 498 499 On Off Off On On On On On
250 500 501 Off On Off On On On On On
251 502 503 On On Off On On On On On
252 504 505 Off Off On On On On On On
253 506 507 On Off On On On On On On
254 508 509 Off On On On On On On On
255 510 511 On On On On On On On On
