APPENDIX B MODULE ERROR CODES AND
RECOMMENDED ACTIONS
Table B-1: Error Codes E00 – E99 : User Serviceable Failures/Advisories
Transceiver Module Controller Module Recommended Action
E00 Reserved Reserved
E01 - Internal 10MHz failure Either replace Controller
Module or use external
10 MHz oscillator
E02 – E03 Reserved Reserved
E04 - DC Revert Active Check AC Power Supply
E05 Channel Programming
Error or
Empty Channel Table
- Check channel programming
using Transceiver Module
Programmer
E06 PA Comms Failure - Check PA inserted correctly
and power applied from
PSU. If PSU fault light is on,
or PSU power light is off,
then replace PSU module.
Otherwise replace PA
module.
E07 PA Over Temperature
Alarm - Check fans operating
correctly.
E08 PA High VSWR Alarm - Check antenna connections.
E09 Remote Diagnostics Active
in Test Mode - An advisory, not an error
condition
E10 – E22 Reserved Reserved
E23 - GPIO Xilinx boot failure Replace Controller Module
E24 DSP boot failure DSP boot failure Replace Module
E25 Reserved Reserved
E26–E99 Not Used
