Whirlpool Europe S.r.l. BUILT-IN MICROWAVE OVEN Users Manual VII

Users Manual VII

BUILT-IN HIGH SPEED MICROWAVE OVEN
Use & Care Guide
For questions about features, operation/performance, parts accessories or service, call: 1-800-422-1230
In Canada, call for assistance 1-800-461-5681, for installation and service, call: 1-800-807-6777 or visit our website at...
www.kitchenaid.com or www.KitchenAid.ca
Table of Contents............................................................................................................2
Models KBHC109 KEHC379 YKBHC109
KBHC179 KBHV109 YKEHC309
KEHC309 KEHV309 YKEHV309
8302974
2
TABLE OF CONTENTS
MICROWAVE OVEN SAFETY........................................................3
Electrical Requirements ...............................................................5
PARTS AND FEATURES................................................................5
Turntable ......................................................................................6
Grids.............................................................................................6
Crisper Pan and Handle...............................................................6
ELECTRONIC OVEN CONTROL...................................................7
Display(s) ......................................................................................8
Number Codes.............................................................................8
Start, Easy Minute........................................................................8
Upper Oven Cancel and Cancel Off ............................................8
Clock ............................................................................................8
Tones............................................................................................9
Fahrenheit and Celsius.................................................................9
Timer.............................................................................................9
Control Lock.................................................................................9
Help Prompts ...............................................................................9
HIGH SPEED COOKING ..............................................................10
High Speed Cooking Chart........................................................10
MICROWAVE OVEN USE ............................................................14
Food Characteristics..................................................................14
Cooking Guidelines....................................................................14
Cookware and Dinnerware ........................................................15
Aluminum Foil and Metal ...........................................................15
Cooking Power...........................................................................16
Cooking ......................................................................................16
Cooking in Stages......................................................................16
Crisper Pan Frying......................................................................17
Custom Reheat ..........................................................................17
Custom Defrost..........................................................................18
Popcorn......................................................................................19
Keeping Food Warm ..................................................................19
Crisp ...........................................................................................20
Broil ............................................................................................20
Convection Cooking...................................................................21
OVEN CARE..................................................................................24
General Cleaning........................................................................24
TROUBLESHOOTING ..................................................................25
ASSISTANCE OR SERVICE.........................................................26
In the U.S.A. ...............................................................................26
In Canada ...................................................................................26
Replacement Parts & Accessories.............................................26
WARRANTY ..................................................................................28
3
MICROWAVE OVEN SAFETY
You can be killed or seriously injured if you don't
immediately follow instructions.
You can be killed or seriously injured if you don't
follow instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you
what can happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all
safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or
WARNING.” These words mean:
SAVE THESE INSTRUCTIONS
WARNING: To reduce the risk of burns, electric
shock, fire, injury to persons, or exposure to excessive
microwave energy:
Read all instructions before using the microwave
oven.
Read and follow the specific “PRECAUTIONS TO
AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY” found in this section.
The microwave oven must be grounded. Connect
only to properly grounded outlet. See “GROUNDING
INSTRUCTIONS” found in this section.
Install or locate the microwave oven only in
accordance with the provided Installation Instructions.
Some products such as whole eggs in the shell and
sealed containers – for example, closed glass jars –
may explode and should not be heated in the
microwave oven.
Use the microwave oven only for its intended use as
described in this manual. Do not use corrosive
chemicals or vapors in the microwave oven. This
type of oven is specifically designed to heat, cook,
or dry food. It is not designed for industrial or
laboratory use.
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances basic safety precautions should be followed, including the following:
As with any appliance, close supervision is necessary
when used by children.
The microwave oven should be serviced only by
qualified service personnel. Contact nearest
authorized service company for examination, repair,
or adjustment.
Do not cover or block any openings on the
microwave oven.
Oversized foods or oversized metal utensils should
not be inserted in the microwave oven as they may
create a fire or risk of electric shock.
Do not clean with metal scouring pads. Pieces can
burn off the pad and touch electrical parts involving
a risk of electric shock.
Do not store any materials, other than manufacturer's
recommended accessories, in this oven when not in
use.
Do not cover racks or any other part of the oven with
metal foil. This will cause overheating of the oven.
Do not use paper products when appliance is
operated in the "PAN BROWN" mode.
Do not operate the microwave oven if it has a
damaged cord or plug, if it is not working properly, or
if it has been damaged or dropped.
Do not deep fry in oven. Microwavable utensils are
not suitable and it is difficult to maintain appropriate
deep frying temperatures.
4
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
See door surface cleaning instructions in the “Oven
Care” section.
To reduce the risk of fire in the oven cavity:
– Do not overcook food. Carefully attend the
microwave oven if paper, plastic, or other
combustible materials are placed inside the oven
to facilitate cooking.
Do not store the microwave oven outdoors. Do not
use this product near water - for example, near a
kitchen sink, in a wet basement, or near a
swimming pool, and the like.
– Remove wire twist-ties from paper or plastic bags
before placing bags in oven.
– If materials inside the oven should ignite, keep
oven door closed, turn oven off, and disconnect the
power cord, or shut off power at the fuse or circuit
breaker panel.
– Do not use the cavity for storage purposes. Do not
leave paper products, cooking utensils, or food in
the cavity when not in use.
To reduce the risk of injury to persons:
Liquids, such as water, coffee, or tea are able to be
overheated beyond the boiling point without appearing
to be boiling. Visible bubbling or boiling when the
container is removed from the microwave oven is not
always present. THIS COULD RESULT IN VERY HOT
LIQUIDS SUDDENLY BOILING OVER WHEN THE
CONTAINER IS DISTURBED OR A SPOON OR
OTHER UTENSIL IS INSERTED INTO THE LIQUID.
Do not overheat the liquid.
Stir the liquid both before and halfway through
heating it.
Do not use straight-sided containers with narrow
necks.
After heating, allow the container to stand in the
microwave oven for a short time before removing
the container.
Use extreme care when inserting a spoon or other
utensil into the container.
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door
open since open-door operation can result in
harmful exposure to microwave energy. It is
important not to defeat or tamper with the
safety interlocks.
(b) Do not place any object between the oven front
face and the door or allow soil or cleaner residue
to accumulate on sealing surfaces.
(c) Do not operate the oven if it is damaged. It is
particularly important that the oven door close
properly and that there is no damage to the:
(1) Door (bent),
(2) Hinges and latches (broken or loosened),
(3) Door seals and sealing surfaces.
(d) The oven should not be adjusted or repaired by
anyone except properly qualified service personnel.
5
Electrical Requirements
The microwave oven is connected to a 110-volt side of the
240-volt circuit required for the lower oven. If the incoming
voltage to the microwave oven is less than 110 volts cooking
times may be longer. Have a qualified electrician check your
electrical system.
PARTS AND FEATURES
This manual covers different models. The oven you have
purchased may have some or all of the parts and features listed.
The location and appearance of the features shown here may not
match those of your model.
GROUNDING INSTRUCTIONS
For all cord connected appliances:
The microwave oven must be grounded. In the event
of an electrical short circuit, grounding reduces the
risk of electric shock by providing an escape wire for
the electric current. The microwave oven is equipped
with a cord having a grounding wire with a grounding
plug. The plug must be plugged into an outlet that is
properly installed and grounded.
WARNING:
Improper use of the grounding plug can
result in a risk of electric shock. Consult a qualified
electrician or serviceman if the
grounding
instructions
are not completely understood
, or if doubt exists as to
whether the microwave oven is properly grounded.
For a permanently connected appliance:
This appliance must be connected to a grounded,
metallic, permanent wiring system, or an equipment
grounding conductor should be run with the circuit
conductors and connected to the equipment
grounding terminal or lead on the appliance.
Do not use an extension cord. If the power supply cord
is too short, have a qualified electrician or serviceman
install an outlet near the microwave oven.
SAVE THESE INSTRUCTIONS
This device complies with Part 18 of the FCC Rules.
A. Light (inaccessible, in ceiling)
B. Convection element and fan
(hidden behind back panel)
C. Turntable
D. Turntable support
(under turntable)
E. Metal shielded window
F. Door handle
G. Lower oven (on combination
models, see separate Use and
Care Guide)
H. Oven control
I. Door safety lock system
J. Broil element (hidden in
ceiling)
K. Dual microwave emission
L. Cooking guide labels
Parts and Features not shown
Broiling grid
Convection grid
Crisper pan and handle
This unit must be connected
to a 240-volt circuit.
H I
A
B
C
D
E
F
G
J
K
L
6
Turntable
The turntable rotates in both directions to help cook food more
evenly. Do not operate the microwave oven without the turntable
in place. See “Assistance or Service” to reorder any of the parts.
The raised, curved lines in the center of the turntable bottom fit
between the 3 spokes of the hub. The hub turns the turntable
during microwave oven use. The rollers on the support should fit
inside the turntable bottom ridge.
Grids
Grids will become hot. Always use oven mitts or pot holders
when handling.
Do not allow the grids to touch the inside cavity walls, ceiling
or floor.
Always use the turntable.
Do not store the grids in the oven. Damage to the oven could
result if someone accidentally turns on the microwave oven.
Do not use another metal object with the grids.
Two-level cooking is not recommended.
Do not place popcorn bags on the grids.
The grids are designed specifically for this oven. Do not
attempt to use any other grid or rack in this oven.
See “Assistance or Service” section to reorder.
Broiling Grid (long legs)
The broiling grid places food close to the broil element, making
it ideal for fast browning of small amounts of food. Use for
broiling only.
Convection Grid (short legs)
The convection grid provides optimal heat circulation for high
speed cooking and convection cooking.
Crisper Pan and Handle
The crisper pan is ideal for rapidly browning and crisping the
bottom of the food, such as cookies and pizza.
The material coating the bottom absorbs microwaves and
transfers the heat to the pan and food. The crisper pan reaches
436°F (210°C) in approximately 3 minutes, at which time it stops
absorbing microwaves and holds this optimal frying temperature.
The crisper pan will become hot. Always use the handle and
oven mitts or pot holders when handling. Place gripping end
on the edge of pan, squeeze handle, and lift pan.
Do not allow the crisper pan or handle to touch the inside
cavity walls, ceiling or floor.
Always use the turntable.
Do not use another metal object with the crisper pan.
The crisper pan is designed specifically for this oven. Do not
use it in any other oven.
Use only wooden or plastic cooking utensils to help prevent
scratches.
See “Assistance or Service” section to reorder.
A. Turntable
B. Hub
C. Support and rollers
A
B
C
7
ELECTRONIC OVEN CONTROL
COMBINATION OVEN MODELS
SINGLE OVEN MODEL
A. Lower oven display
B. Number pads
C. Control lock
D. Upper
oven display
E. Clock
F. Tim er
G. Lower oven selectors
(see separate Use and Care Guide)
H. Quantity
I. Lower oven light
J. Microwave popcorn
K. Microwave cooking power
L. Microwave reheating
M. Broiling
N. Microwave defrosting
O. Crisping
P. Convection cooking
Q. High speed cooking
R. Upper oven cancel
S. Upper oven start and Easy Minute
A B C D E F
G H I J K L M N O P Q R S
A. Microwave popcorn
B. Microwave reheating
C. Microwave defrosting
D. High speed cooking
E. Microwave cooking power
F. B r o il i n g
G. Crisping
H. Convection cooking
I. Number pads
J. Control lock
K. Display
L. Start and Easy Minute
M. Clock
N. Cancel off
O. Quantity
P. Tim e r
A
B
C
D
E
F
G
H
I J K
L
M
N
O P
8
Display(s)
When power is first supplied to the appliance, everything on the
display(s) will light up for 5 seconds. Then, “PF id = 27” or
“PF id = 30” will appear. Touch LOWER OVEN CANCEL, UPPER
OVEN CANCEL or CANCEL OFF (on some models) to clear
display(s).
Any other time “PF id = 27” or “PF id = 30” appears, a power
failure occurred. Touch LOWER OVEN CANCEL, UPPER OVEN
CANCEL or CANCEL OFF (on some models) and reset the clock
if needed.
Lower Oven Display (combination oven models)
When the lower oven is in use, this display shows the lower oven
temperature, heat source(s) and start time.
During lower oven Timed Cooking, this display also shows a
vertical bar and minute time countdown and the stop time (if
entered).
If “Err” appears on the display, an invalid pad was touched.
Touch LOWER OVEN CANCEL, UPPER OVEN CANCEL or
CANCEL OFF (on some models) and retry the entry.
When the lower oven is not in use, this display is blank.
Upper Oven Display (combination oven models),
Display (single oven models)
When the upper oven or single oven is in use, this display shows
the upper oven or single oven heat source(s), cooking power,
quantities, weights and/or help prompts.
If “RETRY” flashes on the display for 1 second, an invalid pad
was touched. Retry the entry.
When the upper oven or single oven is not in use, this display
shows the time of day or Timer countdown.
Number Codes
The oven is preset with shortcut number codes for High Speed
and Microwave Cooking. A number code includes one or more of
the following; cooking power, cook time and food quantity or
weight. See the code charts in the “High Speed Cooking,”
“Custom Reheat,” “Custom Defrost” and “Popcorn” sections for
additional information.
Start, Easy Minute
The START pad controls 2 separate functions: Start and Easy
Minute.
Starting
The START pad begins any upper or single oven function except
the Timer. If not touched within 5 seconds after pressing a pad,
“START?” will appear on the display as a reminder. If not touched
within 5 minutes after pressing a pad, the display will return to the
time of day mode and the programmed function will be canceled.
If cooking is interrupted, touching START will resume the preset
cycle.
Adding Minutes
During High Speed Cooking, Crisping and Broiling, touching
EASY MINUTE (START) while the oven is operating will add cook
time in 1-minute increments.
During Microwave Cooking, touching EASY MINUTE while the
oven is operating, or at the end of a cycle, will add cook time in
1-minute increments.
During Convection Cooking, touching EASY MINUTE will not add
minutes.
Upper Oven Cancel and Cancel Off
The UPPER OVEN CANCEL or CANCEL OFF pad stops any
upper or single oven function except for the Clock, Timer and
Control Lock.
The oven will also turn off when the door is opened. When the
door is opened, the element(s) and fan will turn off, but the oven
light will remain on. Close the door and touch START to resume
the cycle.
Clock
This is a 12-hour clock and does not show a.m. or p.m.
To Set:
Before setting, make sure the ovens, Timer and Timed Cooking
are off.
1. Touch CLOCK SET • START.
2. Touch the number pads to set the time of day.
3. Touch CLOCK SET • START or START.
To remove the time of day from the display: Touch and hold
CLOCK SET • START for 5 seconds.
To return the time of day to the display: Touch CLOCK
SET • START. The time should not have to be reset.
9
Tones
Tones are audible signals, indicating the following:
One tone
Valid pad touch
Oven is preheated
Function has been entered
Three tones
Invalid pad touch
Four tones
End of cycle
Reminder, repeating each minute after the end-of-cycle tones
All Tones (combination oven models only)
All of the above tones are preset on, but can be turned off.
To Turn Off/On: Touch and hold TIMER CANCEL for 5 seconds.
A tone will sound, and “Snd oFF” will appear on the lower oven
display for 3 seconds. Repeat to change back to “Snd on.”
Tone Volume
The volume is preset at high, but can be changed to low.
To Change: Touch and hold the number pad “7” for 5 seconds.
A tone will sound, and “Snd Lo” will appear on the lower oven
display for 3 seconds. Repeat to change back to “Snd HI.”
Reminder tones
The Timer and Timed Cooking reminder tones are preset on,
but can be turned off. Reminder tones do not include end-of-
cycle tones. On combination oven models, if “All Tones” have
been turned off, the reminder tones cannot be independently
turned on.
Timer
To Tur n Tones Off/On: Touch and hold TIMER SET • START until
a tone sounds. Repeat to turn back on.
Timed Cooking (combination oven models only)
To Tur n Tones Off/On: Touch and hold COOK TIME until a tone
sounds and the lower oven display returns to inactive mode
(blank). Repeat to turn back on.
Fahrenheit and Celsius
(combination oven models only)
The temperature is preset in Fahrenheit, however it can be
changed to Celsius.
To Change: Touch and hold BROIL • MAXI •• ECONO for
5 seconds. A tone will sound, and “C°” will appear on the display
for 3 seconds. Repeat to change back to Fahrenheit.
When in Fahrenheit, “°F” follows the oven temperature.
When in Celsius, only “°” follows the oven temperature.
Timer
The Timer can be set in minutes and seconds or hours and
minutes, and counts down the set time. The Timer does not start
or stop the oven.
To Set:
1. Touch TIMER SET • START.
Touch again to switch between MIN/SEC and HR/MIN.
If no action is taken after 1 minute, the display will return to
the time of day mode.
2. Touch the number pads to set length of time.
3. Touch TIMER SET • START or START.
If not touched within 5 seconds, the display will return to the
time of day mode and the programmed function will be
canceled.
When the set time ends, if enabled, end-of-cycle tones will
sound, then reminder tones will sound every minute.
4. Touch TIMER CANCEL anytime to cancel the Timer and/or
stop reminder tones.
Remember, touching the UPPER OVEN CANCEL or CANCEL
OFF pad(s) will turn the respective oven(s) off.
The time can be reset during the countdown by repeating the
above steps.
Control Lock
The Control Lock shuts down the control panel pads to prevent
unintended use of the oven(s).
When the control is locked, only the CLOCK SET • START, TIMER
SET • START and TIMER CANCEL pads will function.
The Control Lock is preset unlocked, but can be locked.
To Lock/Unlock Control: Before locking, make sure the oven(s),
Timer and Timed Cooking are off. Touch and hold the number
pad 3 CONTROL LOCK until “CONTROL LOCK” and a picture of
a lock appear on the display, about 3 seconds. Repeat to unlock
and remove “CONTROL LOCK” from the display.
Help Prompts
Help prompts are visible messages that appear on the upper
oven display on combination oven models or the display on
single oven models. Only Crisping and Broiling help prompts can
be turned off.
Before turning help prompts on/off, the oven(s), Timer and, on
combination oven models, the lower oven Timed Cooking must
be off.
To Turn Off/On: Touch and hold the number pad “2” for
5 seconds. A tone will sound, and either “HELP OFF” or
“HELP ON” will flash on the upper oven display on combination
oven models or the display on single oven models for 3 seconds.
Repeat for desired option.
10
HIGH SPEED COOKING
High Speed Cooking uses the broil element, convection element
and fan and microwaves. All cycle on and off in intervals.
Bakeware and the interior oven surfaces, including the door,
will become hot.
Always use an instant read meat thermometer to determine
doneness of meat and poultry.
Use nonmetallic, ovenproof glass, ceramic or plastic
approved for conventional oven use.
Covers are not necessary unless recommended in recipe.
If recommended, use a casserole dish and its lid for optimal
results.
Do not use covers or containers made of foil, paper, waxed
paper or plastic not recommended for use in a conventional
oven.
When roasting, meats and poultry will spatter. Plastic oven
bags designed for conventional oven use can be used for
easier cleanup. Follow manufacturer’s recommendations.
When using the crisper pan or convection grid, place them
directly on the turntable.
Select tender cuts of meat for optimal cooking results.
Arrange pieces of food in a single layer on the crisper pan or
baking dish.
To Use:
Before high speed cooking, put food in the oven and close the
door. Preheating is not necessary.
1. Touch ULTIMA COOK control.
2. Touch the number pads to enter the food code from the chart.
If “WGT” or “QTY” appears on the display, touch the number
pads to enter the quantity or weight from the chart or touch 0
QUANTITY to increase the weight in increments from the
chart.
3. Touch START or wait 5 seconds for oven to turn on
automatically.
The display will countdown the cook time.
When the cycle ends, “End” will appear in the display. If
enabled, end-of-cycle tones will sound, then reminder tones
will sound every minute.
4. Touch UPPER OVEN CANCEL or CANCEL OFF or open the
oven door when finished cooking to clear the display.
High Speed Cooking Chart
Preset cooking times have been carefully determined, however individual tastes vary. If cooking results are not desirable after the cycle
is over, code number 69 will add 2 additional minutes of cook time. It can be used multiple times. Also, check the food a few minutes
before the cycle ends to help avoid overcooking.
A. Broil element
B. Convection element and fan
C. Dual microwave emission
A
B
C
FOOD CODE QUANTITY OR WEIGHT — INSTRUCTIONS
BISCUITS AND ROLLS
Biscuits, Large, Refrigerated 60 5 or 8. Arrange on crisper pan. Place on turntable.
Biscuits, Small, Refrigerated 59 6 or 12. Arrange on crisper pan. Place on turntable.
Cinnamon Rolls, Large, Refrigerated 62 No quantity entry required. Arrange on crisper pan. Place on turntable.
Cinnamon Rolls, Small, Refrigerated 61 5 or 8. Arrange on crisper pan. Place on turntable.
Orange Sweet Rolls, Refrigerated 63 No quantity entry required. Arrange on crisper pan. Place on turntable.
CASSEROLES
Casserole, Freshly Made 27 4-10 cups (1-2.5 L) in 1 cup (250 mL) increments. Place in casserole dish. Place
convection grid on turntable, then casserole dish on grid.
Entrée, Frozen 29 10-45 oz (283 g-1.3 kg) in 0.5 oz (14 g) increments. Loosen plastic film covering.
Place convection grid on turntable, then entrée on grid.
Lasagna, Freshly Made 28 No quantity entry required. Use recipe that makes about 8 cups (2 L) and an
11" x 7" (28 x 18 cm) baking dish. Place convection grid on turntable, then baking
dish on grid.
CONVENIENCE FOODS, FROZEN
Chicken Breast Tenders 54 5 to 20 pieces. Arrange on crisper pan. Place on turntable.
Chicken Nuggets 55 6 to 26 pieces. Arrange on crisper pan. Place on turntable.
Chicken Wings, Buffalo Hot 49 0.5-1.5 lbs (227-680 g) in 0.25 lb (113 g) increments). Place in baking dish. Place
convection grid on turntable, then baking dish on grid.
11
Dinners 43 6.5-16.5 oz (184-468 g) in 0.5 oz (14 g) increments. Follow package instructions
for venting of plastic film. Place convection grid on turntable, then dinner on grid.
Egg Rolls 47 1 to 8 pieces, 3 oz (85 g) each. Place egg rolls directly on convection grid, then
grid on turntable.
Egg Rolls, Mini 48 6 to 24 pieces. Place egg rolls on crisper pan and crisper pan on turntable.
Entrée 29 10-45 oz (283 g-1.3 kg) in 0.5 oz (14 g) increments. Loosen plastic film covering.
Place convection grid on turntable, then entrée on grid.
Fish Portions, Battered 41 2 to 8 pieces, about 2 oz (57 g) each. Arrange on crisper pan. Place on turntable.
Fish Sticks, Breaded 42 No quantity entry required. Use 4 to 18 pieces. Arrange on crisper pan. Place on
turntable.
French Fries 44 3-12 oz (85-340 g) in 1 oz (28 g) increments. Arrange on crisper pan. Place on
turntable.
Onion Rings 57 4-16 oz (113-454 g) in 1 oz (28 g) increments. Arrange on crisper pan. Place on
turntable.
Pizza 40 6", 9" and 12" (15, 23 and 30 cm) diameter. Arrange on crisper pan. Place on
turntable.
Pizza Rolls, Mini 53 6 to 24 pieces. Arrange on crisper pan. Place on turntable.
Potato Nuggets 46 3-12 oz (85-340 g) in 1 oz (28 g) increments. Arrange on crisper pan. Place on
turntable.
Potato Wedges 45 3-12 oz (85-340 g) in 1 oz (28 g) increments. Arrange on crisper pan. Place on
turntable.
DESSERTS
Baked Apples 37 2 to 8 pieces. Place in baking dish. Place convection grid on turntable, then
baking dish on grid.
Bread Pudding 39 No quantity entry required. Place in 2 qt (2 L) casserole dish. Place convection grid
on turntable, then baking dish on grid.
Brownies 51 No quantity entry required. Use amount of batter for a 9" x 13" (23 x 33 cm) dish.
Spray crisper pan with nonstick cooking spray and dust with dry bread crumbs.
Spread batter into crisper pan. Place crisper pan on turntable.
Cake 50 No quantity entry required. Use amount of batter for a 9" x 13" (23 x 33 cm) dish.
Spray crisper pan with nonstick cooking spray and dust with dry bread crumbs.
Spread batter into crisper pan. Place crisper pan on turntable.
Cookies, Refrigerated Dough 64 No quantity entry required. Drop rounded teaspoonful (5 mL) of cookie dough on
crisper pan. Pan will hold 12 cookies at a time. Place crisper pan on turntable.
Fruit Crisp 38 2 or 3 qts (2 or 3 L). Place in baking dish. Place convection grid on turntable, then
baking dish on grid.
MEATS
Beef
Beef Roast, Boneless 16 1.5-5 lbs (680 g-2.3 kg) in 0.1 lb (45 g) increments. Shake 1 tbs (15 mL) of flour in
oven bag. Put roast in bag and close with plastic tie. Cut 6 small slits in top of bag.
Place in baking dish. Place convection grid on turntable, then baking dish on grid.
Meatballs 20 No quantity entry required. Shape meat mixture into 20, 1¹⁄₂" (4 cm) meatballs.
Place in baking dish. Place convection grid on turntable, then baking dish on grid.
Meat Loaf 18 1.5-2 lbs (680-907 g) of meat in 0.25 lb (113 g) increments. Place meat loaf in a
glass baking dish. Small in a 8.5" x 4.5" (21.5 x 11 cm) dish. Large in a 9" x 5"
(23 x 13 cm) dish. Place convection grid on turntable, then baking dish on grid.
Meat Loaf and 6 Potatoes 19 No quantity entry required. Place meat loaf made with 1.5 lbs (680 g) of meat in an
8¹⁄₂" x 4¹⁄₂" (21.5 x 11 cm) baking dish. Place convection grid on turntable, then
baking dish on grid. Prick skins of potatoes and arrange on grid around the meat
loaf dish.
FOOD CODE QUANTITY OR WEIGHT — INSTRUCTIONS
12
Swiss Steak 17 1-2 lbs (454 g-1 kg) in 0.25 lb (113 g) increments. Follow recipe instructions,
browning meat in a skillet. Place meat in baking dish. Add other recipe ingredients
to dish. Place convection grid on turntable, then baking dish on grid.
Lamb
Leg of Lamb, Boneless 26 1-2.5 lbs (454 g-1 kg) in 0.1 lb (45 g) increments. Shake 1 tbs (15 mL) of flour in
oven bag. Put leg of lamb in bag and close with plastic tie. Cut 6 small slits in top
of bag. Place convection grid on turntable, then baking dish on grid.
Pork
Ham, Fully Cooked, Boneless 25 1-4.5 lbs (454 g-2 kg) in 0.1 lb (45 g) increments . Shake 1 tbs (15 mL) of flour in
oven bag. Put ham and 0.5 cup (125 mL) water in bag. Close with plastic tie and
cut 6 small slits in top of bag. Place in baking dish. Place convection grid on
turntable, then baking dish on grid.
Pork Chops, Bone-in, 3/4" (2 cm) thick 23 0.4-1.5 lbs (181-680 g) in 0.1 lb (45 g) increments. Place in baking dish. Place
convection grid on turntable, then baking dish on grid.
Pork Chops, Boneless, 3/4" (2 cm) thick 24 0.3-1.6 lbs (136 g-2 kg) in 0.1 lb (45 g) increments. Place in baking dish. Place
convection grid on turntable, then baking dish on grid.
Pork Roast, Bone-in 21 2.5-4.5 lbs (1-2 kg) in 0.1 lb (45 g) increments. Shake 1 tbs (15 mL) of flour in oven
bag. Put pork roast in bag and close with plastic tie. Cut 6 small slits in top of bag.
Place in baking dish. Place convection grid on turntable, then baking dish on grid.
Pork Roast, Boneless 22 1-5 lbs (454 g-2.3 kg) in 0.1 lb (45 g) increments. Shake 1 tbs (15 mL) of flour in
oven bag. Put pork roast in bag and close with plastic tie. Cut 6 small slits in top of
bag. Place in baking dish. Place convection grid on turntable, then baking dish on
grid.
POULTRY
Chicken Breasts, Boneless, Skinless 12 0.2-2 lbs (91-907 g) in 0.1 lb (45 g) increments. Place in baking dish. Place
convection grid on turntable, then baking dish on grid.
Chicken Breast Tenders, Frozen 54 5 to 20 pieces. Arrange on crisper pan. Place on turntable.
Chicken Nuggets, Frozen 55 6 to 26 pieces. rrange on crisper pan. Place on turntable.
Chicken Pieces, Bone-in, with Skin 11 0.5-2 lbs (227-907 g) in 0.1 lb (45 g) increments. Place in baking dish. Place
convection grid on turntable, then baking dish on grid.
Chicken Wings, Buffalo Hot, Frozen 49 0.5-1.5 lbs (227-680 g) in 0.25 lb (113 g) increments. Place in baking dish. Place
convection grid on turntable, then baking dish on grid.
Chicken, Whole 10 3-5.5 lbs (1.3-2.5 kg) in 0.1 lb (45 g) increments. Shake 1 tbs (15 mL) of flour in
oven bag. Put chicken in bag and close with plastic tie. Cut 6 small slits in top of
bag. Place in baking dish. Place convection grid on turntable, then baking dish on
grid.
Cornish Hens 15 1.5-4.5 lbs (680 g-2 kg) in 0.1 lb (45 g) increments. Shake 1 tbs (15 mL) of flour in
oven bag. Put hen(s) in bag and close with plastic tie. Cut 6 small slits in top of
bag. Place in baking dish. Place convection grid on turntable and baking dish on
grid.
Turkey Breast, Bone-in 14 2-6.5 lbs (907 g-3 kg) in 0.1 lb (45 g) increments. Shake 1 tbs (15 mL) of flour in
oven bag. Put breast in bag and close with plastic tie. Cut 6 small slits in top of
bag. Place in baking dish. Place convection grid on turntable, then baking dish on
grid. If dish with turkey is too tall, do not use grid.
Turkey, Whole, Unstuffed 13 10-12 lbs (4.5-5.5 kg) in 0.1 lb (45 g) increments. Shake 1 tbs (15 mL) of flour in
oven bag. Put turkey in bag and close with plastic tie. Cut 6 small slits in top of
bag. Place in baking dish. Place convection grid on turntable, then baking dish on
grid. If dish with turkey is too tall, do not use grid.
FOOD CODE QUANTITY OR WEIGHT — INSTRUCTIONS
13
SEAFOOD
Fish Fillets, 3/4" (2 cm) thick 67 0.4-1.2 lbs (181-544 g) in 0.1 lb (45 g) increments. Spray crisper pan with nonstick
cooking spray. Place fish on crisper pan and crisper pan on turntable.
Fish Portions, Battered, Frozen, about 2
oz (57 g) each 41 2 to 8 pieces. Arrange on crisper pan. Place on turntable.
Fish Steaks, 1" (2.5 cm) thick 68 0.3-1.3 lbs (136-590 g) in 0.1 lb (45 g) increments. Spray crisper pan with nonstick
cooking spray. Place fish on crisper pan and crisper pan on turntable.
Fish Sticks, Breaded, Frozen 42 No quantity entry required. Use 4 to 18 pieces. Arrange on crisper pan. Place on
turntable.
Shrimp, Raw, Shelled 52 0.25-1 lbs (113-454 g) in 0.25 lb (113 g) increments. Spray crisper pan with
nonstick cooking spray. Place shrimp on crisper pan and crisper pan on turntable.
VEGETABLES
Baked Potatoes, Large, White 30 1 to 8 potatoes. Pierce skins. Place on convection grid and grid on turntable.
Baked Potatoes, Small-Medium, White 31 1 to 8 potatoes. Pierce skins. Place on convection grid and grid on turntable.
Baked Sweet Potatoes, Large 32 1 to 6 potatoes. Cut off thin, dried ends. Pierce skins. Place on convection grid
and grid on turntable.
Baked Sweet Potatoes,
Small-Medium 33 1 to 6 potatoes. Cut off thin, dried ends. Pierce skins. Place on convection grid
and grid on turntable.
French Fries, Frozen 44 3-12 oz (85-340 g) in 1 oz (28 g) increments. Arrange on crisper pan. Place on
turntable.
Onion Rings, Frozen 57 4-16 oz (113-454 g) in 1 oz (28 g) increments. Arrange on crisper pan. Place on
turntable.
Potato Mixes, Dry, Scalloped or Au
Gratin 35 No quantity entry required. Follow package directions. Place convection grid on
turntable, then baking dish on grid.
Potato Nuggets, Frozen 46 3-12 oz (85-340 g) in 1 oz (28 g) increments. Arrange on crisper pan. Place on
turntable.
Potato Skins 65 No quantity entry required. Bake 1.5 lbs (680 g) potatoes. Scoop out insides
leaving a 3/8" (1 cm) shell. Brush both sides with butter. Place skins on crisper pan
and crisper pan on turntable. With 1 minute of cooking time remaining, add
toppings if desired.
Potato Wedges, Frozen 45 3-12 oz (85-340 g) in 1 oz (28 g) increments. Arrange on crisper pan. Place on
turntable.
Roasted Potatoes, Coating Mix,
3¹⁄₂ cups (875 mL) cubed potatoes 34 No quantity entry required. Follow coating mix package directions. Place in baking
dish. Place convection grid on turntable, then baking dish on grid.
Roasted Vegetables 36 2-8 cups (500 mL-2 L) in 1 cup (250 mL) increments. Cut fresh vegetables in bite-
size pieces. Toss with olive or cooking oil and seasonings. Place in baking dish.
Place convection grid on turntable, then baking dish on grid.
MISCELLANEOUS
Cook 2 minutes longer 69 No quantity entry required. Gives 2 more minutes of cooking time. Use this code
to finish cooking foods not done to your liking. May be used more than once.
Hot Dogs 56 2 to 10 pieces, 0.1 lb (45 g) each. Arrange on crisper pan. Place on turntable.
Nachos 58 No quantity entry required. Use 8 oz (227 g) chips, salsa, cheese and other
toppings to create your own nachos. Place in baking dish. Place convection grid
on turntable, then baking dish on grid.
Pizza Reheat 66 1 to 4 pieces. Place pizza slices on crisper pan and crisper pan on turntable.
FOOD CODE QUANTITY OR WEIGHT — INSTRUCTIONS
14
MICROWAVE OVEN USE
A magnetron in the oven produces microwaves which reflect off
the metal floor, walls and ceiling and pass through the turntable
and appropriate cookware to the food. Microwaves are attracted
to and absorbed by fat, sugar and water molecules in the food,
causing them to move, producing friction and heat which cooks
the food.
Do not lean on or allow children to swing on the oven door.
Do not operate microwave oven when it is empty.
The turntable must be in place and correct side up when
oven is in use. Do not use if turntable is chipped or broken.
See “Assistance or Service” section to reorder.
Baby bottles and baby food jars should not be heated in
microwave oven.
Clothes, flowers, fruit, herbs, wood, gourds, paper, including
brown paper bags and newspaper should not be dried in
microwave oven.
Do not use the microwave oven for canning, sterilizing or
deep frying. The oven cannot maintain appropriate
temperatures.
Paraffin wax will not melt in the oven because it does not
absorb microwaves.
Use oven mitts or pot holders when removing containers from
microwave oven.
Do not overcook potatoes. At the end of the recommended
cook time, potatoes should be slightly firm. Let potatoes
stand for 5 minutes. They will finish cooking while standing.
Do not cook or reheat whole eggs inside the shell. Steam
buildup in whole eggs may cause them to burst. Cover
poached eggs and allow a standing time.
Food Characteristics
When microwave cooking, the amount, size and shape, starting
temperature, composition and density of the food affect cooking
results.
Amount of Food
The more food heated at once, the longer the cook time. Check
for doneness and add small increments of time if necessary.
Size and Shape
Smaller pieces of food will cook more quickly than larger pieces,
and uniformly shaped foods cook more evenly than irregularly
shaped food.
Starting Temperature
Room temperature foods will heat faster than refrigerated foods,
and refrigerated foods will heat faster than frozen foods.
Composition and Density
Foods high in fat and sugar will reach a higher temperature and
heat faster than other foods. Heavy, dense foods, such as meat
and potatoes, require a longer cook time than the same size of a
light, porous food, such as cake.
Cooking Guidelines
Covering
Covering food helps retain moisture, shorten cook time and
reduce spattering. Use the lid supplied with cookware. If a lid is
not available, wax paper, paper towels or plastic wrap approved
for microwave ovens may be used. Plastic wrap should be turned
back at one corner to provide an opening to vent steam.
Condensation on the door and cavity surfaces is normal during
heavy cooking.
Stirring and Turning
Stirring and turning redistributes heat evenly to avoid
overcooking the outer edges of food. Stir from outside to center.
If possible, turn food over from bottom to top.
Arranging
If heating irregularly shaped or different sized foods, the thinner
parts and smaller sizes should be arranged toward the center. If
cooking several items of the same size and shape, place them in
a ring pattern, leaving the center of the ring empty.
Piercing
Before heating, use a fork or small knife to pierce or prick foods
that have a skin or membrane, such as potatoes, egg yolks,
chicken livers, hot dogs, and sausage. Prick in several places to
allow steam to vent.
Shielding
Use small, flat pieces of aluminum foil to shield the thin pieces of
irregularly shaped foods, bones and foods such as chicken
wings, leg tips and fish tail. See “Aluminum Foil and Metal” first.
Standing Time
Food will continue to cook by the natural conduction of heat even
after the microwave cycle ends. The length of standing time
depends on the volume and density of the food.
15
Cookware and Dinnerware
Cookware and dinnerware must fit on the turntable. Always use
oven mitts or pot holders when handling because any dish may
become hot from heat transferred from the food. Do not use
cookware and dinnerware with gold or silver trim. Use the
following chart as a guide, then test before using.
To Test Cookware or Dinnerware for Microwave Use:
1. Put cookware or dinnerware in oven with 1 cup (250 mL) of
water beside it.
2. Cook at 100% cooking power for 1 minute.
Do not use cookware or dinnerware if it becomes hot and the
water stays cool.
Aluminum Foil and Metal
Always use oven mitts or pot holders when removing dishes from
the microwave oven.
Aluminum foil and some metal can be used in the oven. If not
used properly, arcing (a blue flash of light) can occur and cause
damage to the oven.
OK for Use
Racks and bakeware supplied with the oven (on some models),
aluminum foil for shielding, and approved meat thermometers
may be used with the following guidelines:
Do not allow aluminum foil or metal to touch the inside cavity
walls, ceiling or floor.
Always use the turntable.
Do not allow contact with another metal object during
cooking.
Do Not Use
Metal cookware and bakeware, gold, silver, pewter, non-
approved meat thermometers, skewers, twist ties, foil liners such
as sandwich wrappers, staples and objects with gold or silver
trim or a metallic glaze should not be used in the oven.
MATERIAL RECOMMENDATIONS
Aluminum Foil,
Metal See “Aluminum Foil and Metal” section.
Browning Dish Bottom must be at least ³⁄₁₆" (5 mm) above
the turntable. Follow manufacturer’s
recommendations.
Ceramic Glass,
Glass Acceptable for use.
China,
Earthenware Follow manufacturer’s recommendations.
Melamine Follow manufacturer’s recommendations.
Paper Towels,
Dinnerware,
Napkins
Use nonrecycled and those approved by
the manufacturer for microwave oven use.
Plastic Wraps,
Bags, Covers,
Dinnerware,
Containers
Use those approved by the manufacturer
for microwave oven use.
Pottery and Clay Follow manufacturer’s recommendations.
Styrofoam* Do not use in oven.
Straw, Wicker,
Wooden
Containers
Do not use in oven.
Wax Paper Acceptable for use.
16
Cooking Power
Many recipes for microwave cooking specify which cooking
power to use by percent, name or number. For example,
70%=7=Medium-High.
Use the following chart as a general guide for the suggested
cooking power of specific foods.
Cooking
To Use:
1. Touch the number pads to set a length of time to cook.
If using 100% cook power, skip to Step 3.
2. Touch MICRO •• COOK POWER or UPPER •• COOK
POWER then enter the desired power level. See “Cooking
Power” chart.
3. Touch START.
The display will count down the cook time.
When the cycle ends, “End” will appear in the display, 4 end-
of-cycle tones will sound, and then reminder tones will sound
every minute.
4. Touch UPPER OVEN CANCEL or CANCEL OFF or open the
door to clear the display and/or stop reminder tones.
The cook time and cooking power can be changed after touching
START without interrupting cooking.
To Change Cook Time: Touch MICRO •• COOK POWER or
UPPER •• COOK POWER once. Enter the new cook time within
5 seconds. Touch START, or wait 5 seconds and the change will
be entered automatically.
To Change Cooking Power: Touch MICRO •• COOK POWER or
UPPER •• COOK POWER twice. Enter the new cook power
within 5 seconds. Touch START, or wait 5 seconds and the
change will be entered automatically.
Cooking in Stages
The microwave oven can be set to cook at different cooking
powers for various lengths of time, up to 3 stages.
To Cook in Stages:
1. Touch the number pads to set a length of cook time for the
first stage.
2. Touch MICRO •• COOK POWER or UPPER •• COOK
POWER and then enter a cook power (if other than 100%)
from the Cook Power Chart.
3. Touch MICRO •• COOK POWER or UPPER •• COOK
POWER to start programming next stage.
4. Repeat the above steps for second- and third-stage
programming.
The numbers “1,” “2” and/or “3” will appear in the upper oven
display during programming.
5. Touch START when cook times and cook powers have been
entered.
The upper oven display will count down each of the cook
times. The numbers “1,” “2” or “3” will appear in the display
during their respective stages.
When the cycle ends, “End” will appear in the display, 4 end-
of-cycle tones will sound, and then reminder tones will sound
every minute.
Cook time may be changed during any cycling stage by
touching MICRO •• COOK POWER or UPPER •• COOK
POWER once, and then entering the new time within
5 seconds. Time may be added in one-minute increments by
touching EASY MINUTE (START) during the cycling stage.
6. Touch UPPER OVEN CANCEL or CANCEL OFF or open the
door to clear the display and/or stop reminder tones.
PERCENT/
NAME NUMBER USE
100%, High
(default setting) 10 Quick heating convenience
foods and foods with high water
content, such as soups,
beverages and most
vegetables.
90% 9 Cooking small tender pieces of
meat, ground meat, poultry
pieces and fish fillets.
Heating cream soups.
80% 8 Heating rice, pasta or
casseroles.
Cooking and heating foods that
need a cook power lower than
high. For example, whole fish
and meat loaf.
70%,
Medium-High 7 Reheating a single serving of
food.
60% 6 Cooking sensitive foods such as
cheese and egg dishes,
pudding and custards.
Cooking non-stirrable
casseroles, such as lasagna.
50%, Medium 5 Cooking ham, whole poultry and
pot roasts.
Simmering stews.
40% 4 Melting chocolate.
Heating bread, rolls and
pastries.
30%, Medium-
Low, Defrost 3 Defrosting bread, fish, meats,
poultry and precooked foods.
20% 2 Softening butter, cheese, and
ice cream.
10%, Low 1 Taking chill out of fruit.
17
Crisper Pan Frying
When the crisper pan is used with microwaves, it is like a frying
pan or griddle, ideal for French toast, burgers, eggs, stir-frying
and sautéing. See “Crisper Pan and Handle” section first before
using.
To Use:
Before crisper pan frying, brush crisper pan with 1/2 tsp (3 mL) of
oil or spray with nonstick cooking spray. Arrange food on crisper
pan. Place pan on turntable.
1. Touch the number pads to set a length of time to cook.
2. Touch START.
The display will countdown the cook time.
When the cycle ends, “End” will appear in the display. If
enabled, end-of-cycle tones will sound, then reminder tones
will sound every minute.
3. Touch UPPER OVEN CANCEL or CANCEL OFF or open the
door to clear the display and/or stop reminder tones.
CRISPER PAN FRYING CHART
Times are approximate and may be adjusted for individual tastes.
Custom Reheat
Times and cooking powers have been preset for reheating 8 food
types. Use the following chart as a guide.
*Four tones will sound at the midpoint of the reheat cycle, and
“STIR” will appear in the display. Stir food if desired, close door,
and touch START.
To Reheat Foods:
1. Touch CUSTOM REHEAT.
Touch number pad to select food type from the Custom
Reheat chart.
or
Touch CUSTOM REHEAT repeatedly to scan and select food
settings. For example, to select the Bread setting, CUSTOM
REHEAT must be touched twice.
2. Touch number pads to enter quantity (in servings, slices or
cups)
or
Touch QUANTITY (number pad “0”) to scan and select
quantities. For example, to select the quantity of 2 servings,
QUANTITY must be touched twice.
3. Touch START or wait 5 seconds and the microwave oven will
start automatically.
The upper oven display will count down the reheat time.
When the cycle ends, “End” will appear in the display, 4 end-
of-cycle tones will sound, and then reminder tones will sound
every minute.
4. Touch UPPER OVEN CANCEL or CANCEL OFF or open the
door to clear the display and/or stop reminder tones.
FOOD COOKTIME INSTRUCTIONS
Bacon, Canadian
2¹⁄₄" (6 cm) thick
slices
1 min Turn slices over on
crisper pan after
cooking.
Eggs, scrambled
2
445 sec to 1 min
2 to 3 min
Mix 1 tbs of water
per egg and pour
into preheated pan.
French Toast,
Pancakes, Waffles,
4 Frozen
3 to 4 min Turn halfway
through cooking.
Ground Beef,
1 lb (454 g) 6 to 7 min Crumble meat
before cooking. Stir
halfway through
cooking. Make sure
no pink center.
Ground Beef
Patties, two 4 oz
(113 g) patties
Side 1: 2 min
Side 2: 2-4 min Cook completely,
no pink center.
Pizza Dough,
uncooked
9" and 12" (23 and
30 cm)
4 to 5 min Sprinkle with corn
meal. Press dough
into pan. After
precooking dough,
add sauce and
toppings.
Vegetables,
stir-fry, 2 cups
(500 mL)
4 min Cut vegetables in
equal sizes. Stir
after 2 minutes.
FOOD CODE QUANTITY
Dinner Plate 1 1 to 2 servings
Bread 2 1 to 6 slices
Meats 3 1 to 6 servings
Cheese Dip* 4 1 to 3 cups (250 - 750 mL)
Soup* 5 1 to 4 cups (250 mL-1 L)
Sauce* 6 1 to 3 cups (250 - 750 mL)
Pizza 7 1 to 2 servings
Beverage
1 Coffee
2 Tea
3 Hot Chocolate
8 Serving Temperature
1 Warm
2 Hot
3 Very Hot
18
To Reheat Beverages:
1. Touch CUSTOM REHEAT.
2. Touch number pad “8”
or
Touch CUSTOM REHEAT repeatedly until the Beverages
setting, “BEVRG-8” is reached.
3. Touch number pad from chart to select beverage type.
4. Touch number pad from chart to select serving temperature.
5. Touch START or wait 5 seconds and the microwave oven will
start automatically.
The upper oven display will count down the reheat time.
When the cycle ends, “End” will appear in the display, 4 end-
of-cycle tones will sound, and then reminder tones will sound
every minute.
IMPORTANT: Heated liquids can splash out during and after
heating. A wooden stir stick placed in the cup or bowl during
heating may help avoid this.
6. Touch UPPER OVEN CANCEL or CANCEL OFF or open the
door to clear the display and/or stop reminder tones.
For more information on reheating different foods using the
manual microwave function, see “MICROWAVE CUSTOM
REHEAT CHART” at the end of the “MICROWAVE OVEN USE”
section.
Custom Defrost
The Custom Defrost feature can be used, or the microwave oven
can be manually set to defrost by using 30% cook power.
Food should be 0°F (-18°C) or colder at defrosting for optimal
results.
Unwrap foods and remove lids (from fruit juice) before
defrosting.
Shallow packages will defrost more quickly than deep blocks.
Separate food pieces as soon as possible during or at the
end of the cycle for more even defrosting.
Foods left outside the freezer for more than 20 minutes or
frozen ready-made food should not be defrosted using the
Custom Defrost feature, but should be defrosted manually.
Use small pieces of aluminum foil to shield parts of food such
as chicken wings, leg tips and fish tails. See “Aluminum Foil
and Metal” first.
CUSTOM DEFROST CHART
The Custom Defrost system has six categories: Meat, Poultry,
Fish, Bagel, Fruit Juice, and Roll/Muffin. Use the following chart
as a guide.
*See Preparation chart at end of “Custom Defrost” section for
cuts, sizes, and instructions.
**Bagel quantity settings 1 and 2 may appear to have longer
defrost times than necessary. However, longer times use less
cooking power.
To use Custom Defrost:
1. Touch CUSTOM DEFROST.
2. Touch the number pad from the Custom Defrost chart to
select food
or
Touch CUSTOM DEFROST repeatedly to scroll through
foods.
3. Touch number pads from the Custom Defrost chart to select
the weight or quantity
or
Touch QUANTITY (number pad “0”) repeatedly to select
quantity.
4. Touch START or wait 5 seconds and the microwave oven will
start automatically.
The display will count down the defrost time. For better
results, a preset standing time is included in the defrosting
time. This may make the defrosting time seem longer than
expected.
When the cycle ends, “End” will appear in the display, 4 end-
of-cycle tones will sound, and then reminder tones will sound
every minute.
5. Touch UPPER OVEN CANCEL or CANCEL OFF or open the
door to clear the display.
The cook time can be changed during the defrosting cycle
without interrupting cooking.
To Change Defrost Time: Touch MICRO •• COOK POWER or
UPPER •• COOK POWER repeatedly to scroll through “MORE,
“LESS” or “NORML” time.
FOOD
SETTING CODE WEIGHT OR QUANTITY
Meats* 1 0.1 to 6.6 lbs (45 g to 3 kg)
Poultry* 2 0.1 to 6.6 lbs (45 g to 3 kg)
Fish* 3 0.1 to 4.4 lbs (45 g to 1.34 kg)
Bagel** 4 1 to 6 pieces
Fruit Juice 5 6, 12 or 16 oz (170, 340 or 454 g)
Roll/Muffin 6 1 to 6 pieces
19
MEAT, POULTRY AND FISH DEFROST PREPARATION
Use the following chart as a guide when defrosting meat, poultry,
or fish. When setting the Custom Defrost cycle, the net weight
must be entered in pounds and tenths of pounds.
Popcorn
Do not use regular paper bags or glassware.
Pop only one package of popcorn at a time.
Follow manufacturer’s instructions when using a microwave
popcorn popper.
Listen for popping to slow to 1 pop every 1 or 2 seconds,
then stop the cycle. Do not repop unpopped kernels.
Use fresh bags of popcorn for optimal results.
Cooking results may vary by brand and fat content.
Popping time has been preset based on commercially packaged
microwave popcorn. The oven is preset for the 3.5 oz (99 g) size,
but can be changed. Use the following chart as a guide.
To Pop Popcorn:
1. Touch POPCORN (3 SIZES).
The microwave oven will be set to automatically begin the
pop setting for the 3.5 oz (99 g) bag size.
Touch POPCORN (3 SIZES) repeatedly to scan and select
bag size
or
Touch number pad from chart to manually select bag size.
2. Touch START or wait 5 seconds for the popping to begin
automatically.
The upper oven display will count down the popping time.
Time may be added to popping time by touching EASY
MINUTE (START) during or after popping.
When the popcorn cycle ends, “End” will appear in the
display, 4 end-of-cycle tones will sound, and then reminder
tones will sound every minute.
3. Touch UPPER OVEN CANCEL or CANCEL OFF or open the
door to clear the display and/or stop reminder tones.
Keeping Food Warm
Hot cooked food can be kept warm in the microwave oven.
Foods that are cooked covered and complete meals on dinner
plates should be covered while being kept warm. Pastry items
such as pies and turnovers should be uncovered while being
kept warm.
To Keep Food Warm:
1. Touch number pads to set length of warm time.
2. Touch MICRO •• COOK POWER or UPPER •• COOK
POWER.
3. Touch number pad “1” to set cook power at 10%.
4. Touch START.
The upper oven display will count down the warm time.
When the cycle ends, “End” will appear in the display, 4 end-
of-cycle tones will sound, and then reminder tones will sound
every minute.
5. Touch UPPER OVEN CANCEL or CANCEL OFF or open the
door to clear the display.
To program a warm time at the end of a cooking cycle, set the
time and the cook power (10%) as the last cooking stage. See
“Cooking in Stages” section.
MEAT
Beef: ground, steaks, roast,
stew The narrow or fatty areas of
irregular shaped cuts should
be shielded with foil before
defrosting.
Do not defrost less than 1/4 lb
(113 g) or two 4 oz (113 g)
patties.
Place all meats in
microwavable baking dish.
Lamb: stew and chops
Pork: chops, ribs, roasts,
sausage
POULTRY
Chicken: whole and cut up Place in microwavable baking
dish, chicken breast side up.
Remove giblets from whole
chicken.
Cornish hens
Turkey: breast
FISH
Fillets, Steaks, Whole,
Shellfish Place in microwavable baking
dish.
BAG SIZE CODE TOUCH PAD
3.5 oz (99 g) 1 Once
3.0 oz (85 g) 2 Twice
1.75 oz (50 g) 3 Three times
WARNING
Food Poisoning Hazard
Do not let food sit in oven more than one hour
before or after cooking.
Doing so can result in food poisoning or
sickness.
20
Crisp
The Crisp feature uses the broil element and microwaves to crisp
and brown foods. Crisp can be used to saute meats and
vegetables, pan-fry bacon and eggs, and to crisp and brown
pizza and cheese sandwiches. Always use the crisper pan. See
the “Crisper Pan and Handle” section before using.
To Crisp:
Before Crisping, brush crisper pan with 1/2 tsp (3 mL) of oil or
spray with nonstick cooking spray. Arrange food on crisper pan,
and place pan on turntable.
1. Touch CRISP.
2. Touch the number pads to enter a length of time to cook in
minutes and seconds. The time can be set up to 90 minutes.
3. Touch START.
The “USE PAN” prompt will appear in the upper oven display
for 4 seconds, then the display will count down the cook
time.
Time may be added during cooking by touching EASY
MINUTE ( START).
When the cycle ends, “End” will appear in the display, 4 end-
of-cycle tones will sound, and then reminder tones will sound
every minute.
4. Touch UPPER OVEN CANCEL or CANCEL OFF or open the
door to clear the display.
The “USE PAN” prompt may be disabled by touching and holding
the number pad “2” for 5 seconds. Repeat to re-enable.
CRISPING CHART
Times are approximate and may be adjusted for individual tastes.
Broil
The Broil feature uses the broil element to cook and brown 1 to
4 small pieces of food at a time. Always use the broiling grid. The
Crisper Pan may be used with the Broil function to catch
drippings from the food. See “Grids” section before using.
Avoid opening the door often.
For even browning, turn food over halfway through cooking.
Before Broiling:
The turntable hub must be removed to prevent the turntable from
rotating during broiling. See “Turntable” section for hub location.
Remove the turntable, lift out the hub, and then replace the
turntable on the support. The turntable must be in place during
broiling, but it should not rotate.
To Broil:
1. Preheat the broil element by touching BROIL and setting a
broil time of 2-3 minutes.
2. After preheating, place food on the grid and position the grid
on the turntable so that all of the food is directly under the
broil element.
3. Touch BROIL.
4. Touch the number pads to enter a length of time to broil in
minutes and seconds, up to 90 minutes.
5. Touch START.
The “USE GRID” prompt will appear in the upper oven display
for 4 seconds, then the display will count down the cook
time.
Time may be added during cooking by touching EASY
MINUTE (START).
When the cycle ends, “End” will appear in the display, 4 end-
of-cycle tones will sound, and then reminder tones will sound
every minute.
6. Touch UPPER OVEN CANCEL or CANCEL OFF or open the
door to clear the display.
The “USE GRID” prompt may be disabled by touching and
holding the number pad “2” for 5 seconds. Repeat to re-enable.
BROILING CHART
Times are approximate and may be adjusted for individual tastes.
FOOD COOK TIME PREPARATION
Pizza, refrigerated
or fresh
12" (30 cm)
9" (23 cm) 9 min
7 min
Sprinkle crisper pan
with corn meal. Add
additional time for
thick crust and reduce
time for thin crust.
Puff Pastry Fruit
Turnovers, 4 Frozen 10-12 min
Turkey Breast,
boneless 10-12 min per
1lb (454 g) Place turkey in center
of crisper pan. Internal
temperature should be
170°F (77°C).
A. Broil element
B. Broiling grid
C. Crisper pan
FOOD COOK TIME PREPARATION
Garlic Toast or
Open Face
Sandwiches
2 to 3 min
Steaks, 2 top
sirloin, 3/4" (2 cm)
thick, 8 oz (227 g)
portions
Medium doneness
Side 1: 10 min
Side 2: 8 min
Trim excess fat and
score edges. Let
stand 1 min before
serving.
A
B
C
21
Convection Cooking
Convection cooking uses the convection element (on some
models) and the fan. Hot air is circulated throughout the oven
cavity by the fan. The constantly moving air surrounds the food to
heat the outer portion quickly.
The convect function may be used to cook small amounts of food
on a single rack.
Always use the convection grid.
Do not cover turntable or convection grid with aluminum foil.
Do not use light plastic containers, plastic wrap or paper
products. All heatproof cookware or metal utensils can be
used in convection cooking, but metal utensils cannot be
used in microwave cooking. Round pizza pans are excellent
for convection cooking.
Use convection cooking for items such as souffles, breads,
cookies, angel food cakes, pizza, and most meats and fish.
No special techniques are needed to adapt standard oven
recipes to convection cooking, although some temperatures
might need to be reduced, and some cooking times might
need to be shortened.
This oven may be preheated in the same way that standard
oven is preheated. (Most recipes for baked goods call for
preheating.)
To Convect Cook with Preheat:
1. Position convection grid on turntable in microwave oven and
close the door.
2. Touch CONVECT QUICK PREHEAT twice.
“PREHEAT” will appear in the upper oven display.
Touch the number pads to set a temperature other than
325°F (162°C). The cook temperature setting may be
changed as desired from 170°F to 450°F (77°C to 232°C).
Celsius temperatures below 100°C must have a “0” at the
beginning of their entries. For example, 77°C must be entered
as 0-7-7.
3. Touch START.
The upper oven display will show the “TIME” prompt.
4. Touch number pads to enter length of time to cook, in hours
and minutes, up to 4 hours.
5. Touch START.
“Lo” will appear in the upper oven display until the
temperature reaches 170°F (77°C). When that temperature is
reached, the display will show the preheating temperature in
5°F (-15°C) increments until the set cooking temperature is
reached.
When preheating is complete, one tone will sound, and the
display will show the set cook time.
6. Place food or bakeware on convection grid and close the
door.
7. Touch START.
The upper oven display will count down the cook time.
Each time the door is opened during cooking, the START pad
must be touched to restart cooking.
When the cycle ends, “End” will appear in the display, 4 end-
of-cycle tones will sound, and then reminder tones will sound
every minute.
8. Touch UPPER OVEN CANCEL or CANCEL OFF or open the
door to clear the display.
To Convect Cook without Preheat:
1. Position convection grid on turntable in microwave oven,
place food or bakeware on convection grid, and close the
door.
2. Touch CONVECT QUICK PREHEAT once.
Touch the number pads to set a temperature other than
325°F (162°C). The cook temperature setting may be
changed as desired from 170°F to 450°F (77°C to 232°C).
Celsius temperatures below 100°C must have a “0” at the
beginning of their entries. For example, 77°C must be entered
as 0-7-7.
3. Touch START.
The upper oven display will show the “TIME” prompt.
4. Touch number pads to enter length of time to cook, in hours
and minutes, up to 4 hours.
5. Touch START.
The upper oven display will count down the cook time.
Each time the door is opened during cooking, the START pad
must be touched to restart cooking.
When the cycle ends, “End” will appear in the display, 4 end-
of-cycle tones will sound, and then reminder tones will sound
every minute.
6. Touch UPPER OVEN CANCEL or CANCEL OFF or open the
door to clear the display.
A. Broil element
B. Convection fan
C. Convection element
(on some models)
D. Convection grid
A
B
C
D
22
MICROWAVE COOK CHART
These times are approximate and may need to be adjusted to suit individual taste.
FOOD COOK TIME (in min and sec) COOK POWER
Meats, Poultry, Fish, Seafood
Bacon (per slice) 0:45-1:15 per slice 100%
Ground Beef for Casseroles (1 lb [0.45 kg]) 4:00-6:00 100%
Ground Beef Patties (2)
Ground Beef Patties (4) Side 1: 2:00, Side 2: 1:30-2:00
Side 1: 2:30, Side 2: 2:00-3:00 100%
100%
Meat Loaf (1¹⁄₂ lbs [0.7 kg]) 13:00-19:00 70%
Chicken Pieces
Internal temperature should be 185ºF (85ºC) after standing. 6:00-9:00 per 1 lb (454 g) 100%
Turkey Breast
Internal temperature should be 185ºF (85ºC) after standing. 5:00, then
8:00-12:00 100%,
70%
Fish Fillets (1 lb [0.45 kg]) 5:00-6:00 100%
Scallops and Shrimp (1 lb [0.45 kg]) 3:30-5:30 100%
Vegetables
Beans, Green or Yellow (1 lb [0.45 kg]) 6:00-12:00 100%
Broccoli (1 lb [0.45 kg]) 6:00-10:00 100%
Carrots (1 lb [0.45 kg]) 8:00-12:00 100%
Cauliflower (medium head) 6:00-9:00 100%
Corn on the Cob (2)
Corn on the Cob (4) 4:00-9:00
6:00-16:00 100%
100%
Potatoes, Baked (4 medium) 13:00-19:00 100%
Summer Squash (1 lb [0.45 kg]) 3:00-8:00 100%
Other
Applesauce (4 servings) 7:00-9:00 100%
Baked Apples (4) 4:00-6:00 100%
Chocolate (melt 1 square) 1:00-2:00 50%
Eggs, Scrambled (2)
Eggs, Scrambled (4) 1:15-1:45
2:00-3:00 100%
100%
Hot Cereals (1 serving)
Hot Cereals (4 servings) 1:30-5:00
4:30-7:00 100%
100%
Nachos (large plate) 1:30-2:30 50%
Water for Beverage (1 cup [250 mL])
Water for Beverage (2 cups [500 mL]) 2:30-4:00
4:30-6:00 100%
100%
23
MICROWAVE REHEAT CHART
These times are approximate and may need to be adjusted to suit individual taste. If using Broil to reheat, do not cover food.
FOOD/STARTING TEMPERATURE COOK TIME (in min and sec) COOK POWER PREPARATION
Meat (Chicken pieces, chops, hamburgers,
meat loaf slices)
1 serving, refrigerated
2 servings, refrigerated 1:00-2:00
2:30-4:30 70%
70%
Cover loosely.
Meat Slices (Beef, ham, pork, turkey)
1 or more servings, room temp.
1 or more servings, refrigerated 0:45-1:00 per serving
1:00-3:00 per serving 50%
50%
Cover with gravy or wax paper.
Check after 30 sec per serving.
Stirrable Casseroles and Main Dishes
1 serving, refrigerated
2 servings, refrigerated
4-6 servings, refrigerated
2:00-4:00
4:00-6:00
6:00-8:00
100%
100%
100%
Cover. Stir after half the time.
Non-stirrable Casseroles and Main Dishes
1 serving, refrigerated
2 servings, refrigerated
4-6 servings, refrigerated
5:00-8:00
9:00-13:00
13:00-16:00
50%
50%
50%
Cover with wax paper.
Soup, Cream
1 cup (250 mL), refrigerated
1 can (10 oz [284 mL]), room temp. 3:00-4:30
5:00-7:00 50%
50%
Cover. Stir after half the time.
Soup, Clear
1 cup (250 mL), refrigerated
1 can (10 oz [284 mL]), room temp. 2:30-3:30
4:00-5:30 100%
100%
Cover. Stir after half the time.
Pizza (Medium slice)
1 slice, room temp.
2 slices, room temp.
1 slice, refrigerated
2 slices, refrigerated
0:15-0:25
0:30-0:40
0:30-0:40
0:45-0:55
100%
100%
100%
100%
Vegetables
1 serving, refrigerated
2 servings, refrigerated 0:45-1:30
1:30-2:30 100%
100%
Cover. Stir after half the time.
Baked Potato
1, refrigerated
2, refrigerated 1:00-2:00
2:00-3:00 50%
50%
Cut lengthwise, then several
times crosswise. Cover with wax
paper.
Breads (Dinner or breakfast roll)
1 roll, room temp.
2 rolls, room temp.
4 rolls, room temp.
0:08-0:12
0:11-0:15
0:18-0:22
50%
100%
100%
Wrap single piece in paper towel.
Place several pieces on paper
towel, then cover with another
paper towel.
Pie
Whole, refrigerated
1 slice, refrigerated 5:00-7:00
0:30 70%
100%
24
OVEN CARE
General Cleaning
IMPORTANT: Before cleaning, make sure all controls are off and
the oven is cool. Always follow label instructions on cleaning
products.
Soap, water and a soft cloth or sponge are suggested first unless
otherwise noted.
STAINLESS STEEL (on some models)
Do not use soap-filled scouring pads, abrasive cleaners, Cooktop
Polishing Creme, steel-wool pads, gritty washcloths or some
paper towels. Damage may occur.
Rub in direction of grain to avoid damaging.
Stainless Steel Cleaner & Polish (not included):
See “Assistance or Service” section to order.
Liquid detergent or all-purpose cleaner:
Rinse with clean water and dry with soft, lint-free cloth.
Vinegar for hard water spots
OVEN DOOR EXTERIOR
Glass cleaner and paper towels or nonabrasive plastic
scrubbing pad:
Apply glass cleaner to soft cloth or sponge, not directly on
panel.
OVEN CAVITY
Do not use soap-filled scouring pads, abrasive cleaners, steel-
wool pads, gritty washcloths or some recycled paper towels.
Damage may occur.
On stainless steel models, rub in direction of grain to avoid
damaging.
The area where the oven door and frame touch when closed
should be kept clean.
Average soil
Mild, nonabrasive soaps and detergents:
Rinse with clean water and dry with soft, lint-free cloth.
Heavy soil
Mild, nonabrasive soaps and detergents:
Heat 1 cup (250 mL) of water for 2 to 5 minutes in oven.
Steam will soften soil. Rinse with clean water and dry with
soft, lint-free cloth.
Odors
Lemon juice or vinegar:
Heat 1 cup (250 mL) of water with 1 tbs (15 mL) of either
lemon juice or vinegar for 2 to 5 minutes in oven.
TURNTABLE
Replace turntable immediately after cleaning. Do not operate the
microwave oven without the turntable in place.
Mild cleanser and scouring pad
Dishwasher
GRIDS
Steel-wool pad
Dishwasher
CRISPER PAN
Mild cleanser and scouring sponge
Dishwasher
25
TROUBLESHOOTING
Try the solutions suggested here first in order to avoid the cost of an unnecessary service call.
Nothing will operate
Has a household fuse blown, or has a circuit breaker
tripped?
Replace the fuse or reset the circuit.
Is the appliance wired properly?
See Installation Instructions.
Oven will not operate
Is the door completely closed?
Firmly close door.
Is the electronic oven control set correctly?
See “Electronic Oven Control” section.
On some models, is the Control Lock set?
See “Control Lock” section.
On some models, is the Sabbath Mode set?
See “Sabbath Mode” section.
On combination oven models, is the lower oven self-
cleaning?
The upper oven will not work during the lower oven Self-
Cleaning Cycle.
Is the magnetron working properly?
Try to heat 1 cup (250 mL) of cold water for 2 minutes at
100% cooking power. If water does not heat, call for service.
See “Assistance or Service” section.
Oven makes humming noise
This is normal and occurs when the transformer in the
magnetron cycles on.
Oven door looks wavy
This is normal and will not affect performance.
Turntable will not operate
Is the turntable properly in place?
Make sure turntable is correct side up and is sitting securely
on the turntable support.
Is the turntable support operating properly?
Remove turntable. Remove and replace turntable support.
Replace turntable. Place 1 cup (250 mL) of water on the
turntable, then restart oven. If it still is not working, call for
service. See “Assistance or Service” section. Do not operate
the oven without turntable and turntable support working
properly.
Turntable rotates both directions
This is normal and depends on motor rotation at beginning of
cycle.
Display shows messages
Is the display showing “PF”, “PF id=27” or “PF id=30”?
There has been a power failure. Clear the display. See
“Display(s)” section. On some models, reset the clock, if
needed. See “Clock” section.
Is the display showing a letter followed by a number?
Clear the display. See “Display(s)” section. If it reappears, call
for service. See “Assistance or Service” section.
Display shows time countdown, but is not operating
Is the Timer in use?
See “Timer” section.
Tones are not sounding
Are tones disabled?
See “Tones” section.
Smoke is coming from oven vent during broiling
Some smoke is normal and occurs just as in conventional
broiling.
Sparking during broiling
This is normal and occurs as fat burns off from past cooking.
Sparking will stop once fat is completely burned off.
Cooking times seem too long
Is the cooking power set properly?
See “Cooking Power” in “Microwave Oven Use” section.
Are large amounts of food being heated?
Larger amounts of food need longer cooking times.
Is the incoming voltage less than specified in “Parts and
Features”?
Have a qualified electrician check the electrical system of the
house.
26
ASSISTANCE OR SERVICE
Before calling for assistance or service, please check
“Troubleshooting.” It may save you the cost of a service call. If
you still need help, follow the instructions below.
When calling, please know the purchase date and the complete
model and serial number of your appliance. This information will
help us to better respond to your request.
If you need replacement parts
If you need to order replacement parts, we recommend that you
use only factory specified parts. These factory specified parts will
fit right and work right because they are made with the same
precision used to build every new KITCHENAID® appliance.
To locate factory specified parts in your area, call us or your
nearest KitchenAid designated service center.
In the U.S.A.
Call the KitchenAid Customer eXperience Center toll free:
1-800-422-1230.
Our consultants provide assistance with:
Features and specifications on our full line of appliances.
Installation information.
Accessory and repair parts sales.
Specialized customer assistance (Spanish speaking, hearing
impaired, limited vision, etc.).
Referrals to local dealers, repair parts distributors, and
service companies. KitchenAid designated service
technicians are trained to fulfill the product warranty and
provide after-warranty service, anywhere in the United States.
To locate the KitchenAid designated service company in your
area, you can also look in your telephone directory Yellow
Pages.
For further assistance
If you need further assistance, you can write to KitchenAid with
any questions or concerns at:
KitchenAid Brand Home Appliances
Customer eXperience Center
553 Benson Road
Benton Harbor, MI 49022-2692
Please include a daytime phone number in your correspondence.
Accessories U.S.A.
To order accessories, call the KitchenAid Customer eXperience
Center toll free at 1-800-442-9991 and follow the menu prompts.
Or visit our website at www.kitchenaid.com and click on “Shop-
Online,” then “Accessories.” Portable appliances, bakeware,
cookware, gadgets and textiles are also available.
In Canada
For product related questions, please call the KitchenAid Canada
Customer Interaction Center toll free: 1-800-461-5681
Monday to Friday 8:00 a.m. - 6:00 p.m. (EST).
Saturday 8:30 a.m. - 4:30 p.m. (EST).
Our consultants provide assistance with:
Features and specifications on our full line of appliances.
Referrals to local dealers.
For parts, accessories and service in Canada
Call 1-800-807-6777. KitchenAid designated service technicians
are trained to fulfill the product warranty and provide after-
warranty service, anywhere in Canada.
For further assistance
If you need further assistance, you can write to KitchenAid
Canada with any questions or concerns at:
Customer Interaction Center
KitchenAid Canada
1901 Minnesota Court
Mississauga, Ontario L5N 3A7
Please include a daytime phone number in your correspondence.
Replacement Parts & Accessories
Glass Turntable
Part No. 4375405
Turntable Support and Rollers
Part No. 4375406
Turntable Hub
Part No. 4375407
Crisper Pan
Part No. 4393536
Crisper Pan Handle
Part No. 4393900
Broiling Grid
Part No. 4452220
Convection Grid
Part No. 4375443
Stainless Steel Cleaner &
Polish
Part No. 8171420
27
Notes
KITCHENAID
®
HIGH SPEED MICROWAVE OVEN WARRANTY
ONE-YEAR FULL WARRANTY
For one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or
furnished with the product, KitchenAid will pay for factory specified parts and repair labor costs to correct defects in materials or
workmanship. Service must be provided by a KitchenAid designated service company.
SECOND THROUGH FIFTH YEAR LIMITED WARRANTY ON MAGNETRON TUBE, ELECTRIC OVEN ELEMENT AND
SOLID STATE TOUCH CONTROL SYSTEM
In the second through fifth years from the date of purchase, when this appliance has been operated and maintained according to
instructions attached to or furnished with this product, KitchenAid will pay for factory specified parts for the microwave magnetron
tube, any electric oven element and the solid state touch control system to correct defects in materials or workmanship.
SECOND THROUGH TENTH YEAR LIMITED WARRANTY ON STAINLESS STEEL OVEN CAVITY/INNER DOOR
In the second through tenth years from date of purchase, when this appliance is operated and maintained according to instructions
attached to or furnished with this product, KitchenAid will pay for factory specified parts for the stainless steel oven cavity/inner door if
the part rusts through due to defects in materials or workmanship.
KitchenAid will not pay for:
1. Service calls to correct the installation of your appliance, to instruct you how to use your appliance, to replace house fuses or
correct house wiring, or to replace owner-accessible light bulbs.
2. Repairs when your appliance is used in other than normal, single-family household use.
3. Pickup and delivery. Your appliance is designed to be repaired in the home.
4. Damage resulting from accident, alteration, misuse, abuse, fire, flood, improper installation, acts of God or use of products not
approved by KitchenAid or KitchenAid Canada.
5. Repairs to parts or systems resulting from unauthorized modifications made to the appliance.
6. Replacement parts or repair labor costs for units operated outside the United States or Canada.
7. In Canada, travel or transportation expenses for customers who reside in remote areas.
8. Any labor costs during the limited warranty periods.
KITCHENAID AND KITCHENAID CANADA SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES.
Some states or provinces do not allow the exclusion or limitation of incidental or consequential damages, so this exclusion or limitation
may not apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state or
province to province.
Outside the 50 United States and Canada, this warranty does not apply. Contact your authorized KitchenAid dealer to
determine if another warranty applies.
If you need service, first see the “Troubleshooting” section of this book. After checking “Troubleshooting,” additional help can be found by
checking the “Assistance or Service” section or by calling the KitchenAid Customer eXperience Center, 1-800-422-1230 (toll-free), from
anywhere in the U.S.A. In Canada, contact your designated KitchenAid Canada Appliance service company or call 1-800-807-6777.
5/00
Keep this book and your sales slip together for future
reference. You must provide proof of purchase or
installation date for in-warranty service.
Write down the following information about your appliance to
better help you obtain assistance or service if you ever need it.
You will need to know your complete model number and serial
number. You can find this information on the model and serial
number label/plate, located on your appliance as shown in the
“Parts and Features” section.
Dealer name____________________________________________________
Address ________________________________________________________
Phone number__________________________________________________
Model number __________________________________________________
Serial number __________________________________________________
Purchase date __________________________________________________
8302974
© 2004. All rights reserved. ® Registered Trademark/TM Trademark of KitchenAid, U.S.A., KitchenAid Canada licensee in Canada
*Styrofoam is a Registered Trademark of The Dow Chemical Company. 9/04
Printed in U.S.A.

Navigation menu
