Wireless Environment MB220 Power Failure Detector User Manual MB220 Power Failure Detectorl
Wireless Environment LLC Power Failure Detector MB220 Power Failure Detectorl
Users Manual
Thank you for purchasing the Mr. Beams™ Power
Outage Detector and Remote (POD). The POD
works with the Mr. Beams Power Outage Lights to
automatically activate lights in the event of a power
Outage. One POD can activate dozens of Power
Outage Lights. We are certain your Mr. Beams
Power Outage Lighting System will contribute to a
safer environment and provide light where you
need it at a very reasonable cost.
ENCLOSED YOU WILL FIND:
• Power Outage Detector & Remote
• Rechargeable 3.6V NiMH Battery
Item MB220
INSTRUCTION GUIDE
MB220 Power Outage Detector Features:
Power-Outage Activated – Your Power Out-
age Detector works with the MB785 and MB985
Power Outage Lights and has a transmitter that
will activate all Power Outage lights instantly
when a power outage is detected.
Flashlight– The POD has a bright LED for use
as a flashlight. This flashlight automatically
activates during a power Outage.
Remote Control Feature—Your Power Outage
Detector can control all Power Outage Lights as
a remote control.
Low Battery Indicator—The red LED on your
light flashes when it is time to recharge batteries.
WARNING
• RISK OF ELECTRICAL SHOCK. For
adult use only. This product is a light
that uses 120V AC power. This product
is not a toy and should not be stored or
used in locations accessible to children.
For safe use: plug into exposed wall
outlet where device is ventilated and
cannot contact bed coverings or other
materials that may present a fire hazard.
Do not use with extension cords.
• Follow battery instructions for proper
disposal and cautions.
Remove screw on
battery door as shown in
Illustration 1. Remove
battery door from back of
POD (Illustration 2).
IMPORTANT NOTES:
• Auto Shut-Off Feature: If a power Outage occurs, the POD and Power Out-
age Lights will activate. If a button on the POD is not pressed, all lights will
turn off in 30 minutes to conserve battery life.
• For instructions on Power Outage Lights, please refer to their User Manuals.
• POD cannot charge while flashlight is on - therefore use as nightlight is not
recommended.
INSTALLATION INSTRUCTIONS
Mr. Beams
57 E. Washington St.
Chagrin Falls, OH 44035
877.298.9082
www.mrbeams.com
BEFORE YOU PLUG IN YOUR POWER OUTAGE DETECTOR (POD):
Illustration 1 Illustration 3 Illustration 2 Illustration 4
POWER OUTAGE DETECTOR + REMOTE + RECHARGEABLE FLASHLIGHT
Install Battery by inserting the
battery clip into the slot on the
POD as shown in Illustration
3. Tuck wires in, replace bat-
tery door and insert screw
(Illustration 1).
Retract plug on POD (Illustration
4) and plug into electrical outlet
(Illustration 5). For safe use: plug
into exposed wall outlet where de-
vice is ventilated and cannot contact
bed coverings or other materials that
may present a fire hazard.
LIMITED WARRANTY
The product you have purchased is guaranteed against defects in workmanship and materials for the period stated on the package. Warranties implied by law are subject to the same
time period limitation. Some states do not allow limitations on how long an implied warranty lasts, so this time limitation may not apply to you. If the product fails due to a manufac-
turing defect during normal use, return the product and dated sales receipt to the store where purchased for replacement OR send the product and the dated sales receipt to the address
above. Not Covered – Batteries are not covered by this warranty. Repair service, adjustment and calibration due to misuse, abuse or negligence are not covered by this warranty.
Unauthorized service or modification to this product or of any furnished components will void this warranty in its entirety. This warranty does not include reimbursement for incon-
venience, installation, set-up time, loss of use, postage, unauthorized service, or other products used in conjunction with, but are not supplied by, Wireless Environment.
This warranty gives you specific legal rights, and you may also have other rights which vary.
Removing the POD from the electrical outlet
simulates a power Outage (Illustration 6).
This turns on the Flashlight and all Power Out-
age Lights that you have installed . Placing the
POD back into a live electrical outlet will turn
the flashlight off as well as all Power Outage
Lights.
In the event of a power Outage,
the POD will immediately send a
signal to turn on all Power Out-
age Lights. The POD will also
turn on its internal LED to serve
as a flashlight (Illustration 7).
OPERATION OF THE POWER OUTAGE DETECTOR (POD):
To operate the flashlight, push the
round button on the POD
(Illustration 10).
Your POD also serves as a remote
control for all of the Power Outage
Lights. The curved button on the
top right turns all lights on
(Illustration 8).
The curved button on the top left of
the POD turns all lights off
(Illustration 9).
Illustration 5 Illustration 6
Illustration 8
Illustration 7
Illustration 9 Illustration 10
CAUTION
Risk of Electric Shock
Dry location use only
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK, OR
INJURY TO PERSONS
IMPORTANT SAFETY
INSTRUCTIONS
WARNING –
a) Read all the instructions before using the appliance.
b) To reduce the risk of injury, close supervision is necessary when an appliance is used near children.
c) Do not use outdoors.
d) To reduce the risk of electrical shock, do not put the unit in water or other liquid. Do not place or
store appliance where it can fall or be pulled into a tub or sink.
When using electric appliances, basic precautions should
always be followed, including the following:
SAVE THESE INSTRUCTIONS
Any Changes or modificaons not expressly
approved by the party responsible for
compliance could void the user's authority
to operate the equipment.
For household use only.
The baery is not intended to be replaced
by user.
This device complies with Part 15 of the FCC
Rules. Operaon is subject to the following
two condions:
(1) this device may not cause harmful
interference, and
(2) this device must accept any interference
received, including interference that may
cause undesired operaon.
For a Class B digital device or peripheral, the instrucons furnished the user shall include the following or similar
statement, placed in a prominent locaon in the text of the manual:
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protecon against harmful interference in a
residenal installaon. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instrucons, may cause harmful interference to radio communicaons. However,
there is no guarantee that interference will not occur in a parcular installaon. If this equipment does cause harmful
interference to radio or television recepon, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separaon between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
