user manual revision page
2.2.5 Antennas
.
.
Antenna Type Manufacturer and Part Number
2' dish plane polarized, 28.5 dbi Gabriel SSP2-52ARI
2' dish dual polarized, 28.5 dBi Gabriel SSD2-52ARI
*4 ' diameter dish, plane polarized, 33.5 dBi Gabriel SSP4-52A
*4' diameter dish, dual polarized, 33.5 dBi Gabriel SSD4-52A
14" flat panel . 23 dBi MTI Technology MT30102
2 ft dish, 26 dBi Radiowaves SP1-5.2NL
6" ft flat panel, 18 dBi Gabiriel DFPD 5-52
• The 4-foot dish antennas are for use outside the USA only, and are not FCC compliant.
Maximum Power, dBm, into antenna
23 dBi
Mti Panel 18 dBi
Gabriel panel 26 dBi
Radiowaves dish 28.5dBi
Gabriel dish
fo
MHz Max P, dBm Max P, dBm Max P, dBm Max P, dBm
5250-
5350 4 8 0 not used
5807.3 4** 12 4** 0**
5733.6 12 12 12 12
all
others 12 12 12 12
** limited by EIRP restrictions in 15.407(b)2
2.2.6 Diagnostics
