Wire connection guide
Wire Connection Guide
CONNECTOR FUNC NO NAME COLOR / Length
1 12V Main Power Input Red/ .6m FUSE 20A
2 12V Input for Starter & Accessory Blue/ .6m FUSE 30A
3 (-)200 Output for Starter-Kill Violet/ .6m
4 12V Output to Ignition Green /.6m
52
nd Ignition Output White/.6m
6 12V Output to Accessory Brown/.6m
7 12V Output to Starter Yellow/.6m
8pin Main Harness
8 Ground Input Black/.6m
1 Power or Ground Input- Polarity of the Parking Lt. Brown/.6m FUSE 20
Parking Light Harness 2 Parking Light Output Gray/.6m
1 Power or Ground Input -Polarity of the Trunk Motor Blue/ .8m
2 Trunk Output Green/ .8m
3 Siren Output (12V) Yellow/ .8m
4 Door Trigger Input/Dome-Light Out Black/ .8m
Power, Trunk & Dome-light
Harness
5 Power or Ground - Polarity of the door trigger. Brown/.8m
1
(
-200
)
Aux1 Out
p
ut Green / .8m
2
(
-200
)
Aux2 Out
p
ut Yellow/.8m
3 (-200) Rearm Output Brown/ .8m
4 (-200) Disarm Output Orange/ .8m
5 (-200) Horn Output Red/ .8m
OUTPUT HARNESS
SMAW250-O6
6 (-200) 2nd Ignition 1 Violet/ .8m
1 (-)Remote Starter ACT/DEA Input Lt Blue / .8m
2 (-)Option Sensor 2 Input Violet/ .8m
3 (-)Option Sensor 1 Input Green/ .8m Auto only
4 (-)Trunk Trigger Input Vt/Bk / .8m
5 (-)Hood Pin Input Brown/ .8m
6 (+)Brake Input Black/ .8m
7 Glow(+/-) Plug Input Blue/Bk/ .8m
OUTPUT HARNESS
SMAW200-O8
8 Engine Plug Input Yellow/ 3m
1 Internal 12V Input Rd/Bk/ .8m
2 Internal Ground Br/Bk/ .8m
3 (-)Trunk Output Yl/Bk/ .8m
4 (-)Lock/(+)Unlock Red/ .8m
5 (-)Unlock/(+)Lock Lt. Blue/ .8m
OUTPUT HARNESS
SMAW200-O6
6 Output Panic Yellow/ .8m
1 Internal 12V Input Red/ .9m
2 Internal Ground Black/ .9m
3 Shock 1 Stage Green/ .9m
SHOCK MODULE
SMAW250-04
4 Shock 2 Stage Yellow/ .9m
1 Internal 12V Output Red/1.5m
2 Output Knock White/ 1.5m
3 Output LED Yellow/ 1.5m
KNOCK MODULE
SMAW200-04
4 Internal Ground Black/ 1.5m
1 Output LED Black/ 1.5m
LED MODULE
SMAW200-02 2 Internal 12V Output Bk/Wt / 1.5m
1 Plug in By-Pass Switch Brown/ 1m
BY-PASS MODULE
SMAW250-02 2 Internal Ground Green/ 1m
1
2
GEAR SHOCK MODULE
AUTO SKIP 3
AUTO
SKIP
1 Internal Ground
2 ANT
ANT HARNESS
SMAW25-03
3
It lG d
50& CABLE
4.50m
Dip Switch Setting
Dip Switch Funtion Off On
1 Diesel - Polarity of Glow Plug + -
2 Engine Running Time 15(25) minutes 25(40) minutes
3 Engine Sensing Alternator Tach
4 Reserved for future
