Industry Canada User Manual Statements
The nominal passband gain is 25 dB and the nominal bandwidth is 150 MHz to 2.94 GHz.
The rated mean output power is 20 dBm and the input and output impedances are 50 ohms
The Manufacturer's rated output power of this equipment is for single carrier operation. For
situations when multiple carrier signals are present, the rating would have to be reduced by
3.5 dB, especially where the output signal is re-radiated and can cause interference to
adjacent band users. This power reduction is to be by means of input power or gain reduction
and not by an attenuator at the output of the device."
FCC compliance and interference statements
Hub. This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:
1) This device must accept any interference and
2) This device must accept any interference received including interference that may cause undesired
operation
Changes or modifications not expressly approved by Zinwave Ltd. could void the user’s authority to operate the
equipment.
Remote Unit. This device complies with Part 22, Part 24, Part 27, Part 74 and Part 90 of the FCC rules.
Changes or modifications not expressly approved by Zinwave Ltd. could void the user’s authority to operate the
equipment. For a list of services, please contact Zinwave.
This device must only be used with antennas having a maximum gain of 8 dBi
When operating on channel or channels under 47CFR part 90 as identified in the table below, this is a
Class B booster as defined in 47CFR90.219.
o Class B boosters must be registered with the FCC prior to operation, which can be done at the
FCC Part 90 Class B Signal Booster Registration & Discovery website:
https://signalboosters.fcc.gov/signal-boosters/
When operating on channel or channels under 47CFR parts 22, 24, 27 or 74 as identified in the table
below, this is an Industrial Booster as per 47CFR part 20.
Part 90 Signal Boosters THIS IS A 90.219 CLASS B DEVICE
WARNING. This is NOT a CONSUMER device. It is designed for installation by
FCC LICENSEES and QUALIFIED INSTALLERS. You MUST have an FCC LICENSE or
express consent of an FCC Licensee to operate this device. You MUST register
Class B signal boosters (as defined in 47 CFR 90.219) online at
www.fcc.gov/signal-boosters/registration. Unauthorized use may result in
significant forfeiture penalties, including penalties in excess of $100,000 for
each continuing violation.
See User Manual for more information
WARNING. This is NOT a CONSUMER device. It is designed for installation by
FCC LICENSEES and QUALIFIED INSTALLERS. You MUST have an FCC LICENSE or
express consent of an FCC Licensee to operate this device. Un authorised use
may result in significant forfeiture penalties, including penalties in excess of
$100,000 for each continuing violation
Remote units with FCC ID:UPO302-1107 only support services in the following bands of operation:
Rule Part
Band
Downlink Frequency
Range (MHz)
Service
Modulation
VHF Public
Safety
150.05 - 150.8
150.8 – 162.0125
162.0125 – 173.2
173.2 – 173.4
173.4 – 174.0
P25
C4FM (QPSK)
FM
FM ±2.5kHz dev'n
UHF Public
Safety
406 - 420
421 - 430
P25
C4FM (QPSK)
FM
FM ±2.5kHz dev'n
FM
FM ±5.0kHz dev'n
456 – 470
470 –512
P25
C4FM (QPSK)
FM
FM ±2.5kHz dev'n
FM
FM ±5.0kHz dev'n
UHF PMSE
470 – 608
614 – 698
FM
FM ±75kHz dev'n
700MHz Public
Safety
763 – 775
799 - 805
P25
C4FM (QPSK)
OpenSky
4-level GFSK
700MHz LTE
728 - 758
LTE
64 QAM
800MHz Public
Safety
851 - 869
P25
C4FM (QPSK)
OpenSky
4-level GFSK
800MHz SMR
851 - 869
FM & EDACS
FM ±5.0kHz dev'n
800MHz ESMR
851 - 869
iDEN
16-QAM
900MHz ESMR
935 - 940
iDEN
16-QAM
800MHz ESMR
851 - 869
EVDO (QPSK+QAM)
QPSK + QAM
FD-LTE
QPSK + QAM
Cellular
869 - 894
GSM
GMSK
EDGE
8-PSK
UMTS
QPSK
HSPA/HSPA+
16-QAM/64-QAM
CDMA
QPSK
CDMA2000 Ev-DO
8PSK, 16-QAM
929 Paging
929 - 930
FSK
FSK
931 Paging
931 - 932
FSK
FSK
PCS
1930 - 1995
GSM
GMSK
EDGE
8-PSK
UMTS
QPSK
HSPA/HSPA+
16-QAM/64-QAM
FDD LTE (band 2/25)
QPSK + QAM
CDMA
QPSK
CDMA2000 Ev-DO
8PSK, 16-QAM
AWS
2110 - 2170
UMTS
QPSK
HSPA/HSPA+
16-QAM/64-QAM
FD-LTE (band 4)
16-QAM/64-QAM
FD-LTE (band 10)
16-QAM/64-QAM
