eMoMo Technology REMO4 Remo4 Audio System User Manual Remo4 29V
eMoMo Technology Co., Ltd Remo4 Audio System Remo4 29V
Users manual
Safety Warning
Thank you for using our Remo1 Bluetooth sound system!
Before using this unit please, read the manual.
This audio system was for indoor use only.
Do not place the apparatus in direct sunlight or heat.
This apparatus should be placed on a stable surface.
Trying to remove panels or repairing the unit by yourself could result in an electric shock.
This item should be connected to an AC 100V-240V Power outlet.
Do not use chemicals on this product.
Do not press the buttons too hard, it may damage the product.
Do not attempt to repair this product as the warranty will be void, please contact with the store or customer service.
Product
NO.PARTS QTY.
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
Speaker：3”4Ω10W
C05 control box
The extention cable of speaker：L=1000mm
Switch power supply: 29V 2A
Speaker inner grill for
Screw：KA3*16mm，for ⑨
Screw：PA3.5*15，for①
Speaker grill for ⑨
Speaker grill fix
Speaker grill fix cover for⑨
2PCS
1PCS
4PCS
1PCS
2PCS
8PCS
8PCS
2PCS
2PCS
2PCS
①
Basic operation
1. Once power is supplied, the Remo4 bluetooth audio kit begins to search pairing device
automatically. It keeps searching until it pairs with other device successfully. It could
only pair with one bluetooth device. If you want to pair with another device, disconnect
the paired one, then connect with the new one.
2．The Remo4 Bluetooth audio kit could be controlled via the paired bluetooth.
Previous track/ Next track, Increase volume/ Decrease volume, Pause / Play.
3．Description of bluetooth：BT Speaker Remo4
4．Bluetooth reproduction rang: 8m.
Specification
Output 10W*2
Signal to noise ratio
Speaker
Blutooth Edition
≥68dB
3"4Ω 10W
2.4G
Frequently Asked Qustions
The volume switch is on minimum;
the unit is not set to the correct function;
please contact with the store or customer service.
Problem Possible cause and correction or maintenance
No sound at all
Please close all other pairing machines and retry;
Please wait a few seconds or restart the machine;
Do not pair the devices behind a wall or in corner, please
keep the working space within 8 meters;
Pair the device named eMoMo.
Bluetooth can
not pair
FCC Statement
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
To assure continued compliance, any changes or modifications not expressly
approved by the party.
Responsible for compliance could void the user’s authority to operate this
equipment. (Example- use only shielded interface cables when connecting to
computer or peripheral devices).
This equipment complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
FCC Radiation Exposure Statement:
The equipment complies with FCC Radiation exposure limits set forth for
uncontrolled enviroment. This equipment should be installed and operated with
minimum distance 20cm between the radiator and your body.
.
