TOWN OF GRAND LAKE PLANNING COMMISSION TOWN HALL MEETING (see details at bottom to join online) 6:30 P.M. November 4, 2020
AGENDA
I. CALL TO ORDER
II. ROLL CALL
III. APPROVAL OF MINUTES (not available)
IV. UNSCHEDULED CITIZEN PARTICIPATION
(This time is reserved for members of the public to make a presentation to the Commission on items or issues that are not scheduled on the agenda. The Commission will not make any decisions on items presented during this time.)
V. CONFLICTS OF INTEREST
VI. ITEMS OF BUSINESS V a. Recommendation to allow the removal and rebuilding of a boathouse on 536 Cairnes. (pg 2)
VII. ITEMS OF DISCUSSION a. Draft revisions of 2020 Comprehensive Plan Municipal (Pg 34)
VIII. FUTURE AGENDA ITEMS
IX. ADJOURNMENT
Online meeting information (please log on 15 min early if you anticipate needing any technical support):
Please join my meeting from your computer, tablet or smartphone. https://global.gotomeeting.com/join/662397805
You can also dial in using your phone.
United States: +1 (872) 240-3311
Access Code: 662-397-805
2
Date: November 4, 2020 To: Chairman Shockey and the Planning Commissioners From: Kimberly White, Town Planner Re: 536 Cairnes Boathouse
Attachments: 536 Cairnes Boathouse construction documents, USACE documents Background 536 Cairnes has an existing, conforming boathouse. The owners need a larger opening to accommodate their boat, so are requesting approval to construct a boathouse of similar size in place of the existing boathouse.
Analysis The existing boathouse has 4 existing piers, and the new boathouse has proposed 28 piers. The basic footprint, size, scope and character of the boathouse structure itself is the same and it replaces an existing previously-permitted structure, therefore the standard NWP #3 would be the appropriate permitting mechanism. All other standard permit conditions and requirements have been met so the NWP #3 will automatically apply. The USACE is already in receipt of the PCN notice as required and has granted permit approval for this property. Recommendation Staff recommends that the Planning Commission allow the replacement of the current boathouse with the proposed boathouse as attached. I move that the replacement of the boathouse at 536 Cairnes be approved..
P.O. BOX 99, GRAND LAKE, COLORADO 80447-0099 PH. 970/627-3435 FAX 970/627-9290
E-MAIL: town@townofgrandlake.com
5/6/2020 12:08:06 PM I:\Projects-new\1940 - Struna\a\MA_1940_Struna_A184.rvt
ALL DRAWINGS AND WRITTEN DOCUMENTS HEREIN CONSTITUTE THE ORIGINAL INTELLECTUAL PROPERTY OF THE ARCHITECT AND MAY NOT BE REUSED, REPRODUCED OR DISCLOSED WITHOUT THE EXPRESSED WRITTEN CONSENT OF MUNN ARCHITECTURE, LLC.
SHEET INDEX LEGEND:
ISSUED NOT ISSUED
R ISSUED FOR REFERENCE ONLY X REMOVED FROM DRAWING SET
SHEET INDEX
2020-0505 - PERMIT SUBMITTAL
GENERAL NOTES
1) COPYRIGHT: ALL PLANS, DESIGNS AND CONCEPTS SHOWN IN THESE DRAWINGS ARE THE EXCLUSIVE PROPERTY OF MUNN ARCHITECTURE, AIA. LLC AND SHALL NOT BE USED, DISCLOSED, OR REPRODUCED FOR ANY PURPOSE WHATSOEVER WITHOUT THE ARCHITECT'S WRITTEN PERMISSION.
2) CODES: THIS PROJECT IS GOVERNED BY THE LOCALLY ENFORCED BUILDING CODES AS ADOPTED BY THE AUTHORITY HAVING JURISDICTION (AHJ). CODE COMPLIANCE IS MANDATORY. THE DRAWINGS AND SPECIFICATIONS SHALL NOT PERMIT WORK THAT DOES NOT CONFORM TO THESE CODES, UNLESS NOTED OTHERWISE. THE GENERAL CONTRACTOR AND THE SUBCONTRACTORS SHALL BE RESPONSIBLE FOR SATISFYING ALL APPLICABLE CODES AND OBTAINING ALL PERMITS AND REQUIRED APPROVALS. BUILDING AREAS ARE SHOWN FOR CODE PURPOSES ONLY AND SHALL BE RECALCULATED FOR ANY OTHER PURPOSES.
3) FIELD VERIFICATION: VERIFY ALL DIMENSIONS, CONDITIONS, AND UTILITY LOCATIONS ON THE JOB SITE PRIOR TO BEGINNING ANY WORK OR ORDERING ANY MATERIALS. NOTIFY ARCHITECT OF ANY CONFLICTS OR DISCREPANCIES IN THE DRAWINGS IMMEDIATELY.
4) DIMENSIONS: WRITTEN DIMENSIONS ALWAYS TAKE PRECEDENCE OVER SCALED DIMENSIONS. DO NOT SCALE DRAWINGS. VERIFY ALL DIMENSIONS SHOWN PRIOR TO BEGINNING ANY WORK AND NOTIFY ARCHITECT OF ANY CONFLICTS OR DISCREPANCIES FOR INTERPRETATION OR CLARIFICATION. PLAN DIMENSIONS ARE TO THE FACE OF THE FRAMING MEMBERS, FACE OF WOOD FURRING OR FACE OF CONCRETE WALLS UNLESS OTHERWISE NOTED. SECTION OR ELEVATION DIMENSIONS ARE TO TOP OF CONCRETE, TOP OF PLYWOOD, OR TOP OF WALL PLATES OR BEAMS UNLESS OTHERWISE NOTED
5) DISCREPANCIES: THE OWNER HAS REQUESTED THE ARCHITECT TO PROVIDE LIMITED ARCHITECTURAL AND ENGINEERING SERVICES. IN THE EVENT THAT ADDITIONAL DETAILS OR GUIDANCE ARE NEEDED BY THE CONTRACTOR FOR THE CONSTRUCTION OF ANY ASPECT OF THIS PROJECT, HE OR SHE SHALL IMMEDIATELY NOTIFY THE ARCHITECT. FAILURE TO GIVE SIMPLE NOTICE SHALL RELIEVE THE ARCHITECT OF RESPONSIBILITY. DO NOT PROCEED IN AREAS OF DISCREPANCY UNTIL ALL SUCH DISCREPANCIES HAVE BEEN FULLY RESOLVED WITH WRITTEN DIRECTIONS FROM THE ARCHITECT.
6) DUTY OF COOPERATION: RELEASE OF THESE PLANS CONTEMPLATES FURTHER COOPERATION BETWEEN THE OWNER AND/OR OWNER'S REPRESENTATIVE, HIS OR HER CONTRACTOR, AND THE ARCHITECT. DESIGN AND CONSTRUCTION ARE COMPLEX. ALTHOUGH THE ARCHITECT AND HIS CONSULTANTS HAVE PERFORMED THEIR SERVICES WITH DUE CARE AND DILIGENCE, THEY CANNOT GUARANTEE PERFECTION. COMMUNICATION IS IMPERFECT, AND EVERY CONTINGENCY CANNOT BE ANTICIPATED. ANY AMBIGUITY OR DISCREPANCY DISCOVERED BY THE USE OF THESE PLANS SHALL BE REPORTED IMMEDIATELY TO THE ARCHITECT. FAILURE TO NOTIFY THE ARCHITECT COMPOUNDS MISUNDERSTANDING AND INCREASES CONSTRUCTION COSTS. A FAILURE TO COOPERATE BY A SIMPLE NOTICE TO THE ARCHITECT SHALL RELIEVE THE ARCHITECT FROM RESPONSIBILITY FOR ALL CONSEQUENCES.
7) CHANGES TO WORK: ANY ITEMS DESCRIBED HEREIN THAT IMPACT PROJECT BUDGET OR TIME SHALL BE REQUESTED FROM THE CONTRACTOR VIA A WRITTEN CHANGE ORDER REQUEST PRIOR TO SUCH WORK. PERFORMANCE OF SUCH WORK WITHOUT APPROVAL BY CHANGE ORDER INDICATES THE GENERAL CONTRACTOR'S ACKNOWLEDGMENT OF NO INCREASE IN CONTRACT SUM OR TIME. CHANGES FROM THE PLANS OR SPECIFICATIONS MADE WITHOUT THE CONSENT OF THE ARCHITECT ARE UNAUTHORIZED AND SHALL RELIEVE THE ARCHITECT OF RESPONSIBILITY FOR ANY AND ALL CONSEQUENCES RESULTING FROM SUCH CHANGES.
8) WORKMANSHIP: IT IS THE INTENT AND MEANING OF THESE DRAWINGS THAT THE CONTRACTOR AND EACH SUBCONTRACTOR PROVIDE ALL LABOR, MATERIALS, TRANSPORTATION, SUPPLIES, EQUIPMENT, ETC. TO OBTAIN A COMPLETE JOB WITHIN THE RECOGNIZED STANDARDS OF THE INDUSTRY.
9) SUBSTITUTIONS: SUBSTITUTION OF "EQUAL" PRODUCTS WILL BE ACCEPTABLE WITH THE ARCHITECT'S WRITTEN APPROVAL.
10) CONSTRUCTION SAFETY: THESE DRAWINGS DO NOT INCLUDE THE NECESSARY COMPONENTS FOR CONSTRUCTION SAFETY. THE GENERAL CONTRACTOR SHALL PROVIDE FOR THE SAFETY, CARE OF UTILITIES AND ADJACENT PROPERTIES DURING CONSTRUCTION AND SHALL COMPLY WITH STATE AND FEDERAL SAFETY REGULATIONS.
11) EXCAVATION PROCEDURES: UPON COMPLETION OF ANY EXCAVATION, THE OWNER SHALL RETAIN A SOILS ENGINEER TO INSPECT THE SUBSURFACE CONDITIONS IN ORDER TO DETERMINE THE ADEQUACY OF FOUNDATION DESIGN. CONTRACTOR SHALL NOT POUR ANY CONCRETE UNTIL APPROVAL IS OBTAINED FROM SOILS ENGINEER.
12) FIELD CUTTING OF STRUCTURAL MEMBERS: THE GENERAL CONTRACTOR AND THE SUBCONTRACTORS SHALL FIELD COORDINATE AND OBTAIN APPROVAL FROM ENGINEER BEFORE ANY CUTTING, NOTCHING OR DRILLING OF ANY CAST-IN-PLACE CONCRETE, STEEL FRAMING OR ANY OTHER STRUCTURAL ELEMENTS WHICH MAY AFFECT THE STRUCTURAL INTEGRITY OF THE BUILDING. REFER TO 2009 I.R.C., MANUFACTURER'S OR SUPPLIER'S INSTRUCTIONS, AND STRUCTURAL DRAWINGS FOR ADDITIONAL REQUIREMENTS.
13) WEATHER CONDITIONS: THE OWNER HAS BEEN ADVISED THAT DUE TO HARSH WINTER CONDITIONS, ROOF AND DECK SURFACE MUST BE MAINTAINED REASONABLY FREE OF ICE AND SNOW TO ENSURE MINIMAL PROBLEMS WITH THESE SURFACES. ALL ROOFING, ROOFING MEMBRANE AND WATERPROOFING SHALL BE APPROVED IN WRITING BY PRODUCT MANUFACTURER (W.R. GRACE FOR BITUTHENE, ETC.) PRIOR TO PROCEEDING WITH ANY WORK. FAILURE TO PROVIDE THESE WRITTEN APPROVALS REMOVES ALL RESPONSIBILITY FOR THE WORK FROM THE ARCHITECT.
14) BUILDING AREA: BUILDING AREAS ARE SHOWN FOR CODE PURPOSES ONLY AND SHALL BE RECALCULATED FOR ANY OTHER USE.
15) PROJECT STAKING: THE GENERAL CONTRACTOR SHALL VERIFY ALL EXISTING GRADES AND STAKE ALL BUILDING CORNERS AND DRIVEWAY LOCATION FOR OWNER/ARCHITECT AND DESIGN REVIEW BOARD APPROVAL PRIOR TO BEGINNING ANY SITE CLEARING.
16) SITE DISTURBANCE: IT IS THE RESPONSIBILITY OF THE CONTRACTOR TO PROTECT THE EXISTING TREES TO REMAIN AND ADJACENT PROPERTIES FROM DAMAGE DURING CONSTRUCTION. PROVIDE PROTECTIVE FENCING THROUGHOUT CONSTRUCTION.
17) PROJECT GRADES: THE GENERAL CONTRACTOR SHALL CHECK AND VERIFY ALL GRADES INCLUDING PAVED AREAS SLOPES PRIOR TO POURING ANY FOUNDATION. SURVEY WORK SHOULD BE VERIFIED IN DETAIL.
18) SEPTIC DESIGN: IF A SEPTIC SYSTEM IS REQUIRED, THE GENERAL CONTRACTOR IS TO BID NEW SEPTIC FIELD AND ALL NECESSARY PLUMBING PER COUNTY REQUIREMENTS AND PER SEPTIC DESIGN BY A SOILS ENGINEER.
SUSTAINABLE CONSTRUCTION PRACTICES
1) ENVIRONMENTAL HEALTH IT IS THE ARCHITECT'S INTENT THAT THE CLIENT RECEIVE A PRODUCT THAT IS BOTH FUNCTIONAL AND DESIGNED WITH THE HEALTH AND WELL-BEING OF THE CLIENT IN MIND, TO THIS END, IT IS ASSUMED THAT MATERIALS SPECIFIED WILL BE, WHENEVER AND WHEREVER POSSIBLE, OF THE HIGHEST QUALITY AND OF AN ENVIRONMENTALLY SOUND NATURE. THIS INCLUDES, BUT IS NOT LIMITED TO, PAINTS AND CARPETS WITH NO TO LOW VOLATILE ORGANIC COMPOUND EMISSIONS.
2) RECYCLED MATERIALS & PRODUCTS FULLY OR PARTIALLY RECYCLED MATERIALS & PRODUCTS ARE TO BE USED AS ALTERNATIVES TO ORIGINALUSE PRODUCTS WHENEVER APPROPRIATE (e.g. LUMBER, FLOORING, ETC.). IT IS FURTHER EXPECTED THAT THE CONTRACTOR WILL PURCHASE MATERIALS THAT ARE MANUFACTURED AS PHYSICALLY CLOSE TO THE LOCATION OF THE PROJECT AS CAN BE REASONABLY EXPECTED, WITH THE CONSIDERATION OF CARBON EMISSIONS IN MIND.
3) INSULATIONS WHERE CELLULOSE INSULATION IS USED AS AN ALTERNATIVE TO FIBERGLASS BATT OR FOAM, CONTRACTOR IS TO ADHERE STRICTLY TO MANUFACTURER'S GUIDELINES FOR INSTALLATION AND MOISTURE CONTROL. RVALUES MUST EQUAL OR EXCEED SPECIFIED R-VALUES ON PLANS.
4) GLUES AND ADHESIVES LOW V.O.C. GLUES AND ADHESIVES ARE TO BE USED WHEN THEY MEET PROJECT TOLERANCES. EXAMPLES INCLUDE: DAP® 2000® Heavy-Duty Projects VOC-Compliant Construction Adhesive & PL 400® Low VOC Heavy Duty Construction Adhesive.
5) PAINTS AND SOLVENTS USE LOW- OR ZERO-V.O.C. PAINTS SUCH AS KELLY-MOORE 'ENVIRO-COTE' OR DEVOE 'WONDERPURE' TYPE PAINTS. EXTERIOR OIL-BASED PAINTS ARE TO BE THINNED OR CLEANED WITH TURPENTINE, OR OTHER NATURAL SOLVENTS. USE NATURAL PAINTS WHERE POSSIBLE, AS THE CLIENT REQUIRES.
6) RESOURCES USE THE LEED ONLINE GUIDELINES FOR SUSTAINABLE OPTIONS. ADDITIONAL RESOURCES CAN BE FOUND AThttp://www.green-buildings.com/products-certification THE NAHB GREEN ICC 700 NATIONAL GREEN BUILDING STANDARD CAN ALSO BE USED TO INFORM THE SUSTAINABLE BUILDING PRACTICES PLAN OUTLINED BELOW. http://www.NAHBGREEN.ORG
7) THE CONTRACTOR IS TO PRESENT A SUSTAINABLE BUILDING PRACTICES PLAN TO THE ARCHITECT & CLIENT DETAILING THE PROPOSED SUSTAINABLE ALTERNATIVES HE OR SHE INTENDS TO IMPLEMENT.
MINIMUM DESIGN CRITERIA
1.
DESIGN SNOW LOAD: _______________________________________________________________
2.
WIND LOAD (ULTIMATE): ____________________________________________________________
3.
SIESMIC DESIGN: ___________________________________________________________________
68 PSF (ROOF) 115 MPH CATEGORY II
APPLICABLE CODES AND STANDARDS
JURISDICTION APPLICABLE CODES
GRAND COUNTY BUILDING DEPARTMENT THREE LAKES WATER AND SANITATION DISTRICT GRAND LAKE FIRE PROTECTION DISTRICT #2 COLORADO DEPARTMENT OF PUBLIC HEALTH AND ENVIRONMENT
2015 IRC - INTERNATIONAL RESIDENTIAL CODE 2015 IECC - INTERNATIONAL ENERGY CONSERVATION CODE 2015 IFC - INTERNATIONAL FIRE CODE 2015 IFGC - INTERNATIONAL FUEL GAS CODE 2015 IMC - INTERNATIONAL MECHANICAL CODE 2015 IPC - INTERNATIONAL PLUMBING CODE 2017 NEC - NATIONAL ELECTRIC CODE
SHEET #
SHEET TITLE
GENERAL
G0.00 COVER SHEET
CIVIL
SU1.00 SITE SURVEY
ARCHITECTURAL
A0.01 ARCHITECTURAL ABBREVIATIONS AND SYMBOLS LEGEND
A0.20 DOOR, WINDOW, AND FINISH SCHEDULE
A1.00 PROJECT SITE PLAN
A3.01 OVERALL FLOOR PLANS
A5.01 OVERALL EXTERIOR ELEVATIONS
A6.10 OVERALL BUILDING SECTIONS
STRUCTURAL
S0
GENERAL NOTES
S1
FOUNDATION AND FRAMING PLAN
S2
SECTIONS
CONTACT INFO:
ARCHITECT:
MUNN ARCHITECTURE, LLC SCOTT MUNN, AIA 315 E. AGATE AVENUE GRANBY, CO 80446 PH: 970-887-9366
SURVEYOR:
AZIMUTH SURVEY COMPANY WARREN D. WARD P.O. BOX 653 FRASER, CO 80442 PH: 970-531-1120
STRUCTURAL ENGINEER:
JVA, INCORPORATED CRAIG KOBE 47 COOPER CREEK WAY, SUITE 328 WINTER PARK, CO 80482 PH: 303-444-1951
ENVIRONMENTAL ENGINEER:
ENVIRONMENTAL SOLUTIONS, INC. STEVE DAHMER 600 COUNTY ROAD 216 RIFLE, CO 81650 PH: 970-618-6841
STRUNA BOATHOUSE
STEPHEN AND SUSAN STRUNA
536 CAIRNS AVE, GRAND LAKE, CO 80447 PROJECT #: 1940
3
ARCHITECT :
315 EAST AGATE AVENUE P.O. BOX 21
GRANBY, CO 80446 970-887-9366
WWW.MUNNARCH.COM
STAMP :
05/05/2020
ISSUANCE :
PERMIT SUBMITTAL
DATE : 2020-0505
SHEET TITLE : COVER SHEET
SHEET NUMBER :
G0.00
4
5/6/2020 12:07:44 PM I:\Projects-new\1940 - Struna\a\MA_1940_Struna_A184.rvt
