ASUS Eee PC
A-5
Flash Memory Card Reader/Writer
Type Model
USB 2.0 Apacer Card Reader AR020
Apacer Card Reader AP450
Digimaster USB-25IN1
I Rock-All In One
Kingston Card Reader FCR-MLFE
Philips
Powersync CR220W
Sanwa ADR-MLT17
TRANSCEND Multi Card Reader M2
Floppy Devices
Type Model
USB 1.1 Mitsumi D353FUE
Sony MPF82E
HandWriter Devices
Type Model
USB 1.1 PenPower Touch Pad PD8UE
Joystick & Game Pad Devices
Type Model
USB 1.1 Logitech Dual Action GamePad
Logitech Dual Action
2
Logitech Driving Force EX
Logitech Rumblepad2
Logitech Extreme 3D Pro-J-UK17
Keyboard Devices
Type Model
USB 1.1 BenQ 6511-ME
Detrois CT603
Ergotech ET-K701
Logitech LX700
Logitech MX300 Laser
Logitech New Touch keyboard200
Logitech YBP62A
Microsoft Comfort Curve Keyboard200
Samsung PKB7000X
Songwin MCK100
Zippy WK610
M.O. Devices
Type Model
USB 1.1 Imation MO1064-UB
USB 2.0 Buffalo MOUZ-P640R
Fujitsu U2 MO 2.3G
I-O Data MOA-i640S
Microphone Devices
Type Model
Condenser Hawk MIC989
Ktnet KTSep111AS
SonudMAX ARRYA-2S
Dynamic Audio-technica AT-VD5
Mobile Phone Devices
Type Model
USB 1.1 PHS A91
A-6
Appendix
Mouse Devices
Type Model
USB 1.1 Acrox MT5
Genius GM-03003
INX IM7301
INX IM7501
INX IM7701
Logitech G9 Laser
Logitech LX-7 Cordless
Logitech MX1000Laser
Logitech M-RBH113
Logitech M-UAE96
Logitech VAG96B
Logitech V200 Cordless
Logitech M-BZ96C
RaZer Copperhead RZ01
Microsoft Comfort Optical Mouse 3000
Microsoft Wireless Optical Desktop
Microsoft Comfort Optical Mouse
ODD CD/DVD-ROM / CD-RW / Combo / DVD+-RW Devices
Type Model
USB 2.0 BENQ-EW164B
BENQ-EW200G
BENQ-TW200D
Lite-On SHM-165P6SX
Pioneer DVR-X122
Sony DRX-S70U
Sony DRX-820UL
Sony SRX-S50U
Teac DVW28SLA100
PDA / Cell Phone Devices
Type Model
USB 1.1 BENQ P50
Printer Devices
Type Model
USB 1.1 Canon i6100
Epson Stylus Color1160
USB 2.0 Canon PIXMA ip90
Epson Stylus CX3700
Epson Stylus PhotoR800
HP Color Laser Jet 1600
HP DeskJet D2360
HP Photosmart D5160
Lexmark Z818
Samsung ML2010
Epson Stylus Photo790
HP Deskjet 995C
HP Deskjet 5550
PC Camera Devices
Type Model
USB 2.0 Microsoft-VX1000
Logitech VUAR38
Removable H.D.D
Type Model
HITEC-HITC25CG
iPod Video 80G
NuSLIM NS320C+
Toponepower TB-35C2
UCI SA350-T
Vantec
NST-755UF-BK
Zynet HD-D5-U2FW
ASUS Eee PC
A-7
Smart Card
Type Model
SD SanDisk UltraII 2GB
Transcend TS512MUSD
Transcend TS2GSDC
Transcend TS4GSD150
Kingston SD 512M
Smart Card
Type Model
SD Kingston Mini SD/2GB
Kingston SD/2GB
Apacer SD/60x/1G
Apacer SD/60x/2G
Kingston Mini SD 4GB
MMC Kingmax 64MB MMC
Transcend TS128MRMMC
Transcend TS1GRMMC4
Transcend TS512MMCM
Transcend TS2GMMC4
Transcend TS4GMMC4
PQI mobile/1GB
Kingston SD/1GBFE
SDHC A-DATA SDHC 4GB
A-DATA SDHC 8GB
Kingston SDHC 4GB
PNY SDHC 4GB
PQI SDHC 4GB
SanDisk SDHC 4GB
SanDisk ultraII SDHC 4GB
Toshiba M01GR4W 1GB
Toshiba M02GR4W 2GB
Toshiba M04GR4W 4GB
Toshiba M08GR4W 8GB
Transcend TS4GSDHC6
Transcend TS8GSDHC6
Speaker Devices
Type Model
Line out Altec Lansing 5100
Altec Lansing VS-2120
JS JY5000
Logitech S100
Ozaki NU926
USB 1.1 Yamaha YST-MS35D
Logitech V10
Scanner Devices
Type Model
USB 1.1 Epson Perfection 1650 Photo
USB 2.0 Canon CanoScan LiDE30
Epson Stylus CX3700
Epson Perfection 4990 Photo
Sound Adapters
Type Model
USB 2.0 Mediatek Audimax F1
A-8
Appendix
USB Flash Disk
Type Model
USB 2.0 Adata MyFlash
Adata PD10
Apacer HA202 2G Flash
Apacer AH221
Apacer AH320
ASUS Ai-FLASH V
Kingston DTR
PQI U172P
PQI U230
Sandisk SDCZ6
TRANSCEND JetFlash V10
Transcend JetFlash V20
Transcend JF168
USB HUB Devices
Type Model
USB 2.0 ELECOM U2H-MN4BBU
SANWA-206W
Wireless Lan Access Point
Type Model
AP ASUS WL-500W
ASUS WL-320GP
Buffalo WHR-G54S
Corega-CG WLBARAG2
D-Link DI-624
D-Link DIR-635
D-Link DIR-655
Linksys WRT54G
Wireless Lan Access Point
Type Model
AP Netgear WPN824
SMC SMCWBR14-N
Zyxel NBG-415N
Corega CG-WLBARGLV2
Corega CG-WLBARGNR
Pci GW-AP54P
Pci BLW-HPMM-U
Pci MZK-W04N
Zyxel P-330W
Zyxel P-336M
SMC WBR11-G
SMC SMCWBR14T-G2
D-Link DWL-G700AP
D-LinkDGL-4300
D-LinkDIR-451
D-LinkDIR-300
D-LinkDIR-615
D-LinkDI-624S
Zyxel P-334SH
Zyxel P-320W
Corega CG-WLNSC1000
PCI BLW-54MF
PCI BLW-54MR
Buffalo WHR-HP-G54
Lemel LM-WLG6400
Belkin F5D9230-4
ASUS Eee PC
A-9
Wireless Ethernet Adapters
Type Model
USB 2.0 ASUS WL-167G
PCi GW-US300MiniW
3G WLAN Adapter
Type Model
USB ASUS T500
Amoi H01
HUAWEI E220
PAH A91
100 BaseTx Ethernet Adapters
Type Model
USB 2.0 Billionton USB2AR2
A-10
Appendix
Declarations and Safety Statements
Federal Communications Commission Statement
This device complies with FCC Rules Part 15. Operation is subject to
the following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the
limits for a class B digital device, pursuant to Part 15 of the Federal
Communications Commission (FCC) rules. These limits are designed
to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
The use of a shielded-type power cord is required in order to
meet FCC emission limits and to prevent interference to the
nearby radio and television reception. It is essential that only
the supplied power cord be used. Use only shielded cables to
connect I/O devices to this equipment. You are cautioned that
changes or modifications not expressly approved by the party
responsible for compliance could void your authority to operate
the equipment.
ASUS Eee PC
A-11
(Reprinted from the Code of Federal Regulations #47, part 15.193, 1993.
Washington DC: Office of the Federal Register, National Archives and
Records Administration, U.S. Government Printing Office.)
FCC Radio Frequency (RF) Exposure Caution
Statement
Any changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority
to operate this equipment. “The manufacture declares that
this device is limited to Channels 1 through 11 in the 2.4GHz
frequency by specified firmware controlled in the USA.”
This equipment complies with FCC radiation exposure limits set forth
for an uncontrolled environment. To maintain compliance with FCC
RF exposure compliance requirements, please avoid direct contact
to the transmitting antenna during transmitting. End users must
follow the specific operating instructions for satisfying RF exposure
compliance.
Max. SAR Measurement (1g)
802.11b SAR Value: 0.033 W/kg
802.11g SAR Value: 0.055 W/kg
A-12
Appendix
Declaration of Conformity
(R&TTE directive 1999/5/EC)
The following items were completed and are considered relevant
and sufficient:
• Essential requirements as in [Article 3]
• Protection requirements for health and safety as in [Article 3.1a]
• Testing for electric safety according to [EN 60950]
• Protection requirements for electromagnetic compatibility in
[Article 3.1b]
• Testing for electromagnetic compatibility in [EN 301 489-1] & [EN
301]
• Testing according to [489-17]
• Effective use of the radio spectrum as in [Article 3.2]
• Radio test suites according to [EN 300 328-2]
CE Mark Warning
This is a Class B product, in a domestic environment, this product
may cause radio interference, in which case the user may be required
to take adequate measures.
IC Radiation Exposure Statement for Canada
This equipment complies with IC radiation exposure limits set forth
for an uncontrolled environment. To maintain compliance with IC
RF exposure compliance requirements, please avoid direct contact
to the transmitting antenna during transmitting. End users must
follow the specific operating instructions for satisfying RF exposure
compliance.
Operation is subject to the following two conditions:
• This device may not cause interference and
• This device must accept any interference, including interference
that may cause undesired operation of the device.
ASUS Eee PC
A-13
To prevent radio interference to the licensed service (i.e. co-channel
Mobile Satellite systems) this device is intended to be operated
indoors and away from windows to provide maximum shielding.
Equipment (or its transmit antenna) that is installed outdoors is
subject to licensing.
Because high power radars are allocated as primary users (meaning
they have priority) in 5250-5350 MHz, these radars could cause
interference and/or damage to license exempt LAN devices.
Max. SAR Measurement (1g)
802.11b SAR Value: 0.033 W/kg
802.11g SAR Value: 0.055 W/kg
A-14
Appendix
Wireless Operation Channel for Different Domains
N. America 2.412-2.462 GHz Ch01 through CH11
Japan 2.412-2.484 GHz Ch01 through Ch14
Europe ETSI 2.412-2.472 GHz Ch01 through Ch13
France Restricted Wireless Frequency Bands
Some areas of France have a restricted frequency band. The worst
case maximum authorized power indoors are:
• 10mW for the entire 2.4 GHz band (2400 MHz–2483.5 MHz)
• 100mW for frequencies between 2446.5 MHz and 2483.5 MHz
Channels 10 through 13 inclusive operate in the band 2446.6 MHz to
2483.5 MHz.
There are few possibilities for outdoor use: On private property or on
the private property of public persons, use is subject to a preliminary
authorization procedure by the Ministry of Defense, with maximum
authorized power of 100mW in the 2446.5–2483.5 MHz band. Use
outdoors on public property is not permitted.
In the departments listed below, for the entire 2.4 GHz band:
• Maximum authorized power indoors is 100mW
• Maximum authorized power outdoors is 10mW
Departments in which the use of the 2400–2483.5 MHz band is
permitted with an EIRP of less than 100mW indoors and less than
10mW outdoors:
01 Ain Orientales 02 Aisne 03 Allier
05 Hautes Alpes 08 Ardennes 09 Ariège
11 Aude 12 Aveyron 16 Charente
24 Dordogne 25 Doubs 26 Drôme
32 Gers 36 Indre 37 Indre et Loire
41 Loir et Cher 45 Loiret 50 Manche
55 Meuse 58 Nièvre 59 Nord
ASUS Eee PC
A-15
60 Oise 61 Orne 63 Puy du Dôme
64 Pyrénées Atlantique 66 Pyrénées 67 Bas Rhin
68 Haut Rhin 70 Haute Saône
71 Saône et Loire 75 Paris
82 Tarn et Garonne 84 Vaucluse 88 Vosges
89 Yonne 90 Territoire de Belfort
94 Val de Marne
This requirement is likely to change over time, allowing you to use
your wireless LAN card in more areas within France. Please check
with ART for the latest information (www.art-telecom.fr)
Your WLAN Card transmits less than 100mW, but more than
10mW.
A-16
Appendix
UL Safety Notices
Required for UL 1459 covering telecommunications (telephone)
equipment intended to be electrically connected to a
telecommunication network that has an operating voltage to
ground that does not exceed 200V peak, 300V peak-to-peak, and
105V rms, and installed or used in accordance with the National
Electrical Code (NFPA 70).
When using the Eee PC modem, basic safety precautions should
always be followed to reduce the risk of fire, electric shock, and injury
to persons, including the following:
• DO NOT use the Eee PC near water, for example, near a bath tub,
wash bowl, kitchen sink or laundry tub, in a wet basement or
near a swimming pool.
• DO NOT use the Eee PC during an electrical storm. There may be
a remote risk of electric shock from lightning.
• DO NOT use the Eee PC in the vicinity of a gas leak.
Required for UL 1642 covering primary (nonrechargeable) and
secondary (rechargeable) lithium batteries for use as power sources
in products. These batteries contain metallic lithium, or a lithium
alloy, or a lithium ion, and may consist of a single electrochemical
cell or two or more cells connected in series, parallel, or both, that
convert chemical energy into electrical energy by an irreversible or
reversible chemical reaction.
• Do not dispose the Eee PC battery pack in a fire, as they may
explode. Check with local codes for possible special disposal
instructions to reduce the risk of injury to persons due to fire or
explosion.
• Do not use power adapters or batteries from other devices to
reduce the risk of injury to persons due to fire or explosion. Use
only UL certified power adapters or batteries supplied by the
manufacturer or authorized retailers.
ASUS Eee PC
A-17
Power Safety Requirement
Products with electrical current ratings up to 6A and weighing more
than 3Kg must use approved power cords greater than or equal to:
H05VV-F, 3G, 0.75mm
2
or H05VV-F, 2G, 0.75mm
2
.
This symbol of the crossed out wheeled bin indicates that
the product (electrical, electronic equipment, and mercury-
containing button cell battery) should not be placed in
municipal waste. Check local regulations for disposal of
electronic products.
A-18
Appendix
Nordic Lithium Cautions (for lithium-ion batteries)
CAUTION! Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended
by the manufacturer. Dispose of used batteries according to the
manufacturer’s instructions. (English)
ATTENZIONE! Rischio di esplosione della batteria se sostituita in
modo errato. Sostituire la batteria con un una di tipo uguale o
equivalente consigliata dalla fabbrica. Non disperdere le batterie
nell’ambiente. (Italian)
VORSICHT! Explosionsgefahr bei unsachgemäßen Austausch der
Batterie. Ersatz nur durch denselben oder einem vom Hersteller
empfohlenem ähnlichen Typ. Entsorgung gebrauchter Batterien
nach Angaben des Herstellers. (German)
ADVARSELI! Lithiumbatteri - Eksplosionsfare ved fejlagtig håndtering.
Udskiftning må kun ske med batteri af samme fabrikat og type. Levér
det brugte batteri tilbage til leverandøren. (Danish)
VARNING! Explosionsfara vid felaktigt batteribyte. Använd
samma batterityp eller en ekvivalent typ som rekommenderas
av apparattillverkaren. Kassera använt batteri enligt fabrikantens
instruktion. (Swedish)
VAROITUS! Paristo voi räjähtää, jos se on virheellisesti asennettu. Vaihda
paristo ainoastaan laitevalmistajan sousittelemaan tyyppiin. Hävitä
käytetty paristo valmistagan ohjeiden mukaisesti. (Finnish)
ATTENTION! Il y a danger d’explosion s’il y a remplacement incorrect
de la batterie. Remplacer uniquement avec une batterie du mêre
type ou d’un type équivalent recommandé par le constructeur.
Mettre au rebut les batteries usagées conformément aux instructions
du fabricant. (French)
ADVARSEL! Eksplosjonsfare ved feilaktig skifte av batteri.
Benytt samme batteritype eller en tilsvarende type anbefalt
av apparatfabrikanten. Brukte batterier kasseres i henhold til
fabrikantens instruksjoner. (Norwegian)
(Japanese)
ASUS Eee PC
A-19
CTR 21 Approval
(for Eee PC with built-in Modem)
Danish
Dutch
English
Finnish
French
German
Greek
Italian
Portuguese
A-20
Appendix
Spanish
Swedish
ASUS Eee PC
A-21
GNU General Public License
Licensing Information
This product includes copyrighted third-party software licensed
under the terms of the GNU General Public License. See The GNU
General Public License for the exact terms and conditions of this
license.
Specially, the following parts of this product are subject to the GNU
GPL:
• The Linux operating system kernel
• Firefox
• Kworldclock
• Pidgin
• KCal
• Kontact
• KSnapshot
• Thunderbird
• Knotes
• Kalzium
• Kstars
• Tux Typing
• KMessedWords
• KHangMan
• Kbruch
• Tux, of Math Command
• Kig
• KmPlot
• mtPaint
• Tux Paint
• KPatience
• Frozen Bubble
• Crack Attack
• GNOME Sudoku
• KTuberling
• LTris
• The KControl Xprinters Module
• The KControl Clock Module
• GSynaptics
All listed software packages are copyright by their respective
authors. Refer to the source code for detailed information.
ASUSTeK COMPUTER Inc. has exposed the full source code of the
GPL licensed software, including any scripts to control compilation
and installation of the object code. All future firmware updates will
also be accompanied with their respective source code. For more
information on how you can obtain our open source code, visit our
website (http://support.asus.com.tw/download/).
