Users Manual Part 9
ProScale M150, M250 and all products with General Purpose LCD Digital Displays 43 of 43
Description Part Number Description / Use
Digital Display, LCD, (Fully Programmable) 700-1600-200 ProScale M150/250, AA Batteries
Digital Display, LCD, (Fully Programmable) 700-1600-205 ProScale M150/250, 24 VDC
Digital Display, LCD, (Basic) 700-1600-220 ProScale M150/250, AA Batteries
Digital Display, LCD, 1/4 DIN Panel Mount 700-1600-300 ProScale M150/250, 24 VDC
Digital Display, LCD, 1/4 DIN Panel Mount 700-1600-400 ProScale M150/250, 2D Batteries
Readhead, ABS, 12 inch cable 701-1500-012 ProScale M150/250
Readhead, ABS, 24 inch cable 701-1500-024 ProScale M150/250
Readhead, ABS, 36 inch cable 701-1500-036 ProScale M150/250
Readhead, ABS, 72 inch cable 701-1500-072 ProScale M150/250
Readhead, ABS, 120 inch cable 701-1500-120 ProScale M150/250 (standard)
Readhead, ABS, 20 foot cable 701-1500-240 ProSet
Readhead, ABS, Coiled Cable, 80 inch 701-1500-C80 ProKits, ProScale M150 & 250
Readhead, ABS, custom cable length 701-1500-xxx 'xxx' = length in inches
Readhead, INC, 12 inch cable 701-1500-N12 ProPanel, ProStop, M.T. Kits
Readhead, INC, 24 inch cable 701-1500-N24 ProScale M200
Readhead, INC, 72 inch cable 701-1500-N72 ProScale M100
Readhead, Digi, 12 inch cable 701-1500-D12 Digi-Fence, Digi-Stop
Readhead, Digi, 36inch cable 701-1500-D36 Digi-Scale Models 10 & 20
Readhead, Digi, 72 inch cable 701-1500-D72 Digi-Scale Models 10 & 20
Scale, ABS, 10in / 250mm measuring range 700-1500-010 ProScale Model 150-10 Scale
Scale, ABS, 18in / 450mm measuring range 700-1500-018 ProScale Model 150-18 Scale
Scale, ABS, 12in / 300mm measuring range 700-2500-012 ProScale Model 250-1 Scale
Scale, ABS, 24in / 600mm measuring range 700-2500-024 ProScale Model 250-2 Scale
Scale, ABS, 52in / 1.3m measuring range 700-2500-052 ProScale Model 250-4 Scale
Scale, ABS, 96in / 2.4m measuring range 700-2500-096 ProScale Model 250-8 Scale
Scale, ABS, 120in / 2.9m measuring range 700-2500-120 ProScale Model 250-10 Scale
Scale, ABS, 144in / 3.6m measuring range 700-2500-144 ProScale Model 250-12 Scale
Scale, ABS, 240in / 6.0m measuring range 700-2500-240 ProScale Model 250-20 Scale
Scale, INC, 10in / 250mm measuring range 700-3000-010 ProScale Model 100-10
Scale, INC, 18in / 450mm measuring range 700-3000-018 ProScale Model 100-18
Scale, INC, 52in / 1.3m measuring range 700-3000-052 M200, M.T.K, ProStop,-Kit,-Panel
Scale, INC, 96in / 2.4m measuring range 700-3000-096 M200, M.T.K, ProStop, ProKit
Scale, INC, 120in / 2.9m measuring range 700-3000-120 M200, M.T.K, ProStop, ProKit
Scale, INC, 240in / 6.0m measuring range 700-3000-240 M200, M.T.K, ProStop
SPC Cable, 3m, 10 pin to 10 pin 700-1003-001 SPC out to peripheral devices
Universal Mounting Kit 902-0001-001 Installation brackets 150/250
Connector Links, Package of 5 100-1025-005 Used with Model 150 systems
Guide Clips, Package of 5 100-1026-005 Used with Model 250 systems
Fixed Price Repair (call for RMA) Model Description
Readheads 450-1010-001 All ProScale Systems
Digital Displays 450-1030-001 All ProScale Systems
Scales 450-1060-001 Scales up to 24 inches (600 mm)
Scales 450-1061-001 Scales up to 60 inches (1.5m)
Scales 450-1062-001 Scales up to 150 inches (3.8m)
Scales 450-1063-001 Scales up to 220 inches (5.6m)
Scales 450-1064-001 Scales up to 240 inches (6.0m)
SECTION 7 S
PARE PARTS
ProScale M150, M250 and all products with General Purpose LCD Digital Displays 44 of 44
PRODUCT REGISTRATION
Fill out for your records and
FAX to Accurate Technology @ +1.828.654.8824 or
Register on line at http://www.proscale.com/registration.htm
Name
E-Mail
Company
Address
Address
City
State/Region
Zip/Postal Code
Country
Purchased From:
Purchased When:
ProScale Serial Number:
ProScale M150, M250 and all products with General Purpose LCD Digital Displays 45 of 45
Thank you for choosing a ProScale Product
MADE IN USA
Accurate Technology, Inc.
270 Rutledge Rd. Unit E
Fletcher, NC 28732 USA
800 233-0580 • 828-654-7920
Fax 828-654-8824
www.proscale.com
customerservice@accurate-technology.com
This manual is available at www.proscale.com
Please return your Product Registration Card
or register your system at:
http://www.proscale.com/registration.htm
P/N 800-1097-001, Revision E, Copyright © 2002-4, Accurate Technology, Inc. All rights reserved.
