Arts Electronics LPP1000 TURNTABLE AUDIO SYSTEM User Manual 2
Arts Electronics Co., Ltd TURNTABLE AUDIO SYSTEM 2
Contents
user manual 2
25
ENGLISH
Setting the clock (1)
Set the current time before using the unit.
You can set the clock when the unit is in standby.
1 Press the STANDBY/ON button to put
the unit into standby.
NOTE
When the ring around the button is not lit blue, the
unit is in standby. Note that the clock cannot be set
when the unit is on.
2 Press and hold the CLOCK ADJUST but-
ton for at least 2 seconds.
Press and hold for at
least 2 seconds
“SET CLOCK” scrolls across the display.
3 Press the TIME (j/k) buttons to switch
between 24 HOUR and 12 HOUR (24-
hour or 12-hour time display).
c3
oIf a setting is left for more than 20 seconds, this
time setting mode will end.
4 Press the CLOCK ADJUST button again.
Display example
The “hour” value blinks.
5 Press the TIME (j/k) buttons to set
the current hour.
Continued on the next page
LP-P1000_OM_EF_vA_CS6.indb 25 2013/09/11 16:16
26
Setting the clock (2)
6 Press the CLOCK ADJUST button.
Display example
The minute value blinks.
7 Press the TIME (j/k) buttons to set
the current minute.
8 Press the CLOCK ADJUST button.
This completes the procedures for setting the time.
The clock will start from the set minute at 0 seconds.
oThe unit’s clock and wakeup timer settings will be
erased if a power outage occurs or the power cord is
unplugged from an outlet.
Current time display
The clock is always shown when the unit is in standby
mode (off) and when the function is set to PHONO/
AUX.
Press the remote control's DISPLAY button to show the
clock on the display.
oThe current time is shown for 3 seconds in CD and
FM/AM modes.
Display example
Current time
oThe DISPLAY button does not function in AUX/
PHONO and Bluetooth modes.
oIn Bluetooth mode, the current time is only shown
when paired.
LP-P1000_OM_EF_vA_CS6.indb 26 2013/09/11 16:16
27
ENGLISH
Basic operation (1)
3 Turn the VOLUME knob to adjust the
volume.
MIN (0): minimum volume
MAX (40): maximum volume
Turn the VOLUME knob right to raise the volume
and left to lower it.
oThe default value is 20.
oWhen you turn the VOLUME knob, the volume
will be shown for about 3 seconds.
oWhen the volume is at minimum level, “MIN”
appears on the display. At maximum, “MAX”
appears.
V Sudden loud noises could damage your hear-
ing or cause other harm. Set the volume to
minimum. After sound output begins, adjust
the volume to a suitable level.
oWhen not using this unit, press the STANDBY/ON
button to put the unit into standby.
1 Press the STANDBY/ON button to turn
the unit on.
The ring around the STANDBY/ON button lights
blue when on.
oEven when in standby (unit off), pressing a func-
tion button will turn the unit on.
2 Press a function button to set the play-
back source.
When a playback source is selected, the corre-
sponding indicator appears on the display.
Record
External input
Radio
CD
Bluetooth
LP-P1000_OM_EF_vA_CS6.indb 27 2013/09/11 16:16
28
Basic operation (2)
Adjusting the bass, treble and stereo
balance
1 Press the SOUND button to select the
item you want to adjust.
Pressing the SOUND button cycles through the
items in the following order.
BASS TREBLE BALANCE
Ordinary display
2 Within 3 seconds, start using the
VOLUME (+/−) buttons to adjust the
setting.
oIf 3 seconds pass without any adjustment, the
setting mode will end.
Setting items and ranges
BASS (low frequencies)
Use to adjust the bass.
Setting range: −5 to +5
Default value: 0
Display example
TREBLE (high frequencies)
Use to adjust the treble.
Setting range: −5 to +5
Default value: 0
Display example
BALANCE
Use to adjust the left-right stereo balance.
Setting range: L+10 to R+10
Default value: CENTER
Display example
You should usually leave BALANCE set to CENTER.
LP-P1000_OM_EF_vA_CS6.indb 28 2013/09/11 16:16
29
ENGLISH
Adjusting the brightness of the display
Press the DIMMER button to cycle through the follow-
ing brightness settings.
Ordinary brightness Dim Very dim
oWhen the unit enters standby, the dimmer setting is
reset to ordinary brightness.
Muting the output
Press the MUTE button to temporarily silence the out-
put. Press the MUTE button again to resume output at
the previously set volume level.
oWhen the mute function is active, “MUTE” appears on
the display.
oWhen the mute function is active, adjusting the vol-
ume will unmute the output.
oWhen the mute function is active, changing the
source will unmute the output.
LP-P1000_OM_EF_vA_CS6.indb 29 2013/09/11 16:16
30
Listening to a CD (1)
1 Press the CD/Bluetooth button to select
CD.
Press the CD/Bluetooth button again to switch
between CD and Bluetooth.
After switching to CD, “DISC” will appear, “READING”
will blink for several seconds, and then the CD will
be in a stopped state. If no disc is loaded, “NO DISC”
appears on the display.
2 Press the open/close (-) button to
open the tray.
The disc tray opens forward.
3 Place a disc centered on the tray with
the labeled side up.
oNever place more than one disc on the tray.
oIf the tray is closed while a disc is outside the center
guides, the disc might become stuck inside and the
tray might not open. Be sure to always place discs
within the guides at the center of the tray.
oDo not force the tray by hand when opening or
closing.
4 Press the open/close (-) button to
close the tray.
Be careful not to let your fingers be pinched when
the tray closes.
oThe unit takes a few seconds to load the disc. No
buttons will work when “READING” is displayed.
Wait until the disc information is displayed.
LP-P1000_OM_EF_vA_CS6.indb 30 2013/09/11 16:16
31
ENGLISH
Audio CD display example
Total number of tracks Total playback time
MP3/WMA disc display example
Folder number File number
oA non-audio disc might be “played” in the same
manner as an audio disc, but sound will not be
output.
oWhen a WMA disc is loaded, “WMA” will appear
on the left side of the display.
5 Press the play/pause (y/9) button.
Playback will start from the first track and y will
appear on the display.
Track number Playback elapsed time
oIf you press the play/pause (y/9) button
without closing the disc tray, the tray will close
automatically and playback will start.
oMP3/WMA files that are not placed in a subfolder
are in the “001 (ROOT)” folder. Playback starts
from the first track in the “001 (ROOT)” folder.
oFor details about the playback order of MP3/
WMA files, see page 39.
oAfter all tracks have played, playback will auto-
matically stop.
LP-P1000_OM_EF_vA_CS6.indb 31 2013/09/11 16:16
32
Pausing playback
Press the play/pause (y/9) button to pause playback.
When paused, press the play/pause (y/9) button to
resume playback from the paused point.
oWhen paused, the playback time will blink.
Listening to a CD (2)
Stopping playback
Press the stop (8) button to stop playback.
LP-P1000_OM_EF_vA_CS6.indb 32 2013/09/11 16:16
33
ENGLISH
Skipping tracks/files
During playback, turn the skip (.//) knob to skip
to the previous or next track/file and start playback.
Keep turning until you reach the desired track number.
oWhen stopped, after selecting a track with the skip
(.//) knob, press the play/pause (y/9) but-
ton to start playback.
oDuring playback, turn slightly toward . to return
to the beginning of the currently playing track. To
play an earlier track, continue turning toward ..
Search for a part of a track
During playback, press and hold a search (m/,)
button to search forward/backward. When you stop
pressing, ordinary playback will resume.
oNo sound is output when searching forward or back-
ward, but the time display changes.
LP-P1000_OM_EF_vA_CS6.indb 33 2013/09/11 16:16
34
Programmed playback (1)
Up to 32 tracks/files can be programmed in the desired
order.
Program tracks when playback is stopped.
Programming tracks/files
1 Press the CD/Bluetooth button to select
“ C D ”.
2 Press the MEMORY button when
stopped.
Display example
Program number
The track number (or folder and file numbers) and
the MEMORY indicator blink.
oTo stop programming, press the stop (8) button
or wait 20 seconds or more.
oDuring programming if you do nothing for 20
seconds or more, the program will be confirmed.
Example of display after program confirmation
3 Select a track to add to the program.
With an audio CD
Use the skip/search (.m/,/) buttons
to select a track by number.
Display example
Track number
With an MP3/WMA disc
To select a folder by number, use the MP3 (j/k)
buttons.
LP-P1000_OM_EF_vA_CS6.indb 34 2013/09/11 16:16
35
ENGLISH
To select a file by number, use the skip/search
(.m/,/) buttons.
Display example
Folder number File number
oThis unit treats MP3/WMA files that are not in
folders as being in the 001 (ROOT) folder.
oIf you change the folder or file number, only the
MEMORY indicator will blink.
4 Press the MEMORY button.
The selected track is added to the program, and
“P02” appears on the display.
oTo program multiple tracks, repeat steps 3 to 4.
oTo stop programming, press the stop (
8
) button.
5 When you have nished adding tracks
to a program, press the play/pause
(y/9) button to start programmed
playback.
oTo stop programmed playback, press the stop (8)
button. The contents of the program are retained.
oDuring programmed playback, use the skip/search
(.m/,/) buttons to select different
tracks/files in the program. You can also use the scroll
(MULTI JOG) knob on the main unit for this operation.
oDuring programmed playback, shuffle playback
(page 39) is not possible.
oThe display will appear as follows when programmed
playback completes.
Display example
Total number of program tracks
Continued on the next page
LP-P1000_OM_EF_vA_CS6.indb 35 2013/09/11 16:16
36
Checking the program order
When stopped, press the MEMORY button to cycle
through the program numbers and the programmed
track numbers in order.
Adding tracks to the end of the program
1 When stopped, press the MEMORY but-
ton repeatedly to show the number
which is one higher than the last pro-
gram number.
When using an audio CD, the track number and
MEMORY indicator will blink.
When using a MP3/WMA disc, the folder number,
file number and MEMORY indicator will blink.
2 Press the .m or ,/ button
to select a track.
3 Press the MEMORY button.
The track/file is added to the end of the program.
Changing a track/file within the program
1 When programmed playback is stopped,
press the MEMORY button repeatedly
until the program number of the track/
le you want to change appears on the
display.
2 Use the skip/search (.m/,/)
buttons to select the track that you
want to use as a replacement in the
program.
Programmed playback (2)
