Arts Electronics LPP1000 TURNTABLE AUDIO SYSTEM User Manual 3
Arts Electronics Co., Ltd TURNTABLE AUDIO SYSTEM 3
Contents
user manual 3
37
ENGLISH
3 Press the MEMORY button.
The selected track/file is added at the selected pro-
gram number, replacing the file that was there.
Clearing all the program contents
Press and hold the stop (8) button for at least 2 sec-
onds when stopped.
The contents of the program are cleared.
When the contents of the program are cleared,
“PROGRAM CLEAR” scrolls across the display.
oThe program is also cleared in the following cases.
• The unit enters standby mode
• The PHONO/AUX, FM/AM or CD/Bluetooth button
is pressed, changing the source
• The disc tray is opened
LP-P1000_OM_EF_vA_CS6.indb 37 2013/09/11 16:16
38
Repeat and shuffle playback
e
When the CD function is active, press the PLAY MODE
button to cycle through the following playback modes.
When an audio CD is loaded
REPEAT (single track repeat)
REPEAT ALL (all track repeat)
SHUFFLE*
OFF (normal playback)
When an MP3/WMA disc is loaded
REPEAT (single file repeat)
REPEAT FOLDER
REPEAT ALL (all file repeat)
SHUFFLE*
OFF (normal playback)
Press the play/pause (y/9) button when the mode
you want to select appears to start playback.
*If shuffle is selected, playback starts automatically.
oYou can also change the playback mode by pressing
the PLAY MODE button during playback.
oAny of the following operations will end repeat or
shuffle playback mode.
• The stop (8) button is pressed
• The unit enters standby mode
• The PHONO/AUX, FM/AM or CD/Bluetooth button
is pressed, changing the source
• The disc tray is opened
Repeat playback
REPEAT (single track/file repeat)
During playback, press the PLAY MODE button once
to repeat playback of the currently playing track/file.
“REPEAT” appears on the display.
oIf you turn the main unit's skip (.//)
knob or press the remote control's skip/search
(.m/,/) buttons and select another
track/file, that track/file will be played repeatedly.
oWhen stopped, press the PLAY MODE button and
then use the main unit's skip (.//) knob or
remote control's skip/search (.m/,/)
buttons to select a track/file. Press the play/pause
(y/9) button to start single repeat playback.
oDuring programmed playback, the track/file being
played will be played repeatedly.
REPEAT ALL (all track/file repeat)
Press the PLAY MODE button twice (or three times for
an MP3/WMA disc).
“REPEATALL” appears on the display and repeat play-
back of all tracks/files starts.
oDuring programmed playback, the programmed
tracks/files will be played repeatedly.
LP-P1000_OM_EF_vA_CS6.indb 38 2013/09/11 16:16
39
ENGLISH
REPEAT FOLDER
(MP3/WMA discs only)
Press the PLAY MODE button twice.
“REPEAT FOLDER” appears on the display, and the files in
the selected folder are played back repeatedly.
Shuffle playback
All the tracks/files on the disc are played back randomly.
SHUFFLE
Press the PLAY MODE button repeatedly until “SHUFFLE”
appears on the display.
oDuring shuffle playback, turn the main unit's skip
(/) knob right or press the remote control's skip/
search (,/) button to start playback of the
next random track/file.
Turn the main unit's skip (.) knob left or press the
remote control's skip/search (.m) button to
return to the beginning of the current track/file.
oShuffle playback is not possible during programmed
playback.
About MP3/WMA files (1)
File playback order
A disc that contains MP3/WMA files can have the files
in folders in the same manner that files are managed
on an ordinary computer. One folder can also contain
multiple subfolders.
Example of folder numbers and file playback
order ( 1 to 9) during normal playback of a disc
that contains MP3/WMA files
001 “ROOT”
1
2
3
4
8
9
6
7
5
MP3/WMA file
MP3/WMA file
MP3/WMA file
MP3/WMA file
MP3/WMA file
MP3/WMA file
MP3/WMA file
MP3/WMA file
MP3/WMA file
002 folder
001 (ROOT)
004 folder
003 folder
005 folder
Folder
oAdding, removing or relocating files and fold-
ers could change the order shown in the above
illustration.
LP-P1000_OM_EF_vA_CS6.indb 39 2013/09/11 16:16
40
About MP3/WMA files (2)
Changing the display
Each time you press the INFO button, the information
on the display changes as follows.
oThe first 32 characters of the song/artist/album
names are shown.
oIf the file information uses Japanese, Chinese or
other double-byte characters, playback is possible
but information will not be shown correctly on the
display.
oAfter each item of information scrolls across three
times, the elapsed playback time will appear again.
oWhen a WMA disc is loaded, “WMA” will appear on
the left side of the display.
Selecting folders and files
To select a folder by number, use the main unit's search
(m/,) buttons.
When using the remote, use the MP3 (j/k) buttons.
To select a file by number, use the main unit's scroll
(MULTI JOG) knob.
oAfter selecting the folder/file number, press the play/
pause (y/9) button to start playback.
If the play button is not pressed within 5 seconds,
“STOP” will appear on the display.
LP-P1000_OM_EF_vA_CS6.indb 40 2013/09/11 16:16
41
ENGLISH
Display example
Track number Playback elapsed time
c
File name
c
Folder name
c
Title name
c
Album name
c
Artist name
LP-P1000_OM_EF_vA_CS6.indb 41 2013/09/11 16:16
42
Listening to audio from a Bluetooth device
With this unit, you can enjoy listening to music played
back on another Bluetooth device wirelessly.
1 Press the CD/Bluetooth button to select
“Bluetooth”.
“PAIRING” appears on the display, and the unit
searches for paired devices.
oPress the CD/Bluetooth button to select “Bluetooth”
(the Bluetooth indicator lights).
When connection with a Bluetooth device succeeds,
the Bluetooth icon ( ) appears and “BLUETOOTH”
scrolls across the display.
Bluetooth figure mark
c
After “BLUETOOTH” scrolls across 5 times, the current
time is shown.
oThe unit will automatically try to connect to the
previously connected device.
oIf it cannot connect for two minutes or longer,
“NO DEVICE CONNECTED” will scroll across the
display.
oPairing is necessary before using the Bluetooth
function of this unit for the first time and when
you want to connect a new Bluetooth device.
oIf connection fails, confirm that the other
Bluetooth device is able to make a Bluetooth
connection.
oIf the connection is broken during use, “NO
DEVICE CONNECTED” scrolls across this unit's dis-
play. Conduct the connection operations again
on this unit and the other Bluetooth device.
LP-P1000_OM_EF_vA_CS6.indb 42 2013/09/11 16:16
43
ENGLISH
2 Operate the Bluetooth device to start
playback.
If the connected Bluetooth device supports AVRCP,
you can use this unit or the remote control to play,
pause or stop audio on that device.
Depending on the Bluetooth device being used,
remote control operation might not be supported
or actual operations might differ.
oThe volume, however, cannot be adjusted
remotely.
Audio/Video Remote Control Profile (AVRCP)
To control playback of a Bluetooth device, the
Bluetooth device must support AVRCP.
Some Bluetooth devices, however, have different func-
tions depending on their specifications.
oDepending on the Bluetooth device, skipping
tracks might not be possible using this unit’s skip
(.//) knob. In this case, use this unit’s search
(m/,) buttons.
oIf you cannot control another Bluetooth device with
this unit, operate the other Bluetooth device directly.
Unpairing a device
To unpair with a connected Bluetooth device, press the
PAIRING button.
oIf you later want to use a Bluetooth connection with
that Bluetooth device, you must pair them again.
oThis deletes all pairing information. Unpairing with
just one device is not possible.
LP-P1000_OM_EF_vA_CS6.indb 43 2013/09/11 16:16
44
Pairing with another Bluetooth device
Pairing is necessary before using the Bluetooth function
of this unit for the first time and when you want to con-
nect a new Bluetooth device.
Follow these procedures to pair the unit with the other
device.
Pairing
1 Press the CD/Bluetooth button to select
“Bluetooth”.
After “BLUETOOTH” scrolls across the display,
“PAIRING” appears, showing that the unit is ready to
be paired with another device.
Bluetooth indicator
c
If it cannot connect for two minutes or longer, “NO
DEVICE CONNECTED” will scroll across the display.
To begin pairing from this state, press the PAIRING
button to put the unit into pairing mode. “PAIRING”
appears on the display.
2 Enable the Bluetooth communication
function on the other Bluetooth device.
LP-P1000_OM_EF_vA_CS6.indb 44 2013/09/11 16:16
45
ENGLISH
3 From the Bluetooth device select
“LP-P1000” (this unit).
oIf a passkey is required during pairing, input
“0000”.
When connection succeeds, the unit will make an
electronic beeping sound, and the Bluetooth figure
mark ( ) will appear on the display.
oIf it cannot connect for two minutes or longer, “NO
DEVICE CONNECTED” will scroll across the display
and pairing mode will end.
oThis unit can retain pairing data for up to 5 devices.
After 5 devices have been paired, if a new device is
paired, the oldest pairing will be overwritten.
oWhen a Bluetooth device is connected, if you
change the input with a function button or press the
STANDBY/ON button to put the unit into standby
mode, the next time the unit is turned on, the last
connected Bluetooth device will automatically
connect again assuming it is in range and has its
Bluetooth function activated.
oIf you disconnect from the other Bluetooth device,
“NO DEVICE CONNECTED” will appear.
oIf the other Bluetooth device is waiting to pair, pair-
ing will occur automatically when this unit enters
pairing mode.
Listening to records (1)
Before using the record player, use a coin or other tool
to turn the transport locking screw clockwise until it
stops. Remove the stylus cover (made of white plastic)
(page 23).
1 Press the PHONO/AUX button to select
“PHONO”.
Each time the PHONO/AUX button is pressed,
PHONO (record) and AUX (external component) are
selected alternatively.
2 Open the turntable cover slowly.
V Be careful not to pinch your hand, for exam-
ple, when closing the turntable cover.
Continued on the next page
LP-P1000_OM_EF_vA_CS6.indb 45 2013/09/11 16:16
46
6 Lift the cue lever to raise the tone arm.
Tone arm
Cue lever
oYou can also leave the cue lever down and move
the raised tone arm over the record and then
lower the tone arm slowly to start playback.
7 Move the tone arm to the edge of the
record or the track where you want to
start playback.
When you move the tone arm toward the record,
the turntable will begin to turn.
Listening to records (2)
3 Place a record on the turntable.
When playing a 45 RPM large-hole single record,
use the included adapter.
4 Set according to the rotation speed
(RPM) of the record.
The rotation speed can be set to one of three
options: 33 1/3, 45 or 78.
5 Move the tone arm clasp to the right to
release the tone arm.
Clasp
LP-P1000_OM_EF_vA_CS6.indb 46 2013/09/11 16:16
47
ENGLISH
8 Slowly lower the cue lever to slowly
lower the tone arm.
Tone arm
Cue lever
oDuring record playback, you can close the turn-
table cover to avoid dust.
V Do not place anything on the turntable cover.
Objects on the cover might cause noise due
to vibrations or fall off, especially during
playback.
During record playback, feedback could occur if
the volume is too loud. If this happens, turn the
VOLUME knob left to lower the volume.
When playback finishes
When the end of the record is reached, the tone arm
automatically returns to the tone arm holder and turn-
table rotation stops (auto return function).
oTo stop playback manually, slightly lift the tone arm
using the cue lever or a finger and return the tone
arm to the tone arm holder.
Tone arm
Cue lever
The auto return function might not work
depending on the record. In that case, move the
tone arm back to its original position manually.
LP-P1000_OM_EF_vA_CS6.indb 47 2013/09/11 16:16
48
Automatic station selection
Press a j/k button repeatedly until the frequency
begins to change. After the frequency starts chang-
ing, stop pressing the button to start automatic station
selection.
When using the main unit
When using the remote control
o“SEARCH” appears on the display until the station is
found.
Display example
oWhen a radio station is received, automatic station
selection ends.
oTo cancel automatic station selection, press a j/k
button again.
oIf the reception is poor or the antenna is discon-
nected, “PLEASE CHECK ANTENNA” scrolls across on
the display. Check the antenna position and connec-
tion and then try the operation again.
Listening to the radio
Press the FM/AM button to select FM or AM band.
When using the main unit
When using the remote control
FM radio reception example
c
AM radio reception example
c
LP-P1000_OM_EF_vA_CS6.indb 48 2013/09/11 16:16
