Chantry Networks BP200E Access Point with WLAN and UNII User Manual addendum QS1

Chantry Networks Inc. (a Siemens Company) Access Point with WLAN and UNII addendum QS1

quick start guide addendum

Caution:
• There should be at least 9 inches (20 cm) separation between the
BeaconPoint and users.
• Any changes or modifications not expressly approved by Chantry
Networks could void the user’s authority to operate the equipment.
• The BeaconPoints shall be powered by UL approved limited power source
adapter or UL approved limited power source power over ethernet
(P.O.E.).
• The BP200 product will automatically discontinue transmission in case of
either absence of information (no frames transmitted through Ethernet) to
transmit or operational failure.
Chantry
Beaconworks
Addendum to Quick Start Guide
Release 1.1
Updated June 17th, 2004
Warning:
• When the BP200E is enabled in the 5.15 to 5.25 GHz band, it is
authorized for indoor deployment only.
• When the BP200E is enabled in the 5.15 to 5.25 GHz band, the antennas
are permanently attached to the access point. Do not attempt to disconnect.
Note:
The BP200 has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
• Install ferrite bead onto the BeaconPoint 200 data cord as
illustrated below.
• Install ferrite beads onto the BeaconMaster power and data
cords as illustrated below.
Power Cord
,
RJ45 Data Cord
,
Steward
28A2024-0A0
Steward
28A5776-0A2
RJ45 Data Cord
,
Ferrico
K1 NF-65 BK 2
