Cheng Uei Precision Industry H500 Bluetooth Headset User Manual

Cheng Uei Precision Industry Co., Ltd. Bluetooth Headset

Contents

Part 2 Preliminary Manual

3
4
DRAFT
TURNING ON AND OFF CHANGING FOR
LEFT EAR WEAR
Open the ear hook 90
degrees from the
headset.
Gently lift and pull the
top of the ear hook up
and off the upper hinge
pin. Then, pull it away to
remove it.
Flip the headset over.
Hook the bottom of the
ear hook onto the lower
hinge pin, then lift and
pull the top of the ear
hook over the upper
hinge pin.
1
2
3
4
You can wear your H500 headset on your left or
right ear. The headset comes ready for the right
ear. To change the headset for the left ear:
WEARING THE
HEADSET
MAKING CALLS MUTING A CALL
To turn your headset on, press the Call
button. The LED indicator light flashes when
the power is on.
To turn you headset off, press the Call
button. The LED indicator light turns off
when the power is off.
LED INDICATOR LIGHTS
IMPORTANT:
Be sure to first follow the
Quick Start Guide
on the reverse side
of this guide
to complete initial setup
of your H500.
Open the ear piece.
Loop the ear piece over your ear.
Position the microphone as necessary.
Press the headset to your ear.
1
2
CHANGING VOLUME
BUTTON ORIENTATION
3
4
040067o
040059o
If you change your headset for left ear wear,
you can also change the orientation of the
volume buttons.
Turn the headset power off.
Press the Call button and the volume
button you want to assign as the
"volume up" button until the LED
indicator light flashes twice.
The headset power turns on.
1
2
To mute a call, press both volume buttons.
FOR MORE INFORMATION ON USING
YOUR MOTOROLA H500
Visit us at www.hellomoto.com/bluetooth and
click Support.
SUPPORT
If you need more help, contact us at
1- 877-MOTOBLU.
AUDIO TONES
The audio tones provide information about your
headset status.
Audio Tone Headset Status
Single high tone when Volume minimum or
pressing volume button maximum reached
Five rapid high tones Low battery
repeated every 20 sec.
No audio indications; Out of range
detereriorating audio
quality
Series of 4 tones, low Audio link open
to high (headset mode)
Active call
(handsfree mode)
Ring tone Incoming call
Single high tone Pairing confirmation
Single low tone Voice activation
Dual high/low tone Voice tag not
   recognized
Single high tone End call
The LED indicator light provides information
about your headset status.
With the Charger Plugged In
Headset Indicator Headset Status
Off Charging in progress
On (steady) Charging complete
With No Charger Plugged In
Headset Indicator Headset Status
Off Power off
On (steady) Pairing mode
10 rapid flashes Pairing successful
Pulsing (2 seconds
on, 6 seconds off) Connected (on a call)
Flashing (.1 second on,
2.9 seconds off) Standby (not on call)
Call
Button
Volume
Buttons
Call Button
To make a voice dial call, short press the Call
button and speak the name.
To end a call, short press the Call button.
To put an active call on hold, long press the
Call button.
To resume a call on hold, long press the Call
button.
To receive a call, short press the Call button.
To reject a call, long press the Call button.
To answer a second incoming call, long
press the Call button (places first call on hold).
To toggle between two active calls, long
press the Call button.
To transfer a call from the phone to
headset, short press the Call button.
Note: Your H500 supports both Handsfree and Headset
Profiles. Accessing call functions depends upon which
profile your phone supports. See your phone's user's guide
for more information.
Quick Use
H500
Bluetooth®
Handsfree Headset
040059o
1 Open Ear Hook
2 Pull Ear Hook Up
