Manual 2 of 2
©2012 大疆创新 版权所有 4 |
Control mode Descriptions Specification
GPS ATTI
ATTI Manual
Operating
Temperature -10°C ~ 50°C
Power
Consumption 3.12W
Take-off Weight <1200g
Hovering Accuracy
(GPS Mode)
Vertical: ± 0.8m
Horizontal: ± 2.5m
Max Yaw Angular
Velocity 200°/s
Max Tilt Angle 45°
Max Ascent /
Descent Speed ±6m/s
Max Flight Velocity 10m/s
Rudder
Velocity
Maximum rudder angular velocity is 200°/s
Command
Stick Meaning
Multi attitude control; Stick center position
for 0˚ attitude, its endpoint is 45˚.
Max-angular
velocity is 150°/s.
Altitude Lock
Maintain the altitude best above 1 meter
from ground.
NO
Stick
Released
Locks multi-rotor position
when GPS signal is
adequate.
Attitude
stabilizing.
Not
Recommended
GPS Lost
When the GPS signal is
lost for more than
10seconds, the system
enters Atti. Mode
automatically.
Only attitude
stabilization,
GPS /
position lock
not used in
this mode.
GPS not used
Safety
Voltage alarm
Depends on
experience.
Enhanced Fail-Safe
Auto Level
Fail-Safe
Applications
AP work
Sports flying. Extreme flying
Warning & Disclaimer Notes
Please strictly follow these steps to use the
PHANTOM. DJI Innovations accepts no liability
for damage(s) or injuries incurred directly or
indirectly from the use of this product.
This manual will help you to get ready to fly. You
can download an advanced manual from the
DJI website which may lead you to know the
performance of the phantom further and
enhance your flight experience.
DJI and PHANTOM are registered trademarks
of DJI Innovations. Names of product, brand,
etc., appearing in this manual are trademarks or
registered trademarks of their respective owner
companies. This product and manual are
copyrighted by DJI Innovations with all rights
reserved. No part of this product or manual shall
be reproduced in any form without the prior
written consent or authorization of DJI
Innovations. No patent liability is assumed with
respect to the use of the product or information
contained herein.
Make sure the positive and negative poles of the battery are connected correctly.
Keep the antennas of TX and RX visible to each other (no obstacles).
Avoid any impact by external forces to keep the high accuracy performance of the
multi rotor and Tx.
Do not disassemble or modify your multi rotor or transmitter.
Not waterproof and not oil-proof.
Keep the flight away from objects, such as obstacles, human beings, high-voltage
lines, etc.
Do not get close to or even touch the rotating motors and propellers, which will
cause serious injury.
Do not over load the multi-rotor, i.e. do not carry heavy weight
Check that the propellers and the motors are installed correctly and firmly before
flight.
Make sure the rotation direction of each propeller is correct.
Make sure all parts are in good condition before flight. Do not fly with old or broken
parts.
Please switch on the transmitter first, then power on the quad-rotor before takeoff!
Power off the quad-rotor first, and then switch off the transmitter after landing!
Continuously rotating the multi rotor will cause a yaw error. In this case, you should
stop or slow down the rotating, so as to have better flight performance.
Please use the spares / accessories approved by DJI.
Please contact customer service if you have any problems you cannot solve.
FCC CE ROHS dji-innovations.com
©2012 大疆创新 版权所有 5 |
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
To assure continued compliance, any changes or modifications not expressly approved by the party
Responsible for compliance could void the user’s authority to operate this equipment. (Example- use only
shielded interface cables when connecting to computer or peripheral devices).
RF warning statement:
The device has been evaluated to meet general RF exposure requirement. The device can be used in portable
exposure condition without restriction.
Caution: Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate this equipment.
