Electronique Telematique ETELM Canada BSTETRA460 Tetra Base Station User Manual NetisB25 460 025 464 025 MHz Parts list
Electronique Telematique ETELM Canada Inc Tetra Base Station NetisB25 460 025 464 025 MHz Parts list
Contents
NetisB25 460.025-464.025 MHz Parts list
Alim 48v-56
Parts list
Location
Reference
CONN1, CONN4 MKDS 1,5/2-5,08
C9, C10, C11, C12 C0805F103K1RACTU
C5, C6, C7, C8 EEETG1J101UP+
C1, C2, C3, C4 MR-VJ1206Y104KX
C13, C14 EEU-FC2A221
C15, C16, C17, C18 PHE850EA4470MA03R17
CTH1 Rs Pro 307-935
CON1, CON2, CON3 62000211622
CONN2 9051486951
CONN3 Molex Male connector 24 Way 2 Row PCB Housing
D1, D2, D3, D4 LED 2mm GN
L1, L2, L3, L4, L5, L6 150nH 40A SERDI 1221
PFUS1 0031.8231
R6, R7 1.8K 1206
R1, R5 18K 1206
R2 R510 1206
RV2 Cermet Trimmer 100K BOURNS
RV1 Cermet Trimmer 20K BOURNS
D5 VS-30CPF12PBF
A3 XL160
A4 XL275-48
CPUBDT2_C
Parts list
Component location
Reference
D5,D6,D10 1N5615
T2,T3 2N2222
T1 2N2907
IC11,IC17,IC21 74HC00D
IC22,IC23 74HC02D
IC24 74HC11D
IC100,U1, IC7 74HC14D
IC8,IC10 74HC245D
IC2,IC4,IC6,IC9 74HC573D
IC18,IC20 ADM3077E
D8,D9,D17 BAS16
D11,D12,D13,D14,D15,D16,D18,D19,D20 BAS16VY
BZ1 KSTG931AP
C3,C8,C12,C14,C15,C16,C17,C18,C20,C21,C22,C23,C24,C25,C26,C41,C42,C43,C61,C62,
C63,C64,C71,C72,C73,C88,C89,C90,C91 100nF-0805-50V
C9 100pF 0805 50V 20%
C29,C81,C82,C83,C84,C98,C99,C100,C101,C102,C103 10nF 0805 50V
C33,C34,C35,C36,C37,C38,C39,C40,C92,C93,C94,C95,C96,C97 1nF 0805 50V
C28 220nF 0805 50V
C13,C74,C75,C76,C77,C78 220pF 0805 50V
C44,C45,C46,C47,C48,C49,C50,C51,C52,C53,C54,C55,C56,C57 22nF 0805 50V
C79 470pF 0805 50V
C80 NC 0805 50V
C6,C10,C30,C65 100µF tantalum 2917 16V 20%
C2 1µF tantalum 1206 16V 20%
C85,C86,C87 10µF tantalum 1210 16V 20%
C11 1µF tantalum 1210 16V 20%
C1,C4,C5,C7,C19,C31,C32,C58,C59,C60,C66,C67,C68,C69,C70 10µF tantalum 1210 16V 20%
C27 330µF tantalum 2917 10V 10%
CON2 1655910131
CON3 62000211622
CON3 620002113322
CON1 64900411122
CON1 649004013322
J1 09031966921
IC5 XCF02S
FUS1,FUS2,FUS3 SMF 5A
INT1 TP33W0080
L2,L9 822LY101K+
L1 LQH55DN100M03L
L3,L5,L10 LQH32MN100J23L
L4 ELJNA1R0JF
IC15 LD1086-D2T25
D2 LED 2mm GN
D1,D3,D4,D7,L6,L7,L8 LED 2mm YW
IC14 LM317BD2T
IC16 ICL232
IC19 MC78M05 369A
IC12 MC79M05 369A
GPS1 CLP10402LDTR
J5 M20-6112045
IC30 PIC16F870
TS2,TS3,TS4,TS5 Test plot
TS1,TS7 Test plot
P1 Test plug
TP1,TP2,TP3,TP4,TP5,TP6,TP7,TP10 Test plot
R20,R31 10R 0805 0.25W 5%
R4,R5,R18,R63,R64,R65,R66,R67,R68,R69,R70,R101,R106 100R 0805 0.25W 5%
R105 100R 0805 0.25W 1%
R8,R21,R22,R30 100K 0805 0.25W 5%
R6,R7,R32,R37,R72,R73,R74,R75,R76,R86,R87,R88,R132,R133,R134,R135,R136,R137,R
138,R139,R140,R141 10K 0805 0.25W 5%
R44,R46 150K 0805 0.25W 5%
R99,R102,R107 180R 0805 0.25W 5%
R1,R2,R9,R12,R13,R14,R15,R19,R23,R26,R27,R28,R33,R40,R41,R42,R77,R78,R79,R80,
R81,R82,R83,R84,R90,R91,R92,R93,R94,R95,R96,R97,R100,R103,R104,R108,R109,R110
,R111,R112,R113,R114,R115,R116,R117,R118,R126,R127,R128,R129,R130,R131
1K 0805 0.25W 5%
R98 2.2K 0805 0.25W 5%
R10 270R 0805 0.25W 5%
R11 390R 0805 0.25W 1%
R25,R55,R56,R57,R58,R59,R60,R61,R62,R71 5.1K 0805 0.25W 5%
R36 51R 0805 0.25W 5%
R43 510R 0805 0.25W 5%
R47 510K 0805 0.25W 5%
R45 51K 0805 0.25W 5%
R121,R122,R123,R124,R125 NC 0805 0.25W 5%
RJ1 1840855-3
R16,R17,R34,R35,R38,R39,R85,R89 CAT16 x4 10k
R48 CAT16 x4 1k
R24,R49,R50,R51,R52,R53,R54 CAT16 x4 22k
RV2 Trimmer cermet 10k 3266W
IC25 SN74LVC1T45DBVR
J7,J8,J11,J13,J15,J18,J19,J23,J24 Jumper
J2,J3,J4,J6,J10,J16,J17,J20,J21 Jumper
J22 Solder jumper
J9,J12,J14 Solder jumper
S1 1061 + CR2032
IC1,IC13 ULN2803AFWG
VCXO3 VV-701-DAW-2EAE
VCXO2 VTA7-A11B
VCXO1 VVA1-A3E
TCXO2 VT-803-DAW-107A
IC3 XC2S200PQ208
DCTR_G 460-470 MHz
Parts list
Component location
Reference
D5,D6 1N4148
T7,T8,T9,T10,T12,T2,T3,T4,T5,T6 2N2222A
T1 2N2907-SMC
IC25,U2 74HC00D
U1 74HC14
IC13 74HC245D5V
IC12,IC17 74HC541D
IC1,IC4,IC5,IC6,IC7,IC11 74LVC4245A
IC2 AD7863-3
IC19 ADE-1
IC24 ADF4110BRUZ
IC28 ADP3338AKCZ-3.3RL7
IC10 AM29LV0408
D1,D2,D3 BAV99
TR4,TR5 BCX52
C100 47µF 6.3V SMD
C8,C13,C44,C46 100µF 16V 10%
C166,C196 330µF tantalum 10V 20% SMC
C211,C222,C232,C233,C234 1nF 0402
C98 GRM155R61A105KE15D
C229 1nF 0402
C190,C191 10nF 0402
C134,C163,C164,C205,C213,C220 100nF 0402
C170,C171,C172,C225,C226,C248,C249,C259,C274 100pF 0402
C207 270pF 0402
C94,C127 470pF 0402
C215 10µF tantalum 16V 20% SMC
C5,C182 1nF 0805
C153,C155,C162,C165 1pF 50V 20% 0805
C169,C185,C194,C204 1µF ceramic 16v 10% 0805
C243 4.7nF 0805
C160 4.7pF 50V 20% 0805
C167 6pF 100V 20% 0805
C161 8.2pF 50V 20% 0805
C195,C197,C198,C202,C238 10nF 0805
C7,C39,C83,C84 10pF 100V 20% 0805
C235 12pF 100V 20% 0805
C237 15pF 100V 0805
C97,C102,C103,C125,C128,C142,C143,C146,C188,C200
,C253,C254,C255 22nF 35V 20% 0805
C72,C275 22pF 0805
C109,C110,C114,C115 27pF 35V 20% 0805
C41,C101,C105,C129,C203 47pF 0805
C156,C158,C184 82pF 50V 20% 0805
C1,C6,C9,C10,C11,C12,C14,C15,C16,C17,C18,C19,C23,
C24,C25,C26,C27,C28,C29,C30,C31,C32,C33,C34,C35,
C36,C37,C42,C43,C45,C47,C48,C49,C50,C51,C52,C53,
C54,C59,C60,C61,C62,C65,C66,C69,C70,C71,C74,C75,
C76,C77,C78,C79,C80,C81,C82,C88,C89,C104,C118,C1
19,C120,C121,C126,C132,C140,C141,C147,C148,C151,
C152,C173,C209,C210,C212,C214,C216,C227,C230,C25
2,C262,C266,C267,C270,C271,C277
100nF 0805
C55,C56,C130,C131,C145,C154,C174,C176,C177,C178,
C180,C181,C199,C201,C223,C236,C239,C240,C241,C24
2,C244,C264,C268,C269,C272,C273
100pF 100V 20% 0805
C107,C108,C112,C113,C136,C138,C183 120pF 0805
C137,C139 220pF 0805
C106,C111,C116,C117 270pF 35V 20% 0805
C40 330nF 0805 RS 723-5203
C95,C96 330pF 35V 20% 0805
C38 NC 50V 20% 0805
C219 4.7µF 16V 20% 0805
C208,C246 10nF 35V 20% 1206
C224,C231,C247,C250,C256,C257,C258,C260,C261,C26
3,C276 10µF tantalum 16V 20% 1206
C57,C99,C135,C228 10µF tantalum 35V 20% 1210
C2,C3,C4,C20,C21,C22,C73,C86,C87,C122,C123,C124,
C133,C149,C150,C175,C179,C187,C189,C192,C193,C24
5,C251
10µF tantalum 16V 20% SMD
CHF12 56pF 500V SQCB AVX
CHF9,CHF10,CHF11 120pF 500V SQCB AVX
CHF1 150pF 500V SQCB AVX
CHF6,CHF7,CHF8 470pF 500V SQCB AVX
CHF15 CC1206JRNPO9BN821
CHF13,CHF14 1nF 500V SQCB AVX
CHF4 NC 500V SQCB AVX
U3 CD74AC14M96-5VL
CL4,CL5 Shield
CL1,CL2,CL3 Shield
CX2 Coaxial local aera
CX41,CX42 Coaxial local aera 4mm
J1 1655910131
CV2,CV8,CV9,CV11 1.5-3pF trimmer capacitor
CV1,CV3,CV4,CV5,CV6 2-6pF trimmer capacitor
CV12 0.5-1PF trimmer capacitor MURATA
CV7,CV10 1.5-3pF trimmer capacitor
IC18,IC20,IC23,IC34 ERA4
IC26 ERA5
F5 crystal filter QF 23.1 VECTRON
F1 EMI filter NFM41P 5%
F3,F4 SMF 5A
F2 SMF 3A
IC22 GVA84
IC21 ICS542MILF
Y1 Crystal Oscillator 40 Mhz IOXO 57
IC31 JMS-2LH
L1,L2,L3 LQM21PN1R0MC0D
L47,L50,L51 180nH 0805
L12 NPI16W681MTRF
L20 LQM21PN1R0MC0D
L18 7447600339A
L32 10nH 0.25W 10% 0805 COILCRAFT
L24,L25,L39,L42,L43,L45,L46,L48,L49,L52 10µH 0.25W 10% 0805
L31 15nH 0.25W 10% 0805 COILCRAFT
L34 145nH 0.25W 5%
L23,L27,L33 220nH 0.25W 5%
L28 270nH 0.25W 5% 0805 COILCRAFT
L16,L26 330nH 0.25W 5%
L13 1uH 0.25W 5%
L14,L15,L17,L19,L21,L22,L29,L30,L35,L36,L37,L38,L40,
L41,L44 10uH 0.25W 5%
IC14 LD1086-D2T25
IC15 LD1086-D2T33
D8,D9,D10,D11,D12,D13,L4 LED 2mm GN
IC16 LM317BD2T
IC33 LTC6945
IC3,IC30,IC32,IC39 MC78M05
IC37,IC40 MC33275ST-5
IC27,IC38 OP467 SMD
BL2,BL3,BL4 Frame shielding 75x50 PERANCEA
TP6,TP10 Test plot
Y2,Y3 5RDA24000123TF50Q3
R127 3.9K 0402 0.25W 5%
R120 5.1K 0402 0.25W 5%
R126 6.8K 0402 0.25W 5%
R23,R49,R121,R123,R134,R139 10K 0402 0.25W 5%
R140,R144,R145,R148 15R 0402
R69,R117,R130,R141 51.1R 0402
R114,R115,R118,R146 100R 0402
R116 200K 0402
R95,R155 0R 0805
R7,R8,R44,R45,R62,R64,R65,R111,R122,R124,R135 1K 0805 0.25W 5%
R166,R167 2.2K 0805 0.25W 5%
R50,R55,R105 3.9K 0805 0.25W 5%
R108,R109,R136 4.7K 0805 0.25W 5%
R102,R133,R152,R160,R255 5.1K 0805 0.25W 5%
R9,R26,R85 6.8K 0805 0.25W 5%
R61,R80,R81,R82 10R 0805 0.25W 5%
R2,R3,R6,R11,R17,R28,R42,R48,R66,R67,R68,R83,R84,
R86,R161 10K 0805 0.25W 5%
R88,R129 12R 0805 0.25W 5%
R35,R46,R47,R60 15K 0805 0.25W 5%
R38,R79 18R 0805 0.25W 5%
R75 22R 0805 0.25W 5%
R59,R137 22K 0805 0.25W 5%
R113 27R 0805 0.25W 5%
R56,R57,R58,R103,R106,R107 47R 0805 0.25W 5%
R18,R19 47K 0805 0.25W 5%
R1,R37,R91 51R 0805 0.25W 5%
R12,R14,R39,R72,R110,R119,R138,R150,R151,R153,R1
54 100R 0805 0.25W 5%
R16 100K 0805 0.25W 5%
R36 270R 0805 0.25W 5%
R29,R32,R33,R63,R92,R94 330R 0805 0.25W 5%
R15,R70,R71,R76,R78,R89,R90,R131,R132,R158 470R 0805 0.125W 5%
R73,R97,R98,R99,R101,R104 510R 0805 0.25W 5%
R162,R163,R164,R165 820R 0805 0.25W 5%
R96,R100 ADJ 0805 0.25W 5%
R147,R156,R157 NC
R31 0R 0805
R74,R77 27R 1206 0.25W 5%
R34,R40,R41,R43,R87,R93,R112,R125,R128,R143,R254 51R 1206 0.25W 5%
RC1,RC2,RC3,RC4,RC5,RC6,RC7 SR9000SPQ0488BYE
R51 CAT16 x4 1k
R4,R5,R10,R13,R20,R21,R22,R24,R25,R27,R30,R52,R5
3,R54,R142,R149 CAT16 x4 10k
RV7 Trimmer 10K
RV2 Trimmer 50K
RV3,RV4,RV5,RV6 Trimmer 100R
D4,D7 S3A
L9 145µH VAR NEOSIDE
L8 170µH VAR NEOSIDE
L11 560µH VAR NEOSIDE
L5 670µH VAR NEOSIDE
L7 820µH VAR NEOSIDE
L10 47µH VAR NEOSIDE
L6 56µH VAR NEOSIDE
D14 SMP1330-005LF
IC29 SPF5043Z
J14,J15,J16,J17 Jumper
J2,J3,J4 Solder jumper
J5,J6,J7,J8,J9,J10,J11,J12,J21 Solder jumper
IC9 TMS320C6414
VCXO1 VV-701-DAE-SKAE-24M0000000
IC8 XC2S150-PQ208
PA2-25W_F 460-470 MHz
Parts list
Location Reference
D7 BAS16LT1G
T1,T2,T4,T5 2N2222A
T3 2N2907
IC8 74HC00D
IC5 74HC04D
IC2 AH312
D3,D12,D13 DKB370-FDITR-ND
D1,D2 BAT54
J2,J5 1715721
D4,D14,D15,D16 BYG21K
CHF3,CHF5,CHF7,CHF11,CHF12,CHF13,CHF20 10PF HF
CHF1,CHF4,CHF6,CHF10,CHF14,CHF18 120PF HF
CHF8 8,2pF HF
CHF2,CHF38,CHF39 12PF HF
C14,CHF17 18PF HF
C64,CHF19 27PF HF
CHF24,CHF32 4.7PF HF
CHF16,CHF28 6.8PF HF
CHF25 8.2PF HF
CHF23 NC 0805 CMS
C18 1.5nF 0805 - 50v
C9,C11,C13,C21,C23,C24,C27,C53,C62,C78 100nF 0805 - 50v
C6,C42,C43,C44,C46,C74 100nF/100v 0805
C7,C16,C22,C28,C29,C57,C60,C79 100pF/100v 0805
C3,C12,C32,C41,C54,C55,C67,C70,C71,C72,C80,C81 10nF 0805 - 50v
C35,C36,C39 10nF/100v 0805
C2 10pF 0805 - 50v
C4,C19,C31,C73 1nF 0805 - 50v
C20 1pF 0805 - 50v
C59 2.7nF 0805 - 50v
C10 220pF 0805 - 50v
C45,C48,C51 220pF 100V 0805
C15,C58 22nF 0805 - 50v
C8,C40 22nF100v 0805
C63 22pF 0805 - 50v
C56 330pF 0805 - 50v
C25,C65 EEEHB1E101AP
C5,C26,C30,C38,C47 EEETG1J101UP+
C37,C66 MCCA000626
C69,C75,C76,C82 10uF/16v CMS 1210 Tantalum
C77 1uF/16v CMS 1210 Tantalum
C33,C34,C49,C50,C52,C68 12061C105KAT2A
C17,C61 293D225X9050D2TE3
C1 RPS1C221MCN1GS
CTH1 RSpro 307935
CIR1 ADC049GD
CV1 4-20pF Adj
FUS1 FUS CMS 10A
HE1 HE10_16 Cts male
D10,D11 HSMS-2822-TR1G
L10 self 1sp fil 50/100 D=3mm
L23 self 2sp 50/100 D=3.2mm
L5,L6,L7 self 2sp 80/100 D=3.2mm
L26 self 4sp 80/100 D=3.2mm
L28 self 2sp fil 80/100 D=3.2
L13,L20,L21,L25 self 5sp fil 80/100 D=3.2
L9 36501J15NJTDG
L14 36501J18NJTDG
L3,L4,L11,L16 LQW2BHN22NJ03L
L29 10uH CMS SELF
L12,L17 ELJNA47NMF
L2,L18 36502C82NJTDG
L15 ELLCTV270M
L1,L8,L22,L24 IHLP2525AHER4R7M01
D6,D9 LL1N4148
CTH2 LM26CIM5-NPA
IC3 LM393D
IC7 LM5576MH
IC1,IC6 LP2951
D8 MMSZ5260BT1
TR1 MRF6V2010NBR1
IC4 MRF6V4300NR5
TR4,TR7 NDT2955
PFL1,PFL2 shielding 50X25
PFL3 shielding 75X50
R49 R TO126
R16 10 0805 CMS
R50 100 0805 CMS
R15,R20,R23,R30,R31,R53,R60 10K 0805 CMS
R5 12 0805 CMS
R9,R14 150 0805 CMS
R2,R3 180 0805 CMS
R32 19.6K 0.1% 0805 CMS
R17,R24,R34,R41,R42,R51 1K 0805 CMS
R18 1M 0805 CMS
R19,R33 2.2K 0805 CMS
R48 2.7K 0805 CMS
R38 20.5K 0805 CMS
R6,R43 22 0805 CMS
R25 220K 0805 CMS
R7,R26,R35,R46 22K 0805 CMS
R40 3.09K 0805 CMS
R47,R54 3.3K 0805 CMS
R1,R12 33 0805 CMS
R4 39 0805 CMS
R22 330 0805 CMS
R13,R44 470 0805 CMS
R21,R28,R29,R36,R52 5.1K 0805 CMS
R55,R56 NC
R11,R61 TE 35211K3FT
R57 18 ohms 1206 CMS
R27 120 ohms 1206 CMS
R45 2.2K 1206 CMS
R37,R58,R59 330 1206 CMS
R39 ERJT06J512V
R10 3520680RJT
RV3,RV4 BRN3314G-1-103E
RV2 BRN3314G-1-202E
RV1,RV5,RV6 PVG5A202C03R00
L19,L27 742792151
D5 STPS10L60CF
J1,J3,J6,J7 STRAP A SOUDER
Z2,Z3 ZENER 12V CMS
Z1 ZENER 6.2V CMS
UCM3_C 460-470 MHz
Parts list
Component location Reference
IC1 M27C4002
IC6 M27C1001
T2,T3,T4,T5,T6,T7,T8,T9,T10,T11 2N2222
T1 2N2907
IC3 74HC00D
IC15 MC74HC04
IC5-IC18 MC74HC14D
IC20,IC22 74HC245
IC12 74HC32D TEXAS
IC39 MC74HC4078D
IC21,IC49 MC74HC573D
IC4 80C251SB
IC2 AD768
IC81 AD7776AR
IC26 ADE-1
IC24 ADF4110BRUZ
IC28 ADP3338-3.3V
D2 BAS16 or 1N4148
D7,D8,D9,D10 BB833
TR4,TR5 BCX52
CHF1,CHF2,CHF3,CHF4 220pF 500V
CHF5,CHF6,CHF7,CHF8 ADJ
C66,C71,C80,C152,C180,C204 100nF 0402
C158,C159,C248,C249,C257,C260 100pF 0402
C142,C143 10nF 0402
C111,C154 1nF 0402
C155 GRM155R61A105KE15D
C192,C193 270pF 0402
C201 3.9nF 100V 20% 0402
C62,C63 470pF 0402
C112,C220 10µF tantalum 10V 20% 0603 AVX
C2,C9,C14,C42,C48,C49,C50,C51,C61,C65,C85,C8
6,C88,C99,C100,C103,C128,C140,C141,C145,C151
,C164,C170,C175,C182,C188,C190,C191,C195,C19
6,C197,C198,C202,C213,C217,C233,C234,C236,C2
37,C238,C239,C240,C241,C268,C269
100nF 0805
C22,C47,C54,C59,C60,C97,C98,C108,C109,C110,
C119,C136,C137,C146,C161,C162,C168,C169,C17
1,C177,C184,C185,C186,C205,C206,C207,C208,C2
09,C214,C221,C222,C223,C225,C230,C231,C232,C
235,C245,C250
100pF 50V 20% 0805
C8,C12,C13,C130,C135,C147,C148,C165,C247,C2
64 10nF 0805
C173,C176,C183 120pF 0805
C53 12pF 50V 20% 0805
C56,C74 15pF 50V 20% 0805
C75,C76,C121,C126,C131,C132,C133,C270 1nF 50V 20% 0805
C96,C107,C144,C167 C0805C105K4RAC
C77 2.2nF 0805 NPO
C3,C174,C194 220pF 50V 20% 0805
C1,C16,C17,C18,C19,C20,C21,C23,C24,C25,C26,C
27,C28,C29,C30,C31,C32,C33,C34,C45,C81,C82,C
89,C90,C92,C93,C94,C95,C104,C105,C106,C113,C
114,C115,C116,C117,C118,C120,C127,C129,C160,
C163,C181,C224
22nF 0805
C122,C123,C124,C125,C172,C179,C226,C227,C22
8,C229,C243,C244 22pF 0805
C139 330nF 0805
C78,C79 330pF 0805
C10 33nF 50V 20% 0805
C70,C134,C178,C246 33pF 0805
C149 4.7nF 0805
C4 470pF 50V 20% 0805
C11,C52,C166,C187,C189 47pF 0805
C72 56pF 50V 20% 0805
C73 68pF 50V 20% 080
C67,C68 82pF 50V 20% 0805
C41,C43,C266,C267 ADJ 0805
C57,C58,C242 NC 50V 20% 0805
C15 TPSD107K016R0150
C262 100nF 50V 20% 1206
C261 100pF 50V 20% 1206
C5,C6,C7,C36,C39,C55,C101,C102,C138,C153,C1
56,C157,C199,C200,C203,C219,C251,C252,C253,C
254,C255,C256,C258,C259,C263,C44-C46-C69-
C84-C210-C211-C212-C215-C216
10µF tantalum 16V 20% 1206
C35,C37,C38,C40 1µF tantalum 35V 20% 1206
C218 4.7µF tantalum 35V 20% 1206
C150 1µF tantalum 35V 20% 1210
C64 1µF ceramic capacitor X7R 100V 20% 1210
C83,C87,C265 300uF tantalum 10V SMD Case Size E AVX
C91 10µF tantalum 6.3V 1210
CL1,CL2,CL3,CL4,CL5,CL6 Shield 50X50
CLD1 Shield 24mm
CL7 Shield PERANCEA
CX4 Coaxial local aera
J8 09031966921
CV5,CV8,CV14,CV15 4-20pF trimmer capacitor
CV9,CV10,CV11 9401-0SL1
CV1,CV2,CV3,CV4 9401-0SL1
CV6,CV7 0.5-1pF trimmer capacitor MURATA
CV16 2-6pF trimmer capacitor AVX
IC7 CY62256
IC16,IC31,IC32,IC33 ERA4
TR2 ECT1-1-13
F2 QF23.3-12500/06
F1 EMI filter NFM41P 5%
FSAW1 B39471B5052Z810
IC11 XCF02S
FUS1 SMF 5A
IC34 ICS542MILF
IC41 IDT7204
INT1 Pushbutton TP33W0080 SCEME
SPLI1 JYPQ-30
L34 Inductor 1sp wire 50/100 D=3mm
L31,L32 Inductor 3sp wire 10/10 D=3mm
L33 Inductor 4sp wire 50/100 D=3mm
L8 Inductor 50nH 4sp wire 50/100 D=3.2mm
L47,L50,L51 180nH 0805 TE 36502AR18JTDG
L2,L5,L13,L18,L24,L26,L27,L28,L36,L41,L45,L46,L4
8,L49,L52,L53 LQM21FN100N00L
L20 WE 7447905
L17 LQW2BHNR22J03L
L14 LQW2BASR27J00L
L19 LQW2BHNR33J03L
L22 LQH32MN4R7K23L
L21,L44 LQW2BHNR22J03L
L40 ADJ
L1 LQH55DN681M03L
L3,L4,L9,L10,L15,L23,L29,L30,L35,L37,L38,L39,L43 LQH32MN100J23L
L16,L42 ELJNA1R0JF
L25 LQH32MN2R223L
L54 LQH55DN681M03L
IC19 LD1086D2T25TR
D1-D11 LED 2mm GN
D12 LED 2mm BL
D3-4-16-17 LED 2mm YW
D13-14-15 LED 2mm RD
IC14 LM317BD2T
IC23 LTC6945
IC25 MAV11
IC9 MAX232DW
IC36 MC33275ST-5
IC30,IC35 MC78M05
IC27 MC78M08
TR1 MCT3-1
IC38 NJM78L05UA-TE1
IC17,IC37 NJM79L05UA-TE1
IC133 OP284 SOIC
BL2 Frame shielding 50x25 PERANCEA
BL1,BL3,BL4,BL5 Frame shielding 75x50 PERANCEA
TS4,TS5,TS6 Test plot
TS1,TS2,TS3 Test plot
Y1,Y2 5RDA24000123TF50Q3
R17,R81,R85,R103 100R 0402
R24 15R 0402
R104 200k 0402
R39 3.9k 0402 0.25W 5%
R18 5.1k 0402 0.25W 5%
R6,R44,R105 51.1R 0402
R38 6.8k 0402 0.25W 5%
R59,R91,R94,R101 0R 0805
R37,R71,R100,R114,R123,R127,R130,R131,R132,
R133,R134,R135,R136,R141,R160,R161,R162 100R 0805 0.25W 5%
R51,R52,R53,R63 100R 0805 0.25W 5%
R19,R23,R29,R32,R46,R47,R49,R56,R57,R70,R72,
R73,R102,R119 10k 0805 0.25W 5%
R40,R149 12R 0805 0.25W 5%
R82,R83,R84 15R 0805 0.25W 5%
R48,R148 18R 0805 0.25W 5%
R42,R64 150R 0805 0.25W 5%
R93 187k 0805 0.25W 1%
R8,R11,R12,R13,R20,R21,R33,R41,R76,R99,R108,
R113,R126,R139,R144,R154,R155,R156,R157 150R 0805 0.25W 5%
R90,R106 2.2k 0805 0.25W 5%
R9 220k 0805 0.25W 5%
R26,R27,R109 22k 0805 0.25W 5%
R22,R80 27R 0805 0.25W 5%
R158 39R 0805 0.25W 5%
R15,R98,R122 51R 0805 0.25W 5%
R43,R45 68R 0805 0.25W 5%
R10 220R 0805 0.25W 5%
R30,R65 270R 0805 0.25W 5%
R28,R146,R147 330R 0805 0.25W 5%
R92 374k 0805 0.25W 1%
R31 390R 0805 0.25W 5%
R25,R66,R67,R74,R75,R78,R79,R86,R87,R137,R1
38 4.7k 0805 0.25W 5%
R54,R55,R112,R124,R150,R151 470k 0805 0.25W 5%
R153 47k 0805 0.25W 1%
R77,R118,R140 5.1k 0805 0.25W 5%
R1 510R 0805 0.25W 5%
R2,R3 51k 0805 0.25W 5%
R34,R36 680R 0805 0.25W 5%
R4 680k 0805 0.25W 5%
R88,R89,R107,R117 820R 0805 0.25W 5%
R129 93.1k 0805 0.25W 1%
R96,R152 ADJ
R7,R14,R60,R61,R95,R110,R111,R159 NC 0805 0.25W 5%
R50,R58,R62,R68,R69,R97,R115,R116,R120,R121,
R125,R128 51R 1206 0.25W 5%
IC13,IC29,IC115,IC122 SR9000SPQ0565BYE
RR4,RR5 Resistor Networks 8x 10k
RR1,RR2,RR3 Resistor Networks 8x 22k
R5,R16,R35,R214,R215 CAT16 x4 10k
RV4 BRN3314G-1-103E
RV5 BRN3314G-1-201
D5 S3A
L6,L7 100µH VAR NEOSIDE
IC10 SPF-5043Z
IC55 STQ-1016Z
J4,J11,J13,J16,J17,J18,J22 Jumper
J14,J15 Solder jumper
J1,J2,J3,J5,J6,J7,J10,J19,J20 Solder jumper
VCO2 CVCO55CC-0440-505
VCXO1 VCXO SMD 24MHz VECTRON
VCO1 VCO093MHZ
IC8 XC2S200-5PQG208C FPGA
D6 MMSZ5228B-VG08
