G4S Monitoring Technologies SOL915 OM247 SOLO2 User Manual User guide Solo safety

G4S Monitoring Technologies Limited OM247 SOLO2 User guide Solo safety

User guide Solo (safety)

Document Classication: Public
OM247-SOLO
Safety Guide
User Safety and Regulations
Page 2Document Classication: Public
This guide contains basic regulatory and safety information.
Document Number: 94-0159-01
Revision: 1.0
Issue Date: 22/05/2014
About This Guide
Page 3Document Classication: Public
Operational Warnings
Important information on safe and efcient operation. Read this information before using
the device. For safe and efcient use of the device, observe the guidelines outlined below.
International Protection Rating
The device carries an IP rating of IP68 and as such can be immersed in water up to a
depth of 5 metres.
Environmental Specication
10% to 90% humidity
(Battery Charger tted) 0°C to +45°C
(No Battery Charger tted) -20°C to +60°C
Installation
The equipment must be installed by a SERVICE PERSON.
Unit Record
The model number, regulatory number and serial number are located on a nameplate on
the rear of the device.
Battery Charging
When not in use, disconnect the battery charger from both the device and the mains
electricity supply. To halt charging, remove the charging clip from the device.
User Safety
Page 4Document Classication: Public
Do not disassemble, open, crush, deform or puncture the product.
Do not modify, remanufacture, attempt to insert foreign objects, expose to re,
explosion or other hazards.
Only use the product with an approved charger. Use of an unqualied charger may
present a risk of re, explosion, leakage or other hazard.
Use only approved power accessories such as AC-power adaptors.
AC Power Adaptor
Source: G4SMTL
Model: SMC
Part Number: 35-0092-3
Input Rating: 100-240V VAC, 50-60Hz, 350mA
Output Rating: 5VDC, 3000mA
Product Handling
Page 5Document Classication: Public
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician
for help.
FCC Statements
Page 6Document Classication: Public
FCC Statements (continued)
Modications not expressly approved by the manufacturer
could void the user’s authority to operate the equipment
under FCC rules.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
This product meets the FCC Radiofrequency Emission
Guidelines and is certied with the FCC as:
FCC ID: OY3SOLO433
FCC ID: 2ACGBSOL915
The FCC ID is located on a label on the rear face of the
product.
Page 7Document Classication: Public
We hereby declare that this device is in conformance to all
essential requirements of the R&TTE Directive 1999/5/EC.
This equipment is marked with the ‘CE’ symbol and can be
used throughout the European Community.
This indicates compliance with the R&TTE Directive 1999/5/
EC and meets the relevant parts of the following technical
specications:
ETSI EN 300 220-1 V2.3.1
ETSI EN 300 220-2 V2.3.1
ETSI EN 301 489-1 V1.8.1
ETSI EN 301 489-3 V1.4.1
EN 60950-1:2006
EU Regulatory Conformance
This symbol indicates that this product should be recycled and
not be disposed of in unsorted municipal waste. This product
should be returned to the supplier for correct disposal.
Page 8Document Classication: Public
This unit has been tested for RF exposure compliance at a qualied test laboratory. It
was found to comply with the regulations regarding exposure to RF Energy under the
recommendations of the International Commission on Non-Ionizing Radiation Protection
(ICNIRP).
SAR (Specic Absorption Rate) is measured using the device’s highest transmitting power.
Because the device automatically lowers its power output to the minimum required to
connect with the network, the actual SAR while it is operating is typically lower than the
quoted gure.
The SAR limit for mobile devices set by FCC/IC is 4.0 W/kg, averaged over 10 grams of
tissue for the extremities — hands, wrists, ankles, and feet.
The highest reported SAR value of the OM247-SOLO tag is 3.571 W/kg, averaged over
10g.
The maximum 10g volume averaged SAR level measured for all the tests performed did
not exceed the 2.0 W/kg level dened for limiting the exposure of the general population
to time-varying electric and magnetic elds by ICNIRP (1998), which is the relevant
standard for testing according to the CENELEC EN 62209-1: 2006 test method.
RF Safety Exposure (SAR)
