2-22 Foreman PC Hardware Installation Guide
Revision A: October 2002
Figure 2.21 Power Cable 302203 Connected to Electrical Box
Connecting the
Attenuator (105919) 1Connect the attenuator (part number 105919) to the electrical box,
as shown below.
Figure 2.22 Installed Attenuator
Power
cable
302203
Attenuator
