Pantech TX-60B Tri-Mode Dual Band (AMPS/CDMA/PCS-CDMA) Phone User Manual TX 60P verizon 1213 CDM 8450PTT
Pantech Co., Ltd. Tri-Mode Dual Band (AMPS/CDMA/PCS-CDMA) Phone TX 60P verizon 1213 CDM 8450PTT
Pantech >
Contents
- 1. User Manual
- 2. CRN 7826 revised page of user manual
- 3. Users manual
Users manual
AUDIOVOX
AUDIOVOX
CDM-8425PTT
CDM-8425PTT
Digital CDMA2000 1X
Handheld Portable Telephone
In today’s fast paced world, it has become a necessity to
have access to real time information.
Your communications tools must provide you with this
access from anywhere at anytime. With that in mind,
Audiovox developed the CDM-8425PTT, a bar type
handset with 4096 colors STN display.
This 1X digital handset enables carriers supporting 1X
technology to provide consumers with access to high
speed connectivity for web browsing, email and mobile
e-commerce. Operating on the 800 MHz AMPS/CDMA
and 1900 MHz PCS frequencies, the CDM-8425PTT
allows for seamless nationwide coverage as well as
offering state-of-the-art, user-friendly features. Voice
activated dialing and 2-way speaker phone are great for
enhancing hands-free use of this phone. T9
TM
Text Input,
vibrating alert and a 7-line LCD display make the CDM-
8425PTT easier to use.
Your new CDM-8425PTT provides you with something
only an Audiovox phone can: the proven reliability that
has made us a leading wireless handset provider.
Please take a few moments to read the following pages
of the owner’s manual. It will help you make the most
efficient use of this valuable communications tool.
Preface
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 1
T
TABLE OF CONTENTS
ABLE OF CONTENTS
CHAPTER 1 BEFORE USING YOUR PHONE .........7
Inside the Package .................................................8
Handset Description ..............................................9
Function Keys.......................................................10
Display Indicators.................................................11
Using the Battery..................................................13
Installing the Battery ...........................................13
Removing the Battery .........................................13
Charging the Battery............................................14
Power Connection...............................................14
Battery Charging Time ........................................15
Battery Talk & Standby Times.............................15
Battery Information ..............................................16
CHAPTER 2 BASIC OPERATION ...........................17
Using the Phone ...................................................18
Turning the Phone On.........................................18
Turning the Phone Off.........................................18
Using the Menu.....................................................19
Menu Summary.....................................................20
Basic Functions....................................................23
Making a Call ......................................................23
Pause Feature.....................................................24
Speaker phone....................................................24
Answering a Call .................................................25
Caller ID Function ...............................................25
Call Waiting Function ..........................................26
Voice Memo Display ...........................................26
Etiquette Mode ....................................................26
Adjusting Volume.................................................27
Keyguard.............................................................27
Functions During a Call.......................................28
Messaging...........................................................28
Mute (Unmute) ....................................................28
Scratchpad ..........................................................28
Send My Phone # ...............................................29
My Profile ............................................................29
Table of Contents - Page 1
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 2
T
TABLE OF CONTENTS
ABLE OF CONTENTS T
TABLE OF CONTENTS
ABLE OF CONTENTS
Voice Privacy.......................................................29
Location...............................................................29
Speaker Phone Mode .........................................30
CHAPTER 3 MEMORY FUNCTION .......................31
Storing Phone Numbers ......................................32
Text Input Methods ..............................................33
Entering Characters............................................33
Alpha Mode [ABC] ..............................................33
T9TM Predictive Text Mode [T9TMABC] .................34
Numeric Mode [123] ...........................................36
Symbol Mode [SYM] ...........................................36
Speed Dialing .......................................................37
One-Touch/Two-Touch Dialing............................37
Phone Book ..........................................................38
Find.....................................................................38
Add New Entry....................................................40
Edit Existing Entry...............................................40
Edit Group...........................................................41
Edit SMS Group..................................................42
Speed Dial ..........................................................44
My Profile............................................................45
Recent Calls .........................................................46
Dialed..................................................................46
Received.............................................................47
Missed.................................................................48
Call Timers..........................................................49
CHAPTER 4 SETTINGS ..........................................53
Settings .................................................................54
Sounds................................................................54
Display ................................................................59
System ................................................................63
Location ..............................................................65
Others .................................................................66
Page 2 - Table of Contents Table of Contents - Page 3
VS Menu ................................................................71
Voice Memo ........................................................71
Call Answer.........................................................72
Voice Command .................................................73
Voice Dial............................................................75
Voice Alert...........................................................77
Voice Setting.......................................................78
VR Mode................................................................80
Name ..................................................................80
Dial......................................................................81
Redial..................................................................81
Voice Memo ........................................................82
Phone Book ........................................................82
Cancel.................................................................82
PTT ........................................................................83
PTT Contacts ......................................................83
CHAPTER 5 SECURITY FEATURES......................85
Security Features .................................................86
Security ...............................................................86
CHAPTER 6 SUPPLEMENTARY FUNCTIONS......93
Schedule ...............................................................94
Event...................................................................94
Alarm...................................................................95
Calculator..............................................................96
World Clock ..........................................................97
Stop Watch ...........................................................98
CHAPTER 7
VOICE MAIL AND TEXT MESSAGES
...99
Two-Way SMS.....................................................100
Message Indicators...........................................100
Received Message Notification ........................100
Checking Messages ..........................................101
Checking Received Voice Mail Message..........101
Checking Received Text Message....................101
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 4
T
TABLE OF CONTENTS
ABLE OF CONTENTS
T
TABLE OF CONTENTS
ABLE OF CONTENTS
Phone Operation...............................................133
Driving Safety ...................................................133
Electronic Devices ............................................134
Other Safety Guidelines....................................136
Precautions and Warnings................................137
Operating Procedures.......................................138
Safety Information for FCC RF Exposure........139
Caution..............................................................139
SAR Information .................................................140
FDA Consumer Update......................................142
CHAPTER 12 WARRANTY ..................................151
Protect Your Warranty .......................................152
12 Month Limited Warranty...............................153
Page 4 - Table of Contents
Sending Text Messages.....................................102
Sending New Text Messages ...........................102
Inbox....................................................................105
Inbox Menu .......................................................105
Outbox.................................................................108
Outbox Menu ....................................................108
Saved...................................................................110
My Object............................................................111
Erase All ..............................................................112
Settings ...............................................................113
Settings Menu ...................................................113
CHAPTER 8 MAKING AN EMERGENCY CALL ..117
Emergency Calling .............................................118
911 in Lock Mode..............................................118
911 Using Any Available System.......................118
CHAPTER 9 GET IT NOW & INTERNET..............119
Get It Now...........................................................120
Downloading Applications.................................120
Open an Application..........................................121
View Information on Memory and Log..............121
Disable and Restore an Application..................122
Remove an Application.....................................122
Start Internet Browser.......................................124
Access the Internet ...........................................124
Browser Menu ....................................................125
CHAPTER 10 DATA SERVICE...............................129
Data SVC.............................................................130
Connection........................................................130
CHAPTER 11 SAFETY INFORMATION.................131
Safety Information for Wireless Handheld Phones
.132
Exposure to Radio Frequency Signals .............132
Antenna Care....................................................133
Table of Contents - Page 5
“Licensed by QUALCOMM Incorporated under one or more of the following Patents :
U.S.Patent No. 4,901,307 U.S.Patent No. 5,056,109 U.S.Patent No. 5,099,204 U.S. Patent No.
5,101,501 U.S. Patent No. 5,103,459 U.S. Patent No. 5,107,225 U.S.Patent No. 5,109,390.”
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 6
Please read and fully understand this manual before
using your phone.
This chapter addresses your phone, its keys and display
icons, and covers the charging and proper use of
the battery.
Inside the Package
Handset Description
Function Keys
Display Indicators
Using the Battery
Charging the Battery
Battery Information
Chapter 1
BEFORE USING
YOUR PHONE
Chapter 1 - Page 7Page 6
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 8
HANDSET DESCRIPTION
HANDSET DESCRIPTION
Volume
Button
Adjusts the
earpiece
and ringer
volume.
Earpiece
Function
Keys
Keypad
Microphone
END/
Power Key
Send key
Earjack
This phone is a CDMA2000 1X digital phone with data
and web browsing capabilities. The CDM-8425PTT
weighs 3.1 oz. and the dimensions are 3.3” x 1.6” x 9”.
Chapter 1 - Page 9
INSIDE THE P
INSIDE THE PACKAGE
ACKAGE
Thank you for purchasing the CDM-8425PTT wireless
handset. The phone’s giftbox contains all of the items
listed below.
NOTE: Immediately report any product defects or
missing items to the place of purchase.
User Manual Hand strap
Handset
Page 8 - Chapter 1
Antenna
For best call quality,
fully extend the
antenna during the
call.
LCD
Display
Traver Charger
Standard Battery
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 10
DISPLA
DISPLAY INDICA
Y INDICATORS
TORS
Chapter 1 - Page 11
FUNCTION KEYS
FUNCTION KEYS
SEND KEY: Press to make or receive a call.
Press and hold to view most recently dialed
numbers.
END KEY: Press to terminate a call or to
return to the idle screen. Press and hold to
turn the phone on/off.
NAVIGATION KEY:
In Idle Mode-Press up to access the phone
book, down to access the
messaging menu, right for Get
It Now and left for Mobile Web.
Inside the menu-Within a menu, use to
scroll through menu
options. Press to
select an option.
SOFT KEYS: (Soft 1) Press to access the
menu or function displayed on the bottom
line. (Soft 2) Press to enter the Find feature
of the phone book, or to return to the
previous page. Press to clear a digit from
the display.
LOCK KEY: Press and hold to enter Keyguard
Mode.
ETIQUETTE MODE: Press and hold to enter
Etiquette (vibrate) Mode.
Page 10 - Chapter 1
Signal Strength
Indicates current signal strength.
The more lines, the stronger the signal.
Roaming
Phone is outside of its home area.
Service Indicator
indicates call is in progress, indicates
the phone is in standby mode, and indi-
cates the phone cannot receive a signal
from the system.
Message
A text or voice mail message is waiting.
Digital Mode
Phone is operating in digital mode.
Battery
Battery charging level–the more blocks,
the stronger the charge.
Mute
Phone is mute during a call.
Emergency call
Blinks when an emergency call is in
progress.
1X
Phone is in the “1x” service area.
Phone is in the progress of “UP Browser”.
Text
Message
Voice
Message
Voice & Text
Message
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 12
USING THE BA
USING THE BATTER
TTERY
Y
Chapter 1 - Page 13
DISPLA
DISPLAY INDICA
Y INDICATORS
TORS
INSTALLING THE BATTERY
1. Insert the bottom of battery into groove at bottom of
the handset.
2. Press in the top of the battery until it clicks.
REMOVING THE BATTERY
1.
Push the tab with one hand and lift the top of the
battery
to separate.
NOTE: If the battery is not correctly placed in the battery
compartment, the handset will not turn on and/or
the battery may detach during use.
Page 12 - Chapter 1
Voice Memo
New voice memo has been made.
Answering machine
Phone is in answering machine mode.
Etiquette Mode
Phone will vibrate when call is received.
Schedule
Appears when either an event or an alarm
is set.
Ring Mode
Appears when a ringer is set as a ringer
mode.
GPS Icon
Indicates the Location Service of your phone
is disabled.
Indicates the Location Service of your phone
is enabled.
Dormant
Indicates the phone is in disconnection
condition while on “Server Connection”.
Data Only
Phone can receive an async call as a voice call.
Fax Only
Phone can receive a fax call as a voice call.
Ringer Ring off VibrateRinger after
vibrate
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 14
CHARGING THE BA
CHARGING THE BATTER
TTERY
Y
NOTE: Charging time applies only when your phone is
turned off. Charging time may vary if your phone
is turned on.
NOTE: These times are for a new battery.
Talk and standby time may decrease over time.
BATTERY TALK & STANDBY TIMES
BATTERY CHARGING TIME
Chapter 1 - Page 15
CHARGING THE BA
CHARGING THE BATTER
TTERY
Y
NOTE: 1. It is more efficient to charge the battery with
the handset powered off.
2. The battery must be connected to the phone in
order to charge it.
3.
Battery operating time gradually decreases over
time.
4. If the battery fails to perform normally, you may
need to replace the battery.
Page 14 - Chapter 1
POWER CONNECTION
1.
Plug the AC charger into a standard outlet.
2.
Plug the other end of the AC charger into the
bottom of your phone. The battery must be installed
on to the phone.
NOTE: 1. When you charge the battery with the phone
power off, you will see a charging status
screen. You can not operate the phone until
it is powered on.
2.
The battery is not charged at the time
of purchase.
3. Fully charge the battery before use.
4. If you use a data cable while you are
charging the battery: After using the
cable, disconnect the AC charger
first, then the data cable.
Battery Type BTR - 8400
200 minutes
Charging Time
Standard Battery
(900mAh)
150
103
103
25
Talk Time
(min)
Digital
Analog
Digital
Analog
Standby
Time
(hrs)
Battery
Charging
MENU MENU
Charging
Complete
Charging is
in progress
Charging is
in complete
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 16
This chapter addresses the phone’s basic functions
including menus, volume levels, and call features.
Using the Phone
Using the Menu
Menu Summary
Basic Functions
Functions During a Call
Chapter 2
BASIC OPERATION
Chapter 2 - Page 17
Use only manufacturer approved batteries.
Never use a damaged or worn out battery.
Use the battery only for its intended purpose.
Never expose the battery terminals to any other metal
object. This can short circuit the battery.
Avoid exposure to temperature extremes. A phone with
a hot or cold battery may temporarily not work (or
charge), even if the battery is fully charged. Always allow
it to cool down or warm up first and keep the battery
between 41oF and 95oF (5oC and 35oC).
When not in use, store the battery uncharged in a cool,
dark, dry place.
The battery is a self-contained unit. Do not attempt to
open its case.
Battery operating time gradually decreases. You may
need to buy a new battery.
Never dispose of a battery in a fire!
Dispose of used batteries in accordance with local
regulations.
Recycle!
BA
BATTER
TTERY INFORMA
Y INFORMATION
TION
Page 16 - Chapter 1
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 18
USING THE MENU
USING THE MENU
USING THE MENU
1. To access the menu from the idle screen,
press [MENU].
2. Use the Navigation Key to scroll through the menu.
3. To return to the previous page, press [CLR].
To exit the current menu and return to the idle screen,
press .
4. To enter a function press or press the function’s
assigned number.
Chapter 2 - Page 19
USING THE PHONE
USING THE PHONE
TURNING THE PHONE ON
1. Press and hold , until your “Power On” logo
appears and the melody begins to play.
NOTE: 1.
Immediately change or recharge the battery
when “Low Battery Warning Power Off”
appears on the display. Memory may
possibly be damaged if the phone turns off
due to the battery completely draining.
2.
Turn the phone off before removing or
replacing the battery. If the phone is on, data
may be lost.
NOTE: The default password is the last 4 digits of your
phone number.
● To select a logo, refer to page 59 for more details.
● If “PASSWORD” appears, the phone is locked.
To unlock, enter your 4-digit password.
● Hotkey
From the idle screen, move the Navigation Key as follows
to access these functions:
• Upward movement : Phone Book
• Downward movement : Messaging
• Rightward movement : Get It Now
• Leftward movement : Mobile Web
● When the key guard is activated, press 1, 2, 3 to unlock
the key guard.
● To search through the menu in numerical order, press
down or to the right.
TURNING THE PHONE OFF
1. Press and hold until “Power Off” animation
appears.
Page 18 - Chapter 2
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 20
SETTINGS u
MENU SUMMAR
MENU SUMMARY
Y
TOOLS u
1 : Sounds
2 : Display
3 : Security
4 : System
5 : Location
6 : Others
1 : Schedule
2 : Calculator
3 : World Clock
4 : Stopwatch
1 : Ringer Type
2 : Ringer Mode
3 : Volume
4 : Alert
5 : Roam Ringer
6 : Tone Length
7 : Etiquette Mode
1 : Animation Setting
2 : Main Display Setting
3 : LCD Setting
4 : Graphic Setting
1 : Restrict
2 : Special #’s
3 : Clear Phone Book
4 : Reset Phone
5 : Change Password
1 : Set Mode
2 : Force Analog
3 : Nam Setting
4 : PRL ID
1 : Answer Mode
2 : Auto Retry
3 : Auto Answer
4 : Voice Privacy
5 : Key Guard
6 : Language
7 : Web Idle Time
8 : S/W Version
9 : TTY Mode
0 : Speaker Mode
1 : Event
2 : Alarm
Chapter 2 - Page 21
MENU SUMMAR
MENU SUMMARY
Y
PHONE BOOK
RECENT
CALLS
MESSAGING u
u
u
1 : By Name
2 : By Number
3 : By Group
1 : Add New Group
2 : Change Group Name
3 : Clear Group
1 : Add New Group
2 : Change Group Name
3 : Edit Existing Group
4 : Clear Group
1 : Last Call
2 : All Calls
3 : Home Calls
4 : Roam Calls
5 : Cumulative Calls
1 : Inbox
2 : Outbox
3 : Saved
4 : My Object
1 : Save Sent Msg
2 : Default CallBack
3 : Alert
4 : Auto Erase
5 : Entry Mode
6 : Block or Unblock
7 : Signature
8 : Direct View
1 : Find
2 : Add New Entry
3 : Edit Existing Entry
4 : Edit Group
5 : Edit SMS Group
6 : Speed Dial
7 : My Profile
1 : Dialed
2 : Received
3 : Missed
4 : Call Timers
1 : Voice
2 : Send New
3 : Inbox
4 : Outbox
5 : Saved
6 : My Object
7 : Erase All
8 : Settings
Page 20 - Chapter 2
GET IT NOW
MOBILE WEB
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 22
Chapter 2 - Page 23
BASIC FUNCTIONS
BASIC FUNCTIONS
MAKING A CALL
1. Enter a phone number.
2. Press .
The indicator, , appears on the display.
3. To end a call, press . “Press [OK] to save
this number” will appear.
(Refer to page 32 for more details about storing a
phone number.)
Page 22 - Chapter 2
MENU SUMMAR
MENU SUMMARY
Y
VOICE SVC.
u
1 : On/Off
2 : Inbox
3 : Call Speaker
4 : Wait Time
1 : Yes/No
2 : Wake-Up
3 : Top Level
4 : Digit Dial
1 : List
2 : Add
3 : Clear All
1 : On/Off
2 : Record
3 : Play
4 : Clear
1 : Untrain All
2 : Prompt Mode
3 : Digit Mode
4 : HFK Mode
1 : Connection
1: Voice Memo
2: Call Answer
3: Voice Command
4: Voice Dial
5: Voice Alert
6: Voice Setting
1: PTT Contacts
● If “CALL FAILED” appears on the display or the line is
busy, press or .
● If you activate the “AUTO RETRY” function, the phone will
automatically retry for the number of times you have
selected. (refer to page 66)
● If the phone number you’re calling is stored in the phone
book, the name and number will appear when the call is
placed.
● To modify the phone number you have entered :
• To erase one digit at a time, press .
• To erase the entire number, press and hold .
NOTE: Please refer to page 75 (Voice Service) for more
details on using Voice Activated Dialing to place a
call.
PTT
u
DATA SVC. u
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 24
Chapter 2 - Page 25
BASIC FUNCTIONS
BASIC FUNCTIONS
Page 24 - Chapter 2
ANSWERING A CALL
1. To answer a call, press any key except Clear, End or
the Navigation Key.
2. To end the call, press .
● In the Settings menu, you can select either “Any Key” or
“Send Key” to answer a call. lf “Send Key” is selected, the
phone can only be answered by pressing .
See page 66 for more information.
NOTE: In Auto Answer Mode, a call is automatically
answered after a preset number of ring tones.
See page 67 for more details.
NOTE: The caller ID is stored in the call history.
Caller ID is a system dependent feature.
Please contact your service provider for
details.
CALLER ID FUNCTION
Identifies a caller by displaying that person’s phone
number. If the caller’s name and number are stored
in your phone book, the name and number will be
displayed.
BASIC FUNCTIONS
BASIC FUNCTIONS
PAUSE FEATURE
You can dial or save a phone number with pauses for
use in the automated systems where you need to enter
a credit card number, a PIN number, and so on. This
feature will be convenient when you are linked to ARS.
(Advanced Record System).
1. To insert a pause, enter the phone number then press
[PSE].
2. Press to dial or [STO] to store.
Please refer to page 32 for more details about
storing a phone number.
SPEAKER PHONE
1. To activate the speaker phone when the phone is on
the idle screen, in the idle mode, in answering mode,
and in calling mode, press and hold .
2. The phone returns to normal (Speaker phone off)
after ending or call or when the phone is turned off
and back on.
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 26
ADJUSTING VOLUME
Adjusts the volume in two ways: by using the volume
control keys on the side of the handset, or by using the
menu.
1. Press [MENU] and select one of the
following.
2. Adjust volume and press [OK] to save it.
ETIQUETTE MODE
Mutes key tones and activates the vibration mode to
alert you of an incoming call or message.
1. To turn etiquette mode on/off, press and hold .
Chapter 2 - Page 27
BASIC FUNCTIONS
BASIC FUNCTIONS
Page 26 - Chapter 2
BASIC FUNCTIONS
BASIC FUNCTIONS
CALL WAITING FUNCTION
Notifies you of another incoming call when you are on the
phone by sounding a beep and displaying the caller’s
phone number on the screen.
1. To answer another call while on the phone,
press . This places the first call on hold.
2. To switch back to the first caller, press again.
VOICE MEMO DISPLAY
Displays the number of voice memos recorded in the
answering machine.
1. To play the recorded voice memos, press [PLAY].
● Ringer : Controls the ringer volume.
● Key : Controls the keypad tone volume.
● Voice Call : Controls the Speaker & earpiece volume.
● Speaker phone : Controls the speaker & earpiece volume
in speaker phone mode.
NOTE: Move the Navigation Key upward or downward
to adjust volume of earpiece during a call.
KEYGUARD
Locks phone and prevents unauthorized use.
Phone can only be used after inputting the password.
1. To lock the phone, press and hold .
2. To unlock the phone, input the password.
The default password is 1 2 3.
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 28
Chapter 2 - Page 29
FUNCTIONS DURING A CALL
FUNCTIONS DURING A CALL
SEND MY PHONE #
Enables your phone number to be automatically
transmitted to a pager.
(Dependent on pager service.)
1. To transmit your phone number during a call,
press [MENU] and .
MUTE (UNMUTE)
Mutes the microphone while you are on a call so the
other party cannot hear you if you speak.
1. Press [MENU] .
To display menu options during a call, press .
These menu items are available while you are on a call.
Page 28 - Chapter 2
SCRATCHPAD
Stores a new phone number during a call without
the calling party hearing the keypad tones.
1. Press [MENU] .
2. Enter a phone number, press then save the
phone number in the phone book.
FUNCTIONS DURING A CALL
FUNCTIONS DURING A CALL
MESSAGING
Enables you to send a message (SMS) during a call.
1. Press [MENU] .
MY PROFILE
Enables you to review and edit your profile entered
through the phone book entry.
Please see page 45 for more details.
1. Press [MENU] .
VOICE PRIVACY
Enhances voice privacy during a call.
1. Press [MENU] .
● To deactivate, press [MENU] .
● The phone will automatically un-mute in Emergency Call
or Callback mode.
● Press [MENU] to deactivate it.
LOCATION
Enables the network to locate your current location
through Global Positioning System (GPS).
1. Press [MENU] .
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 30
This chapter addresses numerous functions including
saving phone numbers to the internal phone book,
entering text and accessing call logs.
Storing Phone Numbers
Text Input Methods
Speed Dialing
Phone Book
Recent Calls
Chapter 3
MEMORY
FUNCTION
Chapter 3 - Page 31
Page 30 - Chapter 2
FUNCTIONS DURING A CALL
FUNCTIONS DURING A CALL
SPEAKER PHONE MODE
Activates the speaker phone when you are on a call.
The phone returns to normal (speaker phone off)
after ending or call or when the phone is turned off
and back on.
1. Press [MENU] .
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 32
TEXT INPUT METHODS
TEXT INPUT METHODS
ENTERING CHARACTERS
For convenient entry of memory location names and text
messages, your phone offers several text input methods:
Alpha mode : Enters words by repeatedly tapping the
corresponding key until the desired character is
displayed.
T9TM mode : Tap each corresponding key only once and the phone
predicts the word you are entering.
Numeric mode : Only enters numbers.
Symbol mode : Enters symbols like @, #, %.
ALPHA MODE [ABC]
Use the digit keys to enter letters, numbers and characters.
Enter letters using the keypad as follows:
Chapter 3 - Page 33
STORING PHONE NUMBERS
STORING PHONE NUMBERS
Page 32 - Chapter 3
The phone book stores up to 300 entries, each with 5
numbers.
2. Choose Add New Entry or Add Existing Entry.
Press [OK] to select.
3. The Phone # will appear next to a list of icons.
The name of the icon is displayed above the list.
Use the Navigation Key to choose the type of # you’re
adding, as indicated by the icon.
Press [OK] to select.
4. When the Editor is displayed, enter a name. Follow
instructions for entering text on page 33.
To change the input mode, press [MODE].
Press [OK] to store the name.
5. Use the Navigation Key to scroll through more options
for the entry (VAD, secret, etc.).
6. To store the entry, press “New entry is saved”
will be displayed.
1. Enter phone # and press [STO].
Group – Family, Friends, Work, Etc
Voice dial – Home, Mobile, Office, Unassigned
Set Secret – Yes, No
● The other fields are set to Numeric mode as a default.
NOTE:
Alternative way to save a phone number to the
phone book is listed on page 40 “Add New Entry”.
● To enter a space, press . After two seconds, the
cursor will automatically move to the next column.
● Repeat until letters are entered.
There is a 16-letter limit.
● To delete one digit, press . To delete the entire entry,
press and hold .
● To change from lowercase to uppercase, press .
Key Pad 1 Repetition
1
A
D
G
J
M
P
T
W
1
2ABC
3DEF
4GHI
5JKL
6MNO
7PQRS
8TUV
9WXYZ
.
B
E
H
K
N
Q
U
X
@
C
F
I
L
O
R
V
Y
-
2
3
4
5
6
S
8
Z
’
...
...
...
...
...
7
...
9
2 Repetitions 3 Repetitions 4 Repetitions 5 Repetitions
To change the input mode, press [MODE].
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 34
1. Press each key once for each letter of the word you
are writing.
●To write John with the English dictionary selected:
1. Press 5 once - (for - k)
2. Press 6 once - (for - km)
3. Press 4 once - (for - log)
4. Press 6 once - (for - john)
2. Press until the correct word is displayed.
3. To select the correct word and press .
TEXT INPUT METHODS
TEXT INPUT METHODS
NOTE:
The display shows for each key
pressed.
Chapter 3 - Page 35
TEXT INPUT METHODS
TEXT INPUT METHODS
Case
Press to change mode.
[T9Abc][Abc][123][Symbol mode]
Press to view the next matching
word if the highlighted word is not
the word you intended.
Press to accept a word and add a
space.
Press to select a letter case of the
standard text input or T9 text
input mode. [Abc], [ABC], and
[abc] indicate the standard text
input. [T9Abc], [T9ABC], and
[T9abc] indicate the predictive text
input.
Press to delete a character to the
left of the cursor.
Store the letters and numbers you
enter.
KEY FUNCTION
T9TM PREDICTIVE TEXT MODE [T9TMABC]
To choose T9TM mode, press [MODE] then choose
[T9TMABC]. This mode predicts the words you are
entering using a built-in dictionary. With T9TM predictive
text input, you press each key only once for each letter.
The chart below outlines how to use T9TM text input.
Page 34 - Chapter 3
Next
Space
Shift
Clear
Sto
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 36
SPEED DIALING
SPEED DIALING
ONE-TOUCH/TWO-TOUCH DIALING
Ideal for frequently dialed numbers, this feature allows
phone book entries to be dialed via the keypad with only
one or two key presses.
ONE-TOUCH DIALING:
1-9 : Press the corresponding memory number and hold
for more than 1 second.
TWO-TOUCH DIALING:
10-20 : Press the first digit and second digits of the
memory number short and long respectively.
●If no phone number is stored in the location
entered, “There is no number” will appear on the screen.
●If a phone number is stored in secret, you must enter
the password to make a call.
NOTE:
See page 44 for information about saving a phone
number in a speed dial location.
Chapter 3 - Page 37
NUMERIC MODE [123]
Numeric mode allows you to add a number to your
entry/message. To select numeric mode, press ,
[MODE] then select [123].
TEXT INPUT METHODS
TEXT INPUT METHODS
SYMBOL MODE [SYM]
Select symbol mode allows you to add various symbols
to your entry. Whether you are adding an e-mail address
to your phone book or sending an expressive message,
symbols make these entries easier.
To select symbol mode, press [MODE] then choose
[SYM].
The symbols will appear on the display.
The corresponding key number for that symbol
will appear as well. You can press the key to select the
symbol or use the Navigation key to highlight the
symbol, then press .
To move to the next screen of symbols press .
Page 36 - Chapter 3
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 38
Chapter 3 - Page 39
Page 38 - Chapter 3
PHONE BOOK
PHONE BOOK
BY NUMBER
1. Press [MENU] .
2. To search through the menu, enter a part of the
phone number and press .
3. All matching entries will be displayed. Select an
entry and either delete it by pressing [DEL]
or view it by pressing .
4. To call the selected number, press .
FIND
Retrieves an entry by group, name, or number.
1. Press [FIND].
2. All entries will appear in alphabetical order.
“Search Name:” will appear at the top of the list.
3. Type in a name or character string and press .
4. All entries will be displayed.
BY NAME
1. Press [MENU] .
2. Enter a name or its character string and press
to display the names in alphabetical order. Please
refer to page 33 about using the Alpha Editor.
3. All matching entries will be displayed. Select an
entry and either delete it by pressing [DEL]
or view it by pressing .
4. To call the selected number, press .
PHONE BOOK
PHONE BOOK
Stores up to 300 entries, each of which can be assigned
to a group like Personal, Business, etc. Entries can be
retrieved by name, phone number or group.
● If there is no match, “Cannot Find Name” will appear.
● If the entry is set to secret, you will be asked for your
password.
● If there is no match, “Cannot Find Name” will appear.
● If the entry is set to secret, you will be asked for your
password.
BY GROUP
1. Press [MENU] .
2. Select one of the following groups (Personal,
Business, Etc., All) with .
3. All group entries will be displayed. Select an entry
and either delete it by pressing [DEL]
or view it by .
4. To call a selected number, press .
● You are to be asked about “Password” when the entry is set
secret.
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 40
Chapter 3 - Page 41
Page 40 - Chapter 3
PHONE BOOK
PHONE BOOK
EDIT GROUP
Adds, changes and deletes groups.
ADD NEW GROUP
1. To add a new group, press [MENU] .
A maximum of seven groups is allowed.
2. Input a new group name.
3. Press [STO] to save it.
CHANGE GROUP NAME
1. To change a new group,
press [MENU] .
2. Select an existing group name with the Navigation
key.
3. Input a new name.
4. Press [STO] to save it.
ADD NEW ENTRY
Adds a new entry to the phone book.
1. To add a new entry to the phone book,
press [MENU] .
2. Enter a name, then press .
3. Press the Navigation Key until the phone number
type is selected, then press [EDIT].
4. Enter the phone number. Press .
5. To save the entry, press [STO].
To return to the previous page, press [CLR].
EDIT EXISTING ENTRY
Edits an existing entry in the phone book.
1. To edit a existing entry,
press [MENU] .
2. Use the Navigation Key to select a group.
3. Select an entry and press to view and edit the
entry, or [DEL] to delete it.
PHONE BOOK
PHONE BOOK
● Personal, Business, Etc., All.
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 42
Chapter 3 - Page 43
Page 42 - Chapter 3
PHONE BOOK
PHONE BOOK
CHANGE GROUP NAME
1. To change a group name,
press [MENU] .
2. Select an existing group name and press .
3. Input a new name.
4. Press [OK] to save it.
EDIT EXISTING GROUP
1. To editing menu, press [MENU] .
2. The 3 existing group appear - Family, Friend, Work.
3. Use the Navigation key to select an existing group.
4. To edit a group.
5. Press [OK] to save it.
6. Press [OK] again to confirm it.
CLEAR GROUP
1. To delete an existing group,
press [MENU] .
2. Select the group to be deleted and press .
“Clear [Group name]?” will be displayed.
3. Press [OK] to delete it.
EDIT SMS GROUP
Adds, changes and deletes a group.
ADD NEW GROUP
1. To add a new group, press [MENU] .
A maximum of seven groups is allowed.
2. Input a new group name.
3. Press [STO] to save it.
PHONE BOOK
PHONE BOOK
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 44
Chapter 3 - Page 45
Page 44 - Chapter 3
PHONE BOOK
PHONE BOOK
MY PROFILE
Saves your personal information.
1. Press [MENU] to review and edit your
personal information (Name, My Phone number,
Birthday, Blood Type, Address, Home Number, E-Mail,
Work Phone Number, Memo, Set Secret).
2. Use the Navigation key to select the item to be
edited then press .
3. To confirm and save it. Press [STO].
TO CLEAR THE GROUP
1. To clear a group name,
press [MENU] .
2. Select a group name and press .
3. “Clear [Group Name]?” will be displayed.
4. Press [OK] to delete the group.
SPEED DIAL
Links a phone number from the phone book to a location
number and enables you to call that number simply by
pressing its location number from the idle mode.
1. Press [MENU] .
2. To assign a phone number to a location, select the
location and press .
3. Select the group where the phone number is saved
and press .
4. Select the entry and press , select the phone
number and press again.
PHONE BOOK
PHONE BOOK
● If a phone number is already assigned to the location,
press [DEL] and the Navigation key to delete.
NOTE:
To edit a selected item of Blood type,
press .
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 46
RECEIVED
Displays information about the 10 most recently
answered calls. You can dial a selected number by
simply pressing .
1. To see a list of the 10 most recently answered calls,
press [MENU] . If the number is already
stored in your phone book, only the name appears.
If the number is not stored, only the phone number
appears.
2. To view incoming call details, press the .
3. Press [OPTS] to save the number or press
[DEL] to delete it.
RECENT CALLS
RECENT CALLS
DIALED
Displays information about the ten most recently dialed
numbers. You can dial a selected numbers by simply
pressing .
1. To see a list of the 10 most recently dialed numbers,
press [MENU] . If the number is already
stored in your phone book, only the name appears.
If the number is not stored, only the phone number
appears.
2. To view outgoing call details, press .
3. Press [OPTS] to save the number or press
[DEL] to delete it.
Chapter 3 - Page 47
RECENT CALLS
RECENT CALLS
The CDM-8425PTT keeps a log of the 10 most recently
missed, received (incoming) and dialed (outgoing)
calls. Log information includes the phone number,
the date and time of the call.
This feature is not intended for billing purposes.
Page 46 - Chapter 3
In idle mode, you can access Recent Calls by
pressing [MENU] .
● Shortcut : From idle mode, press and hold to access the
recently dialed call numbers.
● “Phone # is already saved in phone book” or “Move to phone
book save mode?” will appear.
●Call details include date, time and phone number.
NOTE:
After the tenth outgoing call, the oldest call will
automatically be erased from the history.
● “Phone # is already saved in phone book” or “Move to phone
book save mode?” will appear.
NOTE:
Call details include date, time and phone number.
NOTE:
After the tenth incoming call, the oldest call will
automatically be erased from the history.
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 48
Chapter 3 - Page 49
Page 48 - Chapter 3
RECENT CALLS
RECENT CALLS
MISSED
Displays information about the 10 most recently missed
calls. Place a call to a missed call number by simply
pressing .
1. To see a list of the 10 most recently missed calls,
press [MENU] . If the number is already
stored in your phone book, only the name appears.
If the number is not stored, only the phone number
appears.
2. To view missed call details, press .
3. Press [OPTS] to save the number or press
[DEL] to delete it.
RECENT CALLS
RECENT CALLS
CALL TIMERS
Checks the talk time and manages your calls within the limit
you set. The five timers include:
LAST CALL
To display the total time of your last call:
1. Press [MENU] .
2. To return to the previous page, press [CLR].
ALL CALLS
To display the total time of all calls:
1. Press [MENU] and the message
“Not intended for billing purposes” appears for
5 seconds.
2. Use the Navigation Key to view the time of the
following items:
3. To resert the timer, press [RST].
● “Phone # is already saved in phone book” or “Move to phone
book save mode?” will appear.
NOTE:
Call details include date, time and phone number.
● Voice, Data/Fax
NOTE:
After the tenth missed call, the oldest call will
automatically be erased from the history.
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 50
Chapter 3 - Page 51
Page 50 - Chapter 3
RECENT CALLS
RECENT CALLS
CUMULATIVE CALLS
To display talk time of cumulative calls:
1. Press [MENU] and the message “Not
intended for billing purposes” appears for 5 seconds.
2. Use the Navigation Key to view the time of the
following items:
HOME CALLS
To display the total time of calls placed within your
home area:
1. Press [MENU] and the message “Not
intended for billing purposes” appears for 5 seconds.
2. Use the Navigation Key to view the time of the
following items:
3. To reset the timer, press [RST].
To return to the previous page, press [CLR].
ROAM CALLS
To display the total time of calls placed outside your
home area:
1. Press [MENU] and the message “Not
intended for billing purposes” appears for 5 seconds.
2. Use the Navigation Key to view the time of the
following items:
3. To reset the timer, press [RST] .
To return to the previous page, press [CLR].
RECENT CALLS
RECENT CALLS
● Voice, Data/Fax
● Voice, Data/Fax
● Voice, Data/Fax
NOTE:
Cumulative ime can not be reset.
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 52
Page 52 - Chapter 3
This chapter addresses customizing your phone by
adjusting backlighting, volume, ring tones and other
user-friendly features.
Settings
VS Menu
VR Mode
PTT
Chapter 4
SETTINGS
Chapter 4 - Page 53
MEMO
MEMO
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 54
Chapter 4 - Page 55
Page 54 - Chapter 4
SOUNDS
This feature allows you to select sounds for Ringer type,
Ringer Mode, Volume, Alert, Roam Ringer, Tone Length
and Etiquette Mode.
RINGER TYPE
Selects a ringer type to alert you of an incoming call.
RINGER LIST
1. Press [MENU] .
2. Select a ringer type from the 9 melodies and
11 ringer types with the Navigation Key, then
press [OK] to save it.
MY DOWNLOADS
My Downloads stores Ringer Lists downloaded through
“Get It Now”.
1. Press [MENU] .
2. To select a downloaded ringer type from “Get It
Now” with the Navigation Key, then press [OK]
to save it.
ANIMATED RINGER
Animated Ringer stores Animated Ringer Lists
downloaded through “Get It Now”.
1. Press [MENU] .
2. Select a downloaded animated ringer type from
“Get It Now” with the Navigation Key, then
press [OK] to save it.
SETTINGS
SETTINGS
EMS DOWNLOADS
EMS Ringer stores Ringer Lists downloaded through
EMS in SMS.
1. Press [MENU] .
2. Select a downloaded ringer type from “SMS” to
“EMS” with the Navigation Key, then press [OK]
to save it.
RINGER MODE
This feature allows you to choose how you want to be
alerted to an incoming call.
1. Press [MENU] .
2. Select one of the following options:
3. To confirm, press [OK].
VOLUME
Controls the Ringer, Key and Voice Call volume.
RINGER
To adjust the ringer volume.
1. Press [MENU] .
2. Adjust the ringer volume using the Navigation Key
or the volume keys on the side of the phone.
3. To save, press [OK].
SETTINGS
SETTINGS
● Ringer : Phone plays ringer selected in Ringer List.
● Vibrate : Phone vibrates only.
● Ringer after Vibrate : The ringer sounds after vibration.
● Silent : Mutes the ringer.
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 56
Page 56 - Chapter 4 Chapter 4 - Page 57
SETTINGS
SETTINGS
KEY
To adjust the keypad tone.
1. Press [MENU] .
2. Adjust the keypad tone using the Navigation Key
or the volume keys on the side of the phone.
3. To save, press [OK].
VOICE CALL
To adjust the earpiece volume.
1. Press [MENU] .
2. Adjust the earpiece volume with the Navigation Key
or the volume keys on the side of the phone.
3. To save, press [OK].
ALERT
This feature allows you to select alerts to sound when
the phone performs certain functions. Alerts include:
MINUTE ALERT
To set an alert to sound every minute of a phone call:
1. Press [MENU] .
2. Select “Off” or “On” then press [OK] to save it.
SETTINGS
SETTINGS
ROAM ALERT
To sounds an alert when leaving a service area and
entering a roaming service area:
1. Press [MENU] .
2. Select “Off” or “On” then press [OK] to save it.
CONNECT ALERT
Sounds an alert to notify you that a call has been
successfully placed:
1. Press [MENU] .
2. Select “Off” or “On” and press [OK] to save it.
FADE ALERT
Sounds an alert when entering an area where calls
cannot be made due to weak signal strength.
1. Press [MENU] .
2. Select “Off” or “On” and press [OK] to save it.
LOW SIGNAL ALERT
Sounds an alert when you encounter low signal
strength.
1. Press [MENU] .
2. Select “Off” or “On” and press [OK] to save it.
NOTE: The alert sounds in standby mode or during a call.
NOTE: The alert sounds in standby mode or during a call.
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 58
SETTINGS
SETTINGS
ROAM RINGER
If you choose Distinctive you will have to select a ringer
type.
1. Press [MENU] .
2. Select “Distinctive” or “Normal” and press [OK]
to save it.
TONE LENGTH
To adjust tone length:
1. Press [MENU] .
2. Select “Normal” or “Long” and press [OK]
to save it.
ETIQUETTE MODE
1. Press [MENU] .
2. Select “On” or “Off”.
3. To save, press [OK].
Chapter 4 - Page 59Page 58 - Chapter 4
SETTINGS
SETTINGS
DISPLAY
Customizes and personalizes the display.
ANIMATION SETTING
Selects your favorite LCD display in the following modes:
IDLE DISPLAY
1. Press [MENU] .
2. Select a display from the Animation list.
3. Press [OK] to save it.
POWER ON DISPLAY
1. Press [MENU] .
2. Select a display from the Animation list.
3. Press [OK] to save it.
POWER OFF DISPLAY
1. Press [MENU] .
2. Select a display from the Animation list.
3. Press [OK] to save it.
● Distinctive : Sounds a different ringer type.
● Normal : Sounds the same ringer type as used in Home
area.
● On : Etiquette Mode on.
● Off : Etiquette Mode off.
Shortcut : To activate/deactivate etiquette mode, press
and hold .
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 60
SETTINGS
SETTINGS
MAIN DISPLAY SETTING
Selects your favorite LCD display for the following
modes:
GREETING INPUT
To input a personal greeting:
1. Press [MENU] .
2. To edit the banner, press .
3. Input your personal banner, using the Alpha
Editor. (Refer to page 33).
4. To save, press [STO].
IDLE CLOCK
To display a clock on the LCD:
1. Press [MENU] .
2. Select one of the following options and
press [OK] to save it.
Chapter 4 - Page 61
Page 60 - Chapter 4
SETTINGS
SETTINGS
LCD SETTING
Controls backlight and LCD contrast for a better view
and more efficient use.
BACKLIGHTING
Backlights the display and keypad for easy viewing
in dark places.
1. Press [MENU] .
2. Select one of the following options:
Off, 5 secs, 10 secs, 20 secs.
To save, press [OK].
CONTRAST
The LCD display contrast can be adjusted to 5 levels.
1. Press [MENU] .
2. Adjust the LCD contrast for better view.
3. To save, press [OK].
● Off : Turn the backlight off.
● 5 secs, 10 secs, 20 secs : Backlight on for 5, 10, or 20
seconds respectively after a
touch of the keypad.
● Digital Clock
● Analog Clock
● Greeting Clock
● Animation + Clock
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 62
GRAPHIC SETTING
SCREEN SAVER
1. Press [MENU] .
WALLPAPER
1. Press [MENU] .
2. Select parameters (Download Image/EMS Image),
then press .
SETTINGS
SETTINGS
Chapter 4 - Page 63
Page 62 - Chapter 4
SETTINGS
SETTINGS
SYSTEM
Scans the channels so your phone can stay connected
to any available system.
SET MODE
Selects the Preferred System.
1. Press [MENU] .
2. Select one of the following options
(Automatic B/Automatic A/Home Only) and
press .
FORCE ANALOG
Temporarily forces phone to use Analog mode – mode
automatically ends in 10 minutes.
1. Press [MENU] .
2. Select “No” or “Yes” then press [OK] to
activate it.
● TIME SETTING : Determines when the screen saver
activates.
Select one of the following options : Off / 5 Secs / 10 Secs
/ 20 Secs / 30 Secs.
● SCREEN SAVER
Select parameters (DOWNLOAD IMAGE/EMS IMAGE)
by using the Navigation Key, then press .
● Automatic B : Scan the radio channels based on the
Automatic B setting.
● Automatic A : Scan the radio channels based on the
Automatic A setting.
● Home Only : Scan radio channelsonly within your home
area or home affiliated area.
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 64
SETTINGS
SETTINGS
NAM SETTING
Enables Auto NAM (Number Assignment Modules) or
manually selects a NAM.
AUTO NAM
Automatically switches phone to proper NAM when you
have multiple NAM registrations.
1. Press [MENU] .
2. Select “Yes” or “No” then press [OK] to save it.
CHANGE NAM
Changes the NAM used by the phone when you have
multiple registrations.
1. Press [MENU] .
2. Select “NAM1-VERIZON” or “NAM2-VERIZON”
then press [OK] to save it.
PRL ID
Displays the phone’s PRL (Preferred Roaming List).
1. Press [MENU] .
Chapter 4 - Page 65
Page 64 - Chapter 4
SETTINGS
SETTINGS
Enables Verizon network system to locate your position
and allows the use of some Verizon wireless applica-
tions.
LOCATION
To determine whether or not the network system can
detect your position:
1. Press [MENU] .
2. Select “911 Only” or “Location On”.
3. To save, press [OK].
● 911 Only : Your location will be hidden from network &
applications except 911.
● Location On : Your location is now available to the
network.
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 66
SETTINGS
SETTINGS
Chapter 4 - Page 67
Page 66 - Chapter 4
SETTINGS
SETTINGS
OTHERS
ANSWER MODE
To select an answer mode:
1. Press [MENU] .
2. Select “Any Key” or “Send Key”.
3. To save, press [OK].
AUTO RETRY
Automatically retries a call up to 5 times after a set time
interval.
RETRY TIME
1. Press [MENU] .
2. Select a time interval option to automatically retry
a call (Off, 3, 5, 7, 10 seconds).
To save, press [OK].
REPEAT
1. Press [MENU] .
2. Select one of the options (1 time, 3 times, 5 times).
To save, press [OK].
● Any Key : Press any key to answer an incoming call
except , , and .
● Send Key : Press only to answer a call.
AUTO ANSWER
Automatically answers a call after a preset number of
rings.
1. Press [MENU] .
2. Select on of the following:
3. To save, press [OK].
VOICE PRIVACY
Enhances voice privacy and avoids tapping during a call.
1. Press [MENU] .
2. Select “Standard” or “Enhanced”.
3. To save, press [OK].
● Off / 5 / 10 / 18 seconds.
● “Enhanced” : Makes it more difficult to wire tap.
NOTE: This function will not be active when you select
Vibrate, Silent, Etiquette or Ringer after Vib as a
ringer mode.
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 68
Chapter 4 - Page 69Page 68 - Chapter 4
SETTINGS
SETTINGS SETTINGS
SETTINGS
KEY GUARD
1. Press [MENU] .
2. Select “On” or “Off”.
3. To save, press [OK].
LANGUAGE
To select the language in which letters and words.
Are displayed on screen.
1. Press [MENU] .
2. Select either “English” or “Spanish”.
3. To save, press [OK].
WEB IDLE TIME
When connected to a network, this feature automatical-
ly disconnects your phone from the network when there
is no key input for a period of time that you set.
1. Press [MENU] .
2. Use the scroll key to set the web idle timer or press
digit keys one by one to enter the time.
3. To save, press [OK].
TTY MODE
Your phone is able to operate with a “TTY” (Teletypewriter)
device in both analog and digital modes. This feature is
system dependent and may not be available in all areas.
CONNECTING TO TTY DEVICE
1. Turn the “TTY” device off.
2. Connect the “TTY” device to the phone at the
earphone-microphone jack.
ACTIVATING/DEACTIVATING TTY MODE
1. Press [MENU] .
2. Select one of the following options (TTY Full/
TTY+TALK/TTY+HEAR/TTY Off) then press .
S/W VERSION
To display the version of your phone:
1. Press [MENU] .
2. Your phone’s software and hardware version appear
on the display.
3. Press [OK].
● On : Prevents accidentally pressing the keypad.
● Off : Key guard off.
● Timer length cannot exceed 3 digits.
NOTE: To unlock the key guard, press .
● A TTY (also known as TDD or Text Telephone) is a
telecommunications device that allows people who
are deaf or hard of hearing, or who have speech or
language disabilities, to communicate by telephone.
Connect the TTY device to the Headset Jack of PCS
Phone. Then type the message you want to send on
the TTY’s keyboard.
MAKING AND ANSWERING A CALL
You can make or answer calls in the same manner as
ordinary calls.
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 70
Chapter 4 - Page 71
VS MENU
VS MENU
1. To start VS menu, press .
2. To enter the voice memo menu, press .
3. When you press to record a voice memo,
instructions will appear and you will hear “Please
record it at the tone”.
4. To stop recording a memo, press .
5. After recording a voice memo you can “Review”,
“Re-record” or “Save”.
VOICE MEMO
1. To start VS menu, press .
2. To enter the voice memo menu, press .
3. To play the voice memo menu, press , select the
desired voice memo, then press .
RECORD VOICE MEMO
PLAY VOICE MEMO
NOTE: Edit Key - Edits the voice memo title.
CLR Key - Deletes the selected voice memo.
1. To start VS menu, press .
2. To enter the voice memo menu, press .
3. To delete a voice memo, press .
CLEAR ALL
NOTE: To pause, press . To resume, press .
Page 70 - Chapter 4
SETTINGS
SETTINGS
SPEAKER MODE
1. Press [MENU] .
2. Select “On” or “Off”.
3. To save, press [OK].
● On : Speaker phone on.
● Off : Speaker phone off.
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 72
Chapter 4 - Page 73
VS MENU
VS MENU
VOICE COMMAND
With Voice Command you can train the Voice Recorder
to make calls by simply saying the control words
outlined below.
YES/NO
1. Press .
2. Select one of the following options, then press .
LIST WORDS : Displays the list of control words in the
Yes/No set. Select a control word from the
list then press . Either train, untrain
or view its status. To train a word, press .
TRAIN ALL : Train Yes/No set to recognize your voice.
UNTRAIN ALL : Untrain Yes/No set to recognize trained
control words.
WAKE-UP
Use Wake-Up to train or untrain the VR with the control
word, Wake-Up.
1. Press .
2. Select one of the following options, then press .
LIST WORDS : Displays the list of control words in the
Wake-Up set. Select a control word from
the list then press . Either train, untrain
or view its status. To train a word, press
and follow the voice prompts.
TRAIN ALL : Train Wake-Up set to recognize your voice.
UNTRAIN ALL : Untrain Wake-Up set not to recognize
trained control words.
Page 72 - Chapter 4
VS MENU
VS MENU
CALL ANSWER
Sets and operates the answering machine.
1. Press .
2. Select one of the following options, then press .
ON/OFF : Turns the Call Answer Mode on/off.
INBOX : Plays or erases a recorded memo.
CALL SPEAKER ON : You can(not) hear the caller’s
voice being recorded by answering
machine.
WAIT TIME : No ringer, 5s, 10s, 18s. Answering machine
will answer the call after a specific time.
RECORDING LIMITATION :
You have a limit of 10 voice memos including those in
Answering Machine. Each voice memo has the time limit of
60 seconds.
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 74
Chapter 4 - Page 75
VS MENU
VS MENU
VOICE DIAL
Voice tags allow you to make calls in VR Mode by simply
saying the person’s name. Using the VS Menu, you can
list, add or erase voice tags for phone book entries.
ADD
1. Press .
2. To add a voice tag to phone book entry,
press .
3. Select a group, then press [OK].
4. Select an entry, then press [OK].
5. Select a phone number, then press [OK].
6. “Enter voice tag?” will be displayed.
Press , then say the name.
LIST
1. Press .
2. To list phone book entries with attached voice
tags, press .
3. Select one of the entries, then press [OK].
Page 74 - Chapter 4
VS MENU
VS MENU
TOP LEVEL
Use Top Level to train or untrain the VR with your
control words (Dial, Redial, Voice Memo, Phone Book,
Cancel).
1. Press .
2. Select one of the following options, then press .
LIST WORDS : Displays the list of control words in the top
level set. Select a control word from the
list then press . Either train, untrain or
view its status. To train a word, press .
TRAIN ALL : Train Top level set to recognize your voice.
UNTRAIN ALL : Untrain Top level set not to recognize
trained control words.
DIGIT DIAL
Use Digit Dial to train or untrain the VR with the control
words (1 to 9, Zero, Oh, Verify, Clear, Call).
1. Press .
2. Select one of the following options, then press .
LIST WORDS 1, 2 : Displays the list of control words in the
digit dial set. Select a control word
from the list then press . Either
train, untrain or view its status. To
train a word, press and follow the
voice prompts.
TRAIN ALL : Train Digit Dial set to recognize your voice.
UNTRAIN ALL : Untrain Digit dial set not to recognize
trained control words.
EDIT : Retrain / Voice Setting / Clear.
PLAY : Play voice tag.
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 76
Chapter 4 - Page 77
VS MENU
VS MENU
VOICE ALERT
Sets the voice alert service.
ON/OFF
1. Press .
2. Select “On” or “Off”, then press .
RECORD
1. Press .
2. Record voice alert.
PLAY
1. Press .
2. Confirm voice alert.
CLEAR
1. Press .
2. Select “Yes” or “No”, then press .
Page 76 - Chapter 4
VS MENU
VS MENU
CLEAR ALL
1. Press .
2. To erase all voice tags in the list, press .
3. “Removing all voice tags proceed?” appears.
4. Press [OK] and you will see the message, “Delete
all tagged book entries too?”. Select No by pressing
,Yes by pressing and CLR by pressing .
5. “All voice tags were deleted successfully” will be
displayed.
OK : Proceed to erase all the voice tags.
CLR : Return to the previous page.
4. Press [PLAY] to play a voice tag or [EDIT]
to edit an existing voice tag.
5. If you select Edit, select one of the following options,
then press [OK].
1) Retrain: “Retrain Voice Name?” appears. Press , then
say a name.
2) Voice Setting: “Change?” appears. Press , select a
phone number, then press again.
3) Clear: “Removing Voice Names Proceed?” appears.
Press .
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 78
Chapter 4 - Page 79
VS MENU
VS MENU
DIGIT MODE
Use the digit mode to select one of the following
options ; ECHO, BEEP, ECHO+BEEP.
1. Press .
2. Select one option, then press .
HFK MODE
HFK stands for Hands-Free Car Kit. With this function,
you can activate and utilize the VR feature when the
phone is in hands-free car kit.
1. Press .
2. Select “On” or “Off”, then press .
ECHO : Digit echoes back when entered.
BEEP : Digit beeps when entered.
ECHO + BEEP : Digit echoes and beeps when entered.
NOTE: Once you say “Wake-Up” and the phone
recognizes your voice, you will hear a beep.
The second time you say “Wake-Up”, your phone
turns to VR mode.
Page 78 - Chapter 4
VS MENU
VS MENU
VOICE SETTING
Customizes the voice service menu.
UNTRAIN ALL
1. Press .
2. Select “Yes” or “No”, then press .
PROMPT MODE
Use the prompt mode to select either beginner or expert
mode. The expert mode consists of shorter texts and just
beeps as opposed to the beginner mode that gives full
instructions.
1. Press .
2. Select “Beginner” or “Expert”, then press .
<Beginner mode>
1st prompt : “Main menu” followed by a short beep.
2nd prompt : “Speak a name to call, or say dial, redial, voice
memo, phone book, or cancel”, followed by a
short beep.
<Expert mode>
1st prompt : A sequence of high and low tones.
2nd prompt : “Main menu”.
NOTE:
The VR times out and the phone returns to the standby
mode after the 1st and 2nd prompts are heard and
nothing is said.
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 80
Page 80 - Chapter 4
VR MODE
VR MODE
DIAL
1. Press and hold until your phone
turns to VR mode.
2. Say “Dial” and the display on the
right will appear.
3. Press or say the digits of the phone number.
4. After entering the entire number, say “Call”.
REDIAL
1. Press and hold until your phone turns to VR
mode.
2. To call the last dialed number, say “Redial”.
NOTE:
Beginner mode
- 1st prompt :“Digit menu”.
- 2nd prompt :“Say digits or verify, cancel, clear, or call”.
Expert mode
- 1st prompt :“doo-doo” (a sequence of high and low tones).
- 2nd prompt :“Digit menu”.
Depending on the prompt mode, expert or beginner, you
will hear a different set of prompts that follows. You will
hear the second prompt when nothing is said.
Say digits one at
a time, or command
Digit Dial
MENU
Chapter 4 - Page 81
VR MODE
VR MODE
Voice Recognition (VR) enables you to place calls and
record voice memos using your voice.
1. Press and hold until your
phone turns to VR mode.
2. When the phone turns to VR mode,
the screen on the right appears.
NAME
1. Press and hold and wait until your phone turns
to VR mode.
2. In VR mode, say a recorded name or tag stored in the
phone book, and the name and number will appear on
the display and you will hear “Calling (name).”
See page 75 for additional details.
NOTE: Depending on the prompt mode – expert or beginner
– you will hear a different set of prompts as listed
below. The second prompt will automatically play if
nothing is said.
Beginner Mode
- 1st : “Main Menu”.
- 2nd : “Speak a name to call, or say dial, redial, voice
memo, phone book or cancel”.
Expert Mode
- 1st : “beep”.
- 2nd : “Main Menu”.
Once you say one of the following options, you will go
through each of the procedures (name, dial, redial, voice
memo, phone book, cancel).
Say a name
or a command
VR Mode
MENU
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 82
Page 82 - Chapter 4
PTT
PTT
PTT CONTACTS
1. Press and hold until your phone turns to VR
mode.
Chapter 4 - Page 83
VR MODE
VR MODE
VOICE MEMO
This feature is the same as on page 71, except you
must use the phone to access the menu not your voice.
1. Press and hold until your phone turns to VR
mode.
2. Say “Voice Memo” instructions will appear and you
will hear “Please record it at the tone”.
3. To stop recording, press .
4. After recording a voice memo you can “Review”,
“Re-record” or “Save”.
PHONE BOOK
1. Press and hold until your phone turns to VR
mode.
2. Say “Phone Book”.
CANCEL
1. Press and hold until your phone turns to VR
mode.
NOTE: To pause, press . To resume, press .
Phone book entries with voice tags will appear and each
voice tag will play.
To exit VR mode or return to the standby mode, say
“Cancel.”
NOTE: To call a phone number with an attached voice
tag, say “Yes” while the voice tag plays.
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 84
PTT
PTT
Page 84 - Chapter 4
This chapter addresses security features including
locking and unlocking the phone, restricting calls and
clearing the phone book.
Chapter 5
SECURITY
FEATURES
Chapter 5 - Page 85
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 86
SECURITY FEA
SECURITY FEATURES
TURES
Chapter 5 - Page 87
NOTE: The default password is the last 4 digits of your
phone number.
DIALED
To block all outgoing calls except emergency calls from
being placed, but allows incoming calls to be answered:
1. Press [MENU] and enter “Password”.
2. Press and select “Allow” or “Restrict”.
3. To save, press [OK].
● Restrict : Restrict to make a call.
● Allow : Allow outgoing calls.
RECEIVED CALL HISTORY
The Received Call History lists the most recent incoming calls,
including phone numbers. To control access to the history:
1. Press [MENU] and enter “Password”.
2. Press and select “Allow” or “Restrict”.
3. To save, press [OK].
● Restrict : Restrict access to received call history.
● Allow : Allow access to received call history.
DIALED CALL HISTORY
The Dialed Call History lists the most recent outgoing calls,
including phone numbers. To control access to the history:
1. Press [MENU] and enter “Password”.
2. Press and select “Allow” or “Restrict”.
3. To save, press [OK].
● Restrict : Restrict access to the dialed call history.
● Allow : Allow access to the dialed call history.
SECURITY FEA
SECURITY FEATURES
TURES
Page 86 - Chapter 5
SECURITY
Prevents the unauthorized use of the handset and only
allows access to certain features to those who have the
password.
RESTRICT
Enables you to restrict certain features with the
password. Password must be entered to use restricted
features.
AUTOMATIC LOCK
Prevents others from using your phone without
permission. When locked, the menu can not be
accessed without the password.
1. Press [MENU] and enter “Password”.
2. Press and select “Off”, “Lock Now” or
“Power Up”.
3. To save, press [OK].
● Off : Do not lock the phone.
● Lock Now : Lock the phone now.
● Lock On Power Up : Lock the phone whenever it is
turned on.
NOTE: The default password is the last 4 digits of your
phone number.
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:37 AM Page 88
SECURITY FEA
SECURITY FEATURES
TURES
Chapter 5 - Page 89
900 #’S
To restrict calling 900 dial service numbers:
1. Press [MENU] and enter “Password”.
2. Press and select “Allow” or “Restrict”.
3. To save, press [OK].
● Restrict : Restrict calls 900-dial services.
● Allow : Allow 900-dial services.
LONG DISTANCE
By restricting long distance calls.
1. Press [MENU] and enter “Password”.
2. Press and select “Allow” or “Restrict”.
3. To save, press [OK].
● Restrict : Restrict calls long distance calls.
● Allow : Allow long distance calls.
NOTE: A phone number over 7 digits is to be restricted.
NOTE: The default password is the last 4 digits of your
phone number.
SECURITY FEA
SECURITY FEATURES
TURES
Page 88 - Chapter 5
MENU
To block access to the menu to prevent any changes:
1. Press [MENU] and enter “Password”.
2. Press and select “Allow” or “Restrict”.
3. To save, press [OK].
● Restrict : Restrict access to the menu.
● Allow : Allow access to the menu.
PHONE BOOK
To block access to, and protect data in your phone book.
1. Press [MENU] and enter “Password”.
2. Press and select “Allow” or “Restrict”.
3. To save, press [OK].
● Restrict : Restrict access to the phone book.
● Allow : Allow access to the phone book.
DATA CALL
To restrict data calls from being placed:
1. Press [MENU] and enter “Password”.
2. Press and select “Allow” or “Restrict”.
3. To save, press [OK].
● Restrict : Restrict data calls.
● Allow : Allow data calls.
NOTE: The default password is the last 4 digits of your
phone number.
Data Call Types : 1x express/qnc/fax/async data/get it now/
mobile web
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 90
SECURITY FEA
SECURITY FEATURES
TURES
Chapter 5 - Page 91
RESET PHONE
Resetting the phone restores it to the original default
settings. Any changes you made to options or features
will return to the factory settings. To reset the phone:
1. Press [MENU] and enter “Password”.
2. Press .
3. Select “Yes” or “No”, then press [OK].
CHANGE PASSWORD
To change your password:
1. Press [MENU] and enter “Password”.
2. Press .
3. Enter a new password and press [OK].
4. Enter the new password again and press [OK].
● When you select “Yes”, you will see “Wait a moment” on
the display and the phone will return to idle mode.
NOTE: The default password is the last 4 digits of your
phone number.
SPECIAL #’S
Special #’s allows you to store 3 phone numbers that
can be called even in the lock mode.
1. Press [MENU] and enter “Password”.
2. Press and select a location.
3. Press [OK] and input a phone number;
press [OK] again to save.
CLEAR PHONE BOOK
To clear all phone book entries:
1. Press [MENU] and enter “Password”.
2. Press .
3. Select “Yes” or “No”, then press [OK].
SECURITY FEA
SECURITY FEATURES
TURES
Page 90 - Chapter 5
NOTE: The default password is the last 4 digits of your
phone number.
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 92
This chapter addresses supplemental functions including
the schedule, calculator, clock and stopwatch features.
Schedule
Calculator
World Clock
Stop Watch
Chapter 6
SUPPLEMENTARY
FUNCTIONS
Chapter 6 - Page 93
MEMO
MEMO
Page 92 - Chapter 5
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 94
Chapter 6 - Page 95
ALARM
You can set up to 3 alarms.
1. To display alarm entries, press [MENU] .
2. Select one of the entries. To set a new alarm, choose
item 1, 2 or 3. To edit an existing alarm, select that
alarm. Press .
3.1. To set a time, press from the Alarm Setting
Menu.
3.2. To set a melody, press from the Alarm Setting
Menu.
3.3. To set a snooze, press from the Alarm Setting
Menu.
3.4. To set a pause, press from the Alarm Setting
Menu.
SCHEDULE
SCHEDULE
● To delete the existing one, press .
● Use the Navigation Key to choose an alarm frequency
(Once, Daily, Weekly, Monthly, Yearly).
To save, press [STO]. “Save Complete” will be
displayed and the screen will return to the alarm list.
● Use the Navigation Key to scroll through the list of
10 ringtones and 30 melody tones. To set a melody,
press [OK].
● Select one of the following : No use, 1 Time, After
3 minutes.
NOTE: Pause setting is available for existing alarms.
It is not available for new entries.
Page 94 - Chapter 6
The schedule allows you to set an event and reminds
you of that event.
EVENT
1. To display a calendar, press [MENU] .
2. Select New Event.
3. Move the Navigation Key to choose a date in the
calendar and press [OK].
4.1. To set a time for an event, press . Enter the
event name then press [STO].
Press [STO] again to save the event.
4.2. To set a melody for the event, press .
Select a melody then press [OK].
4.3. To set a message for the event, press .
5. Press [OK] to save it or [CLR] to return to the
calendar.
6. “Save complete” appears. When you return to the
calendar the day will be highlighted.
SCHEDULE
SCHEDULE
● Day to Day movement : Move the Navigation Key left
and right.
● Week to Week movement : Move the Navigation Key
down and up.
● Choose one of the following on the first line: On time, 10
Min before, 30 Min before, 1 Hour before, No alarm.
● Change the date and time in the second line by moving to
year, month, day, time input with the Navigation Key.
● The date of the event will be marked on your calendar.
● Use the Navigation Key to scroll through the list of
10 ringtones and 30 melody tones. To set a melody,
press [OK]
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 96
WORLD CLOCK
WORLD CLOCK
WORLD CLOCK
Notifies you of the time in a specific preprogrammed city.
1. Press [MENU] .
2. Select a city, then press [OK].
3. The world map appears with the city, its date and
time.
Chapter 6 - Page 97
● Use the Navigation Key to select another city.
Page 96 - Chapter 6
CALCULA
CALCULATOR
TOR
CALCULATOR
Allows you to use the CDM-8425PTT as a calculator to
perform basic mathematic functions (addition,
subtraction, multiplication, division).
1. Press [MENU] .
2. Follow the instructions below to calculate (8*6)/4-2.5
●Input 8.
Move the Navigation Key leftward.
Input 6 and press the Navigation Key.
Move it rightward.
Input 4 and press the Navigation Key.
Move it downward.
Input 2 and press the to input (.).
Press 5, .
3. To reset, press [RST].
NOTE: 1. Up to 10 integer digits and up to 2 decimals
can be displayed. If the calculated result
has more than 10 digits, the result is
displayed in 10 digit logarithm.
2. There is no (-) sign. To express a negative
number, use ‘0-value’.
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 98
This chapter addresses checking voice mail messages,
as well as sending and receiving text messages.
Two-Way SMS
Checking Messages
Sending Text Messages
Inbox
Outbox
Saved
My Object
Erase All
Settings
Chapter 7
VOICE MAIL AND
TEXT MESSAGES
Chapter 7 - Page 99
Page 98 - Chapter 6
STOP W
STOP WA
ATCH
TCH
STOP WATCH
Simultaneously times up to six different events.
To operate the stop watch:
1. Press [MENU] .
2. To measure a time period.
●To start the stop watch, press [START].
●To pause it, press [STOP].
●To resume, press [START].
To reset the counter, press [RST].
3. To time up to six events at once:
● To start, press [START].
● To stop a time period and continue measuring another
one, press [CONT].
● To stop the second and continue measuring a third one,
press [CONT].
● To measure up to six time periods,
To stop, press , repeat the above steps.
● To stop, press . To review the results, press [VIEW].
● To return to the stop watch, press or [CLR].
● To reset it, press [RST].
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 100
CHECKING MESSAGES
CHECKING MESSAGES
CHECKING RECEIVED VOICE MAIL MESSAGE
1. Press , then press or for
Voice Mail.
2. The number of voice mail messages currently
waiting in your mailbox appears. To access your
voice mailbox, press .
CHECKING RECEIVED TEXT MESSAGE
1. Press , then press or “Inbox”.
2. Highlight the message you want to view and press
[SEL]. The text message is displayed.
3. To view the Inbox message menu, press [OPTS].
From therethen you can reply, erase, forward, save,
save address, lock & unlock the message.
Chapter 7 - Page 101
RECEIVED MESSAGE NOTIFICATION
When your phone receives a message, the screen
displays the number of new text messages and voice
mail messages.
1. To display the received message, press the key .
TWO-W
TWO-WA
AY SMS
Y SMS
Your CDM-8425PTT features Two-Way Short Message
Service (SMS). This feature sends and receives text
messages through your phone. Voice mail notification
is also supported.
: Text Message
: Voice + Text Mail Message
: Voice Mail Message
MESSAGE INDICATORS
The following symbols indicate the status of message
received by your phone. These symbols appear for
voice mail and text messages.
Page 100 - Chapter 7
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 102
PRIORITY
Marks messages as urgent.
1. To send an urgent message, press “Priority”.
2. Select the priority (Normal/Urgent),
then press [OK].
CALL BACK
Allows you to input a specific call back number.
Your phone number is the default.
1. To change the call back number, press
“Call Back”.
2. Input call back number, then press [OK].
SAVE
This allows you to save the message into the ‘Outbox’
folder to use later.
1. To save the text message, press “Save”.
SENDING TEXT MESSAGES
SENDING TEXT MESSAGES
Chapter 7 - Page 103
INSERT SIGNATURE
1. To include your signature in message,
press “Insert Signature”.
2. Select (No/Yes), then press [OK].
EDIT MESSAGE
1. Press to change the text message.
2. Input a new text message, and press [OK].
SENDING TEXT MESSAGES
SENDING TEXT MESSAGES
SENDING NEW TEXT MESSAGES
1. Press then press or .
2. Input a new phone number then press [OK]
3. Input a new text message then press [NEXT].
● You can look up a number in the phone book by
pressing [PB].
● If “Delivery Failed. Retry in 3 mins?” appears,
press to select Auto retry.
SEND
1. To send the text message, press .
EDIT RECIPIENT
Edits the recipient’s information - select if a wrong
number is entered.
1. To change the recipient, press .
2. Input a new phone number, and press [OK].
3. Input a new text message, and press [OK].
4. To send, press .
Page 102 - Chapter 7
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 104
INBOX
INBOX
Chapter 7 - Page 105
INBOX MENU
The Inbox Menu options help you manage received text
messages. To access the menu:
1. Press then press or .
2. Select a message then press [SEL] .
The message is displayed.
3. Press [OPTS].
REPLY
1. To reply to the text message, press .
2. Type your reply and press [OK].
ERASE
1. To erase the text message, press .
2. When you see “Delete Msg?”, press [YES].
: Urgent New Msg(not read)
: Urgent read Msg
: New Msg (not read)
: Old Msg (already read)
: Lock (already read and locked)
SAVE ENTERED TEXT
1. To save a text message as a canned message,
press “Save Entered Text”.
SENDING TEXT MESSAGES
SENDING TEXT MESSAGES
Page 104 - Chapter 7
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 106
INBOX
INBOX
Chapter 7 - Page 107
BLOCK SENDER
1. Block all incoming messages from the block list,
press .
SAVE QUICK TEXT
1. Save the received message into canned message
press .
REPLY WITH COPY
1. Reply to the received message and include received
phone number and contents, press .
● BLOCK : Enter the address to block
● UNBLOCK : Enter the address to remove from block.
● VIEW LIST OF BLOCKED ADDRESS : Display the blocked
list on LCD.
IN YOUR PHONE
1. To save the text message in your phone,
press “Save”.
2. Press .
SAVE ADDRESS
1. To save the Call back number from the text message,
press “Save Address”.
2. To save the call back number into a memory
location, follow the procedures for “STORING
PHONE NUMBERS” on page 32.
LOCK & UNLOCK
1. To lock or unlock the text message, press
“Lock/Unlock”.
2. Select “Lock” to lock the message or “Unlock” to
unlock the message, then press [OK].
INBOX
INBOX
FORWARD
1. To forward the text message, press “Forward”.
2. Input the phone number of the person you are sending
the message, then press [OK].
3. Input any text message to go along with the
forwarded message, then press [OK].
Page 106 - Chapter 7
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 108
OUTBOX
OUTBOX
Chapter 7 - Page 109
ERASE
1. To erase a text message, press .
2. When you see “Delete Msg?”, press [YES].
SAVE ADDRESS
1. To save the Call back number,
press “Save Address”.
2. Select the phone number and press [OK].
Follow the procedures for “Storing phone numbers”
on page 32.
SAVE
1. To save the outbox text message in the Saved Folder,
press .
LOCK & UNLOCK
1. To lock or unlock the text message, press
“Lock/Unlock”.
2. Select “Lock” to lock the message or “Unlock” to
unlock the message, then press .
STATE
1. To display the status of an outbox message,
press .
OUTBOX
OUTBOX
OUTBOX MENU
The Outbox Menu options help you manage sent text mes-
sages or messages waiting to be sent. To access the menu:
1. Press then press or .
2. Select a message and press [OK] .
The message is displayed.
3. Press [OPTS].
RESEND
1. To resend a text message, press .
SEND TO
1. To send a message to another person, press .
2. Input the phone number and press .
3. Input a text message and press .
Page 108 - Chapter 7
: Auto resend
: Delivered
: Fail
: Not send
: Read
: Sent
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 110
MY OBJECT
MY OBJECT
Chapter 7 - Page 111
SAVED
Manages saved messages from the Inbox/Outbox.
1. Press then press or .
2. Select a message and press [SEL].
The message is displayed.
3. Press [OPTS].
4.1. If the text message is saved from the “Inbox” menu,
this screen will be displayed.
4.2. If the text message is saved from the “Outbox”
menu, this screen will be displayed.
5. Select one by pressing .
SA
SAVED
VED
Page 110 - Chapter 7
MY OBJECT
1. Press then press or .
2. Select a text message, then press [OK].
SOUND
1. To name, play or erase saved sound objects,
press .
2. Select “Name” to rename a sound with or “Play”
to play a sound with .
3. To erase a sound, press .
GRAPHICS
1. To name, play or erase saved graphic objects,
press .
2. Select “Name” to rename a graphic with or
“View” to view a graphic with .
3. To erase a graphic, press .
ANIMATION
1. To name, play or erase saved animation objects,
press .
2. Select “Name” to rename animation with or
“View” to view animation with .
3. To erase animation, press .
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 112
Chapter 7 - Page 113
ERASE ALL
ERASE ALL
ERASE MESSAGES
Erases all the messages from the “Inbox”, “Outbox”,
“Saved” or “My Object” folder.
1. Press then press or .
2.1. To erase all the inbox messages, press .
2.2. To erase all the outbox messages, press .
2.3. To erase the saved messages, press .
2.4. To erase the my object, press .
3. Select “Yes” by pressing .
Select “No” by pressing .
● Erases entire inbox or old inbox.
● Erases entire outbox or old outbox.
Page 112 - Chapter 7
SETTINGS
SETTINGS
SETTINGS MENU
Manages messaging features through various features.
1. Press then press or .
“Settings”.
SAVE SENT MESSAGES
Saves every sent message.
1. Press “Save Sent MSG”.
2. Select “No”, “Yes”, or “Prompt”, then press [OK].
DEFAULT CALL BACK NUMBER
Edits a default call back number so that the recipient can
call back or reply.
1. Press “Default Call Back”.
2. Input a call back number, then press [OK].
● If you select Prompt, each time you send a message you
will be asked if you want to save it.
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 114
Chapter 7 - Page 115
SETTINGS
SETTINGS
ALERT
Enables phone to alert you of an incoming message.
1. Press “Alert”.
2. Select “Ringer”, “Vibrate”, “Silent”, “Ringer &
Remind”, or “Vibrate & Remind”.
3. Press [OK].
AUTO ERASE
Automatically erases (Inbox/Outbox) messages when
new messages arrive.
AUTO ERASE INBOX
1. Press “Auto Erase Inbox”.
2. Select “Disable” or “Old Inbox”.
3. Press [OK].
AUTO ERASE OUTBOX
1. Press “Auto Erase Outbox”.
2. Select “Disable” or “Old Outbox”.
3. Press [OK].
● The Ringer & Remind or Vibrate & Remind rings or
vibrates every 2 minutes to remind you of an incoming
message. They will be cleared when any key is pressed.
Page 114 - Chapter 7
SETTINGS
SETTINGS
ENTRY MODE
Sets an Entry Mode as a default.
The T9 mode indicator will appear whenever the input
mode is activated if the T9 mode is the default.
1. Press “ENTRY MODE”.
2. Select “T9 Mode” or “Alpha Mode”.
3. Press [OK].
BLOCK OR UNBLOCK
1. Press “Block” or “Unblock”.
2. Select “Block”, “Unblock”, or “View List of Blocked
Address”.
3. Press [OK].
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 116
Chapter 8
MAKING AN
EMERGENCY CALL
Chapter 8 - Page 117
Page 116 - Chapter 7
SETTINGS
SETTINGS
SIGNATURE
With this feature you can create and save a signature
to include in messages.
1. Press “Signature”.
2. Select “Edit Signature” or “Insert Signature”.
3. Press [OK].
DIRECT VIEW
Read the received message without entering inbox in
SMS menu.
1. Press “Direct View”.
2. Select “Yes” or “No”.
3. Press [OK].
● EDIT SIGNATURE : Edit user's signature.
● INSERT SIGNATURE : Select whether the signature will
be included into sending
message.
● YES : Set to read msg without entering inbox in SMS menu.
● NO : Set to read msg after entering inbox in SMS menu.
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 118
This chapter addresses using your handset to access
the Wireless Internet.
Get It Now
Start Internet Browser
Browser Menu
Chapter 9
GET IT NOW &
INTERNET
Chapter 9 - Page 119
911 IN LOCK MODE
The “911” call service is available even in the lock mode.
1. Enter “911” and press .
2. The call connects.
3. The phone exits the Lock Mode for 5 minutes.
EMERGENCY CALLING
EMERGENCY CALLING
Page 118 - Chapter 8
● When the call ends, the phone returns to the Lock
Mode.
911 USING ANY AVAILABLE SYSTEM
1. Enter “911” and press .
2. The call connects.
3. The phone maintains the Emergency Mode for
5 minutes.
● When the call ends, the phone returns to the Lock
Mode.
● The phone continuously attempts to receive service
from any available system.
This 911 feature puts phone in the Emergency Call
Mode when you dial the preprogrammed emergency
number, 911. It also operates in the lock mode and out
of the service area.
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 120
Chapter 9 - Page 121
GET IT NOW
GET IT NOW
OPEN AN APPLICATION
Applications that have been downloaded to the phone
are stored in Get It Now in the phone's Main Menu. Each
application is identified by an icon for easy identification.
1. Press , then select “Get it Now” and press .
2. Select the application icon, then press .
VIEW INFORMATION ON MEMORY AND LOG
You can continue to download applications to your Get It
Now capable phone as long as you have memory
available.
1. Press , “Get it Now”, then press .
2. Select “Get it Now Shopping Cart” then press .
3. Select “Settings” then press .
4. Select “Manage Apps” or “Log” then press .
Some applications require a network connection and use airtime.
A message will appear on the phone display when you launch the
application if airtime charges apply. Airtime usage applies whenever
you are connected to the network.
Some applications may initiate a network connection without the
user pressing on their wireless phone.
● Information : To view available memory.
● Log : To view the application log.
Page 120 - Chapter 9
DOWNLOADING APPLICATIONS
1. Press .
2. Select “Get it Now Apps” then press .
3. Select “Get it Now Shopping Cart” then press .
4. Select a folder in catalog with then press .
5. The phone will access your service provider’s server.
Follow the prompt to download applications.
GET IT NOW
GET IT NOW
Get It NowSM is an exciting new technology offered by Verizon
Wireless. With a Get It Now–capable handset, you can get direct
downloads of popular software applications. You can take advantage
of enhanced graphic applications like games, location-based services,
and productivity tools, and personalize your handset with ringtone
download and digital image sharing tools right on your wireless hand-
set. Application availability is handset dependent.
● Get Tones : Download ringtones and personalize your wireless
phone.
● Get Games : Turn your wireless phone into an arcade with
exciting games like Tiger Woods Golf, UNO and
Wheel of Fortune.
● Get Mail : Use e-mail application software to send, receive and
manage mail from your wireless phone.
● Get Going : Download productivity and information applications
to your wireless phone and manage expenses,
check flights, and find a great restaurant.
● Get Pix : Carry your favorite photos with you on your wireless
phone.
● Get Fun : Find a good joke, get concert information, and find out
what the future has in store with applications like
Laugh, MP3 Mobile and Magic 8 Ball.
● To select an option, press then press .
● When a prompt appears, press to proceed or to cancel.
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 122
Chapter 9 - Page 123
GET IT NOW
GET IT NOW
5. Select the application you wish to remove.
6. Select “Remove” and confirm by press .
Airtime charges will apply while removing applications billed with
subscription pricing.
Page 122 - Chapter 9
GET IT NOW
GET IT NOW
DISABLE AND RESTORE AN APPLICATION
If you attempt to download an application, but your
phone’s memory is full or nearly full you can disable
applications to free up space.
1. Press . “Get it Now” then press .
2. Select “Get it Now Shopping Cart” then press .
3. Select “Settings” then press .
4. Select “Manage Apps” then press .
5. Select the application you wish to disable or restore.
6. Select “Disable” or “Restore” then press .
REMOVE AN APPLICATION
If you no longer want access to an application you can
remove it from your phone. If you wish to use an appli-
cation that has been removed, you must download and
purchase it again.
1. Press , “Get it Now” then press .
2. Select “Get it Now Shopping Cart” then press .
3. Select “Settings” then press .
4. Select “Manage Apps” then press .
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 124
BROWSER MENU
BROWSER MENU
BROWSER MENU
The browser menu lists the actions necessary to
operate the browser.
Press or press to access the browser
menu.
BACK
◆ To return previous page, press or press ,
then press .
HOME
◆ To display the homepage, press or press ,
then press .
EXIT
◆ To exit the browser, press or press ,
then press .
MARK SITE
◆ To add the current page to your bookmark list,
press or press , then press .
Chapter 9 - Page 125
● “No bookmark service site” is displayed when the
Internet site cannot support the bookmark service.
ACCESS THE INTERNET
Your CDM-8425PTT allows you to browse various
Internet websites directly from your phone. This pro-
vides you with access to up-to-date information such
as news, sports, weather and stock quotes when you
subscribe to Internet service with your service provider.
Please contact your service provider for a list of avail-
able websites and service details.
1. To start your Internet browser and access websites
through your wireless handset press or
press .
ST
STAR
ART INTERNET BROWSER
T INTERNET BROWSER
Page 124 - Chapter 9
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 126
BROWSER MENU
BROWSER MENU
PROXY
◆ Enables you to select another WAP PROXY.
◆ To select Set UP.Link, press .
CIRCUIT LINGER
◆ To select Circuit Linger Timer, press .
SCROLL MODE
◆ To select scroll mode, press .
SCROLL SPEED
◆ To select scroll speed, press .
KEY PRESS TIMEOUT
◆ To select Key Press Timeout, press .
SECURITY
◆ Displays Security Menu Options.
◆ To select Security, press .
ADVANCED
◆ Displays Advanced Menu options.
◆ To select Set UP.Link, press .
Chapter 9 - Page 127
● SHOW URL
Displays the URL (Uniform Resource Locator) of the
current page.
1. To select Show URL, press .
● RESTART BROWSER
Causes the deck history and deck cache to be cleared
and starts a new session with the UP.Link.
1. To select Restart Browser, press .
BOOKMARKS
◆ To view your bookmark list, press or
press , then press .
This provides easy website access without entering
its URL.
INBOX
◆ Display inbox list.
To select Inbox, press or press ,
then press .
RELOAD
Reloads current page.
◆ To select Reload, press or press ,
then press .
SETTINGS
◆ Displays Browser Menu Settings.
◆ To select Settings, press or press ,
then press .
●HOMEPAGE
◆ Enables you to change the homepage.
Menu settings include:
To select Homepage, press .
BROWSER MENU
BROWSER MENU
Page 126 - Chapter 9
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 128
Your phone works as wireless modem when
connected to a PC or a Laptop computer with a data
interface cable. This chapter shows you how to choose the
correct settings for this to properly function.
Chapter 10
DATA SERVICE
Chapter 10 - Page 129
Page 128 - Chapter 9
MEMO
MEMO
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 130
Safety Information for Wireless Handheld Phones
Safety Information for FCC RF Exposure
SAR Information
FDA Consumer Update
Chapter 11
SAFETY
INFORMATION
Chapter 11 - Page 131
Page 130 - Chapter 10
DA
DAT
TA SVC
A SVC
CONNECTION
To select a connection mode based on the handset usage:
1. Press [MENU] .
2. Select one of the following connection modes:
3. Press [OK] to save.
NOTE:
This function is available only when the phone is
connected to a data cable.
● Voice Call : To receive a voice call.
● Data Only : To receive data when connected to PC.
● Fax Only : To function as a fax when connected to PC.
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 132
SAFETY INFORMATION FOR
WIRELESS HANDHELD PHONES
ANTENNA CARE
Use only the supplied or an approved replacement anten-
na. Unauthorized antennas, modifications, or attachments
could damage the phone and may violate FCC regulations.
PHONE OPERATION
Normal Position: Hold the phone as you would any other
telephone
with the antenna pointed up and over your shoul-
der.
Tips on efficient operation:
- Extend your antenna fully.
- Do not touch the antenna unnecessarily when the phone
is in use. Contact with the antenna affects call quality and
may
cause the phone to operate at a higher power level
than otherwise
needed.
DRIVING SAFETY
Talking on the phone while driving is extremely dangerous
and is illegal in some states. Remember, safety comes first.
Check the laws and regulations on the use of phones in the
areas where you drive. Always obey them.
Also, if using your phone while driving please:
- Give full attention to driving. Driving safely is your first
responsibility.
- Use hands-free operation, if available.
- Pull off the road and park before making or answering a
call, if driving conditions require.
Chapter 11 - Page 133
SAFETY INFORMATION FOR
WIRELESS HANDHELD PHONES
EXPOSURE TO RADIO FREQUENCY SIGNALS
Your wireless handheld portable telephone is a low power
radio transmitter and receiver. When it is ON, it
receives and
also sends out radio frequency (RF) signals.
In August 1996, the Federal Communications Commissions
(FCC) adopted RF exposure guidelines with safety levels for
handheld wireless phones. Those guidelines are consistent
with the safety standards
previously
set by both U.S. and inter-
national
standards bodies:
ANSI C95.1 (1992) *
NCRP Report 88 (1986) *
ICNIRP (1996) *
Those standards were based on comprehensive and peri-
odic evaluations of the relevant scientific literature.
For
example, over 120 scientists, engineers, and physicians
from
universities, government health agencies, and industry
reviewed the available body of research to develop the ANSI
Standard (C951).
The design of your phone complies with the FCC guidelines
(and those standards).
˙;
American National Standards Institute; National Council on
Radiation Protection and Measurements; International
Commission on Nonionizing Radiation Protection.
Read This Information Before Using Your Handheld
Portable Cellular Telephone
Page 132 - Chapter 11
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 134
SAFETY INFORMATION FOR
WIRELESS HANDHELD PHONES
ELECTRONIC DEVICES
Other Medical Devices
If you use any other personal medical device, consult the
manufacturer of your device to determine if they are ade-
quately shielded from external RF energy Your physician
may be able to assist you in obtaining this information.
Turn your phone OFF in healthcare facilities when any reg-
ulations posted in these areas instruct you to do so.
Hospitals or healthcare facilities may be using equipment
that could be sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or inadequately
shielded electronic systems in motor vehicles. Check with
the manufacturer or its representative regarding your vehi-
cle. You should also consult the manufacturer of any equip-
ment that has been added to your vehicle.
An airbag inflates with great force. DO NOT place objects,
including both installed or portable wireless equipment, in
the area over the airbag or in the air bag deployment area.
If in-vehicle wireless equipment is improperly installed and
the air bag inflates, serious injury could result.
Posted Facilities
Turn your phone OFF where posted notices so require.
Chapter 11 - Page 135
SAFETY INFORMATION FOR
WIRELESS HANDHELD PHONES
ELECTRONIC DEVICES
Most modern electronic equipment is shielded from RF ener-
gy. However, certain electronic equipment may not be shield-
ed against the RF signals from your wireless phone.
Pacemakers
The Health Industry Manufacturers Association recommends
that a minimum separation of six (6”) inches be maintained
between a handheld wireless phone and a pacemaker to
avoid potential interference with the pacemaker. These rec-
ommendations are consistent with the independent research
by and recommendations of Wireless Technology Research.
If you have a pacemaker:
lALWAYS keep the phone more than six inches from
your pacemaker when the phone is turned on.
lDo not carry the phone in a breast pocket.
lUse the ear opposite the pacemaker to minimize the
potential for interference.
lIf you have any reason to suspect that interference is
taking place, turn your phone OFF immediately.
Hearing Aids
Some digital wireless phones may interfere with some hear-
ing aids. In the event of such interference, you may want to
consult your service provider (or call the customer service
line to discuss alternatives).
Page 134 - Chapter 11
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 136
SAFETY INFORMATION FOR
WIRELESS HANDHELD PHONES
PRECAUTIONS AND WARNINGS
Please read and understand all of the Precautions and
Warnings contained in this manual before attempting to
operate your phone.
1. DO NOT use this equipment in an extreme environ-
ment where high temperature or high humidity exists,
such as near a heater or in a closed car parked in the
sun.
2. DO NOT abuse the equipment. Avoid striking, shaking
or shocking. When not using the unit, lay down the unit
to avoid possible damage due to instability.
3. DO NOT expose this equipment to liquids such as rain
or spilled beverages.
4. DO NOT use unauthorized accessories. Use of unau-
thorized accessories may result in fire, electric shock or
other bodily injury.
5. DO NOT disassemble the phone or its accessories. If
service or repair is required, return the unit to an author-
ized Audiovox service center. If unit is disassembled,
the risk of electric shock or fire may result.
6. DO NOT short-circuit the battery terminals with metal
items etc.
7. DO NOT use harsh chemicals, cleaning solvents or
strong detergents to clean this phone. Always clean it
with a soft, damp cloth.
8. DO NOT paint this phone. This can clog moving parts.
Chapter 11 - Page 137
SAFETY INFORMATION FOR
WIRELESS HANDHELD PHONES
OTHER SAFETY GUIDELINES
Aircraft
FCC Regulations prohibit using your phone while in the air.
Switch OFF your phone before boarding an aircraft.
Blasting Areas
To avoid interfering with blasting operations, turn your phone
OFF when in a “blasting area” or in areas posted: “Turn
off two-way
radio.” Obey all signs and instructions.
Potentially Explosive Atmospheres
Turn your phone OFF when in any area with a potentially
explosive atmosphere and obey all signs and instructions.
Sparks in such areas could cause an explosion or fire result-
ing in bodily injury or even death.
Areas with a potentially explosive atmosphere are often, but
not always, clearly marked. They include fueling areas such
as gas stations; below deck on boats; fuel or chemical trans-
fer or storage facilities; vehicles using liquefied petroleum
gas (such as propane or butane); areas where the air con-
tains chemicals or particles, such as grain, dust, or metal
powders; and any other area where you would normally be
advised to turn off your vehicle’s engine.
Page 136 - Chapter 11
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 138
CAUTION
In August 1996, the Federal Communications Commission (FCC)
of the United States with its action in Report and Order FCC 96-
326 adopted an updated safety standard for human exposure to
radio frequency electromagnetic energy emitted by FCC regulated
transmitters. Those guidelines are consistent with the safety stan-
dard previously set by both U.S. and international standards bod-
ies. The design of this phone complies with the FCC guidelines
and these international standards.
Use only the supplied or an approved antenna. Unauthorized
antennas, modifications, or attachments could impair call quality,
damage the phone, or result in violation of FCC regulations.
Do not use the phone with a damaged antenna. If a damaged
antenna comes into contact with the skin, a minor burn may result.
Please contact your local dealer for replacement antenna.
Body-worn Operation
This device was tested for typical body-worn operations with the
back of the phone kept 2.0 cm. from the body. To maintain
compliance with FCC RF exposure requirements, use only belt-clips,
holsters or similar accessories that maintain a 2.0 cm. separation
distance between the user's body and the back of the phone,
including the antenna. The use of belt-clips, holsters and similar
accessories should not contain metallic components in its assembly.
The use of accessories that do not satisfy these requirements may
not comply with FCC RF exposure requirements, and should be
avoided.
Note: For more information about RF exposure, please visit the
FCC website at www.fcc.gov.
SAFETY INFORMATION FOR
FCC RF EXPOSURE
WARNING! Read this information before using
your phone
Chapter 11 - Page 139
SAFETY INFORMATION FOR
WIRELESS HANDHELD PHONES
OPERATING PROCEDURES
Never violate any of the following Rules and Regulations
of the FCC when using your phone. The following offenses
are punishable by fine, imprisonment, or both:
- Using obscene, indecent, or profane language.
- Using the unit to give off false distress calls.
- Wiretapping or otherwise intercepting a telephone call,
unless that person has first obtained the consent of the
parties participating in the call.
- Making anonymous calls to annoy, harass, or molest
other people.
- Charging to an account without authorization to avoid
payment for service.
- Refusing to yield a party line when informed that it is
needed for an emergency call (It is also unlawful to take
over a party line by stating falsely that it is needed for an
emergency).
Page 138 - Chapter 11
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 140
SAR INFORMATION
as described in this user guide, is 0.34W/kg. (Body-worn meas-
urements differ among phone models, depending upon available
accessories and FCC requirements). While there may be differ-
ences between the SAR levels of various phones and at various
positions, they all meet the government requirement for safe expo-
sure.
The FCC has granted an Equipment Authorization for this model
phone with all reported SAR levels evaluated as in compliance with
the FCC RF exposure guidelines. SAR information on this model
phone is on file with the FCC and can be found under the Display
Grant section of http://www.fcc.gov/oet/fccid after searching on
FCC ID PP4TX-60B .
Additional information on Specific Absorption Rates (SAR) can be
found on the Cellular Telecommunications & Internet Association
(CTIA) web-site at http://phonefacts.net.
* In the United States and Canada, the SAR limit for mobile phones
used by the public is 1.6 watts/kg (W/kg) averaged over one gram
of tissue. The standard incorporates a substantial margin of safety
to give additional protection for the public and to account for any
variations in measurements.
Chapter 11 - Page 141
THIS MODEL PHONE MEETS THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver. It is
designed and manufactured not to exceed the emission limits for
exposure to radiofrequency (RF) energy set by the Federal
Communications Commission of the U.S. Government. These lim-
its are part of comprehensive guidelines and establish permitted
levels of RF energy for the general population. The guidelines are
based on standards that were developed by independent scientif-
ic organizations through periodic and thorough evaluation of sci-
entific studies. The standards include a substantial safety margin
designed to assure the safety of all persons, regardless of age and
health.
The exposure standard for wireless mobile phones employs a unit
of measurement known as the Specific Absorption Rate, or SAR.
The SAR limit set by the FCC is 1.6 W/kg.* Tests for SAR are con-
ducted with the phone transmitting at its highest certified power
level in all tested frequency bands. Although the SAR is deter-
mined at the highest certified power level, the actual SAR level of
the phone while operating can be well below the maximum value.
This is because the phone is designed to operate at multiple power
levels so as to use only the power required to reach the network.
In general, the closer you are to a wireless base station antenna,
the lower the power output.
Before a phone model is available for sale to the public, it must be
tested and certified to the FCC that it does not exceed the limit
established by the government-adopted requirement for safe
exposure. The tests are performed in positions and locations (e.g.,
at the ear and worn on the body) as required by the FCC for each
model. The highest SAR value for this model phone when tested
for use at the ear is 1.25 W/kg and when worn on the body,
SAR INFORMATION
Page 140 - Chapter 11
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 142
• Design wireless phones in a way that minimizes any RF expo
sure to the user that is not necessary for device function; and
• Cooperate in providing users of wireless phones with the best
possible information on possible effects of wireless phone use
on human health.
FDA belongs to an interagency working group of the federal agen-
cies that have responsibility for different aspects of RF safety to
ensure coordinated efforts at the federal level. The following agen-
cies belong to this working group:
• National Institute for Occupational Safety and Health
• Environmental Protection Agency
• Federal Communications Commission
• Occupational Safety and Health Administration
• National Telecommunications and Information Administration
The National Institutes of Health participates in some interagency
working group activities, as well.
FDA shares regulatory responsibilities for wireless phones with the
Federal Communications Commission (FCC). All phones that are
sold in the United States must comply with FCC safety guidelines
that limit RF exposure. FCC relies on FDA and other health agen-
cies for safety questions about wireless phones.
FCC also regulates the base stations that the wireless phone net-
works rely upon. While these base stations operate at higher
power than do the wireless phones themselves, the RF exposures
that people get from these base stations are typically thousands of
times lower than those they can get from wireless phones. Base
stations are thus not the subject of the safety questions discussed
in this document.
3. What kinds of phones are the subject of this update?
The term “wireless phone” refers here to hand-held wireless
phones with built-in antennas, often called “cell,” “mobile,” or “PCS”
phones. These types of wireless phones can expose the user to
measurable radiofrequency energy (RF) because of the short dis-
tance between the phone and the user’s head. These RF expo-
sures are limited by Federal Communications Commission safety
Chapter 11 - Page 143
U.S. Food and Drug Administration -
Center for Devices and Radiological Health
Consumer Update on Mobile Phones
1. Do wireless phones pose a health hazard?
The available scientific evidence does not show that any health
problems are associated with using wireless phones. There is no
proof, however, that wireless phones are absolutely safe. Wireless
phones emit low levels of radiofrequency energy (RF) in the
microwave range while being used. They also emit very low levels
of RF when in the stand-by mode. Whereas high levels of RF can
produce health effects (by heating tissue), exposure to low level RF
that does not produce heating effects causes no known adverse
health effects. Many studies of low level RF exposures have not
found any biological effects. Some studies have suggested that
some biological effects may occur, but such findings have not been
confirmed by additional research. In some cases, other researchers
have had difficulty in reproducing those studies, or in determining
the reasons for inconsistent results.
2. What is FDA’s role concerning the safety of wireless
phones?
Under the law, FDA does not review the safety of radiation-emitting
consumer products such as wireless phones before they can be
sold, as it does with new drugs or medical devices. However, the
agency has authority to take action if wireless phones are shown to
emit radiofrequency energy (RF) at a level that is hazardous to the
user. In such a case, FDA could require the manufacturers of wire-
less phones to notify users of the health hazard and to repair,
replace or recall the phones so that the hazard no longer exists.
Although the existing scientific data do not justify FDA regulatory
actions, FDA has urged the wireless phone industry to take a num-
ber of steps, including the following:
• Support needed research into possible biological effects of RF
of the type emitted by wireless phones;
Page 142 - Chapter 11
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 144
5. What research is needed to decide whether RF exposure
from wireless phones poses a health risk?
A combination of laboratory studies and epidemiological studies of
people actually using wireless phones would provide some of the
data that are needed. Lifetime animal exposure studies could be
completed in a few years. However, very large numbers of animals
would be needed to provide reliable proof of a cancer promoting
effect if one exists. Epidemiological studies can provide data that is
directly applicable to human populations, but 10 or more years’ fol-
low-up may be needed to provide answers about some health
effects, such as cancer. This is because the interval between the
time of exposure to a cancer-causing agent and the time tumors
develop - if they do - may be many, many years. The interpretation
of epidemiological studies is hampered by difficulties in measuring
actual RF exposure during day-to-day use of wireless phones.
Many factors affect this measurement, such as the angle at which
the phone is held, or which model of phone is used.
6. What is FDA doing to find out more about the possible
health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology Program and with
groups of investigators around the world to ensure that high priori-
ty animal studies are conducted to address important questions
about the effects of exposure to radiofrequency energy (RF).
FDA has been a leading participant in the World Health
Organization International Electromagnetic Fields (EMF) Project
since its inception in 1996. An influential result of this work has
been the development of a detailed agenda of research needs that
has driven the establishment of new research programs around
the world. The Project has also helped develop a series of public
information documents on EMF issues.
FDA and the Cellular Telecommunications & Internet Association
(CTIA) have a formal Cooperative Research and Development
Agreement (CRADA) to do research on wireless phone safety.
FDA provides the scientific oversight, obtaining input from experts
in government, industry, and academic organizations. CTIA-fund-
ed research is conducted through contracts to independent inves-
tigators.
Chapter 11 - Page 145
guidelines that were developed with the advice of FDA and other
federal health and safety agencies. When the phone is located at
greater distances from the user, the exposure to RF is drastically
lower because a person’s RF exposure decreases rapidly with
increasing distance from the source. The so-called “cordless
phones,” which have a base unit connected to the telephone wiring
in a house, typically operate at far lower power levels, and thus pro-
duce RF exposures far below the FCC safety limits.
4. What are the results of the research done already?
The research done thus far has produced conflicting results, and
many studies have suffered from flaws in their research methods.
Animal experiments investigating the effects of radiofrequency
energy (RF) exposures characteristic of wireless phones have
yielded conflicting results that often cannot be repeated in other
laboratories. A few animal studies, however, have suggested that
low levels of RF could accelerate the development of cancer in lab-
oratory animals. However, many of the studies that showed
increased tumor development used animals that had been geneti-
cally engineered or treated with cancer-causing chemicals so as to
be pre-disposed to develop cancer in the absence of RF exposure.
Other studies exposed the animals to RF for up to 22 hours per
day. These conditions are not similar to the conditions under which
people use wireless phones, so we don’t know with certainty what
the results of such studies mean for human health.
Three large epidemiology studies have been published since
December 2000. Between them, the studies investigated any pos-
sible association between the use of wireless phones and primary
brain cancer, glioma, meningioma, or acoustic neuroma, tumors of
the brain or salivary gland, leukemia, or other cancers. None of the
studies demonstrated the existence of any harmful health effects
from wireless phone RF exposures. However, none of the studies
can answer questions about long-term exposures, since the aver-
age period of phone use in these studies was around three years.
Page 144 - Chapter 11
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 146
methodology for measuring the rate at which RF is deposited in
the heads of wireless phone users. The test method uses a tissue-
simulating model of the human head. Standardized SAR test
methodology is expected to greatly improve the consistency of
measurements made at different laboratories on the same phone.
SAR is the measurement of the amount of energy absorbed in tis-
sue, either by the whole body or a small part of the body. It is meas-
ured in watts/kg (or milliwatts/g) of matter. This measurement is
used to determine whether a wireless phone complies with safety
guidelines.
9. What steps can I take to reduce my exposure to
radiofrequency energy from my wireless phone?
If there is a risk from these products—and at this point we do not
know that there is—it is probably very small. But if you are con-
cerned about avoiding even potential risks, you can take a few sim-
ple steps to minimize your exposure to radiofrequency energy
(RF). Since time is a key factor in how much exposure a person
receives, reducing the amount of time spent using a wireless
phone will reduce RF exposure.
• If you must conduct extended conversations by wireless phone
every day, you could place more distance between your body and
the source of the RF, since the exposure level drops off dramati-
cally with distance. For example, you could use a headset and
carry the wireless phone away from your body or use a wireless
phone connected to a remote antenna.
Again, the scientific data do not demonstrate that wireless phones
are harmful. But if you are concerned about the RF exposure from
these products, you can use measures like those described above
to reduce your RF exposure from wireless phone use.
10. What about children using wireless phones?
The scientific evidence does not show a danger to users of wire-
less phones, including children and teenagers. If you want to take
steps to lower exposure to radiofrequency energy (RF), the meas-
ures described above would apply to children and teenagers using
wireless phones. Reducing the time of wireless phone use and
Chapter 11 - Page 147
The initial research will include both laboratory studies and studies
of wireless phone users. The CRADA will also include a broad
assessment of additional research needs in the context of the lat-
est research developments around the world.
7. How can I find out how much radiofrequency energy
exposure I can get by using my wireless phone?
All phones sold in the United States must comply with Federal
Communications Commission (FCC) guidelines that limit radiofre-
quency energy (RF) exposures. FCC established these guidelines
in consultation with FDA and the other federal health and safety
agencies. The FCC limit for RF exposure from wireless telephones
is set at a Specific Absorption Rate (SAR) of 1.6 watts per kilogram
(1.6 W/kg). The FCC limit is consistent with the safety standards
developed by the Institute of Electrical and Electronic Engineering
(IEEE) and the National Council on Radiation Protection and
Measurement. The exposure limit takes into consideration the
body’s ability to remove heat from the tissues that absorb energy
from the wireless phone and is set well below levels known to have
effects.
Manufacturers of wireless phones must report the RF exposure
level for each model of phone to the FCC. The FCC website
(http://www.fcc.gov/oet/rfsafety) gives directions for locating the
FCC identification number on your phone so you can find your
phone’s RF exposure level in the online listing.
8. What has FDA done to measure the radiofrequency
energy coming from wireless phones ?
The Institute of Electrical and Electronic Engineers (IEEE) is devel-
oping a technical standard for measuring the radiofrequency ener-
gy (RF) exposure from wireless phones and other wireless hand-
sets with the participation and leadership of FDA scientists and
engineers. The standard, “Recommended Practice for
Determining the Spatial-Peak Specific Absorption Rate (SAR) in
the Human Body Due to Wireless Communications Devices:
Experimental Techniques,” sets forth the first consistent test
Page 146 - Chapter 11
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 148
12. Where can I find additional information?
For additional information, please refer to the following resources:
- FDA web page on wireless phones:
(http://www.fda.gov/cdrh/phones/index.html)
- Federal Communications Commission (FCC) RF Safety
Program: (http://www.fcc.gov/oet/rfsafety)
- International Commission on Non-Ionizing Radiation Protection:
(http://www.icnirp.de)
- World Health Organization (WHO) International EMF Project:
(http://www.who.int/emf)
- National Radiological Protection Board (UK):
(http://www.nrpb.org.uk/)
Chapter 11 - Page 149
increasing the distance between the user and the RF source will
reduce RF exposure. Some groups sponsored by other national
governments have advised that children be discouraged from
using wireless phones at all. For example, the government in the
United Kingdom distributed leaflets containing such a recommen-
dation in December 2000. They noted that no evidence exists that
using a wireless phone causes brain tumors or other ill effects.
Their recommendation to limit wireless phone use by children was
strictly precautionary; it was not based on scientific evidence that
any health hazard exists.
11. What about wireless phone interference with medical
equipment?
Radiofrequency energy (RF) from wireless phones can interact
with some electronic devices. For this reason, FDA helped devel-
op a detailed test method to measure electromagnetic interference
(EMI) of implanted cardiac pacemakers and defibrillators from
wireless telephones. This test method is now part of a standard
sponsored by the Association for the Advancement of Medical
instrumentation (AAMI). The final draft, a joint effort by FDA, med-
ical device manufacturers, and many other groups, was complet-
ed in late 2000. This standard will allow manufacturers to ensure
that cardiac pacemakers and defibrillators are safe from wireless
phone EMI.
FDA has tested hearing aids for interference from handheld wire-
less phones and helped develop a voluntary standard sponsored
by the Institute of Electrical and Electronic Engineers (IEEE). This
standard specifies test methods and performance requirements for
hearing aids and wireless phones so that that no interference
occurs when a person uses a “compatible” phone and a “compat-
ible” hearing aid at the same time. This standard was approved by
the IEEE in 2000.
FDA continues to monitor the use of wireless phones for possible
interactions with other medical devices. Should harmful interfer-
ence be found to occur, FDA will conduct testing to assess the
interference and work to resolve the problem.
Page 148 - Chapter 11
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 150
Protect Your Warranty
12 Month Limited Warranty
Chapter 12
WARRANTY
Chapter 12 - Page 151
Page 150 - Chapter 11
MEMO
MEMO
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 152
12 MONTH LIMITED W
12 MONTH LIMITED WARRANTY
ARRANTY
AUDIOVOX COMMUNICATIONS CORP. (the Company) war-
rants to the original retail purchaser of this Audiovox Handheld
Portable Cellular Telephone, that should this product or any
part thereof during normal consumer usage and conditions, be
proven defective in material or workmanship that results in
product failure within the first twelve (12) month period from
the date of purchase, such defect(s) will be repaired or
replaced (with new or rebuilt parts) at the Company’s option,
without charge for parts or labor directly related to the
defect(s).
The antenna, keypad, display, rechargeable battery and bat-
tery charger, if included, are similarly warranted for twelve (12)
months from date of purchase.
This Warranty extends only to consumers who purchase the
product in the United States or Canada and it is not assigna-
ble or transferable.
This Warranty does not apply to:
(a) Product subjected to abnormal use or conditions, accident,
mishandling, neglect, unauthorized alteration, misuse,
improper installation or repair or improper storage;
(b) Product whose mechanical serial number or electronic
serial number has been removed, altered or defaced.
(c) Damage from exposure to moisture, humidity, excessive
temperatures or extreme environmental conditions;
(d) Damage resulting from connection to, or use of any
accessory or other product not approved or authorized by
the Company;
Chapter 12 - Page 153
Read your Warranty carefully, with the special consider-
ation to paragraph seven of the Limited Warranty for
your unit.
“Warranty does not apply to... or to any product or part
thereof which has suffered through alteration...
mishandling, misuse, neglect or accident”.
Many companies are making look alike accessories and
in some cases, promoting that their product is equal to
or better than the Audiovox product. Be careful. Some of
these products may not be compatible to use with your
Audiovox product and may damage the unit or cause it
to malfunction. If service is required on your unit and it is
determined that a non-Audiovox accessory has created
the problem with your unit, the Warranty will not apply. In
addition, if the unit has already suffered irreversible
damage by reason of a non-compatible accessory, the
Warranty will be voided. To protect your Warranty, use
only compatible accessories which cannot damage or
interfere with the functioning of your Audiovox product.
AUDIOVOX COMMUNICATIONS CORP.
555 Wireless Blvd., Hauppauge, New York 11788, 800-229-1235
16808 Marquardt Avenue, Cerritos, California 90703, 562-802-5100
AUDIOVOX COMMUNICATIONS CANADA CO.
5155 Spectrum Way, Unit #5, Mississauga, Ontario
Canada L4W 5A1, 800-465-9672
Page 152 - Chapter 12
PROTECT YOUR W
PROTECT YOUR WARRANTY
ARRANTY
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 154
12 MONTH LIMITED W
12 MONTH LIMITED WARRANTY
ARRANTY
WITHIN A PERIOD OF 18 MONTHS FROM DATE OF ORIGI-
NAL PURCHASE. IN NO CASE SHALL THE COMPANY BE
LIABLE FOR ANY SPECIAL CONSEQUENTIAL OR INCI-
DENTAL DAMAGES FOR BREACH OF THIS OR ANY
OTHER WARRANTY, EXPRESS OR IMPLIED, WHATSOEV-
ER. THE COMPANY SHALL NOT BE LIABLE FOR THE
DELAY IN RENDERING SERVICE UNDER THIS WARRANTY
OR LOSS OF USE DURING THE TIME THE PRODUCT IS
BEING REPAIRED OR REPLACED.
No person or representative is authorized to assume for the
Company any liability other than expressed herein in connec-
tion with the sale of this product.
Some states or provinces do not allow limitations on how long
an implied warranty lasts or the exclusion or limitation of inci-
dental or consequential damage, so the above limitation or
exclusions may not apply to you. This Warranty gives you spe-
cific legal rights, and you may also have other rights which vary
from state to state or province to province.
IN U.S.A.: Audiovox Communications Corp.
555 Wireless Blvd.
Hauppauge, NY 11788
(800) 229-1235
IN CANADA: Audiovox Communications Canada Co.
5155 Spectrum Way, Unit #5
Mississauga, Ontario L4W 5A1
(800) 465-9672
Chapter 12 - Page 155
12 MONTH LIMITED W
12 MONTH LIMITED WARRANTY
ARRANTY
(e) Defects in appearance, cosmetic, decorative or structural
items such as framing and non-operative parts;
(f) Product damaged from external causes such as fire,
flooding, dirt, sand, weather conditions, battery leakage,
blown fuse, theft or improper usage of any electrical source.
The Company disclaims liability for removal or reinstallation of
the product, for geographic coverage, for inadequate signal
reception by the antenna or for communications range or oper-
ation of the Cellular System as a whole.
To obtain repairs or replacement within the terms of this
Warranty, the product should be delivered with proof of
Warranty coverage (e.g. dated bill of sale), the consumer’s
return address, daytime phone number and/or fax number and
complete description of the problem, transportation prepaid, to
the Company at the address shown below or to the place or
purchase for repair or replacement processing. In addition, for
reference to an authorized Warranty station in your area, you
can telephone in the United States (800) 229-1235, and in
Canada (800) 465-9672 (in Ontario call 905-712-9299).
THE EXTENT OF THE COMPANY’S LIABILITY UNDER THIS
WARRANTY IS LIMITED TO THE REPAIR OR REPLACE-
MENT PROVIDED ABOVE AND, IN NO EVENT, SHALL THE
COMPANY’S LIABILITY EXCEED THE PURCHASE PRICE
PAID BY PURCHASER FOR THE PRODUCT.
ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE SHALL BE LIMITED TO THE
DURATION OF THIS WRITTEN WARRANTY. ANY ACTION
FOR BREACH OF ANY WARRANTY MUST BE BROUGHT
Page 154 - Chapter 12
TX-60P(verizon)1213-CDM-8450PTT 2003.12.13 9:38 AM Page 156
