playback
50
USING AN
iPod
You can enjoy playback of your iPod using the supplied remote control.
Listening to Music (A IPOD function)
You can play music files stored in the iPod player by connecting it to the home
theater system.
Connect the iPod dock connector to the iPod jack on the DVD home 1.
theater.
Place the iPod in the Dock.2.
Your iPod is automatically turned on.•
Press the 3. PORT button on the remote control to select OSD IPOD mode.
If the iPod player is connected to the home theater system, each time •
you press the the PORT button, it will be toggled in the order of
USB
OSD IPOD V/P IPOD
.
Press the 4. , buttons on the remote control to select Music and press
the ENTER button.
The • Music categories appear.
Press the 5. , buttons desired category and press the ENTER button.
The music files appear.•
Press the 6. , buttons to select the file to play and press the ENTER
button.
The music will start with a new screen which shows the song title, •
time, artist, and progress bar.
You can use the remote control or main unit to control simple 7.
playback functions such as PLAY, PAUSE, STOP, /,
/ and REPEAT.
Press the • RETURN button to return to the previous menu.
M
See page 31 for compatible iPods. `
Compatibility depends on the software version of your iPod.
This product only supports playing audio from your iPod.
Music categories
File information including the artist name, album name, music title and genre will be displayed according
to the ID3 Tag information on the appropriate music file.
Now Playing : Plays a recently played file or moves to the playback screen of the current file.
Artists : To play by artist.
Songs : To play in numeric or alphabetical order
Playlists : To play by Playlist.
Albums : To play by album.
Genres : To play by genre.
Composer : To play by composer.
M
The category list may differ, depending on the iPod model. `
What is an ID3 Tag? `
This is what is attached to an MP3 to carry information relevant to the file such as
the title, artist, album, year, genre and a comment field.
51
ENG ● PLAYBACK
Watching a Movie (V/P IPOD function)
You can play video files stored in the iPod player by connecting it to the home theater system.
Connect the iPod dock connector to the iPod jack on the DVD home 1.
theater.
In the iPod screen, move to 2. Videos > Settings and set the TV Out
option to On.
Place the iPod in the Dock. 3.
Press the 4. PORT button on the remote control to select V/P IPOD mode.
If the iPod player is connected to the home theater system, each •
time you press the the PORT button, it will be toggled in the order
of
USB OSD IPOD V/P IPOD.
Set the AV IN option of the TV connected to the home theater system 5.
to COMPOSITE.
Follow the iPod onscreen guide through the following steps.
Press the 6. , buttons on the remote control to select Videos and
press the ENTER button.
Press the 7. , buttons on the remote control to select Movies and press
the ENTER button.
Press the 8. , buttons to select the file to play and press the ENTER
button.
Video files of the iPod player will be played on the TV screen. •
You can use the remote control or main unit to control simple 9.
playback functions such as PLAY, PAUSE, STOP, / and
/.
If you press the • PREV button within 3 seconds after the playback,
the player will stop playing and return to the list screen.
If you press the PREV button 3 seconds or later after the playback,
the player will move to the start screen of the current file.
Press the • NEXT button to stop playing and return to the list
screen.
Press the • RETURN button to return to the previous menu.
M
See page 28 for compatible iPods. `
Compatibility depends on the software version of your iPod.
This product only supports playing audio from your iPod.
When the current file is played to the end, the next file will not be played automatically. `
To play the next file, select a file to play in the list screen of the iPod player.
No other screen than the playback one will appear on the TV screen. Check other screens on `
the iPod player.
J If the TV connected to the home theater system supports HDMI CEC, press the `AUX button on
the remote control to switch the mode to DIGITAL IN if you want to watch TV while an iPod
movie is played.
<iPod Screen>
<iPod Screen>
playback
52
PLAYING MEDIA FILES USING THE USB HOST FEATURE
You can enjoy media files such as pictures, movies and music saved on an MP3 player, USB memory stick or digital
camera in high quality video with 5.1 channel Home Theater sound by connecting the storage device to the USB port of
the Home Theater.
Connect the USB device to the USB port on the front 1.
of the unit.
Press the 2. FUNCTION button on the DVD Player or the
PORT button on the remote control to select the USB
mode.
USB• appears on the display screen and then
disappears.
The USB MENU screen appears on the TV screen •
and the saved file is played.
To stop playback, press the 3. STOP (T) button.
To prevent damage to the memory stored in the USB device,
perform safe removal before disconnecting the USB cable.
Press the • STOP (T) button twice in a row.
The display will show REMOVE USB.
Remove the USB cable.•
M
To listen to your music files with 5.1 channel home theater sound, you must set the Dolby `
Pro Logic II mode to Matrix. (See page 63)
In USB mode, you are not able to change the resolution or use the SETUP menu if there is no `
USB device connected to the USB port.
Skip Forward/Back
During playback, press the [,] button.
When there is more than one file and you press the • ]
button, the next file is selected.
When there is more than one file and you press the • [
button, the previous file is selected.
VOLUME
VOLUME
DISC CHANGE
PHONES FUNCTION
AUX IN 1/
ASC IN
Safe USB Removal
53
ENG ● PLAYBACK
Fast playback
During playback, press the (,) button.
Each time you press either button, the playback speed •
will change as follows:
2x ➞ 4x ➞ 8x ➞ 32x ➞ Normal.
Compatible Devices
USB devices that support USB Mass Storage v1.0. (USB devices that operate as a removable disc 1.
in Windows (2000 or later) without additional driver installation.)
MP3 Player: HDD and flash type MP3 players.2.
Digital camera: Cameras that support USB Mass Storage v1.0.3.
Cameras that operate as a removable disc in Windows (2000 or later) without additional driver installation.•
USB HDD and USB Flash Drive: Devices that support USB2.0 or USB1.1.4.
You may experience a difference in playback quality when you connect a USB1.1 device.•
For a USB HDD, make sure to connect an auxiliary power cord to the USB HDD for proper operation.•
5. USB card Reader: One slot USB card reader and Multi slot USB card reader.
Depending on the manufacturer. the USB card reader may not be supported.•
If you install multiple memory devices into a multi card reader, you may experience problems.•
6. If you use a USB extension cable, the USB device might not be recognized.
Supported Formats
Format File name File
extension Bit rate Version Pixel
Sampling
Frequency
Still Picture JPG JPG .JPEG – – 640x480 –
Music
MP3 .MP3 80~384kbps – – 44.1kHz
WMA .WMA 56~128kbps V8 –44.1kHz
Movie
WMV .WMV 4Mbps V1,V2,V3,V7 720x480
44.1KHz~48KHz
DivX
.AVI,.ASF 4Mbps DivX3.11~
DivX5.1, XviD 720x480
44.1KHz~48KHz
CBI (Control/Bulk/Interrupt) is not supported.•
Digital Cameras that use PTP protocol or require additional program installation when connected to a •
PC are not supported.
A device using NTFS file system is not supported. (The system supports only the FAT file system and •
will not play a movie larger than 1 GB in USB mode.)
Some MP3 players, when connected to this product, may not operate depending on the sector size of •
their file system.
The USB host function is not supported if a product that transfers media files by its manufacturer- •
specific program is connected.
Does not operate with Janus enabled MTP (Media Transfer Protocol) devices.•
The USB host function of this product does not support all USB devices. For information on •
supported devices, see page 73.
CD RIPPING
S.VOL
AUDIO
UPSCALE
54
SETTING THE LANGUAGE
OSD(On-Screen Display) language is set to English by default.
In Stop mode, press the 1. MENU button.
Press the Cursor 2.
%
button to move to Setup and then press the
ENTER button.
Select 3. Language and then press the ENTER button.
Press the Cursor 4.
$
,
%
button to select OSD Language and then
press the ENTER button.
Press the Cursor 5.
$
,
%
button to select the desired language
and then press the ENTER button.
Once the setup is complete, the OSD will be English if •
English has been selected as language.
d Press the RETURN button to return to the previous level.
d Press the EXIT button to exit the setup screen.
OSD LANGUAGE• : Selecting the OSD Language
AUDIO• : Selecting the Audio Language (recorded on the disc)
• SUBTITLE : Selecting the Subtitle Language (recorded on the disc)
DISC MENU• : Selecting the Disc Menu Language (recorded on the disc)
a If the language you selected is not recorded on the disc, menu
language will not change even if you set it to your desired language.
OTHERS• : To select another language, select OTHERS and
enter the language code of your country
(see page 72).
AUDIO, SUBTITLE and DISC MENU languages can be
selected
.
SETTING THE HDMI VIDEO OUT MODE
You can select <RGB> or <Y Cb Cr> mode.
In Stop mode, press the 1. MENU button.
Press the Cursor 2.
%
button to move to Setup and then press the
ENTER button.
Press the Cursor 3.
%
button to move to HDMI VIDEO OUT and then
press the ENTER button.
Press the Cursor 4.
$
,
%
button to select the desired item
and then press the ENTER button.
Once the setup is complete, you will be taken to the •
previous screen.
d Press the RETURN button to return to the previous level.
d Press the EXIT button to exit the setup screen.
system setup
For your convenience, you can set this DVD Home Cinema's features for the best use in your home
environment.
MOVE ENTER
EXITRETURN
MOVE ENTER EXITRETURN
MOVE ENTER EXITRETURN
MOVE SELECT EXIT
RETURN
MOVE ENTER
EXITRETURN
55
ENG ● SYSTEM SETUP
SETTING TV SCREEN TYPE
Depending on your TV type (Widescreen or conventional 4:3), you can select the TV's aspect ratio.
In Stop mode, press the 1. MENU button.
Press the Cursor 2.
%
button to move to Setup and then press the
ENTER button.
Press the Cursor 3.
%
button to move to TV DISPLAY and then
press the ENTER button.
Press the Cursor 4.
$
,
%
button to select the desired item
and then press the ENTER button.
Once the setup is complete, you will be taken to the •
previous screen.
d Press the RETURN button to return to the previous level.
d Press the EXIT button to exit the setup screen.
Adjusting the TV Aspect Ratio (Screen Size)
The horizontal to vertical screen size ratio of conventional TVs is 4:3, while that of widescreen and high
definition TVs is 16:9. This ratio is called the aspect ratio. When playing DVDs recorded in different
screen sizes, you should adjust the aspect ratio to fit your TV or monitor.
For a standard TV, select either 4:3PS or 4:3LB option according to personal preference.
Select WIDE/HDTV if you have a widescreen TV.
4:3PS (4:3 Pan&Scan)
Select this to play a 16:9 picture in the pan & scan mode on a conventional
T V.
You can see the central portion of the screen only (with the sides of the •
16:9 picture cut off).
4:3LB (4:3 Letterbox)
Select this to play a 16:9 picture in the letter box mode on a conventional
T V.
Black bars will appear at the top and bottom of the screen.•
WIDE/HDTV
Select this to view a 16:9 picture in the full-screen mode on your
widescreen TV.
You can enjoy the widescreen aspect.•
M
If a DVD is in the 4:3 ratio, you cannot view it in widescreen. `
Since DVD discs are recorded in various image formats, they will look different depending `
on the software, the type of TV, and the TV aspect ratio setting.
When using HDMI, the screen is automatically converted to Wide mode. `
MOVE ENTER EXITRETURN
MOVE SELECT EXIT
RETURN
56
system setup
SETTING PARENTAL CONTROLS (RATING LEVEL)
Use this to restrict playback of adult or violent DVDs you do not want children to view.
In Stop mode, press the 1. MENU button.
Press the Cursor 2.
%
button to move to Setup and then press the
ENTER button.
Press the Cursor 3.
%
button to move to PARENTAL and then press the
ENTER button.
Press the Cursor 4.
$
,
%
button to select the desired rating level and then
press the ENTER button.
If you have selected Level 6, you cannot view DVDs with Level 7 or •
higher.
The higher the level, the closer the content is to violent or adult •
material.
5. Enter the password and then press the ENTER button.
The password is set to "7890" by default.•
Once the setup is complete, you will be taken to the previous screen. •
d Press the RETURN button to return to the previous level.
d
Press the EXIT button to exit the setup screen.
M
This function works only if a DVD disc contains the rating level information. `
SETTING THE PASSWORD
You can set the password for the Parental (rating level) setting.
In Stop mode, press the 1. MENU button.
Press the Cursor 2.
%
button to move to Setup and then press the
ENTER button.
Press the Cursor 3.
%
button to move to PASSWORD and then
press the ENTER button.
Press the 4. ENTER button.
Enter the password and then press the 5. ENTER button.
Enter the old password, a new password, and confirm new •
password.
The setting is complete. •
M
The password is set to "7890" by default. `
If you have forgotten the rating level password, do the following
While the player is in No DIsc mode, hold the DVD Players • STOP (T) button for longer than
5 seconds. INITIAL appears on the display and all settings will return to the default values.
Press the • POWER button.
Using the RESET function will erase all stored settings.
Do not use this unless necessary.
MOVE ENTER EXITRETURN
MOVE SELECT EXITRETURN
MOVE SELECT EXITRETURN
MOVE ENTER EXIT
RETURN
57
ENG ● SYSTEM SETUP
SETTING THE WALLPAPER
dG
While watching a DVD or JPEG CD, you can set the image you like as background wallpaper.
During playback, press the 1. PAUSE button when
an image you like appears.
Press the 2. LOGO button.
COPY LOGO DATA• will be displayed on the TV screen.
The power will turn off and then back on.3.
The selected wallpaper will be displayed. •
You can select up to 3 wallpaper settings. •
M
This function will not work when the HDMI output is 720p, 1080i or 1080p. `
TO SELECT ONE OF THE 3 WALLPAPER SETTINGS YOU'VE MADE
In Stop mode, press the 1. MENU button.
Press the Cursor 2.
%
button to move to Setup and then
press the ENTER button.
Press the Cursor 3.
%
button to move to LOGO and then
press the ENTER button.
Press the Cursor 4.
$
,
%
button to select the desired USER,
and then press the ENTER button.
This selects one of the 3 wallpaper screens.•
5. Press the EXIT button to exit the setup screen.
ORIGINAL • : Select this to set the Samsung Logo image as
your wallpaper.
USER • : Select this to set the desired image as your
wallpaper.
d Press the RETURN button to return to the previous level.
d Press the EXIT button to exit the setup screen.
COPY LOGO DATA
MOVE ENTER EXITRETURN
MOVE SELECT EXIT
RETURN
58
system setup
DviX (R) Registration
Please use the Registration code to register this player with the DivX (R) video on demand format.
To learn more, go to www.divx.com/vod.
SETTING THE SPEAKER MODE
Signal outputs and frequency responses from the speakers will
automatically be adjusted according to your speaker configuration
and whether certain speakers are used or not.
In Stop mode, press the 1. MENU button.
Press the Cursor 2.
%
button to move to Audio and then press the
ENTER button.
In the 3. SPEAKER SETUP, press the ENTER button again.
Press the Cursor 4. ,,, button to move to the desired
speaker and then press the ENTER button.
For C, SL, and SR, each time the button is pressed, the mode switches •
alternately as follows : SMALL
➞
NONE.
For L and R, the mode is set to SMALL.•
SMALL • : Select this when using the speakers.
NONE • : Select this when no speaker is connected.
d Press the RETURN button to return to the previous level.
d Press the EXIT button to exit the setup screen.
M
Depending on PRO LOGIC and STEREO settings, the speaker mode may vary (see page 63). `
MOVE ENTER EXITRETURN
MOVE CHANGE EXIT
RETURN
59
ENG ● SYSTEM SETUP
SETTING THE DELAY TIME
If the speakers cannot be placed at equal distances from the listening position, you can adjust the delay
time of the audio signals from the center and rear speakers.
In Stop mode, press the 1. MENU button.
Press the Cursor 2.
%
button to move to Audio and then press the ENTER button.
Press the Cursor 3.
%
button to move to DELAY TIME and then press the ENTER button.
Press the Cursor 4. ,,, button to move to the desired speaker and then press the ENTER button.
5. Press the Cursor , to set the Delay time.
You can set the delay time for C between 00 and 05mSEC and for SL and SR between 00 and 15mSEC.•
d Press the RETURN button to return to the previous level.
d Press the EXIT button to exit the setup screen.
When 5.1CH Surround Sound is played, you can enjoy the best sound if the distance between you and each
speaker is the same.
Since the sounds arrive at the listening position at different times depending on the placement of speakers, you can
adjust this difference by adding a delay effect to the sound of the Center and Rear Speakers.
Setting CENTER SPEAKER
If the distance of Dc is equal to or longer than the
distance of Df in the figure, set the mode as 0ms.
Otherwise, change the setting according to the table.
Distance
between
Df and Dc
0.00 inch 1 feet,
1.39 inches
2 feet,
2.77 inches
3 feet,
5.73 inches
4 feet,
7.12 inches
5 feet,
9.29 inches
Delay Time
0 ms 1 ms 2 ms 3 ms 4 ms 5 ms
Setting REAR SPEAKER
If the distance of Dc is equal to or longer than the distance of Dr
in the figure, set the mode as 0ms.
Otherwise, change the setting according to the table.
Distance
between
Df and Dc
0.00 inch 3 feet,
5.73 inches
6 feet,
11.7 inches
10 feet,
4.80 inches
13 feet,
10.54 inches
17 feet,
4.27 inches
Delay Time
0 ms 3 ms 6 ms 9 ms 12 ms 15 ms
M With ` PL II (Dolby Pro Logic II), the delay time may be different for each mode.
With AC-3 and DTS, the delay time can be set between 00 and 15mSEC. `
The Center channel is only adjustable on 5.1 channel discs. `
Ideal CENTER SPEAKER
placement
Df: The distance from FRONT SPEAKER
Dc: The distance from CENTER SPEAKER
Dr: The distance from REAR SPEAKER
It is desirable to place all speakers within this circle.
Ideal
REAR
SPEAKER
placement
Setting up the Speaker Delay Time
60
system setup
SETTING THE TEST TONE
Use the Test Tone feature to check the speaker connections.
In Stop mode, press the 1. MENU button.
Press the Cursor 2.
%
button to move to Audio and then press the
ENTER button.
Press the Cursor 3.
%
button to move to TEST TONE and then press
the ENTER button.
The test tone will be sent to • L ➞ C ➞ R ➞ SR ➞ SL ➞ SW in
order.
If the ENTER button is pressed again at this time, the test tone
will stop.
d Press the RETURN button to return to the previous level.
d Press the EXIT button to exit the setup screen.
SETTING THE AUDIO
You can adjust the balance and level for each speaker.
In Stop mode, press the 1. MENU button.
Press the Cursor 2.
%
button to move to Audio and then press the
ENTER button.
Press the Cursor 3.
%
button to move to SOUND EDIT and then
press the ENTER button.
Press the Cursor 4.
,
button to select and adjust the desired item.
Press the Cursor
,
button to adjust the settings.
d Press the RETURN button to return to the previous level.
d Press the EXIT button to exit the setup screen.
MOVE ENTER EXITRETURN
STOP EXIT
MOVE ENTER EXITRETURN
MOVE CHANGE EXIT
RETURN
61
ENG ● SYSTEM SETUP
SETTING THE AUDIO
Press the SOUND EDIT button and then press the Cursor
,
button.
Adjusting Front/Rear Speaker Balance
You can select between 00, -06, and OFF. `
The volume decreases as you move closer to –6. `
Adjusting Center/Rear/Subwoofer Speaker Level
The volume level can be adjusted in steps from +6dB to –6dB. `
The sound gets louder as you move closer to +6dB and quieter as you get closer to -6dB. `
SETTING THE DRC (DYNAMIC RANGE COMPRESSION)
This feature balances the range between the loudest and quietest sounds. You can use this function to enjoy Dolby
Digital sound when watching movies at low volume at night.
In Stop mode, press the 1. MENU button.
Press the Cursor 2.
%
button to move to Audio and then press the
ENTER button.
Press the Cursor 3.
%
button to move to DRC and then press the
ENTER button.
Press the Cursor 4.
,
to adjust the DRC.
When the Cursor •
button is pressed, the effect is greater, and
when the Cursor
button is pressed, the effect is smaller.
d Press the RETURN button to return to the previous level.
d Press the EXIT button to exit the setup screen.
Manually Adjusting the Speaker Volume and Balance with the SOUND EDIT Button.
RETURNMOVE ENTER EXIT
CHANGE EXIT
RETURN
S.VOL
AUDIO
UPSCALE
S.VOL
AUDIO
UPSCALE
62
system setup
SETTING THE AV SYNC
Video may look slower than the audio if it is connected to a digital TV. If this occurs, adjust the audio delay time to
match the video.
In Stop mode, press the 1. MENU button.
Press the Cursor 2.
%
button to move to Audio and then press the
ENTER button.
Press the Cursor 3.
%
button to move to AV-SYNC and then press
the ENTER button.
Press the Cursor 4.
,
button to select the AV-SYNC Delay Time
and then press the ENTER button.
You can set the audio delay time between 0 ms and 300 ms. Set •
it to the optimal status.
d Press the RETURN button to return to the previous level.
d Press the EXIT button to exit the setup screen.
SETTING THE HDMI AUDIO
The audio signals transmitted over the HDMI Cable can be toggled ON/OFF.
In Stop mode, press the 1. MENU button.
Press the Cursor 2.
button to move to Audio and then press the
ENTER button.
Press the Cursor 3.
button to move to HDMI AUDIO and then
press the ENTER button.
Press the Cursor 4.
,
button to select ON or OFF and then press
the ENTER button.
• ON : Both video and audio signals are transmitted over the HDMI
connection cable, and audio is output through your
TV speakers only.
• OFF : Video is transmitted over the HDMI connection cable only,
and audio is output through the home theater speakers only.
d
Press the RETURN button to return to the previous level.
d
Press the EXIT button to exit the setup screen.
M
The default setting of this function is HDMI AUDIO OFF. `
HDMI AUDIO is automatically down-mixed to 2ch for TV speakers. `
MOVE ENTER EXITRETURN
MOVE SELECT EXIT
RETURN
MOVE ENTER EXITRETURN
MOVE SELECT EXIT
RETURN
63
ENG ● SYSTEM SETUP
SOUND FIELD (DSP)/EQ FUNCTION
DSP(Digital Signal Processor) : DSP modes have been designed to simulate different acoustic environments.
EQ :
You can select ROCK, POP, or CLASSIC to optimize the sound for the genre of music you are playing
Press the DSP/EQ button.
DSP• appears on the display panel.
Each time the button is pressed, the selection changes as follows:
POPS ➞ JAZZ ➞ ROCK ➞ STUDIO ➞ CLUB ➞ HALL ➞ MOVIE ➞ CHURCH ➞ PASS ➞ POPS
POP, JAZZ, ROCK • : Depending on the genre of music, you can select POP, JAZZ, and ROCK.
STUDIO • : Provides a sense of presence as if in a studio.
CLUB • : Simulates the sound of a dance club with a throbbing
bass beat.
HALL • : Provides a clear vocal as if listening in a concert hall.
MOVIE • : Provides the feeling of a movie theater.
CHURCH • : Gives the feel of being in a grand church.
PASS • : Select this for normal listening.
M
The DSP/EQ function is only available in STEREO mode. `
Press the PL II mode button to show STEREO on the display.
This feature works with CDs, MP3-CDs, 2 channel DVD-Audio, DivX, tuner and Dolby Digital discs. `
When playing a DVD disc encoded with two or more channels, multi-channel mode will be `
selected automatically and DSP/EQ function does not work.
DOLBY PRO LOGIC II MODE
You can select the desired Dolby Pro Logic II audio mode.
Press the PL II MODE button.
Each time the button is pressed, the mode changes as follows.•
MUSIC ➞ CINEMA ➞ PROLOG ➞ MATRIX ➞
STEREO ➞ MUSIC
PRO LOGIC II
MUSIC • : When listening to music, you can experience
sound effects as if you are listening to the actual
performance.
CINEMA• : Adds realism to the movie soundtrack.
PRO LOGIC• : You will experience a realistic multi-channel effect, as if using five speakers, while using
just the front left and right speakers.
MATRIX • : You will hear 5.1 channel surround sound.
STEREO • : Select this to listen to sound from the front left and right speakers and the subwoofer only.
M
When selecting Pro Logic II mode, connect your external device to the AUDIO INPUT jacks `
(L and R) on the player. If you connect to only one of the inputs (L or R), you cannot listen
to surround sound.
CD RIPPING
S.VOL
AUDIO
UPSCALE
CD RIPPING
S.VOL
AUDIO
UPSCALE
CD RIPPING
S.VOL
AUDIO
UPSCALE
CD RIPPING
S.VOL
AUDIO
UPSCALE
64
system setup
CD RIPPING
S.VOL
AUDIO
UPSCALE
CD RIPPING
DOLBY PRO LOGIC II EFFECT
This function works only in Dolby Pro Logic MUSIC mode.
Press the 1. PL II MODE button to select MUSIC mode.
Press the 2. PL II EFFECT button.
Press the 3.
,
buttons to select the desired effect setting.
PANORAMA : You can select either 0 or 1.•
C- WIDTH : You can select between 0 and 7.•
DIMENS : You can select between 0 and 6.•
ASC (Auto Sound Calibration) SETUP
By setting the ASC function just once when you relocate or install the unit, you can have the unit
automatically recognize the distance between speakers, levels between channels, and frequency
characteristics to create a 5.1-channel sound field optimized for your environment.
M
ASC SETUP can be made when there is no disc in the unit, or it is in Stop mode with a `
DVD/CD inserted.
Because the volume level of the tone is fixed during the ASC setup, you cannot adjust the
`
volume using the volume control buttons.
If the auto sound microphone is disconnected during the ASC setup, the setup will be
`
cancelled.
When ASC function is activated, the DSP/EQ, DOLBY PRO LOGIC ll, and P. BASS sound
`
effects will not work.
To Verify the ASC
Briefly press ASC button.
Distance and level values specified for each channel will appear in the display.•
L: FR O N T SP E A k E R (L)
R: FR O N T SP E A k E R (R)
C: CE N T E R SP E A k E R
SW: SU B W O O F E R
SL: RE A R SP E A k E R (L)
SR: RE A R SP E A k E R (R)
PHONES FUNCTION
AUX IN 1/
ASC IN
ASC
Microphone
65
ENG ● SYSTEM SETUP
ASC (Auto Sound Calibration) SETUP
Plug the ASC microphone into the ASC input jack.1.
Place the ASC microphone at the listening position.2.
Press 3. ASC button.
To create the optimal 5.1 channel sound field, the •
selections are in the following sequence:
L ➞ C ➞ R ➞ SR ➞ SL ➞ SW
When the message "REMOVE MIC" appears in the display, 4.
unplug the ASC microphone.
M
Setting the ASC function takes about 3 minutes. `
To cancel the ASC (Auto Sound Calibration) setup, press ASC
button.
The tone output stops, "CANCEL ASC" appears in the display followed by "REMOVE MIC", and the
setup is cancelled.
To listen in the ASC (Auto Sound Calibration) mode, briefly press
ASC button.
The selection alternates between ASC ON and ASC OFF in the display.
If you select "ASC ON", you will hear sound in the ASC mode.
If you select "ASC OFF", you will hear sound in the mode set in the audio setting of the setup screen.
CD RIPPING
S.VOL
AUDIO
UPSCALE
CD RIPPING
S.VOL
AUDIO
UPSCALE
66
LISTENING TO RADIO
Remote Control
Press the1. TUNER button to select the FM band.
Tune in to the desired station.2.
Automatic Tuning 1• : When the [,] button is
pressed, a preset broadcast station is selected.
Automatic Tuning 2• : Press and hold the ,,.
button to automatically search for active
broadcasting stations.
Manual Tuning• : Briefly press the ,,. button to
increase or decrease the frequency incrementally.
Main Unit
Press the 1. FUNCTION button to select the FM band.
Select a broadcast station2.
.
Automatic Tuning 1• : Press the STOP (T) button to select PRESET and then press the [,]
button to select the preset station.
Automatic Tuning 2• : Press the STOP (T) button to select MANUAL and then press and hold
the [,] button to automatically search the band.
Manual Tuning• : Press the STOP (T) button to select MANUAL and then briefly press
the button to tune in to a lower or higher frequency.
Press the MO/ST button to listen in Mono/Stereo.
•
Each time the button is pressed, the sound switches between STEREO and MONO.
•
In a poor reception area, select MONO for a clear, interference-free broadcast.
PRESETTING STATIONS
Example : Presetting FM 89.10 in the memory
Press the 1. TUNER button to select the FM band.
Press the 2.
,,.
button to select 89.10.
Press the 3. TUNER MEMORY button.
Press the 4.
[,]
button to select preset number.
You can select between 1 and 15 presets.•
5. Press the TUNER MEMORY button again.
6. To preset another station, repeat steps 2 to 5.
To tune in to a preset station, press the •
[,]
button on the remote control to select a channel.
radio
CD RIPPING
S.VOL
AUDIO
UPSCALE
S.VOL
AUDIO
UPSCALE
CD RIPPING
67
ENG
SLEEP TIMER FUNCTION
You can set the time that the Home Theater will shut itself off.
Press the SLEEP button.
SLEEP• will be displayed. Each time the button is pressed, the
preset time changes as follows :
SLP10 ➞ SLP20 ➞ SLP30 ➞ SLP60 ➞ SLP90 ➞ SLP120 ➞
SLP150 ➞ OFF.
To confirm the sleep timer setting, press the SLEEP button.
The remaining time before the Home Theater will shut itself off is •
displayed.
Pressing the button again changes the sleep time from what you have set earlier. •
To cancel the sleep timer, press the SLEEP button until OFF appears on the display.
ADJUSTING DISPLAY BRIGHTNESS
You can adjust the brightness of the display on the main unit so it won't
interfere with your movie viewing.
Press the DIMMER button.
Each time the button is pressed, the brightness of front display will •
be adjusted.
MUTE FUNCTION
This is useful when answering a doorbell or telephone call.
Press the MUTE button.
MUTE• appears in the display.
To restore the sound, press the • MUTE button again.
convenient function
CD RIPPING
S.VOL
AUDIO
UPSCALE
CD RIPPING
S.VOL
AUDIO
UPSCALE
CD RIPPING
S.VOL
AUDIO
UPSCALE
CD RIPPING
S.VOL
AUDIO
UPSCALE
CD RIPPING
S.VOL
AUDIO
UPSCALE
● CONVENIENT FUNCTION
68
S.VOL (SMART VOLUME)
This will regulate and stabilize the volume level against a drastic
volume change when changing channels or during a scene transition.
Press the S.VOL button.
Each time the button is pressed, the selection changes as •
follows :
SV ON SV OFF
P.BASS/AUDIO UPSCALING
P.BASS
P.BASS function stresses low tones providing thudding
sound effects.
Press the P.BASS/AUDIO UPSCALE button to select P.BASS
mode.
Each time the button is pressed, the selection changes as follows •
:
POWER BASS ON UPS ON OFF
AUDIO UPSCALING
This also helps enhance your sound experience (ex. mp3 music).
You can upscale your MP3 level sound(24 kHz, 8bit) to CD level sound(44.1 kHz, 16bit).
Press the P.BASS/AUDIO UPSCALE button to select AUDIO UPSCALE mode.
Each time the button is pressed, the selection changes as follows :•
UPS ON OFF
M
The P.BASS function is only available with 2 channel LPCM sources such as mp3,Divx,cd `
and wma.
Press P.BASS button and "POWER BASS ON" will be displayed on the screen.
The P.bass does not work with DSP/EQ or DOLBY PRO LOGIC ll modes.
`
If you press P.BASS in the DSP/EQ mode, the DSP/EQ mode is automatically shut off and
the P. BASS function comes on.
CD RIPPING
S.VOL
CD RIPPING
S.VOL
CD RIPPING
S.VOL
CD RIPPING
S.VOL
69
ENG ● TROUBLESHOOTING
You can rip a compact disc as a MP3 file on the USB
This feature enables you to ripping with the start of the disc or track of your choice.
Don’t disconnected USB and AC Cord during CD-Ripping.This may cause the file
damage.If you want to stop CD-Ripping during CD-Ripping,you must press stop Key first
and after the CD Stopped,then you can remove the USB device.
If you disconnected USB device when CD Ripping,the main unit will be power off and you
may not delete the ripped file,In this case, please connect the USB on the PC and
backup the USB data on the PC first and then formate the USB device .
On the CD playing ,connect the USB,the CD play will be paused and will resume
playing till the USB initilization finished.
According the different USB the initilization time maybe different.
When the USB memory is not enough,it will be displayed “NOT ENOUGH MEMORY”
DTS-CD can’t for CD Ripping.
Starting CD ripping within 5 seconds can’t create the CD Ripping file.
Ripping file is only created when CD Ripping is stopped afters 5 seconds
(ex. SAM-0001.MP3).
With external HDD,FAT format the USB can be CD Ripping,but not NTFS.The CD
Ripping function of this product does not support all USB devices.
When you use CD high speed search function,the CD Ripping can’t work.
When CD Ripping, CD audio can’t be out.
During CD Ripping,do not deal impact.If is shocked while CD Ripping,CD Ripping maybe
disengage.
Sometimes, some of USB devices, CD Ripping time is long.
If you use scratched disc for CD Ripping, or connect/disconnect HDMI cable
during CD Ripping, there might be some noise and broken sound on ripped file.
When HDMI audio on, the CD RIPPING can’t work.
2
13
Connect the USB.
Switch the system on by
pressing STANDBY/ON. Load a compact
disc(Digital Audio).
4
Press CD RIPPING button
on remote control to
starting ripping.
Press the OPEN/CLOSE button to open the
disc tray.
Insert a CD and press the OPEN/CLOSE
button to close the disc tray.
Use the CD selection ( ) buttons to
select the desired song.
If the system is either at pause or playing state,turn
the CD RIPPING dial down or press CD RIPPING
button on the remote control to start the ripping for the
current track.
Turn CD RIPPING dial up or press and hold CD
RIPPING button on the remote control to start
ripping the all tracks of Disc.
“CD Ripping” is displayed in red and CD RIPPING
starts.
During CD ripping, do not disconnect USB device.
5
To stop ripping, press
STOP button.and
then automatically create
and save as the MP3 file.
After CD-Ripping,a directory named “RIPPING”
will be created in your device.The file name
follows the format:”SAM-XXXX”.MP3.
CD Ripping Feature Supported Player
YP-T8 Samsung MP3 Player
YP-T7F Samsung MP3 Player
YP-D1 Samsung MP3 Player
YP-T8N Samsung MP3 Player
YP-U2 Samsung MP3 Player
YP-T9 Samsung MP3 Player
YP-K5 Samsung MP3 Player
YP-K3 Samsung MP3 Player
YV-150 Samsung MP3 Player
YP-U3 Samsung MP3 Player
Product Company Type
Note
CD RIPPING FUNCTION
convenient function
70
troubleshooting
Refer to the chart below when this unit does not function properly. If the problem you are experiencing is not listed
below or if the instruction below does not help, turn off the unit, disconnect the power cord, and contact the nearest
authorized dealer or Samsung Electronics Service Center.
SYMPTOM Check/Remedy
Disc tray does not open. • Is the power cord plugged securely into the outlet?
• Turn off the power and then turn it back on.
‘Please connect your ipod’
appears on the screen.
• Remove the iPod from the docking cradle and reinsert again.
• If the battery level of your iPod is totally drained, you
have to charge it again before use.
Playback does not start
immediately when the
Play/Pause button is pressed.
• Are you using a deformed disc or a disc with scratches on
the surface?
• Wipe the disc clean.
Sound is not produced. • No sound is heard during fast playback, slow playback, and
step motion playback.
• Are the speakers connected properly? Is the speaker setup
correctly customized?
• Is the disc severely damaged?
Sound can be heard only from a
few speakers and not all six.
• When listening to a CD or radio, sound is output to the front
speakers (L/R) only. Select "PRO LOGIC II" by pressing
PL II (Dolby Pro Logic II) on the remote control to use all
six speakers.
• Make sure that the DVD disc is 5.1-CH compatible.
• If you set C, SL, and SR to NONE in the speaker mode in the
audio setup of the setup screen, no sound is heard from the
center speaker and the front left and right speakers. Set C,
SL, and SR to SMALL.
Dolby Digital 5.1 CH Surround
Sound is not produced.
• Is there "Dolby Digital 5.1 CH" mark on the disc? Dolby
Digital 5.1 CH Surround Sound is produced only if the disc is
recorded with 5.1 channel sound.
• Is the audio language correctly set to DOLBY DIGITAL
5.1-CH in the information display?
The remote control does not
work.
• Is the remote control being operated within its operation
range of angle and distance?
• Are the batteries exhausted?
• Have you selected the mode(TV/DVD) functions of the
remote control (TV or DVD) correctly?
71
ENG ● TROUBLESHOOTING
SYMPTOM Check/Remedy
• Disc is rotating but no
picture is produced.
• Picture quality is poor and
picture is shaking.
• Is the TV power on?
• Are the video cables connected properly?
• Is the disc dirty or damaged?
• A poorly manufactured disc may not be playable.
Audio language and subtitles do
not work.
• Audio language and subtitles will not work if the disc does
not contain them.
Menu screen does not appear
even when the menu function is
selected.
• Are you using a disc that does not contain menus?
Aspect ratio cannot be changed. • You can play 16:9 DVDs in 16:9 WIDE mode, 4:3 LETTER
BOX mode, or 4:3 PAN SCAN mode, but 4:3 DVDs can be
seen in 4:3 ratio only. Refer to the DVD disc jacket and then
select the appropriate function.
• The main unit is not working.
(Example: The power goes out
or strange noise is heard.)
• The DVD player is not working
normally.
• Turn off the power and hold the STOP (T) button on the
main unit for longer than 5 seconds (reset function).
Using the RESET function will erase all stored settings.
Do not use this unless necessary.
The password for rating level has
been forgotten.
• While “NO DISC” message appears on the display of main
unit, hold the main unit's STOP (T) button for longer than 5
seconds. “INITIAL” appears on the display and all settings will
return to the default values.
• Press the POWER button.
Using the RESET function will erase all stored settings.
Do not use this unless necessary.
Can't receive radio broadcast. • Is the antenna connected properly?
• If the antenna's input signal is weak, install an external FM
antenna in an area with good reception.
'CHECK ANTENNA' is displayed. • XM Antenna Jack and the XM Antenna is not properly connected.
Check the connections.
'ON SIGNAL' is displayed. • Reposition your XM Antenna.
'OFF AIR' is displayed. • The selected channel is not currently broadcasting.
Receiving only XM channel 0 and
channel 1.
• XM Antenna is not activated.
• Access the website at “http://activate.xmradio.com” with a credit
card to sign up.
72
language code list
Enter the appropriate code number for the initial settings “Disc Audio”, “Disc Subtitle” and/or “Disc Menu”
(See page 54).
Code Language Code Language Code Language Code Language
1027 Afar 1181 Frisian 1334 Latvian, Lettish 1506 Slovenian
1028 Abkhazian 1183 Irish 1345 Malagasy 1507 Samoan
1032 Afrikaans 1186 Scots Gaelic 1347 Maori 1508 Shona
1039 Amharic 1194 Galician 1349 Macedonian 1509 Somali
1044 Arabic 1196 Guarani 1350 Malayalam 1511 Albanian
1045 Assamese 1203 Gujarati 1352 Mongolian 1512 Serbian
1051 Aymara 1209 Hausa 1353 Moldavian 1513 Siswati
1052 Azerbaijani 1217 Hindi 1356 Marathi 1514 Sesotho
1053 Bashkir 1226 Croatian 1357 Malay 1515 Sundanese
1057 Byelorussian 1229 Hungarian 1358 Maltese 1516 Swedish
1059 Bulgarian 1233 Armenian 1363 Burmese 1517 Swahili
1060 Bihari 1235 Interlingua 1365 Nauru 1521 Tamil
1069 Bislama 1239 Interlingue 1369 Nepali 1525 Tegulu
1066 Bengali; Bangla 1245 Inupiak 1376 Dutch 1527 Tajik
1067 Tibetan 1248 Indonesian 1379 Norwegian 1528 Thai
1070 Breton 1253 Icelandic 1393 Occitan 1529 Tigrinya
1079 Catalan 1254 Italian 1403 (Afan) Oromo 1531 Turkmen
1093 Corsican 1257 Hebrew 1408 Oriya 1532 Tagalog
1097 Czech 1261 Japanese 1417 Punjabi 1534 Setswana
1103 Welsh 1269 Yiddish 1428 Polish 1535 Tonga
1105 Danish 1283 Javanese 1435 Pashto, Pushto 1538 Turkish
1109 German 1287 Georgian 1436 Portuguese 1539 Tsonga
1130 Bhutani 1297 Kazakh 1463 Quechua 1540 Tatar
1142 Greek 1298 Greenlandic 1481 Rhaeto-Romance 1543 Twi
1144 English 1299 Cambodian 1482 Kirundi 1557 Ukrainian
1145 Esperanto 1300 Kannada 1483 Romanian 1564 Urdu
1149 Spanish 1301 Korean 1489 Russian 1572 Uzbek
1150 Estonian 1305 Kashmiri 1491 Kinyarwanda 1581 Vietnamese
1151 Basque 1307 Kurdish 1495 Sanskrit 1587 Volapuk
1157 Persian 1311 Kirghiz 1498 Sindhi 1613 Wolof
1165 Finnish 1313 Latin 1501 Sangro 1632 Xhosa
1166 Fiji 1326 Lingala 1502 Serbo-Croatian 1665 Yoruba
1171 Faeroese 1327 Laothian 1503 Singhalese 1684 Chinese
1174 French 1332 Lithuanian 1505 Slovak 1697 Zulu
73
ENG
DIGITAL CAMERA
Product
Company
Type
Finepix-A340 Fuji Digital Camera
Finepix-F810 Fuji Digital Camera
Finepix-F610 Fuji Digital Camera
Finepix-f450 Fuji Digital Camera
Finepix S7000 Fuji Digital Camera
Finepix A310 Fuji Digital Camera
KD-310Z Konica Digital Camera
Finecam SL300R Kyocera Digital Camera
Finecam SL400R Kyocera Digital Camera
Finecam S5R Kyocera Digital Camera
Finecam Xt Kyocera Digital Camera
Dimage-Z1 Minolta Digital Camera
Dimage Z1 Minolta Digital Camera
Dimage X21 Minolta Digital Camera
Coolpix4200 Nikon Digital Camera
Coolpix4300 Nikon Digital Camera
Coolpix 2200 Nikon Digital Camera
Coolpix 3500 Nikon Digital Camera
Coolpix 3700 Nikon Digital Camera
Coolpix 4100 Nikon Digital Camera
Coolpix 5200 Nikon Digital Camera
Stylus 410 digital Olympus Digital Camera
300-digital Olympus Digital Camera
300-digital Olympus Digital Camera
U300 Olympus Digital Camera
X-350 Olympus Digital Camera
C-760 Olympus Digital Camera
C-5060 Olympus Digital Camera
X1 Olympus Digital Camera
U-mini Olympus Digital Camera
Lumix-FZ20 Panasonic Digital Camera
DMC-FX7GD Panasonic Digital Camera
Lumix LC33 Panasonic Digital Camera
LUMIX DMC-F1 Panasonic Digital Camera
Optio-S40 Pentax Digital Camera
Optio-S50 Pentax Digital Camera
Optio 33LF Pentax Digital Camera
Optio MX Pentax Digital Camera
Digimax-420 Samsung Digital Camera
Digimax-400 Samsung Digital Camera
Sora PDR-T30 Toshiba Digital Camera
Coolpix 5900 Nikon Digital Camera
Coolpix S1 Nikon Digital Camera
Coolpix 7600 Nikon Digital Camera
DMC-FX7 Panasonic Digital Camera
Dimage Xt Minolta Digital Camera
AZ-1 Olympus Digital Camera
Product
Company
Type
Product
Company
Type
Cruzer Micro Sandisk
USB 2.0 USB Flash Drive 128M
Cruzer Mini Sandisk USB 2.0 128M
Cruzer Mini Sandisk USB 2.0 256M
SONY Micro Vault Sony USB 2.0 64MB
FLEX DRIVE Serotech USB 2.0 32MB
AnyDrive A.L tech USB 2.0 128MB
XTICK LG USB 2.0 128M
Micro Mini Iomega USB 2.0 128M
iFlash Imation USB 2.0 64M
LG XTICK(M) USB 2.0 64M
RiDATA EZDrive USB 2.0 64M
Product
Company
Type
USB host feature supported products
USB FLASH DISC
MP3 PLAYER
Product
Company
Type
Creative MuVo NX128M
Creative 128 MB MP3 Player
Iriver H320 Iriver 20G HDD MP3 Player
YH-920 Samsung 20G HDD MP3 Player
YP-T7 Samsung MP3 Player
YP-MT6 Samsung MP3 Player
YP-T6 Samsung MP3 Player
YP-T9 Samsung MP3 Player
YP-ST5 Samsung MP3 Player
YP-T5 Samsung MP3 Player
YP-K5 Samsung MP3 Player
YP-K3 Samsung MP3 Player
YP-U3 Samsung MP3 Player
YP-Z5F Samsung MP3 Player
iAUDIO U2 Cowon MP3 Player
iAUDIO G3 Cowon MP3 Player
iAudio M3 Cowon HDD MP3 Player
SI-M500L Sharp 256MB MP3 Player
H10 Iriver MP3 Player
YP-T10 Samsung MP3 Player
YP-P2 Samsung MP3 Player
Product
Company
Type
●
USB HOST FEATURE SUPPORTED PRODUCTS
74
appendix
CAUTIONS ON HANDLING AND STORING DISCS
Small scratches on the disc may reduce sound and picture quality or cause skipping.
Be especially careful not to scratch discs when handling them.
Handling discs
Do not touch the playback side of the disc.
Hold the disc by the edges so that fingerprints will not get on the surface.
Do not stick paper or tape on the disc.
Disc Storage
Do not keep in direct sunlight Keep in a cool
ventilated area
Keep in a clean Protection jacket.
Store vertically.
M
Do not allow the discs to become contaminated with dirt. `
Do not load cracked or scratched discs. `
Handling and Storing Discs
When you get fingerprints or dirt on the disc, clean it with a mild detergent diluted in water and wipe with
a soft cloth.
When cleaning, wipe gently from the inside to the outside of the disc•
M
Condensation may form if warm air comes into contact with cold parts inside the player. `
When condensation forms inside the player, the player may not operate correctly. If this
occurs, remove the disc and let the player stand for 1 or 2 hours with the power on.
75
ENG ● APPENDIX
SPECIFICATIONS
General
Power Requirements AC 120V, 60Hz
Power Consumption 90 W
Weight 11.5 Ibs
Dimensions 16.9 (W) x 17.3 (H) x 2.9 (D) inches
Operating Temperature Range +41°F to +95°F
Operating Humidity Range 10 % to 75 %
Disc
DVD (Digital Versatile Disc) Reading Speed : 3.49 ~ 4.06 m/sec.
Approx. Play Time (Single Sided, Single Layer Disc) : 135 min.
CD : 5 inches (COMPACT DISC) Reading Speed : 4.8 ~ 5.6 m/sec.
Maximum Play Time : 74 min.
CD : 3 1/2 inches (COMPACT DISC) Reading Speed : 4.8 ~ 5.6 m/sec.
Maximum Play Time : 20 min.
Video Output
Composite Video 480i
1 channel : 1.0 Vp-p (75 Ω load)
Component Video
480i
Y : 1.0 Vp-p (75 load)
Pr : 0.70 Vp-p (75 Ω load)
Pb : 0.70 Vp-p (75 Ω load)
Video/Audio HDMI 1080p, 1080i, 720p, 480p
Amplifier
Front speaker output 170W × 2(3
Ω
)
Center speaker output 180W(3
Ω
)
Rear speaker output 170W × 2(3
Ω
)
Subwoofer speaker output 170W × 2(3
Ω
)
Frequency range 20Hz~20KHz
S/N Ratio 70dB
Channel separation 60dB
Input sensitivity (AUX)400mV
Power Requirements AC120V~ 60Hz
Power Consumption 40 W
Weight 2.9 lbs
Dimensions (W x H x D) 3.0 x 10.1 x 6.9 inches
Operating Temperature Range +41°F to +95°F
Operating Humidity Range 10% ~ 75%
Output 170W x 2
Frequency range 20Hz~20KHz
S/N Ratio 75dB
SWA-4100
76
HT-Z520
HT-TZ522
Speaker
Speaker system 5.1ch speaker system
Impedance
Frequency range
Output sound pressure level
Rated input
Maximum input
Dimensions (W x H x D)
Weights
Front/Rear
3 Ω
140Hz~20KHz
86dB/W/M
170W
340W
Center
3 Ω
140Hz~20KHz
86dB/W/M
180W
360W
Subwoofer
3 Ω
45Hz~160Hz
86dB/W/M
340W
680W
Front/Rear
: 3.5 x 9.0 x 3.6 inches
Center : 11.8 x 4.0 x 3.6 inches
Subwoofer : 7.9 x 15.7 x 16.5 inches
Front
: 1.9 Ibs, Center : 3.1 Ibs
Rear : 1.1 Ibs, Subwoofer : 19.0 Ibs
Speaker
Speaker system 5.1ch speaker system
Impedance
Frequency range
Output sound pressure level
Rated input
Maximum input
Dimensions (W x H x D)
Weights
*: Nominal specification
- Samsung Electronics Co., Ltd reserves the right to change the specifications without notice.
- Weight and dimensions are approximate.
Front/Rear
3 Ω
140Hz~20KHz
86dB/W/M
170W
340W
Center
3 Ω
140Hz~20KHz
86dB/W/M
180W
360W
Subwoofer
3 Ω
45Hz~160Hz
86dB/W/M
340W
680W
Front
: 3.5 x 47.2 x 3.6 inches
Rear
: 3.5 x 9.0 x 3.6 inches
Center : 11.8 x 4.0 x 3.6 inches
Subwoofer : 7.9 x 15.7 x 16.5 inches
Front
: 7.7 Ibs, Center : 3.1 Ibs
Rear : 1.1 Ibs, Subwoofer : 19.0 Ibs
appendix
Speaker
Speaker system 5.1ch speaker system
Impedance
Frequency range
Output sound pressure level
Rated input
Maximum input
Dimensions (W x H x D)
Weights
Front/Rear
3 Ω
140Hz~20KHz
86dB/W/M
170W
340W
Center
3 Ω
140Hz~20KHz
86dB/W/M
180W
360W
Subwoofer
3 Ω
45Hz~160Hz
86dB/W/M
340W
680W
Front/Rear
: 3.5 x 47.2 x 3.6 inches
Center : 11.8 x 4.0 x 3.6 inches
Subwoofer : 7.9 x 15.7 x 16.5 inches
Front : 7.7 lbs, Rear : 7.4 lbs,
Center : 3.1 Ibs, Subwoofer : 19.0 Ibs
HT-TZ525
77
ENG ● APPENDIX
WARRANTY
LIMITED WARRANTY TO ORIGINAL PURCHASER
This SAMSUNG brand product, as supplied and distributed by Samsung Electronics America, Inc. (SAMSUNG) and delivered new,
in the originalcarton to the original consumer purchaser, is warranted by SAMSUNG against manufacturing defects in materials and
workmanship for a limited warranty period of:
One (1) Year Parts and Labor*
(*90 Days Parts and Labor for Commercial Use)
This limited warranty begins on the original date of purchase, and is valid only on products purchased and used in the United States.
To receive warranty service, the purchaser must contact SAMSUNG for problem determination and service procedures. Warranty
service can only be performed by a SAMSUNG authorized service center. The original dated bill of sale must be presented upon
request as proof of purchase to SAMSUNG or SAMSUNG's authorized service center. Transportation of the product to and from
the service center is the responsibility of the purchaser.
SAMSUNG will repair or replace this product, at our option and at no charge as stipulated herein, with new or reconditioned parts
or products if found to be defective during the limited warranty period specified above. All replaced parts and products become
the property of SAMSUNG and must be returned to SAMSUNG. Replacement parts and products assume the remaining original
warranty, or ninety (90) days, whichever is longer.
SAMSUNG’s obligations with respect to software products distributed by SAMSUNG under the SAMSUNG brand name are set forth in the
applicable end user license agreement. Non-SAMSUNG hardware and software products, if provided, are on an “AS IS” basis.
Non-SAMSUNG manufacturers, suppliers, publishers, and service providers may provide their own warranties.
This limited warranty covers manufacturing defects in materials and workmanship encountered in normal, and except to the extent
otherwise expressly provided for in this statement, noncommercial use of this product, and shall not apply to the following, including,
but not limited to: damage which occurs in shipment; delivery and installation; applications and uses for which this product was not
intended; altered product or serial numbers; cosmetic damage or exterior finish; accidents, abuse, neglect, fire, water, lightning or
other acts of nature; use of products, equipment, systems, utilities, services, parts, supplies, accessories, applications, installations,
repairs, external wiring or connectors not supplied and authorized by SAMSUNG, or which damage this product or result in service
problems; incorrect electrical line voltage, fluctuations and surges; customer adjustments and failure to follow operating instructions,
cleaning, maintenance and environmental instructions that are covered and prescribed in the instruction book; product removal
or reinstallation; reception problems and distortion related to noise, echo, interference or other signal transmission and delivery
problems. SAMSUNG does not warrant uninterrupted or error-free operation of the product.
THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE LISTED AND DESCRIBED ABOVE, AND NO WARRANTIES
WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE, SHALL APPLY AFTER THE EXPRESS WARRANTY PERIODS STATED ABOVE, AND
NO OTHER EXPRESS WARRANTY OR GUARANTY GIVEN BY ANY PERSON, FIRM OR CORPORATION WITH RESPECT TO
THIS PRODUCT SHALL BE BINDING ON SAMSUNG. SAMSUNG SHALL NOT BE LIABLE FOR LOSS OF REVENUE OR PROFITS,
FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES
CAUSED BY THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH
THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. NOR SHALL
RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT
SOLD BY SAMSUNG AND CAUSING THE ALLEGED DAMAGE. WITHOUT LIMITING THE FOREGOING, PURCHASER ASSUMES
ALL RISK AND LIABILITY FOR LOSS, DAMAGE OR INJURY TO PURCHASER AND PURCHASER’S PROPERTY AND TO OTHERS
AND THEIR PROPERTY ARISING OUT OF THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT SOLD BY SAMSUNG NOT
CAUSED DIRECTLY BY THE NEGLIGENCE OF SAMSUNG. THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER
THAN THE ORIGINAL PURCHASER OF THIS PRODUCT, IS NONTRANSFERABLE AND STATES YOUR EXCLUSIVE REMEDY.
Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or consequential
damages, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.
To obtain warranty hardware service, please contact SAMSUNG at:
Samsung Electronics America, Inc.
105 Challenger Road Ridgefield Park, NJ 07660-0511
1-800-SAMSUNG (726-7864) and www.samsung.com/us
Contact SAMSUNG WORLD WIDE
If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer
care center.
Region Country Customer Care Center Web Site
North America
CANADA 1-800-SAMSUNG(726-7864) www.samsung.com/ca
MEXICO 01-800-SAMSUNG(726-7864) www.samsung.com
U.S.A 1-800-SAMSUNG(726-7864) www.samsung.com
Latin America
ARGENTINE 0800-333-3733 www.samsung.com/ar
BRAZIL 0800-124-421 , 4004-0000 www.samsung.com
CHILE 800-SAMSUNG(726-7864) www.samsung.com/cl
NICARAGUA 00-1800-5077267
HONDURAS 800-7919267
COSTA RICA 0-800-507-7267 www.samsung.com/latin
ECUADOR 1-800-10-7267 www.samsung.com/latin
EL SALVADOR 800-6225 www.samsung.com/latin
GUATEMALA 1-800-299-0013 www.samsung.com/latin
JAMAICA 1-800-234-7267 www.samsung.com/latin
PANAMA 800-7267 www.samsung.com/latin
PUERTO RICO 1-800-682-3180 www.samsung.com/latin
REP. DOMINICA 1-800-751-2676 www.samsung.com/latin
TRINIDAD & TOBAGO 1-800-SAMSUNG(726-7864) www.samsung.com/latin
VENEZUELA 0-800-100-5303 www.samsung.com/latin
COLOMBIA 01-8000112112 www.samsung.com.co
Europe
BELGIUM 0032 (0)2 201 24 18 www.samsung.com/be
CZECH REPUBLIC
844 000 844
Distributor pro Českou republiku:
Samsung Zrt., česka organizační složka
Vyskočilova 4, 14000 Praha 4
www.samsung.com/cz
DENMARK 70 70 19 70 www.samsung.com/dk
FINLAND 030-6227 515 www.samsung.com/fi
FRANCE 3260 SAMSUNG ( 0,15/Min),
08 25 08 65 65 ( 0,15/Min) www.samsung.com
GERMANY
01805 - SAMSUNG(726-7864) ( 0,14/Min)
www.samsung.com
HUNGARY 06-80-SAMSUNG(726-7864) www.samsung.com
ITALIA 800-SAMSUNG(726-7864) www.samsung.com
LUXEMBURG 0035 (0)2 261 03 710 www.samsung.com/be
NETHERLANDS
0900-SAMSUNG(726-7864) ( 0,10/Min) www.samsung.com/nl
NORWAY 815-56 480 www.samsung.com/no
POLAND 0 801 801 881 , 022-607-93-33 www.samsung.com/pl
PORTUGAL 80820-SAMSUNG(726-7864) www.samsung.com/pt
SLOVAKIA 0800-SAMSUNG(726-7864) www.samsung.com/sk
SPAIN 902 10 11 30 www.samsung.com
SWEDEN 0771-400 200 www.samsung.com/se
U.K 0845 SAMSUNG (7267864) www.samsung.com
EIRE 0818 717 100 www.samsung.com/ie
AUSTRIA 0800-SAMSUNG(726-7864) www.samsung.com/at
SWITZERLAND 0800-SAMSUNG(726-7864) www.samsung.com/ch
CIS
RUSSIA 8-800-555-55-55 www.samsung.com
KAZAHSTAN 8-10-800-500-55-500 www.samsung.kz
UZBEKISTAN 8-10-800-500-55-500 www.samsung.uz
KYRGYZSTAN 00-800-500-55-500
TADJIKISTAN 8-10-800-500-55-500
UKRAINE 8-800-502-0000 www.samsung.com
LITHUANIA 8-800-77777 www.samsung.lt
LATVIA 800-7267 www.samsung.com/lv
ESTONIA 800-7267 www.samsung.ee
Asia Pacic
AUSTRALIA 1300 362 603 www.samsung.com
NEW ZEALAND 0800SAMSUNG(726-7864) www.samsung.com/nz
CHINA 800-810-5858 , 010-6475 1880 www.samsung.com
HONG KONG 3698-4698 www.samsung.com/hk
INDIA 3030 8282 , 1800 110011 www.samsung.com
INDONESIA 0800-112-8888 www.samsung.com
JAPAN 0120-327-527 www.samsung.com/jp
MALAYSIA 1800-88-9999 www.samsung.com/my
PHILIPPINES 1800-10-SAMSUNG(726-7864) www.samsung.com/ph
SINGAPORE 1800-SAMSUNG(726-7864) www.samsung.com
THAILAND 1800-29-3232 , 02-689-3232 www.samsung.com
TAIWAN 0800-329-999 www.samsung.com/tw
VIETNAM 1 800 588 889 www.samsung.com
Middle East &
Africa
TURKEY 444 77 11 www.samsung.com
SOUTH AFRICA 0860-SAMSUNG(726-7864 ) www.samsung.com
U.A.E 800-SAMSUNG (726-7864), 8000-4726
www.samsung.com
QUESTIONS OR COMMENTS?
COUNTRY CALL OR VISIT US ONLINE AT WRITE
IN THE US 1-800-SAMSUNG
(7267864) www.samsung.com/us
Samsung Electronics America, Inc.
105 Challenger Road Ridgefield Park,
NJ 07660-0511
Code No. AH68-02167B (0.0)

Navigation menu
