Users Manual 4

playback
40
DIVX PLAYBACK
The functions on this page apply to DivX disc playback.
Skip Forward/Back D
During playback, press the [,] button.
Goes to the next file whenever you press the • ] button,
if there are over 2 files in the disc.
Goes to the previous file whenever you press the •
[ button, if there are over 2 files in the disc.
Fast Playback D
During playback, press the (,) button.
To play back the disc at a faster speed, press the ( or )
button during playback.
Each time you press either button, the playback speed will •
change as follows:
2x ➞ 4x ➞ 8x ➞ 32x ➞ Normal.
5 Minute Skip function D
During playback, press the Cursor , button.
Playback skips 5 minutes forward whenever you press •
the Cursor button.
Playback skips 5 minutes back whenever you press the •
Cursor button.
Audio Display D
Press the AUDIO button.
If there are multiple audio languages on a disc, you can •
toggle between them.
Each time you press the button, your selection will toggle •
between AUDIO (1/N, 2/N ...) and .
M
` is displayed when there is only one supported language in the disc.
Subtitle Display D
Press the SUBTITLE button.
Each time you press the button, your selection will toggle •
between SUBTITLE (1/N, 2/N ...) and SUBTITLE OFF.
If the disc has only one subtitle file, it will be played •
automatically.
See number 2 (Caption Function) on the next page for more •
details concerning Subtitle usage with DivX discs.
CD RIPPING
S.VOL
AUDIO
UPSCALE
CD RIPPING
S.VOL
AUDIO
UPSCALE
CD RIPPING
S.VOL
AUDIO
UPSCALE
CD RIPPING
S.VOL
AUDIO
UPSCALE
41
ENG ● PLAYBACK
DIVX PLAYBACK
If the Disc has more than One Subtitle File D
If the disc has more than one subtitle file, the default
subtitle may not match the movie and you will have
to select your subtitle language as follows:
In Stop mode, press the Cursor 1. , button, select the
desired subtitle ( ) from the TV screen, and then
press the ENTER button.
When you select the desired DivX file from the TV 2.
screen, the movie will be played normally.
DivX(Digital internet video eXpress)
DivX is a video file format developed by Microsoft and is based on MPEG4 compression technology to
provide audio and video data over the Internet in real-time.
MPEG4 is used for video encoding and MP3 for audio encoding so that the users can watch a movie at
near DVD-quality video and audio.
Supported Formats1.
This product only supports the following media formats.If both video and audio formats are not
supported, you may experience problems such as broken images or no sound.
Supported Video Formats
Format AVI WMV
Supported Versions DivX3.11~DivX5.1, XviD V1/V2/V3/V7
Supported Audio Formats
Format MP3 WMA AC3 DTS
Bit Rate 80~384kbps 56~128kbps 128~384kbps 1.5Mbps
Sampling Frequency 44.1khz 44.1/48khz 44.1khz
DivX files, including audio and video files, created in the DTS format can only support up to 6Mbps.•
Aspect Ratio : Although the default DivX resolution is 640x480 pixels (4:3), this product supports •
up to 800x600 pixels (16:9). TV screen resolutions higher than 800 will not be supported.
When you play a disc whose sampling frequency is higher than 48khz or 320kbps, you may •
experience shaking on the screen during playback.
Caption Function2.
You must have some experience with video extraction and editing in order to use this feature •
properly.
To use the caption function, save the caption file (*.smi) in the same file name as that of the DivX •
media file (*.avi) within the same folder.
Example. Root Samsung_007CD1.avi
Samsung_007CD1.smi
Up to 60 alphanumeric characters or 30 East Asian characters (2 byte characters such as Korean •
and Chinese) for the file name.
CD RIPPING
S.VOL
AUDIO
UPSCALE
playback
42
USING THE PLAYBACK FUNCTION
Displaying Disc Information dBAGD
You can view disc playback information on the TV screen.
Press the INFO button.
M
Depending on the disc, the disc information `
display may appear different.
Depending on the disc, you can also select
`
DTS, DOLBY DIGITAL, or PRO LOGIC.
appears on the TV screen!
If this symbol appears on the TV screen when pressing
a button, that operation is not possible with the disc
currently being played.
Checking the Remaining Time dBA
Press the REMAIN button.
For checking the total and remaining time of a title or •
chapter being played.
Each time the Remain button is pressed
DVD-VIDEO
TITLE ELAPSED ➞ TITLE REMAIN ➞ CHAPTER ELAPSED ➞ CHAPTER REMAIN
DVD-AUDIO
GROUP ELAPSED ➞ GROUP REMAIN ➞ TRACK ELAPSED ➞ TRACK REMAIN
B
TRACK ELAPSED ➞ TRACK REMAIN ➞ TOTAL ELAPSED ➞ TOTAL REMAIN
A
TRACK REMAIN ➞ TRACK ELAPSED
CD RIPPING
CD RIPPING
S.VOL
AUDIO
UPSCALE
43
ENG ● PLAYBACK
Fast Playback dBAD
Press the (,) button.
Each time the button is pressed during playback, the •
playback speed changes as follows:
( 2X ➞ ( 4X ➞ ( 8X ➞ ( 32X ➞ PLAY
) 2X ➞ ) 4X ➞ ) 8X ➞ ) 32X ➞ PLAY
M
During fast playback of a CD or MP3-CD, sound is heard only at 2x speed, and not at 4x, `
8x, and 32x speeds.
Slow Playback dD
Press the SLOW button.
Each time the button is pressed during playback, the playback speed changes as follows:•
d
*1/2 ➞*1/4 ➞*1/8 ➞&1/2 ➞&1/4 ➞&1/8 ➞
PLAY
D
*1/2 ➞*1/4 ➞*1/8 ➞ PLAY
M
No sound is heard during slow playback. `
Reverse slow playback does not work with CD. `
Skipping Scenes/Songs dA
Press the [,] button.
Each time the button is pressed during playback, the •
previous or next chapter, track or directory (file) will be
played.
You cannot skip chapters consecutively.•
CD RIPPING
S.VOL
AUDIO
UPSCALE
playback
44
USING THE PLAYBACK FUNCTION
Repeat Playback dBAGD
Repeat playback allows you to repeatedly play a chapter, title,
track (song), or directory (MP3 file).
Press the REPEAT button.
Each time the button is pressed during playback, the repeat •
playback mode changes as follows:
DVD-VIDEO

REPEAT : CHAPTER ➞ REPEAT : TITLE ➞ REPEAT : OFF
D V D - A U D I O

REPEAT : TRACK ➞ REPEAT : GROUP ➞ REPEAT : OFF
B

REPEAT : TRACK ➞ REPEAT : DISC ➞ REPEAT : OFF
AGD
REPEAT : RANDOM ➞ REPEAT : TRACK ➞ REPEAT : DIR ➞ REPEAT : DISC
➞ REPEAT : OFF
CHAPTER : Repeatedly plays the selected chapter.
TITLE : Repeatedly plays the selected title.
GROUP : Repeatedly plays the selected group.
RANDOM : Plays tracks in random order. (A track that has already been played may be played again.)
TRACK : Repeatedly plays the selected track.
DIR : Repeatedly plays all tracks in the selected folder.
DISC : Repeatedly plays the entire disc.
OFF : Cancels Repeat Playback.
To Select a Repeat Playback Mode in the Disc Information Screen
dB
Press the 1. INFO button twice.
Press the Cursor 2. button to move to REPEAT
PLAYBACK ( ) display.
Press the Cursor 3. button to select the desired Repeat
Playback mode.
To select another album and track, repeat Steps 2 •
and 3 above.
Press the 4. ENTER button.
d
OFF ➞ A- ➞ CHAP ➞ TITLE ➞ OFF
B
OFF ➞ A- ➞ TRACK ➞ DISC ➞ OFF
M
For DivX, MP3 and JPEG discs, you cannot select Repeat Play from the information `
display screen.
CD RIPPING
S.VOL
AUDIO
UPSCALE
Repeat Playback Options
CD RIPPING
S.VOL
AUDIO
UPSCALE
CD RIPPING
S.VOL
AUDIO
UPSCALE
45
ENG ● PLAYBACK
A-B Repeat Playback d
You can repeatedly play back a designated section of a DVD.
Press the 1. INFO button twice.
Press the Cursor 2. button to move to REPEAT PLAYBACK
() display.
Press the Cursor 3. , button to select A- and then press
the ENTER button.
When the • ENTER button is pressed, the selected
position will be stored in memory.
Press the 4. ENTER button at the end of the desired segment.
The specified segment will be played repeatedly. •
A -
A -?
A - B
REPEAT : AÐ
A TO B REPEAT ON
d To return to normal playback, press the Cursor , button to select OFF.
M
The A-B Repeat function does not operate with DivX, MP3 or JPEG discs. `
Step Function dD
Press the STEP button.
The picture moves forward one frame each time the button is •
pressed during playback.
M
No sound is heard during step motion playback. `
CD RIPPING
S.VOL
AUDIO
UPSCALE
playback
46
USING THE PLAYBACK FUNCTION
Angle Function d
This function allows you to view the same scene in different
angles.
Press the 1. INFO button.
Press the Cursor 2. button to move to ANGLE ( )
display.
Press the Cursor 3. , button or numeric buttons to select
the desired angle.
Each time the button is pressed, the angle changes as •
follows:
1/3 ➞ 2/3 ➞ 3/3 ➞ 1/3
M
The Angle function works only with discs on which multiple angles have been recorded. `
Zoom (Screen Enlarge) Function d
This function allows you to enlarge a particular area of the
displayed image.
Press the 1. ZOOM button.
Press the Cursor 2. ,,, button to move to the area
you want to enlarge.
Press the 3. ENTER button.
Each time the button is pressed, the zoom level changes •
as follows:
ZOOM X 1.5 ➞ZOOM X 2 ➞ZOOM X 3
➞ZOOM OFF
ENTER SELECT
SELECT ZOOM POSITION
CD RIPPING
S.VOL
AUDIO
UPSCALE
CD RIPPING
S.VOL
AUDIO
UPSCALE
CD RIPPING
S.VOL
AUDIO
UPSCALE
47
ENG ● PLAYBACK
USING THE PLAYBACK FUNCTION
Audio Language Selection Function d
Press the 1. INFO button twice.
Press the Cursor 2. , button or numeric buttons to select
the desired audio language.
Depending on the number of languages on a DVD disc, a •
different audio language (ENGLISH, SPANISH, FRENCH,
etc.) is selected each time the button is pressed.
EN 1/3 ➞ SP 2/3 ➞ FR 3/3 ➞ EN 1/3
Subtitle Language Selection Function d
Press the 1. INFO button twice.
Press the Cursor 2. button to move to SUBTITLE ( )
display.
Press the Cursor 3. button or numeric buttons to select the
desired subtitle.
EN 01/03 ➞ SP 02/03 ➞ FR 03/03 ➞ OFF/03 ➞
EN 01/03
M
To operate this function, you can also press the `AUDIO or SUBTITLE buttons on the
remote control.
Depending on the disc, the Subtitle and Audio Language functions may not be available. `
Moving Directly to a Scene/Song dBAG
dB
Press the 1. INFO button.
Press the Cursor 2. , button or numeric buttons to select
the desired title/track ( ) and then press the ENTER
button.
Press the Cursor 3. , button to move to the Chapter
() display.
Press the Cursor 4. , button or numeric buttons to select
the desired chapter and then press the ENTER button.
Press the Cursor 5. , button to move to time ( ) display.
Press the numeric buttons to select the desired time 6.
and then press the ENTER button.
CD RIPPING
CD RIPPING
S.VOL
AUDIO
UPSCALE
CD RIPPING
S.VOL
AUDIO
UPSCALE
CD RIPPING
CD RIPPING
S.VOL
AUDIO
UPSCALE
playback
48
Moving Directly to a Scene/Song dBAG
AG
Press the numeric buttons.
The selected file will be played.•
When playing an MP3 or JPEG disc, you cannot use the •
Cursor , button to move to a folder.
To move a folder, press the STOP (T) and then press the
Cursor , button.
M
You can press the `
[,]
button on the remote control to move directly to the desired title,
chapter, or track.
Depending on the disc, you may not be able to move to the selected title or time. `
Using the Disc Menu d
You can use the menus for the audio language, subtitle language, profile, etc.
DVD menu contents differ from disc to disc.
In Stop mode, press the 1. MENU button.
Press the Cursor 2. , button or numeric buttons
to move to Disc Menu and then press the
ENTER button.
When you select Disc Menu and it is not supported by •
the disc, the "This menu is not
supported" message appears on the screen.
Press the Cursor 3. ,,, button to select the desired
item.
Press the 4. ENTER button.
d Press the EXIT button to exit the setup screen.
M
The disc menu display may be different depending on the disc. `
ENTERMOVE EXIT
49
ENG ● PLAYBACK
USING THE PLAYBACK FUNCTION
Using the Title Menu d
For DVDs containing multiple titles, you can view the title of
each movie. Depending on the disc, the availability of this
feature may vary.
In Stop mode, press the 1. MENU button.
Press the Cursor 2. , button to move to Title Menu.
Press the 3. ENTER button.
The title menu appears.•
d Press the EXIT button to exit the setup screen.
M
The Title menu display may be different depending on the disc. `
ENTERMOVE EXIT

Navigation menu
