Users Manual 2
66
Section 6
• SIM card: new phonebook contacts will be saved to your SIM
card.
• Phone memory: new phonebook contacts will be saved to your
phone.
• Ask on saving: you will be prompted to choose between Phone
memory or SIM card whenever you save a new contact.
Copy All to Phone
This option allows you to copy all contacts from your SIM
card to your phone. For more information, see "Copying
all SIM Phonebook Entries" on page 62.
Sort by Contacts
This options allows you to have your contacts sorted by
first name or last name.
Delete All
Important! Once contact entries have been deleted, they cannot be
recovered.
This option allows you to delete your contacts. You may
delete from SIM, Phone, FDN, or All. For more
information, see "Deleting all of the Phonebook Entries"
on page 63.
Memory Status
You can check how many names and numbers are stored
in the Phonebook, in both SIM card and the phone
memory. You can also see the capacity of both memories.
1. When the idle screen displays, press the Phonebook soft
key.
t809.book Page 66 Tuesday, September 27, 2005 4:18 PM
Section 6: Understanding Your Phonebook 67
Management
Section 6
2. Highlight Management and press the Select soft key or
the key.
3. Select the Memory status option by pressing the Up or
Down Navigation key and press the Select soft key or
the key.
4. When you are finished, press the key or the Back
soft key.
t809.book Page 67 Tuesday, September 27, 2005 4:18 PM
68
Section 6
t809.book Page 68 Tuesday, September 27, 2005 4:18 PM
Section 7: Messages 69
Section 7
Section 7: Messages
Topics Covered
•Voice Notes
• Text Messages
• Picture Messages
• Inbox
• Sentbox
• Outbox
• Drafts
• Templates
•Voice mail
• Delete All
• Settings
• Broadcast Messages
• Instant Messaging
• Memory Status
This section describes how to send or receive different
types of messages. It also includes the features and
functionality associated with messaging.
t809.book Page 69 Tuesday, September 27, 2005 4:18 PM
70
Section 7
Types of Messages
Your phone provides the following message types:
• Voice Notes
• Text Messages
• Picture Messages
• Voice Mail Messages
• Broadcast Messages (SIM Dependent)
• Instant Messaging
Voice Notes
In this menu, you can record a voice note of up to one
minute long and then immediately send it by a Picture
Messaging message.
When you access this menu, a timer appears on the screen.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Using the Navigation keys, scroll to the Voice notes icon.
Press the Select soft key or the key to enter the
menu.
3. Press the Record soft key to start recording.
4. Record a memo by speaking into the microphone.
The display shows the elapsed time and the remaining
time at one time.
5. When you are finished, press the Stop soft key. Or, when
the recording time is expired, the display switches to the
next screen.
6. Press the Options soft key for the following options:
t809.book Page 70 Tuesday, September 27, 2005 4:18 PM
Section 7: Messages 71
Voice Notes
Section 7
•Send: allows you to send the Voice note.
•Play: plays back your Voice note.
•Re-record: discards the Voice note and enables you to
record another one.
•Set default destination: allows you to remove or edit the
default destination.
•Save: saves the Voice note and continues to the Send option.
7. To send the Voice note, select the Send option in the
Options menu and press the Select soft key or the
key.
8. Highlight one the following options:
•Recent log: allows you to select a number or an address
from the 20 last destinations you entered for sending the last
messages.
•Phonebook: allows you to enter the phone number you want
from your phonebook. Use the key to check the selected
entries.
•Phone number: allows you to enter a phone number.
•Email address: allows you to enter an email address to
send the voice note to.
•My Album: allows you to send the voice note to My Album.
•My Journal: allows you to send the voice note to My
Journal.
9. Press the Select soft key or the key.
10. Select where you would like to send your voice note
then and it will be entered in the Send menu in a To
field.
11. To add another destination, select Empty and press the
Options soft key.
t809.book Page 71 Tuesday, September 27, 2005 4:18 PM
72
Section 7
Note: When entering multiple destinations, you can also choose Group,
Change recipient, and Back options in addition to the other send options.
12. Repeat from step 8. You can enter up to 20 destinations.
13. When you have finished entering the destinations, press
the Options soft key, highlight the Send option and press
the Select soft key or the key.
Your phone sends the message. After sending, the
message is saved in the Sentbox.
Text Messages
Short Message Service (SMS) allows you to send and
receive short text messages to and from other mobile
phones. In addition, your phone supports the Enhanced
Messaging Service (EMS), which enables you to include
simple pictures, melodies, and animated images in your
messages. To use this feature, you must subscribe to your
service provider’s message service.
When the Message icon ( ) appears, you have received
new text messages. When the memory is full, the message
icon will flash on your phone and you cannot receive any
new messages. You must delete a message before you can
receive additional messages.
Use the Delete option in each message box to delete
obsolete messages.
Create new
In this menu, you can write and send a text message.
t809.book Page 72 Tuesday, September 27, 2005 4:18 PM
Section 7: Messages 73
Text Messages
Section 7
Creating a Simple Text Message
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Using the Navigation keys, scroll to the Messages icon.
Press the Select soft key or the key to enter the
menu.
3. Highlight the Create new option and press the Select
soft key or the key.
4. Highlight the Text message option and press the Select
soft key or the key.
5. Create your message.
Notes: For further details about entering characters, see "Section 5:
Entering Text" on page 45.
You can enter up to 160 standard Alphabet characters per page in your
message. The message can be up to 12 pages long for a total of 1920
characters.
6. When you finish entering your message, press the
Options soft key. The following options are available:
•Send: allows you to send the message.
•Insert text via: allows you to insert Text template,
Phonebook, or Favorite. The Text template allows you to apply
one of the preset message templates to the text. Select one of
the 10 items stored in the Text messages template menu.
Phonebook allows you to add names and phone numbers to
your message. Favorites allows you to add internet addresses
to your message.
•Add content: allows you to add a picture, animation, or
melody to your message.
t809.book Page 73 Tuesday, September 27, 2005 4:18 PM
74
Section 7
•Attach: allows you to attach Name card, Schedule,
Anniversary, Miscellaneous, or To do items to your message.
•Save to Drafts: save the message to your Phone or SIM.
•Language select: allows you to set the language to
English, French, or Spanish.
•Text style: allows you to format the style of the text.
For the Text size, Large, Medium, and Small size are available.
Text mode options are Normal, Underline, and Strikethrough.
The options for Bold and Italic are set by using the key to
place a checkmark by them. Alignment options are Left,
Center, and Right.
•Back: allows you save to your draft folder without sending.
7. Highlight the Send option and press the Select soft key
or the key.
8. Highlight one of the following options:
•Recent log: allows you to select from recipients of your
previous messages.
•Phonebook: allows you to select the phone number(s) you
want from your phonebook.
•Phone number: allows you to enter a number to send your
message to.
9. If you chose Recent log or Phonebook, use the key
to place checkmarks next to the entry or entries you
want your message sent to and press the Add softkey.
10. If you chose Phone number, enter the number in the To
text box.
11. To add another destination, select an Empty option and
press the Options soft key.
t809.book Page 74 Tuesday, September 27, 2005 4:18 PM
Section 7: Messages 75
Picture Messages
Section 7
Note: When entering multiple destinations, you can also choose Group and
Save to Drafts options in addition to the other send options.
12. Repeat from step 8. You can enter up to 20 destinations.
13. When you have finished entering the destinations, press
the Options soft key, highlight the Send option and press
the Select soft key or the key.
Picture Messages
This menu allows you to use the Multimedia Message
Service.
Picture Messaging is a messaging service that provides
delivery of personal multimedia messages from phone to
phone or from phone to e-mail.
In addition to the familiar text content of text messages,
multimedia messages can contain images, graphics,
voice, and audio clips. A Picture Messaging message is a
multimedia presentation in a single file. It is not a text file
with attachments.
Using the Picture Messaging feature, your phone can
receive and send messages that contain multimedia files,
such as photos, videos, sounds and images you
downloaded from the Internet and voice notes you
recorded. This function is available only if it is supported
by your service provider. Only phones that offer
multimedia messaging features can receive and display
multimedia messages.
t809.book Page 75 Tuesday, September 27, 2005 4:18 PM
76
Section 7
Create new
This menu allows you to create a new multimedia
message and send to one or multiple destinations.
Creating and Sending a Multimedia Message
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Using the Navigation keys, scroll to the Messages icon.
Press the Select soft key or the key to enter the
menu.
3. Highlight the Create new option and press the Select
soft key or the key.
4. Highlight the Picture message option and press the
Select soft key or the key.
5. Highlight Subject and press the key.
6. Enter the subject of your message and press the key.
Note: For more information about entering characters, see "Section 5:
Entering Text" on page 45.
7. To add a picture or video clip, highlight the Image &
Video option and press the key.
8. Highlight one of the following options and press the
Select soft key or the key.
•Pictures: allows you to take a picture to include, or select a
picture from your different picture folders or memory card.
•Videos: allows you to record a video to include, or select a
video from your different video folders or memory card.
t809.book Page 76 Tuesday, September 27, 2005 4:18 PM
Section 7: Messages 77
Picture Messages
Section 7
9. Select a picture or video from the various options
available.
10. Highlight the picture or video and press the Options soft
key. Highlight the Add option and press the Select soft
key or the key to add it to your message.
11. To add a sound, highlight the Sound option and press the
key.
Note: if you attached a video clip to your message, you will not be able to
add audio to the message.
12. Highlight one of the following options and press the
Select soft key or the key.
•Record audio: allows you to record a new audio message.
•My sounds: allows you to select a sound from your My
sounds folder.
•Voice list: takes you to the Voice list folder to select a voice
message to add.
13. Select a Sound or Voice note and press key. Press the
Add soft key to add the sound to your message.
14. To add a message, highlight Message and press the
key.
15. Enter your message and press the key.
16. When you have finished creating the message, press the
Options key and highlight the Send option. Press the
Select soft key or the key.
17. Highlight one of the following options:
•Recent log: allows you to select from recipients of your
previous messages.
t809.book Page 77 Tuesday, September 27, 2005 4:18 PM
78
Section 7
•Phonebook: allows you to enter the phone number you want
from your phonebook.
•Phone number: allows you to enter a phone number.
•Email address: allows you to enter an email address.
•My Album: allows you to send the message to the My Album
folder.
•My Journal: allows you to send the message to My Journal.
18. After selected where to send your message, press the
Options softkey and highlight the Send option. Press the
Select soft key or the key. Your phone sends the
message.
Inbox
The Inbox stores messages that you have received. You
can tell what kind of message it is by the icon displayed.
If the icon envelope is open then the message has been
read, otherwise it will appear closed.
The following types of messages may appear in your
inbox:
Voice notes
Text messages
Multimedia messages
Push messages
When you enter the Inbox, the list of messages displays
with the sender’s phone numbers, or names, if available
in your Phonebook. After you have read the message, the
envelope in the icon will appear opened.
t809.book Page 78 Tuesday, September 27, 2005 4:18 PM
Section 7: Messages 79
Inbox
Section 7
Note: By pressing the Left or Right Navigation keys, you may scroll
between Inbox, Sentbox, Outbox, and Drafts.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Using the Navigation keys, scroll to the Messages icon.
Press the Select soft key or the key to enter the
menu.
3. Highlight the Inbox option and press the Select soft key
or the key.
Viewing a Text Message in Inbox
1. Select a text message from the list and press the
Options soft key.
The following options will appear:
•View: read the text message.
•Reply via: allows you to send a reply to the sender by
sending a text or picture message.
•Call back: places a call to the selected number.
•Delete: deletes the selected text message or all messages.
•Move to phone: allows you to move the message from the
SIM card to the phone’s memory. This option is only available
for messages stored in the SIM card.
•Move to SIM card: allows you to move the message from
the phone’s memory to the SIM card. This option is only
available for messages stored in the phone’s memory.
•Sort by: allows you to sort messages by Read/Unread, Date,
Name, Type, Size, or Subject.
t809.book Page 79 Tuesday, September 27, 2005 4:18 PM
80
Section 7
2. Highlight the View option and press the Select soft key
or the key to read the message contents.
3. To scroll through the contents, press the Up or Down
Navigation key.
While reading a text message, you may choose the
following options by pressing the Options soft key:
• Reply via: allows you to send a reply to the sender by sending a
text or picture message.
• Call back: places a call to the selected number.
• Forward: allows you to forward the message to another
number.
• Delete: allows you to delete the message.
• Move to phone: allows you to move the message from the SIM
card to the phone’s memory. This option is only available for
messages stored in the SIM card.
• Move to SIM card: allows you to move the message from the
phone’s memory to the SIM card. This option is only available
for messages stored in the phone’s memory.
• Save address: allows you to extract the sender’s number and
URL, e-mail addresses or phone numbers from the message
text, so that you can save them in your phone’s memory.
• Protection: allows you to lock the message to protect it from
being deleted.
Viewing a Picture Message in Inbox
1. Highlight a picture message from the list and press the
Options soft key.
The following options will appear:
•View: read the picture message.
t809.book Page 80 Tuesday, September 27, 2005 4:18 PM
Section 7: Messages 81
Inbox
Section 7
•Reply via: allows you to send a reply to the sender by
sending a picture message, text message, or voice note.
•Reply all via: allows you to send a reply to All by sending a
picture message or voice note.
•Call back: places a call to the selected number.
•Forward: allows you to forward the message to another
number.
•Delete: deletes the selected picture message or all
messages.
•Sort by: allows you to sort messages by Read/Unread, Date,
Name, Type, Size, or Subject.
•Protection: allows you to lock the message to protect it from
being deleted.
•Properties: shows you information about the message, such
as time and date the message was received, the sender’s e-
mail address or phone number, recipient’s e-mail address or
phone number, Cc, message size, priority, and class.
2. Highlight the View option and press the Select soft key
or the key to read the message contents.
3. To scroll through the contents, press the Up or Down
Navigation key.
While viewing a picture message, you may choose the
following options by pressing the Options soft key:
• Reply via: allows you to send a reply to the sender by sending
a text or picture message or a voice note.
• Reply all via: allows you to send a reply to All by sending a
picture message or voice note.
• Call back: places a call to the selected number.
• Forward: allows you to forward the message to another
number.
t809.book Page 81 Tuesday, September 27, 2005 4:18 PM
82
Section 7
• Replay: allows you to view the message again.
• Delete: allows you to delete the message.
• Save address: allows you to extract the sender’s number and
URL, e-mail addresses or phone numbers from the message
text, so that you can save them in your phone’s memory.
• Save media: allows you to save the message to different areas
or to your vCard or vCalendar.
• Protection: allows you to lock the message to protect it from
being deleted.
• Properties: shows you information about the message, such as
time and date the message was received, the sender’s e-mail
address or phone number, recipient’s e-mail address or phone
number, Cc, message size, priority, and class.
Viewing a Voice Note in Inbox
1. Highlight a Voice note from the list and press the Options
soft key.
The following options will appear:
•View: listen to the voice note and view message details.
•Reply via: allows you to send a reply to the sender by
sending a picture message, text message, or voice note.
•Reply all via: allows you to send a reply to All by sending a
picture message or voice note.
•Call back: places a call to the selected number.
•Forward: allows you to forward the Voice note to another
number.
•Delete: allows you to delete the selected Voice note or all
messages.
•Sort by: allows you to sort messages by Read/Unread, Date,
Name, Type, Size, or Subject.
t809.book Page 82 Tuesday, September 27, 2005 4:18 PM
Section 7: Messages 83
Inbox
Section 7
•Protection: allows you to lock the Voice note to protect it
from being deleted.
•Properties: shows you information about the Voice note,
such as time and date the Voice note was received, the
sender’s e-mail address or phone number, recipient’s e-mail
address or phone number, Cc, Voice note size, priority, and
class.
2. Highlight the View option and press the Select soft key
or the key to listen to the message contents.
While listening to the message, you may choose the
following options by pressing the Options soft key:
• Reply via: allows you to send a reply to the sender by sending a
text or picture message or a voice note.
• Reply all via: allows you to send a reply to All by sending a
picture message or voice note.
• Call back: places a call to the selected number.
• Forward: allows you to forward the message to another
number.
• Replay: allows you to listen to the voice note again.
• Delete: allows you to delete the voice note.
• Save address: allows you to extract the sender’s number and
URL, e-mail addresses or phone numbers from the message
text, so that you can save them in your phone’s memory.
• Save media: allows you to save the message to different areas
or to your vCard or vCalendar.
• Protection: allows you to lock the message to protect it from
being deleted.
• Properties: shows you information about the message, such
as time and date the message was received, the sender’s e-
t809.book Page 83 Tuesday, September 27, 2005 4:18 PM
84
Section 7
mail address or phone number, recipient’s e-mail address or
phone number, Cc, message size, priority, and class.
Viewing a Push Message in Inbox
A Push message is a way of delivering content (e.g.
images, ringtones, etc.) to mobile phones that are WAP
enabled. With a Push message you don't actually send the
content in the text message, you direct the mobile phone
where to get it from.
1. Select a Push message from the list and press the
Options soft key.
The following options will appear:
•View: listen to the Voice note and view message details.
•Delete: allows you to delete the selected message or all
messages.
•Sort by: allows you to sort messages by Read/Unread, Date,
Name, Type, Size, or Subject.
2. Highlight the View option and press the Select soft key
or the key to listen to the message contents.
While reading the message, you may choose the
following options by pressing the Options soft key:
• Go to URL: allows you to go to the website on your WAP
browser.
• Delete: allows you to delete the message.
• Save address: allows you to extract the sender’s number and
URL, e-mail addresses or phone numbers from the message
text, so that you can save them in your phone’s memory.
Viewing a Message When You Receive It
When a new multimedia message comes in, the display
shows the Picture Messaging Message icon.
t809.book Page 84 Tuesday, September 27, 2005 4:18 PM
Section 7: Messages 85
Sentbox
Section 7
1. Press the View soft key to view the message.
Press the Exit soft key if you want to view the message
later in the Inbox.
2. Press the Options soft key or the key to access the
various options described above.
3. When you are finished, press the key.
Sentbox
This message box stores messages that you have sent.
When you enter this menu, the list of messages in the box
displays with the recipients’ phone numbers or names, if
available in your Phonebook.
Note: By pressing the Left or Right Navigation keys, you may scroll
between Inbox, Sentbox, Outbox, and Drafts.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Using the Navigation keys, scroll to the Messages icon.
Press the Select soft key or the key to enter the
menu.
3. Highlight the Sentbox option and press the Select soft
key or the key.
4. Select a message from the list and press the Options
soft key.
5. Highlight the View option and press the Select soft key
or the key to view the message contents.
t809.book Page 85 Tuesday, September 27, 2005 4:18 PM
86
Section 7
6. To scroll through the contents, press the Up or Down
Navigation key.
While reading a message, you can choose different
options by pressing the Options soft key.
Outbox
This message box stores messages that you have
attempted to send but have not actually been sent yet.
When you enter this menu, the list of messages in the box
displays with the recipients’ phone numbers or names, if
available in your Phonebook.
Note: By pressing the Left or Right Navigation keys, you may scroll
between Inbox, Sentbox, Outbox, and Drafts.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Using the Navigation keys, scroll to the Messages icon.
Press the Select soft key or the key to enter the
menu.
3. Highlight the Outbox option and press the Select soft
key or the key.
4. Select a message from the list and press the Options
soft key.
5. Highlight the View option and press the Select soft key
or the key to view the message contents.
6. To scroll through the contents, press the Up or Down
Navigation key.
t809.book Page 86 Tuesday, September 27, 2005 4:18 PM
Section 7: Messages 87
Drafts
Section 7
While reading a message, you can choose different
options by pressing the Options soft key.
Drafts
This message box stores messages that you may want to
edit or send at a later time.
When you enter this menu, the list of messages in the box
displays.
Note: By pressing the Left or Right Navigation keys, you may scroll
between Inbox, Sentbox, Outbox, and Drafts.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Using the Navigation keys, scroll to the Messages icon.
Press the Select soft key or the key to enter the
menu.
3. Highlight the Drafts option and press the Select soft key
or the key.
4. Select a message from the list and press the Options
soft key.
5. Highlight the Edit option and press the Select soft key or
the key to edit the message contents.
6. To send the message, press the Options soft key and
highlight the Send option.
7. Press the Select soft key or the key to send the
message.
t809.book Page 87 Tuesday, September 27, 2005 4:18 PM
88
Section 7
While viewing a draft message, you can choose different
options, depending on the type of message, by pressing
the Options soft key.
Templates
Besides entering message text using the keypad keys, you
can speed message composition by including copies of
stored text (Templates) in your message.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Using the Navigation keys, scroll to the Messages icon.
Press the Select soft key or the key to enter the
menu.
3. Highlight the Templates option and press the Select soft
key or the key.
4. If you want templates for a text message, highlight the
Text template option and press the Select soft key or
the key.
You can choose from ten predefined sentences that you
can add to your text message to save time.
5. If you want templates for a picture message, highlight
the Picture messages template option and press the
Select soft key or the key.
You can choose between twelve different picture
message formats. You can then edit the parts that you
choose.
t809.book Page 88 Tuesday, September 27, 2005 4:18 PM
Section 7: Messages 89
Voice Mail Messages
Section 7
Voice Mail Messages
This menu provides you with a way of accessing your
voice mailbox, if provided by your network.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Using the Navigation keys, scroll to the Messages icon.
Press the Select soft key or the key to enter the
menu.
3. Highlight the Voice mail option and press the Select soft
key or the key.
The following options are available:
• Call voice mail: before using the Voice Mail feature, you must
enter the voice server number obtained from your service
provider. You can then select this option and press the Select
soft key or the key to listen to your messages. You can also
connect to the voice server by pressing and holding the
key in Idle mode.
• Voice server number: allows you to change the voice mail
server number, if necessary.
Note: Voice mail is a network feature. Please contact your service provider
for further details.
Delete All
This menu allows you to delete all of the messages in each
message box. Or, you can also delete all of your messages
in all message boxes at one time.
1. To select a message box to clear, press the Up or Down
Navigation key. To delete all of your messages, select
the All option.
t809.book Page 89 Tuesday, September 27, 2005 4:18 PM
90
Section 7
2. To place or remove a check mark, press the key.
3. Press the Delete soft key to delete the marked objects.
4. After you receive the Delete? confirmation, press the
Yes soft key to delete the selected message box
contents. Otherwise, press the No soft key.
Settings
In this menu, you can set up default text message, picture
message, and push message information. The last setting
you accessed is automatically activated for sending
subsequent messages.
Text message
• Service center: allows you to store or change the number of
your message center, which is required when sending
messages. You must obtain this number from your service
provider.
• Destination address: allows you to enter a number that you
would like to send all messages to. You can still message
others, but this number will always appear in the Send list.
• Validity period: allows you to set the length of time your text
messages are stored at the message center while attempts are
made to deliver them.
• Reply path: allows the recipient of your message to send you a
reply message using your message center, if your network
supports this service.
• Delivery report: allows you to activate or deactivate the report
function. When this function is activated, the network informs
you whether or not your message has been delivered.
t809.book Page 90 Tuesday, September 27, 2005 4:18 PM
Section 7: Messages 91
Broadcast Messages (SIM Dependent)
Section 7
Picture message
The following options are used to set Send and Receive
settings for Picture messages.
Send Settings
• Delivery report: when this option is enabled, the network
informs you whether or not your message has been delivered.
• Read reply: when this option is enabled, your phone sends a
request for a reply along with your message to the recipient.
• Priority: you can select the priority level of your messages.
• Expiry date: The expiration date is how long the message
receiver has to retrieve the message.
• Delivery after: you can set a delay time before the phone sends
your messages.
Receive Settings
• Anonymous reject: you can set your phone to automatically
reject anonymous messages.
• Advert allowed: allows you to receive advertisements.
• Report allowed: you can set the option to receive a delivery
report.
Broadcast Messages (SIM Dependent)
This network service allows you to receive text messages
on various topics, such as the weather or traffic.
Please contact your service provider for further details.
Instant Messaging
Instant Messaging (IM) is a way of sending short, simple
messages that are delivered immediately to users online
at that moment.
t809.book Page 91 Tuesday, September 27, 2005 4:18 PM
92
Section 7
Before using this feature, you need to subscribe to a
messenger service. For further details, contact your
service provider.
Starting your Instant Messaging
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Using the Navigation keys, scroll to the Instant
messaging icon. Press the Select soft key or the key
to enter the menu.
3. Highlight the messenger service to which you subscribed
using the Up or Down Navigation key and press the
Select soft key or the key.
4. Highlight the Sign on, Connect, or Sign in option,
depending on your messenger service and press the
Select soft key or the key.
5. Enter the required sign on information such as ID and
password and press the OK soft key.
Note: The information required for sign on will vary depending on the
instant messaging provider you are using.
6. Follow the on-screen instructions to read, reply to,
compose, send, and manage your IM account.
Using the Instant Messenger Options
On the sign-on screen of the messenger, press the Options
soft key to access the following options:
• Sign on/Connect/Sign in: allows you to login to your IM
account.
t809.book Page 92 Tuesday, September 27, 2005 4:18 PM
Section 7: Messages 93
Memory Status
Section 7
• Saved conversations: shows permanent records of your IM
conversations.
• Offline conversations: shows dynamic records of your last 10
IM conversations.
• Settings: allows you to change your Default community and
Community settings.
• Help: provides various help information depending on the
community you have selected.
Memory Status
You can check the amount of the memory being used and
the memory remaining for text, multimedia, and push
messages.
The display shows the total space including the used and
free space. You can also view how much space is currently
occupied by each message box.
t809.book Page 93 Tuesday, September 27, 2005 4:18 PM
94
Section 7
t809.book Page 94 Tuesday, September 27, 2005 4:18 PM
Section 8
Section 8: Changing Your Settings 95
Section 8: Changing Your Settings
Topics Covered
• Time & Date Settings
• Phone Settings
• Display Settings
• Sound Settings
• Network Services Settings
• Bluetooth
• Security Settings
• Memory Status
• Reset Settings
This section explains the sound and phone settings for
your phone. It includes display settings, security settings,
and extra settings associated with your phone.
t809.book Page 95 Tuesday, September 27, 2005 4:18 PM
Section 8
96
Time & Date Settings
This menu allows you to change the current time and date
displayed.
The following options are available:
• Set time: allows you to change the hour and minute.
• AM/PM: allows you to set either AM or PM.
• Time format: allows you to select whether your time is
displayed in 12 hour or 24 hour format.
• Set date: allows you to enter the month, day, and year.
• Date format: allows you to select MM/DD/YYYY, DD/MM/YYYY,
or YYYY/MM/DD format.
• Week start day: allows you to choose between Sunday or
Monday as the day your week will start.
• Auto update: allows you to receive time information from your
service provider’s network.
• On: the phone automatically updates the time and date
according to the current time zone using the network
service.
• Confirm first: the phone asks for a confirmation before the
update.
• Off: you need to manually set the time and date according to
the current time zone using the Set time menu.
To change your time and date settings:
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Using the Navigation keys, scroll to the Settings icon.
Press the Select soft key or the key to enter the
menu.
t809.book Page 96 Tuesday, September 27, 2005 4:18 PM
Section 8: Changing Your Settings 97
Phone Settings
Section 8
3. Highlight the Time & Date options and press the Select
soft key or the key.
4. Use the Up or Down Navigation key to select the option
you wish to change.
5. To set Set time or Set date, use the Left or Right key to
position the cursor over the number you wish to change.
6. Enter the desired number.
7. To change other options, use the Left or Right key to
select the desired setting.
8. When you are finished changing your settings, press the
Save soft key to save your settings. Otherwise press the
Cancel soft key.
Note: Automatic updates of time and date do not change the time you have
set for alarm settings or calendar memos.
Phone Settings
You can customize various phone settings.
Language
This menu allows you to select a display language for Text
language and Input mode. Choose from English, French,
and Spanish.
Greeting message
This menu allows you to set a greeting to be displayed
briefly when the phone is switched on.
For details about entering characters, see "Section 5:
Entering Text" on page 45.
t809.book Page 97 Tuesday, September 27, 2005 4:18 PM
Section 8
98
Slide settings
This menu allows you to set how your phone will function
when you slide your phone open or closed. The following
options are available:
• Up: Select Accept call if you want the call to be answered
when you slide your phone open. Otherwise, select None.
• Down: Select Stop operation if you want the call to be
discontinued when you slide your phone closed. Otherwise,
select Continue operation.
Volume key
This menu allows you to set how your volume key will
operate when you receive an incoming call. The following
options are available:
• Mute: when this option is selected, the volume keys will act as
a Mute button to turn the sound off when you receive a call.
• Reject: when this option is selected, the volume keys will act as
a Reject button to reject a call when it is received.
USB settings
This menu allows you to set the USB settings you will
need to plug your phone into a USB port on a PC. The
following options are available:
• Modem: when this option is selected, you can use the PC
Studio application to:
• Synchronize contacts in your calendar.
• Transfer MP3 or image files from your PC directly to your
phone’s memory.
• Use your phone as a modem in a wireless network.
t809.book Page 98 Tuesday, September 27, 2005 4:18 PM
Section 8: Changing Your Settings 99
Display Settings
Section 8
• Mass storage: select this option when you want to download
objects from a PC, such as MP3s or images, to your TransFlash
memory card.
Extra settings
You can turn the automatic redialing or answering
features on or off.
1. To turn a feature on, highlight the feature and press the
key. A check mark displays in front of the option.
2. To turn a feature off, highlight the checked feature and
press the key. The check mark no longer displays.
The following options are available:
• Auto redial: when this option is checked, the phone makes
up to ten attempts to redial a phone number after an
unsuccessful call.
Note: The interval between call attempts varies.
• Anykey answer: when this option is checked, you can
answer an incoming call by pressing any key, except the
key or the Reject soft key. To reject the call, press the
key or the Reject soft key. When this option is unchecked,
you must press the key or Accept soft key to answer a
call.
3. When you have finished changing your settings, press
the Save soft key to save your settings. Otherwise press
the Cancel soft key.
Display Settings
In this menu, you can change various settings for the
display or backlight.
t809.book Page 99 Tuesday, September 27, 2005 4:18 PM
Section 8
100
Wallpaper
This menu allows you to change the background image or
the color of the text to be displayed in Idle mode.
The following options are available:
• Get more wallpaper: this option takes you to t-zones where
you can download wallpapers.
• Default wallpapers: allows you to choose from a list of
wallpapers included with your phone.
• My photos: allows you to choose a photo from My photos
folder.
• My downloads: allows you to choose a photo from your
downloaded images folder.
To change the background image:
1. Scroll through the list by pressing the Navigation keys.
2. When the image you want highlights, press the Save soft
key if selecting from Default wallpapers. Otherwise,
press the Options soft key. Highlight the Save option and
press the Select soft key or the key.
Main menu style
This menu allows you to select how the icons will be
displayed in the main menu. Choose Block menu for the
traditional icon look or Flash menu for animated icons.
Info display
This menu allows you to set text style and text color. Press
the Left or Right Navigation key to change the settings.
t809.book Page 100 Tuesday, September 27, 2005 4:18 PM
Section 8: Changing Your Settings 101
Display Settings
Section 8
Interior display
You can select the color of the menus displayed. There are
two different patterns to choose from.
Brightness control
You can adjust the display brightness to see it better in
different lighting conditions.
Press the Left or Right Navigation key or press the
Volu m e keys to adjust the brightness.
Backlight
In this menu, you can select the length of time that the
keypad backlight is on and how much longer the display
is illuminated before going off.
The On setting is how long the keypad backlight is on. You
can select 15 seconds, 30 seconds, 1 minute, 3 minutes, or
10 minutes.
The Dim option is how much longer after the keypad
backlight goes off that the display remains lit. You can
select Off, 5 seconds, 15 seconds, 30 seconds, 1 minute or
3 minutes.
For example, if you set On for 30 seconds and Dim for 5
seconds, after 30 seconds the backlight on the keys would
turn off and 5 seconds later the display light would turn
off.
Press the Left or Right Navigation key to adjust the
settings.
t809.book Page 101 Tuesday, September 27, 2005 4:18 PM
Section 8
102
Dialing display
This menu allows you to select the size and color of your
dialing font. You can also set your background color.
To change the size of the font:
1. Highlight the Font size option and press the Select soft
key or the key.
2. Use the Left or Right key to select between Large,
Medium, or Small.
3. Press the Save soft key or the key to save your
change. Otherwise, press the Cancel soft key.
To change the color of the font:
1. Highlight the Font color option and press the Select soft
key or the key.
2. Use the Left or Right key to select either Basic (black),
Rainbow, Monochrome, or Gradation.
3. Press the Save soft key or the key to save your
change. Otherwise, press the Cancel soft key.
To change the background color:
1. Highlight the Background color option and press the
Select soft key or the key.
2. Use the Left or Right key to select between 10 different
colors or None.
3. Press the Save soft key or the key to save your
change. Otherwise, press the Cancel soft key.
t809.book Page 102 Tuesday, September 27, 2005 4:18 PM
Section 8: Changing Your Settings 103
Sound Settings
Section 8
Calendar
This menu allows you to set a calendar to display over the
top of your wallpaper in Idle mode. Choose between On
or Off. The Calendar is set to Off by default.
Show caller information
By turning this option on, when you miss a call, caller
information such as name will be displayed on your
display when your missed calls are listed.
Sound Settings
You can customize various sound settings for your phone.
Incoming call
Get more mega tones
Using the Get more mega tones option, you can access the
web site preset by T-Mobile and download new sounds.
Get more HiFi Ringers
Using the Get More HiFi Ringers option, you can access
the web site preset by T-Mobile and download new HiFi
Ringers.
Ring tone
This menu allows you to select a ring melody. Highlight
Ring tone and press the key. Use the Up or Down key
to highlight a ring tone. Press the Select soft key or press
the key.
Volume
This menu allows you to adjust the ring volume to one of
5 levels.
t809.book Page 103 Tuesday, September 27, 2005 4:18 PM
Section 8
104
Use the Right or Left key to increase or decrease the
volume.
Alert type
This menu allows you to specify how you are to be
informed of incoming calls. Use the Right or Left key to
select a ring tone.
The following options are available:
• Melody: the phone rings using the ring melody selected in the
Ringtone menu.
• Vibration: the phone vibrates but does not ring.
• Vibration then melody: the phone vibrates 3 times and then
starts ringing.
Keypad tone
This menu allows you to select the key tone and volume
that the phone sounds when you press a key.
Use the Right or Left key to make your selections.
To turn off the sound, select Off.
Message tone
This menu allows you to set up the ringer for incoming
messages and email. You can set the Tone, Alert type, and
Repetition.
Use the Right or Left key to make your selections.
Power on/off
This menu allows you to select the melody that the phone
sounds when it is switched on and off.
To turn off the sound, select Off.
t809.book Page 104 Tuesday, September 27, 2005 4:18 PM
Section 8: Changing Your Settings 105
Sound Settings
Section 8
Slide tone
This menu allows you to select the melody that the phone
sounds when you slide open or close your phone.
To turn off the sound, select Off.
Silent mode
This menu allows you to select whether or not your
phone will vibrate while in quiet mode. You may choose
between Vibration and Mute.
Extra tones
You can customize additional tones for the phone.
1. To turn a given tone on, press the key. A check mark
displays in front of the option.
2. To turn a given tone off, press the key. The check
mark no longer displays in front of the option.
The following options are available:
• Indicative tones: generates a tone whenever a pop-up window
appears on the screen.
• Minute minder: sets whether or not the phone beeps every
minute during an outgoing call to keep you informed of the
length of your call.
• Connection tone: sets whether or not the phone beeps when
your call is connected to the system.
• Alerts on call: sets whether or not you receive tones when a
message arrives while you are on a call.
t809.book Page 105 Tuesday, September 27, 2005 4:18 PM
Section 8
106
Network Services Settings
Call forwarding
This network service enables incoming calls to be
rerouted to the number that you specify.
Example: You may wish to forward your business calls to a colleague while
you are on holiday.
To set your call forwarding options:
1. Select a call forwarding option by pressing the Up or
Down Navigation key and then press the Select soft key
or the key.
The following options are available:
•Forward always: all calls are forwarded.
•Busy: calls are forwarded when your phone is busy.
•No reply: calls are forwarded when your phone is not
answered.
•Unreachable: calls are forwarded when you are not in an
area covered by your service provider or when your phone is
switched off.
•Cancel all: all call forwarding options are canceled.
2. Select the type of calls, Voice calls or Data calls, by
pressing the Up or Down Navigation key, and then press
the Select soft key or the key.
The current status displays. If the option has already
been set, the number to which the calls are forwarded
displays.
3. To activate call forwarding, select Activate by using the
Left or Right key.
t809.book Page 106 Tuesday, September 27, 2005 4:18 PM
Section 8: Changing Your Settings 107
Network Services Settings
Section 8
4. To deactivate call forwarding, select Deactivate by
using the Left or Right key.
5. Enter the number to which the calls are to be forwarded
in the Forward to text box and press the Select soft key
or the key.
To enter an international code, press and hold the
key until the + sign displays.
6. When you select Unavailable in step 1, select the length
of time the network waits for before forwarding a call.
The phone sends your settings to the network and the
network’s acknowledgement displays.
Call barring (SIM Dependent)
Call Barring allows you to restrict specific types of
incoming and outgoing calls for your phone. This is useful
if you allow someone to use your phone for a short period
of time.
Call waiting
This network service informs you when someone is trying
to reach you during another call.
You can specify individual call waiting options for voice
calls and/or data calls.
To set your call waiting options:
1. Select the type of calls, Voice calls or Data calls, to
which the call waiting option is to be applied by pressing
the Up or Down Navigation key and then press the
Select soft key or the key.
t809.book Page 107 Tuesday, September 27, 2005 4:18 PM
Section 8
108
The screen informs you whether call waiting is activated
or deactivated.
2. Highlight Activate or Deactivate and press the Select
soft key or the key.
3. Call waiting will then be activated or deactivated.
4. Select the Cancel all option to deactivate Call waiting on
all voice and data calls.
Network selection
The Network Selection feature enables you to
automatically or manually select the network used when
roaming outside of your home area.
Note: You can select a network other than your home network only if there
is a valid roaming agreement between the two.
To change Network Selection mode:
1. Highlight the Search Now option and press the Select
soft key or the key.
2. Press the Up or Down Navigation key until the network
you want highlights and then press the Select soft key or
the key.
The phone will scan for that network and you will be
connected.
To change you Default setup:
1. Highlight the Default Setup option and press the Select
soft key or the key.
2. Highlight either the Automatic or Manual option and
press the Select soft key or the key.
t809.book Page 108 Tuesday, September 27, 2005 4:18 PM
Section 8: Changing Your Settings 109
Bluetooth
Section 8
If you select Automatic, you are connected to the first
available network when roaming.
3. If you select Manual, press the Up or Down Navigation
key until the network you want highlights and then press
the Select soft key or the key.
The phone will scan for that network and you will be
connected.
Caller ID
You can prevent your phone number from being
displayed on the phone of the person being called.
Note: Some networks do not allow you to change this setting.
The following options are available:
• Default: the default setting provided by the network is used.
• Hide number: your number does not display on the other
person’s phone.
• Send number: your number is sent each time you make a call.
Bluetooth
About Bluetooth
Bluetooth is a short-range wireless communications
technology capable of exchanging information over a
distance of about 30 feet without requiring a physical
connection.
Unlike infrared, you don't need to line up the devices to
beam information with Bluetooth. If the devices are
within a range of one another, you can exchange
t809.book Page 109 Tuesday, September 27, 2005 4:18 PM
Section 8
110
information between them, even if they are located in
different rooms.
The following Bluetooth options are available:
Activation
This option allows you to turn Bluetooth On or Off. Make
a selection and press the Select soft key or the key.
My devices
This option allows you to search for new Bluetooth
devices. Highlight the Search new device option and
press the Select soft key or the key. The phone will
search for available devices.
My phone’s visibility
This option allows you to turn your visibility to On or Off.
Make a selection and press the Select soft key or the
key.
My phone’s name
This option shows the name given to your phone for
Bluetooth purposes. You can edit the name if needed.
Secure mode
This option allows you to turn your secure mode to On or
Off. Make a selection and press the Select soft key or the
key.
Features
Actually, the Bluetooth specification is a protocol that
describes how the short-range wireless technology
works, whereas individual profiles describe the services
t809.book Page 110 Tuesday, September 27, 2005 4:18 PM
Section 8: Changing Your Settings 111
Security Settings
Section 8
supported by individual devices. Profiles reduce the
chance that different devices will not work together.
The following Service profiles are available:
• Headset: The remote Bluetooth headset enables outgoing and
incoming calls.
• Handsfree: The remote Bluetooth car kit enables outgoing and
incoming calls.
• File transfer: The remote Bluetooth device enables users to
transfer files from their handset to others.
• Object push: The remote Bluetooth device enables the transfer
of personal data (e.g. vCard, vCalendar, etc.) to other devices.
• Dial up networking: The remote Bluetooth device enables
Internet access through a phone modem.
• Serial port: The remote Bluetooth device acts as a virtual serial
port.
Help
The Help option sends you to t-zones where you can
search for additional information.
Security Settings
The Security feature enables you to restrict the use of your
phone by others and to restrict the types of calls.
Various codes and passwords are used to protect the
features of your phone.
PIN check
When the PIN Check feature is enabled, you must enter
your PIN each time you switch on the phone.
Consequently, any person who does not have your PIN
cannot use your phone without your approval.
t809.book Page 111 Tuesday, September 27, 2005 4:18 PM
Section 8
112
Note: Before enabling or disabling the PIN Check feature, you must enter
your PIN.
The following options are available:
• Disable: the phone connects directly to the network when you
switch it on.
• Enable: you must enter the PIN each time the phone is
switched on.
Change PIN
This feature allows you to change your current PIN,
provided that the PIN check feature is enabled. You must
enter the current PIN before you can specify a new one.
Once you have entered a new PIN, you are asked to
confirm it by entering it again.
Phone lock
When the Phone lock feature is enabled, the phone is
locked and you must enter the 4- to 8-digit phone
password each time the phone is switched on.
The password is preset to “00000000” at the factory. To
change the phone password, see "Change password" on
page 113.
Once the correct password has been entered, you can use
the phone until you switch it off.
The following options are available:
• Disable: you are not asked to enter the phone password when
you switch on the phone.
• Enable: you are required to enter the phone password when
you switch on the phone.
t809.book Page 112 Tuesday, September 27, 2005 4:18 PM
Section 8: Changing Your Settings 113
Security Settings
Section 8
Change password
The Change password feature allows you to change your
current phone password to a new one. You must enter the
current password before you can specify a new one.
The password is preset to “00000000” at the factory. Once
you have entered a new password, you are asked to
confirm it by entering it again.
Privacy
Using this menu, you can lock your media contents, such
as picture messages, voice messages, voice notes, call
records, phonebook, images, sounds, music, and videos.
Once you have locked the contents, you must enter the
phone’s password to access the associated menus.
1. To select an item to lock, press the Up or Down
Navigation key. To lock all of the contents, select Phone
privacy.
2. To place a check mark, press the key.
3. To remove a check mark, press the key.
4. To lock the marked items, press the Save soft key.
5. Enter a password and press the OK soft key or the
key.
Note: The password is preset to “00000000” at the factory.
To change this password, see "Change password" on page
113.
FDN mode
FDN (Fixed Dial Number) mode, if supported by your
SIM card, allows you to restrict your outgoing calls to a
limited set of phone numbers.
t809.book Page 113 Tuesday, September 27, 2005 4:18 PM
Section 8
114
The following options are available:
• Disable: you can call any number.
• Enable: you can only call phone numbers stored in Phonebook.
You must enter your PIN2. You can obtain your PIN2 from your
service provider.
Change PIN2
The Change PIN2 feature allows you to change your
current PIN2 to a new one. You must enter the current
PIN2 before you can specify a new one. Once you have
entered a new PIN2, you are asked to confirm it by
entering it again.
Note: Not all SIM cards have a PIN2. If your SIM card does not, this menu
does not display.
Memory Status
You can check the amount of the memory being used and
the memory remaining for messages, File manager,
Calendar, Phonebook, and Games.
The display shows the total space including the used and
free space. You can also view how much space is currently
occupied by each message box.
You can also check how many names and numbers are
stored in Phonebook, in both SIM card and the phone
memory. You can also see the capacity of both memories.
In any of the Memory status menus, you can press the Left
or Right navigation keys to scroll through different
categories.
t809.book Page 114 Tuesday, September 27, 2005 4:18 PM
Section 8: Changing Your Settings 115
Reset Settings
Section 8
Reset Settings
From this menu you can reset your phone and sound
settings to the default settings.
The following options are available:
• All: Phone, Display, and Sound settings will be returned to
default values.
• Phone settings: only phone settings will be returned to
default values.
• Display settings: only display settings will be returned to
default values.
• Sound settings: only sound settings will be returned to
default values.
To reset your settings:
1. Highlight one of the options and press the key to
place a check mark next to the option.
2. Press the Reset soft key.
3. You will be prompted with Reset settings?. Press the
Yes soft key.
4. Enter the 4- to 8-digit password and press the OK soft
key or the key. You will receive a Reset confirmation
message.
The password is preset to “00000000.” To change this
password, see "Change password" on page 113.
t809.book Page 115 Tuesday, September 27, 2005 4:18 PM
Section 8
116
t809.book Page 116 Tuesday, September 27, 2005 4:18 PM
Section 9: Fun & Apps 117
Section 9
Section 9: Fun & Apps
Topics Covered
• File Manager
• MP3 Player
• Games
• Image Editor
•Organizer
This section outlines the various applications that are
available on your phone.
t809.book Page 117 Tuesday, September 27, 2005 4:18 PM
118
Section 9
File Manager
File Manager allows you to manage your sounds, images,
and videos in one convenient location.
Sounds
In this menu, you can view the list of sounds downloaded
from the web server or received in multimedia messages.
You can set a downloaded sound as the current ring tone.
The following options are available:
Get more MegaTones
Using the Get More MegaTones option on the sounds list,
you can access the web site preset by T-Mobile and
download new sounds.
Get more HiFi Ringers
Using the Get More HiFi Ringers option on the sounds
list, you can access the web site preset by T-Mobile and
download new HiFi Ringers.
My sounds
Highlight an item in the My sounds menu and press the
Options soft key or the key. The following options are
available:
• Download new: takes you to t-zones where you can download
new sounds.
• Play: plays the sound.
• Send via: allows you to send the sound via Picture message or
Bluetooth.
• Set as: allows you to set the sound as your Ringtone, a Caller
ringtone, or an Alarm tone.
t809.book Page 118 Tuesday, September 27, 2005 4:18 PM
Section 9: Fun & Apps 119
File Manager
Section 9
• Move to Memory card: allows you to move the sound to your
TransFlash memory card.
• Copy to Memory card: allows you to copy the sound to your
TransFlash memory card.
• Delete: allows you to delete the sound or delete all sounds.
• Rename: allows you to change the name of the sound.
• Share for Bluetooth: allows the sound to be shared or released
for the use of another Bluetooth device.
• Protection: allows you to lock the sound to protect it from
deletion.
• Properties: displays the sound name, date, format, length,
size, and protection.
Voice list
The Voice list contains your recorded audio messages.
Highlight an item in the Voice list menu and press the
Options soft key or the key. The following options are
available:
• Play: plays the audio message.
• Send via: allows you to send the audio message via Picture
message or Bluetooth.
• Set as: allows you to set the audio message as your Ringtone,
Caller ringtone, or Alarm tone.
• Move to Memory card: allows you to move the audio message
to your TransFlash memory card.
• Copy to Memory card: allows you to copy the audio message
to your TransFlash memory card.
• Delete: allows you to delete the audio message or delete all
audio messages.
• Rename: allows you to change the name of the audio message.
t809.book Page 119 Tuesday, September 27, 2005 4:18 PM
120
Section 9
• Share for Bluetooth: allows the audio message to be shared or
released for the use of another Bluetooth device.
• Protection: allows you to lock the audio message to protect it
from deletion.
• Properties: displays the audio message name, date, format,
length, size, and protection.
Images
In this menu, you can view the list of images downloaded
from the web server or received in messages. You can set
a downloaded image as the current background image.
The following options are available:
Get More Wallpapers
Using the Get More Wallpapers option, you can access
the web site preset by T-Mobile and download new
images.
My Album
This menu provides the ability for you to view the photos
you have stored on the t-zone browser. Use the following
procedures to access My Album.
1. In your t-zone browser, select the My Albums Menu link
and press the Select soft key or the key.
2. Photos sent to this folder are stored in the Inbox Album.
Press the Select soft key to view the photos.
3. Press the key to exit t-zones and return to the Idle
screen.
My Journal
This menu provides the ability for you to store your
photos using the t-zone browser.
t809.book Page 120 Tuesday, September 27, 2005 4:18 PM
Section 9: Fun & Apps 121
File Manager
Section 9
My downloads
This menu allows you to access your downloaded images.
Scroll to the image you want to view. By pressing the
Options soft key you can access the following options:
• Download new: takes you to t-zones where you can download
new images.
• View: displays the image.
• Send via: allows you to send the image via Picture message or
Bluetooth.
• Set as: allows you to set the image as Wallpaper or as a Caller
ID.
• Move to Memory card: allows you to move the item to the
TransFlash memory card.
• Copy to Memory card: allows you to copy the item to the
TransFlash memory card.
• Delete: allows you to delete the image.
• Rename: allows you to change the name of the item.
• Display mode: allows you to see your images displayed in a
Line view or in Thumbnail view.
• Slide show: allows you to see all of your photos in a slide show
presentation.
• Share for Bluetooth: allows the image to be shared or released
for the use of another Bluetooth device.
• Protection: allows you to lock the image to protect it from
deletion.
• Properties: displays the image name, date, format, resolution,
size, quality, and protection.
t809.book Page 121 Tuesday, September 27, 2005 4:18 PM
122
Section 9
My photos
In this menu you can review the photos you’ve taken.
Highlight a photo and press the Options soft key to
choose from the following options:
• View: displays the photo.
• Send to My Album: sends the photo to My Album.
• Send via: allows you to send the image via Picture message or
Bluetooth.
• Default destination: allows you to remove or replace the
default destination.
• Set as: allows you to set the photo as Wallpaper or as a Caller
ID.
• Edit image: takes you to the Image editor screen where you
can add emoticons or frames to your photos or apply special
effects.
• Move to Memory card: allows you to move the photo to the
TransFlash memory card.
• Copy to Memory card: allows you to copy the photo to the
TransFlash memory card.
• Delete: allows you to delete the photo.
• Rename: allows you to change the name of the photo.
• Display mode: allows you to see your images displayed in a
Line view or in Thumbnail view.
• Slide Show: allows you to see all of your photos in a slide show
presentation.
• Share for Bluetooth: allows the photo to be shared or released
for the use of another Bluetooth device.
• Protection: allows you to lock the image to protect it from
deletion.
t809.book Page 122 Tuesday, September 27, 2005 4:18 PM
Section 9: Fun & Apps 123
File Manager
Section 9
• Properties: displays the image name, date, format, resolution,
size, quality, and protection.
Videos
In this menu, you can view a list of videos downloaded
from the web server or received in multimedia messages.
The following options are available:
Downloaded videos
This menu allows you to access your downloaded video
clips.
Scroll to the video you want to view. By pressing the
Options soft key you can access the following options:
• Play: plays the video.
• Send via: allows you to send the video via Picture message or
Bluetooth.
• Set as caller ID: allows you to set the video as a Caller ID.
• Move to Memory card: allows you to move the video to the
TransFlash memory card.
• Copy to Memory card: allows you to copy the video to the
TransFlash memory card.
• Delete: allows you to delete the video.
• Rename: allows you to change the name of the video.
• Display mode: allows you to see your videos displayed in a
Line view or in Thumbnail view.
• Share for Bluetooth: allows the video to be shared or released
for the use of another Bluetooth device.
• Protection: allows you to lock the video to protect it from
deletion.
t809.book Page 123 Tuesday, September 27, 2005 4:18 PM
124
Section 9
• Properties: displays the video name, date, format, resolution,
size, length, quality, and protection.
My videos
In this menu you can review the photos you’ve taken.
Highlight a video and press the Options soft key to
choose from the following options:
• Play: plays the video.
• Send via: allows you to send the video via Picture message or
Bluetooth.
• Set as caller ID: allows you to set the video as a Caller ID.
• Move to Memory card: allows you to move the video to the
TransFlash memory card.
• Copy to Memory card: allows you to copy the video to the
TransFlash memory card.
• Delete: allows you to delete the video.
• Rename: allows you to change the name of the video.
• Display mode: allows you to see your videos displayed in a
Line view or in Thumbnail view.
• Share for Bluetooth: allows the video to be shared or released
for the use of another Bluetooth device.
• Protection: allows you to lock the video to protect it from
deletion.
• Properties: displays the video name, date, format, resolution,
size, length, quality, and protection.
Memory card
You can check the contents of your TransFlash memory
card and see what has been saved there. Press the Up or
Down navigation keys to scroll between Images, Videos,
Music, Sounds, and Other files.
t809.book Page 124 Tuesday, September 27, 2005 4:18 PM
Section 9: Fun & Apps 125
File Manager
Section 9
This o ption will onl y appear if a TransFlash m emory card
has been inserted in your phone.
Music
This options allows you to access your MP3 files in your
My Music folder. You can also access other MP3 files by
selecting the Sonic wellness option.
Other files
This option allows you to view other types of files that
you have stored on your phone. This includes Excel
spreadsheets, text files, wmf files, PowerPoint
presentations, PDFs, MHTML, JPEGs, GIFs, BMPs, and
Word documents. You can send these files by picture
message or Bluetooth. You can also move or copy the files
to your memory card.
Memory card
You can check the contents of your TransFlash memory
card and see what has been saved there. Press the Up or
Down navigation keys to scroll between Images, Videos,
Music, Sounds, and Other files.
This o ption will onl y appear if a TransFlash m emory card
has been inserted in your phone.
Memory status
You can check the amount of memory being used and
memory remaining for sounds, music, images, and
videos. Press the Left or Right keys to scroll between the
memory status of Fun & Apps, Images, Videos, Music,
Sounds, Other files, and Memory card.
t809.book Page 125 Tuesday, September 27, 2005 4:18 PM
126
Section 9
MP3 Player
The MP3 Player can be used to play files you have loaded
from your PC to your TransFlash memory card.
Note: The following characters cannot be used in the filename:
/ \ * ? “ < > : | 9
The file name is limited to 47 total characters).
1. In the Fun & Apps menu, select MP3 player and press
the Select soft key or the key.
2. Before you select an MP3, press the Options soft key to
select from the following options:
•Add music from: allows you to add music from your Phone
or memory card.
•Open: allows you to open My playlist or Current playlist.
•Settings: allows you to set these settings; repeat, shuffle,
equalize, 3D sound, visualization, MP3 skin, and volume.
3. After you select an MP3, press the Options soft key to
select from the following options:
•Play: allows you to listen to the MP3 from your phone.
•Open: allows you to open My playlist or Current playlist.
•Send via Bluetooth: allows you to send the MP3 by
Bluetooth.
•Set as: allows you to set the MP3 as an Alarm tone.
•Remove from play list: removes the MP3 from your
current playlist.
•Settings: allows you to set these settings; repeat, shuffle,
equalize, 3D sound, visualization, MP3 skin, and volume.
•Properties: allows you to view MP3 name, date, format,
bitrate, length, size, and protection.
t809.book Page 126 Tuesday, September 27, 2005 4:18 PM
Section 9: Fun & Apps 127
Games
Section 9
4. Highlight the Open option and press the Select soft key
or the key.
5. Highlight the My playlist option and press the Select
soft key or the key.
6. Four playlists are shown, each holding up to 30 MP3s.
Highlight a playlist and press the Select soft key or the
key.
7. Press the Up or Down navigation keys to highlight the
song you want to listen to and press to play it.
8. While listening to an MP3, press the Options soft key for
the following options:
•Pause: allows you to pause the song you are listening to.
Press the to resume the song.
•Open: allows you to open My playlist or Current playlist.
•Remove from play list: removes the MP3 from your
current playlist.
•Settings: allows you to set these settings; repeat, shuffle,
equalize, 3D sound, visualization, MP3 skin, and volume.
•Properties: allows you to view MP3 name, date, format,
bitrate, length, size, and protection.
Games
You can download MIDlets (Java applications that run on
mobile phones) from various sources using t-zones and
store them in your phone.
When you access the Games menu, the list of default
games appears. Once you have downloaded games, they
are added to the list.
t809.book Page 127 Tuesday, September 27, 2005 4:18 PM
128
Section 9
Note: Java services may not be available, depending on your service
provider.
Get more games
You can download more games from the web site preset
by your service provider using the Get more games
option.
Games List
1. Scroll to the MIDlet you want on the Games list and press
the key.
2. The startup screen of the MIDlet will be displayed along
with game options. Use the Navigation keys to scroll
between options. Press the key to make a selection.
Note: MIDlet game options will differ depending on the MIDlet you select.
Image Editor
Image Editor allows you to enhance your photos and
images by adding special effects, adjusting brightness,
contrast and color, rotating or flipping, and adding frames
or clip art.
To use the Image Editor, follow these steps:
1. In the Fun & Apps menu, select Image editor and press
the Select soft key or the key.
2. The message No image loaded will appear. Press the
Options soft key.
3. Select the New image option and press the Select soft
key or the key.
t809.book Page 128 Tuesday, September 27, 2005 4:18 PM
Section 9: Fun & Apps 129
Organizer
Section 9
4. To choose an image to edit, select either My photos or
Take Photo and press the Select soft key or the key.
5. After you have selected a photo or taken a new one,
press the Load soft key. You will be returned to the
Image editor screen
6. Press the Options soft key for a list of options you can
use to edit your photo.
•New image: select another image from your My photos
folder or take another picture with your camera.
•Save: allows you to save your edited image.
•Effects: allows you to apply special effects to your image.
Choose between None, Black & White, Negative, Sepia, Blur,
Sharp, Sketch, Posterize, or Solarize.
•Adjust: allows you to adjust the brightness, contrast, and
color.
•Transform: allows you to rotate or flip your image.
•Insert: allows you to add a frame, image, or clip art to your
image.
•Set as: allows you to set your edited image as Wallpaper or
Caller ID.
•Send via: allows you to send your image in a picture
message or Bluetooth.
•Share for Bluetooth: allows the image to be shared or
released for the use of another Bluetooth device.
•Undo: allows you to undo the last action you performed on
your edited image.
Organizer
The Organizer allows you to set alarms, schedule
appointments, view the calendar, create To-Do lists,
t809.book Page 129 Tuesday, September 27, 2005 4:18 PM
130
Section 9
perform simple math calculations, check world time,
perform unit conversions, set a timer, and use a
stopwatch.
Alarm
This feature allows you to:
• set up to 3 alarms to ring at specified times.
• set the phone to switch on automatically and ring the alarm
even if the phone is switched off.
The following options are available:
• Wake-up call: the alarm rings to wake you up in the morning.
• Alarm1: set the day, time, and tone for this alarm.
• Alarm2: set the day, time, and tone for this alarm.
• Auto power: alarm rings at the specified time even if the phone
is turned off. If the option is set to Off and the phone is
switched off at the specified time, the alarm does not ring.
To set an alarm:
1. Highlight the alarm you would like to set and press the
Select soft key or the key.
2. Highlight the Alarm option and press the Right key to set
Alarm to On.
3. Press the Down key to highlight the Alarm time option.
Enter the time you want the Alarm to sound.
4. Press the Down key to highlight the AM/PM option.
Press the Left or Right key to set to AM or PM.
5. Press the Down key to highlight the Monday-Sunday
checkboxes. Press the key to bring up a list of days.
t809.book Page 130 Tuesday, September 27, 2005 4:18 PM
Section 9: Fun & Apps 131
Organizer
Section 9
6. Place a checkmark next to the days you want the alarm
to sound. To place or remove a check mark, press the
key. Press the OK soft key.
7. Press the Down key to highlight the Alarm tone option.
Press the key to bring up a list of alarm tones.
8. Press the Up or Down Navigation key to highlight an
alarm tone. Press the Select soft key or the key.
9. Press the Save soft key or the key.
10. Press the key to return to Idle mode.
Note: Your phone is preset to a 12-hour format. To change the time
format, see "Time & Date Settings" on page 96.
11. To stop the alarm when it rings, press any key.
Calendar
With the Calendar feature, you can:
• consult the calendar by month, week, or day.
• set schedules and note anniversaries
• make a To do list.
• write memos to keep track of your schedule.
• set an alarm to act as a reminder, if necessary.
• check your memory status.
When you select the Calendar menu, the following
options are available:
t809.book Page 131 Tuesday, September 27, 2005 4:18 PM
132
Section 9
Month view
When you select this option, the calendar displays the
selected month with today’s date highlighted.
At the bottom of the calendar, the following icons are
displayed along with the number of entries for each:
Schedule items
Anniversary events
To do items
Miscellaneous items
The number of entries next to each icon reflects the
number of entries for the selected day on the calendar.
The following options are available when you press the
Options soft key:
• View mode: allows you to select between Day view or Week
view of the selected day.
• Create: allows you to create a Schedule, Anniversary,
Miscellaneous, or To do event.
• Go to: allows you to see the Month view with today’s date
highlighted or a specified date.
• Delete: allows you to delete all events for a selected date, or
delete all events for preceding dates. You can also delete all
events.
Week view
When you select this option, the calendar displays the
selected week with today’s date and time highlighted.
The following options are available when you press the
Options soft key:
t809.book Page 132 Tuesday, September 27, 2005 4:18 PM
Section 9: Fun & Apps 133
Organizer
Section 9
• View mode: allows you to select between Day view or Month
view of the selected day.
• Create: allows you to create a Schedule, Anniversary,
Miscellaneous, or To do event.
• Go to: allows you to see the Week view with today’s date
highlighted or a specified date.
• Delete: allows you to delete all events for a selected date, or
delete all events for preceding dates. You can also delete all
events.
Day view
When you select this option, you are taken to the Day
view of the selected day with any events listed. The
following options are available when you press the
Options soft key:
• Create: allows you to create a Schedule, Anniversary,
Miscellaneous, or To do event.
• View mode: allows you to select between Month view or Week
view of the selected day.
Schedule
This option allows you to write memos to a schedule.
1. From Month, Week, or Day View, press the Options soft
key. Highlight the Create option and press the Select
soft key or the key.
2. Highlight the Schedule option and press the Select soft
key or the key.
3. Enter the subject in the Subject text box then press the
Down soft key.
t809.book Page 133 Tuesday, September 27, 2005 4:18 PM
134
Section 9
4. Continue to enter other information including Details,
Start date, Start time, AM/PM, End date, End time, AM/
PM, Location, Alarm, and Alarm tone. Check the Repeat
box using the key if you want to repeat the alarm.
5. When you are finished, press the Save soft key.
Your information is saved to the Schedule.
Anniversary
This option allows you to record Anniversaries in your
calendar. You can also set an alarm to remind you of
important anniversaries.
1. From Month, Week, or Day View, press the Options soft
key. Highlight the Create option and press the Select
soft key or the key.
2. Highlight the Anniversary option and press the Select
soft key or the key.
3. Enter the occasion in the Occasion text box then press
the Down soft key.
4. Continue to enter other information including Date,
Alarm, Alarm time, AM/PM, Alarm tone, and whether or
not to Repeat every year.
5. When you are finished, press the Save soft key.
Your Anniversary information is saved to the Calendar.
Miscellaneous
This option allows you to record miscellaneous dates or
events in your calendar.
1. From Month, Week, or Day View, press the Options soft
key. Highlight the Create option and press the Select
t809.book Page 134 Tuesday, September 27, 2005 4:18 PM
Section 9: Fun & Apps 135
Organizer
Section 9
soft key or the key.
2. Highlight the Miscellaneous option and press the Select
soft key or the key.
3. Enter the subject in the Subject text box then press the
Down soft key.
4. Continue to enter other information including Details,
Start date, Start time, AM/PM, End date, End time, and
AM/PM.
5. When you are finished, press the Save soft key.
Your Miscellaneous information is saved to the Calendar.
To do
This feature allows you to enter a list of tasks to be done.
1. From Month, Week, or Day View, press the Options soft
key. Highlight the Create option and press the Select
soft key or the key.
2. Highlight the To do option and press the Select soft key
or the key.
3. Enter the Item to be done in the To do text box then press
the Down soft key.
4. Continue to enter other information including Start date,
Due date, and Priority.
5. When you are finished, press the Save soft key.
Your To do list is saved to the Calendar.
t809.book Page 135 Tuesday, September 27, 2005 4:18 PM
