136

Section 9

Editing the To do List

When you select a To do list item from the Day view, the

current contents display with a status checkbox and a

priority marker.

If the item has been done, a check appears in the checkbox.

H ig h p rio ri ty ite ms h a ve a red explanation mark, Normal

priority items have a blue explanation mark, and Low

priority items have a gray explanation mark.

1. To mark an item Done, highlight the item and press the

Options soft key.

2. Highlight the Done option and press the Select soft key

or the key.

3. The status checkbox next to the To do item will be

checked.

4. To edit other fields in the To do item, highlight the item

and press the key.

5. Press the Options soft key.

6. Highlight the Edit option and press the Select soft key or

the key.

7. Edit the items you wish to change.

8. Press the Save soft key or the key.

Calculator

With this feature, you can use the phone as a calculator.

The calculator provides the basic arithmetic functions;

addition, subtraction, multiplication, and division.

1. Enter the first number using the numeric keys.

t809.book Page 136 Tuesday, September 27, 2005 4:18 PM

Section 9: Fun & Apps 137

Organizer

Section 9

2. Enter the operation for your calculation by pressing the

following navigation keys:

•Left: subtraction (-)

•Right: addition (+)

•Up: multiplication (x)

•Down: division (÷)

3. The left soft key can be used to create a decimal point and

left and right brackets.

4. Enter the next number.

5. To view the result, press the key.

Repeat steps 1 to 5 as many times as required.

World Time

This feature allows you to find out what time it is another

part of world, using the Left and Right Navigation keys.

There are two time lines available. You can set the first

setting to your home city and then use the second setting

to check other city times.

Press the Options soft key for the following options:

• Save: this allows you to save your world time settings.

• Set daylight saving time: use the key to place a

checkmark next to the cities that you want to set daylight

savings time. Each city listed represents a time zone.

Unit conversion

The conversion menu provides the following conversion

categories:

• Currency

t809.book Page 137 Tuesday, September 27, 2005 4:18 PM

138

Section 9

• Length

• Weight

• Volume

• Area

• Temperature

To convert any of the above categories, do the following:

1. Scroll to the conversion feature you wish to use and

press the Select soft key or the key.

2. Enter the quantity you want converted in the text box.

Note: To include a decimal point, press the key.

3. Use the Up, Down, Left, and Right keys to select the

From and To units of money or measure for the quantity

you want converted.

4. Press the OK soft key or the key.

Timer

You can use this menu to set a timer. To enable the Timer,

use the following options:

1. Press the Set soft key to enter the length of time.

2. Enter the time and press the OK soft key.

3. Press the key to start the timer. Press the key

again to stop the timer.

Stopwatch

This feature allows you to use a stopwatch. Press the

key to start the stopwatch. Press the Reset soft key to erase

t809.book Page 138 Tuesday, September 27, 2005 4:18 PM

Section 9: Fun & Apps 139

Organizer

Section 9

all stopwatch times recorded. Press the key for the lap

time. You can have up to 4 lap times.

t809.book Page 139 Tuesday, September 27, 2005 4:18 PM

140

Section 9

t809.book Page 140 Tuesday, September 27, 2005 4:18 PM

Section 10: Camera and Camcorder 141

Section 10

Section 10: Camera and Camcorder

Topics Covered

• Using the Camera and Camcorder

• Take and Send

• Record Video

• My Photos

• My Videos

• My Album

• My Journal

This section explains how to use the camera and

camcorder on your phone. You can take photos and video

clips using the built-in camera and camcorder.

t809.book Page 141 Tuesday, September 27, 2005 4:18 PM

142

Section 10

Using the Camera and Camcorder

Using the camera/camcorder module in your phone,

you can take photos or video clips of people or events

while on the move. Additionally, you can send photos

and video clips to other people in a Picture Messaging

message or set a wallpaper or caller ID image.

Note:

Do not take photos or videos of people without their permission.

Do not take photos or videos in places where cameras are not allowed.

Do not take photos or videos in places where you may interfere with

another person’s privacy.

Take and Send

Your camera produces photos in JPEG format.

Note: When you take a photo in direct sunlight or in bright conditions,

shadows may appear on the photo.

1. In Idle mode, press and Up navigation key to turn on the

camera.

You can also press the Menu soft key to access Menu

mode. Highlight Camera and press the Select soft key or

press the key.

2. Highlight Take and Send and press the Select soft key

or the key.

t809.book Page 142 Tuesday, September 27, 2005 4:18 PM

Section 10: Camera and Camcorder 143

Take and Send

Section 10

3. Adjust the image by aiming the camera at the subject.

Press the Left soft key to access the camera options. For

details, see "Using Camera Options" on page 143.

You can use the keypad to quickly change the camera

options.

4. Press the key to take the photo. Send To: My

Album? is displayed. Press the Yes soft key if you want

to send the photo to your T-Mobile My Album service.

The phone’s default destination is set to My Album. The

photo is automatically saved in My Photos in the phone.

Note: To change the default destination for your pictures, press the

Options soft key when Send To: My Album? appears on the display.

Highlight the Default destination option. You can then change your default

destination to a phone number, email address, Phonebook, My Album, My

Journal, or a Recent log.

5. To use the photo options, press the Options soft key.

6. To return to Capture mode, select Take another.

7. To return to Idle mode, press the key.

Using Camera Options

In Capture mode, you can use various options for the

camera by pressing the Left soft key.

The following options are available:

Record video: switches from camera to camcorder.

Shooting mode: allows you to take a photo in various

modes. Once you change the mode, the corresponding

indicator appears at the top right of the display. The

following modes are available:

t809.book Page 143 Tuesday, September 27, 2005 4:18 PM

144

Section 10

• Single shot: allows you to take a photo in the normal mode.

• Multi shot: allows you to take a series of action stills. Select the

capture speed, High Speed or Normal Speed, and the number

of photos the camera will take. When you press the key, the

camera takes photos successively.

• Mosaic shot: allows you to take several photos to combine in a

mosaic.

Effects: allows you to change the color tone or apply

special effects to the photo.

Frames: allows you to select a decorative frame. Select a

frame from the list using the Navigation keys and press

the key to save your setting.

Timer: allows you to set a time delay before the camera

takes the photo. Select the length of delay you want. When

you press key, the camera takes the photo after the

specified time has elapsed.

Go to My Photos: takes you to your My Photos folder.

Settings: allows you to change the image settings. Select

Function or Setup.

• Function:

• Size: allows you to set the image size to either

SXGA(1280X1024), Mega(1152X864), SVGA(800X600),

VGA(640x480), QVGA(320x240), Mobile(240X320), or

Frame(240X180). The selected image size displays on the

capture screen.

• View finder: allows you to set the view finder to Full screen,

Full screen & indicator, Full screen & Guideline, or Standard

ratio.

• Scene programs: allows you to choose Normal or Night

scene.

t809.book Page 144 Tuesday, September 27, 2005 4:18 PM

Section 10: Camera and Camcorder 145

Take and Send

Section 10

• Metering exposure: allows you to choose between Matrix,

Center-weighted, and Spot.

• White balance: allows you to choose between Auto,

Daylight, Incandescent, Fluorescent, Cloudy, and Sunset.

• ISO: Allows you to set ISO to Auto, 100, 200, or 400. The ISO

value is a number indicating the digital camera sensors

sensitivity to light. In bright light, set the ISO value lower.

• Setup:

• Shutter sound: allows you to select a tone for the shutter

sound. Choose between 5 tones.

• Zoom sound: allows you to turn zoom sound On or Off.

• Brightness sound: allows you to turn brightness sound On

or Off.

• Default name: allows you to change the default name

assigned to your photo.

Camera short cuts: shows you how to change options

using your keypad in capture mode. The following short

cuts are available:

Up and Down keys zoom in and out.

Left and Right keys adjust the image brightness.

Up volume key flips the image vertically.

Down volume key creates a mirror image.

changes from camera to camcorder or camcorder to camera.

changes the picture resolution.

t809.book Page 145 Tuesday, September 27, 2005 4:18 PM

146

Section 10

changes the camera shot mode.

changes the color tone or applies a special effect to the photo.

selects ISO settings.

selects a decorative frame.

sets a time delay.

takes you to My Photos menu.

changes capture mode to full screen.

adjusts the white balance.

Flipping the Camera Lens

You can flip the camera lens around so that you can see

yourself on the display and take a picture.

To flip the camera lens, slide the phone open and turn the

lens in the direction of the arrow.

Record Video

Your camcorder produces videos in 3GP format.

1. In Idle mode, press and Up navigation key to turn on the

t809.book Page 146 Tuesday, September 27, 2005 4:18 PM

Section 10: Camera and Camcorder 147

Record Video

Section 10

camera. Press the key to toggle from camera to

camcorder.

You can also press the Menu soft key to access Menu

mode. Highlight Camera and press the Select soft key or

press the key.

2. Highlight Record video and press the Select soft key or

the key.

3. Adjust the image by aiming the camcorder at the subject.

Press the Left soft key to access the camcorder options.

For details, see "Using Camcorder Options" on page 147.

You can use the keypad to quickly change the camcorder

options.

4. To start recording your video clip, press the key.

5. To stop the recording, press the Right soft key. The video

clip is automatically saved in the My videos folder.

6. To delete the video clip, press the Left soft key, highlight

Delete soft key, and press the Select soft key or the

key.

To return to Idle mode, press the key.

To access camcorder options, press the Left soft key.

Using Camcorder Options

In Capture mode, you can use various options for the

camcorder by pressing the Left soft key.

The following options are available:

Take and send: allows you to take a photo in camera

mode.

t809.book Page 147 Tuesday, September 27, 2005 4:18 PM

148

Section 10

Effects: allows you to change the color tone or apply

special effects to the video clip.

Timer: allows you to set a time delay before the camcorder

takes the video clip. Select the length of delay you want.

When you press the key, the camcorder records the

video after the specified time has elapsed.

Go to My videos: takes you to your My videos folder

where you can view your videos.

Settings: allows you to change the recording settings.

• Recording mode: allows you to change the size of your video.

Select Normal or Limit for Picture message.

• Size: allows you to set the image size to either CIF (352x288),

QVGA (320x240), QCIF(176x144), or Sub-QCIF(128x96). The

selected image size displays on the capture screen.

• View finder: allows you to set the view finder to Full screen

view, Full screen & indicator, or Standard Ratio.

• Audio Record: allows you to be able to record sounds with your

video. Set to On or Off.

• White balance: allows you to choose between Auto, Daylight,

Incandescent, Fluorescent, and Cloudy.

• Scene programs: allows you to choose Normal or Night scene.

• Zoom sound: allows you to turn zoom sound On or Off.

• Brightness sound: allows you to turn brightness sound On or

Off.

• Default name: allows you to change the default name assigned

to your video.

Camcorder short cuts: shows you how to change options

using your keypad in capture mode. The following short

cuts are available:

t809.book Page 148 Tuesday, September 27, 2005 4:18 PM

Section 10: Camera and Camcorder 149

My Photos

Section 10

Up and Down keys zoom in and out.

Left and Right keys adjust the video brightness.

Up volume key flips the image vertically.

Down volume key creates a mirror image.

changes from camera to camcorder or camcorder to camera.

changes the video resolution.

changes the shooting mode.

changes the color tone or applies a special effect to the video.

turns the audio On or Off.

sets a time delay.

takes you to My videos menu.

changes capture mode to full screen.

adjusts the white balance.

My Photos

1. In Idle mode press the Menu soft key to access the

Menu mode.

2. Highlight Camera and press the Select soft key or the

key.

3. Select My photos and press the Select soft key or the

key.

When you access this menu, your phone displays the

t809.book Page 149 Tuesday, September 27, 2005 4:18 PM

150

Section 10

photos in Thumbnail mode, which shows them as small

images. Use the Navigation keys to scroll through the

photos.

4. To view the photos on the full screen, press the key.

To go back to Thumbnail mode, press the Back soft key

or the key.

5. You can use the Left and Right navigation keys to scroll

through your photos.

Photo Album Options

In the My photos menu, press the Options soft key to use

the following options:

• View: allows you view the photo on your display.

• Send to My Album: allows you to send the photo to My Album.

• Send via: allows you to send the photo via Picture message or

Bluetooth.

• Default destination: allows you to remove or edit the default

destination.

• Set as: allows you to set the photo as your wallpaper or as a

Caller ID.

• Edit image: allows you to add emoticons or frames to your

photos or apply special effects.

• Move to Memory card: allows you to move the selected photo

or all photos to your TransFlash memory card.

• Copy to Memory card: allows you to copy the selected photo

or all photos to your TransFlash memory card.

• Delete: allows you to delete the photo or delete all photos.

• Rename: allows you to change the name of the photo.

t809.book Page 150 Tuesday, September 27, 2005 4:18 PM

Section 10: Camera and Camcorder 151

My Videos

Section 10

• Display mode: allows you to see your photos displayed in a

Line view or in Thumbnail view.

• Slide show: allows you to see all of your photos in a slide show

presentation.

• Share for Bluetooth: allows the photo to be shared or released

for the use of another Bluetooth device.

• Protection: allows you to protect the photo from being deleted.

• Properties: shows the properties of the photo, such as the file

name, file date, file format, image resolution, file size, and

protection status.

Deleting a Photo

You can delete photos one by one or all at one time.

1. From the My photos menu, select the photo you want to

delete and press the Options soft key. Highlight the

Delete option and press the Select soft key or the

key.

2. Highlight the Selected option and press the Select soft

key or the key. Or, highlight All to delete all photos.

3. Press the Yes soft key to confirm the deletion.

4. When you have finished, press the key.

My Videos

1. In Idle mode press the Menu soft key to access the

Menu mode.

2. Highlight Camera and press the Select soft key or the

key.

Select My videos and press the Select soft key or the

key.

When you access this menu, your phone displays the

t809.book Page 151 Tuesday, September 27, 2005 4:18 PM

152

Section 10

video clips in Thumbnail mode, which shows them as

small images. Use the Navigation keys to scroll through

the video clips.

3. To view the video clips on the full screen, press the

key.

My videos Options

In the My videos menu, press the Options soft key to use

the following options:

• Play: allows you to play the video clip on your display.

• Send via: allows you to send the video as part of a Picture

Messaging message or Bluetooth.

• Set as caller ID: allows you to set the video as a Caller ID.

• Move to Memory card: allows you to move the video to your

TransFlash memory card.

• Copy to Memory card: allows you to copy the video (or all

videos) to your TransFlash memory card.

• Delete: allows you to delete the selected video clip or delete all

video clips.

• Rename: allows you to change the name of the video clip.

• Display mode: allows you to see your videos displayed in a

Line view or in Thumbnail view.

• Share for Bluetooth: allows the video (or all videos) to be

shared or released for the use of another Bluetooth device.

• Protection: allows you to protect the video clip from being

deleted.

• Properties: shows the properties of the video clip, such as the

name, date, format, resolution, size, video length, quality, and

protection status.

t809.book Page 152 Tuesday, September 27, 2005 4:18 PM

Section 10: Camera and Camcorder 153

My Album

Section 10

Deleting a Video Clip

You can delete video clips one by one or all at one time.

1. From the My videos menu, use the Up or Down

Navigation key to highlight the video you want to delete

and press the Options soft key.

2. Highlight the Delete Option, then press the Right

Navigation key.

3. Highlight Selected if you only want to delete the video

clip that you selected. Highlight All if you want to delete

all video clips.

4. Press the Select soft key or the key.

5. Press the Yes soft key to confirm the deletion.

6. When you have finished, press the key to return Idle

mode.

My Album

This menu provides the ability for you to view the photos

you have stored on the t-zone website. Use the following

procedures to access My Album.

1. In Idle mode press the Menu soft key to access the

Menu mode.

2. Highlight Camera and press the Select soft key or the

key.

3. Select My Album and press the Select soft key or the

key. The browser is launched and the T-Mobile Web

page displays.

4. Select the My Albums Menu link and press the Select

soft key or the key.

t809.book Page 153 Tuesday, September 27, 2005 4:18 PM

154

Section 10

5. Photos sent to this folder are stored in the Inbox Album.

Highlight the Inbox Album link and press the key.

Highlight a photo and press the key to view the

photos.

6. Press the key to exit t-zones and return to the Idle

screen.

My Journal

This menu provides the ability for you to store your

photos using the t-zone website.

t809.book Page 154 Tuesday, September 27, 2005 4:18 PM

Section 11: t-zones 155

Section 11

Section 11: t-zones

Topics Covered

•t-zones

This section outlines the t-zones service on your phone.

For more information, contact T-Mobile.

t809.book Page 155 Tuesday, September 27, 2005 4:18 PM

156

Section 11

t-zones

Your phone is equipped with a WAP (Wireless

Application Protocol) browser to allow you to access and

navigate the Wireless Web using your phone.

To access t-zones, follow these steps:

1. In Idle mode, press the Menu soft key to access Menu

mode.

2. Using the Navigation keys, scroll to the t-zones icon.

Press the Select soft key or the key to enter the

menu.

The following options are available:

Home

Selecting this menu connects the phone to the network

and loads the t-zones homepage. You can also press the

key in Idle mode to launch the t-zones browser.

The content of the t-zones startup homepage depends on

your Wireless Web service provider. To scroll through the

screen, use the Up and Down keys.

To go to the startup homepage from any other screen in the

t-zones, use the Home option. For more information on

the t-zones menus, see "Selecting and Using Menu

Options" on page 158.

Exiting the t-zones

To exit the browser at any time, simply press the key.

Navigating the t-zones

1. To scroll through browser items, press the Up or Down

Navigation key.

t809.book Page 156 Tuesday, September 27, 2005 4:18 PM

Section 11: t-zones 157

t-zones

Section 11

2. To select browser items, press the Select soft key.

3. To return to the previous page, press the Back soft key or

the key.

4. To return to the startup homepage, press the Home soft

key.

Entering Text in the t-zones

When you are prompted to enter text, the currently active

text input mode is indicated on the screen. The following

modes are available:

• Upper-case character mode (A): allows you to enter upper-

case English characters.

• Lower-case character mode (a): allows you to enter lower-

case English characters.

Note: You can enter symbols in upper-case or lower-case character mode

by pressing the key.

• Number mode (1): allows you to enter numbers.

To change the text input mode, use the following

procedures:

1. Press the Right soft key one or more times.

2. To enter a space, press the key.

3. To edit text, set the cursor to the right of the character(s)

to be corrected.

4. Press the key as required.

5. Enter the correct character(s).

t809.book Page 157 Tuesday, September 27, 2005 4:18 PM

158

Section 11

Selecting and Using Menu Options

Various menus are available when you are using t-zones

to navigate the Wireless Web.

To access the browser options menu:

1. Press the Menu soft key.

2. Or, highlight the Openwave icon at the top of the page by

pressing the Up and Down keys and press the Select

soft key or the key.

Note: The menus may vary, depending on your version of t-zones.

The following options are available:

• Go to URL: allows you to manually enter the URL address of a

Web page. After entering an address, press the OK soft key or

key to go there directly.

• Favorites: shows the bookmarks list. You can bookmark the

current web page or access previously bookmarked pages.

• Messages: allows you to create an SMS message or check

your My messages folder.

• File manager: allows you to access Sounds, Images, Videos,

Music, Other files, Memory card, or check Memory status.

• Home: takes you back at any time to the home page of the

Wireless Web service provider.

• Back: takes you back to the previous web browser screen.

• Show URL: displays the URL address of the Web page to which

you are currently connected. It also enables you to set the

current site as the startup home page.

• Reload: reloads the current page.

t809.book Page 158 Tuesday, September 27, 2005 4:18 PM

Section 11: t-zones 159

t-zones

Section 11

Favorites

This menu stores up to 10 URL addresses.

To store a URL address:

1. Select an empty location and press the Select soft key or

the key.

2. Enter a name for the favorite item in the Name text box

and press the Down key.

3. Enter the address in the URL text box and press the

Options soft key.

4. Highlight the Save option and press the Select soft key

or the key.

Note: For further details about how to enter characters, see "Section 5:

Entering Text" on page 45.

After saving favorite items, you can access the following

options by selecting the item, then pressing the Options

soft key:

• Go: takes you to the site.

• Edit: allows you to edit the address.

• Delete: allows you to delete the address or you can delete all

addresses.

Or, you can select the favorite item and press the key.

Your browser will take you to the site.

Go to URL

This menu allows you to manually enter the URL address

of a web site that you wish to access.

For further details about entering characters, see page 45.

t809.book Page 159 Tuesday, September 27, 2005 4:18 PM

160

Section 11

Clear Cache

You can clear the information stored in the cache, which is

the phone’s temporary memory which stores the most

recently accessed Web pages.

Press the Yes soft key to confirm the deletion. Otherwise,

press the No soft key.

t809.book Page 160 Tuesday, September 27, 2005 4:18 PM

Section 12

Section 12: Health and Safety Information 161

Section 12: Health and Safety

Information

Topics Covered

• Health and Safety Information

This section outlines the safety precautions associated

with using your phone. These safety precautions should

be followed to safely use your phone.

t809.book Page 161 Tuesday, September 27, 2005 4:18 PM

Section 12

162

Health and Safety Information

Exposure to Radio Frequency (RF) Signals

Certification Information (SAR)

Your wireless phone is a radio transmitter and receiver. It

is designed and manufactured not to exceed the exposure

limits for radio frequency (RF) energy set by the Federal

Communications Commission (FCC) of the U.S.

government. These FCC exposure limits are derived from

the recommendations of two expert organizations, the

National Counsel on Radiation Protection and

Measurement (NCRP) and the Institute of Electrical and

Electronics Engineers (IEEE). In both cases, the

recommendations were developed by scientific and

engineering experts drawn from industry, government,

and academia after extensive reviews of the scientific

literature related to the biological effects of RF energy.

The exposure limit set by the FCC for wireless mobile

phones employs a unit of measurement known as the

Specific Absorption Rate (SAR). The SAR is a measure of

the rate of absorption of RF energy by the human body

expressed in units of watts per kilogram (W/kg). The FCC

requires wireless phones to comply with a safety limit of

1.6 watts per kilogram (1.6 W/kg). The FCC exposure

limit incorporates a substantial margin of safety to give

additional protection to the public and to account for any

variations in measurements.

t809.book Page 162 Tuesday, September 27, 2005 4:18 PM

Section 12: Health and Safety Information 163

Health and Safety Information

Section 12

SAR tests are conducted using standard operating

positions accepted by the FCC with the phone

transmitting at its highest certified power level in all

tested frequency bands. Although the SAR is determined

at the highest certified power level, the actual SAR level

of the phone while operating can be well below the

maximum value. This is because the phone is designed to

operate at multiple power levels so as to use only the

power required to reach the network. In general, the

closer you are to a wireless base station antenna, the lower

the power output.

Before a new model phone is available for sale to the

public, it must be tested and certified to the FCC that it

does not exceed the exposure limit established by the

FCC. Tests for each model phone are performed in

positions and locations (e.g. at the ear and worn on the

body) as required by the FCC. Body-worn operations are

restricted to Samsung-supplied, approved, or non-

Samsung designated accessories that have no metal and

must provide at least 1.3 cm separation between the

device, including its antenna (whether extended or

retracted) and the user's body. Non-compliance with the

above restrictions may result in violation of FCC RF

exposure guidelines.

The FCC has granted an Equipment Authorization for

this mobile phone with all reported SAR levels evaluated

as in compliance with the FCC RF exposure guidelines.

The maximum SAR values for this model phone as

reported to the FCC are:

t809.book Page 163 Tuesday, September 27, 2005 4:18 PM

Section 12

164

• Head: ????? W/Kg.

• Body-worn: ????? W/Kg.

SAR information on this and other model phones can be

viewed on-line at www.fcc.gov/oet/fccid. To find

information that pertains to a particular model phone,

this site uses the phone FCC ID number which is usually

printed somewhere on the case of the phone. Sometimes

it may be necessary to remove the battery pack to find the

number. Once you have the FCC ID number for a

particular phone, follow the instructions on the website

and it should provide values for typical or maximum SAR

for a particular phone. Additional product specific SAR

information can also be obtained at www.fcc.gov/cgb/

sar.

Consumer Information on Wireless Phones

The U.S. Food and Drug Administration (FDA) has

published a series of Questions and Answers for

consumers relating to radio frequency (RF) exposure

from wireless phones. The FDA publication includes the

following information:

What kinds of phones are the subject of this update?

The term wireless phone refers here to hand-held wireless

phones with built-in antennas, often called "cell,"

"mobile," or "PCS" phones. These types of wireless phones

can expose the user to measurable radio frequency energy

(RF) because of the short distance between the phone and

the user's head. These RF exposures are limited by Federal

Communications Commission safety guidelines that

were developed with the advice of FDA and other federal

health and safety agencies. When the phone is located at

t809.book Page 164 Tuesday, September 27, 2005 4:18 PM

Section 12: Health and Safety Information 165

Consumer Information on Wireless Phones

Section 12

greater distances from the user, the exposure to RF is

drastically lower because a person's RF exposure

decreases rapidly with increasing distance from the

source. The so-called "cordless phones," which have a

base unit connected to the telephone wiring in a house,

typically operate at far lower power levels, and thus

produce RF exposures well within the FCC's compliance

limits.

Do wireless phones pose a health hazard?

The available scientific evidence does not show that any

health problems are associated with using wireless

phones. There is no proof, however, that wireless phones

are absolutely safe. Wireless phones emit low levels of

radio frequency energy (RF) in the microwave range

while being used. They also emit very low levels of RF

when in the stand-by mode. Whereas high levels of RF can

produce health effects (by heating tissue), exposure to low

level RF that does not produce heating effects causes no

known adverse health effects. Many studies of low level

RF exposures have not found any biological effects. Some

studies have suggested that some biological effects may

occur, but such findings have not been confirmed by

additional research. In some cases, other researchers have

had difficulty in reproducing those studies, or in

determining the reasons for inconsistent results.

What is FDA's role concerning the safety of wireless

phones?

Under the law, FDA does not review the safety of

radiation-emitting consumer products such as wireless

phones before they can be sold, as it does with new drugs

t809.book Page 165 Tuesday, September 27, 2005 4:18 PM

Section 12

166

or medical devices. However, the agency has authority to

take action if wireless phones are shown to emit radio

frequency energy (RF) at a level that is hazardous to the

user. In such a case, FDA could require the manufacturers

of wireless phones to notify users of the health hazard and

to repair, replace or recall the phones so that the hazard no

longer exists.

Although the existing scientific data do not justify FDA

regulatory actions, FDA has urged the wireless phone

industry to take a number of steps, including the

following:

• Support needed research into possible biological effects of RF

of the type emitted by wireless phones;

• Design wireless phones in a way that minimizes any RF

exposure to the user that is not necessary for device function;

and

• Cooperate in providing users of wireless phones with the best

possible information on possible effects of wireless phone use

on human health.

FDA belongs to an interagency working group of the

federal agencies that have responsibility for different

aspects of RF safety to ensure coordinated efforts at the

federal level. The following agencies belong to this

working group:

• National Institute for Occupational Safety and Health

• Environmental Protection Agency

• Federal Communications Commission

• Occupational Safety and Health Administration

• National Telecommunications and Information Administration

t809.book Page 166 Tuesday, September 27, 2005 4:18 PM

Section 12: Health and Safety Information 167

Consumer Information on Wireless Phones

Section 12

The National Institutes of Health participates in some

interagency working group activities, as well.

FDA shares regulatory responsibilities for wireless

phones with the Federal Communications Commission

(FCC). All phones that are sold in the United States must

comply with FCC safety guidelines that limit RF

exposure. FCC relies on FDA and other health agencies

for safety questions about wireless phones.

FCC also regulates the base stations that the wireless

phone networks rely upon. While these base stations

operate at higher power than do the wireless phones

themselves, the RF exposures that people get from these

base stations are typically thousands of times lower than

those they can get from wireless phones. Base stations are

thus not the primary subject of the safety questions

discussed in this document.

What are the results of the research done already?

The research done thus far has produced conflicting

results, and many studies have suffered from flaws in

their research methods. Animal experiments

investigating the effects of radio frequency energy (RF)

exposures characteristic of wireless phones have yielded

conflicting results that often cannot be repeated in other

laboratories. A few animal studies, however, have

suggested that low levels of RF could accelerate the

development of cancer in laboratory animals. However,

many of the studies that showed increased tumor

development used animals that had been genetically

engineered or treated with cancer-causing chemicals so as

to be pre-disposed to develop cancer in absence of RF

exposure. Other studies exposed the animals to RF for up

t809.book Page 167 Tuesday, September 27, 2005 4:18 PM

Section 12

168

to 22 hours per day. These conditions are not similar to the

conditions under which people use wireless phones, so

we don't know with certainty what the results of such

studies mean for human health.

Three large epidemiology studies have been published

since December 2000. Between them, the studies

investigated any possible association between the use of

wireless phones and primary brain cancer, glioma,

meningioma, or acoustic neuroma, tumors of the brain or

salivary gland, leukemia, or other cancers. None of the

studies demonstrated the existence of any harmful health

effects from wireless phones RF exposures. However,

none of the studies can answer questions about long-term

exposures, since the average period of phone use in these

studies was around three years.

What research is needed to decide whether RF exposure

from wireless phones poses a health risk?

A combination of laboratory studies and epidemiological

studies of people actually using wireless phones would

provide some of the data that are needed. Lifetime animal

exposure studies could be completed in a few years.

However, very large numbers of animals would be

needed to provide reliable proof of a cancer promoting

effect if one exists. Epidemiological studies can provide

data that is directly applicable to human populations, but

ten or more years' follow-up may be needed to provide

answers about some health effects, such as cancer. This is

because the interval between the time of exposure to a

cancer-causing agent and the time tumors develop - if

they do - may be many, many years. The interpretation of

epidemiological studies is hampered by difficulties in

t809.book Page 168 Tuesday, September 27, 2005 4:18 PM

Section 12: Health and Safety Information 169

Consumer Information on Wireless Phones

Section 12

measuring actual RF exposure during day-to-day use of

wireless phones. Many factors affect this measurement,

such as the angle at which the phone is held, or which

model of phone is used.

What is FDA doing to find out more about the possible

health effects of wireless phone RF?

FDA is working with the U.S. National Toxicology

Program and with groups of investigators around the

world to ensure that high priority animal studies are

conducted to address important questions about the

effects of exposure to radio frequency energy (RF).

FDA has been a leading participant in the World Health

Organization international Electromagnetic Fields (EMF)

Project since its inception in 1996. An influential result of

this work has been the development of a detailed agenda

of research needs that has driven the establishment of new

research programs around the world. The Project has also

helped develop a series of public information documents

on EMF issues.

FDA and Cellular Telecommunications & Internet

Association (CTIA) have a formal Cooperative Research

and Development Agreement (CRADA) to do research

on wireless phone safety. FDA provides the scientific

oversight, obtaining input from experts in government,

industry, and academic organizations. CTIA-funded

research is conducted through contracts to independent

investigators. The initial research will include both

laboratory studies and studies of wireless phone users.

The CRADA will also include a broad assessment of

additional research needs in the context of the latest

research developments around the world.

t809.book Page 169 Tuesday, September 27, 2005 4:18 PM

Section 12

170

What steps can I take to reduce my exposure to radio

frequency energy from my wireless phone?

If there is a risk from these products - and at this point we

do not know that there is - it is probably very small. But if

you are concerned about avoiding even potential risks,

you can take a few simple steps to minimize your

exposure to radio frequency energy (RF). Since time is a

key factor in how much exposure a person receives,

reducing the amount of time spent using a wireless phone

will reduce RF exposure.

• If you must conduct extended conversations by wireless phone

every day, you could place more distance between your body

and the source of the RF, since the exposure level drops off

dramatically with distance. For example, you could use a

headset and carry the wireless phone away from your body or

use a wireless phone connected to a remote antenna.

Again, the scientific data do not demonstrate that wireless

phones are harmful. But if you are concerned about the RF

exposure from these products, you can use measures like

those described above to reduce your RF exposure from

wireless phone use.

What about children using wireless phones?

The scientific evidence does not show a danger to users of

wireless phones, including children and teenagers. If you

want to take steps to lower exposure to radio frequency

energy (RF), the measures described above would apply

to children and teenagers using wireless phones.

Reducing the time of wireless phone use and increasing

the distance between the user and the RF source will

reduce RF exposure.

t809.book Page 170 Tuesday, September 27, 2005 4:18 PM

Section 12: Health and Safety Information 171

Consumer Information on Wireless Phones

Section 12

Some groups sponsored by other national governments

have advised that children be discouraged from using

wireless phones at all. For example, the government in

the United Kingdom distributed leaflets containing such

a recommendation in December 2000. They noted that no

evidence exists that using a wireless phone causes brain

tumors or other ill effects. Their recommendation to limit

wireless phone use by children was strictly

precautionary; it was not based on scientific evidence that

any health hazard exists.

Do hands-free kits for wireless phones reduce

risks from exposure to RF emissions?

Since there are no known risks from exposure to RF

emissions from wireless phones, there is no reason to

believe that hands-free kits reduce risks. Hands-free kits

can be used with wireless phones for convenience and

comfort. These systems reduce the absorption of RF

energy in the head because the phone, which is the source

of the RF emissions, will not be placed against the head.

On the other hand, if the phone is mounted against the

waist or other part of the body during use, then that part

of the body will absorb more RF energy. Wireless phones

marketed in the U.S. are required to meet safety

requirements regardless of whether they are used against

the head or against the body. Either configuration should

result in compliance with the safety limit.

Do wireless phone accessories that claim to shield

the head from RF radiation work?

Since there are no known risks from exposure to RF

emissions from wireless phones, there is no reason to

t809.book Page 171 Tuesday, September 27, 2005 4:18 PM

Section 12

172

believe that accessories that claim to shield the head from

those emissions reduce risks. Some products that claim to

shield the user from RF absorption use special phone

cases, while others involve nothing more than a metallic

accessory attached to the phone. Studies have shown that

these products generally do not work as advertised.

Unlike "hand-free" kits, these so-called "shields" may

interfere with proper operation of the phone. The phone

may be forced to boost its power to compensate, leading

to an increase in RF absorption. In February 2002, the

Federal trade Commission (FTC) charged two companies

that sold devices that claimed to protect wireless phone

users from radiation with making false and

unsubstantiated claims. According to FTC, these

defendants lacked a reasonable basis to substantiate their

claim.

What about wireless phone interference with

medical equipment?

Radio frequency energy (RF) from wireless phones can

interact with some electronic devices. For this reason,

FDA helped develop a detailed test method to measure

electromagnetic interference (EMI) of implanted cardiac

pacemakers and defibrillators from wireless telephones.

This test method is now part of a standard sponsored by

the Association for the Advancement of Medical

instrumentation (AAMI). The final draft, a joint effort by

FDA, medical device manufacturers, and many other

groups, was completed in late 2000. This standard will

allow manufacturers to ensure that cardiac pacemakers

and defibrillators are safe from wireless phone EMI. FDA

has tested wireless phones and helped develop a

t809.book Page 172 Tuesday, September 27, 2005 4:18 PM

Section 12: Health and Safety Information 173

Consumer Information on Wireless Phones

Section 12

voluntary standard sponsored by the Institute of

Electrical and Electronic Engineers (IEEE). This standard

specifies test methods and performance requirements for

hearing aids and wireless phones so that no interference

occurs when a person uses a compatible phone and a

compatible hearing aid at the same time. This standard

was approved by the IEEE in 2000.

FDA continues to monitor the use of wireless phones for

possible interactions with other medical devices. Should

harmful interference be found to occur, FDA will conduct

testing to assess the interference and work to resolve the

problem.

Additional information on the safety of RF exposures

from various sources can be obtained from the following

organizations:

• FCC RF Safety Program:

http://www.fcc.gov/oet/rfsafety/

• Environmental Protection Agency (EPA):

http://www.epa.gov/radiation/

• Occupational Safety and Health Administration's (OSHA):

http://www.osha.gov/SLTC/radiofrequencyradiation/

index.html

• National institute for Occupational Safety and Health (NIOSH):

http://www.cdc.gov/niosh/topics/emf

• World health Organization (WHO):

http://www.who.int/peh-emf/

• International Commission on Non-Ionizing Radiation Protection:

http://www.icnirp.de

• National Radiation Protection Board (UK):

http://www.nrpb.org.uk

t809.book Page 173 Tuesday, September 27, 2005 4:18 PM

Section 12

174

• Updated 4/3/2002: US Food and Drug Administration

http://www.fda.gov/cellphones

Road Safety

Your wireless phone gives you the powerful ability to

communicate by voice, almost anywhere, anytime. But an

important responsibility accompanies the benefits of

wireless phones, one that every user must uphold.

When driving a car, driving is your first responsibility.

When using your wireless phone behind the wheel of a

car, practice good common sense and remember the

following tips:

1. Get to know your wireless phone and its features, such

as speed dial and redial. If available, these features help

you to place your call without taking your attention off

the road.

2. When available, use a hands-free device. If possible, add

an additional layer of convenience and safety to your

wireless phone with one of the many hands free

accessories available today.

3. Position your wireless phone within easy reach. Be able

to access your wireless phone without removing your

eyes from the road. If you get an incoming call at an

inconvenient time, let your voice mail answer it for you.

4. Let the person you are speaking with know you are

driving; if necessary, suspend the call in heavy traffic or

hazardous weather conditions. Rain, sleet, snow, ice and

even heavy traffic can be hazardous.

t809.book Page 174 Tuesday, September 27, 2005 4:18 PM

Section 12: Health and Safety Information 175

Road Safety

Section 12

5. Do not take notes or look up phone numbers while

driving. Jotting down a "to do" list or flipping through

your address book takes attention away from your

primary responsibility, driving safely.

6. Dial sensibly and assess the traffic; if possible, place

calls when you are not moving or before pulling into

traffic. Try to plan calls when your car will be stationary.

If you need to make a call while moving, dial only a few

numbers, check the road and your mirrors, then

continue.

7. Do not engage in stressful or emotional conversations

that may be distracting. Make people you are talking

with aware you are driving and suspend conversations

that have the potential to divert your attention from the

road.

8. Use your wireless phone to call for help. Dial 9-1-1 or

other local emergency number in the case of fire, traffic

accident or medical emergencies. Remember, it is a free

call on your wireless phone!

9. Use your wireless phone to help others in emergencies. If

you see an auto accident, crime in progress or other

serious emergency where lives are in danger, call 9-1-1

or other local emergency number, as you would want

others to do for you.

10. Call roadside assistance or a special non-emergency

wireless assistance number when necessary. If you see

a broken-down vehicle posing no serious hazard, a

broken traffic signal, a minor traffic accident where no

t809.book Page 175 Tuesday, September 27, 2005 4:18 PM

Section 12

176

one appears injured, or a vehicle you know to be stolen,

call roadside assistance or other special non-emergency

number.

"The wireless industry reminds you to use your phone safely

when driving."

For more information, please call 1-888-901-SAFE, or visit

our web-site www.wow-com.com

Provided by the Cellular Telecommunications & Internet

Association.

Operating Environment

Remember to follow any special regulations in force in

any area and always switch your phone off whenever it is

forbidden to use it, or when it may cause interference or

danger. When connecting the phone or any accessory to

another device, read its user's guide for detailed safety

instructions. Do not connect incompatible products.

As with other mobile radio transmitting equipment, users

are advised that for the satisfactory operation of the

equipment and

for the safety of personnel, it is recommended that the

equipment should only be used in the normal operating

position (held to your ear with the antenna pointing over

your shoulder if you are using an external antenna).

Using Your Phone Near Other Electronic Devices

Most modern electronic equipment is shielded from radio

frequency (RF) signals. However, certain electronic

equipment may not be shielded against the RF signals

t809.book Page 176 Tuesday, September 27, 2005 4:18 PM

Section 12: Health and Safety Information 177

Using Your Phone Near Other Electronic Devices

Section 12

from your wireless phone. Consult the manufacturer to

discuss alternatives.

Pacemakers

Pacemaker manufacturers recommend that a minimum

distance of 15 cm (6 inches) be maintained between a

wireless phone and a pacemaker to avoid potential

interference with the pacemaker.

These recommendations are consistent with the

independent research and recommendations of Wireless

Technology Research.

Persons with pacemakers:

• should always keep the phone more than 15 cm (6 inches) from

their pacemaker when the phone is switched on.

• should not carry the phone in a breast pocket.

• should use the ear opposite the pacemaker to minimize

potential interference.

If you have any reason to suspect that interference is

taking place, switch your phone off immediately.

Hearing Aid Compatibility with Mobile Phones

When some mobile phones are used near some hearing

devices (hearing aids and cochlear implants), users may

detect a buzzing, humming, or whining noise. Some

hearing devices are more immune than others to this

interference noise, and phones also vary in the amount of

interference they generate.

The wireless telephone industry has developed ratings

for some of their mobile phones, to assist hearing device

users in finding phones that may be compatible with their

t809.book Page 177 Tuesday, September 27, 2005 4:18 PM

Section 12

178

hearing devices. Not all phones have been rated. Phones

that are rated have the rating on their box or a label on the

box.

The ratings are not guarantees. Results will vary

depending on the user’s hearing device and hearing loss.

If your hearing device happens to be vulnerable to

interference, you may not be able to use a rated phone

successfully. Trying out the phone with your hearing

device is the best way to evaluate it for your personal

needs.

M-Ratings: Phones rated M3 or M4 meet FCC

requirements and are likely to generate less interference

to hearing devices than phones that are not labeled. M4 is

the better/higher of the two ratings.

T-Ratings: Ph on es ra te d T3 o r T 4 m ee t FCC req ui rem en ts

and are likely to be more usable with a hearing device’s

telecoil (“T Switch” or “Telephone Switch”) than unrated

phones. T4 is the better/higher of the two ratings. (Note

that not all hearing devices have telecoils in them.)

Hearing devices may also be measured for immunity to

this type of interference. Your hearing device

manufacturer or hearing health professional may help

you find results for your hearing device. The more

immune your hearing aid is, the less likely you are to

experience interference noise from mobile phones.

Other Medical Devices

If you use any other personal medical devices, consult the

manufacturer of your device to determine if it is

adequately shielded from external RF energy. Your

physician may be able to assist you in obtaining this

t809.book Page 178 Tuesday, September 27, 2005 4:18 PM

Section 12: Health and Safety Information 179

Potentially Explosive Environments

Section 12

information. Switch your phone off in health care

facilities when any regulations posted in these areas

instruct you to do so. Hospitals or health care facilities

may be using equipment that could be sensitive to

external RF energy.

Vehicles

RF signals may affect improperly installed or

inadequately shielded electronic systems in motor

vehicles. Check with the manufacturer or its

representative regarding your vehicle. You should also

consult the manufacturer of any equipment that has been

added to your vehicle.

Posted Facilities

Switch your phone off in any facility where posted notices

require you to do so.

Potentially Explosive Environments

Switch your phone off when in any area with a potentially

explosive atmosphere and obey all signs and instructions.

Sparks in such areas could cause an explosion or fire

resulting in bodily injury or even death.

Users are advised to switch the phone off while at a

refueling point (service station). Users are reminded of

the need to observe restrictions on the use of radio

equipment in fuel depots (fuel storage and distribution

areas), chemical plants or where blasting operations are in

progress.

Areas with a potentially explosive atmosphere are often

but not always clearly marked. They include below deck

on boats, chemical transfer or storage facilities, vehicles

t809.book Page 179 Tuesday, September 27, 2005 4:18 PM

Section 12

180

using liquefied petroleum gas (such as propane or

butane), areas where the air contains chemicals or

particles, such as grain, dust or metal powders, and any

other area where you would normally be advised to turn

off your vehicle engine.

Emergency Calls

This phone, like any wireless phone, operates using radio

signals, wireless and landline networks as well as user-

programmed functions, which cannot guarantee

connection in all conditions. Therefore, you should never

rely solely on any wireless phone for essential

communications (medical emergencies, for example).

Remember, to make or receive any calls the phone must be

switched on and in a service area with adequate signal

strength. Emergency calls may not be possible on all

wireless phone networks or when certain network

services and/or phone features are in use. Check with

local service providers.

To make an emergency call:

1. If the phone is not on, switch it on.

2. Key in the emergency number for your present location

(for example, 911 or other official emergency number).

Emergency numbers vary by location.

3. Press the key.

If certain features are in use (call barring, for example),

you may first need to deactivate those features before you

can make an emergency call. Consult this document and

your local cellular service provider.

t809.book Page 180 Tuesday, September 27, 2005 4:18 PM

Section 12

When making an emergency call, remember to give all

the necessary information as accurately as possible.

Remember that your phone may be the only means of

communication at the scene of an accident; do not cut off

the call until given permission to do so.

Restricting Children's access to your Phone

Your phone is not a toy. Children should not be allowed

to play with it because they could hurt themselves and

others, damage the phone or make calls that increase your

phone bill.

FCC Notice and Cautions

FCC Notice

This device complies with Part 15 of the FCC Rules. Operation

is subject to the following two conditions: (1) this device may not

cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause

undesired operation.

The phone may cause TV or radio interference if used in

close proximity to receiving equipment. The FCC can

require you to stop using the phone if such interference

cannot be eliminated.

Vehicles using liquefied petroleum gas (such as propane

or butane) must comply with the National Fire Protection

Standard (NFPA-58). For a copy of this standard, contact

the National Fire Protection Association, One

Batterymarch Park, Quincy, MA 02269, Attn: Publication

Sales Division.

Cautions

Changes or modifications maid in the radio phone, not

expressly approved by Samsun, will void the user's

authority to operate this equipment.

Only use approved batteries,

antennas and chargers. The use of any unauthorized

t809.book Page 181 Tuesday, September 27, 2005 4:18 PM

Section 12: Health and Safety Information 181

Section 12

182

accessories may be dangerous and void the phone

warranty if said accessories cause damage or a defect to

the phone.

Although your phone is quite sturdy, it is a complex piece

of equipment and can be broken. Avoid dropping, hitting,

bending or sitting on it.

Other Important Safety Information

• Only qualified personnel should service the phone or install the

phone in a vehicle. Faulty installation or service may be

dangerous and may invalidate any warranty applicable to the

device.

• Check regularly that all wireless phone equipment in your

vehicle is mounted and operating properly.

• Do not store or carry flammable liquids, gases or explosive

materials in the same compartment as the phone, its parts or

accessories.

• For vehicles equipped with an air bag, remember that an air bag

inflates with great force. Do not place objects, including both

installed or portable wireless equipment in the area over the air

bag or in the air bag deployment area. If wireless equipment is

improperly installed and the air bag inflates, serious injury

could result.

• Switch your phone off before boarding an aircraft. The use of

wireless phone in aircraft is illegal and may be dangerous to

the aircraft's operation.

• Failure to observe these instructions may lead to the

suspension or denial of telephone services to the offender, or

legal action, or both.

t809.book Page 182 Tuesday, September 27, 2005 4:18 PM

Section 12: Health and Safety Information 183

Product Performance

Section 12

Product Performance

Getting the Most Out of Your Signal Reception

The quality of each call you make or receive depends on

the signal strength in your area. Your phone informs you

of the current signal strength by displaying a number of

bars next to the signal strength icon. The more bars

displayed, the stronger the signal.

If you're inside a building, being near a window may give

you better reception.

Understanding the Power Save Feature

If your phone is unable to find a signal after 15 minutes of

searching, a Power Save feature is automatically

activated. If your phone is active, it periodically rechecks

service availability or you can check it yourself by

pressing any key.

Anytime the Power Save feature is activated, a message

displays on the screen. When a signal is found, your

phone returns to standby mode.

Understanding How Your Phone Operates

Your phone is basically a radio transmitter and receiver.

When it's turned on, it receives and transmits radio

frequency (RF) signals. When you use your phone, the

system handling your call controls the power level. This

power can range from 0.006 watts to 0.2 watts in digital

mode.

t809.book Page 183 Tuesday, September 27, 2005 4:18 PM

Section 12

184

Maintaining Your Phone's Peak Performance

For the best care of your phone, only authorized

personnel should service your phone and accessories.

Faulty service may void the warranty.

There are several simple guidelines to operating your

phone properly and maintaining safe, satisfactory

service.

• If your phone is equipped with an external antenna, hold the

phone with the antenna raised, fully-extended and over your

shoulder.

• Do not hold, bend or twist the phone's antenna, if applicable.

• Do not use the phone if the antenna is damaged.

• If your phone is equipped with an internal antenna, obstructing

the internal antenna could inhibit call performance.

• Speak directly into the phone's receiver.

• Avoid exposing your phone and accessories to rain or liquid

spills. If your phone does get wet, immediately turn the power

off and remove the battery. If it is inoperable, call Customer

Care for service.

Availability of Various Features/Ring Tones

Many services and features are network dependent and

may require additional subscription and/or usage

charges. Not all features are available for purchase or use

in all areas. Downloadable Ring Tones may be available at

an additional cost. Other conditions and restrictions may

apply. See your service provider for additional

information.

t809.book Page 184 Tuesday, September 27, 2005 4:18 PM

Section 12: Health and Safety Information 185

Battery Standby and Talk Time

Section 12

Battery Standby and Talk Time

Standby and talk times will vary depending on phone

usage patterns and conditions. Battery power

consumption depends on factors such as network

configuration, signal strength, operating temperature,

features selected, frequency of calls, and voice, data, and

other application usage patterns.

Battery Precautions

• Avoid dropping the cell phone. Dropping it, especially on a hard

surface, can potentially cause damage to the phone and

battery. If you suspect damage to the phone or battery, take it

to a service center for inspection.

• Never use any charger or battery that is damaged in any way.

• Use the battery only for its intended purpose.

• If you use the phone near the network's base station, it uses

less power; talk and standby time are greatly affected by the

signal strength on the cellular network and the parameters set

by the network operator.

• Follow battery usage, storage and charging guidelines found in

the user’s guide.

• Battery charging time depends on the remaining battery charge

and the type of battery and charger used. The battery can be

charged and discharged hundreds of times, but it will gradually

wear out. When the operation time (talk time and standby time)

is noticeably shorter than normal, it is time to buy a new

battery.

• If left unused, a fully charged battery will discharge itself over

time.

• Use only Samsung-approved batteries and recharge your

battery only with Samsung-approved chargers. When a charger

is not in use, disconnect it from the power source. Do not leave

the battery connected to a charger for more than a week, since

overcharging may shorten its life.

t809.book Page 185 Tuesday, September 27, 2005 4:18 PM

Section 12

186

• Do not use incompatible cell phone batteries and chargers.

Some Web sites and second-hand dealers, not associated with

reputable manufacturers and carriers, might be selling

incompatible or even counterfeit batteries and chargers.

Consumers should purchase manufacturer or carrier

recommended products and accessories. If unsure about

whether a replacement battery or charger is compatible,

contact the manufacturer of the battery or charger.

• Extreme temperatures will affect the charging capacity of your

battery: it may require cooling or warming first.

• Do not leave the battery in hot or cold places, such as in a car in

summer or winter conditions, as you will reduce the capacity

and lifetime of the battery. Always try to keep the battery at

room temperature. A phone with a hot or cold battery may

temporarily not work, even when the battery is fully charged.

Li-ion batteries are particularly affected by temperatures below

0 °C (32 °F).

• Do not place the phone in areas that may get very hot, such as

on or near a cooking surface, cooking appliance, iron, or

radiator.

• Do not get your phone or battery wet. Even though they will dry

and appear to operate normally, the circuitry could slowly

corrode and pose a safety hazard.

• Do not short-circuit the battery. Accidental short-circuiting can

occur when a metallic object (coin, clip or pen) causes a direct

connection between the + and - terminals of the battery (metal

strips on the battery), for example when you carry a spare

battery in a pocket or bag. Short-circuiting the terminals may

damage the battery or the object causing the short-circuiting.

• Do not permit a battery out of the phone to come in contact with

metal objects, such as coins, keys or jewelry.

• Do not crush, puncture or put a high degree of pressure on the

battery as this can cause an internal short-circuit, resulting in

overheating.

• Dispose of used batteries in accordance with local regulations.

In some areas, the disposal of batteries in household or

business trash may be prohibited. For safe disposal options for

t809.book Page 186 Tuesday, September 27, 2005 4:18 PM

Section 12: Health and Safety Information 187

Care and Maintenance

Section 12

Li-Ion batteries, contact your nearest Samsung authorized

service center. Always recycle. Do not dispose of batteries in a

fire.

Care and Maintenance

Your phone is a product of superior design and

craftsmanship and should be treated with care. The

suggestions below will help you fulfill any warranty

obligations and allow you to enjoy this product for many

years.

• Keep the phone and all its parts and accessories out of the

reach of small children.

• Keep the phone dry. Precipitation, humidity and liquids contain

minerals that will corrode electronic circuits.

• Do not use the phone with a wet hand. Doing so may cause an

electric shock to you or damage to the phone.

• Do not use or store the phone in dusty, dirty areas, as its moving

parts may be damaged.

• Do not store the phone in hot areas. High temperatures can

shorten the life of electronic devices, damage batteries, and

warp or melt certain plastics.

• Do not store the phone in cold areas. When the phone warms

up to its normal operating temperature, moisture can form

inside the phone, which may damage the phone's electronic

circuit boards.

• Do not drop, knock or shake the phone. Rough handling can

break internal circuit boards.

• Do not use harsh chemicals, cleaning solvents or strong

detergents to clean the phone. Wipe it with a soft cloth slightly

dampened in a mild soap-and-water solution.

• Do not paint the phone. Paint can clog the device's moving

parts and prevent proper operation.

t809.book Page 187 Tuesday, September 27, 2005 4:18 PM

Section 12

188

• Do not put the phone in or on heating devices, such as a

microwave oven, a stove or a radiator. The phone may explode

when overheated.

• If your phone is equipped with an external antenna, use only the

supplied or an approved replacement antenna. Unauthorized

antennas or modified accessories may damage the phone and

violate regulations governing radio devices.

• If the phone, battery, charger or any accessory is not working

properly, take it to your nearest qualified service facility. The

personnel there will assist you, and if necessary, arrange for

service.

t809.book Page 188 Tuesday, September 27, 2005 4:18 PM

Section 13: Warranty Information 189

Section 13

Section 13: Warranty Information

Topics Covered

• Standard Limited Warranty

t809.book Page 189 Tuesday, September 27, 2005 4:18 PM

190

Section 13

Standard Limited Warranty

What is Covered and For How Long? SAMSUNG

TELECOMMUNICATIONS AMERICA, L.P.

("SAMSUNG") warrants to the original purchaser

("Purchaser") that SAMSUNG's Phones and accessories

("Products") are free from defects in material and

workmanship under normal use and service for the

period commencing upon the date of purchase and

continuing for the following specified period of time after

that date:

Phone 1 Year

Batteries 1 Year

Leather Case/ Pouch 90 Days

Holster 90 Days

Other Phone Accessories 1 Year

What is Not Covered? This Limited Warranty is conditioned

upon proper use of Product by Purchaser. This Limited

Warranty does not cover: (a) defects or damage resulting

from accident, misuse, abuse, neglect, unusual physical,

electrical or electromechanical stress, or modification of

any part of Product, including antenna, or cosmetic

damage; (b) equipment that has the serial number

removed or made illegible; (c) any plastic surfaces or other

externally exposed parts that are scratched or damaged

due to normal use; (d) malfunctions resulting from the use

of Product in conjunction with accessories, products, or

t809.book Page 190 Tuesday, September 27, 2005 4:18 PM

Section 13: Warranty Information 191

Standard Limited Warranty

Section 13

ancillary/peripheral equipment not furnished or

approved by SAMSUNG; (e) defects or damage from

improper testing, operation, maintenance, installation, or

adjustment; (f) installation, maintenance, and service of

Product, or (g) Product used or purchased outside the

United States or Canada. This Limited Warranty covers

batteries only if battery capacity falls below 80% of rated

capacity or the battery leaks, and this Limited Warranty

does not cover any battery if (i) the battery has been

charged by a battery charger not specified or approved by

SAMSUNG for charging the battery, (ii) any of the seals

on the battery are broken or show evidence of tampering,

or (iii) the battery has been used in equipment other than

the SAMSUNG phone for which it is specified.

What are SAMSUNG's Obligations? During the applicable

warranty period, SAMSUNG will repair or replace, at

SAMSUNG's sole option, without charge to Purchaser,

any defective component part of Product. To obtain

service under this Limited Warranty, Purchaser must

return Product to an authorized phone service facility in

an adequate container for shipping, accompanied by

Purchaser's sales receipt or comparable substitute proof

of sale showing the date of purchase, the serial number of

Product and the sellers' name and address. To obtain

assistance on where to deliver the Product, call Samsung

Customer Care at 1-888-987-4357. Upon receipt,

SAMSUNG will promptly repair or replace the defective

Product. SAMSUNG may, at SAMSUNG's sole option,

use rebuilt, reconditioned, or new parts or components

when repairing any Product or replace Product with a

rebuilt, reconditioned or new Product. Repaired/

replaced leather cases, pouches and holsters will be

t809.book Page 191 Tuesday, September 27, 2005 4:18 PM

192

Section 13

warranted for a period of ninety (90) days. All other

repaired/replaced Product will be warranted for a period

equal to the remainder of the original Limited Warranty

on the original Product or for 90 days, whichever is longer.

All replaced parts, components, boards and equipment

shall become the property of SAMSUNG. If SAMSUNG

determines that any Product is not covered by this

Limited Warranty, Purchaser must pay all parts,

shipping, and labor charges for the repair or return of such

Product.

WHAT ARE THE LIMITS ON SAMSUNG'S WARRANTY/LIABILITY?

EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY

CONTAINED HEREIN, PURCHASER TAKES THE

PRODUCT "AS IS," AND SAMSUNG MAKES NO

WARRANTY OR REPRESENTATION AND THERE

ARE NO CONDITIONS, EXPRESS OR IMPLIED,

STATUTORY OR OTHERWISE, OF ANY KIND

WHATSOEVER WITH RESPECT TO THE PRODUCT,

INCLUDING BUT NOT LIMITED TO:

• THE MERCHANTABILITY OF THE PRODUCT OR ITS FITNESS FOR

ANY PARTICULAR PURPOSE OR USE;

• WARRANTIES OF TITLE OR NON-INFRINGEMENT;

• DESIGN, CONDITION, QUALITY, OR PERFORMANCE OF THE

PRODUCT;

• THE WORKMANSHIP OF THE PRODUCT OR THE COMPONENTS

CONTAINED THEREIN; OR

• COMPLIANCE OF THE PRODUCT WITH THE REQUIREMENTS OF

ANY LAW, RULE, SPECIFICATION OR CONTRACT PERTAINING

THERETO.

NOTHING CONTAINED IN THE INSTRUCTION

MANUAL SHALL BE CONSTRUED TO CREATE AN

t809.book Page 192 Tuesday, September 27, 2005 4:18 PM

Section 13: Warranty Information 193

Standard Limited Warranty

Section 13

EXPRESS WARRANTY OF ANY KIND WHATSOEVER

WITH RESPECT TO THE PRODUCT. ALL IMPLIED

WARRANTIES AND CONDITIONS THAT MAY ARISE

BY OPERATION OF LAW, INCLUDING IF

APPLICABLE THE IMPLIED WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A

PARTICULAR PURPOSE, ARE HEREBY LIMITED TO

THE SAME DURATION OF TIME AS THE EXPRESS

WRITTEN WARRANTY STATED HEREIN. SOME

STATES/PROVINCES DO NOT ALLOW

LIMITATIONS ON HOW LONG AN IMPLIED

WARRANTY LASTS, SO THE ABOVE LIMITATION

MAY NOT APPLY TO YOU. IN ADDITION, SAMSUNG

SHALL NOT BE LIABLE FOR ANY DAMAGES OF ANY

KIND RESULTING FROM THE PURCHASE, USE, OR

MISUSE OF, OR INABILITY TO USE THE PRODUCT

OR ARISING DIRECTLY OR INDIRECTLY FROM THE

USE OR LOSS OF USE OF THE PRODUCT OR FROM

THE BREACH OF THE EXPRESS WARRANTY,

INCLUDING INCIDENTAL, SPECIAL,

CONSEQUENTIAL OR SIMILAR DAMAGES, OR LOSS

OF ANTICIPATED PROFITS OR BENEFITS, OR FOR

DAMAGES ARISING FROM ANY TORT (INCLUDING

NEGLIGENCE OR GROSS NEGLIGENCE) OR FAULT

COMMITTED BY SAMSUNG, ITS AGENTS OR

EMPLOYEES, OR FOR ANY BREACH OF CONTRACT

OR FOR ANY CLAIM BROUGHT AGAINST

PURCHASER BY ANY OTHER PARTY. SOME STATES/

PROVINCES DO NOT ALLOW THE EXCLUSION OR

LIMITATION OF INCIDENTAL OR CONSEQUENTIAL

DAMAGES, SO THE ABOVE LIMITATION OR

EXCLUSION MAY NOT APPLY TO YOU. THIS

t809.book Page 193 Tuesday, September 27, 2005 4:18 PM

194

Section 13

WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS,

AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH

VARY FROM STATE TO STATE/PROVINCE TO

PROVINCE. THIS LIMITED WARRANTY SHALL NOT

EXTEND TO ANYONE OTHER THAN THE ORIGINAL

PURCHASER OF THIS PRODUCT AND STATES

PURCHASER'S EXCLUSIVE REMEDY. IF ANY

PORTION OF THIS LIMITED WARRANTY IS HELD

ILLEGAL OR UNENFORCEABLE BY REASON OF ANY

LAW, SUCH PARTIAL ILLEGALITY OR

UNENFORCEABILITY SHALL NOT AFFECT THE

ENFORCEABILITY FOR THE REMAINDER OF THIS

LIMITED WARRANTY WHICH PURCHASER

ACKNOWLEDGES IS AND WILL ALWAYS BE

CONSTRUED TO BE LIMITED BY ITS TERMS OR AS

LIMITED AS THE LAW PERMITS. THE PARTIES

UNDERSTAND THAT THE PURCHASER MAY USE

THIRD-PARTY SOFTWARE OR EQUIPMENT IN

CONJUNCTION WITH THE PRODUCT. SAMSUNG

MAKES NO WARRANTIES OR REPRESENTATIONS

AND THERE ARE NO CONDITIONS, EXPRESS OR

IMPLIED, STATUTORY OR OTHERWISE, AS TO THE

QUALITY, CAPABILITIES, OPERATIONS,

PERFORMANCE OR SUITABILITY OF ANY

THIRDPARTY SOFTWARE OR EQUIPMENT,

WHETHER SUCH THIRD-PARTY SOFTWARE OR

EQUIPMENT IS INCLUDED WITH THE PRODUCT

DISTRIBUTED BY SAMSUNG OR OTHERWISE,

INCLUDING THE ABILITY TO INTEGRATE ANY

SUCH SOFTWARE OR EQUIPMENT WITH THE

PRODUCT. THE QUALITY, CAPABILITIES,

OPERATIONS, PERFORMANCE AND SUITABILITY

t809.book Page 194 Tuesday, September 27, 2005 4:18 PM

Section 13: Warranty Information 195

Standard Limited Warranty

Section 13

OF ANY SUCH THIRD-PARTY SOFTWARE OR

EQUIPMENT LIE SOLELY WITH THE PURCHASER

AND THE DIRECT VENDOR, OWNER OR SUPPLIER

OF SUCH THIRD-PARTY SOFTWARE OR

EQUIPMENT, AS THE CASE MAY BE.

This Limited Warranty allocates risk of Product failure

between Purchaser and SAMSUNG, and SAMSUNG's

Product pricing reflects this allocation of risk and the

limitations of liability contained in this Limited

Warranty. The agents, employees, distributors, and

dealers of SAMSUNG are not authorized to make

modifications to this Limited Warranty, or make

additional warranties binding on SAMSUNG.

Accordingly, additional statements such as dealer

advertising or presentation, whether oral or written, do

not constitute warranties by SAMSUNG and should not

be relied upon.

Samsung Telecommunications America, L.P.

1301 East Lookout Drive

Richardson, Texas 75082

Phone: 1-800-SAMSUNG

Phone: 1-888-987-HELP (4357)

reserved.

No reproduction in whole or in part allowed without

prior written approval. Specifications and availability

subject to change without notice.

t809.book Page 195 Tuesday, September 27, 2005 4:18 PM

196

Section 13

Intellectual Property Statement

All Intellectual Property, as defined below, owned by or

which is otherwise the property of Samsung or its

respective suppliers relating to the SAMSUNG Phone,

including but not limited to, accessories, parts, or

software relating thereto (the "Phone System"), is

proprietary to Samsung and protected under federal

laws, state laws, and international treaty provisions.

Intellectual Property includes, but is not limited to,

inventions (patentable or unpatentable), patents, trade

secrets, copyrights, software, computer programs, and

related documentation and other works of authorship.

You may not infringe or otherwise violate the rights

secured by the Intellectual Property. Moreover, you agree

that you will not (and will not attempt to) modify, prepare

derivative works of, reverse engineer, decompile,

disassemble, or otherwise attempt to create source code

from the software. No title to or ownership in the

Intellectual Property is transferred to you. All applicable

rights of the Intellectual Property shall remain with

SAMSUNG and its suppliers.

t809.book Page 196 Tuesday, September 27, 2005 4:18 PM

Section 13: Warranty Information 197

Samsung Telecommunications America (STA), Inc.

Section 13

Samsung Telecommunications America (STA),

Inc.

Internet Address: http://www.samsungusa.com

is a registered trademark of Samsung Electronics

America, Inc. and its related entities.

Headquarters: Customer Care Center:

1301 E. Lookout Drive 1000 Klein St.

Richardson, TX 75082 Plano, TX 75074

Tel: 972.761.7000 Toll Free Tel: 1.888.987.HELP (4357)

Openwave® is a registered Trademark of Openwave, Inc.

RSA® is a registered Trademark RSA Security, Inc.

t809.book Page 197 Tuesday, September 27, 2005 4:18 PM

198

Section 13

t809.book Page 198 Tuesday, September 27, 2005 4:18 PM

199

Index

ABC mode 46, 47

Accessing a Menu Function

Alert type 104

Backlight

description 18

settings 101

Battery

charging 8

installing 8

low indicator 9

removing 6

Bluetooth

About 109

Settings 109

Broadcast Messages 91

Calendar 131

Call Barring 107

Call Functions 21

Adjusting the Call Volume 24

Answering a Call 24

Call Records 25

Correcting the Number 22

Ending a Call 22

Making a Call 22

Making a Call from Phone-

book 23

Redialing Last Number 22

Silent mode 28

Call Records

All calls 25

Call time 28

Delete all 27

Incoming calls 27

Missed calls 26

Outgoing calls 27

Call Waiting 34, 107

Caller group 60

Caller ID 109

Camcorder 141

recording video 146

Camera 141

taking photos 142

Change password 113

Charging battery 8

Dialing a Number

Phonebook 59

SIM Card 62

Dialing display 102

Display

backlight 18

icons 17

DTMF 32

Entering Text 45

Changing the Text Entry

Mode 46

Using ABC Mode 47

Using Number Mode 51

Using Symbol Mode 51

Using T9 Mode 49

t809.book Page 199 Tuesday, September 27, 2005 4:18 PM

200

File Manager 118

Fun & Apps 117

Functions and Options 29

Games 127

Get More Help 19

Getting Started 5

Activating Your Phone 6

Voicemail 10

Health and Safety Informa-

tion 161

HiFi Ringers 103, 118

Icons, description 17

Image Editor 128

Instant Messaging 91

International Call 22

Keypad Tone 104

Low battery indicator 9

Making a Call

Phonebook 23

MegaTones 103, 118

Menu Navigation 37

Menu Outline 39

Message settings 90

Message Tone 104

Messages 69

Messaging

Types of Messages 70

Missed Call

Viewing 26

MP3 player 126

Multi-Party Call 34

Dropping One Participant 35

Private Conversation 35

Setting up 34

Mute 31

My Album 120, 153

My Journal 120, 154

My Name Card 64

My photos

accessing pictures 149

My videos 151

Network Selection 108

Network Services

Call Barring 107

Call Forwarding 106

Call Waiting 107

Caller ID 109

Network Selection 108

Network Services Settings

106

Number mode 46

On/off switch, phone 10

Options

During a Call 30

Putting a Call on Hold 30

t809.book Page 200 Tuesday, September 27, 2005 4:18 PM

201

Organizer 129

Calculator 136

Calendar 131

Stopwatch 138

Timer 138

Unit Conversion 137

World time 137

Own Number 64

Phone

icons 17

switching on/off 10

Phone lock 112

Phone Settings 97

Phonebook

Searching for a Number 33

Phonebook Management 65

Picture Messages 75

change 112

check 111

Privacy 113

Push message

viewing in Inbox 84

Reset settings 115

Ring Volume 103

Security 111

Sentbox 85

Settings 95

Sound Settings 103

Shortcuts 38

Silent mode 105

SIM card

installing 6

Soft Keys 29

Speakerphone 32

Speed Dial

Setting Up Entries 59

Standard Limited Warranty

190

Stopwatch 138

Storing a number

Phone’s Memory 55

SIM Card 54

Switching on/off

phone 10

Symbol mode 46

T9 mode 46

Templates 88

Text input mode

changing 46

Text Messages 72

Timer 138

Travel adapter 8

t-zones 156

Entering Text 157

Exiting 156

Navigating 156

Understanding Your Phone 13

Features of Your Phone 14

View of Your Phone 14

t809.book Page 201 Tuesday, September 27, 2005 4:18 PM

202

Understanding Your Phone-

book 53

Finding a Phonebook Entry

Finding My Phone Number

Management 65

Voice Mail 11, 89

changing number 11

Voice Messages 70

Voice notes 70

Warranty Information 189

t809.book Page 202 Tuesday, September 27, 2005 4:18 PM

GH68-08136A

Hearing Aid Compatibility with Mobile Phones

When some mobile phones are used near some hearing devices (hearing aids and

cochlear implants), users may detect a buzzing, humming, or whining noise. Some

hearing devices are more immune than others to this interference noise, and phones

also vary in the amount of interference they generate.

The wireless telephone industry has developed ratings for some of their mobile

phones, to assist hearing device users in ﬁnding phones that may be compatible

with their hearing devices. Not all phones have been rated. Phones that are rated

have the rating on their box or a label on the box.

The ratings are not guarantees. Results will vary depending on the user’s hearing

device and hearing loss. If your hearing device happens to be vulnerable to interfer-

ence, you may not be able to use a rated phone successfully. Trying out the phone

with your hearing device is the best way to evaluate it for your personal needs.

M-Ratings: Phones rated M3 or M4 meet FCC requirements and are likely to gener-

ate less interference to hearing devices than phones that are not labeled. M4 is the

better/higher of the two ratings.

T-Ratings: Phones rated T3 or T4 meet FCC requirements and are likely to be more

usable with a hearing device’s telecoil (“T Switch” or “Telephone Switch”) than

unrated phones. T4 is the better/higher of the two ratings. (Note that not all hearing

devices have telecoils in them.)

Hearing devices may also be measured for immunity to this type of interference. Your

hearing device manufacturer or hearing health professional may help you ﬁnd results

for your hearing device. The more immune your hearing aid is, the less likely you are

to experience interference noise from mobile phones.

GH68-08136A

Compatibilidad de Aparatos Dispositivos Con Teléfonos Móviles

Cuando algunos teléfonos móviles se utilizan cerca de algunos aparatos auditivos

(audífonos e implantes cocleares), es posible que los usuarios detecten un ruido

como zumbido, murmullo o quejido. Algunos aparatos auditivos son más inmunes

que otros a este ruido de interferencia y los teléfonos también varían en la cantidad

de interferencia que generan.

La industria de los teléfonos inalámbricos ha desarrollado clasiﬁcaciones para algu-

nos de sus teléfonos móviles, para ayudar a que los usuarios de aparatos auditivos

encuentren teléfonos que pudieran ser compatibles con este tipo de aparatos. No

todos los teléfonos han sido clasiﬁcados. Los teléfonos que han sido clasiﬁcados

tienen la clasiﬁcación en la caja o una etiqueta en la caja.

Las clasiﬁcaciones no son garantías. Los resultados pudieran variar, dependiendo

del aparato auditivo y de la pérdida de audición del usuario. Si su aparato auditivo

resulta ser vulnerable a la interferencia, es posible que no tenga éxito al usar un

teléfono clasiﬁcado. La mejor manera de evaluar el teléfono para sus necesidades

personales es probarlo con su aparato auditivo.

Clasiﬁcación M: Los teléfonos clasiﬁcados como M3 o M4 cumplen con los req-

uisitos de la FCC y tienen probabilidades de generar menos interferencia para los

aparatos auditivos que los teléfonos que no están clasiﬁcados. M4 es la mejor y más

alta clasiﬁcación de las dos.

Clasiﬁcación T: Los teléfonos clasiﬁcados como T3 o T4 cumplen con los requisitos

de la FCC y tienen posibilidades de usarse más con la telebobina de un aparato au-

ditivo (“interruptor “T” o “interruptor del teléfono”) que los teléfonos no clasiﬁcados.

T4 es la mejor y más alta clasiﬁcación de las dos. (Tenga en cuenta que no todos los

aparatos auditivos tienen telebobinas).

También se puede medir la inmunidad de los aparatos auditivos hacia este tipo

de interferencia. El fabricante de su aparato auditivo o un profesional en la salud

del oído pueden ayudarle a encontrar mejores resultados para su aparato auditivo.

Entre más inmune sea su audífono, tendrá menos posibilidades de tener ruidos de

interferencia con los teléfonos móviles.

Samsung Electronics Co SGHT809 Dual-Band GSM/ EDGE Phone with Bluetooth User Manual 1 1 D820 RF block diagram

Samsung Electronics Co Ltd Dual-Band GSM/ EDGE Phone with Bluetooth 1 1 D820 RF block diagram

Contents

Users Manual 3

Navigation menu

Namespaces

Views

Navigation
