Contents
- 1. Users Manual
- 2. Installation Instruction Manual
Installation Instruction Manual
1.Set up guide
(1) Connect10PIN CABLE as follow Figure 1-1)
Figure 1-1)CABLE Connecting
(2) Be built in TV MONITOR as follow Figure 1-2).
CAUTION : DON’T shield this product from an electric panel
because of antenna for radiation
Figure 1-2)Built-in TV
Thank your purchasing this product.This product is
applied as following 2.4GHz IEEE802.15.4[ZIGBEE]
This is ZIGBEE Radio Receiver module for Remote
Control and in pair with Remote controller
Installation Instruction
