Schneider Electric Systems Canada EB450-XXF01 Remote Radio Data Modem Base/Repeater User Manual Trio Base Station EB450

Trio Datacom Pty Ltd (a wholly owned company of Schneider Electric) Remote Radio Data Modem Base/Repeater Trio Base Station EB450

Base Station EB

Local regulatory conditions may determine
the performance and suitability of individual
versions in different countries. It is the
responsibility of the buyer to confirm these
regulatory conditions. Performance data
indicates typical values related to the
Radio
Frequency Range: 380-520 MHz (various
sub-frequency bands available)
Frequency Splits: Various Tx/Rx
frequency splits - programmable
Channel Selection: Dual synthesizer,
6.25 kHz channel step
Channel Spacing: 12.5 or 25 kHz
Frequency Stability: ±1ppm (-30 to 60°C
ambient, opt. -30 to 70°C) Higher
frequency stability options are available
(with external GPS reference)
Aging: <= 1ppm/annum
Full Duplex: Full duplex (optional
internal or external duplexer available
for single antenna operation)
Configuration: All configuration via
Windows based software
Transmitter
Tx Power: 5W (+37 dBm) ±1 dB
software adjustable with over-
temperature protection. 100% Duty Cycle.
Modulation: Narrow band digital filtered
binary GMSK
Occupied Bandwidth: Designed to FCC,
ETSI, ACA requirements
Tx Keyup Time: < 1 mSecond
Timeout Timer: Programmable 0-255
seconds
Tx Spurious: <= -37 dBm
PTT Control: Auto (on Data) / RTS line
(Port A or B) / System Port (Override)
Receiver
Sensitivity: -118 dBm for 12 dB SINAD
Selectivity: Better than 80 dB
Intermodulation: Better than 75 dB
Spurious Response: Better than 80 dB
AFC Tracking: Digital receiver
frequency tracking
Mute: Programmable digital mute
Diagnostics (Optional)
Network wide operation from any
remote terminal.
Non intrusive protocol - runs
simultaneously with the application.
Over-the-air re-configuration of user
parameters.
Programmable exception reporting of
alarms.
Storage of data error and channel
occupancy statistics.
In-built Error Rate testing capabilities.
Connections
User Data Ports: 2 x DB9 female ports
wired as DCE (modem)
System Port: RJ45 (front and rear)
for diagnostics, configuration and
programming
Antenna:
2 x N female bulkhead (separate
Tx and Rx ports)
1 x N female bulkhead (with optional
internal duplexer)
Power: 2 pin locking, mating
connector supplied
LED Display: Multimode Indicators for
Pwr, Tx, Rx, Sync, TxD and RxD data
LEDs (for both port A and B)
Modem
Data Serial Port #1: RS232, DCE, 600-
76,800 bps asynchronous
Data Serial Port #2: RS232, DCE, 300-
38,400 bps asynchronous
System Port: RS232, 19,200 bps
asynchronous
Flow Control: Selectable
hardware/software/3 wire interface
RF Channel Data Rate:
4800/9600/19,200 bps Full duplex
Data Buffer: 16 kbyte of on-board RAM
Bit Error Rate:
< 1x10-6 @ -110 dBm (4800 bps)
< 1x10-6 @ -108 dBm (9600 bps)
< 1x10-6 @ -106 dBm (19,200 bps)
Collision Avoidance: Trio DataCom’s
unique supervisory channel C/DSMA
collision avoidance system
Multistream™: Trio DataCom's unique
simultaneous delivery of multiple data
streams (protocols)
Data Turnaround Time: <10mS
Firmware: Field upgradeable Flash
memory
General
Power Supply: 13.8 Vdc nominal
(11-16 Vdc)
Transmit Current:
1.3 A nominal @ 1 W
2.5 A nominal @ 5 W
Receive Current: < 150 mA
Dimensions: 19” 2 RU rack mount
485 x 90 x 390 mm
Weight: 5 kg (excluding optional
duplexer)
Options
DUPLX450Bx Internal / External
Duplexers, Band Reject and Band Pass
EDOVM Digital Order Wire Voice
Module
TVIEW+™ Configuration, Network
Management and Diagnostic GUI
Software
DIAGS/E Network Management and
Remote Diagnostics Facilities per Radio
Modem (E Series)
Related Products
EH450 Hot Standby Base Station
ER450 Remote Data Radio
95MSR 6 and 9 Port Stream Router
Multiplexer
E Series
Digital Data Base Station - EB450
Information subject to change without notice.
© Copyright 2002 Trio DataCom Pty Ltd.
All rights reserved. Issue 05/02
41 Aster Avenue, Carrum Downs
Victoria, Australia 3201
Phone +613 9775 0505 Fax +613 9775 0606
sales@trio.com.au www.trio.com.au
Features and Specifications
Trio DataCom’s EB450 is an advanced Full Duplex Base / Repeater Station that complements the ER450 remote data radio
modem. E Series data radio modems are suitable for the most complex and demanding digital high speed Point-to-Point
and Point-to-Multipoint (Multiple Address Radio) SCADA and telemetry applications.
Base stations and repeaters are key elements in data radio communication systems and are subject to heavy duty cycle
operation. The EB450 delivers highly reliable, continuous full duplex operations at maximum (5W) output power.
The high performance E Series data radio system products also include the EH450 Hot Standby Base / Repeater station.
Features
Radio and Modem
- Fully integrated radio, modem and data
multiplexer
- True 19,200 bps over-air data rates
- Fast data turnaround
- Full Duplex Operation
- Broad frequency range with fully synthesized
all digital radio design
- 5 watt transmitter output with 100% duty cycle
up to maximum temperature specification
(-30° to +60°C, +70°C option)
- Housed in a rugged 19” rack mount enclosure
- Insurance against obsolescence with field
upgradeable firmware in flash memory
- Extensive front panel LED diagnostic display
- Internal (compact) or external duplexer
options
- Digital orderwire option
Data Ports
- Two independent data ports and separate
system port
- Compatible with most industry standard data
protocols. eg: MODBUS, DNP-3, IEC 870 etc.
- Selectable 300 - 76.8 k bps asynchronous
RS-232 interface
- Multistream™ simultaneous data streams
allows for multiple vendor devices/protocols
to be transported on the one radio network
- Flexible data stream routing providing
optimum radio channel efficiency
- Internal repeater operation - buffered store
and forward operation
- Unique integrated C/DSMA collision
avoidance technology permits simultaneous
polling and spontaneous alarm reporting
operation in the same system
Network Management and Remote
Diagnostic option
(In conjunction with TView+™ GUI)
- Exceptional network management tools
- Over-the-air user configuration
- Transparent Operation-simultaneous with
user data
- Separate isolated alarm inputs and outputs
- Network wide operation from any radio
terminal
E Series
Digital Data Base Station - EB450
Innovative and sophisticated
digital communications
designs product s and solutions
Local regulatory conditions may determine
the performance and suitability of individual
versions in different countries. It is the
responsibility of the buyer to confirm these
regulatory conditions. Performance data
indicates typical values related to the described unit.
Radio
Frequency Range: 380-520 MHz (various
sub-frequency bands available)
Frequency Splits: Various Tx/Rx
frequency splits - programmable
Channel Selection: Dual synthesizer,
6.25 kHz channel step
Channel Spacing: 12.5 or 25 kHz
Frequency Stability: ±1ppm (-30 to 60°C
ambient, opt. -30 to 70°C) Higher
frequency stability options are available
(with external GPS reference)
Aging: <= 1ppm/annum
Full Duplex: Full duplex (optional
internal or external duplexer available
for single antenna operation)
Configuration: All configuration via
Windows based software
Transmitter
Tx Power: 5W (+37 dBm) ±1 dB
software adjustable with over-
temperature protection. 100% Duty Cycle.
Modulation: Narrow band digital filtered
binary GMSK
Occupied Bandwidth: Designed to FCC,
ETSI, ACA requirements
Tx Keyup Time: < 1 mSecond
Timeout Timer: Programmable 0-255
seconds
Tx Spurious: <= -37 dBm
PTT Control: Auto (on Data) / RTS line
(Port A or B) / System Port (Override)
Receiver
Sensitivity: -118 dBm for 12 dB SINAD
Selectivity: Better than 80 dB
Intermodulation: Better than 75 dB
Spurious Response: Better than 80 dB
AFC Tracking: Digital receiver
frequency tracking
Mute: Programmable digital mute
Diagnostics (Optional)
Network wide operation from any
remote terminal.
Non intrusive protocol - runs
simultaneously with the application.
Over-the-air re-configuration of user
parameters.
Programmable exception reporting of
alarms.
Storage of data error and channel
occupancy statistics.
In-built Error Rate testing capabilities.
Connections
User Data Ports: 2 x DB9 female ports
wired as DCE (modem)
System Port: RJ45 (front and rear)
for diagnostics, configuration and
programming
Antenna:
2 x N female bulkhead (separate
Tx and Rx ports)
1 x N female bulkhead (with optional
internal duplexer)
Power: 2 pin locking, mating
connector supplied
LED Display: Multimode Indicators for
Pwr, Tx, Rx, Sync, TxD and RxD data
LEDs (for both port A and B)
Modem
Data Serial Port #1: RS232, DCE, 600-
76,800 bps asynchronous
Data Serial Port #2: RS232, DCE, 300-
38,400 bps asynchronous
System Port: RS232, 19,200 bps
asynchronous
Flow Control: Selectable
hardware/software/3 wire interface
RF Channel Data Rate:
4800/9600/19,200 bps Full duplex
Data Buffer: 16 kbyte of on-board RAM
Bit Error Rate:
< 1x10-6 @ -110 dBm (4800 bps)
< 1x10-6 @ -108 dBm (9600 bps)
< 1x10-6 @ -106 dBm (19,200 bps)
Collision Avoidance: Trio DataCom’s
unique supervisory channel C/DSMA
collision avoidance system
Multistream™: Trio DataCom's unique
simultaneous delivery of multiple data
streams (protocols)
Data Turnaround Time: <10mS
Firmware: Field upgradeable Flash
memory
General
Power Supply: 13.8 Vdc nominal
(11-16 Vdc)
Transmit Current:
1.3 A nominal @ 1 W
2.5 A nominal @ 5 W
Receive Current: < 230 mA
Dimensions: 19” 2 RU rack mount
485 x 90 x 420 mm
Weight: 5 kg (excluding optional
duplexer)
Options
DUPLX450Bx Internal / External
Duplexers, Band Reject and Band Pass
EDOVM Digital Order Wire Voice
Module
TVIEW+™ Configuration, Network
Management and Diagnostic GUI
Software
DIAGS/E Network Management and
Remote Diagnostics Facilities per Radio
Modem (E Series)
Related Products
EH450 Hot Standby Base Station
ER450 Remote Data Radio
95MSR 6 and 9 Port Stream Router
Multiplexer
E Series
Digital Data Base Station - EB450
Information subject to change without notice.
© Copyright 2002 Trio DataCom Pty Ltd.
All rights reserved. Issue 08/02
41 Aster Avenue, Carrum Downs
Victoria, Australia 3201
Phone +613 9775 0505 Fax +613 9775 0606
sales@trio.com.au www.trio.com.au
Features and Specifications
Trio DataCom’s EB450 is an advanced Full Duplex Base / Repeater Station that complements the ER450 remote data radio
modem. E Series data radio modems are suitable for the most complex and demanding digital high speed Point-to-Point
and Point-to-Multipoint (Multiple Address Radio) SCADA and telemetry applications.
Base stations and repeaters are key elements in data radio communication systems and are subject to heavy duty cycle
operation. The EB450 delivers highly reliable, continuous full duplex operations at maximum (5W) output power.
The high performance E Series data radio system products also include the EH450 Hot Standby Base / Repeater station.
Features
Radio and Modem
- Fully integrated radio, modem and data
multiplexer
- True 19,200 bps over-air data rates
- Fast data turnaround
- Full Duplex Operation
- Broad frequency range with fully synthesized
all digital radio design
- 5 watt transmitter output with 100% duty cycle
up to maximum temperature specification
(-30° to +60°C, +70°C option)
- Housed in a rugged 19” rack mount enclosure
- Insurance against obsolescence with field
upgradeable firmware in flash memory
- Extensive front panel LED diagnostic display
- Internal (compact) or external duplexer
options
- Digital orderwire option
Data Ports
- Two independent data ports and separate
system port
- Compatible with most industry standard data
protocols. eg: MODBUS, DNP-3, IEC 870 etc.
- Selectable 300 - 76.8 k bps asynchronous
RS-232 interface
- Multistream™ simultaneous data streams
allows for multiple vendor devices/protocols
to be transported on the one radio network
- Flexible data stream routing providing
optimum radio channel efficiency
- Internal repeater operation - buffered store
and forward operation
- Unique integrated C/DSMA collision
avoidance technology permits simultaneous
polling and spontaneous alarm reporting
operation in the same system
Network Management and Remote
Diagnostic option
(In conjunction with TView+™ GUI)
- Exceptional network management tools
- Over-the-air user configuration
- Transparent Operation-simultaneous with
user data
- Separate isolated alarm inputs and outputs
- Network wide operation from any radio
terminal
E Series
Digital Data Base Station - EB450
Innovative and sophisticated
digital communications
designs product s and solutions

Navigation menu
