User Manual 4 of 4
174
Settings
External Light Colour
You can select from 7 colours and 1 pattern for each profile and change it during an
incoming call.
“Settings”
→
“Profiles”
1. Highlight the profile you wish to customise.
2. Press [Options] and select “Personalise”.
3. Select “External Light”.
4. Select “For Voice Call”, “For Video Call” or “For New Message”.
5. Select the desired colour or “Off”.
Tip
•If you select “Disco” in step 5, all 7 colours flash in order during an incoming call.
Any Key Answer
You can answer a call by pressing any key except F, , U and [Busy]. For details,
see page 37.
“Settings”
→
“Profiles”
1. Highlight the profile you wish to customise.
2. Press [Options] and select “Personalise”.
3. Select “Any Key Answer”.
4. Select “On” or “Off”.
e_j350.book Page 174 Monday, October 25, 2004 6:33 PM
175
Settings
Setting the Display
You can change the settings of the display.
Wallpaper
For the stand-by screen, 5 pictures are provided.
Pictures taken with the digital camera or images downloaded from a WAP site can be used
for wallpapers.
Setting My Pictures
“Settings”
→
“Display Settings”
→
“Wallpaper”
1. Select “My Pictures”.
2. Select the desired picture.
3. After displaying the picture, press .
Note
•Some pictures cannot be used because of their picture and data types.
•If the picture in My Pictures is already set, it is displayed in step 1. Press [Change] and
select the desired picture.
(M 12-2)
e_j350.book Page 175 Monday, October 25, 2004 6:33 PM
176
Settings
Assigning the Pictures
Pictures can be displayed when turning the power on or off, when receiving an incoming
call, or when operating the alarm.
Pictures taken with the digital camera or images downloaded from a WAP site can be used.
To Set Built-in Pictures
“Settings”
→
“Display Settings”
→
“System Graphics”
1. Select the desired scene to set the picture to.
2. Select “Preset Animation” when you select “Power On” or “Power Off” in step 1.
Select “Pattern 1”, “Pattern 2” or “Pattern 3” when you select “Incoming Call” or
“Alarm” in step 1.
To Set My Pictures
“Settings”
→
“Display Settings”
→
“System Graphics”
1. Select the desired scene to set the picture to.
2. Select “My Pictures”.
3. Select the desired picture.
4. After displaying the picture, press .
5. Specify the area you wish to display using the navigation keys.
Note
•Some pictures cannot be used because of their picture and data types.
•If the picture in My Pictures is already set, it is displayed in step 2. Press [Change] and
select the desired picture.
e_j350.book Page 176 Monday, October 25, 2004 6:33 PM
177
Settings
Setting the Font Weight
You can change the font weight displayed on the screen.
“Settings”
→
“Display Settings”
→
“Font Settings”
1. Select “Thin”, “Normal”, “Bold” or “Bolder”.
The preview image is displayed in the selected weight.
Setting the Greeting Message
You can set the message which is displayed when the phone is turned on.
“Settings”
→
“Display Settings”
→
“Greeting Message”
→
“Switch On/Off”
1. Select “On” or “Off”.
2. Select “Edit Message” and enter the message when you select “On” in step 1.
Up to 10 characters can be saved as a message.
Showing the Clock
You can display the calendar or the current date and/or time during stand-by.
To Set the Clock Display
“Settings”
→
“Display Settings”
→
“Clock & Calendar”
→
“Show Clock”
1. Select the desired clock type or “Off” to set clock display off.
Tip
•When you select “Calendar”, you can display one or two consecutive calendars by
selecting “1 month” or “2 months”.
e_j350.book Page 177 Monday, October 25, 2004 6:33 PM
178
Settings
Backlight
The backlight will shut off if you do not press the keypad for a certain length of time. You
can specify a desired time to elapse before the backlight shuts off, which will help conserve
battery life.
Tip
•When you purchase this phone, Backlight is set to 15 seconds.
To Select the Backlight Time Out
“Settings”
→
“Display Settings”
→
“Backlight”
1. Select the desired time.
Select “Off” to shut it off.
Adjusting the Brightness of the Backlight
You can adjust the brightness of the backlight of the screen between 4 levels.
“Settings”
→
“Display Settings”
→
“Brightness”
1. Press a (Light) and b (Dark) for maximum clarity.
2. Press .
e_j350.book Page 178 Monday, October 25, 2004 6:33 PM
179
Settings
Setting the Display Saving
The screen of this phone will automatically turn off after a given amount of time. You can
change the length of time before the Display Saving goes into effect, which will help
conserve battery life.
Tip
•When you purchase this phone, Display Saving is set to 2 minutes.
“Settings”
→
“Display Settings”
→
“Display Saving”
1. Select the desired time.
Note
•Display Saving does not work while you are making a call, using WAP, or using an
application.
•To cancel the Display Saving: The display saving continues until either a key is pressed
or there is an incoming alert. The first key press only cancels this function. You must
press another key in order to enter any numerical or text value.
Sound Settings
You can use this menu to check or edit the current Profiles settings (except “Any Key
Answer”).
(M 12-3)
e_j350.book Page 179 Monday, October 25, 2004 6:33 PM
180
Settings
Time & Date
You need to set the correct time and date in order for your phone’s various time-based
functions to work correctly.
“Settings”
→
“Time & Date”
→
“Set Date/Time”
1. Enter the day, month and year using the digit keys.
2. Enter the time using the digit keys.
Tip
•When you enter the time in the 12-hour format, press a or b to switch between am
and pm. The order in which the date and time is displayed is based on the format setting.
Selecting the Time Format
“Settings”
→
“Time & Date”
→
“Time Format”
1. Select “24 Hour” or “12 Hour”.
Selecting the Date Format
“Settings”
→
“Time & Date”
→
“Date Format”
1. Select from “D.M.Y”, “M-D-Y” or “Y/M/D”.
Setting the Daylight Saving
“Settings”
→
“Time & Date”
→
“Daylight Saving”
1. Select “On” or “Off”.
(M 12-4)
e_j350.book Page 180 Monday, October 25, 2004 6:33 PM
181
Settings
Setting the Time Zone
“Settings”
→
“Time & Date”
→
“Set Time Zone”
1. Press c or d to select the home city to set.
2. Press .
Customising the Time Zone
“Settings”
→
“Time & Date”
→
“Set Time Zone”
→
[Options]
→
“Set Custom
Zone”
1. Enter the city name.
2. Enter the time-zone differences using the digit keys.
Press a or b to switch between – and +.
3. Press .
Setting the Calendar Format
“Settings”
→
“Time & Date”
→
“Calendar Format”
1. Select “Sunday-Saturday” or “Monday-Sunday”.
e_j350.book Page 181 Monday, October 25, 2004 6:33 PM
182
Settings
Language Setting
You can change the language that the phone uses to display messages.
“Settings”
→
“Language”
1. Select the desired language.
Tip
•You can also change the input language on the text entry screen (p. 53).
Note
•If you select “Automatic” in step 1, the language preset on the SIM/USIM card is selected.
•If the language preset on the SIM/USIM card is not supported, then the default language
of the phone is selected.
Call Settings
Set various types of functions and services for voice calls.
Diverts
Note
•This service may not be available on all mobile phone networks. Contact your network
operator for more information.
This service is used to divert incoming calls to your voice mail system or to another phone
number depending on certain conditions in which you cannot answer a call.
(M 12-5)
(M 12-6)
e_j350.book Page 182 Monday, October 25, 2004 6:33 PM
183
Settings
To Divert Calls
“Settings”
→
“Call Settings”
→
“Diverts”
1. Select one of the following options:
“All Calls”: Diverts all calls without ringing.
“When Busy”: Diverts incoming calls when you are talking on the phone.
“No Answer”: Diverts incoming calls if you do not answer a call within a certain
period of time.
“Not Reachable”: Diverts incoming calls when your phone has no network service or
is switched off.
“Cancel All”: Clears all the above settings.
If you select “No Answer”, go to step 5.
2. Select “On”.
3. Enter a phone number to which you wish to divert calls or search for it in the
Contacts List (p. 61).
4. Press .
5. Select the period of time from 6 levels (05 to 30 seconds).
Note
•When a divert is set to “Voice calls” of “All Calls”, “ ” is displayed during stand-by.
Tip
•If you select “By Service” in step 2, you can select further divert options.
e_j350.book Page 183 Monday, October 25, 2004 6:33 PM
184
Settings
To Check the Divert Status
“Settings”
→
“Call Settings”
→
“Diverts”
1. Select the divert option you wish to check.
2. Select “Status”.
Call Waiting
Note
•This service may not be available on all mobile phone networks. Contact your network
operator for more information.
If you wish to be able to receive another incoming call while you have a call in progress, you
must activate the Call Waiting service.
“Settings”
→
“Call Settings”
→
“Call Waiting”
1. Select “On”, “Off” or “Status”.
Showing Your Phone Number
This lets you control whether to show your phone number when calling another party or not.
“Settings”
→
“Call Settings”
→
“Show Your Number”
1. Select “On”, “Off” or “Status”.
Note
•Some networks do not support this service. Please check with your service provider for
availability.
e_j350.book Page 184 Monday, October 25, 2004 6:33 PM
185
Settings
Call Information
With this setting On, the information of an incoming call is displayed.
“Settings”
→
“Call Settings”
→
“Display Call Info”
1. Select “On” or “Off”.
Restrict Calls
This function lets you place restrictions on incoming and outgoing calls. To activate this
option you will need the specified password, which is available from your service provider.
“Settings”
→
“Call Settings”
→
“Restrict Calls”
1. Select from one of the following options:
“Outgoing Calls”: Restricts outgoing calls.
“Fixed Dialling No.”: Restricts calls for fixed dialling numbers in the Contacts List.
“Incoming Calls”: Restricts incoming calls.
“Rejected Numbers”: You can register for dialling numbers to be restricted.
“Withheld Call”: Restricts withheld calls.
“Change N/W Password”:Changes the network password.
2. Select one of the following options:
(For “Outgoing Calls”)
“Bar All Outgoing Calls”: Restricts all outgoing calls except emergency calls.
“Bar International Calls”: Restricts all outgoing international calls.
“Only Local & Home”: Restricts all outgoing international calls except to your home
country.
e_j350.book Page 185 Monday, October 25, 2004 6:33 PM
186
Settings
(For “Incoming Calls”)
“Bar All Incoming Calls”: Restricts all incoming calls.
“Bar if Abroad”: Restricts all incoming calls when you are outside of the
coverage from your registered network operator.
3. Select one of the following options:
(For “Outgoing Calls” and “Incoming Calls”)
“All Services”: Restricts all services.
“Voice Calls”: Restricts all voice calls.
“Video Calls”: Restricts all video calls.
“Fax”: Restricts all fax calls.
“Messages”: Restricts all messages.
“All except msgs”: Restricts all services except messages.
4. Select “On”, “Off” or “Status”.
5. Enter the network password.
To Cancel Settings
“Settings”
→
“Call Settings”
→
“Restrict Calls”
1. Select “Outgoing Calls” or “Incoming Calls”.
2. Select “Cancel All”.
3. Enter the network password.
e_j350.book Page 186 Monday, October 25, 2004 6:33 PM
187
Settings
Fixed Dialling No.
When the Fixed Dialling No. is enabled, you can only call pre-registered numbers.
To Enable Fixed Dialling No.
“Settings”
→
“Call Settings”
→
“Restrict Calls”
→
“Fixed Dialling No.”
→
“Switch On/Off”
1. Select “On” to enable this function.
To Add a New Name
“Settings”
→
“Call Settings”
→
“Restrict Calls”
→
“Fixed Dialling No.”
→
“Edit
Dial List”
1. Highlight the blank entry, press [Options], then select “Add New Dial”.
2. Enter your PIN2 code.
3. Add a name and a phone number.
For details on adding a name and a phone number, see “Add New Contact” on page 59.
4. Press [Save].
Rejecting an Incoming Call
You can register phone numbers you do not wish to answer.
To Reject the Registered Number
“Settings”
→
“Call Settings”
→
“Restrict Calls”
→
“Rejected Numbers”
→
“Switch On/Off”
1. Select “On” or “Off”.
e_j350.book Page 187 Monday, October 25, 2004 6:33 PM
188
Settings
To Register the Rejected Number
“Settings”
→
“Call Settings”
→
“Restrict Calls”
→
“Rejected Numbers”
→
“Set
Rejecting Number”
1. Select a blank field.
2. Enter the desired number.
Changing the Network Password
“Settings”
→
“Call Settings”
→
“Restrict Calls”
→
“Change N/W Password”
1. Enter the old network password.
2. Enter a new network password.
3. Enter the new network password again.
If you enter the incorrect password, you are asked to enter the password again.
4. Press .
Minute Minder
Minute Minder function informs you of your talk time by sounding a tone after every minute.
“Settings”
→
“Call Settings”
→
“Minute Minder”
1. Select “On” or “Off”.
Displaying Call Timer
“Settings”
→
“Call Settings”
→
“Display Call Timer”
1. Select “On” or “Off”.
Auto Redial
“Settings“
→
“Call Settings“
→
“Auto Redial”
1. 1. Select “On” or “Off”.
e_j350.book Page 188 Monday, October 25, 2004 6:33 PM
189
Settings
Video Call Settings
Set various types of functions and services for video calls.
Selecting an Image for the Alternative Image
You can select your image to be sent through the internal camera from the saved picture
files.
Selecting the Picture Quality
Select the desired incoming data format for your environment.
“Settings”
→
“Video Call Settings”
→
“Picture Quality”
1. Select from “Normal”, “Quality Prio.” or “Frame Rate Prio.”.
Select “Frame Rate Prio.” to perform faster communication.
Backlight
With this setting On, the phone’s backlight is on when making a video call.
“Settings”
→
“Video Call Settings”
→
“Backlight”
1. Select “On”, “As Normal Setting” or “Off”.
The “As Normal Setting” option depends on the backlight setting of the display (p. 178).
Mute
You can mute the microphone while making a video call.
“Settings”
→
“Video Call Settings”
→
“Mute Microphone”
1. Select “Unmute Microphone” to cancel the mute.
(M 12-7)
e_j350.book Page 189 Monday, October 25, 2004 6:33 PM
190
Settings
Assigning Hold Guidance Picture
You can display an image saved in the phone on your display while you are putting a call on
hold.
“Settings”
→
“Video Call Settings”
→
“Hold Guidance Pict”
1. Select “Preset Picture” or “My Pictures”.
2. Select the desired picture.
e_j350.book Page 190 Monday, October 25, 2004 6:33 PM
191
Settings
Security
Enabling/Disabling the PIN Code
If the PIN code is enabled you are asked to enter the PIN code each time the phone is
switched on. Your PIN code is registered on the SIM/USIM card and you should have been
made aware of the code when you purchased the SIM/USIM card. Contact your service
provider for further details.
“Settings”
→
“Security Settings”
→
“PIN Entry”
→
“Switch On/Off”
1. Select “On” to enable the PIN code or “Off” to disable.
2. Enter your PIN code.
Note
•If you enter the wrong PIN code three times in step 2, the SIM/USIM card will lock. To
remove the lock, contact your service provider/SIM/USIM card vendor.
To Change the PIN Code
This allows you to change the PIN code registered on the SIM/USIM card. Before you change
the PIN code, select “On” in step 1 in “Enabling/Disabling the PIN Code”.
“Settings”
→
“Security Settings”
→
“PIN Entry”
→
“Change PIN”
1. Enter the existing PIN code.
2. Enter a new PIN code.
3. Enter the new PIN code again.
(M 12-8)
e_j350.book Page 191 Monday, October 25, 2004 6:33 PM
192
Settings
Changing the PIN2 Code
The PIN2 code is used to protect certain functions in the phone such as Fixed Dialling No.
and call cost limits. The following shows you how to change the PIN2 code.
“Settings”
→
“Security Settings”
→
“Change PIN2”
1. Enter the existing PIN2 code.
2. Enter a new PIN2 code.
3. Enter the new PIN2 code again.
Handset Lock
The Handset Lock is an additional security feature which prevents unauthorised use of the
phone or certain features.
“Settings”
→
“Security Settings”
→
“Handset Lock”
1. Select “On” or “Off”.
2. Enter your handset code.
The default handset code is “9999”. For details on changing the handset code, see “To
Change the Handset Code”.
To Change the Handset Code
Before you change the handset code, select “On” in step 1 in “Handset Lock”.
“Settings”
→
“Security Settings”
→
“Change Handset Code”
1. Enter the old handset code.
2. Enter a new handset code.
3. Enter the new handset code again.
e_j350.book Page 192 Monday, October 25, 2004 6:33 PM
193
Settings
Phone Lock
By setting this option on, your phone will lock the keypad until the correct handset code is
entered.
“Settings”
→
“Security Settings”
→
“Phone Lock”
1. Enter your handset code.
The default handset code is “9999”. For details on changing the handset code, see “To
Change the Handset Code” on page 192.
To Turn Off the Phone Lock
Enter your handset code during stand-by to turn the Phone Lock off.
Showing Secret Data
By setting this option on, the hidden data can be displayed.
“Settings”
→
“Security Settings”
→
“Show Secret Data”
1. Select “On” to display or “Off” to hide.
e_j350.book Page 193 Monday, October 25, 2004 6:33 PM
194
Settings
Memory Settings
Viewing the Memory Status
“Settings”
→
“Memory Settings”
→
“Memory Status”
1. Select from “Handset” or “Memory Card”.
The memory status of the selected item is displayed.
Formatting Memory Card
“Settings”
→
“Memory Settings”
→
“Format Card”
1. Enter your handset code.
The default handset code is “9999”. For details on changing the handset code, see “To
Change the Handset Code” on page 192.
2. Press [Yes] to start formatting.
Master Reset
You can reset M5 and M12 settings or all settings from M1 to M12 and all created data.
Resetting M5 and M12 Settings
“Settings”
→
“Master Reset”
→
“Reset Settings”
1. Enter your handset code.
The default handset code is “9999”. For details on changing the handset code, see “To
Change the Handset Code” on page 192.
(M 12-9)
(M 12-10)
e_j350.book Page 194 Monday, October 25, 2004 6:33 PM
195
Settings
Resetting All Settings from M1 to M12
“Settings”
→
“Master Reset”
→
“Reset All”
1. Enter your handset code.
The default handset code is “9999”. For details on changing the handset code, see “To
Change the Handset Code” on page 192.
e_j350.book Page 195 Monday, October 25, 2004 6:33 PM
196
Call Log (M 11)
The phone will record the last 10 missed calls, received calls and dialled numbers.
Viewing Call Log
“Call Log”
1. Select from “All Calls”, “Dialled Numbers”, “Missed Calls” or “Received Calls”.
The selected call log list is displayed.
To switch logs, press c or d.
2. Select the phone number you wish to view.
If you wish to dial the number, press .
Tip
•You can also confirm call logs by pressing D during stand-by.
Sending Messages
1. In the call log list, highlight the call log you wish to send a message to.
2. Press [Options] and select “Create Message”.
For details on creating a message, see “Creating a New Message” on page 85.
Note
•The Postcard service is not available with some service providers. Please contact your
service provider for more information.
Select Back
Call Log
All Calls
Missed Calls
Received Calls
Dialled Numbers
Call Timers
Call Costs
e_j350.book Page 196 Monday, October 25, 2004 6:33 PM
197
Call Log
Deleting a Call Log
1. In the call log list, press [Options] and select “Delete”.
Call Timers
This function lets you check the duration of your calls.
Checking the Duration of the Last Call and All Calls
“Call Log”
→
“Call Timers”
1. Select “Received Calls” or “Dialled Numbers”.
The duration of the last call and all calls is displayed.
Resetting Call Timers
“Call Log”
→
“Call Timers”
→
“Clear Timers”
1. Enter your handset code.
The default handset code is “9999”. For details on changing the handset code, see “To
Change the Handset Code” on page 192.
(M 11-5)
e_j350.book Page 197 Monday, October 25, 2004 6:33 PM
198
Call Log
Call Costs
This function lets you check the charges for your calls.
Some networks do not support
Charging Advice. Please check with your service provider for availability.
Checking the Cost of the Last Call
“Call Log”
→
“Call Costs”
→
“Last Call”
The cost of the last call is displayed.
Checking the Total Call Cost
“Call Log”
→
“Call Costs”
→
“All Calls”
The cost of all calls is displayed.
Setting the Charge Rate
Set the charge rate to calculate the call cost and set the maximum limit for call cost.
“Call Log”
→
“Call Costs”
→
“Cost Units”
→
“Set Units”
1. Enter your PIN2 code.
2. Enter a currency unit (up to 3 characters).
3. Enter a cost per unit.
To enter a decimal point, press R.
(M 11-6)
e_j350.book Page 198 Monday, October 25, 2004 6:33 PM
199
Call Log
Setting the Charge Limit
This function is useful if you wish to make sure you do not exceed a certain charge limit.
“Call Log”
→
“Call Costs”
→
“Max Cost”
→
“Set Limit”
1. Enter your PIN2 code.
2. Enter a value.
Checking the Residual Credit
“Call Log”
→
“Call Costs”
→
“Residual Credit”
Resetting All Call Costs
“Call Log”
→
“Call Costs”
→
“Clear Costs”
1. Enter your PIN2 code.
e_j350.book Page 199 Monday, October 25, 2004 6:33 PM
200
Connectivity (M 10)
By configuring the settings in this menu, you can connect to
Bluetooth
wireless technology
or infrared enabled phones via these connections, as well as a PC via
Bluetooth
wireless
technology or infrared connections.
Bluetooth
For using the
Bluetooth
wireless function, you need to search for other
Bluetooth
wireless
technology enabled devices to establish contact with your phone. Keep your phone within a
distance of 10 metres before searching.
Using the Bluetooth Wireless Function
To Turn On or Off
“Connectivity”
→
“Bluetooth”
→
“Switch On/Off”
1. Select “On” or “Off”.
The
Bluetooth
wireless setting is activated, and “ ” is displayed.
To Show or Hide Your Phone
“Connectivity”
→
“Bluetooth”
→
“Visibility”
1. Select the desired visibility settings.
“Show My Phone”:
Allows other devices to recognise your phone.
“Hide My Phone”:
Hides your phone from other devices.
Select Back
Connectivity
Bluetooth
Infrared
Network Settings
Internet Settings
Backup/Restore
(M 10-1)
e_j350.book Page 200 Monday, October 25, 2004 6:33 PM
201
Connectivity
To Search for Devices to be Paired
“Connectivity”
→
“Bluetooth”
→
“Search for Devices”
The phone starts searching for devices within 10 metres. A maximum of 16 devices can be
searched for and listed on the displayed.
1. Select the desired device for pairing.
2. Enter the device passcode.
Note
•If the Bluetooth wireless function is off before searching, the phone turns the Bluetooth
wireless function on automatically and starts searching.
•You can only select one device for pairing. To change the paired device, see “Handsfree
Devices”.
Handsfree Devices
You can activate, rename and delete the paired handsfree device in the list.
To Activate a Device
“Connectivity”
→
“Bluetooth”
→
“Handsfree Devices”
1. Select the device you wish to activate.
e_j350.book Page 201 Monday, October 25, 2004 6:33 PM
202
Connectivity
Tip
•You can save battery power by turning the Bluetooth wireless function off while it is not
in use. Turn the Bluetooth wireless function off in “To Turn On or Off” on page 200 or in
“To Turn Off Automatically” on page 204.
•During a call, you can divert voice calls to the paired device. Press [Options] and select
“Enable Bluetooth” or “Disable Bluetooth”. If you wish to disconnect the paired device,
select “Off”.
To Rename a Device
“Connectivity”
→
“Bluetooth”
→
“Handsfree Devices”
1. Highlight the device you wish to rename.
2. Press [Options] and select “Change Name”.
3. Rename the device.
To Clear a Device Name
“Connectivity”
→
“Bluetooth”
→
“Handsfree Devices”
1. Highlight the device you wish to clear.
2. Press [Options] and select “Delete”.
e_j350.book Page 202 Monday, October 25, 2004 6:33 PM
203
Connectivity
Paired Devices
You can rename and delete the paired device in the list.
“Connectivity”
→
“Bluetooth”
→
“Paired Devices”
1. Highlight the desired device.
2. Press [Options].
3. Select “Change Name” or “Delete”.
You can rename or delete by pressing after selecting desired device.
To Send All Data to Other Devices
You can send all the data for applications such as Contacts List, Calendar, Tasks or etc. to
selected devices.
“Connectivity”
→
“Bluetooth”
→
“Send All”
1. Select the desired device.
If a device is not specified, searching starts automatically.
2. Enter your handset code.
The default handset code is “9999”. For details on changing the handset code, see “To
Change the Handset Code” on page 192.
3. Enter the device passcode for unpaired devices.
4. Select the desired data to send.
Note
•If the handsfree device is connected, the confirmation screen to deactivate the handsfree
function is displayed. Press [Yes] to deactivate.
e_j350.book Page 203 Monday, October 25, 2004 6:33 PM
204
Connectivity
Bluetooth Wireless Settings
With this setting you can rename your phone, prevent other phones from recognising your
phone, turn the
Bluetooth
wireless function off automatically to save battery power, etc.
To Rename Your Phone
You can rename your phone. The name is shown in other devices when your phone is
detected.
“Connectivity”
→
“Bluetooth”
→
“Bluetooth Settings”
→
“Device Name”
1. Enter the new device name.
To Turn Off Automatically
“Connectivity”
→
“Bluetooth”
→
“Bluetooth Settings”
→
“Bluetooth Timeout”
1. Select the desired time.
Your phone turns the function off automatically in the specified time.
To Switch the Handsfree Settings
You can switch modes of the handsfree kit between two modes; talking with the handsfree
kit or talking with the phone.
“Connectivity”
→
“Bluetooth”
→
“Bluetooth Settings”
→
“Handsfree Setting”
1. Select “Private mode” or “Handsfree mode”.
“Private mode”: For talking with the handset
“Handsfree mode”: For talking with the handsfree kit
e_j350.book Page 204 Monday, October 25, 2004 6:33 PM
205
Connectivity
Infrared
In order to use the infrared function, you need to search for other infrared enabled devices
to establish contact with your phone. Keep your phone within a distance of 20 centimetres
before searching. The infrared setting will return to off when no data is transmitted/received
via infrared communication.
Turning On or Off
“Connectivity”
→
“Infrared”
→
“Switch On/Off”
1. Select “On” or “Off”.
The infrared setting is activated, and “ ” is displayed.
Sending All Data
“Connectivity”
→
“Infrared”
→
“Send All”
1. Enter your handset code.
The default handset code is “9999”. For details on changing the handset code, see “To
Change the Handset Code” on page 192.
2. Select the desired data to send.
3. Enter the authorisation code.
Network Settings
System Settings
To Select a System Automatically
Each time the power is turned on, your phone always performs the selected system.
(M 10-2)
(M 10-3)
e_j350.book Page 205 Monday, October 25, 2004 6:33 PM
206
Connectivity
“Connectivity”
→
“Network Settings”
→
“System Settings”
1. Select “Auto”.
To Set the System Manually
“Connectivity”
→
“Network Settings”
→
“System Settings”
1. Select “GSM”.
Network Settings
To Select a Network Automatically
Each time the power is turned on, your phone always tries to connect to the preferred
network.
If your phone is not connected to the network, you can perform the following immediately
to establish the preferred network connection.
“Connectivity”
→
“Network Settings”
→
“Network Settings”
→
“Select
Network”
→
“Automatic”
To Set the Network Manually
“Connectivity”
→
“Network Settings”
→
“Network Settings”
→
“Select
Network”
→
“Manual”
1. Select the desired network.
To Add a New Network
“Connectivity”
→
“Network Settings”
→
“Network Settings”
→
“Select
Network”
→
“Add New Network”
If there are no entries, press and go to step 2.
If there is an entry, press and perform the following steps.
e_j350.book Page 206 Monday, October 25, 2004 6:33 PM
207
Connectivity
1. Select “Add”.
2. Enter the country code.
Up to 3 digits code can be entered.
3. Enter the network code.
Up to 3 digits code can be entered.
4. Enter a new network name.
Up to 25 characters can be entered.
5. Select “Select network type”.
6. Select the desired network.
To Change the Position of a Network in the Preferred List
“Connectivity”
→
“Network Settings”
→
“Network Settings”
→
“Select
Network”
→
“Set Preferred”
1. Select the name of the network you wish to change the position in the list.
2. Select “Insert” to insert over the selected position or “Add to end” to insert at the
end.
To Delete a Network from the Preferred List
“Connectivity”
→
“Network Settings”
→
“Network Settings”
→
“Select
Network”
→
“Set Preferred”
1. Select the name of the network you wish to delete.
2. Select “Delete”.
e_j350.book Page 207 Monday, October 25, 2004 6:33 PM
208
Connectivity
To Cut the Network Connection
“Connectivity”
→
“Network Settings”
→
“Network Settings”
→
“Off Line Mode”
1. Select “On” or “Off”.
To Show the Network Information
“Connectivity”
→
“Network Settings”
→
“Network Settings”
→
“Network
Information”
Information about the operator name, package and services are displayed.
Internet Settings
Note
•In normal operations, you do not need to change the settings.
•Internet settings have already been made in your phone depending on your network
operator. You may have restrictions on viewing, deleting, copying or modifying the
settings. Contact your network operator for details.
“Connectivity”
→
“Internet Settings”
→
“Proxy”
Proxy
“Proxy Name”: Proxy name (Unique name)
“IP Address”: IP address
“Access Point”: Access point
“Home”: Home page URL
“Port Number”: Port number (1-65535)
“Authentication Type”: Authentication Type (“HTTP-BASIC” or “HTTP-DIGEST”)
“User Name”: User name for authentication
“Password”: Password for authentication
(M 10-4)
e_j350.book Page 208 Monday, October 25, 2004 6:33 PM
209
Connectivity
“Connectivity
→
“Internet Settings
→
“Access Point”
Access Point
“Access Point Name”: Access point name (Unique name)
“APN”: APN setting
“Authentication Type”: Authentication type (“NONE”, “PAP” or “CHAP”)
“User Name”: User name for access point
“Password”: Password for access point
“DNS”: DNS setting
“Linger Time”: Linger time setting
“Connectivity”
→
“Internet Settings”
→
“Re-Provisioning Settings”
Re-Provisioning Settings
“Execute Pending”: Updates provisioning data.
“Connectivity”
→
“Internet Settings”
→
“Clear DNS Cache”
Clears the DNS cache.
“Connectivity”
→
“Internet Settings”
→
“White List”
White List:
“SMSC Address”: SMSC address
“SM Originating Address”: SM originating address
e_j350.book Page 209 Monday, October 25, 2004 6:33 PM
210
Connectivity
Application Settings
“Connectivity”
→
“Internet Settings”
→
“Application”
WAP Settings
“Profile Name”: WAP profile name (Unique name)
“Proxy”: Proxy setting for WAP
MMS Settings
“Profile Name”: MMS profile name (Unique name)
“Proxy”: Proxy setting for MMS
“Relay Server URL”: MMS relay server
Email Settings
“Account Name”: Email account name (Unique name)
“POP3”: Server name, user ID, password and port number for
POP3 server
“SMTP”: Server name, user ID, password, port number for SMTP
server and SMTP Authentication
“Access Point”: Access point for email
“Email Address”: Email address
Streaming Settings
“Profile Name”: Profile name for streaming (Unique name)
“Proxy Address”: Proxy address
“Port Number”: Port number (1-65535)
“Access Point”: Access point
e_j350.book Page 210 Monday, October 25, 2004 6:33 PM
211
Connectivity
To Activate the WAP/MMS/Email/Streaming Profile
“Connectivity”
→
“Internet Settings”
→
“Application”
1. Select from “WAP Settings”, “MMS Settings”, “Email Settings” or “Streaming
Settings”.
2. Highlight the desired profile.
3. Press [Options] and select “Activate”.
To Edit the WAP/MMS/Email/Streaming Profile
“Connectivity”
→
“Internet Settings”
→
“Application”
1. Select from “WAP Settings”, “MMS Settings”, “Email Settings” or “Streaming
Settings”.
2. Highlight the desired profile.
3. Press [Options] and select “Edit”.
4. Edit the desired item.
To Copy the WAP/MMS/Email/Streaming Profile
“Connectivity”
→
“Internet Settings”
→
“Application”
1. Select from “WAP Settings”, “MMS Settings”, “Email Settings” or “Streaming
Settings”.
2. Highlight the desired profile.
3. Press [Options] and select “Copy”.
4. Edit the new profile name.
e_j350.book Page 211 Monday, October 25, 2004 6:33 PM
212
Connectivity
To Delete the WAP/MMS/Email/Streaming Profile
“Connectivity”
→
“Internet Settings”
→
“Application”
1. Select from “WAP Settings”, “MMS Settings”, “Email Settings” or “Streaming
Settings”.
2. Highlight the desired profile.
3. Press [Options] and select “Delete”.
4. Press [Yes].
Backup/Restore
With a memory card inserted in your phone, you can make backup files of Bookmarks, Text,
Contacts, Calendar and Tasks in the handset memory card to the memory card. You can
also restore the backup data from the memory card.
Making a Backup File on the Memory Card
“Connectivity”
→
“Backup/Restore”
→
“Backup”
1. Enter your handset code.
The default handset code is “9999”. For details on changing the handset code, see “To
Change the Handset Code” on page 192.
2. Press [OK].
3. Select the desired item to backup.
(M 10-5)
e_j350.book Page 212 Monday, October 25, 2004 6:33 PM
213
Connectivity
To Backup All Files
“Connectivity”
→
“Backup/Restore”
→
“Backup”
1. Enter your handset code.
2. Press [OK].
3. Select “Select All”.
Restoring a Backup File
“Connectivity”
→
“Backup/Restore”
→
“Restore”
1. Enter your handset code.
2. Press [OK].
3. Select the desired item.
4. Select the desired file to restore.
A confirmation message indicates deletion from the memory card is displayed on the
screen.
5. Press [Yes].
To Restore All Files
“Connectivity”
→
“Backup/Restore”
→
“Restore”
1. Enter your handset code.
2. Press [OK].
3. Select “Select All”.
A confirmation message indicating deletion from the memory card is displayed on the
screen.
4. Press [Yes].
e_j350.book Page 213 Monday, October 25, 2004 6:33 PM
214
Connectivity
To Delete a Backup File
“Connectivity”
→
“Backup/Restore”
→
“Restore”
1. Enter your handset code.
2. Press [OK].
3. Select the desired item.
4. Highlight the desired file.
5. Press [Options] and select “Delete”.
A confirmation message to delete the selected file is displayed on the screen.
6. Press [Yes].
e_j350.book Page 214 Monday, October 25, 2004 6:33 PM
215
Connecting 802SH to Your PC
You can use the following functions by connecting the 802SH to your PC using an infrared
port, USB port* or
Bluetooth
wireless technology port:
• 3G/GSM GPRS modem
• Handset Manager for 802SH
* Requires an optional USB data cable XN-1DC30 for USB port connection.
System Requirements
Operating System:
Windows® 98*, Windows® Me, Windows® 2000**, Windows® XP***
* Windows® 98 Second Edition, Windows® 98 Service Pack 1 with Internet Explorer 5.01
or later
** Service Pack 4
*** Service Pack 1a
Supported Software:
Microsoft® Outlook/Outlook Express
Interface:
Infrared port, USB port or
Bluetooth
wireless port
CD-ROM drive
e_j350.book Page 215 Monday, October 25, 2004 6:33 PM
216
Connecting 802SH to Your PC
3G/GSM GPRS Modem
You can use 802SH as a 3G/GSM GPRS modem to access the Internet from your PC.
Connect your phone to your PC via
Bluetooth
wireless technology or USB interface. Software
installation on your PC is required. For details, see “Software Installation” on page 217.
Modem via the USB Cable
To use the modem function using a USB cable, use the cable mentioned above and see the
instructions accompanying the cable.
Modem via Bluetooth connection
To use the modem function via
Bluetooth
wireless technology interface, see “Using the
Bluetooth Wireless Function” on page 200 and turn the modem function on.
For details on software support, refer to the following site:
http://www.sharp-mobile.com
Note
•Modem communication is not possible while communicating with the Handset Manager
via Bluetooth wireless technology, infrared or USB interface.
•Your phone exhausts the battery when connected to a PC, even when not
communicating.
e_j350.book Page 216 Monday, October 25, 2004 6:33 PM
217
Connecting 802SH to Your PC
Handset Manager
You can transmit the following items between your phone and your PC, and can use
Contacts List entries on your PC:
• My Items files (pictures/sounds/video clips/Other Documents data)
• Contacts List entries
• Schedule entries
To use the Handset Manager function, see “Connecting 802SH to Your PC” on page 215
and set your phone to Data Transfer mode.
For details on software support, refer to the following site:
http://www.sharp-mobile.com
Software Installation
1. Insert the supplied CD-ROM into your CD-ROM drive.
The 802SH CD-ROM screen is displayed.
If the 802SH CD-ROM screen is not displayed, double-click [Launcher.exe] in your
CD-ROM.
2. Press the desired button.
The installation starts.
3. Follow the on-screen instructions to complete installation.
e_j350.book Page 217 Monday, October 25, 2004 6:33 PM
218
Connecting 802SH to Your PC
Note
•The phone may not recognise the USB data cable if it is connected while an application
(Camera, My Items, etc.) is running. Connect the USB data cable during stand-by.
Infrared communication
•Infrared ports need to be aligned with each other.
•Infrared ports need to be placed within 20 cm of each other and within a 30° angle.
3G/GSM GPRS modem
•It is not recommended that you make or answer calls when you are using 802SH as a
3G/GSM GPRS modem. The operation may be interrupted.
Handset Manager
•Some large files may not be able to be transmitted from the PC to the phone.
•Applications (Camera, My Items, etc.) do not run when the phone is connected to the PC
via Bluetooth wireless technology interface, infrared port or USB data cable.
Infrared port
e_j350.book Page 218 Monday, October 25, 2004 6:33 PM
219
Troubleshooting
Problem Solution
The phone does not turn on. •Make sure the battery is properly inserted and charged.
PIN code or PIN2 code is rejected.
•Make sure you have entered the correct code (4 to 8 digits).
•Your SIM/USIM card/protected functions will become locked after three unsuccessful attempts.
•Contact your SIM/USIM provider if you do not have the correct PIN code.
The SIM/USIM card becomes locked.
•Enter the PUK code (8 digits) provided by your service provider (if supported).
•If the attempt is successful, enter the new PIN code and confirm your phone is operational again.
Otherwise contact your dealer.
The display is difficult to read. •Adjust the backlight brightness for the display.
Phone functions do not work after the
phone is turned on.
•Check the radio signal strength indicator as you may be outside the service area.
•Check to see if any error message is displayed when you turn your phone on. If so, contact your dealer.
•Make sure the SIM/USIM card is correctly inserted.
Calls cannot be made or received.
•If the message “SIM card error” is displayed when the phone is switched on, you cannot use your SIM/
USIM card or the SIM/USIM card is damaged. Contact your dealer or network service provider.
•Check your call barring, fixed dialling setting, remaining battery and call forwarding settings.
•Check if your phone is currently performing data communication using Infrared (IrDA),
Bluetooth
wireless
technology interface or a USB data cable.
•Check the remaining balance if you are using a pre-paid SIM/USIM card.
Call quality is poor. •Your current location may not provide good call quality (i.e., in a car or train). Move to a location where
radio signal strength is greater.
e_j350.book Page 219 Monday, October 25, 2004 6:33 PM
220
Troubleshooting
Cannot access network service. •Check where your account has been registered and where the service is available.
Cannot send or receive text message. •Make sure you are correctly subscribed for the Short Message Service, that the network supports this
service, and that the centre number is set up correctly. If not, contact your network service provider.
Cannot connect to Multimedia Messaging
Service provider.
•MMS settings and configuration may be missing or incorrect or the network does not support it. Check
your service provider’s access point number.
Contact your service provider to confirm the correct settings.
Limited memory available. •Delete any unnecessary data.
Call is terminated unexpectedly. •Magnetised objects such as health necklaces placed near the phone may terminate the call. Keep your
phone away from such objects.
No entries are displayed in the Contacts
List. •Confirm that the Contacts Location setting (Handset or SIM/USIM) is made correctly.
Fax transmission failure •Before transmitting fax data, configure your fax software to use the software flow control.
•Use of the optional data cable is recommended for transmitting fax data.
Cannot receive OBEX data. •The OBEX data can only be received only during stand-by. The message “Please return to stand-by.”
is displayed.
Problem Solution
e_j350.book Page 220 Monday, October 25, 2004 6:33 PM
221
Safety Precautions and Conditions of Use
Your phone conforms to international regulations insofar as it is used under normal
conditions and in accordance with the following instructions.
CONDITIONS OF USE
Electromagnetic waves
• Do not switch on your phone aboard an aircraft (as your phone may interfere with the
aircraft’s electronic systems). Current legislation forbids this use and legal action can be
taken against the user.
• Do not switch on your phone in a hospital, except in designated areas.
• Use of your phone’s function may affect the performance of medical electronic units
(pacemakers, hearing aids, insulin pumps, etc.). When the phone function is on, do not
bring it near medical equipment or into areas in which medical equipment is being used.
If you have a hearing aid or a pacemaker, only use the phone on the opposite side of your
body from where it is located. The phone should be kept at least 6 inches (15.24 cm)
from a pacemaker ANYTIME the phone is switched on.
• Do not switch on your phone near gas or flammable substances.
• Observe the rules concerning the use of mobile phones at gasoline stations, chemical
plants and at all sites where a risk of explosion exists.
e_j350.book Page 221 Monday, October 25, 2004 6:33 PM
222
Safety Precautions and Conditions of Use
Caring for your phone
• Do not allow children to use your phone without supervision.
• Do not open or attempt to repair your phone yourself. The product can only be repaired
by authorised service personnel.
• Do not drop your phone or subject it to severe impacts. Bending the body and pushing
the display or keys with extreme force could damage the phone.
• Do not use solvents to clean your phone. Use only a soft, dry cloth.
• Do not carry your phone in your back pocket as it could break when you sit down. The
display is made of glass and is particularly fragile.
• Avoid touching the external connector on the underside of the phone, since the delicate
components within can be damaged by static electricity.
e_j350.book Page 222 Monday, October 25, 2004 6:33 PM
223
Safety Precautions and Conditions of Use
Battery
• Use your phone only with batteries, chargers and accessories recommended by the
manufacturer. The manufacturer disclaims any liability for damage caused by the use of
other chargers, batteries or accessories.
•Network configuration and phone usage will affect talk-time and stand-by
time.
Using the games or camera will hasten battery consumption.
•When the battery charging alert is displayed on the screen, charge the battery as
soon as possible. If you continue using your phone ignoring the alert, the phone may
cease to function, and all data and settings you have stored may be lost at any moment.
• Before removing the battery from the phone, make sure the phone is switched off.
• Replace and charge the new battery as soon as possible after removing the old one.
• Do not touch the battery terminals. Batteries can cause damage, injury or burns if a
conductive material touches exposed terminals. When the battery is detached from the
phone, use a cover made of non-conductive material for keeping and carrying the battery
safely.
• Recommended temperature for using and storing batteries is approximately 20°C.
• The batteries’ performance is limited in low temperatures, particularly below 0°C and the
phone may not work temporarily regardless of the amount of remaining battery power.
• Exposing the phone to extreme temperatures will shorten battery life.
e_j350.book Page 223 Monday, October 25, 2004 6:33 PM
224
Safety Precautions and Conditions of Use
• The battery can be charged and discharged hundreds of times but it will eventually wear
out. When the operating time (talk-time and stand-by time) is noticeably shorter than
normal, it is time to buy a new battery.
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE,
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS
See “Battery Disposal” on page 21.
Aerial Care
• Do not cover the top of the phone (p. 17, No. 20) with your hand when in use as this may
interfere with the performance of the built-in aerial. Call quality may deteriorate leading
to shortened talk-time and stand-by time because the mobile phone has to operate on a
higher power level than is necessary.
e_j350.book Page 224 Monday, October 25, 2004 6:33 PM
225
Safety Precautions and Conditions of Use
• Use only the aerial supplied or one approved by Sharp for your mobile phone. Using
unauthorised or modified aerials may damage the mobile phone. Moreover, since the
mobile phone may violate the appropriate regulations, it may lose performance or exceed
the limitation of SAR levels.
• To avoid impaired performance, do not damage the aerial of the mobile phone.
• While talking directly to the microphone, please hold the mobile phone so that the aerial
is upwards over your shoulder.
• To avoid interfering with blasting operations, please turn off the mobile phone in a
blasting area or in a place where a “turn off two-way radio” sign is posted.
e_j350.book Page 225 Monday, October 25, 2004 6:33 PM
226
Safety Precautions and Conditions of Use
Camera Operation
• Learn picture quality, file formats, etc. beforehand.
The taken pictures can be saved in JPEG format.
• Be careful not to move your hand while taking pictures.
If the phone moves while taking a picture, the picture can become blurred. When taking
a picture, hold the phone firmly to prevent it from moving, or use the delay timer.
• Clean the lens cover before taking a picture.
Fingerprints, oils, etc. on the lens cover hinder clear focusing. Wipe them off with a soft
cloth before taking a picture.
Others
• As with any electronic storage unit, data may be lost or corrupted under various
circumstances.
e_j350.book Page 226 Monday, October 25, 2004 6:33 PM
227
Safety Precautions and Conditions of Use
• Before connecting the phone with a PC or a peripheral unit, read the operation manual
for the other unit carefully.
• If the phone’s battery has been removed for some time, or the phone has been reset, the
unit’s clock and calendar may be reinitialised. The date and time should be updated in
this case.
ENVIRONMENT
• Keep your phone away from extreme heat. Do not leave it on the dashboard of a car or
near a heater. Do not leave it in any place that is extremely damp or dusty.
• Since this product is not waterproof, do not use it or store it where fluids such as water
can splash onto it. Raindrops, water spray, juice, coffee, steam, perspiration, etc. will also
cause malfunctions.
e_j350.book Page 227 Monday, October 25, 2004 6:33 PM
228
Safety Precautions and Conditions of Use
PRECAUTIONS CONCERNING VEHICLE USE
• It is the user’s responsibility to check the local laws governing the use of a mobile phone
in vehicles. Pay full attention to driving. Pull off to the side of the road, park the car, and
switch off the engine before making or answering a call.
• Use of your phone’s function may interfere with the vehicle’s electronic systems, such as
the ABS anti-lock brakes or the air-bag. To ensure no such problem occurs, please check
with your dealer or car manufacturer before connecting your phone.
• Only allow qualified service maintenance personnel to install the vehicle accessories.
The manufacturer disclaims any liability for damage which may result as a consequence of
improper use or use contrary to the instructions contained herein.
e_j350.book Page 228 Monday, October 25, 2004 6:33 PM
229
Safety Precautions and Conditions of Use
SAR
Your Sharp mobile phone has been designed, manufactured and tested so as not to exceed
the limits for exposure to electromagnetic fields recommended by the Council of the
European Union. These limits are part of comprehensive guidelines developed by
independent scientific organisations. The guidelines include a substantial safety margin
designed to assure the safety of the phone user and others and to take into account
variations in age and health, individual sensitivities and environmental conditions. European
standards provide for the amount of radio frequency electromagnetic energy absorbed by
the body when using a mobile phone to be measured by reference to the Specific Absorption
Rate (SAR). The SAR limit for the general public is currently 2 watts per kilogram averaged
over 10 grams of body tissue. Your Sharp mobile phone SAR value is 0.686 watts per
kilogram. This has been tested to ensure that this limit is not exceeded even when the phone
is operating at its highest certified power. In use however your Sharp mobile phone may
operate at less than full power because it is designed to use only sufficient power to
communicate with the network.
e_j350.book Page 229 Monday, October 25, 2004 6:33 PM
230
Safety Precautions and Conditions of Use
PRECAUTIONS FOR USE IN USA
FCC Declaration of Conformity
This mobile phone 802SH with PC/Data interface cable XN-1DC30 complies with part 15 of
the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Responsible Party:
SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, New Jersey 07430
TEL: 1-800-BE-SHARP
Tested To Comply With FCC Standards
FOR HOME OR OFFICE USE
FCC Notice
The phone may cause TV or radio interference if used in close proximity to receiving
equipment. The FCC can require you to stop using the phone if such interference cannot be
eliminated.
Information To User
This equipment has been tested and found to comply with the limits of a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications.
e_j350.book Page 230 Monday, October 25, 2004 6:33 PM
231
Safety Precautions and Conditions of Use
However, there is no guarantee that interference will not occur in a particular installation; if
this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
1. Reorient/Relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modifications not expressly approved by the manufacturer
responsible for compliance could void the user’s authority to operate the equipment.
Exposure to Radio Waves
THIS MODEL PHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE
TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not
to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal
Communications Commission of the U.S. Government. These limits are part of
comprehensive guidelines and establish permitted levels of RF energy for the general
population. The guidelines are based on standards that were developed by independent
scientific organizations through periodic and thorough evaluation of scientific studies. The
standards include a substantial safety margin designed to assure the safety of all persons,
regardless of age and health.
e_j350.book Page 231 Monday, October 25, 2004 6:33 PM
232
Safety Precautions and Conditions of Use
The exposure standard for wireless mobile phones employs a unit of measurement known
as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg.* Tests
for SAR are conducted using standard operating positions specified by the FCC with the
phone transmitting at its highest certified power level in all tested frequency bands.
Although the SAR is determined at the highest certified power level, the actual SAR level of
the phone while operating can be well below the maximum value. This is because the phone
is designed to operate at multiple power levels so as to use only the power required to reach
the network. In general, the closer you are to a wireless base station antenna, the lower the
power output.
Before a phone model is available for sale to the public, it must be tested and certified to
the FCC that it does not exceed the limit established by the government-adopted
requirement for safe exposure. The tests are performed in positions and locations (e.g., at
the ear and worn on the body) as required by the FCC for each model. The highest SAR value
for this model phone when tested for use at the ear is 0.549 W/kg and when worn on the
body, as described in this user guide, is 0.326 W/kg. Body-worn Operation; This device was
tested for typical body-worn operations with the back of the phone kept 1.5 cm from the
body. To maintain compliance with FCC RF exposure requirements, use accessories that
maintain a 1.5 cm separation distance between the user’s body and the back of the phone.
The use of belt-clips, holsters and similar accessories should not contain metallic
components in its assembly.
The use of accessories that do not satisfy these requirements may not comply with FCC RF
exposure requirements, and should be avoided. While there may be differences between
the SAR levels of various phones and at various positions, they all meet the government
requirement for safe exposure.
e_j350.book Page 232 Monday, October 25, 2004 6:33 PM
233
Safety Precautions and Conditions of Use
The FCC has granted an Equipment Authorization for this model phone with all reported SAR
levels evaluated as in compliance with the FCC RF emission guidelines. SAR information on
this model phone is on file with the FCC and can be found under the Display Grant section
of http://www.fcc.gov/oet/fccid after searching on FCC ID APYHRO00039.
Additional information on Specific Absorption Rates (SAR) can be found on the Cellular
Telecommunications & Internet Association (CTIA) web-site at http://www.phonefacts.net.
* In the United States and Canada, the SAR limit for mobile phones used by the public is
1.6 watts/kg (W/kg) averaged over one gram of tissue. The standard incorporates a
substantial margin of safety to give additional protection for the public and to account for
any variations in measurements.
e_j350.book Page 233 Monday, October 25, 2004 6:33 PM
For your safety concerning radio frequency radiation exposure pursuant
to FCC guidelines, please keep a separation of 30cm or more away from an
optional antenna. The correlation between minimum safe distance and antenna
gain is given below, you can determine the minimum separation required by
checking your antenna gain.
Antenna Gain Minimum Safe Distance
2dBi 11cm
6dBi 18cm
10dBi 28.2cm
Optional Mobile Phone Antenna for Vehicle Use
234
Specifications and Optional Accessories
Specifications
Weight: Approximately 141 g (with battery)
Dimensions (W × H × D): Approximately 50 × 102 × 26 mm (without protruding parts)
Battery: Lithium Ion, 3.7 V, 870 mAh
Optional Accessories
• Lithium Ion Battery (XN-1BT90)
• Cigarette Lighter Charger (XN-1CL30)
• USB Data Cable (XN-1DC30)
• AC Charger (XN-1QC30, XN-1QC31)
• External Antenna Cable (XN-1AT90)
• Audio Remote-Controller (XN-1AR90)
• Car Holder (XN-1CH90)
• Desktop Holder (XN-1DH90)
• Stereo Headset (XN-1HS90)
• Handsfree Microphone Unit (XN-1HU90)
The above accessories may not be available in all regions.
For details, please contact your dealer.
e_j350.book Page 234 Monday, October 25, 2004 6:33 PM
235
Index
Symbols
#/Flash Light Key 16
* /Shift Key 14
A
Alarms 150
Resetting 152
Setting 150
Area Info 98
Enabling/Disabling 98
B
Backup/Restore 212
Making a Backup File 212
Restoring a Backup File 213
Battery 20
Charging 22
Disposal 21
Inserting 20
Removing 21
Battery Cover 17
Battery Level Indicator 23
Bluetooth Wireless Function 200
Built-in Aerial 17
C
Calculator 152
Calendar
Creating 146
Deleting Schedule Entries 149
Editing a Schedule Entry 148
Receiving a Schedule Entry 148
Sending a Schedule Entry 147
Viewing a Schedule Entry 148
Viewing the Memory Status 149
Call Costs 198
Checking the Cost of the Last Call 198
Checking the Residual Credit 199
Checking the Total Call Cost 198
Resetting All Call Costs 199
Setting the Charge Limit 199
Setting the Charge Rate 198
Call Log 196
Deleting 197
Sending Messages 196
Viewing 196
Call Settings 182
Auto Redial 188
Call Information 185
Call Waiting 184
Changing the Network Password 188
Displaying Call Timer 188
Diverts 182
Fixed Dialling No. 187
Minute Minder 188
Rejecting an Incoming Call 187
Restrict Calls 185
Showing Your Phone Number 184
Call Timers 197
Checking the Duration of the Last Call
and All Calls 197
Resetting Call Timers 197
Camera (digital/video) 68
Adjusting the Exposure 70, 80
Auto Save 77
Changing the Picture Size 83
Continuous Shoot 73
Mobile Light 71, 80
Recording Close-up Video Clips 79
Recording Video Clips 78
Recording with Sound 82
Saving 76, 83
Selecting a Frame 74
Selecting the Picture Quality 75
Selecting the Picture Size 70
Selecting the Recording Time 81
Selecting the Scene 72
Selecting the Shutter Sound 75
Selecting Video Quality 82
Sending 69, 79
Switching to the Photo Camera Mode 82
Switching to the Video Camera Mode 74
Taking Close-up Pictures 69
Taking Pictures 68
Using the Timer 72
Using the Zoom Function 80
Viewing 80
Cell Broadcasts 96
Enabling/Disabling 96
Reading 96
Setting Languages 96
e_j350.book Page 235 Monday, October 25, 2004 6:33 PM
236
Index
Subscribing 97
Centre Key 14, 29
Characters 51
Changing the Input Languages 53
Changing the Input Mode 53
Using Templates 55
Clear/Back Key 15
Conditions of Use 221
Connectivity 200
Bluetooth 200
Infrared 205
Internet Settings 208
Network Settings 205
Contacts List 57
Assigning a Ringtone or a Ring Video
Clip 64
Changing the List 58
Changing the List Order 59
Changing the Name Order 58
Copying 61
Creating 59
Deleting 62
Dialling 61
Editing 62
Finding 61
Manage Group 63
Memory Status 65
Receiving 67
Selecting the Storage Memory 59
Sending 66
Setting in the Speeddial List 65
Speeddial List 65
Viewing My Contact Details 60
Countdown Timer
Editing the Countdown Time 164
D
Display 15
Adjusting the Brightness of the Backlight
178
Assigning the Pictures 176
Backlight 178
Setting My Pictures 175
Setting the Display Saving 179
Setting the Font Weight 177
Setting the Greeting Message 177
Showing the Clock 177
Wallpaper 175
Display Indicators 29
Display Position
Normal Position 32
E
Earpiece 14
Earpiece Volume 39
Emergency Calls 35
End/Power Key 15
Expenses Memo 165
Modifying the Category Name 166
Recording 165
Viewing Totals 165
External Camera 17
External Connector 17
F
Flash Light Key 16
Functions
Navigating 33
G
Games & More 140
Activating Files with Copyright
Protection (DRM) 133
Deleting an Application 142
Downloading 131
Executing 132
Java™ Information 145
More Games 133
Receiving 135
Sending 134
Setting Network Access 141
Setting Security Level 140
Settings 143
Switching the Screensaver On or Off
142
Using 131
Viewing Application Information 142
H
Handset Code 192
Handset Lock 192
Handsfree Microphone Connector 17
e_j350.book Page 236 Monday, October 25, 2004 6:33 PM
237
Index
I
Incall Menu (Video Call) 46
Changing the Image of Yourself 46
Muting the Microphone 46
Swapping Images 46
Turning the Speaker On and Off 47
Video Call Settings 47
Incall Menu (Voice Call) 39
Accessing SMS/MMS Menu during a
Call 40
Adjusting the Earpiece Volume 39
Call Waiting 41
Conference Call 41
Muting the Microphone 43
Putting a Call on Hold 40
Turning the Speaker On and Off 39
Infrared 205
Infrared Port 18
International Calls 36
Internet Settings 208
J
Java™ Applications 140
K
Keypad 16
Keypad Lock 28
L
Language Setting 182
Left Soft Key 14
M
Macro Switch 17
Master Reset 194
Media Player 107
Music Player 107
Switching between Music Player and
Video Player 107
Video Player 110
Memory Card
Inserting 25
Removing 26
Memory Card Slot Cover 18
Memory Settings 194
Formatting Memory Card 194
Viewing the Memory Status 194
Menu and Shortcut 49
Messages (MMS/SMS/Email)
Calling the Phone Number 91
Creating 85
Downloading 92
Email Settings 101
Forwarding 93
General Settings 98
Locking or Unlocking 93
MMS Settings 101
Reading 91
Remote Forward 93
Replying 92
Sending a Message in the Drafts Box 90
Sending with Postcard 94
SMS Settings 100
Sorting the Messages 93
Storing the Phone Number 91
Microphone 15
Mobile Light 17
Monaural Speaker 17
Multimedia Key 15
Music Player 107
Adding a File to the Playlist 108
Adding a New Playlist 110
Playing Back 107
Searching a File to Be Played Back 108
Streaming 109
My Items 114
Bookmarks 135
Games & More 131
My Saved Page 135
Other Documents 137
Pictures 115
Sounds & Ringtones 126
Text Templates 136
Videos 121
N
Navigation Keys 14
Network Settings 205
O
Organiser 146
Alarms 150
e_j350.book Page 237 Monday, October 25, 2004 6:33 PM
238
Index
Calculator 152
Calendar 146
Countdown Timer 164
Expenses Memo 165
Phone Help 166
Scanner 155
Stopwatch 159
Tasks 160
Voice Recorder 154
World Clock 163
P
PC Connection 215
3G/GSM GPRS Modem 216
Handset Manager 217
Software Installation 217
System Requirements 215
Phone Help 166
Pictures
Adjusting the Size 117
Downloading 120
Editing 116
Operating 118
Saving to Contacts List Entries 116
Sending a Picture File 117
Switching the Memory Source 115
Uploading 120
Viewing 115
Power On and Off 26
Profiles 168
Activating 168
Any Key Answer 174
Assigning a Ring Video Clip File 171
Assigning a Ringtone 170
Customising 168
External Light Colour 174
Keypad Tones 172
Message Notification 172
Resetting 169
Ringer Volume 169
Vibration 173
R
Redialling 37
Right Soft Key 15
S
Safety Precautions 221
Scanner 155
Checking the Information of the Scanned
Data 159
Creating QR Codes 157
Deleting the Scanned Data 158
Reading Barcodes 155
Renaming the Scanned Data 159
Scanning Texts 157
Screensavers 142
Setting Applications 143
Security 191
Changing the PIN2 Code 192
Enabling/Disabling the PIN Code 191
Handset Lock 192
Phone Lock 193
Showing Secret Data 193
Send/Redial Key 14
Shortcut Key 14
Side Keys 18
SIM Application 167
SIM Card 20
Inserting 20
Removing 21
Small Light 18
Sound Settings 179
Sounds & Ringtones
Downloading 130
Operating 128
Playing Back 126
Sending a Sound File 127
Switching the Memory Source 126
Uploading 130
Using the Sound Files as a Ringtone 127
Speed Dialling 36
Stopwatch 159
Sub Camera (Internal Camera) 15
Switching the Screensaver On or Off 142
T
Tasks
Creating 160
Deleting 163
e_j350.book Page 238 Monday, October 25, 2004 6:33 PM
239
Index
Editing 161
Sending 162
Setting the Alarm 160
Viewing the Memory Status 162
Time & Date 180
Customising the Time Zone 181
Selecting the Date Format 180
Selecting the Time Format 180
Setting the Calendar Format 181
Setting the Daylight Saving 180
Setting the Time Zone 181
Troubleshooting 219
V
Video Call
Answering 45
Letting the Caller Know You are
Unavailable 45
Making 44
Rejecting 45
Status Indicators 44
Video Call Settings 47, 189
Assigning Hold Guidance Picture 190
Backlight 189
Mute 189
Selecting Picture Quality 189
Video Clip
Downloading 125
Operating 122
Playing Back 121
Sending a Video Clip File 121
Switching the Memory Source 121
Uploading 124
Video Player 110
Adding a File to the Playlist 111
Adding a New Playlist 112
Backlight 113
Editing the Video Clip File 113
Playing Back Video Clip Files 110
Searching a File to Be Played Back 111
Streaming 112
Vodafone live! 102
Voice Call 35
Answering 37
Call Waiting 41
Conference Call 41
Earpiece Volume 39
Making 35
Muting 43
Putting on Hold 40
Rejecting 38
Speed Dialling 36
Voice Mail Key 14
Voice Recorder 154
Recording 154
Selecting Storage Memory 155
Sending 154
Viewing Record Time 155
W
WAP Browser
Browser Menu 104
Navigating a WAP Page 103
Starting 103
World Clock
Setting the Daylight Saving 164
Setting the Time Zone 163
e_j350.book Page 239 Monday, October 25, 2004 6:33 PM
240
List of Menu Functions
Menu No./
Main Menu Menu No./
Sub Menu1
1Games & More
1Games
2Screensavers
3Settings
4Java™ Information
2Vodafone live!
3Media Player
4Messages
1Create New
2Inbox
3Drafts
4Templates
5Sent
6Outbox
7Iive! Studio
8Messenger
9Voice Mail
10 Cell Broadcasts
11 Area Info
12 Settings
13 Memory Status
5Camera
6My Items
1Pictures
2Videos
3Sounds & Ringtones
4Games & More
5Bookmarks
6My Saved Page
7Text Templates
8Other Documents
7Organiser
1Calendar
2Alarms
3Calculator
4Voice Recorder
5Scanner
6Stopwatch
7Tasks
8World Clock
9Countdown Timer
10 Expenses Memo
11 Phone Help
8Contacts
1Contacts List
2Manage Group
3Speeddial List
4My Contact Details
5Advanced
9SIM Application
10 Connectivity
1Bluetooth
2Infrared
3Network Settings
4Internet Settings
5Backup/Restore
Menu No./
Main Menu Menu No./
Sub Menu1
e_j350.book Page 240 Monday, October 25, 2004 6:33 PM
241
List of Menu Functions
Menu No./
Main Menu Menu No./
Sub Menu1
11 Call Log
1All Calls
2Missed Calls
3Received Calls
4Dialled Numbers
5Call Timers
6Call Costs
12 Settings
1Profiles
2Display Settings
3Sound Settings
4Time & Date
5Language
6Call Settings
7Video Call Settings
8Security Settings
9Memory Settings
10 Master Reset
e_j350.book Page 241 Monday, October 25, 2004 6:33 PM
