Personal Entertainment Organizer
PEG-NZ90
© 2003 Sony Corporation
Read
This
First
Operating Instructions
Checking the package contents
Sony CLIÉ
™
handheld components
Charging your Sony
CLIÉ™ handheld
Performing the initial
settings
Basic operations of your
Sony CLIÉ
™
handheld
1
2
3
4
Enjoying your CLIÉ™
handheld
Using applications
Taking images/movies
Using your CLIÉ
™
handheld
with your computer
5
6
2
About this manual
This manual provides an overview of your CLIÉ™ handheld’s features including information
about setting up your CLIÉ™ handheld and what you can do with your CLIÉ™ handheld.
Checking the package
contents
Sony CLIÉ™ handheld
components
Charging your Sony
CLIÉ™ handheld
Performing the initial
settings
Basic operations of your
Sony CLIÉ™ handheld
Using applications
Page 10
Make sure that all the accessories are
supplied in the package.
Page 12
Learn about the parts of your CLIÉ
handheld and other accessories.
Page 19
Be sure to charge your CLIÉ
handheld before you start using it
for the first time.
Page 23
Configure the initial settings before
operating your CLIÉ handheld.
Page 29
Learn about the basic operations of
your CLIÉ handheld.
Page 73
Learn about your CLIÉ handheld’s
features.
Page 86
Learn about the applications supplied
with your CLIÉ handheld.
Enjoying your CLIÉ™
handheld
Taking images/movies
Using your CLIÉ™ handheld
with your computer
Page 50
Learn about the basic operations of
your CLIÉ handheld.
Page 65
Use your CLIÉ handheld with your
computer.
3
Refer to the following together with this manual.
Handbook (A PDF file in the CD-ROM)
• When using CLIÉ handheld for the first time
The basic features and operations are explained in detail.
• CLIÉ handheld advanced operations
The convenient features and how to make full use of your
CLIÉ handheld are explained in detail.
CLIÉ Application Manual (HTML format:
Start up on a computer)
The manual explains about how to use the supplied
applications in detail.
For details on using the manual, refer to “Using CLIÉ
Application Manual” on page 86 in this manual.
Troubleshooting Q&A
The manual helps in solving problems that you may face
while using your CLIÉ handheld.
4
