User Manual Part 2
18
Cautions
Briey press the Voice Recording ( ) button to turn the audio recording on or o.
2-10. Audio Recording
Users do not reserve the right to use the product for purposes other than as specied in this user guide.
According to the Personal Information Protection Act and other related regulations, the user/owner may
be held liable if the video and/or conversation recorded by the device are distributed without their
consent. Thus, special attention should be paid in using this product.
Press and hold the FORMAT button for 3 seconds to initiate memory card format.
2-11. Formatting MicroSD Card
Press Briey
19
Basics
02
The system will automatically be updated if the MicroSD card contains the rmware upgrade le.
The device restarts automatically after the upgrade has been completed.
Make sure your device is always up to date with latest rmware.
Please check back frequently at THINKWARE website (www.thinkware.com) for the latest rmware updates.
Do NOT disconnect your device from power while it is being updated. This will result in damage to the
dash cam.
2-13. Upgrading Firmware
Press and hold REC and FORMAT buttons simultaneously to reset the device settings to default factory
settings.
2-12. Initializing Device Settings
20
3-1. Thinkware Dash Cam Mobile Viewer
3. Mobile Viewer Application
3-1-1. Connect Wi-Fi with Password
①
Download and install Thinkware Dash Cam Mobile Viewer application
②
Press briey the Wi-Fi button on the dash cam to enter Wi-Fi connection mode
③
(Make sure to turn on the Wi-Fi in the device setting for iOS devices) In the Thinkware Dash Cam Mobile
Viewer application, turn on the Wi-Fi option, select “thinkware” from SSID list, and enter password as
“123456789”
Password is only required during rst time you try to connect.
The device will auto-connect in subsequent connections.
The distance range between the dash cam and connecting smart device is approximately 10 meters (33ft)
in an open eld environment.
Use of ADAS features (road safety warning system) are restricted while being accessed using Thinkware
Dash Cam Mobile Viewer.
When device and mobile phone are connected over Wi-Fi, all control buttons of device will not be working,
except power button.
Cautions
※ Dash cam will automatically turn o the Wi-Fi connection mode if not connected within 2 minute.
Thinkware Dash Cam Mobile Viewer App is available through Google Play and the App Store from iTunes.
Mobile App device OS version requirements: Android 4.0 (Ice Cream Sandwich) or higher, iOS 7.0 or higher.
You may disable Cellular data (Data networks) for using apps in some of devices operating Lollipop.
For iOS devices, Wi-Fi settings can only be accessed using the smartphone or tablet settings.
Press Briey
Wi-Fi LED
21
Mobile Application
03
Connecting with WPS ( Only Android OS)
①
Download and install Thinkware Dash Cam Mobile Viewer application.
②
Press and hold Wi-Fi ( )
button for more than 5 seconds on the dash cam to enter WPS connection
mode.
③
Select "WPS" button on the Thinkware Dash Cam Mobile Viewer application to automatically connect to
the Thinkware dash cam using Wi-Fi. (takes approximately 20~30 seconds)
: Retry Wi-Fi search
.
Press and hold for 5 seconds
22
3-2-1. Live View
Live View : When using Live View, the continuous recording will be disabled.
Back
Switch to front/rear view
(appears only when
the rear view camera is
connected)
Live View
Current speed/voltage
Current date/time
GPS status
Audio recording
on/o
3-2. Thinkware Dash Cam Mobile Viewer Main Menu
Following section describing the Thinkware Dash Cam Mobile Viewer menu is based on Android devices.
Layouts and screen captures might be slightly dierent for iOS devices.
23
Mobile Application
03
3-2-2. Video List
Continuous Recording : Lists loop recording videos during continuous mode
(in 1 minute segments)
Incident in Continuous Mode : Lists incident recording videos during
continuous mode
Parking image : Lists motion detection recording videos during parking
surveillance mode
Incident in Parking Mode : Lists incident recording videos during parking
surveillance mode
Manual Recording : Lists manual recording videos initiated by selecting
manual recording button
Recording List Menu
Download : Copies selected video le to the device from the dash cam
MicroSD card (Wi-Fi must be connected)
Video Info : Displays date/time, le name, recording type, size, duration,
video quality for the selected video le
Delete : Removes the selected video le
24
Video download
Rear view videos
Front view videos
Cautions
For Android OS devices, it may take a while until downloaded videos are displayed in the list.
25
Mobile Application
03
3-2-3. Memory Settings
Memory Card Settings
Memory Partition Setting :
Sets how storage space on the memory card will be allotted for each
recording mode (Entire memory card will be formatted when the
memory partition setting is changed)
Memory card format :
Formats the MicroSD card. Formatting will completely erase all video
les stored in the memory card
※ It is recommended that you back up data before formatting the
memory card.Once you format the memory card, all data will be
deleted and cannot be restored.The method for formatting a
MicroSD card might vary depending on the computer operating
system.
Video Overwrite Setting :
Sets the overwriting option which will allow new video les to
overwrite oldestvideo in storage reserved for each mode
Dual Save Settings
Dual Save Video : Lists Dual Save videos
Copy to memory card : Copy all Dual Save videos saved on the inter-
nal memory to the MicroSD card
Delete Dual Save : Delete all Dual Save videos saved on the internal
memory
26
3-2-4. Settings > Dashcam Setting
Camera Settings
Brightness-F/R :
Sets the video recording brightness for front/rear camera
Wide Dynamic Range :
Sets the WDR mode to record clear video even in extreme contrast/
back-lit environment.
Record Settings
Cont. sensitivity :
Sets the impact sensitivity during continuous recording mode. It is
recommended that you set the sensitivity according to vehicle type.
High sensitivity setting is recommended for cars with softer ride such
as luxury sedans; while low sensitivity setting is recommendedfor cars
such as performance cars, trucks, or SUVs which tends to have stier
suspension settings.
Parking Mode :
Monitors vehicle ignition status to automatically convert to parking
mode when the vehicle engine is turned o. The dash cam must be
hardwired to the vehicle for the use of parking mode.
Parking sensitivity / Motion sensitivity :
Sets the motion detection sensitivity level during Parking mode.
Sets impact sensitivity when using Time Lapse function.
Super Night Vision :
Enhance video exposure for low-light conditions during Parking
Surveillance Mode.
Device auto-O Timer :
Sets the timer for the dash cam to automatically shut down in parking
mode to prevent From draining the vehicle battery
Device auto-O Voltage :
Sets the voltage level for the dash cam to automatically shut down if the dash cam detects voltage level
lower than congured value for more than 5 minutes in order to prevent fromdraining the vehicle battery
27
Mobile Application
03
Road Safety Warning System Settings
Safety Camera Alert :
Sets the audible notications for road safety warnings
Vehicle type :
Sets the vehicle type to be used to optimize Advanced Driver
Assistance System (ADAS) features such as Lane Departure Warning
System (LDWS) and Forward Collision Warning System (FCWS).
LDWS (Lane Departure Warning) :
Sets the LDWS driver assistance notication.
Left LDWS sensitivity / Right LDWS sensitivity :
Sets the lane departure detection L/R sensitivity. (It is recommended
that the sensitivity is set at high for wider vehicles)
LDWS speed :
Sets the speed at which the LDWS notication is enabled. LDWS
warning will only be notied to the driver when the vehicle veers
o the lane travelling at the congured speed.
Forward Collision Warning System (FCWS) :
Sets the FCWS driver assistance notication and Sets the forward
collision detection sensitivity .
System Settings
Language : Sets dash cam system language
Volume : Sets the volume level
Security LED : Sets the pattern for security LED
Time zone : Sets the time zone
Daylight saving : Sets the daylight saving time
Speed unit : Sets the unit for the vehicle speed
Speed Stamp : Sets vehicle speed information (tracked by GPS) to
be shown or hidden directly on video
