UBS-Axcera 500-Watt VHF Low-band Television Transmitter Appendix B Log Sheet

Appendix B Log Sheet

500-Watt VHF Low Band Transmitter Appendix B, Sample Log Report
Sheet
325A, Rev. 0 B-1
VHF Exciter
ALC (0 to 1 V) = ____________V % Aural Power (0 to 120) =
__________%
% Exciter (0 to 120) =
______________% Video (0 to 1 V) = ________________IRE
% Reflected (0 to 120) =
____________% Audio
(
0 to 100 kHz
)
= ____________kHz
% Visual Power
(
0 to 120
)
= _________%
VHF Amplifier Trays
(A6) (A7)
AGC Voltage (0 to 10 V) = ___________V AGC Voltage (0 to 10 V) = ___________V
% Reflected Power (0 to 120) =
_______% % Reflected Power (0 to 120) =
_______%
% Output Power (0 to 120) = ________% % Output Power (0 to 120) = ________%
Power Supply Voltage (0 to 100 V) = ___V Power Supply Voltage (0 to 100 V) = ___V
AGC Sample = ____________ V AGC Sample = ____________ V
Current I1 = ___________I Current I1 = ___________I
Current I2 = ___________I Current I2 = ___________I
Current I3 = ___________I Current I3 = ___________I
Current ID = ___________I Current ID = ___________I
500-Watt VHF Low Band Transmitter Appendix B, Sample Log Report
Sheet
325A, Rev. 0 B-2
Date __________________
Customer Name ______________________________ Call Letters
________________
Technician ___________________________________________
