500-Watt VHF Low Band Transmitter Chapter 3, Circuit Descriptions

325A, Rev. 0 3-1

Chapter 3

Circuit Descriptions

3.1 (A4) Low Band VHF Exciter

(1070820; Appendix C)

3.1.1 (A4) Aural IF Synthesizer

Board, 4.5 MHz (1265-1303;

Appendix D)

The aural IF synthesizer board amplifies

each of the three possible audio inputs

and the amplifier circuits that supply the

single audio output. The balanced audio

or the composite audio input is connected

to the board while the subcarrier audio

(SCA) input can be connected at the

same time as either of the other two

inputs. The board has the 4.5-MHz

voltage-controlled oscillator (VCO) and

the aural modulation circuitry that

produces the modulated 4.5-MHz output.

The board also contains a phase lock loop

(PLL) circuit that maintains the precise

4.5-MHz separation between the aural

(41.25 MHz) and the visual (45.75 MHz)

IF frequencies.

3.1.1.1 Balanced Audio Input

The first of the three possible baseband

inputs to the board is a 600Ω-balanced

audio input (+10 dBm) that enters

through jack J2, pins 1 (+), 2 (GND), and

3 (-), and is buffered by U1B and U1C.

Diodes CR1 to CR4 protect the input

stages of U1B and U1C if an excessive

signal level is present on the input leads

of jack J2. The outputs of U1B and U1C

are applied to differential amplifier U1A;

U1A eliminates the common mode

signals (hum) on its input leads. A

pre-emphasis of 75 ms is provided by

R11, C11, and R10 and can be eliminated

by removing jumper W5 on J5. The signal

is then applied to amplifier U1D whose

gain is controlled by jumper W3 on J11.

Jumper W3 on jack J11 is positioned

according to the input level of the audio

signal (0 or +10 dBm). If the input level

is approximately 0 dBm, the mini-jumper

should be in the high gain position

between pins 1 and 2 of jack J11. If the

input level is approximately +10 dBm,

the mini-jumper should be in low gain

position between pins 2 and 3 of jack

J11. The balanced audio is then

connected to buffer amplifier U2A whose

input level is determined by the setting of

balanced audio gain pot R13. The output

of the amplifier stage is wired to the

summing point at U2D, pin 13.

3.1.1.2 Composite Audio Input

The second possible audio input to the

board is the composite audio (stereo)

input at BNC jacks J3 and J13. The two

jacks are loop-through connected; as a

result, the audio can be used in another

application by connecting the unused

jack and removing W4 from J12. Jumper

W4 on jack J12 provides a 75Ω-input

impedance when the jumper is between

pins 1 and 2 of jack J12 and a high

impedance when it is between pins 2 and

3. Diodes CR9 to CR12 protect the input

stages of U6A and U6B if an excessive

signal level is applied to the board. The

outputs of U6A and U6B are applied to

differential amplifier U2C, which

eliminates common mode signals (hum)

on its input leads. The composite input

signal is then applied to amplifier U2B;

the gain of this amplifier is controlled by

composite audio gain pot R17. The

composite audio signal is connected to

the summing point at U2D, pin 13.

3.1.1.3 Subcarrier Audio Input

The third possible input to the board is

the SCA input at BNC jack J4. The SCA

input has an input impedance of 75Ω that

can be eliminated by removing jumper

W2 from pins 1 and 2 of J14. The SCA

input is bandpass filtered by C66, C14,

R22, C15, C67, and R23 and is fed to

buffer amplifier U3A. The amplified signal

is then applied though SCA gain pot R24

to the summing point at pin 13 of U2D.

500-Watt VHF Low Band Transmitter Chapter 3, Circuit Descriptions

325A, Rev. 0 3-2

3.1.1.4 Audio Modulation of the VCO

The balanced audio, or the composite

audio and/or the SCA-buffered audio

signals, are fed to the common junction

of resistors R14, R20, and R27 that

connect to pin 13 of amplifier U2D. The

output audio signal at pin 14 of U2D is

typically .8 Vpk-pk at a ±25-kHz

deviation for balanced or .8 Vpk-pk at

±75-kHz deviation for composite as

measured at TP1. This signal is applied to

VCO U10. A sample of the deviation level

is amplified, detected by U7A and U7B,

and connected to J10 on the board. This

audio-deviation level is connected to the

front panel meter through the transmitter

control board.

The audio is connected to CR13 to CR16;

these are varactor diodes that frequency

modulate the audio signal onto the

generated 4.5-MHz signal in U10. U10 is

the 4.5-MHz VCO that generates the 4.5-

MHz continuous wave (CW) signal. The

output frequency of this signal is

maintained and controlled by the

correction voltage output of U5 PLL IC.

The audio-modulated, 4.5-MHz signal is

fed to amplifiers U11A and U11B. The

output of U11B is connected to the 4.5-

MHz output jacks at J7 and J8.

3.1.1.5 Phase Lock Loop (PLL) Circuit

A sample of the signal from the 4.5-MHz

aural VCO at the output of U11A is

applied to PLL IC U5 at the Fin

connection. In U5, the signal is divided

down to 50 kHz and is compared to a 50-

kHz reference signal. The reference

signal is a divided-down sample of the

visual IF, 45.75-MHz signal that is

applied to the oscillator-in connection on

the PLL chip through jack J6 on the

board. These two 50-kHz signals are

compared in the IC and the fV, and fR is

applied to the differential amplifier U3B.

The output of U3B is fed back through

CR17 to the 4.5-MHz VCO IC U10; this

sets up a PLL circuit. The 4.5-MHz VCO

will maintain the extremely accurate 4.5-

MHz separation between the visual and

aural IF signals; any change in frequency

will be corrected by the AFC error

voltage.

PLL chip U5 also contains an internal lock

detector that indicates the status of the

PLL circuit. When U5 is in a "locked"

state, pin 28 goes high and causes the

green LED DS1 to illuminate. If the 4.5-

MHz VCO and the 45.75-MHz oscillator

become "unlocked," out of the capture

range of the PLL circuit, pin 28 of U5 will

go to a logic low and cause the red LED

DS2 to light. A mute output signal from

Q3 (unlock mute) will be applied to jack

J9. This mute is connected to the

transmitter control board.

3.1.1.6 Voltage Requirements

The ±12 VDC needed for the operation of

the board enters through jack J1. The

+12 VDC is connected to J1-3 and

filtered by L2, C3, and C4 before it is

connected to the rest of the board. The

-12 VDC is connected to J1-5 and filtered

by L1, C1, and C2 before it is connected

to the rest of the board. +12 VDC is

connected to U8 and U9; these are 5-volt

regulator ICs that provide the voltage to

the U10 and U5 ICs.

3.1.2 (A5) Sync Tip Clamp/

Modulator Board (1265-1302;

Appendix D)

The sync tip clamp/modulator board can

be divided into five circuits: the main

video circuit, the sync tip clamp circuit,

the visual modulator circuit, the aural IF

mixer circuit, and the diplexer circuit.

The sync tip clamp/modulator board

takes the baseband video or 4.5-MHz

composite input that is connected to the

video input jack (either J1 or J2, which

are loop-through connected), and

produces a modulated visual IF + aural

IF output at output jack J20 on the

board. The clamp portion of the board

maintains a constant peak of sync level

over varying average picture levels

(APL). The modulator portion of the

500-Watt VHF Low Band Transmitter Chapter 3, Circuit Descriptions

325A, Rev. 0 3-3

board contains the circuitry that

generates an amplitude-modulated

vestigial sideband visual IF signal output

that is made up of the baseband video

input signal (1 Vpk-pk) modulated onto

an externally generated 45.75-MHz IF

carrier frequency. The visual IF signal

and the aural IF signal are then

combined in the diplexer circuit to

produce the visual IF + aural IF output

that is connected to J20, the IF output

jack of the board.

3.1.2.1 Main Video Signal Path (Part 1 of

The baseband video or the 4.5-MHz

composite input connects to the board at

J2. J2 is loop-through connected to J1

and terminated to 75 watts if jumper W4

is on jack J3. With jumper W4 removed,

the input can be connected to another

transmitter through J1; J1 is loop-

through connected to J2.

Test point TP1 is provided to monitor the

level of the input. The input is fed to the

non-inverting and inverting inputs of

U1A, a differential amplifier that

minimizes any common-mode hum that

may be present on the incoming signal.

Diodes CR1 to CR4 form a voltage-limiter

network in which, if the input voltages

exceed the supply voltages for U1A, the

diodes conduct, preventing damage to

U1A. CR1 and CR3 conduct if the input

voltage exceeds the negative supply and

CR2 and CR4 conduct if the input voltage

exceeds the positive supply voltage.

The video output of U1A is connected to

J22 on the board. Normally, the video at

J22 is jumpered to J27 on the board. If

the 4.5-MHz composite input kit is

purchased, the 4.5-MHz composite signal

at J22 connects to the external composite

4.5-MHz filter board and the 4.5-MHz

bandpass filter board. These two boards

provide the video-only signal to J27 and

the 4.5-MHz intercarrier signal to J28

from the 4.5-MHz composite input. The

video through the video gain pot R12

(adjusted for 1 Vpk-pk at TP2) connects

to amplifier U1B.

The output of U1B, if the delay equalizer

board is present in the tray, connects the

video from J6, pin 2, to the external

delay equalizer board and back to the

sync tip clamp/modulator board at J6,

pin 4. If the delay equalizer is not

present, the video connects through

jumper W1 on J5, pins 1 and 2. The

delay equalizer board plugs directly to J6

on the sync tip clamp/modulator board.

The video from J6, pin 4, is then

connected through jumper W1 on J5,

pins 2 and 3, to the amplifier Q1. The

output of Q1 connects to Q2; the base

voltage of Q2 is set by the DC offset

voltage output of the sync tip clamp

circuit.

3.1.2.2 Sync Tip Clamp Circuit

The automatic sync tip clamp circuit is

made up of U4A, Q7, U3B, and

associated components. The circuit

begins with a sample of the clamped

video that is split off from the main video

path at the emitter of Q3. The video

sample is buffered by U3A and connected

to U4A. The level at which the tip of sync

is clamped, approximately -1.04 VDC as

measured at TP2, is set by the voltage-

divider network connected to U4A. If the

video level changes, the sample applied

to U4A changes. If jumper W7 on J4 is in

the Clamp-On position, the voltage from

the clamp circuit that is applied to the

summing circuit at the base of Q2 will

change; this will bring the sync tip level

back to approximately -1.04 VDC. Q7 will

be turned off and on according to the

peak of sync voltage level that is applied

to U4A. The capacitors C14, C51, C77,

and C41 will charge or discharge to the

new voltage level, which biases U3B

more or less, through jumper W7 on J4

in the Auto Clamp-On position. U3 will

increase or decrease its output, as

needed, to bring the peak of sync back to

the correct level as set by R152 and R12.

This voltage level is applied through U3B

to Q2. In the Manual position, jumper W7

500-Watt VHF Low Band Transmitter Chapter 3, Circuit Descriptions

325A, Rev. 0 3-4

on J4 is in the Clamp-Off position,

between pins 1 and 2, and adjustable

resistor R41 provides the manual clamp

bias adjustment for the video that

connects to Q2.

Jumper W6 on jack J35 must be in the

Normal position, between pins 2 and 3,

for the clamp circuit to operate with a

normal non-scrambled signal. If a

scrambled signal is used, the tray is

operated with jumper W6 in the Encoded

position, connected between pins 1 and

2. The clamp circuit is set by adjusting

depth of modulation pot R152 for the

correct depth of modulation as measured

at TP2.

Depending on the input video level, the

waveform as measured at TP2 may not

be 1 Vpk-pk. If W7 on J4 is moved to the

Clamp-Off (Manual) position, between

pins 1 and 2, the clamp level is adjusted

by R41 and will not automatically be

clamped to the set level. The output of

buffer amplifier U3A drives the sync tip

clamp circuit consisting of differential

amplifier U4A, FET Q7, and buffer

amplifier U3B. U4A is biased by R124,

R125, R184, R152, and R126 so that the

clamped voltage level at peak of sync is

approximately -1.04 VDC as measured at

TP2.

3.1.2.3 Main Video Signal Path (Part 2 of

The clamped video from Q2 is connected

to white clipper circuit Q3. Q3 is adjusted

with R20 and set to prevent video

transients from overmodulating the video

carrier. The clamped video is connected

to sync clipper circuit Q4 (adjusted by

R24); Q4 limits the sync to -40 IRE units.

The corrected video connects to emitter

follower Q4 whose output is wired to

unity gain amplifier U2A and provides a

low-impedance, clamped video output at

pin 1.

3.1.2.4 Visual Modulator Circuit

The clamped video signal from U2A is

split. One part connects to a metering

circuit, consisting of U20 and associated

components, that produces a video

output sample at J8-6 and connects

through the transmitter control board to

the front panel meter for monitoring. The

other clamped video path from U2A is

through a sync-stretch circuit that

consists of Q5 and Q6. The sync-stretch

circuit contains R48; R48 adjusts the

sync stretch magnitude (amount) and

R45 adjusts the cut-in. This sync-stretch

adjustment should not be used to correct

for output sync problems, but it can be

used for video input sync problems. The

output of the sync-stretch circuit

connects to pin 5, the I input of mixer

Z1.

The video signal is heterodyned in mixer

Z1 with the visual IF CW signal (45.75

MHz). The visual IF CW signal enters the

board at jack J15 and is connected to U9,

where it is amplified and wired to pin 1,

the L input of mixer Z1. The adjustable

capacitor C78 and resistor R53 are set up

to add a small amount of incidental

carrier phase modulation (ICPM)

correction to the output of the mixer

stage to compensate for any non-

linearities generated by the mixer.

The modulated 45.75-MHz RF output of

mixer Z1 is amplified by U5 and is fed to

double-sideband visual IF output jack

J18. The level of this output jack is

adjusted by R70. J18 is the visual IF

loop-through output jack that is normally

jumpered to J19 on the board. If the

optional visual IF loop-through kit is

purchased, the visual is connected out of

the board to any external IF processor

trays.

After any external processing, the

modulated visual IF, double-sideband

signal re-enters the board through J19.

The visual IF from J19 is amplified by

U10 and U11 and routed through the

vestigial sideband filter network,

500-Watt VHF Low Band Transmitter Chapter 3, Circuit Descriptions

325A, Rev. 0 3-5

consisting of T1, FL1, and T2, and

produces a vestigial sideband visual IF

signal output. The filtered vestigial

sideband visual IF is amplified by U7 and

connected to a T-type attenuator. R62

can be adjusted to set the visual IF gain;

this is the amount of visual IF signal that

is coupled to amplifier IC U8. R63 and

C30 are adjusted for the best VSBF

frequency response. The amplified IF

signal is fed to the input of the diplexer

circuit that consists of R76, L13, and L12.

A detected voltage sample of the visual

IF is available at test point TP5.

3.1.2.5 41.25-MHz Aural IF Circuit

On this board, the 41.25-MHz aural IF is

created by mixing the modulated 4.5-

MHz aural intercarrier signal, produced

by the aural IF synthesizer board or from

the composite 4.5-MHz filter board, with

the 45.75-MHz CW signal produced by

the 45.75-MHz IF carrier oven oscillator

board. The modulated 4.5-MHz aural

intercarrier signal enters the board at J14

or J28 and is connected to IF relay K1.

Jumper W3 on J7 determines whether

the 4.5-MHz used by the board is

internally generated or from an external

source. With jumper W3 connected

between pins 2 and 3, the 4.5 MHz from

the aural IF synthesizer board or from

the 4.5-MHz composite input is

connected to mixer Z2. If an external

4.5-MHz signal is used, it enters the

board at J12 and is fed through gain pot

R88 to amplifier IC U13A. The amplified

4.5 MHz is then connected to J7 and, if

jumper W3 is between pins 1 and 2, the

4.5-MHz signal from the external source

is connected to the mixer. Mixer Z2

heterodynes the aural-modulated, 4.5-

MHz signal with the 45.75-MHz CW signal

to produce the modulated 41.25-MHz

aural IF signal.

The output of the mixer is fed to a

bandpass filter that is tuned to pass only

the modulated 41.25-MHz aural IF signal

that is fed to jack J16, the 41.25-MHz

loop-through out jack of the board.

For normal operation, the 41.25-MHz

signal is jumpered by a coaxial cable

from J16 to J17 on the board. If the

(optional) aural IF loop-through kit is

purchased, the 41.25-MHz signal is

connected to the rear of the tray, to

which any processing trays can be

connected, and then back to jack J17 on

the board. The modulated 41.25-MHz

aural IF signal from J17 is connected

through amplifier ICs U15 and U16. The

amplified output is connected to the

attenuator-matching circuit that is

adjusted by R85. R85 increases or

decreases the level of the 41.25 MHz that

sets the A/V ratio for the diplexer circuit.

The diplexer circuit takes the modulated

45.75-MHz visual IF and the modulated

aural IF and combines them to produce

the 45.75-MHz + 41.25-MHz IF output.

The combined 45.75-MHz + 41.25-MHz

IF signal is amplified by U12 and

connected to combined IF output jack

J20 on the board. A sample of the

combined IF output is provided at J21 on

the board. If a NICAM input is used, it

connects to J36 on the board. The level

of the NICAM signal is set by R109 before

it is fed to the diplexer circuit consisting

of L28, L29, and R115. This circuit

combines the NICAM signal with the

45.75-MHz visual IF + 41.25-MHz aural

IF signal.

3.1.2.6 Operational Voltages

The +12 VDC needed to operate the

transmitter control board enters the

board at J23, pin 3, and is filtered by

L26, L33, and C73 before it is fed to the

rest of the board.

The -12 VDC needed to operate the

board enters the board at J23, pin 5, and

is filtered by L27 and C74 before being

fed to the rest of the board.

3.1.3(Optional) (A6) Delay Equalizer

Board (1227-1204; Appendix D)

The (Optional) delay equalizer board

provides a delay to the video signal,

500-Watt VHF Low Band Transmitter Chapter 3, Circuit Descriptions

325A, Rev. 0 3-6

correction to the frequency response, and

amplification of the video signal.

The video signal enters the board at J1-2

and is connected to a pi-type, low-pass

filter consisting of C16, L7, and C17. This

filter eliminates any unwanted higher

frequencies from entering the board. The

output of the filter is connected to

amplifier stage U1; the gain is controlled

by R29. The video output of the amplifier

stage is wired to the first of four delay-

equalizing circuits that shape the video

signal to the FCC specification for delay

equalization or to the desired shape

needed for the system. The board has

been factory-adjusted to this FCC

specification and should not be

readjusted without the proper

equipment.

Resistors R7, R12, R17, and R22 adjust

the sharpness of the response curve

while inductors L1, L2, L3, and L4 adjust

the position of the curve. With a delay

equalizer test generator signal or a sine

x/x video test pattern input, the resistors

and inductors can be adjusted, while

monitoring a Tektronix VM700 test

measurement set, until the desired FCC

delay equalization curve or system curve

is attained. The delay-equalized video

signal is connected to J1-4, the video

output of the board. A sample of the

delayed video signal is connected to J2

on the board and can be used for testing

purposes.

The ±12 VDC needed to operate the

board enters the board at J1. The +12

VDC connects to J1-9, which is filtered by

L5 and C11 before it is directed to the

rest of the board. The -12 VDC connects

to J1-6, which is filtered by L6 and C12

before it is directed to the rest of the

board.

3.1.4 (A7) IF Carrier Oven Oscillator

Board (1191-1404; Appendix D)

The IF carrier oven oscillator board

generates the visual IF CW signal at

45.75 MHz for NTSC system "M" usage.

The +12 VDC is applied through jack J10

to crystal oven HR1, which is preset to

operate at 60° C. The oven encloses

crystal Y1 and stabilizes the crystal

temperature. The crystal is the principal

device that determines the operating

frequency and is the most sensitive in

terms of temperature stability.

Crystal Y1 operates in an oscillator circuit

consisting of transistor Q1 and its

associated components. Feedback is

provided through a capacitor-voltage

divider, consisting of C5 and C6, that

operates the crystal in a common-base

amplifier configuration using Q1. The

operating frequency of the oscillator can

be adjusted by variable capacitor C17.

The oscillator circuit around Q1 has a

separate regulated voltage, 6.8 VDC,

which is produced by a combination of

dropping resistor R4 and zener diode

VR1. The output of the oscillator at the

collector of Q1 is capacitively coupled

through C8 to the base of Q2. The small

value of C8, 10 pF, keeps the oscillator

from being loaded down by Q2.

Q2 is operated as a common-emitter

amplifier stage whose bias is provided

through R8 from the +12 VDC line. The

output of Q2, at its collector, is split

between two emitter-follower transistor

stages, Q3 and Q4. The output of Q3 is

taken from its emitter through R11 to

establish an approximate 50-ohm source

impedance through C11 to J3, the main

output jack. This 45.75-MHz signal is at

about the +5 dBm power level. In most

systems, this output is either directed to

a visual modulator board or to some

splitting and amplifying arrangement that

distributes the visual IF carrier for other

needs. The second output from the

collector of Q2 is fed to the base of Q4,

the emitter follower transistor.

Q4 drives two different output circuits.

One output is directed through voltage

dividers R14 and R15 to jack J2 and is

meant to be fed to a frequency counter.

While monitoring J2 the oscillator can be

set exactly on the operating frequency

500-Watt VHF Low Band Transmitter Chapter 3, Circuit Descriptions

325A, Rev. 0 3-7

(45.75 MHz) by adjusting C17. The

output at J2 is at a power level of

approximately -2 dBm, which is sufficient

to drive most frequency counters. The

other output of Q4 connects to prescaler

chip U1, which divides the signal by 15.

The output of U1 is applied to U2, a

programmable divider IC. U2 is

programmed through pins 11 to 20 to

divide by 61. This results in a 50-kHz

signal at pin 9 that is available as an

output at J1. The output of 50 kHz is

generally used in systems where the

visual IF carrier oven oscillator is used as

the reference for a PLL circuit; an

example of this is when the PLL circuit

uses the aural IF synthesizer board and

the aural VCO. The 50-kHz CMOS output

at jack J1 is not capable of achieving

enough drive level for a long coaxial

cable length. As a result, when a long

coaxial cable is needed, the output at

jack J5 is utilized. The push-pull

transistor stage Q5 and Q6, along with

emitter resistor R18, provide a large-load

output capability at J5.

The stages U1, U2, Q5, and Q6 are

by using the +12 VDC line voltage, and

voltage-dropping resistor R16 and zener

diode VR2.

The +12 VDC power is applied to the

board through jack J4, pin 3, and is

isolated from the RF signals which may

occur in the +12 VDC line through the

use of RF choke L2 and filter capacitor

C10.

3.1.5 (A8) ALC Board, NTSC (1265-

1305; Appendix D)

The automatic level control (ALC) board

provides the ALC and amplitude linearity

correction of the IF signal. The ALC

adjusts the level of the IF signal through

the board to control the output power of

the transmitter.

The visual + aural IF input (0 dBm)

signal from the modulator enters the

board at modulator IF input jack J32. If

the (optional) receiver tray is present,

the visual + aural IF input (0 dBm) from

the receiver tray connects to receiver IF

input jack J1. The modulator IF input

connects to relay K3 and the receiver IF

input connects to relay K4. The two

relays are controlled by the Modulator

Select command that is connected to J30

on the board. Modulator select

enable/disable jumper W11 on J29

controls whether the Modulator Select

command at J30 controls the operation of

the relays or not. With jumper W11 on

J29, pins 1 and 2, the Modulator Select

command at J30 controls the operation of

the relays; with jumper W11 on J29, pins

2 and 3, the modulator is selected all of

the time.

3.1.5.1 Modulator Selected

With the modulator selected, J11-10 and

J11-28 on the rear of the UHF exciter

tray are connected together; this makes

J30 low and causes relays K3 and K4 to

de-energize. When K4 is de-energized, it

connects the receiver IF input at J1, if

present, to 50 watts. When K3 is de-

energized, it connects the modulator IF

input at J32 to the rest of the board;

Modulator Enable LED DS5 will be

illuminated.

3.1.5.2 Receiver Selected

With the receiver selected, which is J11-

10 and J11-28 on the rear of the UHF

exciter tray (connected to J30 on the

board) not connected together, relays K3

and K4 are energized. When K4 is

energized, it connects the receiver IF

input at J1, if present, to the rest of the

board. When K3 is energized, it connects

to the modulator IF input at J32 to 50

watts; Modulator Enable LED DS5 will be

illuminated.

3.1.5.3 Main IF Signal Path (Part 1 of 3)

The selected visual + aural IF input (0

dBm) signal is split, with one half of the

signal entering a bandpass filter that

consists of L3, L4, C4, L5, and L6. This

500-Watt VHF Low Band Transmitter Chapter 3, Circuit Descriptions

325A, Rev. 0 3-8

bandpass filter can be tuned with C4 and

is substantially broader than the IF signal

bandwidth. It is used to slightly steer the

frequency response of the IF to make up

for any small discrepancies in the

frequency response in the stages that

precede this point. The filter also serves

the additional function of rejecting

unwanted frequencies that may occur if

the tray cover is off and the tray is in a

high RF environment (if this is the case,

the transmitter will have to be serviced

with the tray cover off in spite of the

presence of other RF signals). The

filtered IF signal is fed through a pi-type

matching pad consisting of R2, R3, and

R4 to the pin-diode attenuator circuit

consisting of CR1, CR2, and CR3.

3.1.5.4 Input Level Detector Circuit

The other part of the split IF input is

connected through L2 and C44 to U7; U7

is an IC amplifier that is the input to the

input level detector circuit. The amplified

IF is fed to T4; T4 is a step-up

transformer that feeds diode detector

CR14. The positive-going detected signal

is then low-pass filtered by C49, L18, and

C50. This allows only the video with

positive sync to be applied through

emitter follower Q1. The signal is then

connected to detector CR15 to produce a

peak-sync voltage that is applied to op-

amp U9A. There is a test point at TP3

that provides a voltage reference check

of the input level. The detector serves

the dual function of providing a reference

that determines the input IF signal level

to the board and also serves as an input

threshold detector.

The input threshold detector prevents the

automatic level control from reducing the

attenuation of the pin-diode attenuator to

minimum (the maximum signal) if the IF

input to the board is removed. The ALC,

video loss cutback, and the threshold

detector circuits will only operate when

jumper W3 on jack J6 is in the Auto

position, between pins 1 and 2. Without

the threshold detector, and with the pin-

diode attenuator at minimum, when the

signal is restored it will overdrive the

stages following this board.

As part of the threshold detector

operation, the minimum IF input level at

TP3 is fed through detector CR15 to op-

amp IC U9A, pin 2. The reference voltage

for the op-amp is determined by the

voltage divider that consists of R50 and

R51 (off the +12 VDC line). When the

detected-input signal level at U9A, pin 2,

falls below this reference threshold

(approximately 10 dB below the normal

input level), the output of U9A at pin 1

goes to the +12 VDC rail. This high is

connected to the base of Q2. At this

point, Q2 is forward biased and creates a

current path from the -12 VDC line and

through red LED DS1, the input level

fault indicator, which becomes lit, resistor

R54, and transistor Q2 to +12 VDC. The

high from U9A also connects through

diode CR16 to U9B, pin 5, whose output

at pin 7 goes high. The high connects

through range adjust pot R74 to J20,

which connects to the front panel-

mounted power adjust pot. This high

connects to U10A, pin 2, and causes it to

go low at output U10A, pin 1. The low is

applied through jumper W3 on J6 to the

pin-diode attenuator circuit that cuts

back the IF level and, therefore, the

output power level, to 0. When the input

signal level increases above the threshold

level, the output power will raise, as the

input level increases, until normal output

power is reached.

The video input level at TP3 is also fed to

a sync-separator circuit, consisting of IC

U8, CR17, Q3, and associated

components, and then to a comparator

circuit made up of U9C and U9D. The

reference voltage for the comparators is

determined by a voltage divider

consisting of R129, R64, R65, R66, and

R130 (off the -12 VDC line). When the

input signal level to the detector at TP3

falls below this reference threshold,

which acts as a loss of sync detector

circuit, the output of U9C and U9D goes

towards the -12 VDC rail and is split, with

one part biasing on transistor Q5. A

500-Watt VHF Low Band Transmitter Chapter 3, Circuit Descriptions

325A, Rev. 0 3-9

current path is then established from the

+12 VDC line through Q5, the resistors

R69, R137, and the red LED DS3 (video

loss indicator), which becomes lit. When

Q5 is on, it applies a high to the gates of

Q6 and Q7. This causes them to conduct

and apply video loss fault pull-down

outputs to J18, pins 5 and 2.

The other low output of U9C and U9D is

connected through CR20 to jack J5.

Jumper W2 on J5, in the Cutback Enable

position (between pins 2 and 3),

connects the low to the base of the

forward-biased Q4. If jumper W2 is in

the Disable position, between pins 1 and

2, the auto cutback will not operate. With

Q4 biased on, a level determined by the

setting of cutback level pot R71, which is

set at the factory to cut back the output

to approximately 25%, is applied to U9B,

pin 5. The output of U9B at pin 7 goes

low and is applied through the power

adjust pot to U10A, pin 2, whose output

goes low. This low is applied to the pin-

diode attenuator to cut back the level of

the output to approximately 25%.

3.1.5.5 Pin-Diode Attenuator Circuit

The input IF signal is fed to a pin-diode

attenuator circuit that consists of CR1 to

CR3. Each of the pin diodes contain a

wide intrinsic region; this makes the

diodes function as voltage-variable

resistors at this intermediate frequency.

The value of the resistance is controlled

by the DC bias supplied to the diode. The

pin diodes are configured in a pi-type

attenuator configuration where CR1 is

the first shunt element, CR3 is the series

element, and CR2 is the second shunt

element. The control voltage, which can

be measured at TP1, originates either

from the ALC circuit when jumper W3 on

J6 is in the ALC Auto position, between

pins 1 and 2, or from pot R87 when the

jumper is in the Manual Gain position.

On the pin-diode attenuator circuit, a

current path exists from J6 through R6

and then through the diodes of the pin

attenuator. Changing the amount of

current through the diodes by forward

biasing them changes the IF output level

of the board. There are two extremes of

attenuation ranges for the pin-diode

attenuators. In the minimum attenuation

case, the voltage, measured at TP1,

approaches the +12 VDC line. There is a

current path created through R6, through

series diode CR3, and finally through R9

to ground. This path forward biases CR3

and causes it to act as a relatively low-

value resistor. In addition, the larger

current flow increases the voltage drop

across R9 that tends to turn off diodes

CR1 and CR2 and causes them to act as

high-value resistors. In this case, the

shunt elements act as a high resistance

and the series element acts as a low

resistance to represent the minimum loss

condition of the attenuator (maximum

signal output). The other extreme case

occurs as the voltage at TP1 is reduced

and goes towards ground or even slightly

negative. This tends to turn off (reverse

bias) diode CR3, the series element,

causing it to act as a high-value resistor.

An existing fixed current path from the

+12 VDC line, and through R5, CR1,

CR2, and R9, biases series element CR3

off and shunt elements, diodes CR1 and

CR2 on, causing them to act as relatively

low-value resistors. This represents the

maximum attenuation case of the pin

attenuator (minimum signal output). By

controlling the value of the voltage

applied to the pin diodes, the IF signal

level is maintained at the set level.

3.1.5.6 Main IF Signal Path (Part 2 of 3)

When the IF signal passes out of the pin-

diode attenuator through C11, it is

applied to modular amplifier U1. This

device includes within it the biasing and

impedance matching circuits that makes

it operate as a wide-band IF amplifier.

The output of U1 is available, as a

sample of the pre-correction IF for

troubleshooting purposes and system

setup, at jack J2. The IF signal is then

connected to the linearity corrector

portion of the board.

500-Watt VHF Low Band Transmitter Chapter 3, Circuit Descriptions

325A, Rev. 0 3-10

3.1.5.7 Linearity Corrector Circuits

The linearity corrector circuits use three

stages of correction to correct for any

amplitude non-linearities of the IF signal.

Each stage has a variable threshold

control adjustment, R34, R37, or R40,

and a variable magnitude control

adjustment, R13, R18, or R23. The

threshold control determines the point at

which the gain is changed and the

magnitude control determines the

amount of gain change that occurs once

the breakpoint is reached. Two reference

voltages are needed for the operation of

the corrector circuits. Zener diode VR1,

with R33 and R135, provides a +6.8 VDC

reference and the diodes CR11 and CR12

provide a .9 VDC reference that

temperature compensates for the two

diodes in each corrector stage.

For the linearity correctors to operate, an

IF signal is applied to transformer T1,

which doubles the voltage swing by

means of a 1:4 impedance

transformation. Resistors R14, R15, and

R16 form an L-pad that lowers the level

of the signal. The amount that the level

is lowered is adjusted by adding more or

less resistance, using R13, in parallel

with the L-pad resistors. R13 is only in

parallel when the signal reaches a level

large enough to turn on the diodes CR4

and CR5. When the diodes turn on,

current flows through R13, putting it in

parallel with the L-pad.

When R13 is put in parallel with the

resistors, the attenuation through the

L-pad is lowered, causing signal stretch

(the amount determined by the

adjustment of R13). The signal is next

applied to amplifier U2 to compensate for

the loss through the L-pad. The

breakpoint, or cut-in point, for the first

corrector is set by controlling where CR4

and CR5 turn on. This is accomplished by

adjusting cut-in resistor R34; R34 forms

a voltage-divider network from +6.8 VDC

to ground. The voltage at the wiper arm

of R34 is buffered by unity-gain amplifier

U5D. This reference voltage is then

applied to R35, R36, and C39 through

L12 to the CR4 diode. C39 keeps the

reference from sagging during the

vertical interval. The .9 VDC reference

created by CR11 and CR12 is applied to

unity-gain amplifier U5B. The reference

voltage is then connected to diode CR5

through choke L11. The two chokes L11

and L12 form a high impedance for RF

that serves to isolate the op-amp ICs

from the IF.

After the signal is amplified by U2, it is

applied to the second corrector stage

through T2. This corrector and the third

corrector operate in the same fashion as

the first. All three corrector stages are

independent and do not interact with

each other.

The correctors can be disabled by moving

jumper W1 on J4 to the Disable position,

between pins 2 and 3; this moves all of

the breakpoints past the tip of sync so

that they will have no affect. The IF

signal exits the board at IF output jack J3

after passing through the three corrector

stages and is normally connected to an

external IF phase corrector board.

3.1.5.8 Main IF Signal Path (Part 3 of 3)

After the IF signal passes through the

external IF phase corrector board, it

returns to the ALC board at IF input jack

J7. The IF then passes through a

bandpass filter consisting of L20, C97,

C62, L21, C63, L22, L23, C64, and C99.

This bandpass filter is identical in both

form and function to the one described in

Section 3.3 of this chapter. In this case,

the filter is intended to make up for small

errors in frequency response that are

incurred by the signal while being

processed through the linearity and

incidental phase correction circuits.

Following the bandpass filter, the signal

is split using L24, L25, and R89. The

signal passing through L24 is the main IF

path through the board. A sample of the

corrected IF signal is split off and

connected to J10, the IF sample jack.

500-Watt VHF Low Band Transmitter Chapter 3, Circuit Descriptions

325A, Rev. 0 3-11

The IF connects to jacks J27 and J28.

These jacks control whether a 6-dB pad

is included in the circuit by the

positioning of jumpers W9 and W10. The

6-dB pad-in is when jumpers W9 and

W10 are connected between pins 2 and 3

on J27 and J28. The 6-dB pad-out is

when jumpers W9 and W10 are

connected between pins 1 and 2 on J27

and J28. Normally, the pad is out. The IF

signal is then applied to a two-stage,

frequency-response corrector circuit that

is adjusted as needed.

Variable resistors R103 and R106 adjust

the depth and gain of the notches and

variable caps C71 and C72 adjust the

frequency position of the notches. The IF

signal is amplified by U13 and U14 before

it is connected to J12, the IF output jack

of the board. R99 is an output level

adjustment that is set to provide

approximately 0 dBm of IF output at J12.

A sample of the IF is fed to J11 to

provide an IF sample point that can be

monitored without breaking the signal

path and gives an indication of the IF

signal after the linearity and the

frequency-response correction takes

place.

3.1.5.9 ALC Circuit

The other path of the corrected IF signal

is used in the ALC circuit. The IF is wired

out of the splitter through L25 and

connects to op-amp U12. The output of

U12 is wired to jacks J8 and J9 on which

jumpers W4 and W8 control the normal

or encoded operation of the ALC circuitry.

For normal operation, jumper W4 on J8 is

between pins 1 and 2 and jumper W8 on

J9 is between pins 1 and 2. The IF signal

is applied to transformer T5; T5 doubles

the voltage swing by means of a 1:4

impedance transformation before it is

connected to the ALC detector circuit on

the board and amplified by U10B.

For normal operation, jumper W7 on J26

is between pins 1 and 2 and jumper W5

on J21 is between pins 1 and 2. The

detected ALC voltage is wired to U10A,

pin 2, where it is summed with the front

panel power control setting. The output

power adjustment for the transmitter is

achieved, if the (optional) remote power

raise/lower kit (1227-1039) is purchased,

by R75, a motor-driven pot controlled by

switch S1 on the board, or screwdriver

adjust pot R1 on the front panel of the

UHF exciter tray. An external power

raise/lower switch can be used by

connecting it to jack J10, at J10-11

power raise, J10-13 power raise/lower

return, and J10-12 power lower, on the

rear of the UHF exciter tray. S1, or the

remote switch, controls relays K1 and K2,

which control motor M1 that moves

variable resistor R75. If the (optional)

remote power raise/lower kit is not

purchased, the ALC voltage is controlled

only by screwdriver adjust pot R1 on the

front panel of the UHF exciter tray. The

ALC voltage is set for .8 VDC at TP4 with

a 0 dBm output at J12 of the board. A

sample of the ALC at J19, pin 2, is wired

to the transmitter control board where it

is used on the front panel meter and in

the AGC circuits.

This ALC voltage, and the DC level

corresponding to the IF level after signal

correction, are fed to U10A, pin 2, whose

output at pin 1 connects to the ALC pin-

diode attenuator circuit. If there is a loss

of gain somewhere in an IF circuit, the

output power of the transmitter will drop.

The ALC circuit senses this drop at U10A

and automatically lowers the loss of the

pin-diode attenuator circuit to

compensate by increasing the gain.

The ALC action starts with the ALC

detector level that is monitored at TP4.

The detector output at TP4 is nominally

+.8 VDC and is applied through resistor

R77 to a summing point at op-amp

U10A, pin 2. The current available from

the ALC detector is offset, or

complemented, by current taken away

from the summing junction. In normal

operation, U10A, pin 2, is at 0 VDC when

the loop is satisfied. If the recovered or

peak-detected IF signal at IF input jack

J7 of this board should drop in level,

500-Watt VHF Low Band Transmitter Chapter 3, Circuit Descriptions

325A, Rev. 0 3-12

which normally means that the output

power is decreasing, the null condition

would no longer occur at U10A, pin 2.

When the level drops, the output of

U10A, pin 1, will go more positive. If

jumper W3 on J6 is in the Automatic

position, it will cause the ALC pin-diode

attenuators CR1, CR2, and CR3 to have

less attenuation and increase the IF

level; this will act to compensate for the

decrease in level. If the ALC cannot

increase the input level enough to satisfy

the ALC loop, due to there not being

enough range, an ALC fault will occur.

The fault is generated because U10D, pin

12, increases above the trip point set by

R84 and R83 until it conducts. This

makes U10D, pin 14, high and causes the

red ALC Fault LED DS2 to light.

3.1.5.10 Scrambled Operation with

Encoding

For encoded, scrambled operation,

jumper W4 on J8 must be connected

between pins 2 and 3, jumper W8 on J9

must be between pins 3 and 2, jumper

W7 on J26 must be between pins 2 and

3, and jumper W5 on J21 must be

between pins 2 and 3. The IF is

connected through W4 on J8 to the sync

regeneration circuits.

If this board is operated with scrambling,

using suppressed sync, the ALC circuit

operates differently than described above

because there is no peak of sync present

on the IF input. A timing pulse from the

scrambling encoder connects to the

board at J24. This timing pulse is

converted to sync pulses by U17A and

U17B, which control the operation of Q8.

The sync amplitude is controlled by R149

and is then applied to U15A, where it is

added to the detected IF signal to

produce a peak of sync level. The output

of U15A is peak detected by CR26 and

fed to U15B. If necessary, intercarrier

notch L39 can be placed in the circuit by

placing W6 on J22. The intercarrier notch

is adjusted to filter any aural and 4.5-

MHz intercarrier frequencies. The peak of

sync signal is fed through R162, the ALC

calibration control, to amplifier U15C. The

amplified peak of sync output is

connected through J21, pins 2 and 3, to

U10A, where it is used as the reference

for the ALC circuit and the AGC reference

to the transmitter control board. Voltage

TP4 should be the same in either the

normal or the encoded video mode.

Monitor J9, pins 3 and 4, with a spectrum

analyzer, check that the board is in the

AGC mode, and tune C103 to notch-out

the aural IF carrier.

3.1.5.11 Fault Command

The ALC board also has circuitry for an

external mute fault input at J19, pin 6.

This is a Mute command and, in most

systems, it is involved in the protection

of the circuits of high-gain output

amplifier devices. The Mute command is

intended to protect the amplifier devices

against VSWR faults. In this case, the

action should occur faster than just

pulling the ALC reference down. Two

different mechanisms are employed: one

is a very fast-acting circuit to increase

the attenuation of the pin-diode

attenuator, CR3, CR1, and CR2, and the

second is the reference voltage being

pulled away from the ALC amplifier

device. An external Mute is a pull-down

applied to J19, pin 6, to provide a current

path from the +12 VDC line through R78

and R139, the LED DS4 (Mute indicator),

and the LED section of opto-isolator U11.

These actions turn on the transistor

section of U11 that applies -12 VDC

through CR21 to U10A, pin 3, and pulls

down the reference voltage. This is a

fairly slow action that is kept at this pace

by the low-pass filter function of R81 and

C61. When the transistor section of U11

is on, -12 VDC is also connected through

CR22 to the pin-diode attenuator circuit.

This establishes a very fast muting

action, by reverse biasing CR3, in the

event of an external VSWR fault.

500-Watt VHF Low Band Transmitter Chapter 3, Circuit Descriptions

325A, Rev. 0 3-13

3.1.5.12 ±12 VDC Needed to Operate the

Board

The ±12 VDC connects to the board at

J14. The +12 VDC connects to J14-3 and

is filtered by L30, L41, and C80 before it

is applied to the rest of the board. The

-12 VDC connects to J14-5 and is filtered

by L31 and C81 before it is applied to the

rest of the board.

The +12 VDC also connects to U16, a 5-

VDC regulator IC, that produces the +5

VDC needed to operate timing IC U17.

3.1.6 (A9) IF Phase Corrector Board

(1227-1250; Appendix D)

The IF phase corrector board has

adjustments that pre-correct for any IF

phase modulation distortion that may

occur in output amplifier devices such as

Klystron power tubes and solid-state

amplifiers. Two separate, adjustable IF

paths are on the board: a quadrature IF

path and an in-phase IF path. The

quadrature IF is 90° out of phase and

much larger in amplitude than the in-

phase IF. When they are combined in Z1,

it provides the required adjustable phase

correction to the IF signal.

The IF input signal enters at J1 and is AC

coupled to U1. U1 amplifies the IF before

it is connected to Z1, a splitter that

creates two equal IF outputs: IF output 1

is connected to J2 and IF output 2 is

connected to J3. The IF output 1 at J2 is

jumpered through coaxial cable W4 to

jack J6, the quadrature input, on the

board. The IF output 2 at J3 is jumpered

through coaxial cable W5 to jack J7, the

in-phase input, on the board.

3.1.6.1 Phase Corrector Circuit

The phase corrector circuit corrects for

any amplitude nonlinearities of the IF

signal. It is designed to work at IF and

has three stages of correction. Each

stage has a variable threshold and

magnitude control. The threshold control

determines the point at which the gain is

changed and the magnitude control

determines the gain change once the

breakpoint is reached. The second stage

has a jumper that determines the

direction of correction, so that the gain

can increased either above or below the

threshold, and either black or white

stretch can be achieved.

In the phase corrector circuit, the IF

signal from J6 is applied to transformer

T1; T1 doubles the voltage swing using a

1:4 impedance transformation. Resistors

R8, R61, R9, and R48 form an L-pad that

attenuates the signal. This attenuation is

adjusted by adding R7, a variable

resistor, in parallel with the L-pad. R7 is

only in parallel when the signal reaches a

level large enough to bias on CR1 and

CR2 and allow current to flow through

R7. When R7 is put in parallel with the L-

pad, the attenuation through the L-pad is

lowered, causing black stretch.

Two reference voltages are utilized in the

corrector stages and both are derived

from the +12 VDC line. Zener diode VR1,

with R46 as a dropping resistor, provides

+6.8 VDC from the +12 VDC line. Diodes

CR11 and CR12 provide a .9 VDC

reference to temperature compensate

the corrector circuits from the effects of

the two diodes in each corrector stage.

The threshold for the first corrector stage

is set by controlling where CR1 and CR2

turn on. This is accomplished by

adjusting R3 to form a voltage divider

from +6.8 VDC to ground. The voltage at

the wiper of R3 is buffered by U9C, a

unity-gain amplifier, and applied to CR1.

The .9 VDC reference is connected to

U9D, a unity-gain amplifier, whose

output is wired to CR2. These two

references are connected to diodes CR1

and CR2 through chokes L2 and L3. The

two chokes form a high impedance for RF

to isolate the op-amps from the RF. The

adjusted signal is next applied to

amplifier U2 to compensate for the loss

through the L-pad. U2 is powered

through L4 and R10 from the +12 VDC

line. After the signal is amplified by U2, it

500-Watt VHF Low Band Transmitter Chapter 3, Circuit Descriptions

325A, Rev. 0 3-14

is applied to the second corrector stage

through T2 and then to a third corrector

stage through T3. The other two

corrector stages operate in the same

manner as the first; they are

independent and do not interact with

each other.

When jumper W1 on J8 is connected

from center to ground, R15 is put in

series with ground. In this configuration,

black stretch (white compression) is

applied to the IF signal by controlling the

attenuation through the path. When W1

is connected from the center pin to the

end that connects to T2, R15 is put in

parallel with the L-pad. In this

configuration, black compression (white

stretch) is applied to the IF signal by

controlling the attenuation through the

path.

The phase correctors can be bypassed by

moving jumper W2 on J9 to the Disable

position. This action will move all of the

threshold points past sync tip so that

they will have no effect. R68 can be

adjusted and set for the correction range

that is needed. TP2 is a test point that

gives the operator a place to measure

the level of the quadrature IF signal that

is connected to pin 6 on combiner Z2.

3.1.6.2 Amplitude Corrector Circuit

The amplitude corrector circuit uses one

stage of correction to correct for any

amplitude nonlinearities of the IF signal.

The stage has a variable threshold

control, R31, and a variable magnitude

control, R35. The threshold control

determines the point at which the gain is

changed and the magnitude control

determines the amount of gain change

once the breakpoint is reached.

Two reference voltages are needed for

the operation of the corrector circuit.

Zener diode VR1 with R46 provides +6.8

VDC and the diodes CR11 and CR12

provide a .9 VDC reference voltage to

temperature compensate for the two

diodes in the corrector stage. In the

amplitude corrector circuit, the IF signal

from J7 is applied to transformer T4 to

double the voltage swing by means of a

1:4 impedance transformation. Resistors

R36, R55, R56, and R37 form an L-pad

that lowers the level of the signal. The

amount that the level is lowered is

adjusted by adding more, or less,

resistance, using R35 in parallel with the

L-pad resistors. R35 is only in parallel

when the signal reaches a level large

enough to turn on diodes CR8 and CR9.

When the diodes turn on, current flows

through R35 and puts it in parallel with

the L-pad. When R35 is in parallel with

the resistors, the attenuation through the

L-pad is lowered, causing signal stretch

(the amount of stretch determined by the

adjustment of R35).

The signal is next applied to amplifier U5

to compensate for the loss in level

through the L-pad. The breakpoint, or

cut-in point, for the corrector stage is set

by controlling where CR8 and CR9 turn

on. This is achieved by adjusting cut-in

resistor R31 to form a voltage divider

from +6.8 VDC to ground. The voltage at

the wiper arm of R31 is buffered by

unity-gain amplifier U8B. This voltage is

then applied to R34 through L11 to the

CR9 diode. The .9 VDC reference created

by CR11 and CR12 is applied to unity-

gain amplifier U8A. C36 keeps the

reference from sagging during the

vertical interval. The reference voltage is

then connected to diode CR8 through

choke L12. The two chokes L11 and L12

form a high impedance for RF to isolate

the op-amp ICs from the IF.

After the signal is amplified by U5, it is

applied to a second stage through T5.

The transformer doubles the voltage

swing by means of a 1:4 impedance

transformation. Resistors R39, R57, R58,

and R40 form an L-pad that lowers the

level of the signal. The signal is applied

to amplifier U6 to compensate for the

loss in level through the L-pad. After the

signal is amplified by U6, it is applied to a

third stage through T6. The transformer

doubles the voltage swing by means of a

500-Watt VHF Low Band Transmitter Chapter 3, Circuit Descriptions

325A, Rev. 0 3-15

1:4 impedance transformation. Resistors

R42, R59, R60, and R43 form an L-pad to

lower the level of the signal. The signal is

applied to amplifier U7 to compensate for

the loss in level through the L-pad. TP1 is

a test point that gives the operator a

place to measure the level of the in-

phase IF signal that is connected to

mixer stage Z2. The amplitude corrector

can be disabled by moving jumper W3 on

J10 to the Disable position; this will move

the breakpoint past sync tip and will have

no effect on the signal.

3.1.6.3 Output Circuit

The phase-corrected signal from pin 1 on

combiner Z2 exits the board at IF output

jack J4 after passing through a matching

network consisting of six resistors.

3.1.7 (A11) VHF Mixer/Amplifier

Enclosure Assembly (1070902;

Appendix C)

The VHF mixer/amplifier enclosure

assembly is made up of the x2 multiplier

board, the VHF filter/mixer board, and

the low-band VHF filter/amplifier board.

3.1.7.1 (A1) x2 Multiplier Board (1172-

1111; Appendix D)

The x2 multiplier board multiplies the

frequency of an RF input signal by a

factor of two. The board is made up of a

x2 broadband frequency doubler.

The input signal (+5 dBm) at the

fundamental frequency enters through

SMA jack J1 and is fed through a 3-dB

matching pad, consisting of R1, R2, and

R3, to amplifier IC U1. The output of the

amplifier stage is directed through a

bandpass filter, consisting of L1 and C4,

that is tuned to the fundamental

frequency. The voltage measured at TP1

is typically +0.6 VDC. The doubler stage

consists of Z1 with bandpass filter L2 and

C6 tuned to the second harmonic. The

harmonic is amplified by U2 and fed to

the SMA output jack of the board at J2.

The typical LO signal output level is a

nominal +15 dBm.

The +12 VDC for the board enters

through jack J3-3 and is filtered by L3

and C7 before being distributed to the

circuits on the board.

3.1.7.2 (A2) VHF Filter/Mixer Board

(1153-1101; Appendix D)

The VHF filter/mixer board is made up of

three separate circuits: a filter and

amplifier circuit for the LO input, a mixer

stage, and a filter and amplifier for the

RF output of the mixer. The board is

mounted inside of (A11) the VHF

mixer/amplifier enclosure assembly an

aluminum enclosure that provides RFI

protection. The filter/amplifier board

(1064251) is also mounted inside the

enclosure.

The LO input (+5 dBm) connects to the

board at J3 and is fed to a filter circuit.

The input to the filter consists of C11,

C12, and L5, with C12 adjusted for the

best input loading. C13 and C17 are

adjusted for the best frequency response

and C18 is adjusted for the best output

loading of the LO signal. The filtered LO

is amplified by U2 and connected to LO

output jack J4. Typically, the output at

jack J4 is jumpered by a coaxial jumper

to jack J5 on the board. The LO at J5

connects to mixer Z1 at pin 1 (+14

dBm).

The IF input connects to the board at J7

and is fed to mixer Z1 at pin 3 (-3 dBm).

Mixer Z1 takes the LO input at pin 1 and

the IF input at pin 3 to produce an RF

output at pin 8. The RF output at pin 8

connects through a pi-type attenuator,

made up of R3, R4, and R5, before it is

connected to RF output jack J6 (-14

dBm). Normally, jack J6 is connected by

a coaxial jumper to J1 on the board. J1

connects to the input of a filter circuit,

consisting of C25, C1, C23, C2, and L1,

with C2 adjusted for the best input

500-Watt VHF Low Band Transmitter Chapter 3, Circuit Descriptions

325A, Rev. 0 3-16

C3 and C6 are adjusted for the best

center frequency, C4 is adjusted for the

best coupling, and C7 is adjusted for the

best output loading of the RF signal. The

filtered RF is amplified by U1 and

connected to the RF output jack for the

board at J2 (-2 dBm).

The +12 VDC needed for the operation of

the board is supplied by an external

power supply in the tray. The +12 VDC

enters the board at J8, pin 3, and is

filtered and isolated from the rest of the

tray by L7 and C22 before being applied

to the board.

3.1.7.3 (A3) Low Band VHF Filter/

Amplifier Board (1064251; Appendix D)

The VHF low band filter/amplifier board is

made up of two separate circuits: a filter

circuit and an amplifier with a gain

control circuit.

The RF input connects to the board at J7

and is fed through a channel filter circuit.

The input to the filter consists of C27,

C28, and C29, with C29 adjusted for the

best input loading. C23 and C26 are

adjusted for center frequency, with C24

adjusted for the best coupling, and C20 is

adjusted for the best output loading of

the RF signal. The filtered RF is

connected to RF output jack J6; J6 is

usually jumpered to jack J1 on the board.

The filtered RF at J1 connects through a

7-dB pi-type attenuator, consisting of R1,

R2, and R3, before it is wired to a pin-

diode attenuator circuit. The pin-diode

attenuator circuit is made up of CR1,

CR2, and CR3 and is controlled by the

bias current applied through R5. The

diodes CR1, CR2, and CR3 are pin-type

diodes with a broad intrinsic region

sandwiched inside the diode. This broad

intrinsic region causes the pin diodes to

act as variable resistors instead of as

detecting devices at the RF frequencies.

The resistance values of the pin diodes

are determined by the relative amount of

forward bias that is applied to the diodes.

Jumper W1 on J5 is set for manual gain

or auto gain by its position on the jack.

Between 1 and 2 is manual gain, which

uses pot R9 to set the output level;

between 2 and 3 is auto gain, which uses

the external control voltage input to jack

J4 as the level control (this arrangement

is not used in this configuration).

The level-controlled RF is pre-amplified

by U1 and connected to Q1, the output

amplifier for the board. C17 is used to

maximize the RF signal. The RF output is

amplified by Q1 and fed through direction

coupler Z1 before exiting the board at J2,

the RF output. Z1 provides a RF sample

that has two functions. The first function

is to provide an RF sample at J8 through

a voltage divider consisting of R19 and

R18 that is fed to the front panel of the

exciter tray. The second function is to

provide a peak-detected voltage that is

used by the exciter tray for metering

purposes. The sample provided by Z1,

pin 3, is first fed through a dB pad

consisting of R20, R21, and R22. The

voltage is stepped up by a 1 to 4

transformer T1. The signal is then peak

detected by C32 and CR4 before being

buffered and amplified by U2A. The level

of the peak-detected voltage at J9-1 and

J9-2, which is used for metering

purposes, is controlled by the pot R29 on

the board.

The +12 VDC needed for the operation of

the board is supplied by an external

power supply in the tray. The +12 VDC

enters the board at J3 pin 3, and is

filtered and isolated from the rest of the

tray by L5 and C19 before being applied

to the entire board. The –12 VDC enters

the board at J3 pin 5, and is filtered and

isolated from the rest of the tray by L6

and C35 before being applied to the

entire board.

3.1.8 (A17) Transmitter Control

Board (1265-1311; Appendix D)

The transmitter control board provides

information on system control functions

and the operational LED indications, that

can be viewed on the front panel of the

500-Watt VHF Low Band Transmitter Chapter 3, Circuit Descriptions

325A, Rev. 0 3-17

transmitter. The main control functions

are for the Operate/Standby and

Auto/Manual selections. When the

transmitter is switched to Operate, the

board supplies the enables to the

external amplifier trays. The board also

performs the automatic switching of the

transmitter to Standby upon the loss of

the video input when the transmitter is in

Auto.

The transmitter control board contains a

VSWR cutback circuit. If the VSWR of the

transmitter increases above 20%, the

VSWR cutback circuit will become active

and cut back the output level of the

transmitter, as needed, to maintain a

maximum of 20% VSWR.

An interlock (low) must be present at J8-

24 for the transmitter to be switched to

Operate and, when the interlock is

present, the green Interlock LED DS5 will

be lit.

3.1.8.1 Operate/Standby Switch S1

K1 is a magnetic latching relay that

controls the switching of the transmitter

from Operate and Standby. When the

Operate/Standby switch S1, on the front

panel of the tray, is moved to Operate,

one coil of relay K1 energizes and causes

the contacts to close and apply a low to

U4B-9. If the transmitter interlock is

present, and there is no overtemperature

fault, lows will also be applied to U4B-10,

U4B-11, and U4B-12.

With all the low inputs to U4B, the output

at U4B-13 will be low. The low biases off

Q1 and this turns off the amber Standby

LED DS1 on the front panel. In addition,

this action applies a high to Q2 and turns

on and lights the green Operate LED DS2

(also on the front panel). When Q2 is

biased on, it connects a low to Q12 and

biases it off; this allows the ALC to be

applied to J1 and connect to any external

amplifier trays. The low from U4B-13 is

also applied to Q4 and Q24, which are

biased off, and removes the disables

from J1-4 and J18-1. The low from U4B-

13 also connects to Q10, which is biased

on, and connects a high to Q6, Q7, Q8,

and Q9; these are biased on and apply

-12 VDC enables to J8-2, J8-3, J8-4, and

J8-5, which connect to any external

amplifier trays. The high applied to Q2 is

also connected to Q5 and Q26, which are

biased on, and apply a low enable to J1-

3, which connects to a remote operate

indicator. The transmitter is now in the

Operate mode.

When the Operate/Standby switch S1 is

moved to Standby, the other coil of relay

K1 energizes, causing the contacts to

open and a high (+12 VDC) to be applied

to U4B-9. The high at the input causes

the output at U4B-13 to go high. The

high biases on Q1 and applies a low to

the amber Standby LED DS1, on the

front panel, and turns on and applies a

low to Q2. This causes Q2 to turn off and

extinguishes the green Operate LED DS2.

When Q12 is biased on, the output from

U2C goes low and pulls the ALC voltages

at J1 low; this lowers the gain of the

external amplifier trays. The high from

U4B-13 is applied to Q4 and Q24, which

are biased on, and applies disables at J1-

4 and J18-1. The high from U4B-13

connects to Q10, which is biased off. The

Q10 bias off removes the high from Q6,

Q7, Q8, and Q9, which are biased off,

and removes the -12 VDC enables at J8-

2, J8-3, J8-4, and J8-5, which connect to

the external amplifier trays. The low

applied to Q2 is also connected to Q5 and

Q26, which are biased off, and removes

the remote enable at J1-3. The

transmitter is now in the Standby mode.

3.1.8.2 Automatic/Manual Switch S2

K2 is a magnetic latching relay that

switches the operation of the transmitter

to Automatic or Manual using Auto/

Manual switch S2 on the front panel of

the tray.

When S2 is set to the Auto position, the

operation of the transmitter is controlled

by the fault circuits and will stay in

Operate even if Operate/Standby switch

500-Watt VHF Low Band Transmitter Chapter 3, Circuit Descriptions

325A, Rev. 0 3-18

S1 is moved to Standby. With S2 in Auto,

a low is applied to one coil in the relay

and this energizes and closes the

contacts. The closed contacts apply a low

to the green Automatic LED DS3; as a

result, DS3 is illuminated. The low from

the relay connects to U5A, pin 2; U5D,

pin 13; Q21; and Q23. When Q21 and

Q23 are biased off, this causes their

outputs to go high. The high from Q21

connects to the amber Manual LED DS4,

on the front panel, biasing it off, and to

Q22, biasing it on. The drain of Q22 goes

low and is applied to J8-7; this enables

any remote auto indicator connected to

J8-7. The low to Q23 biases it off and

removes the enable to any remote

manual indicator connected to J8-6.

When S2 is set to the Manual position,

the operation of the transmitter is no

longer controlled by the fault circuits; it is

controlled by Operate/Standby switch S1.

With S2 in Manual, a low is applied to the

other coil in the relay and this energizes

and opens the contacts. The open

contacts remove the low from the green

Automatic LED DS3 on the front panel

and causes it to not light. The high

connects to U5A, pin 2; U5D, pin 13;

Q21; and Q23. Q21 and Q23 are biased

on; this causes their outputs to go low.

The low from Q21 connects to the amber

Manual LED DS4 on the front panel,

biasing it on, and to Q22, biasing it off.

The drain of Q22 goes high and is applied

to J8-7; this will disable any remote auto

indicators connected to it J8-7. Q23 is

biased on and applies a low enable to any

remote manual indicator connected to J8-

3.1.8.3 Automatic Turning On and Off of

the Transmitter Using the Presence of

Video

The transmitter control board also allows

the transmitter to be turned on and off

by the presence of video at the

transmitter when the transmitter is in

Auto. When a video fault occurs due to

the loss of video, J7-5 goes low. The low

is applied through W1, on J10, to Q16,

which is biased off, and to the red Video

Loss Fault LED DS9, on the front panel,

which will light. The drain of Q16 goes

high and connects to U5B, pin 5, causing

the output at pin 4 to go low. The low

connects to Q18, which is biased off, and

causes the drain of Q18 to go high. The

high connects to U3D, pin 12, whose

output at pin 14 goes high. The high

connects to U5C, pins 8 and 9, causing

its output at pin 10 to go low, and to

U5A, pin 1, causing its output at pin 3 to

go low.

With S2 set to Automatic, a low is applied

to U5A, pin 2, and to U5D, pin 13. When

U5A, pin 1, is high and U5A, pin 2, is low,

it causes the output at pin 3 to go low.

When U5D, pin 12, is low and U5D, pin

13, is low, it causes its output to go high.

When U5A, pin 3, is low, it biases off Q20

and removes any pull down to the

Operate switch. A high at U5D, pin 11,

biases on Q19 and applies a low enable

to the Standby switch that places the

transmitter in the Standby mode.

When the video signal is returned, J7-5

goes high. The high is applied to Q16,

which is biased on, and to the red Video

Fault LED DS9, which is extinguished.

The output of Q16 goes low and connects

to U5B, pin 5. If there is no receiver ALC

fault, U5B, pin 6, is also low; this causes

the output at pin 4 to go high. The high

connects to Q18, which is biased on, and

causes the drain of Q18 to go low. The

low connects to U3D, pin 12, whose

output at pin 14 goes low. The low

connects to U5C, pins 8 and 9, which

causes its output at pin 10 to go high,

and to U5A, pin 1. With Auto/Manual

switch S2 in Auto, a low is applied to

U5A, pin 2, and to U5D, pin 13. When

U5A, pins 1 and 2, is low, its output at

pin 3 goes high. When pin 12 of U5D is

high, the output of U5D at pin 11 goes

low. When U5A, pin 3, is high, it biases

on Q20 and applies a pull-down enable to

the Operate switch. A low at U5D, pin 11,

biases off Q19 and removes any pull

down to the Standby switch. As a result

of these actions, the transmitter is

switched to Operate.

500-Watt VHF Low Band Transmitter Chapter 3, Circuit Descriptions

325A, Rev. 0 3-19

3.1.8.4 Faults

There are four possible faults, video loss

fault, VSWR cutback fault,

overtemperature fault, and ALC fault,

which may occur in the transmitter and

are applied to the transmitter control

board. During normal operation, no faults

are sent to the board. The receiver ALC

fault circuit will only function if a receiver

tray is part of the system. The

overtemperature fault is only used with

2-kW transmitters and is controlled by

the temperature of the reject load.

3.1.8.5 Video Loss Fault

If a video loss occurs while the

transmitter is in Auto, the system will

change to the Standby mode until the

video is returned; at that point, it will

immediately revert to Operate. A video

loss fault applies a low from the ALC

board to the video fault input at

J7-5 on the board.

With jumper W1 in place on J10, the

video fault is connected to LED DS9 and

to Q16. The red Video Loss Fault LED

DS9 on the front panel will light. Q16 is

biased off and causes its drain to go high.

The high is wired to U5B, pin 5, whose

output at U5B, pin 4, goes low. The low

is wired to Q18, which is biased off, and

causes the drain to go high. The high is

connected to U3D, pin 12, which causes

its output at U3D, pin 14, to go high. The

high connects to U5A, pin 1, and, if the

transmitter is in Auto, pin 2 of U5A is

low. When pin 1 is high and pin 2 is low,

the output of U5A goes low and reverse

biases Q20, shutting it off. The high at

U5C, pins 8 and 9, causes its output at

pin 10 to go low. This low is connected to

U5D, pin 12, and, if the transmitter is in

Auto, pin 13 of U5D is also low. The lows

on pins 12 and 13 cause the output to go

high and forward bias Q19. The drain of

Q19 goes low and connects the coil in

relay K1, causing it to switch to Standby.

When the video returns, the video loss

fault is removed from the video fault

input at J7-5. With jumper W1 in place

on J10, the base of Q16 goes high. The

red Video Loss Fault LED DS9 on the

front panel will be extinguished. Q16 is

biased on, which causes its drain to go

low. The low is wired to U5B, pin 5; U5B,

pin 6, will be low if no ALC fault occurs.

The two lows at the inputs make the

output at U5B, pin 4, go high. The high is

wired to Q18, which is biased on, causing

the drain to go low. The low is connected

to U3D, pin 12, which causes its output

at U3D, pin 14, to go low. The low

connects to U5A, pin 1, and, if the

transmitter is in Auto, pin 2 of U5A is

also low. With both inputs low, the

output of U5A at pin 3 goes high. The

high forward biases Q20 and causes its

drain to go low. The low connects to the

operate coil on relay K1 that switches the

transmitter to Operate. The low at U5C,

pins 8 and 9, causes its output at pin 10

to go high. This high is connected to

U5D, pin 12, and, if the transmitter is in

Auto, pin 13 of U5D is low. The high on

pin 12 causes the output of U5D to go

low and reverse bias Q19. The drain of

Q19 goes high and this removes the low

from the standby coil in relay K1.

3.1.8.6 Overtemperature Fault

In the 500 Watt transmitter, there is no

connection to the overtemperature circuit

on the transmitter control board. In the

2-kW transmitter, the thermal switch on

the output dummy load connects to J8-1

on the board. In the 100-watt

transmitter, the (A6) thermal switch on

(A23) the 100-watt amplifier heatsink

assembly connects to J12 on the board.

If the temperature of the thermal switch

raises above 170° F, it closes and applies

a low to J8-1 or to J12. The low connects

to Q3, which is biased off, and to the red

Overtemperature LED DS6, which is

biased on. The drain of Q3 goes high and

connects to pins 11 and 12 of U4B. The

high at the input to U4B causes it to go

high and switches the system to

Standby; this removes the Operate

Enable commands to any external

amplifier trays.

500-Watt VHF Low Band Transmitter Chapter 3, Circuit Descriptions

325A, Rev. 0 3-20

3.1.8.7 VSWR Cutback Fault

The reflected power sample of the RF

output of the transmitter is connected to

J2, pin 9, of the transmitter control

board. The sample connects to op-amp

U1B, pin 5, which buffers the signal

before it is split. One of the split-reflected

samples connects to J1-5 on the board;

J1-5 is wired to J10-5 on the rear of the

tray for remote monitoring. Another split-

reflected sample connects to position 3

on the front panel meter for the tray. The

final split remote-reflected sample

connects to U2B, pin 5.

If the reflected sample level increases

above the level set by R22, the VSWR

cutback pot, the output of U2B at pin 7,

goes high. The high is connected to Q11

through CR11, which is biased on,

making U2C, pin 10, low and causing

U2C, pin 8, to go low. This low is split

and fed out of the tray at J1-6, J1-7, J1-

8, and J1-9. These are ALC outputs to

the amplifier trays that cut back the

output power of the amplifier trays. The

low from U2C, pin 8, is also fed through

coaxial jumper W2 on J13 and J14 to

R73. R73 is a bias-adjust pot that sets

the level of the pin attenuator bias

available as an output at J16. The high at

U2B, pin 7, is also fed to the base of Q14

and Q13, which are forward biased. This

produces a low at the drains that connect

to the front panel amber VSWR Cutback

LED DS7, causing it to light and indicate

that the tray is in cutback, and to output

jack J8-37 for the connection to a remote

VSWR cutback indicator.

3.1.8.8 Receiver ALC Fault

If a receiver tray is part of the system, a

sample of the ALC voltage from this tray

is connected to J8-11 on the transmitter

control board. If the receiver is operating

normally, the ALC level that is applied to

U3C, pin 9, remains below the trip level

set by R35; as a result, the output at pin

13 stays high. The high is applied to the

red ALC Fault LED DS8, which is off. The

high also connects to U3A, pin 2, and to

Q15. Q15 is biased on and the drain

goes low. The low connects to U5B, pin

6. In addition, U5B normally has a low

that is connected to U5B, pin 5, and

produces a high at output pin 4. The high

is wired to Q18, which is biased on, and

makes its drain low. The low connects to

U3D, pin 12, which, because the level is

below the preset, the output at U3D, pin

14, goes low. A low at this point indicates

a no-fault condition. The high that is

connected to U3A, pin 2, causes its

output to go low. The low is connected to

Q25, which is biased off. The low is

removed from J8-12, which will not light

any remote receiver fault indicator that is

connected to it.

If the receiver malfunctions, the ALC

level applied to U3C, pin 9, goes high.

This is above the level set by R35 and

causes the output at pin 13 to go low.

The low is applied to the red ALC Fault

LED DS8, which lights. The low also

connects to U3A, pin 2, and to Q15. Q15

is biased off and the drain goes high. The

high connects to U5B, pin 6, and

produces a low at output pin 4. The low

is wired to Q18, which is biased off, and

this makes its drain go high. The high

connects to U3D, pin 12 and, because

the level is above the preset, the output

at U3D, pin 14, goes high. A high at this

point indicates a fault condition that

switches the transmitter to Standby. The

low connected to U3A, pin 2, causes its

output to go high. The high is connected

to Q25, which is biased on, and causes

the drain to go low. The low is connected

to J8-12, which can light any remote

receiver fault indicator that is connected

to it.

3.1.8.9 Metering

The front panel meter connects to J3-1

(-) and J3-2 (+), the output of switch S3,

on the transmitter control board. The

front panel meter has seven metering

positions which are controlled by S3:

Audio, Video, % Aural Power, % Visual

Power, % Reflected Power,

500-Watt VHF Low Band Transmitter Chapter 3, Circuit Descriptions

325A, Rev. 0 3-21

% Exciter, and ALC. The video sample

connects to the board at J5-4 and is

connected through video calibration pot

R20 to position 6 on front panel meter

switch S3. The audio sample enters the

board at J5-6 and is connected through

audio calibration pot R19 to position 7 on

front panel meter switch S3.

The reflected sample connects to the

board at J2-9 and is connected through

buffer amplifier U1B and 100Ω resistor

R84 to position 3 on front panel meter

switch S3. The visual sample connects to

the board at J2-5 and is connected

through buffer amplifier U1D and 100Ω

resistor R86 to position 4 on front panel

meter switch S3. The aural sample

connects to the board at J2-7 and is

connected through buffer amplifier U1C

and 100-watt resistor R85 to position 5

on front panel meter switch S3. The

exciter sample connects to the board at

J2-3 and is connected through buffer

amplifier U1A and 100Ω resistor R87 to

position 2 on front panel meter switch

S3. The ALC sample connects to the

board at J6-1 and is connected through

buffer amplifier U2C and ALC calibration

pot R15 (which adjusts the output of

U2A, pin 1) and through 100Ω resistor

R18 to position 1 on front panel meter

switch S3. Typical readings on the meter

are:

• Video = 1 Vpk-pk at white

• % Reflected = < 5%

• % Visual power = 100%

• % Aural power = 100%

• % Exciter = The level on the meter

needed to attain 100% output power

from the transmitter

Refer to the test specifications sheet for

the transmitter for the actual reading:

• ALC = .8 VDC

• Audio = ±25 kHz with a balanced

audio input or ±75 kHz with a

composite audio input

Samples are provided for the remote

metering of the exciter at J1-10, the

visual at J8-26, the aural at J8-27, and

the reflected at J1-5.

U6 is a temperature-sensor IC that gives

the operator the ability to measure the

temperature inside the tray by measuring

the voltage at TP1. The sensor is set up

for +10 mV equals 1° F (for example,

750 mV equals 75° F).

3.1.8.10 Operational Voltages

The +12 VDC needed for the operation of

the transmitter control board enters the

board at jack J4, pin 3. C28, L1, and L3

are for the filtering and isolation of the

+12 VDC before it is split and applied to

the rest of the board. The -12 VDC

needed for the operation of the board

enters the board at jack J4, pin 5. C29

and L2 are for the filtering and isolation

of the -12 VDC before it is split and

applied to the rest of the board.

The +12 VDC is split when it is connected

to the board. Four of the +12 VDC

outputs are fed out of the board at J8-16,

J8-17, J8-18, and J8-19 through diodes

CR7, CR8, CR9, or CR10 and resistors

R50, R51, R52, or R53 are fed to any

external amplifier trays for use in their

logic circuits. The resistors are for current

limiting and the diodes are to prevent

voltage feedback from the external

amplifier trays.

3.1.9 (A19) Visual/Aural Metering

Board (1265-1309; Appendix D)

The visual/aural metering board provides

detected outputs of the visual, aural, and

reflected output samples that are used

for monitoring on the front panel meter.

The board also provides adjustments for

the calibration of the readings on the

meter. These readings are attained from

samples of the forward power and

reflected power outputs of the tray.

A forward power sample, visual + aural,

is applied to SMA jack J1 on the board.

The input signal is split, with one path

connected to forward power sample SMA

500-Watt VHF Low Band Transmitter Chapter 3, Circuit Descriptions

325A, Rev. 0 3-22

jack J2 for monitoring purposes. The

other path is connected through C1 to

CR2, R4, R5, R6, C4, and CR1, which

make up a detector circuit. The detected

visual + aural signal is amplified by U6B

and its output is split. One amplified

output of U6B connects to the aural level

circuit and the other output connects to

the visual level circuit.

3.1.9.1 Aural Level Circuit

One of the detected visual + aural level

outputs of U6B connects through C6 to

the intercarrier filter circuit that consists

of R13, R14, L1, C7, and C8; C8 and L1,

the intercarrier filter, can be adjusted for

a maximum aural reading. The filter

notches out the video + aural and only

leaves the 4.5-MHz difference frequency

between the visual and aural, which is a

good representation of the aural level.

The 4.5-MHz signal is fed to buffer

amplifier U6A. The output of U6A is

detected by diode detector CR3 and U1A

and then fed through aural calibration

control R20 to amplifier U2D. The

amplified output of U2D is split, with the

main output connected through R21 to

J6, pin 1, which supplies the aural level

output to the front panel meter for

monitoring. The other output of U2D is

connected to aural null adjust R51 and

offset null adjust R48, which are adjusted

to set up the visual power calibration.

3.1.9.2 Visual Level Circuit

The other detected visual + aural level

output from U6B is connected to U1C

and, if there is no scrambling, connects

directly to intercarrier notch L3, which is

adjusted to filter out the aural and the

4.5-MHz intercarrier frequencies, leaving

only a visual-with-sync output. The

visual-with-sync output is fed to a peak-

detector circuit consisting of CR5 and

U2A. The signal is then fed through visual

calibration control R28, which is adjusted

for a 100% visual reading with no aural,

to amplifier U2B. The amplified visual

peak of sync output is connected to

comparator U2C. The other input to U2C

is the level set by aural null adjust R51,

which is adjusted for 100% visual power

after the aural is added and the peak

power is adjusted back to the reference

level. Inputs to U2C also come from

offset null adjust R48, which is adjusted

for 0% visual power with the transmitter

in Standby. The adjusted output is

amplified by U3D and connected to the

other input of U2C. The output of U2C

connects to J6, pins 2 and 3, which

supply the peak of sync visual level

output to the front panel meter for

monitoring.

If this board is operated with scrambling,

using suppressed sync, the visual level

circuit operates differently than described

above because there is no peak of sync

present on the forward sample input. For

the board to operate properly, a timing

pulse from the scrambling encoder must

connect to the board at J4. This timing

pulse is converted to sync pulses by U4A

and U4B, which control the operation of

Q2. Intercarrier notch L2 is tuned to

remove any visual + aural signal that

may remain.

The sync amplitude is controlled by gate

amplitude adjust R25 and then applied to

the minus input of U1C. At this point, it is

inserted into the visual + aural signal

that is connected to the plus input of

U1C, producing a peak of sync in the

signal. The output of U1C is connected to

intercarrier notch L3, which is adjusted to

filter out the aural and the 4.5-MHz

intercarrier frequencies. The visual-with-

sync output is fed to a peak-detector

circuit, consisting of CR5 and U2A, and

then fed through visual calibration control

R28 to amplifier U2B. The amplified

visual peak of sync output is connected

to J6, pins 2 and 3, that supply the peak

of sync visual level output to the front

panel meter for monitoring. R32 moves

the pulse to where the sync should be

and R25 sets the visual metering

calibration with no sync present.

500-Watt VHF Low Band Transmitter Chapter 3, Circuit Descriptions

325A, Rev. 0 3-23

3.1.9.3 Reflected Level Circuit

A reflected-power sample is applied to J3

of the visual/aural metering board and is

detected by diode detector CR7 and U3B.

The detected output is fed through

reflected calibration pot R39, which can

be adjusted to control the gain of U3C.

The output of U3C connects to J6, pin 7,

which supplies a reflected-power level

output to the front panel meter.

3.1.9.4 Voltages for Circuit Operation

The ±12 VDC is applied to the board at

J5. The +12 VDC is connected to J5, pin

3, and is isolated and filtered by L4 and

C34 before it is connected to the rest of

the board. The +12 VDC also connects to

U5, a 5-VDC regulator that provides the

voltage needed to operate U4. The -12

VDC is applied to J5, pin 1, and is

isolated and filtered by L5 and C35

before it is connected to the rest of the

board.

3.1.10 (A14) Channel Oscillator

Assembly, Dual Oven (1145-1202;

Appendix D)

The channel oscillator assembly contains

(A14-A1) the channel oscillator board

(1145-1201) that generates a stable

frequency-reference signal of

approximately 100 MHz. The channel

oscillator assembly is an enclosure that

provides temperature stability for the

crystal oscillator. An SMA output at jack

J1 and an RF sample at BNC connector

jack J2 are also part of the assembly.

Adjustments can be made through access

holes in the top cover of the assembly.

These adjustments are set at the factory

and should not be tampered with unless

it is absolutely necessary and the proper,

calibrated equipment is available. R1 is

the temperature adjustment; C11 is the

course-frequency adjustment; C9 is the

fine-frequency adjustment; and C6, C18,

L2, and L4 are adjusted for the maximum

output of the frequency as measured at

jack J1.

The +12 VDC for the assembly enters

through FL1 and the circuit-ground

connection is made at E1.

3.1.11 (A4-A13) EEPROM FSK

Identifier Board (1265-1308;

Appendix D)

The FSK identifier board, with EEPROM,

generates a morse code identification call

sign by frequency-shift keying the VCXO

oscillator in the upconverter or by

sending a bias voltage to the IF

attenuator board to amplitude modulate

the aural carrier. This gives the station a

means of automatically repeating its

identification call sign, at a given time

interval, to meet FCC requirements.

The starting circuit is made up of U1B

and U1D, which are connected as a

flip-flop, with gate U1A used as the set

flip-flop. U1A automatically starts the

flip-flop each time U3 completes its

timing cycle. At the start of a cycle, U1B

enables clock U2. U2 applies the clock

pulses that set the speed, which is

adjusted by R2, for when the

identification code is sent to 12-bit binary

counter U4. R2, fully clockwise (CW), is

the fastest pulse train and R2, fully

counter-clockwise (CCW), is the slowest

pulse train. U4 provides binary outputs

that address EEPROM U5.

The scans in U4 will continue until field

effect transistor (FET) Q1 is gated on.

The gate of Q1 is connected to pin 13 on

U4, which is the maximum count used in

the EEPROM, and will provide a reset

pulse each time the binary counter goes

high on pin 13. The reset pulse, when the

drain of Q1 goes low, is applied to the

flip-flop and the timer U3, which

determines the length of time between

the sending of the identification code.

R14 is adjusted to set this time interval.

R14, fully CW, is the longest interval

between identification calls,

approximately eight minutes. R14, fully

CCW, is the shortest interval between the

500-Watt VHF Low Band Transmitter Chapter 3, Circuit Descriptions

325A, Rev. 0 3-24

sending of the code (approximately 10

seconds).

U6B is an amplifier connected to the

output of U5, which turns the LED DS1

on and off at the rate set by R2. This

gives the operator a visual indication that

the FSK identifier board is operating and

at the rate at which it is operating.

The data output of U5, which is serial, is

connected to U6A, whose output shifts

low and high, and is applied to the VCXO

board, which shifts the frequency

according to the programming of U5. The

deviation of the shift is adjusted by R4

and is typically set at 1 kHz. Once R4 is

set, R9 is re-adjusted to -1.5 VDC at J3-

The +12 VDC from an external power

supply enters the board at J1, pin 3. The

voltage is fed through RF choke L1 and is

filtered by C1 before being applied to the

rest of the tray. The +12 VDC is also

applied to U7, which is a voltage

regulator that regulates its output at +5

VDC. The +5 VDC is fed to the ICs on the

board. The -12 VDC from an external

power supply enters the board at J1, pin

5. The voltage is fed through RF choke L2

and filtered by C2 before being applied to

the rest of the tray.

3.1.12 (Optional) (A12) IF

Attenuator Board (1150-1201;

Appendix D)

The IF attenuator board is operated with

the FSK identifier board to produce an

amplitude-modulated aural IF signal for

broadcasting the required FCC station

identification call sign at the proper time

intervals.

The board contains a pin-diode

attenuation circuit that consists of CR1

and the two resistors R2 and R3. The

bias output of the FSK identifier board is

applied to J3 of the IF attenuator board.

As the bias applied to J3 increases and

decreases, the amplitude of the aural IF

signal, which enters the board at J1 and

exits the board at J2, will increase and

decrease. This produces an amplitude-

modulated IF signal at J2, the aural IF

output jack of the board.

3.2 (A6 and A7) Low Band VHF

Amplifier Trays (1198-1600;

Appendix C)

The low band VHF amplifier tray (1198-

1600) is adjusted at the factory for use

as a visual + aural RF amplifier tray. The

tray has approximately 55 dB of gain at

the frequency of the VHF low band

channel and will take the typical +3 dBm

input and amplify it to an output level of

approximately +57 dBm. As a visual +

aural amplifier, the tray is calibrated for

500 watts peak of sync visual plus –10

dB aural power (50 watts) is equal to a

100% reading.

The tray is made up of the boards and

assemblies listed in Table 3-1.

500-Watt VHF Low Band Transmitter Chapter 3, Circuit Descriptions

325A, Rev. 0 3-25

Table 3-1. VHF Amplifier Tray Boards and Assemblies

MAJOR ASSEMBLY

DESIGNATOR BOARD/ASSEMBLY NAME DRAWING NUMBER

A1-A1 Phase shifter board

(mounted in [A1] an RF

enclosure assembly) 1198-1602

A1-A2 Filter/amplifier board

(mounted in [A1] an RF

enclosure assembly) 1198-1606

A2-A1 Low band VHF amplifier

board (mounted in [A2] an

RF enclosure assembly) 1198-1605

A2-A2 Overdrive protection board

(mounted in [A2] an RF

enclosure assembly) 1198-1601

A2-A3 3-way splitter board

(mounted in [A2] an RF

enclosure assembly)

1198-1607 (CH. 2-4) or

1198-1608 (CH. 5-6)

A3-A1, A3-A2 and A3-A3

Three low band VHF

amplifier boards (mounted

in [A3] an RF enclosure

assembly)

1198-1624 (CH. 2-4) or

1198-1631 (CH. 5-6)

A4-A1 3-way combiner

board(mounted in [A4] an

RF enclosure assembly)

1198-1625 (CH. 2-4) or

1198-1626 (CH. 5-6)

A4-A2 and A4-A3 Two low pass filter boards

(mounted in [A4] an RF

enclosure assembly) 1198-1628

A5 AGC control board 1142-1601

A8 Current metering board 1198-1609

A10 +48 VDC switching power

supply assembly VS3-L9-B9-21-CE

The on-channel visual RF or aural RF

input signal (+6 dBm) enters the rear of

the tray at BNC jack J1 and is fed

through J1 of the (A1) enclosure

assembly to J1 of (A1-A1) the phase

shifter board (1198-1602). The board

provides a phase shifter adjustment of

the RF signal that is needed to provide

maximum output during the combining of

multiple VHF amplifier trays in an

amplifier array. Front panel-mounted

phase shift potentiometer R2 connects to

J3 on the board and controls the phase of

the RF signal.

If the input signal level to the phase

shifter board falls below a preset level, a

high, which is an input fault, connects

from J5 of the board to J14 on the AGC

control board. When an input fault

occurs, the AGC control board generates

a fault output at J1, which is connected

to J4 on the filter/amplifier board. The

fault cuts back the RF signal level using

the pin-diode attenuator circuit on the

filter/amplifier board.

The phase-controlled output at J2 of the

phase shifter board (+4 dBm) is directed

to J7, the input jack of (A1—A2) the filter

amplifier board (1198-1606) that is made

up of two circuits. The first circuit is a

channel filter that is adjusted for the

desired channel frequency and

bandwidth. The filtered output (+2 dBm)

is connected to the second circuit; this

500-Watt VHF Low Band Transmitter Chapter 3, Circuit Descriptions

325A, Rev. 0 3-26

circuit contains two amplifiers. The RF

connects through a pin-diode circuit to

amplifier IC U1. The amplitude of the RF

signal through the pin-diode attenuator

circuit is controlled by the voltage applied

to J4, the external control jack of the

board. Jumper W1 on J5 should be

between pins 2 and 3; these pins provide

external control, through J4, of the gain

of the board as well as the output level of

the tray. R9 is the manual gain pot that

is in the circuit when the jumper W1 is

between pins 1 & 2.

The front panel-mounted gain pot R3

connects to the AGC control board and is

used to adjust the AGC pin-attenuator

bias voltage that connects to J4 on the

filter/amplifier board. The RF signal, after

the pin-attenuator circuit, is amplified by

the second amplifier stage Q1 to about

+16 dBm; this signal is connected to the

output of the board at J2.

The RF output of the filter/amplifier

board connects to J2 of (A2) a RF

enclosure that contains the low band VHF

amplifier board, the overdrive protection

board and the 3-way splitter board. The

RF from J2 on the enclosure connects to

J1 on the low band VHF amplifier board

(1198-1601) that amplifies the signal 20

dB.

The RF output of the low band VHF

amplifier board at J2 (+34 dBm)

connects to J4 of (A2-A2) the overdrive

protection board (1198-1601). The RF

signal is through-connected directly to

J5, the RF output jack of the board. A

sample of the RF on the board is applied

to a diode-detector circuit that consists of

CR1 and U1A. The gain of amplifier U1D

is controlled by detector gain pot R11,

which is set to +.4 VDC as measured at

TP1. The set output of U1D is connected

to comparator IC U1B. The trip point for

the comparator is adjusted by R12,

typically to 110% output power, sync

only. When the signal reaches that level,

the overdrive protection board will cut

back the output power of the tray and

the red Overdrive LED DS1 on the board

and the red Overdrive LED DS1 mounted

on the front panel will be illuminated.

Typically, the output power level will

bounce down and then up and continue

bouncing until the output level is lowered

to the normal operating level (100%).

The red Overdrive LED DS1, the green

Module LED DS3, and the Enable LED

DS2 may blink on and off during the

bouncing of the output level; this is a

normal occurrence. The greater the

output level is above 110%, the larger

the bounce will be.

The RF output of the overdrive protection

board at J5 connects to J1 on (A2-A3)

the 3-way splitter board (1198-1607 or

1198-1608). The splitter board takes the

+34 dBm input and provides three +30

dBm outputs at J2, J3 and J4 of the (A2)

amplifier enclosure.

The three RF outputs connect to (A3) the

final amplifier enclosure. This enclosure

contains three (A3-A1, A3-A2 and A3-A3)

low-band amplifier boards (1198-1624 or

1198-1631). The RF signals connect to J1

on each of the low-band amplifier boards.

Each amplifier board provides

approximately 20 dB of gain.

The RF signal inputs to the amplifier

boards (+30 dBm) are amplified to +50

dBm outputs at J2. These outputs are

connected to J1, J2 and J3 on (A4-A1) a

3-way combiner board (1198-1625 or

1198-1626). The 3-way combiner takes

the three +50 dBm inputs and combines

them to form the 500-watt RF output at

J4 of the combiner that connects to J2,

the RF output jack of the tray.

The 3-way combiner board provides a

forward power sample at J5 and a

reflected output power sample at J8.

Both samples are fed through a low pass

filter board, low band (1198-1628)

before connecting to the AGC control

board. The forward output power sample

connects to J4 on (A13) the AGC control

board (1142-1601). The reflected output

power sample connects to J5 on (A13)

the AGC control board (1142-1601).

500-Watt VHF Low Band Transmitter Chapter 3, Circuit Descriptions

325A, Rev. 0 3-27

The AGC control board contains two

peak-detector networks that provide

detected outputs that are used for front

panel and remote meter indications of

forward and reflected output power

levels, the AGC detector voltage level,

and the VSWR cutback protection if the

reflected power level increases above the

preset level.

Two voltages, +48 VDC from the internal

switching power supply and +12 VDC

from the exciter control panel, are

needed for the operation of the tray. The

+12 VDC connects to J3-7 and J3-8 on

the rear of the tray; these are wired to

J8, pins 4 and 1, on (A13) the AGC

control board. The +12 VDC is connected

to U8, a +5 VDC regulator IC that

supplies the +5 VDC needed for the

operation of the front panel-mounted

LEDs.

The (A10) +48 VDC switching power

supply provides the +48 VDC to (A8) the

current metering board (1198-1609). The

current metering board distributes the

voltages through fuses to the amplifier

devices on the filter/amplifier, the low-

band driver board, the low-band amplifier

board, and the three final low-band

amplifier boards.

The fuses F1, F2 and F3 are 10-amp

fuses; F4 is an 8-amp fuse; and F6 and

F7 are 1-amp fuses. F5 is not used in this

configuration. There are two spare fuses,

one 1 amp and one 10 amp, located on

the top, right-hand side of the tray.

The 10 amp fuse F1 protects (A3-A1) one

of the low-band final amplifier board; 10

amp fuse F2 protects (A3-A2) another

low-band final amplifier board and the 10

amp fuse F3 protects (A3-A3) the last

low-band final amplifier board. The 8

amp fuse F4 protects (A2-A1) the low-

band VHF amplifier board. The fuse F5 is

not used in this configuration. The 1

amp fuse F6 protects (A1-A2) the

filter/amplifier board. The 1 amp Fuse F7

supplies +48 VDC to J8, pin 2, on the

AGC control board. The +48 VDC is

connected to regulator IC U7 that takes

the +48 VDC and provides a +12 VDC

output. The +12 VDC is used for the

operation of the AGC control board. The

+12 VDC is also connected through the

current metering board, jumpered from

TB1-5 to TB1-6, to the phase shifter

board, the filter/amplifier board, and the

overdrive protection board.

The current metering board also supplies

sample outputs of the operating currents

of the amplifier devices in the tray to the

front panel current meter. The meter in

the (I1) position reads the current for the

(A3-A1) low-band final amplifier board;

the meter in the (I2) position reads the

current for (A3-A2) the low-band final

amplifier board and the meter in the (I3)

position reads the current for the (A3-A3)

low-band final board. The meter in the

(I4) position reads the current for the

(A2-A1) low-band VHF amplifier board.

To read the desired current, place switch

S2 in the proper position, checking that

S1 is in the Current position. These

current readings can be used when

setting up the idling currents, no RF drive

applied, for the devices. (I1, I2, and I3)

are each set for 2 amps, while (I4) is set

for 3 amps, when the tray is a visual

amplifier, or a visual + aural amplifier,

and they are set for 1 amp when the tray

is an aural amplifier.

In the tray, the 230 VAC is applied

through jack J4 to terminal block TB1.

When CB1, the 15-amp, front panel-

mounted circuit breaker, is switched on,

the 230 VAC is distributed from TB1 to

(A11 and A12) two cooling fans, which

will begin to operate, and to (A10) the

switching power supply. There are two

surge suppressors, VR1 and VR2,

mounted on TB1 that provide protection

from transients or surges on the input AC

line. There are two other surge

suppressors, VR3 and VR4, mounted at

the input to the switching power supply

from each AC line to ground, that provide

protection from transients or surges on

the AC line.

500-Watt VHF Low Band Transmitter Chapter 3, Circuit Descriptions

325A, Rev. 0 3-28

The switching power supply only

operates when the power supply enable

control line, jack J3, pins 9 and 10, on

the rear of the tray, is shorted. The

enable is generated by the control panel

when the amplifier array is switched to

Operate. The enable is applied to (A5)

the AGC control board (1142-1601)

which, if there is no thermal fault,

connects the enable from J10, pins 6 and

7and then to J1-6 and J1-8 located on

the switching power supply assembly.

The green Enable LED DS2 on the front

panel will light, indicating that an enable

is present. If the amplifier array is in

Standby, or if a thermal fault occurs, the

AGC control board will not enable the

switching power supply. As a result, the

+48 VDC will be removed from the

amplifier modules and the front panel

Enable and Module Status LEDs will not

be lit.

The front panel meter (A9) uses the front

panel Selector switch S1 to monitor the

AGC Voltage, % Output Reflected Power,

% Forward Power, and the Switching

Power Supply Voltage (+48 VDC). The

meter in the AGC position will read

anywhere from .5 volts to 3 volts. The

meter is calibrated in the Power Supply

position using R86 on the AGC control

board. The % Output Power is calibrated

using R44 and the % Reflected Power is

calibrated using R53 on the AGC control

board. With S1 in the Current position,

S2 can be switched to read the idling

currents, no RF drive applied, of the

high-band amplifier boards. Typical

readings are an idling current of 2 amps

visual, or visual + aural, or 1 amp aural

in the amplifier assembly I1, I2, and I3,

positions and 3 amps in the I4 position.

The reflected power sample from the 3-

way combiner board through the low

pass filter board is fed back to the AGC

control board at J5. On the board, the

reflected sample is connected through

the detector circuit to VSWR cutback

circuit U13C. If the reflected power

increases above 20%, the output power

of the tray, as set by R60 (the VSWR

cutback on the AGC control board), will

be cut back to maintain a 20% reflected

output level. The red VSWR Cutback LED

DS4 on the front panel will remain lit

until the reflected level drops below 20%.

There are three thermal switches in the

tray for overtemperature protection. Two

of the thermal switches (A13 and A14)

are mounted on the rear of (A3) the

heatsink for the low-band final amplifier

boards and the third thermal switch

(A15) is mounted on the heatsink for

(A4-A1) the 3-way combiner board. The

thermal switches close when the heatsink

on which they are mounted reach a

temperature of 175° F. The closed

thermal switch causes the AGC control

board to remove the enable to the

switching power supply. This eliminates

the +48 VDC and lights the red

Overtemperature LED DS5 on the front

panel. The AGC control board will

extinguish the Module Status LED DS3.

3.3 (A9) Bandpass Filter Assembly

(Appendix C)

The RF input connects to the (A9)

constant impedance bandpass filter

assembly at jack J1 of (A1) a

splitter/combiner board (1092-1092).

The splitter/combiner board divides the

combined RF signal into two signals

before feeding it to jack J1 of (A2 and

A3) two 7-section bandpass filters with

traps. These filters screen the 6 MHz-

wide signal and attenuate the –4.5-MHz

and +9-MHz out-of-band products. These

signals connect to jacks J2 and J3 on

(A4) the other splitter/combiner board

(1092-1092), that recombines the two

signals before sending them on to jack J1

of (A5) the directional coupler module

(1092-1308). The directional coupler

module provides forward and reflected

samples to the exciter tray for metering

purposes.

The RF Output of the Transmitter, 500

Watts, is at A5-J2 of the bandpass filter

assembly.

UBS Axcera 325A 500-Watt VHF Low-band Television Transmitter User Manual Chapter 3

UBS-Axcera 500-Watt VHF Low-band Television Transmitter Chapter 3

Contents

Chapter 3

Navigation menu

Namespaces

Views

Navigation
