Vertu Quad Band Phone Constellation F Reference Manual

User manual Part 2

MESSAGES
English
24
To call your voice mailbox:
From the Home screen, press Menu » Messages » Voice
messages » Listen to voice msgs. Or, press and hold the 1
key on the number keypad.
To enter, search for or edit your voice mailbox number:
From the Home screen, press Menu » Messages » Voice
messages » Voice mailbox no.
Info messages
With the Info messages network service, you can receive messages
on various topics from your service provider.
To check availability, topics, and the relevant topic numbers,
contact your service provider.
Service messages
Your Vertu phone is able to receive service messages (pushed
messages) sent by your service provider. Service messages are
notifications (for example, news headlines), and they may contain a
text message or an address of a service.
When you receive a service message:
1. Press Show to display the message.
2. Or, press Exit to save the message to your inbox.
Service message settings
To update service message settings:
1. From the Home screen, press Menu » Messages » Message
settings » Service messages.
2. Scroll to one of the following options and then press Select:
Service messages » On or Off to set whether you want to
receive service messages
Message filter » On to set the phone to receive service
messages only from content authors approved by the service
provider
Autom. connection » On to set the phone to automatically
activate the browser from the stand-by mode when the phone has
received a service message. If you select Off, the phone activates
the browser only after you select Retrieve when the phone has
received a service message.
Bluetooth messages
Business cards, notes and messages sent by Bluetooth are
available in the Messages inbox.
Service commands
Use the service commands editor to enter and send service
requests (also known as USSD commands) to your service
provider. Contact your service provider for information about service
commands.
To send a service command:
1. From the Home screen, press Menu » Messages » Serv.
commands.
2. Use the NUMBER keys to enter a service request, for example an
activation command for a specific network service and press Send.
The first time you access your voice mailbox, you may be
required to enter a voice mailbox number, depending on your
operator.
CONTACTS
English
25
4 CONTACTS
Your Vertu phone Contacts list has capacity for up to 2,000 entries.
Contacts memory
Contact names and numbers can be stored in the phone memory or
on the SIM card, or both.
Phone memory
Each contact can contain up to five numbers and five text items, for
example a postal address, an e-mail address, an image and a
specific ring tone.
If you use the phone memory you can store more data and access
more functions, for example voice tags, than if you use the SIM card
memory.
SIM card memory
Contacts stored on your SIM card have one associated number.
The number of contacts and the length of names and numbers that
you can store on your SIM card is determined by your service
provider.
Selecting the memory type
Certain features, for example business cards and multiple numbers
associated with a contact, are only available when using the phone
memory. If you plan to make frequent use of these features, we
recommend that you set your Vertu phone to use the phone
memory. If you plan to transfer your SIM card from your Vertu phone
to other phones, we recommend that you set your Vertu phone to
use the SIM card memory.
To select a memory type:
1. From the Home screen, press Menu » Contacts » Settings »
Memory in use.
2. Scroll to one of the following options and then press Select:
Phone and SIM to save new contacts to the phone and display
contacts from the phone and SIM
Phone to save and display phone contacts
SIM card to save and display SIM card contacts.
A message confirms which memory you have selected.
Copying between memories
The copying feature allows you to copy names and numbers
between the phone memory and the SIM card memory.
1. From the Home screen, press Menu » Contacts » Copy
contacts.
2. Scroll to one of the following options and then press Select:
From SIM to phone to copy all information from the SIM card
memory to your Vertu phone memory
From phone to SIM to copy the name and the number from your
Vertu phone memory to the SIM card memory.
3. Press Yes to confirm your action, or press No to cancel.
Move between memories
The move feature enables you to move contact names and numbers
from the phone to the SIM card memory and vice versa.
1. From the Home screen, press Menu » Contacts » Move
contacts.
2. Scroll to one of the following options and then press Select:
From SIM to phone to move all information from the SIM card
memory to your Vertu phone memory. The information is no longer
held on your SIM card
From phone to SIM to move the name and the number from
your Vertu phone memory to the SIM card memory. The information
is no longer held in your Vertu phone memory
3. Press Yes to confirm your action, or press No to cancel.
Copying individual numbers
You can also copy individual directory numbers between the phone
memory and SIM card memory directly from the contacts list.
To copy individual numbers:
1. From the Home screen, press Menu » Contacts » Names.
2. If the contact name is not visible, press the first letter of the contact
name. The first name starting with that letter is highlighted. Scroll to
the desired name and press Details.
3. Press Options » Copy number.
4. Select Keep original and then press Select to keep the
contacts in both memories.
5. Or select Move original and then press Select to delete the
original information.
A message confirms that the number has been copied.
If you change the SIM card in your Vertu phone, the memory
type is automatically reset to phone.
If you are copying from phone memory to SIM card memory
and your Vertu phone memory contains more entries than
your SIM card can store, some of the entries will not be
copied.
CONTACTS
English
26
Check memory status
You can check your Vertu phone's memory to see how much
information is stored and how much free space is available.
To check the memory status:
1. From the Home screen, press Menu » Contacts » Settings »
Memory status.
2. Scroll to either Phone or SIM card and then press Select.
If Phone is selected the phone's contact free memory and used
memory is displayed as a percentage of the available memory
If SIM card is selected the absolute number of free contacts and
contacts in use for the SIM card is displayed.
3. Press Back to exit the screen.
Adding contacts
To add a contact:
1. From the Home screen, press Menu » Contacts » Add new.
2. Press Select and then use the NUMBER keys to enter the
contact’s first name. Scroll down to the next field.
3. Use the NUMBER keys to enter the contact’s last name. Scroll
down to the next field.
4. Use the NUMBER keys to enter the mobile phone number. Scroll
down to the next field.
5. Use the NUMBER keys to enter the home phone number. Scroll
down to the next field.
6. Use the NUMBER keys to enter the email address. Scroll down to
the next field.
7. Scroll right or left to open the image gallery and select an image to
associate with this contact.
8. Select Save to confirm your entry, or press Cancel.
A message confirms which memory you have saved the contact
details to.
Accessing contacts
There are several ways to access a contact, giving you flexibility to
use your Vertu phone in the way that suits you best.
A: Follow menu path
1. From the Home screen, press Menu » Contacts » Names.
2. Key in the first letter of the contact name.
3. The first name starting with that letter is highlighted.
4. Scroll to the desired name.
B: Go to command
If your contacts is one of the most used functions on your phone,
Names is displayed in the Go to shortcut menu (see “My
shortcuts” on page 36). You can use the left SELECTION key to
open the shortcut menu and display your contacts list:
1. From the Home screen, press Go to » Names.
2. Key in the first letter of the contact name.
3. The first name starting with that letter is highlighted.
4. Scroll to the desired name.
C: Selection key
If your right SELECTION key has been configured as Names (see
“My shortcuts” on page 36) you can use the following method to
display your contacts list:
1. From the Home screen, press the right SELECTION key.
2. Key in the first letter of the contact name.
3. The first name starting with that letter is highlighted.
4. Scroll to the desired name.
Deleting contacts
To delete a contact:
1. Select your contact name as in “Accessing contacts”.
2. Press Options » Delete» Delete contact.
3. Press Yes to confirm deletion.
A message confirms which contact you have deleted.
SIM card memory capacity is defined by your SIM card, not
by your Vertu phone. For more information contact your
service provider.
The following instructions use Method A to access your
contact name list however, the other methods can be used if
your SELECTION keys have been configured correctly.
CONTACTS
English
27
Contact number and text types
The first number added to a contact is automatically set as the
default number. When you select a contact to call or send a
message to, this default number is always used.
You can store different numbers for each contact from the following
types:
>General
>Work
>Mobile
>Home
>Fax
You can also store multimedia information, E-mail address and Web
address..
Multimedia information Tone, Image and Video can be stored.
Personal information, for example , Postal address, Company, User
ID, Job title, Birthday, Formal name, Nickname, Note can be
included.
Adding information to a contact
You can add phone numbers or text items to a contact.
To add a number to a contact:
1. Select your contact name as in “Accessing contacts”.
2. With the contact name highlighted, press Details.
3. Press Options.
4. Scroll to Add detail and press Select.
5. Scroll to Number and press Select.
6. Scroll to the type of number you want to add and then press Select.
7. Key in the phone number.
8. Press Next until the Save option appears. Press Save to confirm
the number, or press Options and scroll to Save. Press Select
to confirm.
A message confirms that the details have been saved to the phone
memory.
Alternatively,
1. Enter the telephone number and press Save.
2. Press Options.
3. Press Add to contact.
4. Scroll to the required contact and press Add.
5. Scroll to the type of number you want to add and then press Select.
A message confirms that the details have been saved to the phone
memory.
To add a text item to a contact:
1. Select your contact name as in “Accessing contacts”.
2. With the contact name highlighted, press Details.
3. Press Options.
4. Scroll to Add detail and then press Select.
5. Scroll to the type of text you want to add, for example, Web address
or Nickname, and then press Select.
6. Key in the text and press Next until the Save option appears. Press
Save to confirm the number, or press Options and scroll to
Save. Press Select to confirm.
A message confirms that the details have been saved to the phone
memory.
Changing the default number
The first number you add to a contact is automatically set as the
default number. If more than one number is added to an entry, for
example if the contact has a mobile phone number and an office
number, you can change the default number.
To change the default number:
1. Select your contact name as in “Accessing contacts”.
2. Press Details.
3. Scroll to the number to set as the default and press Options.
4. Scroll to Set as default and then press Select.
A message confirms that the default number has been set.
Setting the contacts view
Your Vertu phone can display your contacts in several different
ways:
Normal name list displays five contacts at a time
Name and number displays one contact with the default number
Name and image displays one contact with an associated
image.
To set the type of view:
1. From the Home screen, press Menu » Contacts » Settings »
Contacts view.
2. Scroll to the required view and then press Select.
A message confirms that the contacts view has been selected.
Setting the name display
To select whether the contact’s first or last name is displayed first:
1. From the Home screen, press Menu » Contacts » Settings »
Name display.
2. Scroll to the required view and then press Select.
A message confirms that the contacts view has been updated.
Setting the font size for the list of contacts
To set the font size for your messages, contacts and web pages:
1. From the Home screen, press Menu » Settings » Display »
Font size.
2. Scroll to Small font, Normal font or Large font and then
press OK.
A message confirms that the font size has been updated.
A contact can have duplicate number and text types, for
example two mobile numbers or two e-mail addresses.
CONTACTS
English
28
Contacts menu
You can use the options in the contacts menu to make a call, send
a text message and send a business card to anyone whose contact
information you have saved. Your phone automatically adds voice
tags to your contacts, and you can also assign numbers to the
speed dial list.
Searching and calling
To search for an entry and call the default number:
1. Select your contact name as in “Accessing contacts”.
2. Scroll to the required name and press the SEND key.
To search for an entry and call a number other than the default
number (using the phone memory only):
1. Select your contact name as in “Accessing contacts” and press
Details.
2. Scroll to the required number.
3. Press the SEND key or press Call to make the call.
Text messages
When you have a contact open, you can send them a text message
without returning to the main menu.
Sending text messages
To send a text message:
1. Select your contact name as in “Accessing contacts” and press
Details.
2. Scroll to the required number and press Options.
3. Scroll to Send message and then press Select.
4. With Message highlighted, press Select.
5. Key in the message and press Send.
Business cards
The business card function allows you to send and receive contact
information, via text message, multimedia or Bluetooth. This function
can be used with both the phone memory and the SIM card
memory, although the SIM card memory only allows you to send the
default number.
Sending business cards
To send a business card:
1. Select your contact name as in “Accessing contacts” and press
Details.
2. Press Options » Send business card.
3. Select the transmission method you want to use:
To send by multimedia message:
1. Scroll to Via multimedia and then press Select.
2. Refer to “Writing and sending multimedia messages” on page 21 to
complete and send your multimedia message.
To send by text message:
1. Scroll to Via text message and then press Select.
2. Refer to “Writing and sending text messages” on page 19 to
complete and send your text message.
To send by Bluetooth:
1. Scroll to Via Bluetooth and then press Select.
2. Scroll to the recipient’s device on the list and then press Select. A
message confirms that the business card has been sent.
Receiving business cards
When you receive a business card a message appears on the outer
display. An audible alert sounds if your Vertu phone is set up for
audible alerts.
When you open the phone a message tells you there is a business
card.
To display a received business card:
Press Show to display the business card.
To save a business card to your directory:
Press Save. A message confirms that you have saved the business
card.
To discard a business card without saving it:
Press Exit then press Yes to confirm. A message confirms that you
have discarded the business card.
Speed dialling
The Contacts menu enables you to compile a speed dial list very
quickly. You can have up to eight numbers saved in your speed dial
list. To dial a number, simply press and hold one of the NUMBER
keys.
The phone memory can store additional contact information
for example a person’s work and mobile phone numbers and
an e-mail address.
Speed dialling key number 1 is reserved for the voice
mailbox.
CONTACTS
English
29
Adding numbers to the speed dial list
To add a number to the speed dial list from within a contact:
1. Select your contact name as in “Accessing contacts” and press
Details.
2. Scroll to the required number and press Options.
3. Scroll to Speed dial and then press Select.
4. Scroll to an empty speed dial key, or one that you want to overwrite
(see below).
5. With the desired key highlighted, press Assign.
A message confirms which speed dial number key has been
assigned.
To add a number to the speed dial list using the speed dial menu:
1. From the Home screen, press Menu » Contacts » Speed
dials.
2. Scroll to the desired speed dial key and press Assign.
3. Key in the Phone number: or press Search to select it from the
Contacts list and then press OK.
4. Enter the First name: if creating a new contact.
5. Enter the Last name: of the contact.
6. Scroll to Save and press Select.
A message confirms which memory the contact has been saved to,
followed by a message that confirms which speed dial number key
has been assigned.
Changing speed dial numbers
To change speed dial numbers from within a contact:
1. Select your contact name as in “Accessing contacts” and press
Details.
2. Scroll to the required number and press Options.
3. Scroll to Speed dial and then press Select.
4. A message confirms that a speed dial already exists for the contact.
5. Scroll to the desired speed dial key and press Assign.
A message confirms which speed dial number key has been
assigned.
To change speed dial numbers using the speed dial menu:
1. From the Home screen, press Menu » Contacts » Speed
dials.
2. Scroll to the desired speed dial and press Options.
3. Scroll to Change and then press Select.
4. Enter the new Phone number: by keying it in or by pressing
Search and then selecting an existing number.
5. Enter the First name: if creating a new contact and then press
Next.
6. Enter the contact Last name: then press Next.
7. Scroll to Save and press Select.
A message confirms which memory the contact has been saved to,
and which speed dial number key has been assigned.
Deleting speed dial numbers
To delete speed dial numbers using the speed dial menu:
1. From the Home screen, press Menu » Contacts » Speed
dials.
2. Scroll to the desired speed dial and press Options.
3. Scroll to Delete and then press Select.
4. Press Yes to confirm.
A message confirms which speed dial number key has been
deleted.
Voice tags
Your Vertu phone can make a call to a contact using a voice tag.
Voice tags are automatically added to all contacts.Your Vertu phone
can store up to 2000 voice tags.
Using voice tags
To make a voice tag call:
1. Press and hold the down the right SELECTION key.
2. Speak the voice tag clearly into the microphone.
3. A list of possible matches is displayed briefly giving you a chance to
scroll to the correct one or Quit if it is not on the list.
4. After about 2 seconds your phone will automatically dial the number.
Playing voice tags
To play a voice tag from within a contact:
1. Select your contact name as in “Accessing contacts” and press
Details.
2. Scroll to the contact name within the details and press Options.
3. Scroll to Play voice tag and then press Select.
The voice tag is played.
Groups
Use groups to associate a contact name to a group. The group
name appears on the display when a member of a group calls you.
You can assign a different ringing tone to each group for easy
recognition of incoming calls.
Viewing groups
To view groups:
From the Home screen, press Menu » Contacts » Groups.
The Groups are displayed.
Creating a group
To create a contact group:
1. From the Home screen, press Menu » Contacts » Groups.
2. Press Add. If you have existing groups listed, press Options and
then Add new group.
3. Add a Group name.
4. Add a Group image and tone (if required).
5. Press Save.
A message confirms that the group has been added.
This method can add contact details and assign a speed dial
number key at the same time. Very short names do not work well for voice tags. Use longer
unique names, for example “Vertu Concierge Service.”
CONTACTS
English
30
Adding contacts to a group
To open a group and link contacts to it:
1. From the Home screen, press Menu » Contacts » Groups.
2. Scroll to the desired group and press View.
3. Press Add to display your contacts list.
4. Scroll to the desired name and then press Select. Repeat for each
contact to be added to the group.
A message confirms that the contact has been added to the group.
Editing group names
To edit group names:
1. From the Home screen, press Menu » Contacts » Groups.
2. With the group name to be edited highlighted, press Options.
3. With Group details highlighted, press Select.
4. With Group name highlighted, press Select.
5. Key in the new name for the group and then press OK.
A message confirms that the group has been renamed.
Deleting contacts from a group
To delete contacts from a group:
1. From the Home screen, press Menu » Contacts » Groups.
2. Scroll to the desired group and press View.
3. Scroll through the group members to the desired contact and press
Options.
4. With Remove member highlighted, press Select.
5. Press Yes to confirm.
A message confirms that the contact has been removed from the
group.
Adding group details to a contact
To open a contact and add group details:
1. Select your contact name as in “Accessing contacts” and press
Details.
2. Press Options.
3. Scroll to Add to group and then press Select.
4. Scroll to the desired group and then press Select.
A message confirms that the contact has been added to the group.
Deleting group details from a contact
To delete group details from a contact:
1. Select your contact name as in “Accessing contacts” and press
Details.
2. Scroll to the group name and press Options.
3. Scroll to Remove from group and then press Select.
4. Press Yes to confirm.
A message confirms that the contact has been removed from the
group.
Setting group ringing tones
All groups initially have a default ringing tone. To set a distinctive
ringing tone for each group:
1. From the Home screen, press Menu » Contacts » Groups.
2. Scroll to the desired group and press Options » Group details.
3. Scroll to Group tone:.
4. Press Options » Change tone and select your ringing tone from
Default / Open Gallery / Tone downloads.
5. Press Save.
A message confirms that the group ringing tone has been selected.
Options on contact numbers
Add detail
Scroll to one of the following categories and press Select to add
more details:
>Number
>Internet
>Multimedia
>Personal info
Voice call
Press Select to call the contact.
Send message
Select a type of message and then press Select. See the chapter
“MESSAGES” on page 16 for further instructions on sending
messages.
Add image
Press Select to open the Gallery and select an image. See “Adding
contacts” on page 26.
Edit
1. Scroll to Edit and then press Select.
2. Press Clear as many times as necessary to delete the number to
the left of the cursor.
3. Key in the new number.
4. Press Save to save the new number.
Delete
1. Scroll to Delete and then press Select.
2. Scroll to either Delete number to remove the number but retain
the other contact details or Delete contact to remove all of the
contact details and then press Select.
3. Press Yes to confirm the deletion.
Set as default
Highlight a number in the list and press Set as default. A
message confirms that number has been set as default.
The default ringing tone for the caller groups is the ringing
tone set up in the profiles menu.
CONTACTS
English
31
Change type
Allows you to redefine the number type as General, Mobile,
Home, Office or Fax. Press Select and a message will be
displayed to confirm the change.
Copy number
1. Select Keep original or Move original.
2. Press Select.
3. A message confirms that the number has been copied.
Send business card
Select a transmission method and then press Select. See
“Business cards” on page 28 for further instructions on sending
business cards.
Add to group
Press Select to add the contact to a group. “Adding contacts to a
group” on page 30.
Use number
This makes a copy of the selected number allowing you to save it
under a new contact record.
Press Save and then use the NUMBER keys to enter a name for
the new contact.
Speed dial
Select a speed dial key and press Assign. A message confirms
which speed dial key has been assigned.
CALL HISTORY
English
32
5 CALL HISTORY
The Call history feature allows you to view information about calls
that you have missed, received and made. You can also view
information (volume of data / session duration) for packet data
transfer and number of messages sent and received (both SMS and
Multimedia).
The call history
The call history stores information about your most recent missed,
received, and dialled calls. When the list is full, the most recent call
replaces the oldest.
To ensure that the call history is able to store your received and
missed call information, your service provider must support caller
ID, and it must be enabled. If the caller’s number is not available, for
example if the caller withheld their number or the network did not
transmit the number, No number appears in the calls list.
The call history can only store information about calls that are
actually received by your Vertu phone. If you do not have a signal or
if your calls are blocked, any incoming calls will not be stored.
Viewing the call history
To view recent call information:
1. From the Home screen, press Menu » Call history » All calls.
2. The calls will be listed in chronological order.
Viewing missed calls
To view details of calls that have been missed:
From the Home screen, press Menu » Call history » Missed
calls.
Viewing received calls
To view details of calls that have been successfully received by your
Vertu phone:
From the Home screen, press Menu » Call history » Received
calls.
Viewing dialled numbers
To view details of numbers that have been dialled from your Vertu
phone:
From the Home screen, press Menu » Call history » Dialled
numbers.
Viewing message recipients
To view details of contacts to whom messages have been sent:
From the Home screen, press Menu » Call history » Msg.
recipients.
Clearing log lists
To clear information from your Vertu phone’s log
1. From the Home screen, press Menu » Call history » Clear log
lists.
2. Scroll to one of the options and then press Select:
All call lists removes all information from your Vertu phone log
Missed calls removes details from the Missed calls log
Received calls removes details from the Received calls log
Dialled numbers removes details from the Dialled numbers log
Message recipients removes details from the Message
recipients log.
Viewing call duration
To view information about the duration of calls made and received
by your Vertu phone:
1. From the Home screen, press Menu » Call history » Call
duration.
2. The following information will be available for examination:
Last call shows the length of the last call regardless of type
Received calls shows the total combined duration of all received
calls
Dialled calls shows the total combined duration of all dialled calls
All calls shows the total combined duration of all calls to and from
your Vertu phone
3. Clear timers it will be necessary to enter your security code to
complete this operation. See “SECURITY” on page 13.
Viewing the packet data counter
To view approximate information about the volume of data sent and
received:
1. From the Home screen, press Menu » Call history » Data
counter.
2. The following information will be available for examination:
Sent in last session is the amount of data in bytes, sent in the
last transmission
Received in last sess. is the amount of data in bytes, received
in the last transmission
All sent data is the total amount of data in bytes, sent in all
transmissions
All received data is the total amount of data in bytes, received in
all transmissions
This operation will take immediate effect without requiring
confirmation. Once log lists have been cleared the information
cannot be recovered.
CALL HISTORY
English
33
3. Clear counters resets all of the counters. It will be necessary to
enter your security code to complete this operation. See
“SECURITY” on page 13.
Viewing the data timer
To view approximate information about the duration of sessions over
GPRS:
1. From the Home screen, press Menu » Call history » Data
timer.
2. The following information will be available:
Duration of last sess. shows the length of time spent on the
last session
Duration of all sess. shows the combined length of time spent
on all sessions
3. Clear timers resets all of the timers. It will be necessary to enter
your security code to complete this operation. See “SECURITY” on
page 13.
Viewing the message log
To view details of messages that have been sent and received by
your Vertu phone:
1. From the Home screen, press Menu » Call history » Message
log.
2. The following information will be available:
Sent text messages shows number of text messages and parts
sent
Sent MMS msgs. shows number of multimedia messages sent
Sent e-mails shows number of email messages sent
Received text msgs. shows number of text messages and
parts received
Received MMS msgs. shows number of multimedia messages
received
Downloaded e-mails shows number of downloaded messages
to My mailbox.
3. Clear all counters it will be necessary to enter your security
code to complete this operation. See “SECURITY” on page 13.
Viewing the positioning log
This displays a list of the GPS fixes you have made.
From the Home screen, press Menu » Call history » Positioning.
Viewing the sync log
Sync log shows statistics on data you have transferred while
synchronising your Vertu phone.
To view the sync log, from the Home screen, press Menu » Call
history » Sync log.
SETTINGS
English
34
6 SETTINGS
The Settings menu enables you to control the core functionality of
your Vertu phone. You can define personalised themes, configure
the inner display, adjust the time and date settings, set up personal
shortcuts, configure various connectivity preferences, modify call
and phone settings, set up security features and restore your factory
default settings.
Refer to “SECURITY” on page 13 for more information about the
security settings.
Date and time
Time management
This where you can customise the dual time clock settings. The dual
time clock is available when you are travelling. The larger analogue
clock shows the local time and the smaller digital clock shows the
home time.
Select a time source
1. From the Home screen, press Menu » Settings » Date and
time » Time management » Clock mode
2. Scroll to one of the following options and then press Select to
customise the time source:
Accurate displays dual time when you are travelling. Set up the
home location as below and the travel clock displays automatically.
Single fixed zone (only available for manual set-up) enables you
to select a location for the large clock.
Dual fixed zone (only available for manual set-up) enables you to
select a location for the small clock.
Select a home location
From the Home screen, press Menu » Settings » Date and
time » Time management » Home location
This enables you to set up a home location for manual and
automatic time keeping.
Select an alternate location
From the Home screen, press Menu » Settings » Date and time »
Time management » Alternate location
This enables you to set up a second location for manual time
keeping.
Date and time settings
This enables you to manually set the date and time in the home
location. You can only do this if Accurate time is not selected.
1. From the Home screen, press Menu » Settings » Date and
time » Date & time settings
2. Scroll to one of the following options and then press Select to
customise the time settings:
Date: enables you to use the NUMBER keys to set the date on the
phone
Time: enables you to use the NUMBER keys to set the time on the
clock
3. Scroll down and select Save to confirm your settings.
Date and time format
To adjust the date format:
1. From the Home screen, press Menu » Settings » Date and
time » Date and time format » Date.
2. Scroll to one of the following options and then press Select to
customise the time settings:
Date format sets how the date will be displayed
Date separator sets whether spaces, dots or slashes are used.
To adjust the time format:
1. From the Home screen, press Menu » Settings » Date and
time » Date and time format » Time.
Time format enables you to set the time in 24-hour or 12-hour
format
Profiles
Profiles are an easy way to control the most common groups of
settings, for example audible and vibrating alerts. Activating an
alternative profile changes all the associated settings.
Profiles define how your Vertu phone reacts when you receive a call
or a message, how your NUMBER keys sound when you press a
key, and more.
Activating a profile
You can change your profile at any time to ensure that your Vertu
phone’s alerts are appropriate to your surroundings.
Timed profiles can be used to prevent missed calls. For example,
you attend an event that requires your Vertu phone be set to Silent
before the event starts, but you forget to return it to General until
long after the event. During this time, you might miss several calls
because the ringing tone is silent. The Flight profile cannot be
timed.
With the timed profile feature, you can set a profile to expire after
any length of time up to 24 hours. When the timed profile expires,
your Vertu phone automatically returns to the original profile.
To change your current profile from the Home screen:
1. Press the power key once briefly.
2. Scroll to the desired profile and then press Select.
To change your current profile using the menus:
1. From the Home screen, press Menu » Settings » Profiles.
2. Scroll to the desired profile and then press Select.
3. With Activate highlighted, press Select.
SETTINGS
English
35
To set a time limit for the selected profile:
1. From the Home screen, press Menu » Settings » Profiles.
2. Scroll to the desired profile and then press Select.
3. Scroll to Timed and then press Select.
4. Use the NUMBER keys or scroll to enter the time you want your new
profile selection to end and then press OK.
Personalising a profile
You can customise the default profiles to adjust your Vertu phone’s
characteristics so they best suit your own preferences and situation.
For the silent profile, you can only change the vibrate setting.
To personalise a standard profile:
1. From the Home screen, press Menu » Settings » Profiles.
2. Scroll to the profile that you want to customise and then press
Select.
3. Scroll to Personalise and then press Select.
4. Scroll to one of the following options and then press Select to
customise the profile:
Incoming call alert: selects how the phone notifies you of an
incoming call, the available options are:
Ringing plays the ringing tone
Ascending makes the volume of the ringing tone increase the
longer the call is unanswered
Ring once plays only one cycle of the ringing tone
Beep once plays a single beep
Off causes no ringing tone for an incoming call
Ringing tone: enables you to select the ringing tone for incoming
calls
Ringing volume: sets the volume of your ringing tone
(use + and -)
Incoming call video: uses a video as a ringing tone for received
calls
Vibrating alert: turns the vibrating alert On or Off
Message alert tone: selects the tone for received messages
E-mail alert tone: selects the tone for received e-mails
IM alert tone: selects the tone for received instant messages
Keypad tones: sets the volume of your keypad tones (use + and
-)
Application tones: turns the tones for applications On or Off
Alert for: to define which caller groups you want your Vertu phone
to alert you for when you receive a call from someone belonging to a
specified group
If you receive a call from someone who is not included in a specified
caller group, an information note appears on the display, but your
Vertu phone remains silent. See “Groups” on page 29 for more
information.
Profile name: enables you to rename the selected profile (all of
the preset profiles can be renamed except for General). Use the
NUMBER keys to enter the new name.
Press Save when you have made your changes.
Themes
A theme defines the image that is used as a background on all of
your Vertu phone menus.
To select a theme:
1. From the Home screen, press Menu » Settings » Themes.
2. Scroll to the desired theme and press Apply.
3. Press Options at any time while scrolling through the themes to
display the following options:
Details displays name, file size and creation date information
Type of view displays how the folders and files appear on the
screen
Sort enables you to select the order in which files and folders are
displayed (by name, date, format or size).
Tones
The tones settings menu allows you to personalise the tone settings
of the selected active profile on your Vertu phone.
To personalise the tone settings:
1. From the Home screen, press Menu » Settings » To ne s .
2. Scroll to the tone type that you want to customise and then press
Change.
3. Select a ringing tone from the list.
Display
To personalise your Vertu phone’s inner display and other features:
1. From the Home screen, press Menu » Settings » Display.
2. Scroll to one of the following options and then press Select:
Glowing light controls whether the light at the bottom of the
phone is On or Off
>When the phone is in stand-by mode, the light flashes
slowly
>When the phone is in stand-by mode with a missed call
or text message, the light flashes quickly
>When the phone is in stand-by mode and charging the
light remains on constantly
Wallpaper enables you to select a background image for the inner
display. You can either use a theme wallpaper or select another
image. You can also turn the travel wallpaper on or off.
Home screen font col. lets you change the font colour of the
date and time in the Home screen. This is displayed only if Clock
display iis Off (see below)
Notification details lets you select to show or hide details, such
as contact information in both missed call and message received
notifications.
Font sizeselect Small font, Normal font or Large font.
Cell info display displays the local area code on the Home
screen.
Clock display controls whether the clock on the inner display is
shown or not. You may prefer to see your wallpaper graphic without
the clock being there.
Vertu feeds enables you to switch the Vertu feeds on or off on the
Home screen.
SETTINGS
English
36
My shortcuts
With personal shortcuts you get quick access from the Home
screen to frequently used functions of your Vertu phone.
If the left SELECTION key is Go to, select Go to » Options and
select from the following options to personalise your Go to menu:
Select options - to add or to remove a function
Organise - to rearrange the functions on your personal shortcut
list.
Auto sorting on - dynamically displays the menu options you use
most often at the top of the list
The auto sorting feature must be disabled for you to use the
Select options and Organise functions.
Left selection key
To select a function for the left SELECTION key:
1. From the Home screen, press Menu » Settings » My
shortcuts » Left selection key.
2. Scroll to the desired function and then press Select.
Right selection key
To select a function for the right SELECTION key:
1. From the Home screen, press Menu » Settings » My
shortcuts » Right selection key.
2. Scroll to the desired function and then press Select.
4-way scroll key
To select functions for the 4-way scroll key:
1. From the Home screen, press Menu » Settings » My
shortcuts » Navigation key.
2. Select the key to be changed. Please note that the UP key is
reserved for Vertu feeds but can be changed.
3. Press Change.
4. Scroll to the required shortcut from the list and press Select.
Connectivity
You can connect your Vertu phone to a compatible device using
Bluetooth wireless technology or a USB data cable (CA-101V)
connection. You can also define the settings for internet dial-up
connections.
Bluetooth wireless technology
Your Vertu phone is compliant with Bluetooth Specification 2.0.
You can use Bluetooth car kits, perform data transfer and use your
Vertu phone as a modem.
To ensure interoperability between other devices supporting
Bluetooth technology, use Vertu approved enhancements for this
model. Check with the manufacturers of other devices to determine
their compatibility with this device.
There may be restrictions on using Bluetooth technology in some
locations. Check with your local authorities or service provider.
Features using Bluetooth technology, or allowing such features to
run in the background while using other features, increase the
demand on battery power and reduce the battery life.
Bluetooth technology allows you to connect the phone to a
compatible Bluetooth device within 10 meters (32 feet). Since
devices using Bluetooth technology communicate using radio
waves, your Vertu phone and the other devices do not need to be in
direct line-of-sight, although the connection can be subject to
interference from obstructions for example walls or from other
electronic devices.
Bluetooth settings
To define how your Vertu phone is recognised by other Bluetooth
devices:
1. From the Home screen, press Menu » Settings » Connectivity
» Bluetooth.
2. Scroll to one of the options and then press Select:
Bluetooth enables you to switch your bluetooth connection on
and off
Conn. to audio access. enables you to connect your phone
with an audio accessory and the device that you want to connect
Paired devices enables you to add a new Bluetooth device and
view existing devices already paired with your phone
Active devices checks which Bluetooth connection is currently
active
My phone’s visibility enables you to operate the phone in
hidden mode to avoid malicious software
My phone’s name enables you to define the name that you want
your Vertu phone to be recognised by on the network.
Bluetooth wireless connection
To make a Bluetooth wireless connection:
1. From the Home screen, press Menu » Settings » Connectivity
» Bluetooth.
2. Scroll to Paired devices and press Select.
3. Select a device from the list of available devices or scroll to Add
new device and press Select.
Your Vertu phone will automatically turn Bluetooth on if necessary
and search for available devices.
4. Scroll to the device to connect to and press Add.
5. Enter a passcode if necessary and press OK.
A message is displayed when the device is connected successfully
and the paired device is added to the Paired devices list.
To check which Bluetooth connection is currently active, scroll to
Active devices and then press Select.
Select Options to access available options depending on the status of
the device and the Bluetooth connection.
GPS
This is where you can set up a connection to another GPS device
that you want to use, and set preferences for Internet Assisted
GPS.
Bluetooth driver compatibility information is available in the
Vertu PC Suite help.
Do not accept Bluetooth connectivity from sources you do
not trust. Alternatively, switch off the Bluetooth function.
This will not affect other functions of your Vertu phone.
SETTINGS
English
37
USB data cable
You can use the micro-USB data cable to transfer data between the
phone and a compatible computer or a printer supporting
PictBridge. You can also use the micro-USB data cable with Vertu
PC suite.
To change the USB mode, select Menu » Settings »
Connectivity » USB data cable.
To connect your phone using the micro-USB data cable:
1. Connect the data cable. A message appears on the display Select
USB mode:
2. Select from the following options:
PC Suite - to use the phone to interact with applications on a
computer that has Vertu PC suite installed.
Printing & media - to use the phone with a PictBridge
compatible printer, or to connect the phone to a PC to synchronise it
with Windows Media Player.
Data storage - to connect to a computer that does not have Vertu
software and use the phone as data storage.
Ask on conn.. - to reconfirm every time you connect a USB cable.
Internet connectivity
With your Vertu phone you can take advantage of HSPA (3.5G) and
WCDMA (3G) packet data services to surf the internet and
download and upload files. You will also find that MMS messaging,
e-mail and computer dial-up are faster using these services.
For availability and subscription to data services contact your
service provider or network operator.
Using your Vertu phone as a modem, you can connect your PC to
the internet even if you cannot connect using your regular ethernet
connection.
1. Install Vertu PC Suite (supplied on the CD-ROM) on your computer.
2. Connect your Vertu phone to your computer using Bluetooth or a
micro-USB cable.
3. Open Vertu PC Suite and click on Connect to the Internet. The One
Touch Access application will get you connected to the Internet.
Call settings
You can personalise the way your Vertu phone behaves during a
call by using the call settings.
Call divert
The call divert feature redirects your incoming voice and video calls
to another number, for example your voice mailbox number.
When a call is diverted your Vertu phone does not give any
indication of an incoming call. The call divert feature is managed by
your service operator and is not phone specific. The call divert
feature may remain active even if your SIM card is not currently in a
phone.
To manage your call divert settings:
1. From the Home screen, press Menu » Settings » Call » Call
divert.
2. Scroll to one of the divert options:
All voice calls forwards all calls to the number you specify
If busy forwards all calls when you are in a call
If not answered forwards all calls to another number when you
do not answer. You can also set a delay before forwarding takes
place
If out of reach forwards all calls when your Vertu phone is turned
off or out of the coverage area
If not available forwards all calls when you do not answer, your
Vertu phone is busy or turned off, or out of the coverage area. You
can also set a delay before forwarding takes place
No call diverts cancels all call diversions.
3. Press Select:
Activate sets up the divert. Use the NUMBER keys to enter the
divert number or select a contact and then press OK
Cancel cancels the divert
Check status displays the current status of the divert. A
progress indicator appears, followed by an information note
indicating whether the divert is active and to which number.
Open fold to answer
This function enables you to answer an incoming call by
opening the fold.
To change the fold open to answer setting:
1. From the Home screen, press Menu » Settings » Call » Answ.
if fold opened.
2. Select On or Off and then press OK.
Anykey answer
Anykey answer allows you to answer an incoming call by briefly
pressing any key except the POWER key, SELECTION and END
keys.
To change the anykey answer setting:
1. From the Home screen, press Menu » Settings » Call » Anykey
answer.
2. Select On to enable Anykey answer, or Off to disable it and then
press OK.
Automatic redial
Occasionally, your network may experience heavy traffic, or the
called party is busy and you might not be able to make a call. With
automatic redial activated, your Vertu phone redials the number up
to 10 times, and notifies you once the network is available.
To change the automatic redial setting:
1. From the Home screen, press Menu » Settings » Call »
Automatic redial.
2. Select On to enable automatic redial, or Off to disable it and then
press OK.
Voice clarity
This feature enhances speech intelligibility especially in noisy
environments.
To change the voice clarity setting:
1. From the Home screen, press Menu » Settings » Call » Voice
clarity.
Cancelling all call diversions may affect your ability to receive
voice mail messages. Some service providers may not allow
cancelling of all diversions. Contact your service provider for
specific details.
SETTINGS
English
38
2. Select Active to enable voice clarity, or Inactive to disable it and
then press OK.
Speed dialling
Single key speed dialling enables you to quickly dial a number by
pressing and holding a single key.
To activate the speed dialling feature:
1. From the Home screen, press Menu » Settings » Call » Speed
dialling.
2. Select On to enable speed dialling, or Off to disable it and then
press OK.
To change the speed dial settings for your contacts, see “Speed
dialling” on page 28.
Call waiting
Call waiting notifies you of an incoming call while you are in another
call. You can accept, reject, or ignore the incoming call. Contact
your service provider for more details.
To change the call waiting setting:
1. From the Home screen, press Menu » Settings » Call » Call
waiting.
2. Scroll to one of the options and then press Select:
Activate enables call waiting
Cancel cancels call waiting
Check status displays whether the option is active and for which
type of call.
To use the call waiting feature:
1. When you have a call in progress and you receive an incoming call,
you will hear an audible alert and the display indicates that another
call is waiting. Press the SEND key to answer the call. The person
you were speaking to is put on hold. Call waiting may not work
correctly if If busy is set.
2. Press the SEND key to swap between the calls. A confirmation
message is displayed. The person on hold becomes the active call,
and the other person is put on hold.
3. Press the END key to end the active call. A confirmation message is
displayed and the other call becomes active.
4. Press Options then scroll to End all calls and then press
Select to end all calls.
Call duration display
This displays the call duration during each call.
To change the display setting:
From the Home screen, press Menu » Settings » Call » Call
duration display.
Select On or Off and then press OK.
Summary after call
Your Vertu phone can display the time spent on a call.
To change the call summary setting:
1. From the Home screen, press Menu » Settings » Call »
Summary after call.
2. Select On to enable summary after call, or Off to disable it and then
press OK.
Send my caller ID
Shows your phone number to the person you are calling.
To change the caller ID setting:
1. From the Home screen, press Menu » Settings » Call » Send
my caller ID.
2. Select Yes to enable caller ID, No to disable it, or Set by
networkto use the setting agreed with your service provider and
then press OK.
Phone settings
You can personalise the following options on your Vertu phone
using this menu.
Language settings
1. From the Home screen, press Menu » Settings » Phone »
Language settings.
2. Scroll to one of the options and then press Select.
Phone language enables you to set the display language of your
Vertu phone. If you select Automatic, the phone selects the
language according to the information on the SIM card
SIM language enables you to select the USIM card language
Memory status
1. From the Home screen, press Menu » Settings » Phone »
Memory status.
2. Scroll through the options to see how much of your Vertu phone’s
memory is being used to store media, messages and
applications and how much free space is available.
Automatic keyguard
To set the keys of your Vertu phone to lock automatically after a
preset time delay when the phone is in the stand-by mode and no
function of the phone has been used:
1. From the Home screen, press Menu » Settings » Phone »
Automatic keyguard.
2. Select On, and use the NUMBER keys to enter the time delay.
Security keyguard
To set your Vertu phone to ask for the security code when you
unlock the keyguard:
1. From the Home screen, press Menu » Settings » Phone »
Security keyguard.
2. Enter your Security code (see “Security code” on page 13) and
select On.
Voice recognition
You can call contacts and carry out phone functions by speaking a
voice command.
Voice commands are language-dependent. Select Menu »
Settings » Phone » Voice recognition » Recognition lang.
and your language before using voice commands.
From the Home screen, press Menu » Settings » Phone » Voice
recognition » Voice recog. training to train the voice
recognition of your phone to your voice.
When the keyguard is on, calls still may be possible to the
official emergency number programmed into your device.
SETTINGS
English
39
To activate a voice command for a function:
1. From the Home screen, press Menu » Settings » Phone »
Voice recognition » Voice commands.
2. Select a feature and a subsequent function.
To activate a deactivated voice tag, select Add.
To play the activated voice command, select Play.
To manage the voice commands, scroll to a function, and select
Options and from the following:
Edit to rename the voice command
Remove to deactivate the voice command
Add all to activate all voice commands
Restore all to deactivate voice commands for all functions in the
voice commands list
To use voice commands, see “Voice dialling” on page 11.
Flight query
You can deactivate all radio frequency functionality and still have
access to offline games, calendar and phone numbers. Use Flight
mode in areas sensitive to radio emission, on board aircraft and in
hospitals.
Your Vertu phone will ask if you wish to switch to Flight mode when
you switch the phone on. To activate or deactivate Flight mode
query:
1. From the Home screen, press Menu » Settings » Phone »
Flight query.
2. Scroll to On or Off and then press Select.
In Flight mode you can make an emergency call. Enter the
emergency number, press the CALL key and select Yes when
asked if you want to exit the Flight mode profile. The phone attempts
to make the emergency call and then automatically reverts to
General profile when the call has ended.
To manually activate or deactivate Flight mode profile:
1. From the Home screen, press Menu » Settings » Profiles »
Flight » Activate or Personalise.
To deactivate the Flight mode, select any other profile.
Phone updates
Enables you to update your phone’s software if there is an update
available.
1. From the Home screen, press Menu » Settings » Phone »
Phone updates.
2. Select one of the following options:
Current softw. details displays the software version in your
phone
Downl. phone softw. enables new phone software to be
downloaded
Install softw. update enables newly downloaded software to
be installed on your phone
Software update provider displays your software update
provider
Automatic SW update check enables your phone to
automatically check for updates Every month, Every 3
months or Never.
Network mode
Enables you to switch between 3G and GSM networks and dual
mode - 3G+GSM.
To change the network mode:
1. From the Home screen press Menu » Settings » Phone »
Network mode.
2. Choose from 3G+GSM, GSM or 3Gand press OK.
Operator selection
This is useful when you are travelling and need to select a new
network operator. You can select one manually or your Vertu phone
will select one automatically. See “Set up manual roaming” on
page 52.
To change your operator selection setting:
1. From the Home screen, press Menu » Settings » Phone »
Operator selection.
2. Scroll to one of the options and then press Select:
Manual displays all the locally available networks. Select the
one you want to use.
Automatic selects the default network for the area you are in.
Start-up tone
To select whether or not your Vertu phone plays a tone when the
phone is switched on:
1. From the Home screen, press Menu » Settings » Phone »
Start-up tone.
2. Select On or Off and then press OK.
SIM services
Your SIM card may provide additional services. You can access this
menu only if it is supported by your SIM card. The name and
contents of the menu depend on the available services.
For availability and information on using SIM card services, contact
your SIM card vendor. This may be the service provider, network
operator, or other vendor.
To set the phone to show you the confirmation messages sent
between your Vertu phone and the network when you are using the
SIM services:
1. From the Home screen, press Menu » Settings » Phone »
Confirm SIM actions.
2. With Yes highlighted, press Select.
Accessories
This menu is shown only if the phone is or has been connected to a
compatible mobile accessory, such as a charger or headset.
1. From the Home screen, press Menu » Settings » Accessories.
2. Scroll to one of the options and then press Select (available
options will depend upon the accessory selected):
You can disable 3G from the Go to menu to maximise battery
performance. 3G enables faster data downloading and is a
necessity if you are roaming in Japan.
This option is shown only if supported by your SIM card.
Accessing these services may involve sending messages or
making a phone call for which you may be charged.
SETTINGS
English
40
Default profile enables you to select the profile that you want to
be automatically activated when you connect to the selected
accessory
Automatic answer sets the phone to answer an incoming call
automatically after 5 seconds. If Incoming call alert is set to Beep
once or Off, automatic answer is off
Lights sets the lights permanently On or select Automatic to set
the lights on for 15 seconds after a key press.
Configuration
You can configure your Vertu phone with settings that are required
for certain services to function correctly. These services include
multimedia messaging, synchronisation, e-mail, streaming and
browser. Use the Order Settings link from your CD-ROM to take
you directly to the appropriate page on the Vertu web site to obtain
the settings for your phone.
1. From the Home screen, press Menu » Settings »
Configuration.
2. Scroll to one of the options and then press Select:
Web config. settings only the configurations that support the
browsing service are shown. Select a service provider, Default, or
Personal configuration for browsing.
Default config. sett. displays the service providers saved in the
phone. Scroll to a service provider, and select Details to view the
applications that the configuration settings of this service provider
support. To set the configuration settings of that service provider as
default settings, press Options » Set as default. To delete
configuration settings, select Delete.
Activ. def. in all apps. activates the default configuration
settings for supported applications
Preferred access pt. displays the saved access points. Scroll
to an access point and press Options. With Details highlighted,
press Select to view the name of the service provider, data bearer,
and packet data access point or GSM dial-up number for that
access point
Connect to support downloads the configuration settings from
your service provider if this is supported by the service provider
Personal config. sett. enables you to add new personal
accounts for various services, and to activate or delete them. To add
a new personal account if you have not added any, select Add,
otherwise, press Options and with Add new highlighted, press
Select. Select the required service type and then press Select.
Use the NUMBER keys to enter each of the required parameters.
The parameters differ according to the selected service type. To
delete or activate a personal account, select it, press Options,
select either Delete or Activate and then press Select.
Security
Your Vertu phone includes security options for the phone, SIM card,
memory and calls.
To configure your security settings:
1. From the Home screen, press Menu » Settings » Security.
2. Scroll to one of the following options and then press Select:
PIN code request lets you select whether a code is required
when switching on your phone. The SIM card may require that the
code is always asked for
Call barring service restricts incoming calls and outgoing calls.
A barring password is required
Closed user group specifies a group of people you can call and
who can call you
Security level sets the security code whenever a new SIM card
is inserted into the phone
Access codes changes the security codes that protect the phone
and memory. Change either the Create security code,
Change PIN code, Change PIN2 code or the Change
barring pass.
Code in use selects whether the PIN code is active
PIN2 code request selects whether the PIN2 code is required
when using a specific phone feature which is protected by the PIN2
code. Some SIM cards do not allow the code request to be turned
off
Authority certificates displays the list of authority certificates
downloaded into your phone
User certificates displays the list of user certificates
downloaded into your phone
Security module sett. See “Security module” on page 14.
Workshop reset
To restore your Vertu phone’s original settings:
1. From the Home screen, press Menu » Settings » Workshop
reset » Restore settings only
2. Use the NUMBER keys to enter the security code.
To restore all your Vertu phone’s original settings and delete user
data, e.g. phonebook entries:
1. From the Home screen, press Menu » Settings » Workshop
reset » Restore all.
Use the NUMBER keys to enter the security code.
Sync and backup
To synchronise or backup your Vertu phone data with another
device:
Select Menu » Settings » Sync and backup and from the
following options.
Phone switch to synchronise or copy selected data between
your phone and another phone using Bluetooth
Create backup to create a backup of selected data
Restore backup to select a backup file and restore it to the
phone. Select Options » Details for information about the
selected backup file
Data transfer to synchronise or copy selected data between
your phone and another device, PC or network server (network
service).
Due to the complexity of entering all of the settings manually,
it is strongly recommended that you use the order settings
link from your CD-ROM to take you directly to the appropriate
page on the Vertu website to obtain the settings for your Vertu
phone.
When security features that restrict calls are in use (such as
call barring, closed user group, and fixed dialling) calls are
still possible to the official emergency number programmed
into your device.
Data you have entered or downloaded, for example names
and phone numbers saved in Contacts, are not deleted.
SETTINGS
English
41
Data transfer
Synchronise your calendar, contacts data, and notes with another
compatible device, for example a compatible PC, or a remote
Internet server (network service).
Your Vertu phone allows data transfer with a compatible PC or
another compatible device when using the phone without a SIM
card. Note that when you use the phone without a SIM card, some
functions appear dimmed in the menus and cannot be used.
Synchronising with a remote Internet server is not possible without
a SIM card.
Data transfer with a compatible device
Bluetooth wireless technology can be used for synchronisation. The
other device should be in the stand-by mode.
To start data transfer:
1. From the Home screen, press Menu » Settings » Sync and
backup » Data transfer.
2. Scroll to the required entry in the Partner list (other than Server
sync or PC synchronisation) and then press Select.
According to the settings, the selected data is copied or
synchronised. The other device also must be activated for receiving
data.
Synchronise from a compatible PC
Before you synchronise data from calendar, notes, and contacts
with a PC, you must install the Vertu PC Suite software on a
compatible PC. Use Bluetooth wireless technology, or a USB data
cable for the synchronisation, and start the synchronisation from the
PC.
Synchronise from a server
To use a remote Internet server, you must subscribe to a
synchronisation service, e.g. Vertu Fortress (see “Vertu Fortress” on
page 51). For more information and the settings required for this
service, contact your service provider. You may receive the settings
as a configuration message.
If you have saved data on the remote Internet server, to synchronise
your Vertu phone, start the synchronisation from your phone:
1. From the Home screen, press Menu » Settings » Sync and
backup » Data transfer » Server sync.
2. Depending on the settings, select Initialising
synchronisation or Initialising copy.
Synchronising for the first time or after an interrupted
synchronisation may take up to 30 minutes to complete, if the
contacts or calendar are full.
ADDITIONS
English
42
7 ADDITIONS
Your Vertu phone has a multimedia player with which you can view,
play, and download files, such as images, audio, video, and
animated images. You can also view compatible streaming videos
from a network server (network service).
Games
Your Vertu phone contains games and applications.
To launch a game:
1. From the Home screen, press Menu » Additions » Games.
2. Scroll to the desired game, and press Open.
To download an application:
Your phone supports J2ME Java applications. Make sure that the
application is compatible with your phone before downloading it.
You can download new Java applications and games using the
Vertu Application Installer from Vertu PC Suite. You can also
download and install applications over-the-air.
Calculator
The calculator in your Vertu phone adds, subtracts, multiplies,
divides, calculates the square and the square root.
To perform a calculation:
1. From the Home screen, press Menu » Additions » Calculator.
2. When 0 is displayed, enter the first number in the calculation.
3. Use the 4-way scrollkey to select the function you want to
perform.
4. Enter the second number.
5. Press the = sign to display the result.
To start a new calculation select Clear.
Media player
Your Vertu phone includes a media player for listening to music
tracks, recordings or other MP3, MP4, AAC, eAAC+ or Windows
Media.
With the media player you can download, view, and play compatible
audio and video files in a variety of formats.
Your Vertu phone can play music tracks, recordings or other MP3 or
AAC sound files that you have transferred to the phone with the
Audio Manager application (part of Vertu PC Suite), BT or USB
cable or web.
Music files stored in a folder in the phone memory or on the memory
card, will automatically be detected and added to the default track
list.
Playing the music tracks
To play the music tracks:
1. From the Home screen, press Menu » Additions » Media
player.
2. Scroll to one of the following options to find the track you want to
listen to:
All songs lists all songs stored on your phone
Playlists shows all playlists you have created and stored on your
phone
Artists lists the songs by artist name
Albums lists the songs by album title
Genres lists the songs by genre type
Videos lists all video files stored on your phone.
3. Press Open to open the file. Press Play to start the track.
4. Use the following commands to control the media player:
Press the centre select key to play or pause
Move the 4-way scroll key up to open the media player menu
and scroll up
Move the 4-way scroll key down to open the media player
menu and scroll down
Move the 4-way scroll key left to go to previous track
Move the 4-way scroll key right to go to next track
5. Press Options to access the media player options (see “Media
player settings,” below).
6. Press the END key to close the media player.
To stop the media player, press the STOP key.
If music is still playing after you exit the media player, you can stop
the media player by pressing and holding the END key.
When you open the media player menu, the details of the first track
on the default track list are shown.
Only install and use applications and other software from
sources that offer adequate security and protection
against harmful software.
For the availability of different services, pricing, and tariffs,
contact your service provider.
Your device may have some bookmarks loaded for sites not
affiliated with Vertu. Vertu does not warrant or endorse these
sites. If you choose to access them, you should take the same
precautions, for security or content, as you would with any
Internet site.
Press # to enter a decimal point.
Press * to display more functions.
Warning! Listen to music at a moderate level. Continuous
exposure to high volume may damage your hearing.
ADDITIONS
English
43
Media player settings
To change the media player settings:
1. From the Home screen, press Menu » Additions » Media
player.
2. Press Options from the media player menu and scroll to one of the
following:
Downloads to access tracks from the following options:
Bookmarks to open the web bookmarks
Go to addressto enter the address of a mobile Internet service
and then press OK
Streaming settings to set the connection settings for the
media service. Contact your service provider for information about
connection settings. You may receive the streaming settings as a
connection settings message from the Vertu web site for your
service provider.
Update library to update your music library with your latest
downloads
Music libr. details to view data on the number of songs stored
on your phone, memory used and last updated date.
3. Press Options while a track is playing and select one of the
following:
Go to Media menu to return to the main media player menu
Now playing to show details of the current track
Settings to access the following features:
Equaliser to select from Normal, Pop, Jazz, Classical or
Set %N and Set %N for your own custom settings while the
track is playing
Shuffle to play a random choice of your stored tracks
Repeat to repeat a track
Downloads to access tracks via the web
Mute audio to mute the current track
Web page to access a Web page associated with the currently
played track. Dimmed if no Web page is available
Play via Bluetooth connects to a Bluetooth audio accessory
Equaliser
You can control the sound quality when using the music player by
amplifying or diminishing frequency bands.
Change equaliser settings
To change the equaliser settings:
1. From the Home screen, press Menu » Additions » Equaliser.
2. Scroll to an equaliser set and press Activate. Choose from
Normal, Pop, Jazz, Classical or Set %N and Set %N for
your own custom settings.
A message confirms your equaliser setting.
View equaliser settings
To view equaliser settings:
1. From the Home screen, press Menu » Additions » Equaliser.
2. Scroll to an equaliser set and press Options.
3. Scroll to View and press Select.
Edit equaliser settings
To edit equaliser settings:
1. From the Home screen, press Menu » Additions » Equaliser.
2. Scroll to an equaliser set and press Options.
3. Scroll to Edit and press Select.
4. Scroll up or down to adjust each equaliser channel.
5. Scroll left or right to change channels.
6. Press Save to save your changes. A message appears to confirm
your new settings.
Press Activate to select your new equaliser set. A message confirms
your equaliser setting.
Rename equaliser settings
To rename equaliser settings:
1. From the Home screen, press Menu » Additions » Equaliser.
2. Scroll to an equaliser set and press Options.
3. Scroll to Rename and press Select.
4. Use the NUMBER keys to enter a new name.
Press OK to confirm your changes. A message confirms your new
equaliser set name.
Video recorder
See “Video recorder” on page 56.
Voice recorder
You can record speech or an active call, and save the recordings in
the gallery. This is useful, for example, when recording a name and
phone number to write down later.
Record sound
To make a voice recording:
1. From the Home screen, press Menu » Additions » Voice
recorder.
2. To start the recording, with the RECORD button highlighted, press
Select and then record your message.
3. To stop the recording, with the STOP button highlighted, press
Select. The recording is saved in the Recordings folder of the
Media memory by default.
Record a phone call
To record a phone call:
1. During a call, press Options.
2. Scroll to Record and then press Select. While the call is being
recorded, all parties to the call can hear a beeping sound every five
seconds.
3. To stop recording, with the STOP button highlighted, press Select.
The recording is saved in the Recordings folder of the gallery.
When recording a call, hold the phone in the normal position near to
your ear.
Not all settings can be edited.
Not all settings can be edited.
ADDITIONS
English
44
Voice recorder options
Immediately before or after a recording, press Options to view the
following:
Play last recorded to listen to the latest recording
Send last recorded to attach the recording to a Multimedia or Audio
message or to send via Bluetooth
Recordings list to see the list of recordings in Gallery
Select memory to choose recording file destination. Choose
from Media memory or Other folder.
Notes
You can write yourself notes as reminders, but these are not
associated with the calendar and do not alert you with an alarm.
Creating notes
To create a note:
1. From the Home screen, press Menu » Additions » Notes.
2. Press Add.
3. Use the NUMBER keys to write the note and press Save.
A message confirms that the note is saved.
Viewing notes
To view a note:
1. From the Home screen, press Menu » Additions » Notes.
2. Scroll to the note you want to view and press View.
Editing notes
To edit a note:
1. From the Home screen, press Menu » Additions » Notes.
2. Scroll to the note you want to edit and press View » Edit.
3. Use the NUMBER keys to make the required changes to the note
and press Save.
Sending notes
You can send a note to another phone using Bluetooth or the
messaging service or convert it to a message.
To send a note as a text message:
1. From the Home screen, press Menu » Additions » Notes.
2. Scroll to the required note and press Options.
3. Press Send note » Send as message.
4. Press OK to send the note.
A message confirms that the note is being sent.
To send a note using Bluetooth:
1. From the Home screen, press Menu » Additions » Notes.
2. Scroll to the required note and press Options.
3. Press Send note » Via Bluetooth.
4. Highlight the device you want to send the note to, and then press
Select.
A message confirms that the note is being sent.
Deleting notes
You can delete notes one at a time or all at once.
To delete one note:
1. From the Home screen, press Menu » Additions » Notes.
2. Scroll to the required note and press Options » Delete.
3. Press Yes to confirm deletion.
4. A message confirms that the note has been deleted.
To delete all notes:
1. From the Home screen, press Menu » Additions » Notes »
Options » Delete all notes.
2. Press Yes to confirm deletion.
A message confirms that all of the notes have been deleted.
Collection
Preloaded Java applications are available here. Applications
downloaded from third-party sites are also stored here.
Stopwatch
You can measure time, take intermediate times, or take lap times
using the Stopwatch.
To open the stopwatch:
From the Home screen, press Menu » Additions » Stopwatch
Select from the following options:
Split timing - to take intermediate times. Use the Options key to
save, view and delete split times.
Lap timing - to take lap times. Use the Options key to save, view
and delete lap times.
CALENDAR
English
45
8 CALENDAR
Calendar
Your Vertu phone has a calendar where you can add notes about
meetings, calls, birthdays, memos and reminders. You can also
create a To-do list and check your memory status from the Options
menu.
Opening the calendar
To open the calendar:
1. From the Home screen, press Menu » Calendar.
2. The current month is displayed, with today highlighted. Press the 4-
WAY SCROLL key to move to different dates.
When there is a note associated with a date, the date will be
highlighted.
Calendar settings
On the Settings menu you can change the following
characteristics of the calendar:
>Date & time settings
>Select the Default view
>Select the day that Week starts on
>Select a Calendar tone
>Select how often to Auto-delete notes
Date and time settings
To adjust the date and time settings if you are not using the
Accurate time settings:
1. From the Home screen, press Menu » Calendar
2. Press Options and scroll down to Settings.
3. Press Select and Date & time settings.
4. Scroll to one of the following options and then press Select to
customise the time settings:
Date: enables you to use the NUMBER keys to set the date on the
phone
Time: enables you to use the NUMBER keys to set the time on the
clock
Time zone: enables you to set the valid offset from GMT
Daylight saving: enables you to select between Wintertime or
Summertime (+1 or +2 hours) daylight saving periods.
5. Scroll down and select Save to confirm your settings.
Selecting the default view
You can configure the calendar on your Vertu phone to default to
month view or week view.
To set the default view:
1. From the Home screen, press Menu » Calendar » Options »
Settings » Default view.
2. Highlight the required view and then press Select.
A message confirms which default view has been selected.
Selecting when the week starts
The calendar can display the week starting on Saturday, Sunday or
Monday.
To select a day that the week starts on:
1. From the Home screen, press Menu » Calendar » Options »
Settings » Week starts on.
2. Highlight the required day and then press Select.
A message confirms which day the week starts on.
Selecting a calendar tone
To select a tone for the calendar:
1. From the Home screen, press Menu » Calendar » Options »
Settings » Calendar tone.
2. Select Standard for standard tone or Open Gallery to choose
from a tone stored in the Gallery folders.
3. Press Select to confirm the new settings.
Calendar Notes
Notes enables you to make a note associated to a date and time.
To make a note:
1. From the Home screen, press Menu » Calendar.
2. Scroll to the date you want to make a note for.
3. Press Options » Make a note.
4. Select from the following options:
Reminder - enables you to use the NUMBER keys to enter a title
for the reminder and set an alarm.
Meeting - enables you to use the NUMBER keys to enter details
about a meeting: subject, location, start and finish date and times and
set an alarm
Call - enables you to use the NUMBER keys to enter details about
a phone call: phone number, name and time details and set an alarm
Birthday - enables you to use the NUMBER keys to enter details
about a birthday: name, year of birth, and set an alarm
Anniversary - enables you to use the NUMBER keys to enter
details about an anniversary: name, occasion, date, year and set an
alarm
Memo - enables you to use the NUMBER keys to enter details
about a memo: subject, start date, end date and set an alarm
CALENDAR
English
46
Viewing notes
If there are notes for a day, the date will be highlighted. You can
view notes for a particular day or for the whole week.
To view the notes for a day:
1. From the Home screen, press Menu » Calendar.
2. With the required day highlighted, press View.
3. The notes for that day will be displayed.
Viewing notes for a week
To view notes for a week:
1. From the Home screen, press Menu » Calendar.
2. Scroll to a day in the week of interest.
3. Press Options » Week view.
4. The week is displayed showing any notes.
Editing notes
To edit a note:
1. From the Home screen, press Menu » Calendar.
2. With the required day highlighted, press View. The notes for that
day will be displayed.
3. Press Options » Edit to open the note for editing.
4. Edit the details as required and press Save.
Moving notes
You can move a note to a different date and time.
To move a note:
1. From the Home screen, press Menu » Calendar.
2. With the required day highlighted, press View.
3. Press Options » Move.
4. Enter a new date and time and then press OK.
5. Set an alarm if required and then press OK.
A message confirms that the note has been moved.
Sending a note
To send a note using the calendar:
1. From the Home screen, press Menu » Calendar.
2. With the required day highlighted, press View.
3. Press Options » Send note » Via calendar.
4. Key in the phone number or press Search to use the Contacts
list.
5. Press OK to send the note.
Copying notes
You can copy a note to another date and time.
To copy a note:
1. From the Home screen, press Menu » Calendar.
2. With the required day highlighted, press View.
3. Press Options » Copy.
4. Key in the new date and then press OK.
5. Key in the new time and then press OK.
A message confirms that the note has been copied.
Auto-deleting notes
Your Vertu phone can delete notes automatically. Notes can be
deleted after one day, one week or one month.
To auto-delete notes:
1. From the Home screen, press Menu » Calendar » Options »
Settings » Auto-delete notes.
2. Highlight the required frequency, or Never and then press Select.
A message confirms whether auto-delete is activated or not.
To-do list
The To-do list enables you to create notes for tasks you have to do.
You can send a to-do note to another phone as a text message, or
as a multimedia message or by Bluetooth. You can also save a to-do
note to the calendar.
Opening the to-do list
To open the to-do list:
From the Home screen, press Menu » Calendar » Options » Go
to to-do list.
Any to-do notes will be displayed.
Creating a to-do list
To create a to-do list:
1. From the Home screen, press Menu » Calendar » Options »
Go to to-do list.
2. Press Add.
3. Use the NUMBER keys to enter Subject: details.
4. Select High, Medium or Low priority using the left and right 4-
WAY SCROLL keys. The priority determines where the to-do note
will be displayed in your list of to-do notes. High priority notes are
displayed at the top of the list, whilst low priority notes are displayed
at the bottom of the list.
5. Use the NUMBER keys to enter the due date and time and set an
alarm if required.
6. Then select Save.
A message confirms that the To-do note is saved.
To change the priority, view the to-do note and select the deadline
option. You can also mark notes as done, edit and delete them.
Deleting a to-do list
To delete a to-do list
1. From the Home screen, press Menu » Calendar » Options »
Go to to-do list.
2. Scroll to the desired to-do note and press Options.
3. Scroll to Delete or Delete all notes and then press Select.
4. Press Yes to confirm.
A message confirms the deletion.
If you mark your to-do notes as completed when you have
finished your tasks, you can select Delete done notes to
delete all the completed to-do notes at once.
ALARM CLOCK
English
47
9 ALARM CLOCK
Your Vertu phone contains a simple to use alarm clock.
If you are using the accurate time clock feature, when you are
travelling the phone automatically adjusts to the local time and any
preset alarms sound at the usual time wherever you are. You do not
need to reset your alarm clock at your destination.
The alarm will sound even if your Vertu phone is switched off.
Setting the alarm
To set the alarm:
1. From the Home screen, press Menu » Alarm clock.
2. Use the NUMBER keys to enter the time you want the alarm to
sound.
3. Press Options and use the 4-way scroll key to set the alarm
details.
Alarm use the 4-way scroll key to toggle the alarm on and off.
Alarm time: displays the time the alarm is set for and can only be
changed as above
Repeat: use the 4-way scroll key to toggle the repeat feature on
and off. Setting the repeat feature to On means that the alarm will
sound every day at the specified time
Repeat days: press Options and Change to select the days
on which you want the alarm to repeat. This option is only available if
Repeat: is switched On
Alarm tone: use the 4-way scroll key to select an alarm tone
Standard is the default alarm tone
Open Gallery enables you to select a tone from the gallery files
on your Vertu phone
Tone downloads enables you to select and download a tone
from the website
Snooze time-out: use the NUMBER keys to enter the snooze
time-out in minutes
4. Select Save when complete.
A message confirms that the alarm is on, and a red marker is visible
on the clock at the alarm time.
Cancelling the alarm
To cancel the alarm:
1. From the Home screen, press Menu » Alarm clock » Tu rn
alarm off.
A message confirms that the alarm has been turned off..
Turning off the alarm
To turn off a ringing alarm:
1. When the alarm sounds press the stop icon on the outer display.
2. If your Vertu phone is switched off when the alarm sounds, a
message asks if you want to switch the phone on. Press Yes to
switch the phone on or press No to leave the phone switched off.
Activating the snooze function
To activate the snooze function:
1. When the alarm sounds turn the phone over onto its front. If the
phone is already on its front, rotate it through 360 degrees.
2. The alarm will sound again after the Snooze time-out duration defined
when setting the alarm.
3. If you leave the alarm ringing, it will ring for approximately one minute
and then go into snooze mode.
Do not press Yes when wireless phone use is prohibited or
when it may cause interference or danger.
WEB
English
48
10 WEB
You can access various Web services on your Vertu phone.
Check the availability of these services, pricing, tariffs, and
instructions with your service provider.
Automatically setting up Web browsing
Depending on which service provider you use, your Vertu phone
might already have Web settings installed so you might be able to
browse the Web straight away. If you cannot connect to the Web,
please contact Vertu Concierge or visit www.vertu.com on your
computer and download your settings.
Check the availability of these services, pricing, tariffs, and
instructions with your service provider.
Manually setting up Web browsing
First, ensure that the correct configuration settings of the service
that you want to use are activated.
To select the settings for connecting to the service:
1. From the Home screen, press Menu » Web » Web settings »
Configuration sett.
Only the configurations that support the browsing service are shown.
Select a service provider or Default for browsing.
2. Scroll to Account and highlight a browsing service account
contained in the active configuration settings and then press
Select.
Vertu Mobile
Vertu Mobile is Vertu’s presence on the Mobile Internet, tailored for
handsets and carefully designed for being accessed on the go.
To open Vertu mobile:
From the Home screen, press Menu » Web » Vertu Mobile.
The following options are available:
>Discover contains the latest Vertu news
>Where to buy enables you to find an authorised Vertu retailer
wherever you are in the world
>About Vertu contains information about Vertu
>Recommend us enables you to enter a friends mobile phone
number and they will receive a text message providing a link to
Vertu Mobile.
Go to address
To enter a web page address:
1. From the Home screen, press Menu » Web » Go to address.
2. Use the NUMBER keys to enter the service URL.
Browse pages
While you are browsing the Internet, the function of the phone keys
may vary. Follow the text labels on the phone display and see below
for more information.
is shown on the top left of the display during browsing. If you
are on a 3G network you can call and browse at the same time.
However on other networks if you receive a call or a text message
while browsing, indicates that the Internet connection is
suspended while you receive the call or text message. When the
call or text message ends, your Vertu phone reconnects the
browsing session.
Browse with phone keys
To browse through the page, scroll in any direction.
To select a highlighted item, press the CALL key, or press Select.
To enter letters and numbers, press the NUMBER keys. To enter
special characters, press *.
Options while browsing
Press Options to open a new list of options for browsing:
Press Home to return to your start page
Press Bookmarks to access the list of bookmarks
Press Go to address to enter a specific web page address
Press Add bookmark to save the page as a bookmark
Press Navigation to view browsing history, downloads or to
reload the current page
Press This page to show the list of options for the active page
Press Too ls to show a list of other options
Press Settings to view or change browsing settings. See
“Settings” on page 48.
Press Quit to disconnect from a service.
The service provider may also offer other options.
Receive a bookmark
When you have received an address that is sent as a bookmark, the
message 1 bookmark received is displayed. The received
bookmark is saved automatically to Received files. To view it,
press Show and select Bookmarks.
Settings
Appearance settings
1. From the Home screen, press Menu » Web » Web settings.
2. Scroll to Display and then press Select.
3. Scroll to one of the following options and then press Select:
Important: Use only services that you trust and that offer
adequate security and protection against harmful software.
Important: Use only services that you trust and that offer
adequate security and protection against harmful software.
WEB
English
49
Press Show images and No to hide pictures on the page. This
can speed up the browsing of pages that contain a lot of pictures
Press Show page title and No to hide the page title on the page.
This saves screen space.
Minimap zooms out while you are scrolling to enable you to
navigate the web more easily. If you select Off, while scrolling the
pages are displayed in full size view.
Press WML text wrapping and On to set the text to continue on
the next line on the display. If you select Off, the text is abbreviated
Scroll to General and press Select.
4. Backstep. opens hist. enables you to open the visual history
when you go back a page.
Press Auto-fill and Enable to enable your Vertu phone to
complete fields for you
Press Unicode (UTF-8) addr. and On to set the phone to send
a URL as a UTF-8 encoding. You may need this setting when you
access a Web page created in foreign language
Press Content encoding to select the encoding for the browser
page content
Press JavaScript and Enable to enable the Java scripts.
Setting the font size for web pages
To set the font size for your messages, contacts and web pages:
1. From the Home screen, press Menu » Settings » Display »
Font size.
2. Scroll to Small font, Normal font or Large font and then
press OK.
A message confirms that the font size has been updated.
Security settings
Cookies
Cookies are parcels of information used by Web servers to
differentiate a user and their preferences when navigating a website
or services such as online shopping. Cookies are saved in the
cache memory of your Vertu phone. Cookies are saved until you
clear the cache memory.
To allow or prevent the phone from receiving cookies, while browsing:
1. From the Home screen, press Menu » Web » Web settings »
Security » Cookies.
2. Select Allow or Reject.
Unsecure content
To set an alert when a secure page contains an unsecure item.
1. From the Home screen, press Menu » Web » Web settings »
Security » Alert for unsec. mode.
2. Press Yes to set the phone to alert when a secure page contains an
unsecure item.
These alerts do not guarantee a secure connection.
Scripts over secure connection
You can select whether to allow the running of scripts from a secure
page. The phone supports WML scripts.
From the Home screen, press Menu » Web » Web settings »
Security » WMLscript » Allow or Reject.
Downloading sett. enables you to allow or disallow software and
configuration updates in the home network.
Configuration sett. only the configurations that support the
browsing service are shown. Select a service provider or default for
browsing.
Clear the cache
A cache is a memory location that is used to store data temporarily.
If you have tried to access or have accessed confidential
information requiring passwords, empty the cache after each use.
The information or services you have accessed is stored in the
cache.
To empty the cache:
From the Home screen, press Menu » Web » Clear the cache.
Browser security
Security features may be required for some services, for example
online banking or shopping. For such connections you need
security certificates and possibly a security module, which may be
available on your SIM card. For more information, contact your
service provider.
Security module
The security module improves security services for applications
requiring a browser connection, and allows you to use a digital
signature. The security module may contain certificates as well as
private and public keys. The certificates are saved in the security
module by the service provider.
To view or change the security module settings:
From the Home screen, press Menu » Settings » Security »
Security module settings.
Certificates
The existence of a certificate does not offer any protection by itself;
the certificate manager must contain correct, authentic, or trusted
certificates for increased security to be available.
Before changing any certificate settings, you must make sure that
you really trust the owner of the certificate and that the certificate
really belongs to the listed owner.
There are two kinds of certificates:
>server certificates
>user certificates.
You may receive these certificates from your service provider. User
certificates may also be saved in the security module by the service
provider.
Important: Even if the use of certificates makes the risks
involved in remote connections and software installation
considerably smaller, they must be used correctly in order to
benefit from increased security.

Navigation menu
