Wistron MS2119 Laptop with 2.4 GHz 802.11 User Manual WireLAN

Wistron Corporation Laptop with 2.4 GHz 802.11 WireLAN

WLAN Manual Part 2

5
Important: Turn off the wireless function when inside an airplane to prevent
interference with navigation systems.
WireLAN.book Page 5 Tuesday, February 5, 2002 4:02 PM
6
Card Specifications
Physical Specifications
Note: Although the PCI Card may still operate in the range of -20° to 70° C,
operation outside the range of 0° to 55° C may no longer be according to
specifications.
Power Characteristics
Form Factor MINI PCI Card
Dimensions (LxWxH) 59.75x 50.95 x 4.5 mm
Weight 15 gram (PC Card)
Temperature & Humidity
Operation 5° to 35° C maximum humidity 95%
Transit -20° to 70° C 15 to 95% (no condensation allowed)
Storage -10° to 60° C 10 to 90% (no condensation allowed)
Doze Mode 30mA
Receive Mode 230 mA
Transmit Mode 330 mA
Power Supply 3.3 V ± 0.2 V
WireLAN.book Page 6 Tuesday, February 5, 2002 4:02 PM
7
Networking Characteristics
Radio Characteristics
Radio Characteristics of the MPCI3A-20/R WIRELESS LAN CARD may vary:
•According to the country where the product was purchased.
•According to the type of product that was purchased.
Wireless communication is often subject to local radio regulations. Although the
MPCI3A-20/R WIRELESS LAN CARD has been designed for operation in the
license-free 2.4 GHz band, local radio regulations may impose a number of
limitations to the use of wireless communication equipment.
To comply with such regulations, MPCI3A-20/R WIRELESS LAN CARD is marketed
with dedicated channel-sets with a number of factory-programmed channels
identified by the following acronyms:
•ETS for countries that adhere to the regulations as defined by the European
Telecommunications Standards Institute (ETSI),
•FCC for countries that adhere to the regulations as defined by the US Federal
Communications Commission (FCC),
•FR for France, and
•JP for Japan.
Data Rate High 11 Mb/s
Medium 5.5 Mb/s
Standard 2 Mb/s
Low 1 Mb/s
The cards use an automatic Transmit Rate Select mechanism.
WireLAN.book Page 7 Tuesday, February 5, 2002 4:02 PM
8
Radio Characteristic Specifications
R-F Frequency Band 2.4 GHz (2400-2500 MHz)
Number of selectable
sub-channels North America (FCC) 11
Europe (ETS) 11
France (FR) 2
Japan (JP) 11
Other Countries: 11
Modulation
Technique Direct Sequence Spread Spectrum
CCK for High & Medium Transmit Rate
DQPSK for Standard Transmit Rate
DBPSK for Low Transmit Rate
Spreading 11-chip Barker Sequence
Bit Error Rate (BER) Better than 10-5
Nominal Output
Power 15 dBm
Range (100 bytes
User Data) /
Transmit Rate
High Speed
11 Mb/s Medium
Speed
5.5 Mb/s
Standard
Speed
2 Mb/s
Low Speed
1 Mb/s
Open Office
Environment 160 m
(525 ft.) 270 m
(885 ft.) 400 m
(1300 ft.) 550 m
(1750 ft.)
Semi-Open Office
Environment 50 m
(165 ft.) 70 m
(230 ft.) 90 m
(300 ft.) 115 m
(375 ft.)
Closed Office 25 m
(80 ft.) 35 m
(115 ft.) 40 m
(130 ft.) 50 m
(165 ft.)
Receiver Sensitivity -83 dBm -87 dBm -91 dBm -94 dBm
Delay Spread (at
FER of <1%) 65 ns 225 ns 400 ns 500 ns
WireLAN.book Page 8 Tuesday, February 5, 2002 4:02 PM
9
Supported Frequency Sub-bands
Subject to the radio regulations that apply in your country, your MPCI3A-20/R
WIRELESS LAN CARD may support a different set of 2.4 GHz channels (see
table below).
Consult your authorized sales office for information about the radio regulations
that apply in your country
MPCI3A-20/R IEEE 802.11 Channels Sets
Frequency Range 2400-2500 MHza
a. Numbers printed in bold are the factory-set default channels.
Channels ID FCC ETSI France Japan
1 2412 2412 - 2412
2 2417 2417 - 2417
3 2422 2422 - 2422
4 2427 2427 - 2427
5 2432 2432 - 2432
6 2437 2437 - 2437
7 2442 2442 - 2442
8 2447 2447 - 2447
9 2452 2452 - 2452
10 2457 2457 2457 2457
11 2462 2462 2462 2462
WireLAN.book Page 9 Tuesday, February 5, 2002 4:02 PM
10
WireLAN.book Page 10 Tuesday, February 5, 2002 4:02 PM
